Dish Network TR-40CRA User manual

Enjoying your converter is as easy as 1-2-3!
CONNECTIONS
1
From the antenna
to the converter
From the converter
to the TV
See pages 2 & 3
Set TV to channel 3, push
POWER on the TR-40CRAremote,
and follow the on-screen instructions
Install batteries
in back of remote
SET UP
2
See pages 3 & 4
FINDING A CHANNEL
3
Program Guide Channel Up/DownNumber Pad
See pages 5-7
164835
Enjoying your converter is as easy as 1-2-3!
TR-40CRA User
Guide
C
M
Y
CM
MY
CY
CMY
K
164835_01_TR-40CRA_cover.pdf 8/14/2008 12:48:01 PM

Warning and Attention Symbols
You must be aware of safety when you install and use this system. This User Guide
provides various procedures. If you do some of these procedures carelessly, you could
injure or kill yourself or damage equipment or property. Some other procedures require
special attention.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the apparatus.
The class II equipment symbol means that the equipment has additional
insulation and does not need to be grounded.
For Your Safety
Do not try to open the case of the power adapter or receiver. There is risk of
electrical shock, which may cause damage to the apparatus and/or personal
injury or death to you. There are no user-serviceable parts inside. Opening
the case or making unauthorized changes will void the warranty.
Warning: To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
Important Software Notice
As with all software controlled products, unexpected behavior could arise if the user
tries to perform operations in a non-routine manner. This product, like almost any other
high tech product, is subject to bugs and hence DISH Network CANNOT AND DOES
NOT GUARANTEE OR WARRANT THAT ALL FEATURES, SUCH AS PARENTAL
CONTROL, WILL WORK AS INTENDED UNDER ALL CIRCUMSTANCES. In
compliance with the terms of the GNU Public License (GPL), DISH Network is making
some source code available to the public to download from www.dishnetwork.com.
Equipment and Software Covered by this Guide
This User Guide covers the TR-40CRA Digital-to-Analog TV Converter. This Guide
may cover other devices, not listed here. The information in this User Guide may
change without notice. We may issue revisions to tell you about such changes.
Copyright Notice
Part Number: 164835
Copyright © 2008 EchoStar Technologies L.L.C., Englewood, Colorado 80112. All
rights reserved.
The software embedded in this product includes code that is copyright © 2005 the
FreeType Project (www.freetype.org) and which is licensed under the FreeType
Project Licence of January 27, 2006.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.
tr40.book Page 1 Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
Page i
Table of Contents
CONTENTS C
Important Safety Instructions........................... ii
TR-40CRA Top Tips........................................... v
Introduction........................................................ 1
Guide Conventions.................................. 1
Getting Started......................................... 1
Installation................................................ 2
The Remote Control ......................................... 5
Remote Control Buttons......................... 6
Using the Menus................................................ 9
Watching TV........................................... 10
Finding Programs.................................. 10
Using Event Timers............................... 12
Customizing Your TR-40CRA......................... 13
Locks...................................................... 14
System Setup......................................... 16
Audio Setup ........................................... 18
Closed Caption...................................... 18
Troubleshooting.............................................. 19
TV Guide On Screen or Guide Plus Setup .... 23
Limited Warranty............................................. 31
FCC Compliance.............................................. 34
FCC Digital Television Transition Notice...... 37
tr40.book Page i Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
IMPORTANT SAFETY INSTRUCTIONS
Page ii
Important Safety Instructions
SAFETY S
IMPORTANT SAFETY INSTRUCTIONS
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with a dry cloth.
7 Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8 Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11 Use only attachments/accessories specified by the manufacturer.
12 Unplug this apparatus during lightning storms or when unused for long periods of time.
13 Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as the power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
Apparatus shall not be exposed to dripping or splashing and no objects filled
with liquids, such as vases, shall be placed on the apparatus.
tr40.book Page ii Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
IMPORTANT SAFETY INSTRUCTIONS
Page iii
IMPORTANT SAFETY INSTRUCTIONS
•Only connect the original power adapter to the TV converter. Other power adapters
may damage the TV converter and cause a fire risk.
