DR FIELD and BRUSH MOWER Maintenance and service guide

TOW-BEHIND DR®FIELD and BRUSH MOWER
SAFETY & OPERATING INSTRUCTIONS
READ AND UNDERSTAND THIS MANUAL AND ALL INSTRUCTIONS
BEFORE OPERATING THIS MOWER.

ii TOW-BEHIND DR®FIELD and BRUSH MOWER
Congratulations on your purchase of a new TOW-BEHIND DR FIELD and BRUSH MOWER!
We have done our utmost to ensure that your TOW-BEHIND DR FIELD and BRUSH MOWER will be one of
the most trouble-free and satisfying pieces of equipment you have ever owned. Please let us know of any
questions you may have. We want to answer them as quickly as possible. When you do call, please have your
serial number and/or order number handy. For technical assistance, please call Toll-Free 1-800-DR-OWNER
(376-9637) and one of our Technical Support Representatives will be happy to help you. We also hope to hear
from you on how much you like your new helper.
In addition, please tell your friends about your new TOW-BEHIND DR FIELD and BRUSH MOWER! Having
DR Owners spread the word about our products and our way of doing business is the best advertising we can
have, and the best way to help us provide even better service in the years to come.
Thanks once again!
for all of us at
Country Home Products, Inc.
SALES MANAGER
COPYRIGHT
©2007 Country Home Products, Inc. All rights reserved.
DR®Power Equipment
A division of Country Home Products®
127 Meigs Road
Vergennes, VT 05491
Toll-Free phone: 1-800-DR-OWNER (376-9637)
Fax: [phone]
Web site:
www.dr-owner.com

CALL TOLL-FREE 1-800-DR-OWNER iii
Table of Contents
CHAPTER 1 ................................................................................................................................................ 1
INTRODUCING:................................................................................................................................ 1
THE TOW-BEHIND DR FIELD and BRUSH MOWER ..................................................................... 1
Conventions used in this manual ..................................................................................................... 1
Specifications..................................................................................................................................... 2
CHAPTER 2 ................................................................................................................................................ 3
GENERAL SAFETY RULES:................................................................................................................ 3
Labels ................................................................................................................................................. 3
Protecting Yourself and Those Around You ..................................................................................... 5
Slope Operation................................................................................................................................. 6
Safety for Children ............................................................................................................................. 6
Safety with Gasoline-Powered Machines.......................................................................................... 7
General Safety.................................................................................................................................... 8
A Note to All Users............................................................................................................................ 9
Additional Information and Potential Changes................................................................................ 9
CHAPTER 3 .............................................................................................................................................. 11
SETTING UP: ................................................................................................................................... 11
THE TOW-BEHIND DR FIELD and BRUSH MOWER ................................................................... 11
TOW-BEHIND DR FIELD and BRUSH MOWER Controls and Features ...................................... 12
Unpacking and Assembling the Machine....................................................................................... 13
About the Battery............................................................................................................................. 14
Connecting the Battery Wire ........................................................................................................... 14
Adding Oil and Gasoline ................................................................................................................. 15
Attaching the Out-Rigger™ Tow Bar to the TOW-BEHIND DR FIELD and BRUSH MOWER..... 16
Connecting the Remote Control Cable and Wire Cord .................................................................. 17
Connecting the TOW-BEHIND DR FIELD and BRUSH MOWER to your Tow Vehicle ................ 19
Attaching the TOW-BEHIND DR FIELD and BRUSH MOWER Remote Control Panel ............... 20
Checking the Tire Pressure.............................................................................................................. 20
CHAPTER 4 .............................................................................................................................................. 21
OPERATING: ................................................................................................................................... 21
THE TOW-BEHIND DR FIELD and BRUSH MOWER ................................................................... 21
Operating Parameters ..................................................................................................................... 21
Before Starting the Engine .............................................................................................................. 23
Starting............................................................................................................................................. 23
Stopping the Engine ........................................................................................................................ 23
Engaging the Blades ........................................................................................................................ 24
Stopping the Blades......................................................................................................................... 24
Adjusting the Mower Deck Height.................................................................................................. 24
Offset Mowing ................................................................................................................................. 25
Slopes and Uneven Terrain ............................................................................................................. 26
If the machine gets hung up ........................................................................................................... 26
Cutting Brush and Saplings ............................................................................................................ 26
Cutting Wet and Heavy Growth ...................................................................................................... 26
CHAPTER 5 .............................................................................................................................................. 27
MAINTAINING:............................................................................................................................... 27
THE TOW-BEHIND DR FIELD and BRUSH MOWER ................................................................... 27
Regular Maintenance Check List..................................................................................................... 27
Removing the Engine Oil and Filter................................................................................................ 28
Removing and Replacing the Blades’ Drive Belt ............................................................................ 29

iv TOW-BEHIND DR®FIELD and BRUSH MOWER
Removing and Replacing the Swinging Blades .............................................................................. 31
Replacing the Wheels ...................................................................................................................... 32
Battery Care...................................................................................................................................... 33
Charging the Battery........................................................................................................................ 33
Disposing of the Battery Responsibly ............................................................................................. 34
Recycling a Used Battery ................................................................................................................. 34
End of Season and Storage ............................................................................................................. 35
CHAPTER 6 .............................................................................................................................................. 37
TROUBLESHOOTING..................................................................................................................... 37
Troubleshooting Table..................................................................................................................... 37
CHAPTER 7 .............................................................................................................................................. 41
PARTS LISTS, SCHEMATIC DIAGRAMS AND WARRANTY.......................................................... 41
Parts List - Deck and Drive Assembly ............................................................................................. 41
Schematic - Deck and Drive Assembly ........................................................................................... 43
Parts List - Wheels and Push Bar Assembly ................................................................................... 44
Schematic - Wheels and Push Bar Assembly.................................................................................. 45
Parts List - Tow Bar and Remote Control Panel Assembly ............................................................ 46
Schematic - Tow Bar and Remote Control Panel Assembly........................................................... 47
Warranty........................................................................................................................................... 51

