ASROCK PG27FF1A User manual

Published November 2022
Copyright© 2022 ASRock INC. All rights reserved.
Copyright Notice
No part of this documentation may be reproduced, transcribed, transmitted, or translated in
any language, in any form or by any means, except duplication of documentation by the
purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this documentation may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Disclaimer
Because the monitor specifications and the firmware might be updated, the content of this
documentation will be subject to change without notice. In case any modifications of this
documentation occur, the updated version will be available on ASRock’s website without
further notice. If you require technical support related to this motherboard, please visit our
website for specific information about the model you are using. You may find the latest
monitor support list on ASRock’s website as well.
ASRock Website: http://www.asrock.com
This product incorporates HDMI technology.

Table of Contents
Chapter 1 Introduction .......................................................................................................................1
1.1 Package Contents ...............................................................................................................1
1.2 Installation Instructions.....................................................................................................2
Chapter 2 Specifications....................................................................................................................7
2.1 Monitor specifications........................................................................................................7
2.2 Preset Display Modes.........................................................................................................8
Chapter 3 Monitor Overview...........................................................................................................10
Chapter 4 Adjusting the Viewing Angle.......................................................................................14
Chapter 5 Connecting the Monitor................................................................................................15
Chapter 6 OSD Setup........................................................................................................................16
6.1 OSD Keys .............................................................................................................................16
6.2 OSD Menus (The descriptions for function control).................................................17
Chapter 7 Troubleshooting.............................................................................................................22
Chapter 8 Safety Instructions.........................................................................................................23

1
Chapter 1 Introduction
Thank you for purchasing PG27FF1A, a reliable monitor produced under ASRock’s
consistently stringent quality control. It delivers excellent performance with robust design
conforming to ASRock’s commitment to quality and endurance.
1.1 Package Contents
•ASRock PG27FF1A Monitor Head
•ASRock PG27FF1A Stand
•ASRock PG27FF1A Quick Start Guide
•DisplayPort Cable (DisplayPort to DisplayPort)
•HDMI Cable
•Power Cord
⚠Important
Contact your place of purchase or local distributor if any of the items is damaged or
missing.
Package contents may vary by country.
The included power cord is exclusively for this monitor and should not be used with other
products.

2
1.2 Installation Instructions
Leave the monitor in its protective foam packaging. Align the latches of the stand to the
monitor. Tighten the stand with screws.
Connect the stand base to the stand and tighten the screw to secure the stand base.
Align the latches to place the stand cover.
Adjust the angle of the stand, make sure the stand assembly is properly installed before
setting the monitor upright.
⚠Important
Remove the screws on the monitor groove if needed before installing the stand.
Place the monitor on a soft, protected surface to avoid scratching the display panel.
Do not use any sharp objects on the panel.
The groove for installing the stand bracket can also be used for wall mount. Please contact
your dealer for proper wall mount kit.

3

4

5

6

7
Chapter 2 Specifications
2.1 Monitor specifications
Monitor
ASRock PG27FF1A
Size
27 inch
Curvature
Flat
Panel Type
IPS
Resolution
1920 x 1080
Horizontal scan range
30 ~ 183KHz
Vertical scan range
48 ~ 165Hz
Aspect Ratio
16:9
Brightness (nits)
250
Contrast Ratio
1100:1
Refresh Rate
165Hz
Response Time
1ms(MPRT)
I/O Ports
• DisplayPort x 1
• HDMI Port x 2
•Earphone Jack x 1
View Angles
178°(H) , 178°(V)
Color Space
85% NTSC
Surface Treatment
Anti-Glare
Display Colors
16.7M
Monitor Power Options
100~240Vac, 50/60Hz, 1.5A
Power Consumption
Power On < 42W (Max)
Power Saving < 0.5W
Power Off <0.3
Adjustment (Tilt)
-5°~ 23°
Adjustment (Swivel)
-20°~ 20°
VESA Mounting
• Plate Type: 100 x 100mm
• Screw Type: M4 x 10 mm
Dimension (W x H x D)
612.42*434.83*192.61 mm
Weight
4.48 Kg (Net)
6.23 Kg (Gross)
Environment
Operating
• Temperature: 0℃to 40℃
• Humidity: 10% to 85%, non-condensing
• Altitude: 0 ~ 3658m