•Do not install the power adapter or TV converter in any area where the temperature
can be less than 40°F or more than 113°F, and do not cover them.
•Connect the power adapter only to the type of power source indicated on its label. The
power adapter must be readily accessible so that the equipment can be easily
disconnected from the AC power. Unplug the power adapter by gripping the power
adapter, not the cable.
•Do not overload wall outlets or extension cords; this can result in a risk of fire or
electrical shock.
•Do not attempt to service the power adapter or TV converter yourself, as opening or
removing covers may expose you to dangerous voltage, and will void the Limited
Warranty.
•Unplug the power adapter from the AC power outlet before cleaning. The power
adapter is still connected to the AC power whenever it is plugged in to a live power
outlet, even if the TV converter is turned off.
•Do not place naked flame sources such as lighted candles on or near the TV converter
or power adapter.
•Do not expose the remote control batteries to excessive heat or fire.
tr40.book Page iii Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
IMPORTANT SAFETY INSTRUCTIONS
Page iv
Note to Installer: This reminder is provided to call the installer's attention to Article
810 section II of the National Electrical Code (NEC) that provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building as close to the point of cable entry as practical.
•Do not locate the antenna near overhead light or power circuits, or where it can fall into
such power lines or circuits. When installing the antenna, take extreme care to avoid
touching such power lines or circuits, as contact with them can be fatal.
Proper Care of Your Equipment
•Locate the TV converter in an open, well-ventilated area.
•If the TV converter is cold to the touch, do not plug it in immediately. Let it sit unplugged
at room temperature for at least 30 minutes before plugging it in.
•Always handle the TV converter and power adapter carefully.
•Unplug the power adapter from the AC power outlet before cleaning.
•Always turn the TV converter off and unplug it before moving it.
•The use of accessories or attachments not recommended by the TV converter
manufacturer will void the Limited Warranty.
•Use an outlet that contains surge suppression or ground fault protection. During an
electrical storm or when the TV converter is left unattended and unused for long
periods of time, unplug the adapter from the wall outlet, and disconnect the lines
between the TV converter and the antenna. This will provide additional protection
against damage caused by lightning or power line surges.
Example of Antenna Grounding
Antenna
Lead in Wire
Antenna
Discharge
Unit
(NEC Section 810-20)
Ground Clamp
Ground Clamp
Grounding
Conductors
(NEC Section 810-21)
Electric
Service
Equipment
Power Service Grounding
Electrode System
(NEC Art. 250, Part H)
National Electrical Code, 2008
tr40.book Page iv Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
TR-40CRA TOP TIPS
Page v
Quick Tips to Get You Started
TR-40CRA TOP TIPS
The TR-40CRA converts your local digital over-the-air TV broadcasts into a
format that can be viewed on your analog TV so you will be able to continue to
watch your local TV channels after the FCC-mandated digital transition.
The TR-40CRA is easy-to-use and takes your TV to the next level with built-in
features to make your life easier. Get the most out of your TR-40CRA with these
helpful tips.
USING YOUR ON-SCREEN PROGRAM GUIDE
The TR-40CRA converter’s easy-to-use Program Guide is a great source of
programming information displaying a complete list of available channels and
programs. Press GUIDE on the TR-40CRA remote control to open the Program
Guide and browse programs many hours in advance. Use the ARROW buttons
on the remote control to move through the Program Guide.
See page 10 for more information on the Program Guide.
tr40.book Page v Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
TR-40CRA TOP TIPS
Page vi
EVENT TIMERS
Never worry about having to
remember when your favorite shows
start! The TR-40CRA converter’s
Event Timer feature automatically
changes the channel to your favorite
program at the time it is scheduled to
begin. While in the Program Guide,
press SELECT on a future program
to create an event timer. Timers can
be created to tune to a channel one-time, daily, Monday-Friday, or weekly. See
page 12 for more information on Event Timers.
PARENTAL CONTROL
Block content you believe is
inappropriate for your household by
creating Locks. The Locks feature
requires a password to view content
you deem inappropriate. Access the
Locks menu by pressing MENU on
the remote control, selecting Setup,
then selecting Locks. See page 14
for more information on the TR-
40CRA converter’s Locks feature.
