Ebac E-Care+ AWM96D2-WH User manual

1
WASHING MACHINES
E-Care+
UK User Manual
Model No's. AWM74D2-WH/AWM74D2H-WH/
AWM86D2-WH/AWM86D2H-WH/
AWM96D2-WH/AWM96D2H-WH
(Part no. AWC6021-05)
Beautifully British
MANUFACTURING

Contents
5
General safety 5
Children’s safety 6
Packaging information 6
Disposing of the product at the end of it’s useful life 6
Compliance with WEEE directive 6
7
8
In the box
Getting started
8
9
9
10
12
12
Removal oftransit bolts
Location
Floor types
Water connection
Drainage connection
Electrical connection
Levelling 13
Before first time use 14
Using your machine 15
Sorting your laundry 15
Loading the machine 16
Understanding your controls 17
Selecting the right programme 18
Choosing extra settings 19
Adding detergent & softener 23
Starting your wash 24
Knowing your wash has finished 24
Stopping your wash before it has finished 25
Machine maintenance & cleaning 27
Cleaning external surfaces 27
Cleaning door seals 27
Cleaning detergent drawer & recessed compartment 27
Removing debris from the drain pump filter 28
Machine drum clean 28
Troubleshooting guide 29
Self Sense diagnostic code explanation 29
Step-by-step problem solving guide 30
Warranty registration 33
How to register 33
Warranty registration 33
Why register 33
Welcome page
Safety information
4

Welcome
MADE IN BRITAIN
Other Ebac Appliance brands:
  NORFROST
 WATERCOOLERS 
4
Dear Customer,
We would like to thank you for purchasing an Ebac E-Care + washing machine, the only British
manufactured washing machine.
The E-care + is packed full of practical features that are simple to use and come with washing
ideas to make your laundry days easier. The E-Care + will give you total peace of mind and
reassurance, delivering outstanding cleaning performance year after year whilst saving you
precious time and money!
With over 40 years of manufacturing and design expertise Ebac are confident that you will
love your new product.
Ebac are so confident that you will love your new machine, we are offering a no q uibble 30
day money back guarantee if you are not fully satisfied. This is in addition to your peace of
mind PAR T S and LABOUR guarantee.
..Automatically protects clothes against damage from unbalanced wash loads

5
Safety information
General safety
•This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made
by children without supervision.
•The power supply and voltage indicated
on the machine-rating label must be the
same.
•The washing machine must only be
connected to an AC supply circuit of
the appropriate rating using a properly
installed fixed socket that is compatible
with the plug fitted to the mains
connection lead.
•The socket must provide earth connection
and comply with current electrical safety
regulations. The plug should be a good
fit in the socket. Do not use electrical
adapters or a trailing extension cable.
Unplug the product when not in use.
The product must be unplugged during
installation, maintenance, cleaning and
repair procedures.
•If the mains cable or plug needs replacing,
it must only be replaced by the correct
replacement part available from Ebac and
must only be fitted by Ebac, an authorized
service agent or a similarly qualified
person.
•Never touch the plug with wet hands!
Never unplug by pulling on the cable,
always pull out using the plug.
•The machine should be positioned on a
flat, hard surface. Do not place the product
onto a carpet or other floor covering that
may prevent cooling air from entering the
machine. Lack of airflow may cause the
machine to overheat and have an adverse
eect to safety or reliability.
•Any obvious electrical or mechanical faults
or failure of the product should be
investigated and rectified by an authorised
repair agent before the unit is used again.
To avoid risk of electrical shock, an
appointed agent or other properly qualified
person should only carry out repairs.
•Never clean the washing machine by
spreading or pouring water onto it. There
is the risk of electric shock. In the event of
a power failure, the machine will resume
operation at the appropriate position of the
washing cycle. If you wish to cancel the
washing cycle, see the section Using Your
Machine – Step 9 – Stopping your wash
before a cycle has finished.
•The water supply and draining hoses must
be securely fastened and remain
undamaged. Otherwise, there is the risk of
water leakage.
•Never open the loading door or remove
the filter while there is still water in the
drum. Otherwise there is a risk of flooding
and injury from hot water.
•Do not force open the locked loading door.
The loading door will be ready to open just
a few seconds after the washing cycle
comes to an end. If the loading door is
forced open, the door and the lock
mechanism may get damaged.
•This washing machine has been designed
for domestic use. It is not suitable for
commercial use and it must not be used for
any purpose other than washing or rinsing
or spinning of domestic clothing.
•The washing machine must only be used
for washing and rinsing of laundry that are
marked accordingly.

