Eco Pure EPWHP User manual

Manufactured and warranted by
Ecodyne Water Systems
1890 Woodlane Drive
Woodbury, MN 55125
Model EPWHP
Do not return unit to store
If you have any questions or concerns when
installing, operating or maintaining your water
heater protector, call our toll free number:
1-800-693-1138
or visit www.ecopure.com
7368140 (Rev. A 12/19/17)
Installation and Operation Manual
Point-of-entry system tested and certified by
NSF International under NSF/ANSI Standard 372
for low lead content and NSF/ANSI Standard 61
for materials safety requirements only.
Not certified for contaminant reductions or
structural integrity by NSF International.
How to install, operate
and maintain your
Water Heater Protector

2
EXPLANATI N F SIGNAL W RD C NSEQUENCES
WARNING Indicates a potentially hazardous situation, which, if not avoided, could result in death
or serious injury and/or property damage.
CAUTION Indicates a potentially hazardous situation, which, if not avoided, may result in property
damage.
Supply Water Pressure Min. - Max. 20 - 100 psi (138 - 689 kPa)
Supply Water Temperature Min. - Max. 40 - 100 °F (4 - 38 °C)
Service Flow Rate 8 gpm
Pressure Drop at Service Flow Rate 12 psi
Inlet - utlet 3/4 inch Male NPT
WARNING
To reduce the chance of scald injuries from hot water spillage during a filter change:
=You must open a hot water faucet downstream of the water heater and allow at least 2 gallons (7.5 liters) of
water to drain before removing the cartridge. Water in pipes and filter may be much hotter than the
temperature of the pipes or the surface of the filter.
To reduce the risk associated with ingestion of contaminants:
=D N T use this system on water that is micro biologically unsafe or of unknown quality without adequate
disinfection before or after the system.
Safety Information
Read, understand, and follow all safety information contained in these instructions prior to installation and
use of the EcoPure Water Heater Protector Model EPWHP. Retain these instructions for future reference.
Specifications
CAUTION
To reduce risk associated with property damage due to water leakage:
=Read and follow instructions before installation and use of this system.
=Installation and use MUST comply with all state and local plumbing codes.
=D N T install on hot water supply lines. Hot water will damage the Water Heater Protector. The maximum
supply water temperature of this system is 100°F (38°C).
=Do not install this product where it will be exposed to outdoor weather or direct sun.
=Do not install or store this product where it will be exposed to temperatures below freezing. Water freezing in
the Water Heater Protector will damage it.
=The maximum operating water pressure of this system is 100 pounds per square inch. If your home water
supply pressure exceeds 80 psi, install a Pressure Reducing Valve (PRV) before installing the Water Heater
Protector.
=Do not solder fittings while attached to the Water Heater Protector. Soldering heat will damage the inlet/outlet
ports.
=Take care when using pliers or pipe wrenches to tighten plastic fittings, as damage may occur if over
tightening occurs.
IMPORTANT
=During installation, SHUT FF FUEL R ELECTRIC P WER T WATER HEATER after shutting off water
supply.
=The disposable cartridge MUST be replaced every 6 months, or sooner if a noticeable reduction in flow rate
occurs.

3
Installation
1. The Water Heater Protector has 3/4” male NPT
threads on the inlet and outlet ports. btain two
3/4” female NPT fittings (not included) of the
appropriate size and type to adapt to the existing
C LD water supply pipe.
N TE: If you cannot identify the cold water supply
pipe to your water heater, consult a plumber.
2. Shut off the cold water supply. pen a hot water
faucet downstream of the water heater to relieve
pressure (faucet to remain open until end of Step
6). SHUT FF FUEL R ELECTRICAL P WER
SUPPLY T THE WATER HEATER. Drain water
from the pipe.
3. Cut a section of the C LD water supply pipe, as
needed to install the Water Heater Protector and
install plumbing adaptors. Do not solder fittings
while attached to the Water Heater Protector.
Soldering heat will damage the inlet/outlet ports.
4. Apply 4 wraps of sealant tape to the threaded ends
of the Water Heater Protector’s inlet and outlet
ports. Tighten all fittings firmly.
5. Make sure that the filter cartridge is fully installed,
so that the arrow lines up with the mark on the
head assembly (See Fig. 3 on the next page).
6. Make sure that a hot water faucet is still open
downstream of the water heater. With plumbing
work completed, slowly turn the cold water supply
back on. When water flows smoothly, shut off
faucet and check the installation for leaks.
7. Restart the water heater.
8. pen a hot water faucet downstream of the water
heater and allow water to run through the system
for 10 minutes to flush the filter cartridge.
FIG. 1
Install at least
18” (46 cm) above
water heater
H T
water out
C LD
water in
Water
Heater
Protector
Water
Heater
It is recommended to replace the
EPWHP Water Heater Protector
each time your water heater is replaced.
CAUTION
To reduce risk associated with property damage due to water leakage:
=Do not install on hot water supply lines. Hot water will damage the Water Heater Protector. The maximum
supply water temperature of this system is 100°F (38°C).
=During installation, SHUT FF FUEL R ELECTRIC P WER T WATER HEATER after shutting off water
supply.
=Do not solder fittings while attached to the Water Heater Protector. Soldering heat will damage the inlet/outlet
ports.
=Take care when using pliers or pipe wrenches to tighten plastic fittings, as damage may occur if over
tightening occurs.
=Ensure all tubing and fittings are secure and free of leaks.
IMPORTANT
=Install the Water Heater Protector with the inlet and outlet ports oriented as shown in Figure 1. Make sure not
to reverse connections.
=Do not install the Water Heater Protector horizontally or upside-down.
=Install the Water Heater Protector at least 18” (46 cm) away from the water heater.
=Allow a minimum of 2" (5 cm) clear space under filter to allow cartridge change.
Inlet
utlet
Allow at least
2” (5 cm) clear
space under
filter to allow
cartridge change