ANALOG PASS-THROUGH
Your TR-40CRA supports analog pass-through, allowing you to easily view
channels that still broadcast using an analog signal. To view analog over-the-air
channels, simply press the ANALOG PASS-THROUGH button on the remote
control, then change channels using the remote control for your TV.
To resume viewing digital over-the-air channels, turn your TV back to channel 3,
4 or the alternate video input used to view your TR-40CRA, then press the
ANALOG PASS-THROUGH button on the TR-40CRA remote control again.
See pages 2 and 7 for more information on analog pass-through.
tr40.book Page vi Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
TR-40CRA TOP TIPS
Page vii
QUICK TROUBLESHOOTING TIPS
If You Get a Black or Blank Screen
•Make sure your TR-40CRA is powered on. There should be a green light
on the front panel of the TR-40CRA converter. If not, press the POWER
button on your TR-40CRA remote control.
•Make sure your TV is on the correct channel for viewing your TR-40CRA.
Your TV needs to be on either channel 3 or 4 (if connected using coax
cable) or a video input (if connected using RCA cables).
•Your TR-40CRA might need a simple "reset". Simply unplug the TR-
40CRA from your power outlet for 30 seconds and then plug it back in.
Your TR-40CRA will reset and should be ready to use again within minutes.
Not Receiving a Digital Signal During Your Installation/
Set Up
Please note: Not all broadcasters are currently broadcasting a digital signal and
the source of the digital signal may move at any time. Go to
www.antennaweb.org or contact your local broadcaster to find out which
channels in your area are broadcasting a digital signal.
•If you are not able to receive a
digital TV signal for ANY of your
local channels and you see "The
receiver is unable to detect a
signal in your area" message on
your screen, it is possible that
you do not have the correct over-
the-air antenna to receive a
digital signal or are out of range
for digital broadcasts. Go to www.antennaweb.org for more information on
which over-the-air antenna is best for your area or visit your nearest
electronics retailer.
•If you are not able to receive a digital TV signal for SOME of your local
channels you may simply need to adjust your over-the-air antenna or get
an over-the-air antenna that is optimized for your area. Go to
www.antennaweb.org for more information on which over-the-air antenna
is correct for your area or visit your nearest electronics retailer.
Top_Tips.fm Page vii Monday, September 15, 2008 7:25 AM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
TR-40CRA TOP TIPS
Page viii
No Longer Receiving a Digital Signal After Your Installa-
tion/Set Up
•If you are no longer able to receive a digital TV signal for some or all of your
local channels and your TR-40CRA Digital-toAnalong TV Converter is
hooked up correctly, it is possible that you will need to adjust your over-the-
air antenna or get an over-the-air antenna that is optimized for your area as
the source of the digital signal may have moved. Go to
www.antennaweb.org for more information on which over-the-air antenna
is best for your area or visit your nearest electronic retailer.
•You can easily check the signal
strength of a local channel by
pressing BROWSE on your
remote control when tuned to the
channel on your TR-40CRA.
The signal strength for that
channel appears in the upper
right hand corner of your TV
screen.
For more helpful troubleshooting information go to page 19 in this manual.
MORE INFORMATION/CUSTOMER SUPPORT
1-888-667-0633 or www.dtvpal.com.
UPGRADE TO DISH NETWORK
Although the TR-40CRA is a great digital-to-analog TV converter box, you may
not be able to receive any or all digital over-the-air signals. Get over 100 or
more of the most popular national channels, such as Discovery, CNN, and
ESPN, and your local channels* by getting your programming through DISH
Network. Call 1-888-638-9912 or visit www.dishnetwork.com/dtvpal today and
get DISH Network for the lowest all-digital price nationwide...every day!
*where available
tr40.book Page viii Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
INTRODUCTION
Page 1
Introduction and Installation
Getting to Know the TR-40CRA and Connecting It to Your TV
CHAPTER 1
INTRODUCTION
Welcome and thank you for choosing TR-40CRA Digital-to-Analog Converter!