CALL TOLL-FREE 1-800-DR-OWNER 1
CHAPTER 1
INTRODUCING:
THE TOW-BEHIND DR FIELD and BRUSH MOWER
This manual will help you set up and safely operate your new TOW-BEHIND DR FIELD and BRUSH
MOWER. Careful adherence to the safety and operating instructions in this manual will ensure many years
of productive use. Please let us know of any questions you may have. We want to answer them as quickly
as possible. When you do call, please have your serial number and/or order number handy. For technical
assistance, please call Toll-Free 1-800-DR-OWNER (376-9637) and one of our Technical Support
Representatives will be happy to help you.
Conventions used in this manual
THIS INDICATES A HAZARDOUS SITUATION, WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH OR
SERIOUS INJURY.
Tip: This is a helpful hint to guide you in getting the most out of your TOW-BEHIND DR FIELD and
BRUSH MOWER.
Tools Needed: This indicates you will need a special tool to perform a maintenance function on your
Mower.
NOTE: This information may be helpful to you .
If you are ever unsure about an action you are about to take, don’t do it. Contact Country Home Products’
Toll-Free support at 1-800-DR-OWNER (376-9637) for help or information.
THIS INDICATES A HAZARDOUS SITUATION, WHICH, IF NOT AVOIDED, COULD RESULT IN MINOR
OR MODERATE INJURY .
THIS INFORMATION IS IMPORTANT IN THE PROPER USE OF YOUR MACHINE. FAILURE TO FOLLOW
THIS INSTRUCTION COULD RESULT IN DAMAGE TO YOUR MACHINE OR PROPERTY.

2TOW-BEHIND DR®FIELD and BRUSH MOWER
Specifications
13 HP Model 17 HP Model
Machine Warranty 2 year Residential, 90 day Commercial 2 year Residential, 90 day Commercial
Engine Warranty 2 year Residential, 1 year Commercial 2 year Residential, 2 year Commercial
Engine 13 HP Briggs & Stratton Engine, Electric
Start, OHV, 1 Cast-Iron Sleeve, Full
Pressure Oil Pump w/ Oil Filter, 48 oz
Oil Capacity, Dual-Element Air Filter,
Fuel Pump, Electronic Ignition
17 HP Kawasaki KAI Engine, Electric
Start, V-Twin OHV, 2 Cast-Iron Sleeves,
Full Pressure Oil Pump w/ Oil Filter, 58
oz Oil Capacity, Dual-Element Air Filter,
Fuel Pump, Electronic Ignition
Fuel Tank 2.5 Gallons, Gasoline, Unleaded 2.5 Gallons, Gasoline, Unleaded
Wheels 18" Dia. x 6-7/8" Wide, All Terrain
Tread, 28 PSI, Sealed, Tubeless
18" Dia. x 6-7/8" Wide, All Terrain
Tread, 28 PSI, Sealed, Tubeless
Remote Control Panel Key Switch, Throttle Lever, and Blade
Engage Switch, 5' from Versa-Hitch™ to
front of Control Panel.
Key Switch, Throttle Lever, and Blade
Engage Switch, 5' from Versa-Hitch™ to
front of Control Panel.
Deck Offset 0%, 50%, 75%, 100%
Out-Rigger™ Tow Bar
0%, 50%, 75%, 100%
Out-Rigger™ Tow Bar
Adjustable Cutting Height 5", 6-1/4", and 7-1/2"
Step & Mow™ Wheel Axle
and Versa-Hitch™
5", 6-1/4", and 7-1/2"
Step & Mow™ Wheel Axle
and Versa-Hitch™
Cutting Width 44" 44"
Cutting Capacity 4' High Grass, 1-1/2" Thick Saplings 6' High Grass, 1-1/2" Thick Saplings
Blade Tip Speed 195 MPH or 17,180 Ft/Min 195 MPH or 17,180 Ft/Min
Swinging Blades “PRO-TEK” Swinging Blades
2 Blades, .25" Thick x 16-1/2" Long
Hardened Steel
“PRO-TEK” Swinging Blades
2 Blades, .25" Thick x 16-1/2" Long
Hardened Steel
Deck 11 GA (.12" thick) Welded Steel 11 GA (.12" thick) Welded Steel
Spindle 1-3/8" Dia. Shaft with 2 Sealed 30 mm
Bearings
1-3/8" Dia. Shaft with 2 Sealed 30 mm
Bearings
Spindle Housing 7 GA (.18" thick) Welded Steel 7 GA (.18" thick) Welded Steel
Push Bar 1-1/4" Dia. x 11 GA (.12" thick) Steel
Tubing
1-1/4" Dia. x 11 GA (.12" thick) Steel
Tubing
Front Guard 3/16" Thick Compressed Rubber 3/16" Thick Compressed Rubber
Belt 5/8" x 53.8" Type BP51 5/8" x 53.8" Type BP51
Electric Clutch 75 ft-lb Ogura 75 ft-lb Ogura
Fuses 20 AMP Type AGC Fuse (Engine
Alternator Circuit)
7 AMP Type AGC Fuse (Clutch Circuit)
20 AMP Type AGC Fuse (Engine
Alternator Circuit)
7 AMP Type AGC Fuse (Clutch Circuit)
Machine Overall Width 64-1/4" Outside the Wheels 64-1/4" Outside the Wheels
Machine Overall Length 110" with the Tow Bar fully extended 110" with the Tow Bar fully extended
Machine Overall Height 28-1/4" 28-7/8"
Machine Weight at Tow Bar 35 lbs. 27 lbs.
Machine Weight 442 lbs. 465 lbs.
Shipping Weight 617 lbs. 641 lbs.
Shipping Crate 73" x 60" x 36" 73" x 60" x 36"

