Empire Heating Systems PVS18N-3 Operating instructions

Page 1
OWNER’S MANUAL
AND INSTALLATION
INSTRUCTIONS
WARNING
If the information in these instructions are
not followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier,
call the re department.
— Installation and service must be
performed by a qualied installer,
service agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
Attention: Check local codes for venting requirements.
Young children should be carefully supervised when
they are in the same room as the appliance.
If installed in a direct-vent application, this appliance
may be installed in an aftermarket, permanently
located, manufactured home or mobile home, where
not prohibited by state or local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certied
kit is used.
Carton Contents:
UltraSaver 90 Plus Wall Furnace (with shroud attached)
Instruction Envelope Containing:
Owner’s Manual and Installation Instructions
Shut-off Valve
2-1/2” Hose Clamp
Hardware Pack Containing:
(4) - #10 x 1-1/2” Hex Head Screws
4’ - 3/8 I.D. Condensate Drain Hose
WARNING
If not installed, operated and maintained
in accordance with the manufacturer’s
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
ULTRASAVER 90 PLUS
WALL FURNACE
MODELS
PVS18(N,P)-3
PVS35(N,P)-3

37873-0-0217Page 2
TABLE OF CONTENTS
SECTION PAGE
IMPORTANT SAFETY INFORMATION........................................................................................3
SAFETY INFORMATION FOR USERS OF LP-GAS ...................................................................4
REQUIREMENTS FOR MASSACHUSETTS ...............................................................................5
GENERAL SAFETY INFORMATION............................................................................................6
OWNER’S MANUAL AND OPERATION INSTRUCTIONS.................................................. 7 - 12
INSTALLATION INSTRUCTIONS ...................................................................................... 13 - 38
Introduction ..................................................................................................................... 14 - 20
FAQ - Installation Considerations............................................................................................14
Accessories .............................................................................................................................15
Specications and Dimensions ...............................................................................................16
Clearances to Combustibles ...................................................................................................17
Wall Furnace Display ..............................................................................................................18
Wall Furnace Component Arrangement - Front ......................................................................19
Wall Furnace Component Arrangement - Rear .......................................................................20
Wall Furnace Installation ................................................................................................ 21 - 38
Mounting the Rear Shroud .............................................................................................. 21 - 22
Gas Supply...................................................................................................................... 23 - 24
Vent Clearances......................................................................................................................25
Venting Requirements.............................................................................................................26
Venting ............................................................................................................................. 27- 28
Vent Examples for Single Flue ........................................................................................ 29 - 30
Direct Vent Examples...................................................................................................... 31 - 32
Lighting Instructions ................................................................................................................33
Wiring .............................................................................................................................. 34 - 35
Startup Checklist .....................................................................................................................36
Initial Startup and Adjustments........................................................................................ 37 - 38
TROUBLESHOOTING................................................................................................................39
MAINTENANCE & SERVICE ............................................................................................. 40 - 41
PARTS LIST................................................................................................................................42
EXPLODED VIEW ......................................................................................................................43
MASTER PARTS DISTRIBUTOR LIST......................................................................................44
HOW TO ORDER REPAIR PARTS ............................................................................................44
APPLIANCE SERVICE HITORY ........................................................................................ 45 - 46
WARRANTY................................................................................................................................47

37873-0-0217 Page 3
IMPORTANT SAFETY INFORMATION
THIS IS A HEATING APPLIANCE
WARNING
This appliance must be installed and repaired by a qualied
service person. Installers who are not familiar with the
installation of the UltraSaver and have questions, should
contact Empire Comfort Systems, Inc. prior to installing the
appliance to avoid creating a hazardous operating condition.
• Due to high temperatures the appliance should be
located out of trafc and away from furniture and
draperies.
• Children and adults should be alerted to the hazards of
high surface temperatures and should stay away to avoid
burns or clothing ignition.
• Young children should be carefully supervised when they
are in the same room as the appliance.
• Clothing or other ammable material should not be
placed on or near the appliance.
• Any safety screen or guard removed for servicing an
appliance, must be replaced prior to operating the
appliance.
• Keep burner and control compartment clean.
• For manufactured home or mobile home or residen-
tial installation convertible for use with natural gas and
liqueed petroleum gases when provision is made for the
simple conversion from one gas to the other.
• Do not block warm air discharge. Do not allow anyone to
sleep directly in front of the wall furnace.
WARNING
The appliance should be inspected before use and at least
annually by a qualied service person. More frequent
cleaning may be required due to excessive lint from
carpeting, bedding materials, etc. It is imperative that control
compartments, burners and circulating air passageways of
the appliance be kept clean.
• DO NOT put anything around the appliance that will
obstruct the ow of combustion and ventilation air.
• DO keep the appliance area clear and free from combus-
tible material, gasoline and other ammable vapors and
liquids.
• Do examine venting system periodically and replace
damaged parts.
• Do make a periodic visual check of burner. Clean and re-
place damaged parts.
• DO NOT use the appliance if any part has been under
water. Immediately call a qualied service technician
to inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
• DO NOT operate this appliance without the front panel
installed.
Note to the Installer
1. The installer must leave instruction manual with owner after
installation.
2. The installer must have the owner ll out and mail registration
card supplied with the wall furnace or register the wall furnace
online at www.empirezoneheat.com.
3. The installer should show the owner how to start and operate
wall furnace and thermostat.
4. The installer must locate wall furnace near a grounded wall
receptacle for 115VAC power and must provide gas supply
and vent the wall furnace properly for safe operation.
Safety markings are frequently used in this manual to designate a degree or level of
seriousness and should not be ignored.
DANGER: Indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
Notice: Addresses practices not related to personal injury.

