DOMOTECH XQB70-A User manual

User's Manual
Specifications the back cover
DTD 307 XQ
Picking list
Fuzzy Logic Automatic Washing Machine
Contents
Before using
Using process
Trouble shooting *
Answers to questions
16
Please read this manual carefully before using.
Retain it for future reference
Please check if the power receptacle has good earthing
condition before using to guarantee your safety.
The manufacturer will not bear the responsibility for
those risks occurred from not obeying this manual.
7
8
9
10
14
14
15
Preparation before washing
Put in the laundries
Add the detergent and softener
Use the operation buttons
Close the top lid
Finish washing
Disposal after washing
nd
Names of the parts The 2 cover
Safety precautions
Installation and adjustment
Install the water inlet hose 5
1
3
17
Domotech

Water inlet hose
(2 pieces)
Names of the parts
Before using
Before using
Before using
Before using
Meaning and description of the symbols
Accessories
Bottom plate
(1 piece)
Water inlet
hose jointer
(2 pieces)
Tapping screw
ST4x 16
(8 pieces)
Contents marked with
that symbol are related
to the safety of the
product and the personal
safety of the users. Failure
to comply with the
instruction could cause
damage of the machine
or injure the personal
safety of the user.
Contents marked with
that symbol are actions
forbidden to perform.
Failure to comply with
the instruction could
result in damage of the
machine or injure the
personal safety of the user.
Warning
mark
Forbidding
mark
The end connecting to
the washing machine
The end connecting to
the water inlet hose jointer
Jointer connecting
the water inlet hose
to the water faucet
Adjustable foot
Front control
board
Front fixed
foot
Rear fixed foot
back cover
Cabinet
base frame
Drain hose
Back faceplate
Control panel
film
Control panel
Lint filter(Installed by user)
Filter cover
Level meter
Power line
Pulsator
Inner tub
Detergent box
Drier outlet
cover
Top lid B
Cabinet handle
Warm watervalve
Cool water valve
Top lid A
Adjustable foot
seam
hanging hole
for the drain
hose
Lint filter
(1 piece)

Safety precautions Before using
Before using
Before using
Before using
In normal usage of the washing machine,
the power plug shall be ready to be pulled
or plugged with hand. Be sure to pull the
plug off and close the water faucet in
following cases: power failure, delivering
the machine, setting the machine idle or
cleaning the machine. Do not plug
or pull the power plug with wet hand.
In case the washing machine is installed on
ground with carpet, be careful not to block the
ventilation hole with carpet.
Do not let the machine share one receptacle with other
electric appliances. If the power plug is damaged, or the
plugging into the receptacle is loose, do not use it any
more.
Do not set the machine atdamp place
like the bathroom. Never wash it with water.
Do not put wet laundries on the control
panel coating.
Do not use water with temperature
higher than 50 inside the tub.
Do not wash water-proof laundries like
the raincoat, bikecovers, down textiles etc.
to avoid abnormal vibrations in spinning and
damaging the laundries.
Do not bend, stretch, twist, bind the power cord by force,
or reform it. Do not press or clamp it with heavy items. If the
power cord and power plug are bad, or the receptacle is loose,
be sure to have it replaced by the technicians of our special shop
or our agent, or the after-sale service department for the sake
of avoiding any risk. Keep the prong of the power plug clean.
If dust is found on the power plug, please wipe it off with dry cloth.
Earth
The ventilation
holes at the
bottom
Please insert the power cord into special
receptacle with rated voltage.Be sure to
use single-phase three pins receptacle.
The earthing terminal must be earthed
reliably.If possible,please adopt electric
leakage protector.

Do not put hand into the rotating tub. It is
dangerous even if the rotation speed is slow.
Take special care of the children. Keep
children away from the washing machine
to avoid them climbing on it.
Do not decompose, repair or alter
the machine by yourself.
Do not put any hot or heavy items
(such as the kettle with hot water) on the
washing machine.
Do not wash laundries with volatile
materials (such as thinner, petrol etc.).
Keep the machine away from direct
sunlight and heat source like the heater.
The handicapped or children shall not
use the machine without care.
Safety precautions Before using
Before using
Before using
Before using
Please check if the water faucet is open, and if
the connection of the water inlet pipe is proper.
It is suggested to use foamless washing powder.
To prevent the lint in the tub from blocking
the cascade outlet and influencing the
cascade effect, please keep the lint filter
in good condition, and install it to proper
position during washing. If the lint filter is
lost or damaged, please contact the local
after-sale service department of our
company.
Toprotect your laundries and washing
machine, please take out all of the coins,
buttons, sand, hairpin and other foreign
materials before washing.

