Digital Extender HD-D102N User manual

Total Digital Connectivity Solutions
User’s Manual
1x2 HDMI Distribution Amplifier
HD-D102N
Cautions:
1. Digital extender logo is our own trademark of RTcom USA.,Inc.
2. Any of the products may be changed without any notice in order to improve the function of
the product.
3. The design and specification of the product may be changed without any prior notice.

Unpacking
HD-D102N HDMI Distributor package includes the following items;
• HD-D102N HDMI Distribution Amplifier Unit x 1
• 5V Power SupplyAdapter x 1
• User manual x 1
Declaration of Conformity
According to Council Directive 73/23/EEC (February 19, 1973) on the Harmonization of the Laws of Member States
relating to Electrical Equipment; Council Directive 89/336/EEC (May 3, 1989) on Electromagnetic Compatibility; Council
Directive 93/68/EEC (July 22, 1993)-Amending Directives 89/336/EEC (MC) and 73/23/EEC (Low Voltage Equipment
Safety), and/or CPU Boards and Power Supplies used Council Directive 93/68/EEC with Distributor, RTcomUSA, Inc.,
286 Houses Corner Rd. Sparta, NJ 09871 973-383-4878, declares under sole responsibility, that the product identifies
with 93/66/EEC of the Council Directive Low Voltage Equipment Safety. Each product marketed is identical to the
representative unit tested and found to be compliant with the standards.

CONTENTS
Contents 1-1
Description,GeneralSpecification 1-2
Environmental and Reliability Specifications 1-3
MainFeatures 1-4
VideoConnection 1-5
MechanicalSpecification 1-6
TechnicalSpecification 1-7
WarrantyInformation 1-8
1-1 Contents

Description, General Specification
Digital extender® HD-D102N HDMI Distribution Amplifiers, allow one digital video sources
to be spilt into multiple digital displays.
The built-in amplification function enables HDMI signal distribution without signal loss
ITEM DESCRIPTION
Model Name HD-D102N
Input Signal HDMI Single Link , 1port
Output Signal HDMI Single Link , 2ports,
Resolution 640x480, 800x600, 1024x576
1280x720, 1920x1080
480i/p , 720i/p , 1080i/p, 1080p
HDCP Support OK
Power Consumption DC +5V ,13W Max
Dimension 182(W) x 108(D) x 35(H) mm
Weight 560 g
1-2 Description , General Specification

Environmental and Reliability Specifications
1 Operating Conditions
Temperature :10℃~ 40℃
Humidity : 10% ~ 80%, non-condensing
Altitude : maximum 3,000m
2 Transportation Conditions
Temperature :-25℃~ 60℃
Humidity : 5% ~ 95%, non-condensing
Altitude : maximum 15,000m
3 Storage Conditions
Temperature :-20℃~ 45℃
Humidity : 5% ~ 95%, non-condensing
Altitude : maximum 3,000m
4 Reliability Specifications
MTBF : more than 50,000 hours at 90% confidence level
Reliability specification and items : refer to “Specification of reliability test for LCD monitor”
1-3 Environmental and Reliability Specifications

Main Features
High Quality Picture - No Signal Loss and Digital Noise Free
Our Distribution Amplifiers are built to deliver the highest quality picture preserving the native
resolutions of the video sources without any signal loss. At the same time, the digital noises that may
affect the picture quality will be eliminated. Due to the nature of the digital signals and passing
through multiple stages of connection when using distribution amplifiers, it is important to eliminate
the digital noises and boost the signal strength to preserve/enhance the video signal quality.
Signal Amplification for signal reliability and long length signal transmission.
Our 5V power adapter supplies adequate power to amplify the video signals from the video source.
This is necessary as the overall length from the video source to the displays is longer when using the
distribution amplifiers (distance from the video source to the distribution amplifier + distance from the
distribution amplifier to the display). In most cases, the overall distance that the HDMI signal will
need to travel is over 10ft. Due to the nature of HDMI signals, amplification is necessary to warrant
the video quality and reliability. (Without amplification, there may be occasional blackouts or blinking
effects or no sound) With this amplification feature, your video display can be extended up to 50ft
using RTcomUSA, copper HDMI cables.
Compliance to HDMI ver 1.3
Our HDMI distribution amplifiers support HDMI ver 1.3.
It allows for higher resolution, such as WUXGA (1920X1080p) crossing a single digital link.
HDCP (High-bandwidth Digital Content Protection) Compliant
Our HDMI distribution amplifiers are fully HDCP compliant. Many video sources such as DVD
players and Satellite/Cable Receivers are HDCP encrypted. For these video sources to be displayed
correctly, Must be HDCP compliant devices (e.g., TV / Projector, HDMI Receiver, Distribution
amplifier) are required.
1-4 Main Features