CALL TOLL-FREE 1-800-DR-OWNER 3
CHAPTER 2
GENERAL SAFETY RULES:
READ THIS SAFETY
& OPERATING INSTRUCTIONS MANUAL BEFORE YOU USE THE TOW-BEHIND DR FIELD
AND BRUSH MOWER. BECOME FAMILIAR WITH THE SERVICE RECOMMENDATIONS TO ENSURE THE BEST
PERFORMANCE FROM YOUR MOWER.
Labels
Your TOW-BEHIND DR FIELD and BRUSH MOWER carries prominent labels as reminders for its proper
and safe use. Shown below are copies of all the labels that appear on the equipment. Take a moment to
study them and make a note of their location on your TOW-BEHIND DR FIELD and BRUSH MOWER as you
assemble and before
you operate the machine. Replace damaged or missing safety and information labels
immediately.
Keep combustible substances away from
the Engine when it is hot. (#136831)
Make sure you add oil before starting the
Engine; the unit shipped without oil. Fill
the oil reservoir slowly to make sure you
do not overfill it. (#127811)
Use caution operating the
machine on slopes.
Keep body parts away
from the Mower Blades.
Always wear safety glasses
or goggles while operating
the machine.
Remove all objects that
could be thrown by the
Mower Blades.
Do not operate the
machine near people
or animals.
Read the Safety &
Operating Instructions
Manual.

4TOW-BEHIND DR®FIELD and BRUSH MOWER
To avoid injury, keep your hands and
feet away from the spinning Blades.
(#136491)
This label reminds you operate the machine safely and provides
helpful operating information. (#222221)

CALL TOLL-FREE 1-800-DR-OWNER 5
Protecting Yourself and Those Around You
THIS IS A HIGH-POWERED MACHINE WITH FAST MOVING PARTS OPERATING AT HIGH SPEEDS. YOU
MUST OPERATE THIS MACHINE SAFELY. UNSAFE OPERATION CAN CREATE HAZARDS FOR YOU, AS WELL
AS ANYONE ELSE IN THE WORK AREA. USE PROPER CLOTHING AND SAFETY GEAR WHEN OPERATING
THIS MACHINE TO PREVENT OR MINIMIZE THE RISK OF SEVERE INJURY. ALWAYS TAKE THE
FOLLOWING PRECAUTIONS WHEN OPERATING THE TOW-BEHIND DR FIELD AND BRUSH MOWER:
• ALWAYS WEAR PROTECTIVE GOGGLES OR SAFETY GLASSES WITH SIDE SHIELDS WHILE MOWING TO
PROTECT YOUR EYES FROM POSSIBLE OBJECTS THROWN FROM THE MACHINE.
• WE RECOMMEND WEARING SAFETY SHOES WHEN USING THIS MACHINE. WEAR SHOES WITH
NON-SLIP TREADS TO IMPROVE FOOTING ON SLIPPERY SURFACES. DO NOT USE THE MACHINE
WEARING OPEN SANDALS OR WHILE BAREFOOT.
• WE RECOMMEND WEARING LONG PANTS AND GLOVES WHILE USING THIS MACHINE. BE SURE THE
GLOVES FIT PROPERLY AND DO NOT HAVE LOOSE CUFFS OR DRAWSTRINGS.
• WE RECOMMEND THE USE OF EAR PROTECTORS OR EAR PLUGS RATED FOR AT LEAST 20 DBA TO
PROTECT YOUR HEARING.
• ALLOW ONLY RESPONSIBLE INDIVIDUALS WHO ARE FAMILIAR WITH THESE GENERAL SAFETY RULES
AND OPERATING INSTRUCTIONS TO USE YOUR TOW-BEHIND DR FIELD AND BRUSH MOWER.
NEVER ALLOW PEOPLE WHO ARE UNFAMILIAR WITH THESE RULES AND INSTRUCTIONS TO USE
YOUR MACHINE.
• HAVE A COMPLETE WORKING KNOWLEDGE OF YOUR TOW VEHICLE AND KNOW HOW TO HANDLE
IT WITH THE TOW-BEHIND DR FIELD AND BRUSH MOWER ATTACHED.
• KEEP YOUR HANDS AND FEET AWAY FROM THE BLADES, BELT, BLADE PULLEY, AND CONCEALED
AREAS WHILE THE ENGINE IS RUNNING. NEVER REACH UNDER THE DECK OR GRAB HOLD OF ANY
PART OF THE DECK WHEN THE ENGINE IS RUNNING.
• KEEP BYSTANDERS AT LEAST 100 FEET AWAY FROM YOUR WORK AREA AT ALL TIMES. THE MOWER
CAN THROW OBJECTS FAR AND AT GREAT SPEEDS. TO BE SAFE, DO NOT OPERATE THE TOW-
BEHIND DR FIELD AND BRUSH MOWER NEAR CHILDREN OR PETS, AND NEVER ALLOW CHILDREN
TO OPERATE THE MACHINE. STOP THE TOW VEHICLE AND THE TOW-BEHIND DR FIELD AND BRUSH
MOWER ENGINE WHEN ANOTHER PERSON OR PET APPROACHES.
• CLEAR THE AREA OF OBJECTS SUCH AS ROCKS, TOYS, WIRE, BONES, STICKS, ETC., WHICH COULD BE
PICKED UP AND THROWN BY THE BLADES.
• BE SURE THE BLADE CONTROL KNOB IS DOWN (DISENGAGED) BEFORE ATTEMPTING TO START THE
ENGINE.
• NEVER GET OFF THE TOW VEHICLE WITHOUT FIRST STOPPING THE BLADES AND SHUTTING OFF
THE TOW VEHICLE ENGINE AND THE TOW-BEHIND DR FIELD AND BRUSH MOWER ENGINE.
• DO NOT TOUCH THE MUFFLER AND ENGINE WHEN THE MACHINE IS IN USE AS THEY BECOME
VERY HOT AND CAN CAUSE SEVERE BURNS.
• NEVER, UNDER ANY CONDITIONS, REMOVE, BEND, CUT, FIT, WELD, OR OTHERWISE ALTER
STANDARD PARTS ON THE TOW-BEHIND DR FIELD AND BRUSH MOWER. THIS INCLUDES ALL
SHIELDS AND GUARDS. MODIFICATIONS TO YOUR MACHINE COULD CAUSE PERSONAL INJURIES
AND PROPERTY DAMAGE AND WILL VOID YOUR WARRANTY.