37873-0-0217Page 4
SAFETY INFORMATION FOR USERS OF LP-GAS
Propane (LP-Gas) is a ammable gas which can cause res
and explosions. In its natural state, propane is odorless and
colorless. You may not know all the following safety precautions
which can protect both you and your family from an accident.
Read them carefully now, then review them point by point with
the members of your household. Someday when there may not
be a minute to lose, everyone’s safety will depend on knowing
exactly what to do. If, after reading the following information,
you feel you still need more information, please contact your
gas supplier.
LP-GAS WARNING ODOR
If a gas leak happens, you should be able to smell the gas
because of the odorant put in the LP-Gas.
That's your signal to go into immediate action!
• Do not operate electric switches, light matches, use your phone.
Do not do anything that could ignite the gas.
• Get everyone out of the building, vehicle, trailer, or area. Do
that IMMEDIATELY.
• Close all gas tank or cylinder supply valves.
• LP-Gas is heavier than air and may settle in low areas such as
basements. When you have reason to suspect a gas leak, keep
out of basements and other low areas. Stay out until reghters
declare them to be safe.
• Use your neighbor’s phone and call a trained LP-Gas service
person and the re department. Even though you may not
continue to smell gas, do not turn on the gas again. Do not
re-enter the building, vehicle, trailer, or area.
• Finally, let the service man and reghters check for escaped
gas. Have them air out the area before you return. Properly
trained LP-Gas service people should repair the leak, then
check and relight the gas appliance for you.
NO ODOR DETECTED - ODOR FADE
Some people cannot smell well. Some people cannot smell
the odor of the chemical put into the gas. You must nd out if
you can smell the odorant in propane. Smoking can decrease
your ability to smell. Being around an odor for a time can affect your
sensitivity or ability to detect that odor. Sometimes other odors in
the area mask the gas odor. People may not smell the gas odor or
their minds are on something else. Thinking about smelling a gas
odor can make it easier to smell.
The odorant in LP-gas is colorless, and it can fade under some
circumstances. For example, if there is an underground leak, the
movement of the gas through soil can lter the odorant. Odorants in
LP-Gas also are subject to oxidation. This fading can occur if there
is rust inside the storage tank or in iron gas pipes.
The odorant in escaped gas can adsorb or absorb onto or into
walls, masonry and other materials and fabrics in a room. That will
take some of the odorant out of the gas, reducing its odor intensity.
LP-Gas may stratify in a closed area, and the odor intensity could
vary at different levels. Since it is heavier than air, there may be
more odor at lower levels. Always be sensitive to the slightest gas
odor. If you detect any odor, treat it as a serious leak. Immediately
go into action as instructed earlier.
SOME POINTS TO REMEMBER
• Learn to recognize the odor of LP-gas. Your local LP-Gas
Dealer can give you a “Scratch and Sniff” pamphlet. Use it to
nd out what the propane odor smells like. If you suspect that
your LP-Gas has a weak or abnormal odor, call your LP-Gas
Dealer.
• If you are not qualied, do not light pilot lights, perform service,
or make adjustments to appliances on the LP-Gas system. If
you are qualied, consciously think about the odor of LP-Gas
prior to and while lighting pilot lights or performing service or
making adjustments.
• Sometimes a basement or a closed-up house has a musty
smell that can cover up the LP-Gas odor. Do not try to light
pilot lights, perform service, or make adjustments in an area
where the conditions are such that you may not detect the odor
if there has been a leak of LP-Gas.
• Odor fade, due to oxidation by rust or adsorption on walls of
new cylinders and tanks, is possible. Therefore, people should
be particularly alert and careful when new tanks or cylinders
are placed in service. Odor fade can occur in new tanks, or
reinstalled old tanks, if they are lled and allowed to set too
long before relling. Cylinders and tanks which have been out
of service for a time may develop internal rust which will cause
odor fade. If such conditions are suspected to exist, a periodic
sniff test of the gas is advisable. If you have any question
about the gas odor, call your LP-gas dealer. A periodic
sniff test of the LP-gas is a good safety measure under
any condition.
• If, at any time, you do not smell the LP-Gas odorant and you
think you should, assume you have a leak. Then take the same
immediate action recommended above for the occasion when
you do detect the odorized LP-Gas.
• If you experience a complete “gas out,” (the container is under
no vapor pressure), turn the tank valve off immediately. If the
container valve is left on, the container may draw in some air
through openings such as pilot light orices. If this occurs, some
new internal rusting could occur. If the valve is left open, then
treat the container as a new tank. Always be sure your con-
tainer is under vapor pressure by turning it off at the container
before it goes completely empty or having it relled before it is
completely empty.