Your TR-40CRA is a TV converter that connects between your new or existing
over-the-air antenna and TV. The TR-40CRA converts your local digital over-
the-air TV broadcasts into a format for viewing on your standard-definition
analog TV.
This chapter walks you through connecting your TR-40CRA to your TV and
provides an introduction to the features of the TR-40CRA. If you experience any
issues connecting the TR-40CRA, refer to Troubleshooting on page 19 for
assistance.
GUIDE CONVENTIONS
•The names of remote control buttons are all uppercase.
Example: Press SELECT.
•On-screen menu options are bold.
Example: Choose the Setup option.
•“Select” means to move the on-screen highlight using the remote control’s
ARROW buttons then press SELECT on the remote control.
Example: Select the Locks option.
GETTING STARTED
•To learn about the remote control, refer to Chapter 2 on page 5.
•To learn about using the features of your TR-40CRA converter, refer to
Chapter 3 on page 9.
•If you experience any issues using your TR-40CRA converter, refer to the
Troubleshooting steps on page 19.
•If your analog TV supports TV Guide On Screen or Guide Plus, refer to
page 23 for setup instructions.
tr40.book Page 1 Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
INSTALLATION
Page 2
INSTALLATION
Note: These instructions assume you already have an over-the-air antenna
installed. If you need help choosing or installing an over-the-air antenna, refer to
www.antennaweb.org or your local retailer.
Connecting Your TR-40CRA to Your TV
Important Safety Note: Do not connect your TV or your TR-40CRA
converter to a power supply until after you have properly connected all
of the cables using the following instructions.
TR-40CRA Back Panel Connections
1 On the back of your TV, locate the ANTENNA INconnection, which connects
your TV to your over-the-air antenna. This connection may be labeled
OVER-THE-AIR ANTENNA IN, CABLE IN, COAX IN, or another name. Refer to
your TV’s User Guide for help locating this connection.
2 Disconnect the coaxial cable from your TV’s ANTENNA INconnection.
Note: If your TV uses twin-lead (300 ohm) connections, you will need to
obtain and install a 75 ohm to 300 ohm converter on your TV. This
converter can be found at most consumer electronics stores.
3 Look at the back of the TR-40CRA, and locate the OVER-THE-AIR ANTENNA
INconnection (refer to image above). Connect the coaxial cable from
step 2 to the OVER-THE-AIR ANTENNA INconnection on the TR-40CRA. Do
not use a wrench to tighten this connection.
Note: The TR-40CRA includes only a digital over-the-air tuner. If channels
in your area are still broadcasting analog signals, you can view these
channels by pressing the ANALOG PASS-THROUGH button on the TR-
40CRA remote, and then changing channels using the TV’s remote control.
4 Determine the connection type you’ll use to connect your converter to your
TV. The TV SET OUT connection uses a coaxial cable to connect to a TV’s
ANTENNA INconnection, and carries video and mono audio on RF channels
3 or 4 (step 5). Alternatively, if your TV has RCA connectors for audio and
video, you can use RCA cables to connect from the AUDIO/VIDEO
connection (RCA-type) on your converter to your TV’s video input (go to
step 6).
tr40.book Page 2 Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
INSTALLATION
Page 3
5 To connect your TR-40CRA converter to your TV using a coaxial cable:
a Connect one end of the coaxial cable to the TV’s ANTENNA INconnection.
b Connect the other end of the coaxial cable to the TV SET OUT connection
on your TR-40CRA converter.
6 To connect your TR-40CRA converter to your TV using composite cables
(red, white, and yellow RCA-type).
a Connect the composite cables to the TV’s RCA-type composite input.
b Connect the other end of the cables to the AUDIO/VIDEO connections on
your TR-40CRA converter.
7 Plug the TR-40CRA power adapter into the power adapter plug on the back
of your TR-40CRA converter. Plug the other end into an electrical outlet.
Make sure your TV also is plugged in to power.
Using the Installation Wizard
8 Install the two included AAA batteries in the TR-40CRA remote control. Be
sure to follow the battery installation diagram printed on the remote control.