4
N TE: The Water Heater Protector’s automatic
bypass feature eliminates the need to shut
off your water supply when changing the
filter cartridge.
1. pen a hot water faucet downstream of the
water heater and allow at least 2 gallons of
water to run through the system before
removing the cartridge. Close the faucet.
2. Turn the filter cartridge to the left to remove
from the head assembly (See Fig. 2). A small
amount of water will be discharged from the
head assembly when removing the cartridge.
3. Dispose of the used cartridge in a proper manner.
4. Remove the new filter cartridge from its
packaging. Insert the new cartridge into the
head assembly and turn to the right to attach it.
IMP RTANT: Tighten the filter cartridge until the
arrow lines up with the mark on the
head assembly. (See Fig. 3).
5. pen a hot water faucet downstream of the water
heater and allow water to run through the system
for 10 minutes to flush the cartridge.
4
Replace the Filter Cartridge every 6 months
Replacement Cartridge P/N EPWHC
Register for reminders to change
filter cartridges at www.ecopure.com
FIG. 3
Turn to
the left
to remove
Filter
Cartridge
Head
Assembly
FIG. 2
Turn to
the right
to install
Tighten cartridge
until arrow lines
up with mark on
head assembly
Filter Replacement
CAUTION
To reduce risk associated with property damage due to water leakage:
=The disposable cartridge MUST be replaced every 6 months or sooner if a noticeable reduction in flow rate
occurs.
WARNING
To reduce the chance of scald injuries from hot water spillage during a filter change:
=You must open a hot water faucet downstream of the water heater and allow at least 2 gallons (7.5 liters) of
water to drain before removing the cartridge. Water in pipes and filter may be much hotter than the
temperature of the pipes or the surface of the filter.
Questions? Call Toll Free 1-800-693-1138 or visit www.ecopure.com

5
WARRANTY
NE YEAR LIMITED WARRANTY N WATER HEATER PR TECT R
(except filter cartridges)
Warrantor: Ecodyne Water Systems, 1890 Woodlane Drive, Woodbury, MN 55125
Warrantor guarantees, to the original owner, that the Water Heater Protector, when installed and maintained in
accordance with the instructions, will be free from defects in materials and workmanship for a period of one (1) year
from the date of purchase. If, within the first year, a part proves, after inspection, to be defective, Warrantor will, at its
sole option, either replace or repair the part without charge except normal shipping and installation charges. Labor to
maintain the equipment is not part of the warranty. Filter cartridges, which are expendable, are not covered by the
warranty.
T BTAIN WARRANTY PARTS, SIMPLY CALL 1-800-693-1138 for assistance. This warranty applies only while this
product is in use in the United States or Canada.
General Provisions
The above warranties are effective provided the Water Heater Protector is operated at water pressures not exceeding
100 psi, and at water temperatures not exceeding 100°F; provided further that the Water Heater Protector is not
subject to abuse, misuse, alteration, neglect, freezing, accident or negligence; and provided further that the Water
Heater Protector is not damaged as the result of any unusual force of nature such as, but not limited to, flood,
hurricane, tornado or earthquake.
Warrantor is excused if failure to perform its warranty obligations is the result of strikes, government regulation,
materials shortages, or other circumstances beyond its control.
*THERE ARE N WARRANTIES N THE WATER HEATER PR TECT R BEY ND TH SE SPECIFICALLY
DESCRIBED AB VE. ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY F
MERCHANTABILITY R F FITNESS F R A PARTICULAR PURP SE, ARE DISCLAIMED T THE EXTENT
THEY MIGHT EXTEND BEY ND THE AB VE PERI DS. THE S LE BLIGATI N F WARRANT R UNDER
THESE WARRANTIES IS T REPLACE R REPAIR THE C MP NENT R PART WHICH PR VES T BE
DEFECTIVE WITHIN THE SPECIFIED TIME PERI D, AND WARRANT R IS N T LIABLE F R C NSEQUENTIAL
R INCIDENTAL DAMAGES. N WARRANT R DEALER, AGENT, REPRESENTATIVE, R THER PERS N IS
AUTH RIZED T EXTEND R EXPAND THE WARRANTIES EXPRESSLY DESCRIBED AB VE.
Some states do not allow limitations on how long an implied warranty lasts or exclusions or limitations of incidental or
consequential damage, so the limitations and exclusions in this warranty may not apply to you. This warranty gives
you specific legal rights, and you may have other rights which vary from state to state. This warranty applies to
consumer-owned installations only.