37873-0-0217 Page 5
REQUIREMENTS FOR MASSACHUSETTS
For all side wall horizontally vented gas fueled equipment installed
in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the
Commonwealth and where the side wall exhaust vent termination
is less than seven feet above nished grade in the area of the
venting, including but not limited to decks and porches, the
following requirements shall be satised:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS.
At the time of installation of the side wall horizontal vented
gas fueled equipment, the installing plumber or gastter shall
observe that a hard wired carbon monoxide detector with an
alarm and battery back-up is installed on the oor level where
the gas equipment is to be installed. In addition, the installing
plumber or gastter shall observe that a battery operated
or hard wired carbon monoxide detector with an alarm is
installed on each additional level of the dwelling, building or
structure served by the side wall horizontal vented gas fueled
equipment. It shall be the responsibility of the property owner
to secure the services of qualied licensed professionals for
the installation of hard wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas
fueled equipment is installed in a crawl space or an attic,
the hard wired carbon monoxide detector with alarm and
battery back-up may be installed on the next adjacent
oor level.
b. In the event that the requirements of this subdivision
can not be met at the time of completion of installation,
the owner shall have a period of thirty days to comply
with the above requirements; provided, however, that
during said thirty day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each
carbon monoxide detector as required in accordance with the
above provisions shall comply with NFPA 720 and be ANSI/
UL 2034 listed and IAS certied.
3. SIGNAGE. A metal or plastic identication plate shall be
permanently mounted to the exterior of the building at a
minimum height of eight feet above grade directly in line
with the exhaust vent terminal for the horizontally vented
gas fueled heating appliance or equipment. The sign shall
read, in print size no less than one-half (1/2) inch in size,
“GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL
OBSTRUCTIONS”.
4. INSPECTION. The state or local gas inspector of the side
wall horizontally vented gas fueled equipment shall not
approve the installation unless, upon inspection, the inspector
observes carbon monoxide detectors and signage installed
in accordance with the provisions of 248 CMR 5.08(2)(a) 1
through 4.
(b) EXEMPTIONS: The following equipment is exempt from
248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled
“Equipment Not Required To Be Vented” in the most
current edition of NFPA 54 as adopted by the Board;
and
2. Product Approved side wall horizontally vented gas
fueled equipment installed in a room or structure
separate from the dwelling, building or structure
used in whole or in part for residential purposes.
(d) MANUFACTURER REQUIREMENTS - GAS
EQUIPMENT VENTING SYSTEM NOT PROVIDED.
When the manufacturer of a Product Approved side
wall horizontally vented gas fueled equipment does not
provide the parts for venting the ue gases, but identies
“special venting systems”, the following requirements
shall be satised by the manufacturer:
1. The referenced “special venting system” instructions
shall be included with the appliance or equipment
installation instructions; and
2. The “special venting systems” shall be Product
Approved by the Board, and the instructions for
that system shall include a parts list and detailed
installation instruction.
(e) A copy of all installation instructions for all Product
Approved side wall horizontally vented gas fueled
equipment, all venting instructions, all parts lists for
venting instructions, and/or all venting design instructions
shall remain with the appliance or equipment at the
completion of the installation.
Commonwealth of Massachusetts: The installation must be
made by a licensed plumber or gas tter in the Commonwealth
of Massachusetts.