9 Turn on your TV using the TV’s remote control or front panel button.
10 Change your TV to the correct channel or input to view your TR-40CRA.
a If your TV is connected to your TR-40CRA converter using the coaxial
connection (step 5), set the TV to channel 3, which is the default output
channel for the TR-40CRA.
Note: If you have a local or cable channel that broadcasts on channel 3,
you can change the output setting for your TR-40CRA converter to
channel 4 during the Installation Wizard, described below.
b If your TV is connected using the RCA-type connection (step 6), you will
need to set the TV to the correct video input or source. Most TV remote
controls have a VIDEO, INPUT, or SOURCE button that you can use to
change the TV’s video input or source. Refer to your TV’s user guide for
additional help changing the TV’s input or source.
11 The first time your
converter turns on, an
Installation Wizard screen
appears and guides you
through the setup process.
The Installation Wizard
scans for local digital over-
the-air channels, and helps
you set up the time zone
and TV display settings.
Installation Wizard
tr40.book Page 3 Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
INSTALLATION
Page 4
12 To navigate through the Installation Wizard,
use the SELECT button on your TR-40CRA
remote control to choose the highlighted
(orange) on-screen option. To highlight other
options, use the ARROW buttons.
13 Select Continue to begin the Wizard.
14 The Installation Wizard scans for local digital
over-the-air channels.
15 After the channel scan completes, you will be taken to the Set Time Zone
screen. Use the UP and DOWN ARROW buttons to find your time zone
and to set if your area follows Daylight Savings time. Select Next once
you’ve made these settings and to go to the next step.
16 The Channel 3-4 Setup screen is used to change the output channel of the
TV SET OUT connection on your TR-40CRA converter. The channel setting
on the Channel 3-4 Setup screen must match your TV’s channel. If you
have a local or cable channel that broadcasts on channel 3, be sure to
change this setting to channel 4. If you do this, you will also need to change
your TV channel to 4. Select Next.
17 Use the ARROWS or NUMBER PAD to enter your ZIP code. Select Next.
18 The TR-40CRA begins to
download the Program
Guide information. This
takes a few minutes. After
the Program Guide has
downloaded, the TR-40CRA
will exit out to a channel.
19 Congratulations! Your
converter is now installed
and ready to use! To start
watching TV, press either
the UP or DOWN ARROW buttons on the remote control to change
channels, or enter the channel number using the NUMBER PAD.
Note: Some broadcasters choose to send several channels in their
broadcast range rather than just a single channel. These additional
channels are referred to as sub-channels, and are identified by a dash and
then a number (for example, channel 9-2 is a sub-channel of channel 9). To
change to a sub-channel, enter “0” before entering the channel number.
For example, to change to channel 9-2, enter “0092” on the NUMBER PAD.
Navigation Buttons
Downloading Guide
tr40.book Page 4 Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
THE REMOTE CONTROL
Page 5
Remote Control
Using Your TR-40CRA Remote Control
CHAPTER 2
THE REMOTE CONTROL
The remote control that came with your TR-
40CRA will operate only your TR-40CRA
Digital-to-Analog Converter. If you own a
universal remote control, you may be able to
program your universal remote control to
operate your TR-40CRA converter as well as
your TV. Review the device codes provided
in your universal remote control’s User
Guide. Look for the codes listed for
EchoStar, EchoSphere, or DISH Network.
tr40.book Page 5 Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
REMOTE CONTROL BUTTONS
Page 6
REMOTE CONTROL BUTTONS
POWER Turns your TR-40CRA converter on or off.
ARROWS
Use the UP and DOWN ARROWS to
quickly change channels. The ARROW
buttons also allow you to move through on-
screen menus and highlight different
options.
SELECT Selects a highlighted on-screen option or, if pressed while viewing a channel, displays
the program information banner.
VOLUME
and MUTE Adjusts the volume level of the TR-40CRA converter or mutes its volume.
NUMBER
PAD
Quickly change channels by entering the
channel number, or choose numbered on-
screen options.
Note: The STAR (*) and POUND (#)
buttons are not used by the TR-40CRA
converter.
