ebm-papst IAQ Monitor
Quick Start Manual
Safety Information
●Only use the provided charger and cable for USB-C.
●For 12-32V DC supply, operation is only permitted with a double isolated power supply.
●For indoor use only!
●Not suitable for ceiling installation!
○Please visit https://reset.build/standard/air for further RESET requirements.
●Unplug the monitor from the outlet before servicing!
●DO NOT clean with liquid!
●DO NOT use in wet or damp areas!
●DO NOT exceed the recommended electrical ratings!
Support
In case you have any problems, please contact https://www.ebm-papst-neo.com/support/.
Manufacturer
ebm-papst neo GmbH & Co. KG
Bachmühle 2
74673 Mulfingen
Germany
info@epneo.com
Made in Thailand and China
2
Version 1.0 • Release 2023-02-07 • S. Berge
ebm-papst neo GmbH & Co. KG •
Emil-Figge-Str. 80 •
44227 Dortmund • Germany
Product Overview
The ebm-papst IAQ Monitor is a powerful air quality monitor measuring particulate matter (PM2.5), carbon
dioxide (CO2), volatile organic compounds (TVOC), temperature and humidity including a customizable colored
LED bar.
Figure 1: ebm-papst IAQ Monitor + accessories (depending on order)
Package Contents
The ebm-papst IAQ Monitor package contains the following:
Order Information
Material
Number 8350000147 8350000148 8350000162 8350000163
Description
ebm-papst IAQ
Monitor UK
ebm-papst IAQ
Monitor
ebm-papst IAQ
Monitor EU
ebm-papst IAQ
Monitor US
Accessories
UK USB power
supply adapter,
2m USB-A/USB-C
cable,Safety Lock
Safety Lock
EU USB power
supply adapter,
2m USB-A/USB-C
cable, Safety Lock
US USB power
supply adapter,
2m USB-A/USB-C
cable, Safety Lock
Table 1: Order Information
3
Version 1.0 • Release 2023-02-07 • S. Berge
ebm-papst neo GmbH & Co. KG •
Emil-Figge-Str. 80 •
44227 Dortmund • Germany
Specifications
Sensor Modules Accuracy
PM2.5 (laser scattering
principle)
±10% @ 100~500 μg/m³,
±10 μg/m³ @ 0~100 μg/m³
CO2(NDIR) Range 0 - 10.000ppm, ± 40 ppm ± 3%,
automatic baseline calibration
TVOC (multi-pixel gas
sensor)
0 - 1,000 ppm of ethanol equivalents,
accuracy: 15%
Temperature
-40 to 125°C ±0.3°C @ 0-90 °C
Relative Humidity Range 0 - 100% RH ±2% @ 0-100% RH
Table 3: Sensor Modules Accuracy
Cable specifications
The following table lists information about the connection cable (depending on the order) included in the
package:
USB-C cable specifications
Cable Type USB-C to USB-A
Color
white
Length
2m
Table 4: Cable Specifications
General Specifications
Name ebm-papst IAQ Monitor
Model EPAQM-1
Material Number
8350000148 (Modbus Model)
Enclosure Dimensions 130 x 130 x 36 mm
Enclosure Color Signal White RAL 9003
Enclosure Material
ASA Plastic (PW-957 Kibilac)
Weight 300 gr
Wireless Connectivity
Wi-Fi 2.4 GHz
Input 12-32V DC (optional: 5V DC over supplied USB-C Power Supply)
Color-LED bar
configurable
Certifications
RESET
TM
Air, FCC, CE, RoHS, WEEE
IP Protection Class IP20
Operating Temperature
0° to 50° Celsius
Table 2: General Specifications
4
Version 1.0 • Release 2023-02-07 • S. Berge
ebm-papst neo GmbH & Co. KG •
Emil-Figge-Str. 80 •
44227 Dortmund • Germany
Mounting instructions
The monitor should be placed away from doors, windows ventilation or HVAC registers, and avoid direct
sunlight. Please ensure that the monitor is mounted on the wall in the correct orientation and with unobstructed
air flow at the bottom and top of the monitor.