37873-0-0217Page 6
GENERAL SAFETY INFORMATION
WARNING
The safety information listed below must be followed
during the installation, service, and operation of this
product. Failure to following the safety recommendations
could result in possible damage to the equipment, serious
personal injury, or death.
General Information
This series is designed certied in accordance with American Na-
tional Standard/CSA Standard Z21.86 and CSA 2.32 as a power
vent wall furnace to be installed according to these instructions.
Any alteration of the original design, installed other than as
shown in these instructions will be the responsibility of the
person and company making the changes, and will void the
warranty. This product may not be used with any type of gas
other than what is shown on the rating plate unless converted
using an Empire approved conversion kit.
Installation
Installation and replacement of gas piping, gas utilization equip-
ment or accessories, and the repair and servicing of this equip-
ment must be performed by a qualied agency. The term “qualied
agency” means any individual, rm, corporation or company which
either in person or through a representative is engaged in and is
responsible for (a) the installation or replacement of gas piping or
(b) the connection, installation, repair or servicing of equipment,
who is experienced in such work, familiar with all precautions re-
quired and has complied with all the requirements of the authority
having jurisdiction.
• This installation must conform with local codes, or in the
absence of local codes, the National Fuel Gas Code,
NFPA 54/ANSI Z223.1.
• This appliance, when installed, must be electrically grounded
in accordance with local codes or. In the absence of local
codes, with the National Electrical Code, ANSI/NFPA 70.
• Provide adequate clearances around the wall furnace for ser-
vicing and ensure there are no obstructions to the combustion
air intake situated at the back of the wall furnace. Refer to
Pages 16 and 17.
• This wall furnace is equipped with a three-prong [ground-
ing] plug for your protection against shock hazard and
should be plugged directly into a properly grounded
three-prong receptacle. Do not cut or remove the ground-
ing prong from this plug. For an ungrounded receptacle,
purchase an adapter with two prongs and a wire for grounding.
• This installation must conform with local codes, or in the
absence of local codes, in Canada use Canadian Electrical
Code CSA C22.1 and in the United States use the National
Fuel Gas Code NFPA 54/ANSI Z223.1.
• This appliance, when installed, must be electrically ground-
ed in accordance with local codes or. In the absence of lo-
cal codes, in Canada with the Canadian Electrical Code CSA
C22.1 and in the United States with the National Electrical
Code ANSI/NFPA 70.
A manufactured home (USA only) or mobile home OEM installa-
tion must conform with the Manufactured Home Construction and
Safety Standard, Title 24 CFR, Part 3280, or when such a stan-
dard is not applicable, the Standard for Manufactured Home In-
stallations, ANSI/NCSBCS Z225.1, or Standard for Gas Equipped
Recreational Vehicles and Mobile Housing, CSA Z240.0.
Installation in Residential Garages
Gas utilization equipment in residential garages shall be installed so
that all burners and burner ignition devices are located not less than
18 inches (457 mm) above the oor. The equipment shall be locat-
ed, or protected, so it is not subject to physical damage by vehicles.
Operation of Wall furnace During Construction
The wall furnace shall not be used during construction.
WARNING
Any change to this wall furnace or its control can be dan-
gerous.
WARNING
This is a heating appliance and any panel, door or guard
removed for servicing the appliance must be replaced prior
to operating the appliance.
NOTICE: During initial ring of this wall furnace, residual oil from
the heat exchanger may bake off and smoke may occur.
Provide adequate ventilation to the area where the
wall furnace is installed to prevent triggering of smoke
alarms. Refer to page 36 for more detail.
Additional code information listed below is for reference pur-
poses only and does not necessarily have jurisdiction over
local or state codes. Always consult with local authorities be-
fore installing any gas appliance.
Attention: This appliance may be installed in the U.S. or in
Canada.
Combustion and Ventilation Air
U.S.: National Fuel Gas Code NFPA 54/ANSI Z223.1(NFGC),
Air for Combustion and Ventilation.
CANADA: National Standard of Canada for Natural Gas and
Propane Installation Codes (NSCNGPIC)
CAN/CGA-B149.1 and .2, Part 7, Venting Systems and Air
Supply for Appliances
Electrical Connections
U.S.: National Electrical Code (NEC) ANSI/NFPA 70
CANADA: Canadian Electrical Code CSA C22.1
Gas Piping and Gas Pipe Pressure Testing
U.S.: NFGC and National Plumbing Codes
CANADA: NSCNGPIC Part 5
General Installations
U.S.: Current edition of the NFGC and NFPA 90B. For copies con-
tact the National Fire Protection Association Inc., Batterymarch
Park, Quincy, MA 02269 or American Gas Association, 400 N.
Capitol, N.W., Washington DC 20001 or www.NFPA.org.
CANADA: NSCNGPIC. For a copy, contact Standard Sales, CSA
International, 178 Rexdale Blvd., Etobicoke (Toronto), Ontario,
M9W 1R3 Canada
Safety
U.S.: NFGC NFPA 5/ANSI Z223.1
CANADA: (NSCNGPIC) CAN/GCA-B149.1 and .2 National
Standard of Canada

37873-0-0217 Page 7
OWNER’S MANUAL
AND
OPERATION INSTRUCTIONS
www.empirezoneheat.com