8
Storage
• Temperature: -20℃to 60℃
• Humidity: 5% to 80%, non-condensing
• Altitude : 0~12192m

9
2.2 Preset Display Modes
Standard
Resolution
PG27FF1A
Remark
HDMI
DP
HDR
IBM MODE DOS
720x400 @70Hz
V
V
VGA
640x480 @60Hz
V
V
640x480 @67Hz
V
V
640x480 @72Hz
V
V
640x480 @75Hz
V
V
SVGA
800x600 @56Hz
V
V
800x600 @60Hz
V
V
800x600 @72Hz
V
V
800x600 @75Hz
V
V
XGA
1024x768 @60Hz
V
V
1024x768 @70Hz
V
V
1024x768 @75Hz
V
V
SXGA
1280x1024 @60Hz
V
V
1280x1024 @75Hz
V
V
WXGA+
1440x900 @60Hz
V
V
WSXGA+
1680x1050 @60Hz
V
V
----
1152x864 @75Hz
V
V
1280x960 @60Hz
V
V
1280x720 @60Hz
V
V
Full HD
1920x1080 @60Hz
V
V
V
DTD
(Default)
1920x1080 @100Hz
DTD
1920x1080 @120Hz
V
V
V
DTD
1920x1080 @144Hz
V
V
V
DTD
1920x1080 @165Hz
V
V
V
DTD
1920x1080 @240Hz
QHD
2560x1440 @60Hz
2560x1440 @120Hz
2560x1440 @144Hz
2560x1440 @165Hz

10
WQHD
3440x1440 @60Hz
3440x1440 @120Hz
3440x1440 @144Hz
3440x1440 @165Hz
UHD
3840x2160 @60Hz
3840x2160 @120Hz
3840x2160 @144Hz
Video Timing
Resolution
640x480P 59.94/60Hz 4:3
V
V
720x480P 59.94/60Hz 4:3
720x480P 59.94/60Hz
16:9
V
V
720x576P 50Hz 4:3
720x576P 50Hz 16:9
V
V
1280x720P 50Hz 16:9
V
V
1280x720P 59.94/60Hz
16:9
V
V
1920x1080P 59.94/60Hz
16:9
V
V
V
1920x1080P
119.88/120Hz 16:9/1:1
V
V
V
2160P @25Hz
2160P @30Hz
2160P @50Hz
2160P @60Hz
2160p @120Hz

11
Chapter 3 Monitor Overview
Front view
No.
Item
LED Indication
1
Power Indicator
•Blue - Power on mode
•Orange - Standby mode
•LED Off - Off mode

12
Back side
No.
Description
2
OSD Keys
3
Serial Label
4
Cable Management Slot
5
Built-in Speakers (2x2W)

13
Bottom Side
No.
Item
6
AC input
7
HDMI input
8
HDMI input
9
DisplayPort input
10
Audio output

14
Chapter 4 Adjusting the Viewing Angle
For optimal viewing, it is recommended to
look at the full face of the monitor, and
then adjust the monitor’s angle to your
own preference.
Hold the stand so you do not topple the
monitor when you adjust the monitor’s
angle.
You are able to adjust the tilted angle from
-5°to 23°.
⚠Important
Avoid touching the display panel when adjusting the monitor.
You are able to swivel the monitor for the angle.
NOTE:
Do not touch the LCD screen when you adjust the angle. It may cause damage or break
the LCD screen.
Careful attention is required not to catch your fingers or hands when you adjust the angle.

15
Chapter 5 Connecting the Monitor
1. Turn off your computer.
2. Connect the video cable from the monitor to your computer.
3. Connect the power cord to the monitor power jack. (Figure A)
4. Plug the power cord into the electrical outlet. (Figure B)
5. Turn on the monitor. (Figure C)
6. Power on the computer and the monitor will auto detect the signal source.
7. Plug one end of the DisplayPort/HDMI cable to the monitor’s DisplayPort/HDMI port.
8. Connect the other end of the DisplayPort/HDMI cable to your computer's
DisplayPort/HDMI port.

16
Chapter 6 OSD Setup
This chapter provides you with essential information on OSD Setup.
⚠Important
All information is subject to change without prior notice.
6.1 OSD Keys
The monitor comes with OSD Keys that help navigate the On-Screen Display (OSD)
menu.
No.
Item
Description
1
Menu / Enter
When there is no OSD, Press to display the OSD or
confirm the selection.
2
Volume / +
Activates the Volume control when the OSD is OFF,
navigate through adjustment icons when OSD is ON, or
adjust a function when function is activated.
3
Preset Modes / -
Activates the Presets Modes function when the OSD is
OFF, navigate through adjustment icons when OSD is
ON, or adjust a function when function is activated.
4
Input Select / EXIT
• Press to select input from external sources.
• When OSD menu is on, press to exit the OSD menu.
5
Power
Press the power button to turn on/off the monitor.
1
2
3
4
5

17
6.2 OSD Menus (The descriptions for function control)
Function: Luminance
Main Menu
Item
Sub Menu
Item
Sub Menu
Description
Luminance
Contrast
0-100
Contrast from Digital-
register.
Brightness
0-100
Backlight Adjustment
Preset
Modes
Standard
Standard Mode
Text
Text Mode
Internet
Internet Mode
Game
Game Mode
Movie
Movie Mode
Sports
Sports Mode
DCR
On
Dynamic contrast ratio
Off
MPRT
On
MPTRT function On/Off
