ECOheat SLIMLINE User manual

Thanks for investing in the Ecoheat Induction Cooker.
Please read this user guide thoroughly before use.
Retain for future reference. Happy Cooking.
Model: EcoHeat Slimline
Operating Manual

2 Ecoheat Slimline Operating Manual
NOTE Each time you shift between Wattage
and Temperature, using the T/Wbutton, the
cooker will revert to its default factory settings
of 500 watts or 180ºC.
PLEASE NOTE
• Cookware must be placed
on top of unit to turn on
• Only magnetic cookware
will activate the plate
The Control Panel and Basic Operation
1 Turning the Cooker On
2 Selecting Wattage
• When the unit is turned on, the default wattage of 500 appears on the LED screen.
• To select a wattage, press +or –buttons. Watch for indicator light to display.
• To increase wattage press +
• To decrease wattage press –
•L MHBare not buttons, the are
indicators, to indicate the selected setting.
• The range of power settings:
–L500 watts, M1000 watts, H1500 watts or B2000 watts.
• H(1500 watts) is recommend. It is the most common wattage used at home.
3 Selecting Temperature
• To select temperature, press the T/Wbutton.
• The default temperature of 180ºC will appear on the LED screen.
• To increase temperature press +
• To decrease temperature press –
• Press +for maximum temperature of 200ºC or –for lower temperatures.
The minimum temperature is 60ºC.
Push the Power Button TWICE

Ecoheat Induction 3
Variable Energy Settings
The cooker has 4 built in variable energy settings
500 W (LOW) 1000 W (MEDIUM) 1500 W (HIGH) 2000 W (BOOST)
L500 WATTS (LOW) Use in very lower power situations .eg extended
simmering Not suitable for modified inverter use.
M1000 WATTS (MEDIUM) Use to conserve power or for genuine 2 KVA or
stronger off road generators.
H1500 WATTS (HIGH) Use for domestic use and where 240 volt power is
available. Minimizes energy consumption without
sacrificing efficiency
B2000 WATTS (BOOST) Use for flash frying or where rapid heat generation
is required.
Select BBQ when barbequing on the cooker for prolonged periods.
Additional Settings
ON/OFF Connect cooker to power. The ON/OFF LED light will illuminate. Avoid power
overload: Never share a power point or use power board with other appliances.
STAND BY When LED panel continually flashes ON/OFF, the cooker is
on STAND BY and heating will only occur once the power button is pressed again and
the illuminated LED light is on, but ceases to flash.
AUTO SHUT DOWN Cooker will shut down within 30 seconds of a pot being removed
from glasstop.
TIMER To activate timer press Icon down and hold for 3 to 4 seconds. Press icon
once and the LED screen will display “0:00”. The minute value “:00” will flash. To set,
press +or –icons. Range: 0 to 59 minutes. Press icon again to illuminate hour setting.
Value will flash “0:” Whilst flashing, press +or –icons to adjust hours from a minimum
of 0 to a maximum of 3 . To cancel timer, press down on icon for 3 to 4 seconds.
CHILD LOCK Press Icon down for 3 seconds to activate child lock. Press down again
for 3 seconds to cancel.