37873-0-0217Page 8
OWNER’S MANUAL
Before You Start
1. Verify there is electrical power to the wall furnace.
Verify the Main Power Switch is turned on. See Figure 1.
Figure 1
If electrical power is present, the red and green control board
LED’s will begin to ash alternately. See Figure 3. Each light will
ash four times then the wall furnace will enter standby mode.
While in remote mode, the green LED will ash slowly and the
display panel will show a double dash “ - - “. See Figure 2.
Figure 2
Figure 3
If the control board LED’s do not activate, verify the wall furnace
is plugged in and the breaker is on. If the wall furnace is still not
activated, contact a qualied service technician.
2. Verify the main gas supply to the unit is on.
The shutoff valve should be in the “OPEN” position. See Figure 4.
CLOSED
OPEN
Figure 4
Starting the Wall Furnace
The wall furnace has three modes for controlling operation:
Remote, Manual and Local. When in Remote mode, the wall
furnace can be operated by an external Millivolt thermostat,
remote control, or on/off wall switch. When in Manual mode, the
wall furnace can be turned on and off and the heat level adjusted
manually from the display panel. When operating in Local mode,
the owner sets a desired room temperature on the display panel
and the wall furnace will automatically turn on and off and adjust
the heat level to achieve the set temperature.
Wall Furnace Operation - Remote Mode (External Millivolt
Thermostat or Remote)
1. To initiate the wall furnace Remote mode, press the “Mode
Select” button on the wall furnace display panel once from
OFF mode to display a double dash “ - - “. See Figure 5.
Figure 5

37873-0-0217 Page 9
2. When the external control is activated, the wall furnace dis-
play panel will illuminate and show the heat level along with
the remote signal symbol. The wall furnace will begin the
start up sequence automatically. See Figure 6.
Figure 6
Notice: When a Millivolt thermostat or on/off switch is used, the
wall furnace will only operate on high (Level 5).
Notice: When operating in Remote mode, a button sequence
may be used to lock the display panel. See page 12.
3. If a Millivolt thermostat or thermostatic remote is used, set to
the desired room temperature. The wall furnace will turn on
and off automatically in response to the thermostat.
Wall Furnace Operation - Manual Mode
Notice: When operating the wall furnace in Manual mode from
the display panel, only basic operations are available: On, off and
heat level adjustment.
1. To operate the wall furnace in Manual mode, press the “Mode
Select” button on the display panel twice from off mode until
a number appears in the Heat Level location on the display
panel. See Figure 7. The wall furnace will begin the start up
sequence.
Figure 7
2. Use the UP and DOWN adjustment buttons on the right of the
display panel to set the desired level. The display will illumi-
nate and the word “SET” will appear in the top right corner of
the display. After the level is set, the display panel will darken
and the heat level will be displayed.
Wall Furnace Operation - Local Mode (Internal Thermostat)
1. To operated the wall furnace in Local (thermostatic) mode,
press the Mode Select button on the wall furnace display
panel three times from the off mode. The display panel will
show the current room temperature. See Figure 8.
Figure 8
Notice: The temperature sensing probe is built into the left rear
of the wall furnace. A kit to relocate the probe is available. See
page 15.
2. Use the up and down adjustment buttons on the display
panel to set the desired room temperature.
The display will illuminate and the word “SET” will appear
in the top right corner of the display. See Figure 9. After the
temperature is set, the display panel will darken and return
to displaying the room temperature.
Figure 9
3. When the room temperature drops to 3°F below the set tem-
perature, the wall furnace will begin the start up sequence.
4. The wall furnace will automatically adjust the starting level to
meet the heat demand.
Notice: The greater the difference between the room and de-
sired temperatures the higher the starting level.
As the room temperature nears the desired temperature the
level will decrease.
5. The wall furnace will turn off if the room temperature rises
slightly above the set temperature when operating at level 1.
Notice: The wall furnace will adjust the heat level in order to
reach a point of equilibrium between the room and desired tem-
peratures. This may cause the wall furnace to operate for long
periods of time at low levels.
When the backlight button is pushed, the display will cycle be-
tween the level, set temperature and room temperature.
Notice: While the wall furnace is operating in Local mode, the
display will only show the room temperature unless the backlight
button is pushed.
OWNER’S MANUAL

37873-0-0217Page 10
Wall Furnace Operations Sequence
1. When the main power switch is turned on, the red and green
control board LED’s will begin to ash alternately. If using the
FRBTPL Remote accessory (page 15) the remote receiver
will search for the remote transmitter’s signal. See Figures
10 and 11.
Figure 10
Figure 11
Each light will pulse four times then the wall furnace will
enter Remote mode. While in Remote mode, the green LED
will ash slowly and the display panel will shown a double
dash “- -”. See Figure 12.
Figure 12
2. When a call for heat is received, the wall furnace display
panel will illuminate and show the level. See Figure 13.
Figure 13
3. Adjust level with the up and down adjustment buttons in Man-
ual Mode. If operating in Local mode, the heat level will adjust
automatically.
4. The red and green control panel LED lights will begin to ash
alternately while the wall furnace performs a safety test. After
approximately 45 seconds the test will complete and the wall
furnace will prepare to ignite.
5. After the safety test is complete, the ignitor will glow red and
the burner will light within approximately 30 seconds.
Notice: If the burner fails to light, the wall furnace will retry the
ignition sequence three times then enter lock-out mode if it fails
to light. See page 39 for the fault codes and their meanings.
6. After the burner lights, the ame icon on the display panel will
appear and the wall furnace will automatically adjust to the
heat level shown on the display. The wall furnace will always
ignite on Level 5 (High) prior to adjusting to the heat level
shown on the display panel. See Figure 14.
Figure 14
OWNER’S MANUAL