6TOW-BEHIND DR®FIELD and BRUSH MOWER
Slope Operation
USE OF MACHINERY ON SLOPES IS A MAJOR FACTOR RELATED TO ACCIDENTS, WHICH CAN RESULT IN
SEVERE PERSONAL INJURY. USE OF MACHINERY ON SLOPES REQUIRES CAUTION. IF YOU FEEL UNEASY
USING THE TOW-BEHIND DR FIELD AND BRUSH MOWER ON A SLOPE, DO NOT OPERATE IT. ALWAYS
TAKE THE FOLLOWING PRECAUTIONS WHEN USING THIS MACHINE ON SLOPES:
ALWAYS:
• OPERATE THE MACHINE UP AND DOWN THE FACE OF SLOPES AND AVOID GOING ACROSS.
EXERCISE EXTREME CAUTION WHEN CHANGING DIRECTION ON SLOPES.
• REMOVE OBJECTS SUCH AS GLASS, LARGE STICKS, STONES, METAL OBJECTS, WIRE, ROPE, AND
STRING-LIKE MATERIAL.
• WATCH FOR HOLES, RUTS, AND BUMPS ON THE GROUND.
NEVERS:
• NEVER OPERATE NEAR DROP-OFFS, DITCHES, OR EMBANKMENTS; YOU COULD LOSE CONTROL OF
YOUR TOW VEHICLE AND/OR THE TOW-BEHIND DR FIELD AND BRUSH MOWER.
• NEVER OPERATE ON SLOPES GREATER THAN 20 DEGREES, OR ON ANY EXCESSIVELY STEEP SLOPE.
SEE THE OPERATING PARAMETERS SECTION ON PAGE 21 FOR FURTHER RESTRICTIONS RELATING
TO YOUR TOW VEHICLE.
• NEVER OPERATE ON WET, OR SLIPPERY SLOPES. REDUCED TRACTION COULD RESULT IN TIPPING
OVER YOUR TOW VEHICLE AND/OR THE TOW-BEHIND DR FIELD AND BRUSH MOWER.
• NEVER PARK THE TOW VEHICLE ON A STEEP GRADE OR SLOPE.
Safety for Children
TRAGIC ACCIDENTS CAN OCCUR IF THE OPERATOR IS NOT ALERT TO THE PRESENCE OF CHILDREN.
CHILDREN CAN BE ATTRACTED TO THE TOW-BEHIND DR FIELD AND BRUSH MOWER AND THE MOWING
ACTIVITY. NEVER
ASSUME THAT CHILDREN WILL REMAIN WHERE YOU LAST SAW THEM.
• KEEP CHILDREN OUT OF THE WORK AREA AND UNDER THE WATCHFUL CARE OF A RESPONSIBLE
ADULT.
• BE ALERT AND ALWAYS TURN OFF YOUR TOW VEHICLE ENGINE AND THE DR TOW-BEHIND FIELD &
BRUSH MOWER ENGINE IF CHILDREN ENTER THE WORK AREA.
• BEFORE, AND WHILE MOVING YOUR TOW VEHICLE BACKWARDS, LOOK BEHIND, AND DOWN FOR
SMALL CHILDREN.
• NEVER ALLOW CHILDREN TO OPERATE THE TOW-BEHIND DR FIELD AND BRUSH MOWER.
• NEVER ALLOW CHILDREN TO RIDE ON THE MOWER, EVEN IF THE ENGINE IS NOT RUNNING.
• USE EXTRA CARE WHEN APPROACHING BLIND CORNERS, SHRUBS, TREES, OR OTHER OBJECTS THAT
MAY OBSCURE YOUR VISION.