Video Connection
1. Connect your video source’s HDMI output port to the HD-D102N’s HDMI input port using standard
HDMI cables (not included). Make sure all your HDMI source and the displays are turned off
before connecting the cables.
2. Connect your HDMI display’s HDMI input port to HD-102N’s HDMI output port. Make sure your
HDMI display is turned off before connecting the cables.
3. Plug the 5V power supply into the switch’s power input port.
4. Plug the 5V wall mount power supply into the wall outlet.
5. Turn on Distributor power.
6. Turn on your displays.
7. Turn on your video source.
EDID Set up
I. EDID Set up
1, Disconnect all HDMI cable,
2, Connect Monitor or HDTV to “OUTPUT 1” back panel of Distributor
3, Turn on distributor and HDTV power
4, Push the” EDID” button in front of HD-D102N (3 sec)
until GREEN LED light is on.
5, Turn off distributor
6, Reconnect all device follow the “Video Connection”
**** EDID [Extended Display Indentification Data]
EDID is defined by a standard published by the Video Electronics Standards Association (VESA). The
EDID includes manufacturer name, product type, phospher or filter type, timings supported by the display,
display size, luminance data and (for digital displays only) pixel mapping data.
1-5 Video Connection

Mechanical Specification
Dimensions
HD-D102N : 182(W) x 108(D) x 35(H) mm
DC 5V : DC Power Input (+5 V)
POWER : Power On / Off Switch
ON : Power On / Off Indication LED
INPUT : HDMI Input Signal
OUTPUT 1 ~ 2 : HDMI Output Signals
EDID: indicate EDID on/off
EDID s/w : EDID Setting Switch
1-6 Mechanical Specification

Technical Specification
Frequency bandwidth: 2.25 Gbps (Single Link)
Supporting Graphic Resolution: 640x480, 800x600, 1024x576
1280x720, 1920x1080
480i/p, 720i/p, 1080i/p
Inputs: HDMI Female 1 port
Output: HDMI Female 2 ports
Power supply: DC 5V, 2A Adapter included.
Connector Pin Assignment
HDMI Input , Output
Part No. Pin No. Description Remarks
1 TMDS DATA 2P
2 TMDS DATA 2 Shield
3 TMDS DATA 2M
4 TMDS DATA 1P
5 TMDS DATA 1 Shield
6 TMDS DATA 1M
7 TMDS DATA 0P
8 TMDS DATA 0 Shield
9 TMDS DATA 0M
10 TMDS Clock P
11 TMDS Clock Shield
12 TMDS Clock M
13 CEC
14 RESERVED
15 DDC Clock
16 DDC DATA
17 GND
18 +5v
HDMI 19pin
19 Hot Plug Detect
1-7 Technical Specification

Warranty Information
1 (One) Year Warranty
RTcomUSA, Inc. warrants this Digital extender® HD-D102N HDMI Distribution Amplifiers to be free
from defects in workmanship and materials, under normal use and service, for a period of one (1) year
from the date of purchase from RTcomUSA Inc.or its authorized resellers.
If a product does not work as warranted during the applicable warranty period, RTcomUSA, Inc. shall, at
its option and expense, repair the defective product or part, deliver to customer an equivalent product or
parts to replace the defective item, or refund to customer the purchase price paid for the defective product.
All products that are replaced will become the property of RTcomUSA, Inc.
Replacement products may be new or reconditioned.
Any replaced or repaired product or parts has a ninety (90) day warranty or the reminder of the initial
warranty period, whichever is longer.
RTcomUSA, Inc. shall not be responsible for any software, firmware, information, or memory data of
customer contained in, stored on, or integrated with any products returned to RTcomUSA, Inc. for repair
under warranty or not.
Warranty Limitation and Exclusion
RTcomUSA, Inc. shall have no further obligation under the foregoing limited warranty if the product has
been damaged due to abuse, misuse, neglect, accident, unusual physical or electrical stress, unauthorized
modifications, tampering, alterations, or service other than by RTcomUSA, Inc. or its authorized agents,
causes other than from ordinary use or failure to properly use the Product in the application for which said
Product is intended.
1-8 Warranty Information