37873-0-0217 Page 11
7. The blower will activate after 45 to 70 seconds depending on
heat level. The blower will automatically adjust its speed to
match the heat level. The blower speed will be indicated on
the display panel. See Figures 16 to 19.
8. The heat level can be adjusted either up or down at any
point during the wall furnace’s operation in Manual Mode.
If using the Local mode, the wall furnace adjusts the level
automatically.
Notice: When changing from a low heat level to a higher heat
level, the wall furnace will automatically increase to Level 5
(High) prior to proceeding to the desired heat level. This is to
ensure consistent operation.
9. When the wall furnace is shut down, the inducer will operate
at full power for approximately 10 seconds after the burner is
extinguished. This is to clear any ue products from the wall
furnace’s combustion chamber. The circulating air blower will
continue to operate from 100 to 160 seconds to ensure the
wall furnace cools sufciently.
Turning the Wall Furnace Off - Display Panel
To turn the wall furnace off from the display panel, press the “Mode
Select” button on the wall furnace display panel until the panel
turns off.
Figure 15
The burner will instantly go off, but the circulating air blower will
continue to operate from 100 to 160 seconds to ensure the wall
furnace cools off.
Power Interruption
The wall furnace requires a 115VAC power source to operate. See
Specications on page 16.
When power is restored to the wall furnace after a power interrup-
tion, the wall furance will automatically reactivate in “Remote” (--)
mode and all operation settings will have reset to the factory de-
faults. If the wall furnace is normally operated using Manual mode
or with the built-in thermostat, the operation settings will need to
be manually reset to the desired mode and settings to resume
operation.
Installing an optional Millivolt thermostat allows the wall furnace to
automatically resume operation once power is restored.
Circulating Air Blower Operation
The circulating air blower is operated by a built in timer. The blower
will activate after approximately 45 to 70 seconds depending on
heat level. The blower will automatically adjust its speed to match
the heat level. The blower icon and speed are indicated on the
display panel. See Figures 16 to 19.
Figure 16 - Heat Levels 1 and 2, Blower Speed 1
Figure 17 - Heat Level 3, Blower Speed 2
Figure 18 - Heat Level 4, Blower Speed 3
Figure 19 - Heat Level 5, Blower Speed 4
After the wall furnace is turned off, the blower will continue to oper-
ate for 100 to 160 seconds to ensure the wall furnace cools suf-
ciently.
Notice: When the wall furnace is turned off, the blower speed will
be displayed while it is running.
OWNER’S MANUAL

37873-0-0217Page 12
OWNER’S MANUAL
Humidier Operation
With the optional humidication tray kit (page 15), as the wall fur-
nace operates condensate is collected and transferred to a pan in
the bottom of the wall furnace. When the condensate reaches a
certain level, a heating element evaporates the water into the air
stream.
While the condensate is being evaporated, the “AUX” symbol will
be displayed. See Figure 20.
Notice: The humidier may not operate with every cycle.
AUX
Figure 20
Troubleshooting
This wall furnace’s controls include a troubleshooting feature
which will display a code on the display panel should an error oc-
cur. See page 39 for a list of troubleshooting codes. Some codes
will require the system to be reset.
To reset the wall furnace, press the mode selection button on the
display panel repeatedly until the wall furnace cycles through the
“OFF” setting once. If the error has been cleared, the wall furnace
will operate normally. If the error is still present, consult a qualied
service technician.
Remote Mode - Anti-tamper
To lock the display panel when operating the wall furnace in
remote mode, press and hold the Mode, Up adjust and Down
adjust buttons for ten seconds. The display panel will display “At”.
See Figure 21.
Figure 21
After the display panel darkens it will show the level and blower
speed as normal during operation. When the wall furnace is in an
OFF cycle, the display panel will show “At”.
To deactivate the Anti-tamper mode, press and hold the Mode,
Up adjustment and Down adjustment buttons for ten seconds.
The display will return to the double dash “- -”.