GUIDE Opens the on-screen Program Guide, which displays this list of available channels
and programs.
INFO Displays program information.
tr40.book Page 6 Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
REMOTE CONTROL BUTTONS
Page 7
PAGE UP
andDOWN
(PICTURE
FORMAT
and CC)
Up PAGE UP or PAGE DOWN while in the
Program Guide and other menus to move
through the menus one page at a time.
While watching TV, pressing PAGE UP/
PICTURE FORMAT adjusts formatting of
programs to fit your TV screen.
Pressing PAGE DOWN/CC while watching
TV turns closed captioning on or off.
MENU Opens your TR-40CRA main menu, which allows you to open all other TR-40CRA
menus.
CANCEL Allows you to exit out of any menu without
saving changes.
VIEW TV Quickly exits you all the way out of menus
to return to viewing TV.
RECALL Returns you to the previous channel.
SEARCH Quickly opens the Event Search screen. See page 11 for more details on Event
Search.
BROWSE
Displays the Browse Banner, allowing you
to see what is showing on other channels.
See page 11 for more details on the Browse
Banner.
SYS INFO Opens the System Information screen, which provides technical details on your
TR-40CRA Digital-to-Analog TV Converter.
ANALOG
PASS-
THROUGH
Provides the ability to pass-through the
analog antenna signal directly to the TV,
allowing the TV’s tuner to be used for
analog channels.
tr40.book Page 7 Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
NOTES
Page 8
NOTES
tr40.book Page 8 Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
USING THE MENUS
Page 9
Features and Menus
Using Your TR-40CRA Menus and Features
CHAPTER 3
USING THE MENUS
Opening the Menus
•Press the MENU button on the remote control to open your TR-
40CRA converter’s Main Menu. You can open all other menus and
options from the Main Menu.
•While watching TV, other remote control buttons provide quick access to
certain menus of your TR-40CRA.
–GUIDE opens the Program Guide.
–SEARCH opens the Event Search screen.
–BROWSE opens the Browse Banner.
Navigating the Menus and Selecting Options
•Use the remote control ARROW buttons to move the highlight to your
desired option. The option that is highlighted will be orange in color. In the
Program Guide, the highlighted program is dark blue.
•To choose a highlighted option, press SELECT.
•If the option has a number on it, you can quickly select the option by
pressing that number on the NUMBER PAD.
TR-40CRA Main Menu
tr40.book Page 9 Thursday, August 14, 2008 12:47 PM

TR-40CRA DIGITAL-TO-ANALOG TV CONVERTER
WATCHING TV
Page 10
Closing the Menus
There are several ways to exit out of the on-screen menus.
•Select Done to save any changes you’ve made in a menu.
•Press CANCEL (or select Cancel) to exit a menu without saving changes.
•Press VIEW TV to exit out of all the menus and return to watching TV.
•Menus will automatically close after several minutes of inactivity.
WATCHING TV
Press the UP or DOWN ARROWS to move through the available channels one
channel at a time. If you know the channel’s number, you can enter the channel
number using the remote control’s NUMBER PAD.
To change to a sub-channel, enter “0” before entering the channel number. For
example, to change to channel 9-2, enter “0092” on the NUMBER PAD. See
page 4 for an explanation of sub-channels.
Press INFO while watching TV or while in the Program Guide to view additional
information on the program.
Note: To view Closed Captioning information, you must either enable Closed
Captions through your TR-40CRA converter’s menus (press the CC button on
the remote control or see page 18), or enable the display of Closed Captioning
using your TV’s menus (refer to your TV’s user guide).
FINDING PROGRAMS
Finding Programs Using
the Program Guide
The Program Guide displays the
listofdigital over-the-airchannels
and programs. The top of the
Program Guide displays the date,
time, and title of the program that
is highlighted.
Note:Program Guideinformation
is provided by the local channel
broadcasters. The amount of guide information available varies by channel.
•Use the ARROW buttons to move through the Program Guide.
•Use the PAGE UP or PAGE DOWN buttons to move through the Program
Guide one page at a time.
Program Guide
tr40.book Page 10 Thursday, August 14, 2008 12:47 PM