CALL TOLL-FREE 1-800-DR-OWNER 7
Safety with Gasoline-Powered Machines
GASOLINE IS A HIGHLY FLAMMABLE LIQUID. GASOLINE ALSO GIVES OFF FLAMMABLE VAPOR THAT
CAN BE EASILY IGNITED AND CAUSE A FIRE OR EXPLOSION. NEVER OVERLOOK THE HAZARDS OF
GASOLINE AND ALWAYS FOLLOW THESE PRECAUTIONS:
• NEVER RUN THE TOW-BEHIND DR FIELD AND BRUSH MOWER ENGINE IN AN ENCLOSED AREA
OR WITHOUT PROPER VENTILATION AS THE EXHAUST FROM THE ENGINE CONTAINS CARBON
MONOXIDE, WHICH IS AN ODORLESS, TASTELESS, AND DEADLY POISONOUS GAS.
• STORE ALL FUEL AND OIL IN CONTAINERS SPECIFICALLY DESIGNED AND APPROVED FOR THIS
PURPOSE AND KEEP AWAY FROM HEAT, OPEN FLAME, AND OUT OF THE REACH OF CHILDREN.
• FILL THE GASOLINE TANK OUTDOORS WITH THE ENGINE OFF AND ALLOW THE ENGINE TO
COOL COMPLETELY. DO NOT HANDLE GASOLINE IF YOU OR ANYONE NEARBY IS SMOKING, OR
IF YOU ARE NEAR ANYTHING THAT COULD CAUSE IT TO IGNITE OR EXPLODE. REPLACE THE
FUEL TANK AND FUEL CONTAINER CAPS SECURELY.
• IF YOU SPILL GASOLINE, DO NOT ATTEMPT TO START THE ENGINE. MOVE THE MACHINE AWAY
FROM THE AREA OF THE SPILL AND AVOID CREATING ANY SOURCE OF IGNITION UNTIL THE
GAS VAPORS HAVE DISSIPATED. WIPE UP ANY SPILLED FUEL TO PREVENT A FIRE HAZARD AND
PROPERLY DISPOSE OF THE WASTE.
• ALLOW THE TOW-BEHIND DR FIELD AND BRUSH MOWER ENGINE TO COOL COMPLETELY
BEFORE STORING IN ANY ENCLOSURE. NEVER STORE THE MACHINE WITH GAS IN THE TANK
OR WITH GAS IN A FUEL CONTAINER NEAR AN OPEN FLAME OR SPARK SUCH AS A WATER
HEATER.
• NEVER MAKE ADJUSTMENTS OR REPAIRS WITH THE ENGINE RUNNING. BEFORE MAKING AN
ADJUSTMENT OR REPAIR, SHUT OFF THE TOW-BEHIND DR FIELD AND BRUSH MOWER ENGINE,
WAIT FIVE (5) MINUTES TO COOL, THEN DISCONNECT THE SPARK PLUG WIRE(S) AND KEEP THE
WIRE(S) AWAY FROM THE SPARK PLUG(S) TO PREVENT ACCIDENTAL STARTING.
• NEVER CHECK FOR AN IGNITION SPARK WITH THE SPARK PLUG OR SPARK PLUG WIRE(S)
REMOVED. ALWAYS USE AN APPROVED SPARK TESTER.
• NEVER TAMPER WITH SAFETY DEVICES. REGULARLY CHECK THEIR PROPER OPERATION.
• NEVER CHANGE THE ENGINE GOVERNOR SETTINGS OR MODIFY THE ENGINE SPEED.
MODIFICATIONS WILL VOID YOUR WARRANTY.
• TO REDUCE FIRE HAZARD, KEEP THE ENGINE AND MUFFLER AREA FREE OF DEBRIS BUILD-UP
SUCH AS LEAVES, GRASS, OIL, GREASE, OR ANY OTHER COMBUSTIBLE MATERIAL. CLEAN THE
ENGINE AREA AFTER EACH USE.
• NEVER OPERATE THE ENGINE WITHOUT THE MUFFLER. INSPECT THE MUFFLER PERIODICALLY
AND REPLACE IF NECESSARY. IF THE ENGINE IS EQUIPPED WITH A MUFFLER DEFLECTOR,
INSPECT IT PERIODICALLY AND REPLACE IF NECESSARY.
• NEVER OPERATE THE ENGINE WITH THE AIR CLEANER OR COVER OVER THE CARBURETOR AIR
INTAKE REMOVED, EXCEPT FOR ADJUSTMENT. REMOVAL OF SUCH PARTS COULD CREATE A FIRE
HAZARD. DO NOT USE FLAMMABLE SOLUTIONS TO CLEAN THE AIR FILTER.
• ALWAYS CHECK FUEL LINES AND FITTINGS FREQUENTLY FOR CRACKS OR LEAKS, REPLACE IF
NECESSARY.