Install the bottom plate
Adjust the installation position
3
Please install and adjust the machine according to the requirement of the manual, which is very
important for you to operate the machine safely and properly.
After opening the package, please lean the
washing machine gently down on soft items
(like towel cloth, blanket, etc.). Install the
bottom plate to the bottom of the machine
with eight screws by a cross screwdriver,
then lift the machine up gently. See to the
figure:
Safety precautions Before using
Before using
Before using
Before using
Front
Back
Soft item
Screw
Bottom plate
Loosen Fasten
High Low
Adjustable nut
Adjustable leg
The largest allowable slope of the shank base
of the machine is 2 . The slanting or rough
ground will result in unstable running or
stoppage of the machine. Please adjust it with
following methods:
Confirm it's horizontal:
Adjust the adjustable leg:
If the bulb of the level meter at the balance display
position is inside the standard circle, it indicates that
the machine is horizontal. Otherwise you need to
adjust the adjustable leg of the machine.
1.To twist the adjustable leg, please first lift up the
leg side slightly, loosen the adjustable nut, and
then twist the leg.
2.After adjustment, fasten the nut.
Air bubble
Standard circle
Suitable Not suitable

Before using
Before using
Before using
Before using
Inner tub Lint filter
After opening the package, please take out the lint
filter from the document bag, install it to the filter cover
of inner tub. See to the figure.
Install the lint filter
1.Lean the machine down gently with the front
surface facing the ground. Loosen the eight
screws by a cross screwdriver.
3.Extend the drain hose from the left side. Push the
drain hose into the groove with hands.
4.Install the bottom plate (as per indicated before),
then lift the machine up gently.
2.Pull out the drain hose from the groove at the left side.
Back
Front
Bottom plate
Soft item
Use groove at
this side after
direction changing Page 3
How to change the direction of the drain hose
1.The height of the drain hose shall be
less than 10cm, or the drainage will not
be smooth, and cost such long time that
the machine may stop at mid way.
2.Do not ramp or press the drain hose.
If the drain hose is too long, cut it at mid
point. To make smooth drainage, cut the
front end of the hose slantingly.
4.If extra drain hose is needed, please
make separate purchase. The inner
diameter of the extra hose shall not
less than 30mm, and the length shall
not exceed 1.5m.
If the extra hose is too long, cut it
either at A or at B point.
Usage of the drain hose
The drain hose shall drain smoothly

Install the water inlet pipe
Connection between the water inlet hose jointer and the water faucet
5
Water faucet, suitable water faucet, not suitable
It is required that the front end shall be longer than 10mm.
The outlet end surface of the faucet shall be flat and smooth. If not, please file it smooth to avoid leakage.
2 Loosen the four screws of the water inlet hose jointer till the water faucet can be accessed. Then set the water inlet hose
jointer on the faucet. See to Figure 2. If the faucet is too large and the jointer cannot be set on, please loosen the four
screws and take out the bush inside the jointer. See to Figure 3.
1.Press the lower end of the lock lever and push down the slider. Take off the water inlet hose jointer from the
water inlet hose component. See to Figure 1.
3 Fasten the four screws of the water inlet hose jointer evenly. See to Figure 4.
About 4mm after twisting
Remark: .Before installation, the threading is 4mm above the upper surface of the nut.
After installation, the threading is 2mm above the upper surface of the nut..
About above 2mm after twisting
Water inlet hose jointer
Screw knife
Screw
Bushing
Nameplate
Screw nut
Water inlet hose Figure 1
Figure 4
Figure 2
Figure 5
Figure 3
Figure 6
Slider
Lock level
Before Using
Before Using
Install the water inlet hose
4 Take off the nameplate. Twist the fastening nut as per the indication of the figure
to seal up the exit end face of the faucet. See to Figure 5.
Connection between the water inlet hose and the washing machine
1 Do nottake off the water absorptioncushion. Please check
if the cushionis dropped ordamaged each timebefore using.
If it happensso, please dulycontact our after-sale service
department.
2 Set thenut of thewater inlet hoseon the waterinlet valve jointer.
3 Fasten thenut. Swing itgently to confirmif it's fastenedwell.
Water absorptioncushion.
Water inlet
hose nut
Water inletvalve jointer