6
Children’s safety
•Packaging materials are dangerous to
children. Keep packaging materials in
a safe place away from reach of the
children.
•Electrical products are dangerous for
children. Keep children away from the
product when it is in use. Do not let
children tamper with the product. Use a
child lock to prevent children from
intervening with the product.
•Do not forget to close the loading door
when leaving the room where the product
is located.
•Store all detergents and additives in a safe
place away from the reach of children by
closing the cover of the detergent
container or sealing the detergent
package.
Packaging information
•Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations.
•Do not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated by
the local authorities.
Disposing of the product at the end of it’s
useful life
This product has been manufactured with
high quality parts and materials that can
be reused and are suitable for recycling.
Therefore, do not dispose of the product
with normal domestic waste at the end of
its service life. Take it to a collection point
for the recycling of electrical and electronic
equipment. Please consult your local
authorities to learn the nearest collection
point. Help protect the environment
and natural resources by recycling used
products. For children’s safety, cut the power
cable and break the locking mechanism
of the loading door so that it will be non-
functional before disposing of the product.
Compliance with WEEE directive
This appliance’s packaging material is
recyclable. Help recycle it and protect
the environment by dropping it o in the
municipal receptacles provided for this
purpose.
Your appliance also contains a great amount
of recyclable material. It is marked with this
label to indicate the used appliances that
should not be mixed with other waste. This
way, the appliance recycling organised by
your manufacturer will be done under the
best possible conditions, in compliance
with European Directive 2/96/EC on Waste
Electrical and Electronic Equipment.
Contact your local authority or your retailer
for the used appliance collection points
closest to your home. We thank you for
contributing to protecting the environment.
Safety information

7
In the box
5
6
2
1
14
10
15
8
9
11
3
7
13
12
4
1. Door
2. Detergent
3. Control Panel
4. Transit Bolt Assembly*
5. Water Connections**
6. Power Plug
7. Drain Hose
8. Pump Filter
9. Emergency Door Release Cord
10. Pump Filter Drain Hose
11. Front Cover Kick Plate
12. Drain Hose Guide
13. Water Inlet Hoses**
14. Transit Bolt Cover Caps
15. Liquid Detergent Boat
T1. Spanner
*4 or 5 transit bolts are fitted dependent on your model.
**2 connections & 2 water inlet hoses are supplied on Dual Fill models only.
Tools included

8
Getting started
1Removal of transit bolts
• All transit bolt assemblies must be removed before installation.
• If the transit bolts are not removed and the machine is operated with them
fitted it will cause damage, excess vibration and noise.
• All transit bolt assemblies should be kept and re-used when transporting
your washing machine in the future.
The washing machine comes fitted with transit bolts*
to prevent any internal damage during transport.
Using a 10mm spanner
(supplied), loosen the
transit bolt assembly by
25mm.
DO NOT unscrew the bolt
all the way out as this will
cause the bolt to separate
inside your machine
Ease out and remove the
transit bolt assembly by
twisting and pulling on the
section highlighted in red
on the diagram.
Insert the transit bolt
cover caps supplied to
cover the holes.
1. 2. 3.
*4 or 5 transit bolts are fitted dependent on your model.
25mm