37873-0-0217 Page 13
INSTALLATION
INSTRUCTIONS
www.empirezoneheat.com

37873-0-0217Page 14
What tools are needed for installation?
Pipe Wrench
Adjustable Wrench
Drill
Tape Measure
10” x 5/16” Nut Driver
Thread Sealant
Level
2-1/2” Diameter Hole Saw for 2” pipe
2” Diameter Hole Saw for 1-1/2” pipe
1” Diameter Hole Saw
Non-corrosive Leak Check Solution
Where will the wall furnace be installed?
• On the Floor - Wall Furnace comes equipped from
factory for this option. See Page 21.
• Wall Mounted - Wall mount shroud needed. See
Page 15 for kit number.
• Mount wall furnace at a height so that the con-
trols can still be observed.
• Interior Wall - Maximum vent length is 50 feet.
• Exterior Wall
• Locate Electrical Supply - Extension cords may
NOT be used.
• Wall Furnace Dimensions page 16.
• Clearances to Combustibles page 17.
What kind of venting application will be used?
• Single Flue - Wall Furnace comes equipped from
factory for this option. A 2” or 1-1/2” pipe may be
used. If a 1-1/2” pipe is used, it must be enlarged to
a 2” pipe prior to exiting the wall into the shroud.
• Direct Vent - An “Air Pipe Kit” is required and is
available for order. See page 15.
How will the venting be run?
• Straight out the back - Wall Furnace comes
equipped from factory for this option. Standard Rear
Shroud supplied. See page 27.
• In Front of the wall - Deep Shroud needed. Venting
option may NOT be done in Wall Mount installations.
See page 15 for kit number.
• Venting Guidelines pages 25 to 32.
• Maximum vent length is 50 feet.
• Notice: Clean all debris from the inside of the ue
pipe prior to applying the glue and nal assembly
of the pipe. Since the condensate is designed to
ow back to the appliance this debris will be carried
to the condensate trap resulting in a clog. An “A2”
error will appear on the display panel if this happens.
The clog, and the work required to x it, can be eas-
ily prevented by pulling a wet cloth through the pipe
prior to applying the glue and nal assembly.
How will the condensate be disposed?
• To a drain - Wall Furnace comes equipped from the
factory to drain up to 3 feet away from the appliance.
• An Extension Kit and External Condensate Pump
kit may also be used. See page 15 for kit numbers.
• Humidication - Optional Heated Humidication Tray
Kit available for order. See page 15 for kit number.
• Winterization information on page 41.
How will the wall furnace be operated?
• Remote - external Millivolt thermostat, wall switch or
remote control. See page 15 for kits available from
Empire Comfort Systems.
• Manual - use the display panel to control the heating
level and turn the wall furnace on and off.
• Local (Internal Thermostatic) - Factory installed
temperature probe on the wall furnace with a built-
in thermostatic function to control the wall furnace’s
operation.
• If it is desired to use the temperature sensed in
another part of the room, a wired temperature
probe accessory kit is available. See page 15 for
kit numbers.
• See Operation Instructions pages 7 to 12.
• Notice: Following a power outage, this wall furnace
will not automatically resume operation when oper-
ated manually or with the internal thermostat. Once
power is restored, the wall furnace will automatically
power on in “Remote Mode” (--), and the original op-
eration settings will need to be re-entered. Installing
an optional Millivolt thermostat control allows the wall
furnace to automatically resume operation under that
thermostat’s control once power is restored. Ask your
dealer for details.
INTRODUCTION
FAQ - INSTALLATION CONSIDERATIONS

37873-0-0217 Page 15
IMPORTANT
All correspondence regarding repair and service should
refer to complete Model Number, Serial Number and type
of gas.
ACCESSORIES
VENTING
Part Number Description Typical Uses
PVSA1 Air Pipe Kit Converts wall furnace from single ue to direct-vent (Comes standard with heater)
PVSDV35A DV35 Vent Transition Cap Replaces DV35 Vent cap with a transition to PVC pipe for a 2” single ue
SHROUDS
Part Number Description Typical Uses
PVSDS1 Deep Rear Shroud Allows venting to be run in front of the wall in on the oor installations
PVSWS1 Wall Mount Shroud Allows installation of wall furnace off of the oor
CONDENSATE KITS
Part Number Description Typical Uses
PVSHT2 Heated Humidication Tray Evaporates condensate as humidity back into the room
PVSEP2 External Condensate Pump Pumps condensate away from wall furnace instead of gravity drain
PVSCT10 Condensate Hose Extension 10 ft condensate drain extension
CONTROLS
Part Number Description Features
PVSRT1 Temperature Sensor Relocation Kit Room Temperature Sensor Extension
Notice: Following a power outage, this wall furnace will not automatically resume operation when operated manually or with
the internal thermostat. Once power is restored, the wall furnace will automatically power on in “Remote Mode” (--), and the
original operation settings will need to be re-entered. Installing an optional Millivolt thermostat control allows the wall furnace
to automatically resume operation under that thermostat’s control once power is restored. Ask your dealer for details.
INTRODUCTION
ACCESSORIES
Removing the Front Panel
It may become necessary to remove the front panel of the
appliance to remove dropped or fallen objects.
Remove the front panel by lifting up then pulling out. Re-
place the panel by reversing this step.
WARNING
FOR YOUR SAFETY, TURN OFF POWER TO APPLIANCE.
WARNING
Do not operate this appliance without the front panel.