6
Dismount the water inlet hose
Connection between the water inlet hose jointer and the water inlet hose
Check the connection between the water inlet hose jointer and the
water faucet
1.Swing the hosegently to checkif it isfastened stably.
2.After installation, openthe faucet tocheck if itleaks water.
3.Do not bendthe hose byforce.
4.Each time beforeusing, please checkif the connection
between the waterinlet hose jointerand the waterfaucet,
and the installation of the waterinlet hoseis firm,so as
to avoid droppingowing to improperinstallation.
1 Push down the slider. Plug the water inlet hose into the jointer.
2 Hang the lock lever onto the jointer. Release
the slider till a click sound is heard.
Lock level
Slider
The water inlet
hose jointer
Slider
Locking level
1 Close the water faucet.
2 Press the lock lever and push down the slider. Then pull off the
water inlet hose. If the machine is used more than once every
week, the water inlet hose jointer can remain on the faucet to
avoid damaging the fastening screws.
Before Using
Before Using

Using process
Using process
1Preparation before washing
Pay attention to the followings before washing
Preparation before washing
1 Connect the water inlet hose. Open the water faucet.
2 Confirm that the washing machine is earthed reliably.
Then plug the power plug into the receptacle. The
earthing terminal shall not link to gas pipeline and
faucet water pipeline.
3 Put down the drain hose.
Check if
the laundries
have special
requirement
on washing
Clear the
pocket. Take
out the coins,
sand, hairpins
etc.
Tie the long
strips; fasten
the buttons;
close zippers.
When the pulsator
is running ,the
buttons of the
laundries may
cause noise. For
the sake of
discretion, please
put the laundries
with buttons into
other laundries.
The quantity of
the laundries
shall not be too
large. Stretch
and loosen the
laundries before
putting them in
the tub.
A. Check if the laundries are applicable for washing with machine.
b. Divide the laundries that are not colorfast from other laundries.
c. Put the laundries difficult to absorb water into water with hand.
d. For the laundries with heavy soil, please first remove the dirt like mud or dust.
For the parts with heavy soil, please apply detergent on them in advance, which
can make it easier to remove the soil.
e. For the laundries that may get lint ball and those with long fur, turn it over before
putting in.
f. Do not put the laundries polluted by chemicals into the washing machine directly.
Earth

8
Reference weight of the laundries:
Working suit up,down
Jeans about 800g
The capacity of washing and spinning refer to the
largest weight of the standard laundries under dry
condition that can be washed or spinned in one
cycle. Washingquantity for one cycle shall be
less than the rated capacity.The largest capacity of
this machine is 7.0kg.
The thickness, size and type of the cloth will
influence the actual washing capacity. It is
feasible to put in suitable amount of laundries and
the laundries can be tumbled normally in washing
for one cycle.
Please do not select high water level for laundries
less than 2.5kg to avoid splashing.
In washing the fluffy laundries like the woolen
blanket, the quantity shall not exceed 3kg for
each cycle.
In using water with high temperature, please pay
attention to the washing temperature limit stated
on the label of the laundries.
blending coat
about 800g
Shirt Jacket
Single bed sheet
Socking
Underpants
Undershirt
Pajamas
Blanket
cotton,about 900g
cotton,about
300g
cotton,about
800g
cotton,about 600g
blending,about 50g
cotton,about 70g
cotton,about 180g
about 200g
Using process
Using process
2 Put in the laundries
cotton,about 1120g