9
2Location
The washing machine should
always be installed on a flat
solid surface free from sloping,
unevenness or any flexing.
A power supply socket must
be within 1.5 metres of either
side of the washing machine.
Do not overload the socket with
multiple appliances.
Avoid positioning the washing
machine directly next to any gas
supplies or appliances such as
cookers/hobs.
Do not install the washing machine in
temperatures below 0oc or where water
pipes, pump, valves or hoses could
potentially freeze.
For safety reasons a minimal clearance
gap of 10mm should be left around the
whole washing machine. This is especially
important in alcove or closed installation.
3Floor types
•Choose a suitable solid, even floor surface
to ensure the machine is level and free from
movement.
•During machine operation floor surface finish can
contribute to additional noise.
•Concrete floors are ideal as long as they are even.
•Tiled floors are ideal as long as there is no flex
from the materials they are laid on i.e. floorboards.
•Wooden floors may need to be reinforced
should they flex when the washing machine is
in operation. A piece of 600x600x18+mm water
resistant plywood should be firmly screwed to the
floor to try and help minimise vibration.
•Do not place the product onto a carpet or other
floor covering that may prevent cooling air from
entering the machine. Lack of airflow may cause
the machine to overheat and have an adverse
eect to safety or reliability.
•If the floor is uneven never use additional items
such as pieces of wood, plastic or metals to correct
as these could become loose and move due to
machine vibration over time.
Getting started
Uneven floors Weak floors
Carpet Slippery surfaces

10
4Water connection
• This appliance must be connected in compliance with any local or national
regulations or bylaws.
• To ensure your washing machine works correctly and to its optimum
performance the water supply pressure must be between 0.1MPa (1 bar)
and 1MPa (10 bar).
• Use the detachable water inlet hoses provided with the machine to
connect to the water supply never re-use an old hose set.
• If the supplied hoses (1.5m) are not long enough do not modify them to be
made longer. Replace then with new longer hoses.
• Do not use the washing machine if there is a leak! You are at risk of an
injury or an electric shock.
• Avoid over tightening that may damage the hose, causing the plastic screw
threads to be stripped.
• Always ensure the hoses are connected to the correct water supplies. The
hot supply should be connected to the right handside connector marked
red and the cold supply the the left handside connector marked blue.
Check each end of the
inlet hose to ensure the
black rubber seal is fitted.
Connect the L-shaped
inlet hose end to the back
of the machine.
Tighten by hand by turning
clockwise. Ensure the hose
is not twisted or kinked
before connecting the
other straight end of the
hose.
Connect the straight
end of the inlet hose to
the cold water supply
isolating valve. When
complete, open isolating
valve to let water into the
machine.
Check all connections for
no leaks.
1. 2. 3.
Cold fill machines
Getting started

11
Check the end of each
inlet hose to ensure the
black rubber seal is fitted.
Connect the L-shaped
inlet hose ends to the
back of the machine.
Tighten by hand by turning
clockwise. Ensure the
hoses are not twisted or
kinked before connecting
the other straight end of
the hoses.
Connect the straight end
of the inlet hoses to the
appropriate water supply
isolating valve. When
complete, open isolating
valves to let water into the
machine.
Check all connections for
no leaks.
1. 2. 3.
Dual fill machines
• The hot water supply is always located on the right-hand side connector
marked red.
• Dual fill machines can operate with cold supply only but in these cases a Y
connecting piece (not supplied) must be used and connected to the cold
water supply isolating valve. From this, both the hot and cold water inlet
hoses can be connected to the two inlet connections at the rear of the
machine.
• Always ensure the hot and cold water supply is connected to the correct
hot and cold water intake at the rear of the machine.
Getting started
Water connection (continued)