37873-0-0217Page 16
SPECIFICATIONS
Models PVS18(N,P) PVS35(N,P)
Maximum Input BTU/HR (KW/H)* 17,500 (5.13) 35,000 (10.26)
Minimum Input BTU/HR (KW/H)* 8,750 (2.56) 17,500 (5.13)
Height 27-7/8” 27-7/8”
Width 36-1/8” 36-1/8”
Depth with Shroud** 13 13
Gas Inlet (Pipe) 3/8” Pipe 3/8” Pipe
Electrical - The wall furnace comes equipped with a 5 foot (1.5m) 3 pronged cord exiting the rear left side of the wall furnace, for
connection to an approved 115 VAC, 60 Hz, 15A (maximum) wall receptacle. The Minimum Circuit Amp (MCA) is 8A, 920W and with
an accessory heated humidication tray installed, the MCA is 10A, 1150W.
Vent Pipe: 1-1/2 or 2 inch diameter pipe, 50 feet maximum equivalent length. See pages 26 and 29 to 32. The vent termination elbow
does not contribute to the overall vent length measurement.
* Input ratings are based on sea level operation and may vary at different elevations. No orice change is required. The appliance will
de-rate automatically 1.5% per 1,000 feet.
** Add 3-3/8 inches for deep shroud.
All vent and combustion air pipes and ttings must be Schedule 40 PVC, ULC S636 and meet the ANSI/ASTM Standard D1785. Cement
must conform to ASTM Standard D2564. Empire-approved poly pipe with gasketed joints may also be used. Contact your Empire dealer
for availability.
Listed for Category IV venting.
INTRODUCTION
SPECIFICATIONS AND DIMENSIONS
Dimensions - Figure 22
Approved Alternate Vent Systems
Manufacturer Vent System
Duravent PolyPro
Centrotherm InnoFlue

37873-0-0217 Page 17
Select a location with adequate accessibility clearances for servicing
and proper installation. Locate the wall furnace within 5 feet of a 115
VAC wall receptacle to properly power the wall furnace. Do NOT
use an extension cord.
When facing the front of the wall furnace the minimum clearances
from casing to combustible construction are 12" (305mm) on top, 0"
(0mm) on each side and 0” (0mm) from the oor, 0” (0mm) to rear
wall, and 36” (914mm) in front of the wall furnace to walls or furniture.
Notice: It is recommend to leave 8" (203mm) clearance on each
side for servicing, furniture and other easily moved items may be
placed to the sides (not the front) of the wall furnace. See Figure 23.
CLEARANCES TO COMBUSTIBLES
INTRODUCTION
12”
0”
(8” service area
recommended)
36”
0”
(8” service area
recommended)
Figure 23

37873-0-0217Page 18
INTRODUCTION
WALL FURNACE DISPLAY
SET
AUX
RESET
Temperature Display
Shows room temperature
and set temperature
Level
Shows heating
level
Blower Speed
Shows current
blower speed
Flame Icon
Shows when
burners are on
SET
Shows while adjusting the heat level or set temperature.
Also shows in Local Mode when the backlight button is
pushed when the set temperature is displayed. It will
disappear when the room temperature is displayed.
RESET
Shows when heater
needs to be reset
Blower Icon
Shows when room air
blower is running
ºC/ºF
Changes temperature units
from Fahrenheit to Celsius
Mode Select
Changes between modes
Off/Remote/Manual/Local
AUX
Shows during operation of
heated tray accessory
Backlight
Activates back lighting of display.
Also shows set temperature and
heat/blower level information in
Local Mode.
Up Adjustment
Adjusts heat level or
set temperature up
Signal Icon
Shows during
Remote Mode
Down Adjustment
Adjusts heat level or
set temperature down
Figure 24

37873-0-0217 Page 19
INTRODUCTION
WALL FURNACE COMPONENT ARRANGEMENT - FRONT
CONTROL BOARD
BLOWER MOTOR
MAIN POWER
ON/OFF SWITCH
BURNER COMPARTMENT
GAS VALVE
GAS VALVE
ON/OFF SWITCH
CIRCULATING AIR BLOWER
INDUCER
INDUCER MOTOR
HEAT EXCHANGER
FRONT SHIELD
INNER SHIELD
(SINGLE TUBE UNITS ONLY)
FRONT LOUVER ASSEMBLY
DISPLAYPANEL OUTER CASING
FRONT COVER ASSEMBLY
CONDENSATE TRAP
AIR PRESSURE
TRANSDUCER
PRESSURE SWITCH
Figure 25
Figure 26

37873-0-0217Page 20
INTRODUCTION
COMBUSTION AIR DUCT
FILTER
COMBUSTION AIR INTAKE
TEMPERATURE SENSOR
FLUE OUTLET
DISPLAYPANEL
FILTER COVER
REAR SHROUD
COMBUSTION AIR INTAKE
(DIRECT VENT)
FLUE OUTLET
GAS LINE OPENING
ALTERNATE GAS LINE OPENINGS
ALTERNATE ELECTRICAL
CORD OPENING
WALL FURNACE COMPONENT ARRANGEMENT - REAR
Figure 27
Figure 28