8TOW-BEHIND DR®FIELD and BRUSH MOWER
General Safety
SAFE OPERATION OF THE TOW-BEHIND DR FIELD AND BRUSH MOWER IS NECESSARY TO PREVENT OR
MINIMIZE THE RISK OF DEATH OR SERIOUS INJURY. UNSAFE OPERATION CAN CREATE A NUMBER OF
HAZARDS FOR YOU. ALWAYS TAKE THE FOLLOWING PRECAUTIONS WHEN OPERATING THIS MACHINE:
• THE TOW-BEHIND DR FIELD AND BRUSH MOWER IS A POWERFUL TOOL AND NOT A PLAYTHING.
WHEN USING THIS MACHINE, EXERCISE EXTREME CAUTION AT ALL TIMES. THE DESIGN OF THIS
MACHINE IS TO MOW GRASS AND BRUSH. DO NOT USE IT FOR ANY OTHER PURPOSE.
• THE OPERATOR OR USER OF THE TOW-BEHIND DR FIELD AND BRUSH MOWER IS RESPONSIBLE FOR
ACCIDENTS OR HAZARDS OCCURRING TO OTHER PEOPLE, THEIR PROPERTY, AND THEMSELVES.
• ALWAYS MOUNT THE REMOTE CONTROL PANEL WITHIN EASY REACH OF THE OPERATOR’S POSITION.
• KNOW HOW TO QUICKLY STOP THE TOW-BEHIND DR FIELD AND BRUSH MOWER. SEE PAGE 22.
• NEVER ALLOW PEOPLE OR PETS TO RIDE ON THIS MACHINE, EVEN WITH THE ENGINE TURNED OFF.
• IF THE MACHINE SHOULD MAKE AN UNUSUAL NOISE OR VIBRATION, SHUT OFF THE TOW VEHICLE
AND THE TOW-BEHIND DR FIELD AND BRUSH MOWER ENGINES. VIBRATION IS GENERALLY A
WARNING OF TROUBLE. WAIT FIVE (5) MINUTES FOR THE TOW-BEHIND DR FIELD AND BRUSH
MOWER ENGINE TO COOL. DISCONNECT THE SPARK PLUG WIRE(S) AND THEN INSPECT THE
MACHINE FOR CLOGGING, OR LOOSE ENGINE MOUNTING BOLTS. CLEAR ANY OBSTRUCTIONS
AND REPAIR AND/OR REPLACE DAMAGED PARTS.
• THE MOWER BLADES ARE SHARP AND CAN CUT. WRAP THE BLADES OR WEAR GLOVES, AND USE
EXTRA CAUTION WHEN SERVICING.
• ALWAYS KEEP THE MACHINE IN GOOD SAFE OPERATING CONDITION. ALWAYS MAKE CERTAIN
NUTS AND BOLTS ARE TIGHT AND ALWAYS USE THE SUPPLIED SELF-LOCKING HARDWARE. DO NOT
USE SUBSTITUTE HARDWARE.
• ALWAYS SHUT OFF THE TOW VEHICLE ENGINE TOW-BEHIND DR FIELD AND BRUSH MOWER ENGINE,
WAIT FIVE (5) MINUTES TO COOL, AND DISCONNECT THE SPARK PLUG WIRE(S) BEFORE ATTEMPTING
TO REMOVE GRASS OR DEBRIS FROM THE UNDERSIDE OF THE DECK.
• USE THE TOW-BEHIND DR FIELD AND BRUSH MOWER ONLY IN DAYLIGHT AND GIVE COMPLETE
AND UNDIVIDED ATTENTION TO THE JOB AT HAND.
• DO NOT HURRY OR TAKE THINGS FOR GRANTED WHEN USING THE TOW-BEHIND DR FIELD AND
BRUSH MOWER. WHEN IN DOUBT ABOUT THE MACHINE OR YOUR SURROUNDINGS, STOP THE
MOWING ACTIVITY AND TAKE TIME TO LOOK THINGS OVER.
• DISENGAGE THE BLADES AND EXERCISE EXTREME CAUTION WHEN ON OR CROSSING DRIVES,
WALKS, OR ROADS. STAY ALERT FOR HIDDEN HAZARDS OR TRAFFIC.
• IF LEAVING THE MACHINE, SHIFT THE TOW VEHICLE INTO NEUTRAL AND SET THE PARKING BRAKE;
TURN OFF THE TOW VEHICLE ENGINE AND REMOVE ITS KEY; TURN OFF THE TOW-BEHIND DR FIELD
AND BRUSH MOWER ENGINE AND REMOVE ITS KEY.
• DO NOT OPERATE THE MOWER WHEN UNDER THE INFLUENCE OF ALCOHOL, DRUGS, OR MEDICATION.
• SEE THE MANUFACTURER’S INSTRUCTIONS FOR PROPER OPERATION AND INSTALLATION OF
ACCESSORIES. ONLY USE ACCESSORIES APPROVED BY COUNTRY HOME PRODUCTS, INC.
• NO LIST OF WARNINGS AND CAUTIONS CAN BE ALL-INCLUSIVE. IF SITUATIONS OCCUR THAT ARE
NOT COVERED BY THIS MANUAL, THE OPERATOR MUST APPLY COMMON SENSE AND OPERATE THE
TOW-BEHIND DR FIELD AND BRUSH MOWER IN A SAFE MANNER. CALL 1-800-DR-OWNER (376-9637)
FOR ASSISTANCE.

CALL TOLL-FREE 1-800-DR-OWNER 9
A Note to All Users
Under California law, and the laws of some other states, you are not permitted to operate an internal
combustion engine using hydrocarbon fuels without an engine spark arrester. This also applies to operation
on US Forest Lands. All TOW-BEHIND DR FIELD and BRUSH MOWERS shipped to California, New Mexico,
and Washington State are provided with spark arresters. Failure of the owner/operator to maintain this
equipment in compliance with state regulations is a misdemeanor under California law and may be in
violation of other state and/or federal regulations. Contact your local fire marshal or forest service for specific
information in your area.
Additional Information and Potential Changes
Country Home Products, Inc. reserves the right to discontinue, change, and improve its products at any time
without notice or obligation to the purchaser. The descriptions and specifications contained in this manual
were in effect at printing. Equipment described within this manual may be optional. Some illustrations may
not be applicable to your machine.

