Dream Vision Eos Series User manual

www.dreamvision.net
Part. No.: R699904
Upgrade procedure for Eos Series
Date: 15032019 Rev: 01

USB drive
page 2
Required Equipment:
To successfully complete this procedure you will need the following equipment:
• This projector
• Acomputertocopythelatestrmwareupdate
• An USB drive/Key, FAT32 formatted with 1 Go of free space or more
Downloading and extracting the rmware:
• Download the zip le for the update onto the PC. The le name should be
jkcpj201601v[xxxx].zipwherexxxxistheversionnumber
• Unzipthisleandcopythe“UD_B2A1”folderanditscontentstotherootdirectoryof
theUSBdrive.TheUSBdriveshouldcontainonlyonefoldernamedUD_B2A1.
WARNING: Placing the copied data in a location other than the root directory, changing the
folder name and le name can prevent the rmware from updating properly.
Checking the current rmware version:
• TurnontheprojectorandgointotheMenuandbrowsetoMenu>InformationMenu.
Youcanalsopressthe“INFO”buttonontheRCUtodirectaccessthismenu.
• Thecurrentrmwareversionisdisplayedatthe“SoftVer.”line.
• Ifthermwareversionoftheprojectoristhesameastheversionoftheupdatele,
thatmeansthatthisprojectorisuptodateanddoesn’tneedanupdate.Ifthermware
version is an earlier version, please proceed to the next steps.
Performing the Update:
• Connect the USB drive to the “SERVICE” terminal located at the rear side of the
projector.
• TurnontheprojectorandgointotheMenuandbrowsetothissub-menu:

page 3
Menu>Function>“SoftwareUpdate”
• Selectthe“SoftwareUpdate”inthemenu.Aconrmationscreenaskingwhetherto
start the software update appears.
• Beforeconrmingtheupgrade,checktherequiredtime.Thenselect“Yes”toconrm
thebeginningoftheupgradeprocedure.
CAUTION: !!! Do not turn off the projector or remove the USB drive while updating.
Interrupting the update may cause the projector to malfunction !!!
• Oncetherequiredtimeisreachedandthattheupdateiscompleted,theprojectorwill
automaticallyturnoffandalltheLEDindicatorswillgoout.
• Youcan turnon thepower again, by pressing the[Power] buttonon theprojector.
Alternatively,youcanpressanybuttonontheRCUtoexitthestandbystateandthen
pressthe[ON]buttontoswitchthisprojectoron.
Checking the new Firmware Version after the upgrade procedure:
• TurnontheprojectorandgointotheMenuandbrowsetoMenu>InformationMenu.
Youcanalsopressthe“INFO”buttonontheRCUtodirectaccessthismenu.
• Thecurrentrmwareversionisdisplayedatthe“SoftVer.”line.Iftheversionnumber
is the same as the Firmware le version, then the upgrade procedure has been
successful.

OperatingLEDs
STBY/ON
LIGHT
WARNING
page 4
LED Indication during the Update:
Standby/On,LIGHT/WARNINGLEDs
lightupsequencefromrighttoleftLEDs
Data writing in progress
Standby/OnandWarninglightupsimultaneouslyand
blinkalternatelywithLight
USB drive detection in
progress
Blink simultaneously
Update error: Request for
repair at your authorized
dealer.
Troubleshooting:
Iftheupdatedoesnotendevenafterithaslongpasttheestimatedrequiredtime,thereis
apossibilitythatupdatehasfailed.Youshouldrequestforrepairatyourauthorizeddealer
.
Double check that the USB drive is correctly
inserted and that it is correctly formatted in
FAT32.
TheUpdateleisnotfound,checkthatitwas
correctly copied into the USB drive and that
the le name or folder names have not been
changed.