12
5Drainage connection
Option 1 - Washing machine trap with standpipe
1. Unclip the drain hose from the back of the machine.
2. Push the drain hose down into in the drainpipe.
3. Attach the drain hose guide accessory and secure the drain hose
from any movement.
This appliance must be connected in compliance with any local or national
regulations or byelaws.
The drainpipe should always be vertical and not horizontal.
6Electrical connection
You will find your plug and mains lead plugged into the back of
your washing machine. Gently pull the plug free and close the
space with the cap attached. The mains lead is 1.5m. Plug the mains
lead into an AC220-240v/50Hz approved socket.
• Do not use an extension cord or double adapter.
• The appliance should be positioned so that the electrical supply can be
easily accessed to be switched on and o.
• Do not modify the supplied electric mains cable. If the cable is not long
enough then reposition the washing machine or move the electrical socket.
• A professionally qualified electrician can move the socket and it should be
in line with local or national regulations or byelaws.
Option 2 - Direct into the undersink appliance trap
1. Unclip the drain hose from the back of the machine.
2. Ensure the appliance trap nozzle is open and unblocked at the sink.
3. Place the drain hose over the appliance trap nozzle and secure tightly with
a hose retainer clip.
Getting started

13
7Levelling
When the machine is in its location ensure it is level. Only the two front feet can be adjusted.
To alter the feet height:
Lift machine up o the floor to access the
front feet and loosen the locking nut using
the spanner provided.
1. Adjust to the desired height by turning the
foot clockwise / anticlockwise.
2.
Ensure you re-tighten the locking nut to
secure the foot into position.
3. Check the washing machine is level and
stable using a spirit level.
4.
x2
• Take care when moving the machine on dierent floor types.
• When handling the machine do not apply force onto the control panel area.
Always handle the machine by the side or base edges.
• Ensure locking nut is tight before use to avoid any potential machine
virbation when in use.
• Use a spirit level to ensure your washing machine is level.
Getting started

14
Before rst time use
Before you use your machine for the first time we advise you run the drum clean wash programme, it is
designed to clean any dirt or old water that might have been left in the machine during factory approval
testing. Your door and detergent drawer may be initially sti because it is new and has not been used. After
time and use it will loosen and become easier to use.
Follow these steps before you do your first laundry wash:
Open the door and wipe
the door seal using
a damp cloth. Before
closing the door, ensure
the drum is empty.
Turn the machine on by
turning the dial to select
the drum clean wash
programme.
N.B: Do not add any
laundry, detergent or
softener.
Press the Start Button.
1. 2. 3.
DelayTemp Spin Time Saver
Extra Rinse
Prewash
Drum Clean
Rinse
Off
Hand Wash
Synthetic
Delicate
Basic Universal
Mixed
Quiet
Refresh
Dark
Spin


Synthetic
Delicate
Drum Clean
Allergy Care
Off
Time Saver
Rinse Hold
DelayTemp Spin Set
My Wash
Prewash
Intensive
Extra Rinse
Easy Iron Rinse & Spin
Allergy Care
My Wash
Cotton Saver
Cotton
F-Series
Hand/Wool Wash
Wool
E-Series
Colours
Quick 30
Intensive 60
Dark
White
Mixed
Quick
Mid Universal and BLDC
60°
40°
30°
20°
600
1000
800
1200
6h
3h
12h
9h
TS
90°Ready
Rinse
Wash
End
Spin
60°
40°
30°
20°
600
1000
800
1400
90°Delay
Rinse
Wash
End
Spin
H
60 °
Touch BLDC

S-Series
Cotton Saver
Cotton
40 °
60 ° 40 °
DelayTemp Spin Time Saver
Extra Rinse
Prewash
Drum Clean
Rinse
Off
Hand Wash
Synthetic
Delicate
Basic Universal
Mixed
Quiet
Refresh
Dark
Spin


Synthetic
Delicate
Drum Clean
Allergy Care
Off
Time Saver
Rinse Hold
DelayTemp Spin Set
My Wash
Prewash
Intensive
Extra Rinse
Easy Iron Rinse & Spin
Allergy Care
My WashCotton Saver
Cotton
F-Series
Hand/Wool Wash
Wool
E-Series
Colours
Quick 30
Intensive 60
Dark
White
Mixed
Quick
Mid Universal and BLDC
60°
40°
30°
20°
600
1000
800
1200
6h
3h
12h
9h
TS
90°Ready
Rinse
Wash
End
Spin
60°
40°
30°
20°
600
1000
800
1400
90°Delay
Rinse
Wash
End
Spin
H
60 °
Touch BLDC
Cotton Saver
Cotton
40 °
60 ° 40 °