10 TOW-BEHIND DR®FIELD and BRUSH MOWER

CALL TOLL-FREE 1-800-DR-OWNER 11
CHAPTER 3
SETTING UP:
THE TOW-BEHIND DR FIELD and BRUSH MOWER
This chapter outlines a few simple steps you will need to follow to set up your new machine before you use
it. It may be helpful to familiarize yourself with the controls and features on your new machine by reviewing
Figure 1 on the following page before beginning the steps outlined in this chapter. If you have any
questions at all, please feel free to contact our Technical Support Representatives at our Toll-Free number:
1-800-DR-OWNER (376-9637).

12 TOW-BEHIND DR®FIELD and BRUSH MOWER
TOW-BEHIND DR FIELD and BRUSH MOWER Controls and Features
NOTE:The model shown in Figure 1 may look slightly different from your machine.
Figure 1
Throttle Control
Blade Control Knob
Kawasaki 17 HP Engine
(Briggs
& Stratton 13HP will
look di
ff
erent than shown
)
Electric-Start Key Switch
Oil Fill
Fuel Tank
Battery
Off
On
Fuel Shut-Off
Valve
Remote Control Panel
Left Step
& Mow™ Height Adjuster
Fuel Filter
Versa-Hitch™
Push Bar
Out-Rigger™ Tow Bar
Front Guard
Out-Rigger™ Tow Bar
Locking Pin
Right Step & Mow™
Height Adjuster
Pulley Cover

CALL TOLL-FREE 1-800-DR-OWNER 13
Unpacking and Assembling the Machine
NOTE: Unpacking and assembling the TOW-BEHIND DR FIELD and BRUSH MOWER is a two-person
job as the 13 HP unit weighs 442 pounds and the 17 HP unit weighs 465 pounds. We recommend
you have an extra set of hands available before you begin.
Parts Supplied in Crate:
• TOW-BEHIND DR FIELD and BRUSH MOWER
• Safety & Operating Instructions Manual
• Briggs & Stratton or Kawasaki Engine Manual
• Small Parts Bag:
- Hitch Tongue Extender with 1/2" x 2" Bolt, Lock Nut and Washers
- Hook and Loop Straps
- Plastic hose (oil drain)
- Extra Zip-Tie Wraps
Tools and Supplies Needed:
• Pry Bar
• Metal Shears
• Hammer
• Gloves and Eye Protection
• STABILIZE THE SHIPPING CONTAINER ON CLEAN FLAT TERRAIN BEFORE ATTEMPTING TO
UNPACK AND ASSEMBLE THE MACHINE.
• ALWAYS WEAR EYE PROTECTION AND STAND TO ONE SIDE WHEN CUTTING THE BANDING. THE
BANDING IS UNDER A LOT OF TENSION AND CAN CAUSE INJURY WHEN YOU RELEASE THE
TENSION.
• USE CAUTION AROUND EXPOSED NAILS WHEN UNCRATING THE MACHINE.
1. Pry off and remove the top cross members of the shipping crate. Be careful of the nails when
removing the boards.
2. Pry off and remove the crate sides; the two (2) long sides first, and then the two (2) short sides.
3. Stand to one side and cut any bands holding the machine to the shipping pallet and the bands
holding the Remote Control Panel carton to the Push Bar. Be careful when cutting the banding.
WEAR GLOVES AND BE VERY CAREFUL WHEN HANDLING THE DECK. THE BLADES ARE VERY SHARP,
AND MAY SPIN AS YOU MANEUVER THE DECK.
4. The Out-Rigger™ Tow Bar shipped unassembled; remove it from the pallet.
5. Raise the Mower Deck Height to the highest setting (7-1/2") to clear the blocking beneath the back
of the machine (see page 24) and then roll the Mower off the shipping pallet.
6. Remove the Blade Protector from the Blades. (See CAUTION note above)
7. Do not discard your pallet and packaging material until you are fully satisfied with your new TOW-
BEHIND DR FIELD and BRUSH MOWER.

14 TOW-BEHIND DR®FIELD and BRUSH MOWER
About the Battery
The TOW-BEHIND DR FIELD and BRUSH MOWER comes with a 12-Volt, maintenance-free, rechargeable,
sealed lead acid Battery. Properly maintained and charged, the Battery provides years of dependable service.
ELECTRICAL HAZARD: PREVENT FIRE
• NEVER MODIFY THE TOW-BEHIND DR FIELD AND BRUSH MOWER’S ELECTRICAL SYSTEM.
MODIFICATIONS COULD RUIN THE ELECTRICAL SYSTEM AS WELL AS CAUSE A FIRE, RESULTING IN
SERIOUS INJURY.
• USING ELECTRICAL COMPONENTS OTHER THAN THOSE SUPPLIED WITH YOUR MACHINE COULD
CAUSE THE ELECTRICAL SYSTEM TO OVERHEAT, EXPLODE, OR START A FIRE.
• USING THE WRONG TYPE OF BATTERY OR CHARGER COULD CAUSE A FIRE OR EXPLOSION,
RESULTING IN SERIOUS INJURY.
• USE THE CHARGER ONLY IN DRY LOCATIONS. AVOID CONTACT WITH WATER.
• ONLY ADULTS SHOULD HANDLE THE BATTERY. IT CONTAINS SULFURIC ACID (AN ELECTROLYTE)
AND THE BATTERY IS HEAVY; DROPPING IT COULD RESULT IN SERIOUS INJURY.
• NEVER ALLOW CHILDREN TO CHARGE THE BATTERY. THE ELECTRICITY INVOLVED IN CHARGING
THE BATTERY COULD INJURE A CHILD.
• EXAMINE THE CHARGER, ITS CONNECTORS, AND THE BATTERY FOR EXCESSIVE WEAR OR DAMAGE
EACH TIME YOU CHARGE THE BATTERY. IF YOU SEE ANY EXCESSIVE WEAR OR DAMAGE, DO NOT
USE THE CHARGER OR THE BATTERY, REPLACE THEM.
• NEVER LIFT OR CARRY THE BATTERY BY THE CABLES OR TERMINALS. THIS CAN DAMAGE THE
BATTERY AND POSSIBLY START A FIRE, RESULTING IN SERIOUS INJURY. LIFT AND CARRY THE
BATTERY ONLY BY ITS CASE.
• DO NOT SHORT CIRCUIT THE BATTERY.
• READ THE SAFETY INSTRUCTIONS ON THE BATTERY.
Connecting the Battery Wire
We ship all Electric-Starting systems with the negative terminal Battery wire disconnected. This prevents the
Battery from discharging during shipment. Before using your TOW-BEHIND DR FIELD and BRUSH MOWER,
you must connect the Battery wire.
Tools Needed:
(2) 5/16" Wrench or Socket
Connect the Green negative wire to the negative terminal on the Battery (Figure 2)
.
Negative Battery Terminal
Figure 2
Battery
Green Negative Wire