How to use the whitener
Standard dosage of the detergent and water quantity
Laundries
quantity
(kg)
Water
level
Water
quantity
Common powder,
Put the washing powder and softener into the detergent
box directly as indicated in the left figure.
After that, please close the detergent box. Refer to the
following table for the usage of the detergent: The
standard dosage of the detergent and the water
quantity
How to use the washing powder
Fill water to decided level. Dilute the
whitener with container. Pour it slowly into
the washing tub.
Do not use whitener on laundries with
color or print as they are not colorfast.
The whitener shall not touch the laundries
directly.
Refer to the user's manual for the usage
and dosage of the whitener.
As to whitener in powder, please dissolve
it before using.
Not applicable for fuzzy program and reserve
washing
Directly dissolved in the machine:
1.Fill in small quantity of water.
2.Add the washing powder. Run for 30 seconds
to dissolve it completely.
3.Put in the laundries. Select suitable water level.
The instant dissolving of the washing powder:
1.Prepare warm water of 30 and a container.
2.Add the powder into the container while
stirring to fully dissolve it.
The powder is more likely to pollute the laundries
than the detergent. Therefore please use it with
suitable quantity.
It is suggested not to use high sudsing detergent.
Washing powderwith poor quality or long time
storage may be caked. Please pay attention to
cleaning the detergent box in time.
Concentrated powder,
Add 40g in each 30L water Add 25g in each 30L water
3 Add the detergent and softener
Using process
Using process
Using process
Using process
Below 1.0
About 66L
About 57L About 76g About 47.5g
About 49L About 65.3g About 40.8g
About 40L About 53.3g About 33.3g
About 30L About 40g About 25g
About 61L
About 53L About 70.7g About 44g
About 44L About 58.7g About 36.6g
About 34L About 45.3g About 28.3g
About 23L About 30.7g About 19g
About 88g About 55g
About 81.3g About 50.8g
9
Inlet for concentratedwashing
powder and detergent
Detergent box
Softener inlet

a Description of the function of the operation buttons
Balance display
If the bulb of the level meter is inside the standard circle, it indicates
that the machine is horizontal.
Cool water
WATER INLET button
CURRENT button
When the washingmachine starts running, it
will set thecurrent automatically.
Youcan select currentby self accordingto the
actual requirement.
Please do notselect strong currentunder low
water level toavoid splashing andvibration.
In FASTand GENTLE programs,the washing
machine will setthe current automatically, and
the users cannotselect current inthat case.
Select the fuzzy program. After clothdetection, the water
level will beset to oneout of 4,6, 8, and10.
If there's water inside the tub, the machine cannot detect
the cloth andwill display water level 6
If wet laundries are putin, it maydisplay water level 10
Youcan also set water level by self.After themachine is
started, it will not detectthe cloth.
If quick program is selected, the waterlevel will beset to 2
automatically. When level is reached, itwill perform
washing while filling water. The 2 water level indicator is
on, and the4 water level indicator isflashing. When the “4”
water level isreached, it will stop fillingwater. 2level
indicator is off, and 4 level indicator is on.It will perform
normal washing.
WATER LEVEL button
COOL
STRONG
CURRENT
WATER
LEVEL
WATER
INLET
Balance display
4 Use the operation buttons
In starting themachine, it isset to COOL
WATERautomatically
Push the buttonto select onefrom the three
modes of COOLWATERonly,both WARM
WATERand COOLWATER,or hot wateronly.
Note that thewater temperature insidethe
tub shall notexceed 50 .
Using process
Using process
Using process
Using process
No requirement on water temperature
Cool water
Warm water
If the hot water temperature is too high
and needs to be mixed with cool water
Warm water
When the temperature of hot water is
suitable, or when you need to improve
the water temperature inside the tub
Mode and meaning of the indicator
Flash: indicating the running mode
On: indicating the mode about to run
Flash rapidly: indicating abnormal situation