15
The way you sort your laundry and the amount you load into your machine can have a significant impact on
how well your garments are cleaned. For the best results sort your garments into piles of:
a) Fabric types
Certain washing programmes are
designed for specific fabric types
to maintain fabric quality and
brightness. Where possible try to
wash similar fabrics together but
ensure the right programme is
selected for the garment type.
b) Dirtiness (soiled levels)
Washing garments with similar
levels of dirtiness oers the best
cleaning outcome. For heavily
soiled dirt levels additional
options such as prewash or
intensive actions can be added for
a brilliant clean. For light or normal
dirt levels there is a wide choice
of everyday programmes and
options to choose from.
c) Colours
By washing garments of similar
colours, it prevents any colour
dye transfer from garments to
garments. As a rough guide it
is best to separate garments
into darks, whites, pale or bright
colours.
1
Using your machine
Wash symbols Dry Clean symbols
Ironing symbols
Drying symbols
Chlorine / Bleach
No dash
Suitable for high
agitation wash
(eg cotton)
Type of solvent
Hot 200ºC
May be tumble
dried
Any bleach
(when needed)
One dash
Suitable for
medium agitation
(eg synthetic)
Do not dry clean
Warm 150º Cold 110º Do not iron
May be tumble
dried on normal
heat
Bleach/non-
chlorine
(when needed)
Two dashes
Suitable for a low
agitation wash
(eg wool)
May be tumble
dried on delicate
heat
Do not bleach
Not suitable for
machine washing
Do not tumble dry Dry flat
Hand wash only
Hang dry Drip dry
recommended
40 40 40 A F
P
d) Understanding your garment labels
To make sure your garment fabrics are correctly washed and cared for please take a few moments to check
your garment care label symbols to ensure they are washed in the correct way.
Sorting your laundry
N.B: Number refers to max temperature

16
2
Door opening
Squeeze in the handle on
the top right hand side of
the door and gently pull
door back to open.
1. Machine loading
See laundry loading
care below for best
results.
2. Door Closing
Simply push the door
shut. A positive clicking
noise will be heard as
the locking mechanism
engages.
3.
N.B. Once the door is locked a door lock icon ( 26 ) is illuminated on the control display. (see page 17)
Laundry loading care
To avoid risk of any garments getting damaged, caused by an out of balance load or damage to the machine
ensure the following steps are taken:
1. Check all zips, hooks and strings are closed and
tied to avoid any garments becoming caught,
trapped or snagged.
2. Check all pockets are empty of any items
including coins, screws, pens, nails, hair clips or
keys etc.
3. Pre-treat any bad stains prior to loading the
machine to help improve cleaning performance
where necessary.
4. Each wash programme has a max and min load
size (kg) limit that should be respected and
followed at all times. - see tables on page 22for
load size recommendation by wash programme.
5. Before you close the door ensure garments are
not trapped or that the gasket is not folded out of
shape.
6. Out of balance loading can result in poor or no
spinning, built in sensor technology will only allow
balanced loads to spin to protect the machines
performance, so take care to only use balanced
load every time. An example of an out of balance
load could be a single large bath towel.
7. Load items of similar size together to ensure
the load remains balanced i.e. large items first
followed by smaller items to fill the drum.
8. Use of laundry nets for small items such as socks,
underwear, handkerchiefs, gloves etc is
recommended to help prevent them getting
caught or damaged. Laundry nets should always
be washed with other items and never on their
own, because it could result in an out of balance
load performance.
9. Trainers or shoes should not be washed inside
this washing machine.
Loading the machine
Using your machine

17
3
DelayTemp Spin Time Saver
Extra Rinse
Prewash
Drum Clean
Rinse
Off
Hand Wash
Synthetic
Delicate
Basic Universal
Mixed
Quiet
Refresh
Dark
Spin