CALL TOLL-FREE 1-800-DR-OWNER 15
Adding Oil and Gasoline
• YOU MUST ADD OIL BEFORE STARTING THE ENGINE. THIS MACHINE SHIPPED WITHOUT OIL.
TRACES OF OIL MAY BE IN THE RESERVOIR FROM FACTORY TESTING, BUT YOU MUST ADD OIL
BEFORE STARTING THE ENGINE. FILL THE RESERVOIR SLOWLY, CHECKING THE DIPSTICK
FREQUENTLY TO AVOID OVERFILLING.
• TO GET AN ACCURATE READING WHEN CHECKING THE OIL LEVEL:
⇒ THE MACHINE SHOULD BE ON A LEVEL SURFACE.
⇒ THE DIPSTICK SHOULD BE SCREWED DOWN ON BRIGGS & STRATTON ENGINES.
⇒ THE DIPSTICK SHOULD
NOT BE SCREWED DOWN ON KAWASAKI ENGINES.
Tip: To avoid confusion, we recommend leaving the caps ON the Fuel and Oil Fills until you are ready to
pour either gasoline or oil into the correct Fill.
NOTE:Use only SAE 30 HD (High Detergent) oil. Other types of oil could cause problems with the operation of
your machine. Please refer to your Engine Owner’s Manual for detailed oil information.
Approximate Engine Oil Required
Briggs & Stratton - 13 HP 48 oz. (1.4 L)
Kawasaki - 17 HP 58 oz. (1.7 L)
1. Place the machine on a level surface and initially add 32 oz. of SAE 30 High Detergent oil
(recommended by the Engine Manufacturer) into the Oil Fill (Figure 3) and wait one minute for the oil
to settle.
2. Check the Dipstick and continue adding a few ounces of oil at a time, rechecking the Dipstick until the
oil reaches the fill mark. Be careful not to overfill.
3. Fill the Fuel Tank to not more than 1/4" from the bottom of the Fill Neck with fresh, unleaded gas.
See the Engine Owner’s Manual for more information.
Fuel Fill
Oil Fill
Figure 3
Briggs & Stratton 13 HP Engine Kawasaki 17 HP Engine
Oil Fill
Fuel Fill

16 TOW-BEHIND DR®FIELD and BRUSH MOWER
Attaching the Out-Rigger™ Tow Bar to the TOW-BEHIND DR FIELD and BRUSH MOWER
WHEN ATTACHING THE TOW BAR AND CONTROL CABLES, YOU MUST FIRST DISCONNECT THE
SPARK PLUG WIRE(S), KEEPING IT AWAY FROM THE SPARK PLUG(S) TO PREVENT ACCIDENTAL
STARTING OF THE ENGINE.
Tool Needed:
• 7/16" Wrench or Socket
1. Using a 7/16" Wrench or Socket, remove the three (3)
Bolts and Washers that retain the Black Pulley Cover
and remove the Cover (Figure 4).
2. Locate and remove the Tow Bar Retaining Pin and
Collar from the Pivot Pin on the front of the Mower
Deck (Figure 4).
3. Pull the Handle of the Tow Bar Locking Pin up so its
Cross Pin is above the Tow Bar and then twist the
Handle 90º so the Cross Pin rests on the Tow Bar
(Figure 5).
Adjusting Tip: Enlist the help of another person to hold
the Tow Bar level during the next step.
4. Place the Tow Bar over the Pivot Pin and install the
Collar and the Tow Bar Retaining Pin (Figure 5).
NOTE: The Remote Control Panel Throttle Cable and Wire
Cord are routed inside the Tow Bar housing. Use care
not to pinch them when attaching the Tow Bar over
the Pivot Pin.
5. Pull the Tow Bar Locking Pin Handle (Figure 5) up,
turn it 90º, and release the Locking Pin into the center
hole in the Tow Bar Mount Plate (Figure 5).
Figure 4
Retaining
Bolts and
Washers
Zip-Tie Tow Bar
Retaining
Pin
Collar
Pivot Pin
Figure 5
Tow Bar Locking
Pin Handle
Tow Bar
Collar
Tow Bar
Retaining Pin
Pivot
Pin
Tow Bar
Mount Plate
Cross Pin
Pulley Cover
Hole
s