Standard Common washing
Night Low noise washing during night
Gentle Washing the woolen textiles or underwear
FAST 10-minute quick washing of laundries with light soil
PROGRAM button
The following fourprograms are availablefor your
option
SURPLUS
RESERVE HOURS LATER
FAST
GENTLE
FUZZY
STANDARD
NIGHT
SOAK
WASH
RINSE
SPIN
START
PAUSE
SELECT
PROGRAM
RESERVE
POWER
ON/OFF
Program
Push it to select one or more programs from SOAK
WASH RINSE and SPIN
After the poweris switched on,push it tostart
the machine
During working, pushit to pauseworking.
During pause, pushit to resumeworking.
During sensing, itdisplays --
During operation ofprograms, it displaysthe
remained time (minute)
During reserve procedure, it displaysthe
remained reserve time(in hour)
In case ofabnormal phenomenon, it displays
the abnormal symbol(see to Page16)
SELECT button
START/PAUSE button
Digitron
Remarks: Push theOn/Off button to switch onthe power.If the washingmachine is idlefor 5 minutes,it will automatically
switch off the power.
RESERVE button
Push the buttonto select washingfinishing
time between 2-24hours.
When the RESERVE function isactivated, the
RESERVE and TIME REMAIN indicators are
on. The other indicators areoff.
Push the RESERVE button todisplay the
reserve mode.
Push the On/Off button toswitch on thepower.
When the poweris on, pushit again toswitch
off the power.
POWER ON/OFF button
Using process
Using process

2 Push the program button to select suitable automatic program.
3 Push the select button to select suitable procedure.
After switchingon the power, the washingmachine will setto WASH-SPINprocedure
automatically. It is thecommon procedure.Toselect other procedures,push the SELECTbutton to
select one ormore procedures fromSOAK, WASH,RINSE ANDSPIN. Refer toPROCEDURE
SELECTION METHOD tomake selection.
After switching onthe power,the machine willset standard programautomatically. To select otherautomatic program,
push the PROGRAMbutton till therelative indicator ison.
Refer to thePROGRAM button onPage 11 for theselection.
For instance: selectQUICK program forlaundries with smallquantity and lightsoil.
B Steps of using the operation buttons and description of each step.
In selecting thestandard and night programs, the
machine will execute fuzzy program to select
water level andwash time according to thecloth
and weight ofthe laundries. The full procedure is
controlled automatically.
COOL
WARM
SOFT
STRONG
SURPLUS
RESERVE HOURS LATER
MIN
FAST
GENTLE
FUZZY
STANDARD
NIGHT
SOAK
WASH
RINSE
SPIN
START
PAUSE
SELECT
SELECT
PROGRAM
PROGRAM
RESERVE
CURRENT
WATER
LEVEL
WATER
INLET
POWER
ON/OFF
POWER
ON/OFF
BALANCE DISPLAY
Page 13
Page 11
1 Push the POWER ON/OFF button to switch on the power.
Using process
Using process
Using process
FAST
GENTLE
FUZZY
STANDARD
NIGHT

Even there's no water in the tub, a certain period
is required before spin starting.
Do not use the SOAK program for the woolen
textiles.
Separate the laundries that are not colorfast from
other laundries in washing.
Procedure selection method
Times of pushing the
SELECT button
Push the SELECT button for 6 times, and it will resume the initial mode. It will circulate in that sequence.
The SOAK procedure can work in cooperation with automatic programs like standard and night. There is
intermittent pulsator stirring during soak.
Selected procedure Applicable circumstance Contents (the lightedindicators
indicate the programsabout to run)
Spin
(spin after drain)
WASH
(the washing liquid
remains in thetub)
When the commonlaundries need
washing, rinsing and spinning. SOAK WASH RINSE SPIN
Repeat using thewashing liquid
When the laundriesneed only
spinning after manualwashing (first
drain then spin)
The laundries arevery dirty, or the
sleeves and collarsof the shirtare
very dirty. First soakthen wash.
Attention
5 Push the WATER LEVEL button to select suitable water level
4 Push the WATER INLET button to select water inlet mode
After the poweris switched on,the washing machinewill execute fuzzyprogram automatically todetect the cloth.After
defection, it canset the waterlevel automatically. To select otherwater level, pushthe WATER LEVEL button to setthe
water level. Referto STANDARD DOSAGE OFDETERGENT AND WATER QUANTITY in Page 9and WATER LEVELin
Page 10 forselection.
After the power is switched on, the washing machine will set to COOL WATER inlet mode automatically. To
select WARMWATER only or both COOL WATER and WARM WATER, push the WATER INLET button to make
selection. See to WATER INLET in Page 10 for details.
WATER
LEVEL
Page 9
Page 10
WASH -SPIN
RINSE - SPIN
WASH -RINSE
(the rinsing liquid
remains in thetub)
SOAK - SPIN
When prevent thelaundries from
corrugating, and thelaundries do not
need spinning
Using process
Using process
Using process
SOAK WASH RINSE SPIN
SOAK WASH RINSE SPIN
SOAK WASH RINSE SPIN
SOAK WASH RINSE SPIN
SOAK WASH RINSE SPIN
When the laundriesneed rinsing
and spinning aftermanual washing
Page 10