Synthetic
Delicate
Drum Clean
Allergy Care
Off
Time Saver
Rinse Hold
Delay
Set
Temperature
Set
Spin Speed Set
My Wash
Prewash
Intensive
Extra Rinse
Easy Iron Spin Only
Rinse and Spin
My WashCotton Saver
Cotton
AWM86D2H-WH
Hand/Wool Wash
Wool
E-Series
Colours
Quick 30
Intensive 60
Dark
White
Mixed
Quick
Mid Universal and BLDC
60°
40°
30°
20°
600
1000
800
1200
6h
3h
12h
9h
TS
90°Ready
Rinse
Wash
End
Spin
60°
40°
30°
20°
600
1000
800
1400
90°Delay
Rinse
Wash
End
Spin
H
60 °
Touch BLDC

S-Series
Cotton Saver
Cotton
40 °
60 ° 40 °
DelayTemp Spin Time Saver
Extra Rinse
Prewash
Drum Clean
Rinse
Off
Hand Wash
Synthetic
Delicate
Basic Universal
Mixed
Quiet
Refresh
Dark
Spin


Synthetic
Delicate
Wool
Hand Wash
Off
Time Saver
Rinse Hold
DelayTemp Spin Set
My Wash
Prewash
Intensive
Extra Rinse
Easy Iron Rinse & Spin
Allergy Care
My WashCotton Saver
Cotton
F-Series
Drum Clean
Wool
E-Series
Colours
Quick 30
Intensive 60
Dark
White
Mixed
Quick
Mid Universal and BLDC
60°
40°
30°
20°
600
1000
800
1200
6h
3h
12h
9h
TS
90°Ready
Rinse
Wash
End
Spin
60°
40°
30°
20°
600
1000
800
1400
90°Delay
Rinse
Wash
End
Spin
H
60 °
Touch BLDC

S-Series
Cotton Saver
Cotton
40 °
60 ° 40 °
16 17 18 19 20 21 22
24
34
33
32
31
25
26
27
28
29 30
35
23
16. Temperature Button
17. Spin Speed Button
18. Delay Button
19. Prewash / Intensive Button
20. Time Saver / Rinse Hold Button
21. Extra Rinse / Easy Iron Button
22. Set My Wash Button
23. Start / Pause Button
24. Wash Programme Selector & On/O
25. Start / Pause Icon
26. Door Locked Icon
27. Prewash Icon
28. Intensive Icon
29. Time Saver Icon
30. Rinse Hold Icon
31. Easy Iron Icon
32. Extra Rinse Icon
33. Eco Running Icon
34. Child Safety Icon
35. Time Remaining Display
36. Wash cycle stage indicator
Switching on Your Machine
To switch on your machine turn the wash
programme selector dial from the o position to
a dedicated wash programme. The dial maybe
turned both clockwise and anticlockwise.
Eco Running Icon
This will illuminate when the
machine is operating in an
ecient way based on the load
size within the machine.
36
Understanding your controls
Using your machine
Digital Inverter Technology Perfect Wash Protection
Press Both to Lock Press Both to Silence
E-Care+
8kg
Intelligent Hot & Cold Fill