Screws and wall anchors are recommended for wall mounting or you can use strong tape (e.g. ‘command
strip’). The monitor enclosure cable management allows for use of a wall socket above or below the monitor.
The monitor must remain plugged in with power at all times to ensure uninterrupted operation of the device.
Table 5: Wall mounting
5
Version 1.0 • Release 2023-02-07 • S. Berge
ebm-papst neo GmbH & Co. KG •
Emil-Figge-Str. 80 •
44227 Dortmund • Germany
Wi-Fi / IT Infrastructure Requirements
Please note the following:
-ebm-papst IAQ Monitor only supports 2.4GHz WiFi.
-ebm-papst IAQ Monitor does not support WPA 2 Enterprise authentication.
-ebm-papst IAQ Monitor does not support Wi-Fi authentication through captive portals. It needs a regular
SSID with a password.
-In case you need to white list the MAC address of the monitor, the serial number printed on the back of
the device corresponds to the MAC address.
Wi-Fi Connection
When the monitor is powered on for the first time, it requires an initial connection to your Wi-Fi network. To
configure the connection to your Wi-Fi network, the monitor needs to be set into a Configuration Mode. In the
Configuration Mode it will open an access point where you can connect directly with your phone to enter your
Wi-Fi network credentials.
Please follow these steps to activate the Configuration Mode:
1) Push the RESET button on the backside of the monitor by using a non-conductive pin of about 2mm
diameter and keep it pushed.
2) Plug in the Power Supply.
3) The LED test of the monitor LEDs will be executed and the monitor will flash through the different LED
colors.
4) After the LED test is finished, release the RESET button.
5) If a WiFi network has been configured before, the monitor will attempt to connect to this network.
6) If this network is not found or no network has been configured before, the monitor will start the Configuration
Mode after 5 seconds.
7) The Configuration Mode remains active for 15 minutes.
8) To establish a connection with your phone to access the internal configuration page of the monitor, open
the QR code reader of your phone and scan the QR Code “Add to WiFi/APP on the back of the monitor.
9) The phone should now connect automatically to the access point of the monitor and open the browser of
your phone with the configuration page of the monitor, where you can enter the WiFi credentials of your
WiFi network.
6
Version 1.0 • Release 2023-02-07 • S. Berge
ebm-papst neo GmbH & Co. KG •
Emil-Figge-Str. 80 •
44227 Dortmund • Germany
IAQ-Connect App
In order to connect the monitor to the ebm-papst IAQ APP, open the app and click on the “Scan QR Code”
button. Now scan the QR code “Add to WiFi/APP” on the monitor’s label. To download the App and to find
further documentation for the IAQ Monitor, you can visit https://ebm-papst-neo.com/IAQ or scan the QR Code
“Quick Start” on the back of the IAQ Monitor.
Figure 2: Measured Data Overview (App)
IAQ Monitor Dashboard
In order to connect the monitor to the IAQ Monitor dashboard, scan the QR code “Add to WiFi/APP” on the
monitor’s label.
If you have any issues with connecting the monitor, please contact us at
https://www.ebm-papst-neo.com/support/.
Figure 3: IAQ Monitor Dashboard (example)
7
Version 1.0 • Release 2023-02-07 • S. Berge
ebm-papst neo GmbH & Co. KG •
Emil-Figge-Str. 80 •
44227 Dortmund • Germany
Test Report
The test report of the monitor can be downloaded from https://ebm-papst-neo.com/IAQ.
CE Information of Conformity
Hereby, ebm-papst neo GmbH & Co. KG informs that the radio equipment type Wireless Local
Area Network Device is in compliance with Directive 2014/53/EU.
WEEE Statement
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive
2012/19/EU) which should not be mixed with unsorted household waste. Instead, you should protect
human health and the environment by handing over your waste equipment to a designated collection
point for the recycling of waste electrical and electronic equipment, appointed by the government or local
authorities. Correct disposal and recycling will help prevent potential negative consequences to the
environment and human health. Please contact the installer or local authorities for more information about the
location as well as terms and conditions of such collection points.
FCC Statement
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
FCC 20cm Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20cm between the
radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
Contains: FCC ID: 2AC7Z-ESP32WROVERE.