7 Push the RESERVE button to select suitable reserve wash program
6 Push the CURRENT button to select suitable water current
8 Push the START/PAUSE button
5 Close the top lid. 6 The washing is finished.
After the poweris switched on,the reserve programis set tooff modeautomatically.If you needto set thewashing
procedure to befinished at reservedtime, please pushthe RESERVE button to setthe reserve washprogram. Refer to
RESERVE BUTTONin Page 11 for selection.
After the poweris switched on,the washing machinecan set thecurrent automatically accordingto the laundries.If you
need to selectcurrent by yourself,please push theCURRENT button.
Refer to CURRENTin Page 10for details.
When the RESERVE function is activated, the indicator of the program you have set will be
off. The RESERVE (HOUR) and TIME REMAIN indicators will be on. During reserve
procedure, you can push the RESERVE button to display the reserve mode.
To change the running program or cancel the reserve setting, you need to switch off the
power and make new selection.
The washing will be finished after 18 hours.
Water Level and Time Table of Each Program
* Total time: including the normal water inlet time and drain time.
* Washtime: adjustable according to the water temperature automatically.
* Spin time: the time from intermittent running to finishing
* The standard and night programs can have SOAK procedure. After water inlet, it will first perform soaking
for about 15-35 minutes along with slightly pulsator stirring, and then do washing.
* The washing finishing time may be influenced by the water inlet pressure.
It beeps toindicate the
finishing of washing
Confirm the operationof reserve program
Page 10
RESERVE
START
PAUSE
The power will be switched off automatically after the finishing of the washing.
If you open the top lid, the machine will stop working before spinning.
Standard
Gentle
Fast
Program Water
level
Wash
(minute)
About 5~6
About 6~8
About 2
About 2
About 83~45 About 48~30
About 99~55 About 65~40
About 21~17
About 10
About 4About 3
Rinse (minute) Spin
(minute)
Total time (minute)
Rinse twice
Spray twice,
rinse once
Rinse once
Rinse once
Soak included Soak excluded
Using process
Using process
Using process
Night
Reserve time from 2 to 24 hours

7 Disposal After Washing
If the cabinetis dirty, wipe itwith wet softcloth
Do not washwith water directly.
Wipe with neutraldetergent.
Do not wipewith thinner,petrol, alcohol, etc.
1.After washing, close the water faucet. (If desired, dismount the water inlet hose).
2.Do not store water in the washing machine for a long period. Drain the water completely
after each using.
3.Be sure to pull off the power plug before maintenance.
4.Hang up the power cord and drain hose.
5.Wipe off the water drops on the surface of the machine and inside the tub. Open the top lid
for some time (about 1 hour), then close the top lid.
Lint filter:
1.Pull it upto dismount.
2.Push it downto install it.
3.After washing, cleanthe filter screen
Dismount and installDismount CleanInstall
The filter screenis likely tobe blocked byforeign
materials and influencewater inlet. Pleaseclean it
with brush frequently.
Please take off the detergentbox and washit with water
1.How to takeit off: Pull it upwardsslantingly and gently.
2.How to install:Put it infrom the topslantingly, then push
it in tothe right position.
Using process
Using process
Using process

