Distar DWE-3105A User manual

User's manual
Automatic Washing Machine
Troubleshooting Answer to question.....12
Names of the parts....................the 2nd cover
Safety precautions .............................1
Installation and adjustment .......................3
Install the water inlet hose..................4
Packing list ..........................13
Using process
Contents
Before using
Preparation before washing ..................6
Put in the laundries .........................7
Put in the detergent ..............................8
Close the top lid ..............................8
Select water level............................9
Press the POWER button.......................9
Select program.................................9
Press the START/PAUSE button..............10
The washing is finished .......................10
Disposal after washing ................................11
Specification....................the back cover
Please read this manual carefully before using.
Please retain it for future reference.
Please check if the power receptacle is earthed
reliably before usage to guarantee your safety
The manufacture is not responsible for any risks
occurred owing to disobey these stipulations.

Before Using
Before Using
Names of the parts
Adjustable foot
(four pieces)
Power line
Water inlet valve
Water absorption
cushion
Drain hose joint
Meaning and description of the symbols
Warning sign
Prohibition sign
Contents marked with that symbol
are related to the safety of the
product and the personal safety
of the users. Please operate in
strict conformity to the contents,
otherwise it may cause damage
of the machine or injure the
personal safety of the user.
Contents marked with that symbol
are actions forbidden to perform.
Performing of those actions may
result in damage of the machine
or injure the personal safety of
the user.
Accessories
Honourable users:
Thank you for choosing our products.
Our products integrade high-tech, precision frontier science.To facilitate using it, please
read this manual carefully and operate this machine according to it.
Power switch
Program selector
Bleach injection inlet
Cabinet
Control panel
Control panel seat
Inner tub
Top lid
Water level knob
Control foot of door switch
Pulsator
Start/Pause switch
Outer drain
hose component
(one)
Drain hose
clamp
(one)
Door switch
the end connecting to
the water inlet hose jointer
the end connecting to
the washing machine
jointer connecting the
water inlet hose and
the water faucet
water inlet hose
(one)
Water inlet
hose jointer
(one)
Lint filter
(one)

Before Using
Before Using
Safety precautions
If the power line is bad, to avoid risk it is required to have it replaced by the technicians
of our special shop or our agent or the after-sale service department. Keep the pin of
the power plug clean.
Do not use water hotter than 50
Do not wash water-proof laundries like
the raincoat, bike covers etc. to avoid
abnormal vibrations in spinning.
Do not let the machine share one receptacle
with other electric appliances. If the power
plug is damaged, or the plugging into the
receptacle is loose, do not use the plug any
more.
Ensure that the earth terminal of the power
receptacle is earthed reliably.
Be sure to pull the plug off when the machine
is idle or when cleaning the machine. Plug
prongs shall be kept clean.
Do not put the machine at damp place
like the bathroom . Never wash it with
water. Do not place wet laundries on the
control panel.

Safety precautions
Do not decompose, repair or alter the
machine by yourself.
Do not put any hot or heavy items (such
as the kettle with hot water ) on the
washing machine.
Do not wash laundries with volatile
materials (such as thinner, petrol etc.)
The handicapped or children without
care shall not use the machine.
Keep the machine away from direct
sunlight and heat source like the heater.
Do not stretch hands into the working
machine. It is dangerous even if the
rotation is slow. Take special care of
the children.
Petrol
Thinner
To prevent your laundries and washing
machine from damages, be sure to take
out all of the foreign materials from your
pocket, such as coins, buttons, sand or
hair pins etc. Before washing, please check if the
water tap is open, and if the water inlet
pipe is connected properly.
It is suggested to use low-foaming
washing powder.
In case the washing machine is installed
on ground with carpet , do not block the
ventilation hole with carpet.

Installation and adjustment
Please install and adjust the machine according to the requirement of the manual. It is
very important to your security and correct operating the machine.
Adjust the installation position
The largest allowed slope of the base of the machine is 2 . The slanting or rough
ground will result in unstable running or stoppage of the machine. Please adjust
it with following methods:
Confirm it's horizontal:
Hang the lead line to confirm
if it is horizontal.
Adjust the adjustable foot:
1.To twist the adjustable foot, please first lift up
the side of the foot slightly, and twist the foot.
2.Fasten the nut after adjustment.
High Low
Adjustable foot
Put the drain hose clamp on the outer drain hose,
insert the outer drain hose into the joint for it, and
then clutch tightly with drain hose clamp.
Drain hose joint
Drain hose clamp
Drain hose
Install the drain hose
Usage of the drain hose
If the drain hose is too long, cut it at mid
point. To make smooth drainage, cut the
front end of the hose slantingly.
4.If extra drain hose is needed, please
make separate purchase. The inner
diameter of the extra hose shall not
less than 30mm, and the length shall
not exceed 1.5m.
1.The height of the drain hose shall be
less than 10cm, or the drainage will not
be smooth, and cost such long time that
the machine may stop at mid way.
2.Do not tramp or press the drain hose.
The drain hose shall drain smoothly
Before Using
Before Using
After opening the package, please take out the lint filter
from the document bag and install it into the frame of
the inner tub. See to the right Figure.
Filter frame Lint filter
Install the lint filter