18
4
Programme Recommendation
Cotton Saver Designed for cottons, bed linen,
table linen, underwear, towels,
shirts etc. This wash is shorter
in time and uses less energy
compared to our cotton wash.
Cotton Designed for cottons to
ensure the most ecient and
best cleaning performance is
achieved.
Synthetic Designed for synthetic/polyester
materials such as blouses, shirts,
trousers.
Delicate Designed for delicate fabrics
(such as silk or linen).
Mixed Designed for everyday mixed
fabric (such as cottons with
synthetics) garments. Similar
colours to be washed together
removing the need for separate
sorting.
Hand/Wool
Wash
Designed specifically for wool garments
to ensure they are left feeling clean and
soft. Please check garment label for
correct washing instructions.
NB: *On the Quiet programme the wash stops prior to spin stage and must be reactivated by the user
to complete the programme by pressing the start button again.
Wash programme selector (24)
Turn dial to select the appropriate wash programme. (See programme recommendation
table below) The selected programme temperature, spin speed, extra wash options and
time will be illuminated on the digital display area.
Selecting the right programme
Please check all garment labels for correct washing instructions to ensure
the best cleaning performance and garment care is achieved. Step 1 of this
section can help and give you some guidence with this.
Programme Recommendation
Drum Clean Designed to clean your machine
and keep it operating at it’s
optimum performance by
removing internal dirt and
bacteria build up.
My Wash You decide - create and store your very own
favourite wash programme. That wash you
always do.
Refresh Designed to freshen up by removing odours
from garments that have been worn once or
are not dirty. No detergent required softener
only.
Quick Designed for small loads that require
cleaning in a hurry.
Dark Designed for dark coloured garments to
maintain their original colours overtime.
Quiet * Designed to offer a low noise wash
programme for mixed fabrics – ideal to be
operated during the night or in times when
silence is required. The wash stops prior to
spin stage and must be reactivated by the
user to complete the programme.
Spin Only Designed to remove excess water from the
clothes. This is not recommended for use
with delicate, wool or hand wash garments.
Allergy Care Designed to reduce and remove
excess detergent from your
garments – Bedding / childrens
garments.
Using your machine
Rinse & Spin Designed to remove excess water from the
clothes. This is not recommended for use
with delicate, wool or hand wash garments.

19
5Choosing extra settings
• To protect your laundry not all options and functions are available with
every wash programme.
• When an option is selected to show it is activated, it’s icon will be
illuminated on the display.
• When an option is selected but it is not possible, it’s icon will flash and then
go o on the display.
Temperature button (16) & Spin Speed button (17)
1. Press button repeatedly to cycle through the available options.
N.B: Not all temperatures and spin speeds are available on all wash
programmes.
Delay button (18)
1. Press the delay button to select the number of hours delay for your wash.
2. You can choose from 1 to 24 hours which is highlighted in the digital display.
3. Press the start/pause button to activate the desired delay start.
Prewash / Intensive button (19)
1. Press button once to activate Prewash option.
2. Press twice to deactivate Prewash and activate intensive option.
3. Press three times to activate both Prewash and intensive options.
4. Press four times to deactivate both Prewash and intensive options.
N.B: By selecting these options the wash programme time will increase.
Prewash
An extra wash cycle that is ideal
for heavily dirty clothes.
Intensive
Adds extra agitation to
provide a better clean.
Using your machine
Set
Temperature
Set
Spin Speed
l

20
Choosing extra settings (continued)
Time Saver / Rinse Hold button (20)
1. Press button once to activate Time Saver.
2. Press twice to deactivate Time Saver.
3. Press three times to activate Rinse Hold option.
4. Press four times to deactivate Rinse Hold option.
N.B: Time Saver option is only suitable for use on selected programmes. Rinse Hold
option will increase wash programme time. The machine will stop and pause during the
rinse stage, holding your clothes in water. To finish the wash cycle you must manually
press the start / pause button.
Time Saver
Enables the wash
time to be speeded
up for when you are
in a hurry.
Rinse Hold
After the rinse the wash cycle pauses and
holds clothes in water. This is ideal if you
leave clothes in the machine for long periods
of time before unloading because it reduces
them smelling and creasing as they dry.
Extra Rinse / Easy Iron button (21)
1. Press button one to activate Extra Rinse option.
2. Press twice to deactivate Extra Rinse and activate Easy Iron option.
3. Press three times to activate both Extra Rinse and Easy Iron.
4. Press four times to deactivate both Extra Rinse and Easy Iron.
N.B: By selecting these options the wash programme time will increase.
Extra Rinse
Adds extra water
to remove excess
detergent.
Easy Iron
Special drum spinning rotation
reduces the amount of creases
left in your clothes.
Using your machine