4 Ecoheat Slimline Operating Manual
Twin Fan
Ecoheat Slimline represents cutting edge
technology in reflected heat extraction
performance. The dual extraction fans
will continue to extract reflected heat
from the inner core of the cooker until the
inner circuitory has cooled to a safe level.
This ensures continual future optimum
performance of the cooker. Power to the
cooker must remain on at all times after
cooking is completed until fans reach
auto shutdown.Once fans shut down it
is then safe to disconnect cooker from
power source.
Cookware
Induction friendly cookware with a flat
base diameter between 10cm - 26cm is
most compatible. Use the ‘magnet’ test
to check induction compatibility. If magnet
sticks to cookware base, it is induction
friendly. Ceramic, glass and aluminum
cookware are not suitable. Cookware
with a base diameter less than 10cm is
not suitable. Curved and footed bases
are not induction friendly. Non induction
friendly cookware will activate Error Code
E0 that will illuminate on the LED screen.
If suitable cookware is not placed on
cooktop within one minute, it will revert
to Stand-by mode.
Cleaning, Maintenance
Cleaning the glass cooktop and control
panel. Clean with soft wet cloth. For oily
residues, clean with soft wet cloth dipped
in a little toothpaste or neutral detergent.
Wipe clean till residue free. Avoid using
scouring pads or harsh abrasives.
Air vents: Clean using a flexible dry
cleaning brush.
Safety Notice
• Never use a power board or share
a socket with other appliances.
• Keep cooker horizontal and 10cm away
from any wall for adequate ventilation.
• Never clean cooker with water whilst
powered.
• Keep cookers ventilation slots free
and clear at all times.
• Keep metallic utensils clear of glass
top during cooking.
• Never use induction cooker if glass top
is cracked or damaged.
• Never place an empty pot on cooktop.
• Children should remain clear of cooker
at all times.
• Electromagnetic fields are in force and
persons with a fitted pacemaker should
seek medical advice prior to use.
• Never place the induction cooker on
metal surface. This may cause metal
surface to heat and cause injury.
• Reflected heat may cause cooktop
to heat. Let cool prior to handling.
• Damaged or frayed power cord must
be replaced by a licensed electrician.
• Once cooking is completed, keep
cooker power on till fan stops. This will
cool down internal circuitry and avoid
heat damage. The fan will automatically
shut down once cooled to a safe level.
• Avoid direct impact or force to the black
crystal plate, as it may cause damage.
• Never place cooker on carpet,
tablecloth, paper or gas cooktop.
• Always unplug cooker at the power
point prior to cleaning.
• Ensure the black crystal plate is cool
before storing.

Ecoheat Induction 5
Built In Detection and Prevention Sensors
E0 Incompatible Cookware Detection
Non-magnetic cookware placed on the cooker will activate error code E0. This will
appear on the LED screen.
E1 Internal Overheat Detection
Should the internal temperature of the cooker get too high, it will automatically revert
to stand-by mode, and display the error code E1.
E3 Dry Burn Detection
If the cooktop excessively overheats or a pot base exceeds 270ºC or burns dry, the
cooker will automatically revert to stand-by mode and display error code E3.
E2 Voltage Abnormality Detection
If an abnormality in voltage or current is detected, the cooker will automatically revert
back to stand-by mode and display error code E2. The cooker will restart once power
returns to normal.
Two Hour Shutdown Protection
If the cooker is on for longer than two hours without a mode or function icon pressed,
it will automatically revert to stand-by mode. (Unless timer is preset for a longer period).
One Minute Shutdown Protection
If a pot is removed from the cooktop for longer than 30 seconds, the cooker will stop
heating and automatically return to stand-by mode and display error code E0.
E4 Internal Thermostat Shortening
If an abnormality In thermostat function is detected the cooker will automatically revert
to standby mode and display error code E4. An electrician should conduct testing to
establish thermostat functioning correctly.
E5 IGBT Board Malfunction
The IGBT board has a short circuit or open circuit condition and an electrician should
investigate.

6 Ecoheat Slimline Operating Manual
Troubleshooting Checklist
The Problem Troubleshooting Guide
1. Power is switched ON at a. Check to see power point is working.
point, but no sound can be b. Check to see if plug is in good
condition. be heard, or the
POWER icon has been pressed
but LED light isn’t on.
2. The cooker shuts down after a. Is the pot induction friendly?
60 seconds and alarm sounds. b. Have you placed pot in centre of
the cooktop?
c. Is the base diameter of the cooker
wider than 12cm?
3. The cooker stops suddenly a. Is the pot’s base heat too high
during cooking. (above 270º?)
b. Is the ventilation inadequate or airflow
blocked surrounding the cooker?
c. Has timer been accidentally activated
and time has expired?
d. Has an error code appeared
indicating power voltage or fuse
problem?
Specifications
Rated voltage Rated Frequency Rated Power AMP
240V 50Hz 500W 2.08
240V 50Hz 1000W 4.16
240V 50Hz 1500W 6.25
240V 50Hz 2000W 8.33

Ecoheat Induction 7
Warranty
ALL ECOHEAT INDUCTION COOKERS ARE SOLD
WITH A 12 MONTH MANUFACTURE’S WARRANTY.
We trust you’ll love cooking with Ecoheat.
Certification