There may be some waterflowing out ofthe drain
hose in thefirst use ofthe machine.
It is thewater remained inthe machine duringthe
ex-factory performance inspection.
Phenomenon Reason How to solve
It rings afterstarting the reserve
function. The digitron displays E0.
The water faucetleaks water
There's abnormal soundinside
the machine
The cascade currentis poor or
there's no cascadecurrent.
The machine
does not act.
The safety switch acts, and the
spinning cannot work (after twice
automatic imbalance revising). The
digitron displays E3 and it rings.
The water inletdoes not work,or is
too slow (cannotreach the water
level after about15 minutes). The
digitron displays E4and it rings.
The drainage cannot work, or is too slow.
The digitron displays E1 and it rings.
After washing andrinsing, it stops
running during spinning.The
digitron displays E2and it rings.
Common phenomena
Phenomena Explanation
The spinning is intermittent whenit starts.
The wash procedure pauses.
The pulsator pauses during water filling in washing and rinsing.
In adding water, the pulsatorperforms stirring slightly
It is tobalance the laundriesto avoid slanting.
The cloth sensoris detecting thecloth. It willstart
adding water afterabout 48 seconds.
The program is setting thedrain time.A certain
period is neededbefore it startsspinning.
It is toavoid splashing duringwater filling.
It is tosoak the laundriesmore completely.
Trouble-shootingAnswers to questions
Trouble-shootingAnswers to questions
Trouble-shootingAnswers to questions
Trouble-shootingAnswers to questions
The top lidis opened.
Is the drainhose blocked?
The top lidis not closed.
Are the laundriesput slantingly?
Is the machineslanting?
Is the machineslanting?
Are there anyforeign materials?
Are the laundriesput slantingly in
spinning?
Is the waterfaucet opened, oris
there water supplyfailure?
Is the waterinlet valve blocked?
Is there foreignmaterial blocking
the spray outlet?
Is there powerfailure?
Is the powerplug inserted tightly?
Is the waterlevel reached preset
position?
Is the screwof the waterinlet hose
jointer loose?
Is the screwof the waterinlet hose
jointer twisted awry?
Close the toplid.
Close the toplid.
Clean the foreignmaterial. Push
the start buttonagain.
Reorder the laundries.Close the toplid.
Set the washingmachine horizontally and
then open andclose the toplid once.
Open the waterfaucet. Push the
Start/Pause button again.
Clean the waterinlet valve thenpush the
Start/Pause button again.
Adjust the machineto be even
Remove the foreignmaterials.
Reorder the laundriesand close thetop lid.
Fasten the screwof the jointerproperly.
Clear the foreignmaterial.
Please use itwhen there's powersupply.
Insert the powerplug tightly.
Fill water tothe preset position.
Push the SPINbutton, but itdoesn't act.
(If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns
sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special
maintenance department or after-sale service department of our company. Do not repair it by yourself.
Not wash
Not spin Is the powerplug inserted tightly?
Is the toplid closed reliably?
Are the laundriesset flat?
Insert the powerplug tightly.
Close the toplid.
Set the laundriesflat.
No water inlet.
Is the power plug plugged tightly?
Is the water faucet opened?
Are the POWER ON/OFF and
START/PAUSE buttons pushed down?
Plug the powerplug tightly.
Open the waterfaucet.
Push the powerON/OFF button and
START/PAUSE button.
The water temperature is too high.
The digital tube displays E5, and rings.
The temperature ishigher
than 60 C. After cooling. Pressthe Star/Pause knob.

Packing list
Name
User's manual
Lint filter
Water inlethose component
Bottom plate
Tapping screw, ST4x16
Fuzzy logic automatic
washing machine
Quantity
Inside the document bag
Inside the document bag
Storage position
Inside the accessory bag
Between the upper cushion of the
washing machine package and the upper
seal of the package carton
Inside the accessory bag
1 piece
1 piece
2 pieces
1 piece
8 pieces
1 set

Model
Rated voltage frequency
Max water consumption
Rated washing power
Rated spinning power
Weight
Dimensions (mm)
DTD 307 XQ
220V ~ 50Hz
7.0kg
380W
260W
About 38kg
L 610 W 555 H 945
Water level/Water
quantity (about)
Water inlet pressure
Specifications
Specifications
Rated washing / spinning capacity
1/23L, 2/30L, 3/34L, 4/40L, 5/44L,
6/49L, 7/53L, 8/57L, 9/61L, 10/66L
About 186L (the highest water level, standard program)
0.03MPa-0.78MPa (when water temperature is
70 ~90 , the water inlet pressure of hot water
shall not exceed 0.4MPa)
