deVOL THE VINEYARD TABLE User manual

THE
VINEYARD TABLE
CONTENTS, ASSEMBLY GUIDE & SPECIFICATION

CONTENTS
ASSEMBLY GUIDE
11 x pine table top (with 1 pivot bracket pre-attached) 62 x M6 bolts
21 x oak frame 72 x cross dowels
31 x oak pivot bracket 84 x oak plugs (spares inc.)
42 x oak feet 91 x Allen key
54 x woodscrews 10 1 x Torx key
TOOLS REQUIRED: In addition to the parts & ttings provided you will also need a at head screwdriver
and a mallet or hammer to successfully assemble this table.
Please read these instructions in full before attempting to assemble this product. We recommend that you retain this
document for future reference.
1. Remove contents from packaging and check that all components listed above are present.
2. Begin by inserting the cross dowels (7) into the holes located at the base of the frame legs (2). Use a at head
screwdriver to turn the cross dowels (7) so that the grooves are vertical.
3. Slot the feet (4) onto the frame legs (2), secure in place by inserting the M6 bolts (6) through the underside of the feet
(4). Use the Allen key (9) provided to tighten. Ensure both bolts are securely fastened.
4. Lay the table top (1) face down on a clean soft surface. Hold the frame (2) upside down and slot one of the oak dowels
into the pre-attached pivot bracket on the underside of the table top (1).
123
4 x 2
x 2x 4
x 2 x 4
5
7
6
9
810

5. Ask someone to hold the frame (2) upright or gently lower it to rest on one side. Slot the loose pivot bracket (3) onto
the opposite dowel on the frame (2).
6. Check that the holes on the pivot bracket (3) align with the holes on the underside of the table top (1). Secure in place
using the woodscrews (5). Use the Torx key (10) provided to tighten. Ensure all xings are securely fastened.
7. Insert the oak plugs (8) over the woodscrews (5). Gently tap into position with a mallet or hammer, you can refer to
the plugs on the pre-attached pivot bracket to ensure they are positioned correctly.
8. The table is now fully assembled. Take care when turning it back over.
2.
4.
6.
3.
5.
7.

Cotes Mill, Nottingham Road, Cotes, Loughborough, LE12 5TL | www.devolkitchens.co.uk
v12.22
For any questions about your table or the assembly process, please contact our customer service team (quoting your original
order number if possible) and we will aim to respond as soon as possible. Please note that our customer service team is
based in the UK and is normally active Monday - Friday, 8:30am-5pm (excluding bank holidays).
[e-mail] 01509 606011
SPECIFICATION
This document relates to the following product: VT22-1100
Dimensions ø 1100 h 695 mm Folded Dimensions w 1100 h 1197 d 495 mm
Materials & Finish Top - Reclaimed pine, tinted wax nish with a low sheen
Frame - Oak, tinted wax nish with a low sheen
©
This table should be stored indoors and kept out of rain.
Clean with mild soap and a damp cloth, slight colour transfer when cleaning is normal. Ensure to wipe up any spills promptly
to avoid discoloration. Harsh cleaners and abrasive pads may damage the surface and remove the nish.
Small scratches to the wood will settle in naturally over time and the nish can be reapplied if it begins to wear and you
would like to refresh it. Please contact our customer service team for advice before attempting any repairs.
All of our furniture is made using responsibly sourced natural timbers. This table is handcrafted in our Leicestershire
workshops and has been designed and made to last a lifetime.
Please recycle your packaging in accordance with local regulations.
CLEANING & MAINTENANCE
SUSTAINABILITY
CONTACT
