INSTALLATION INSTRUCTIONS
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
We suggestthat our
wood burning hearth
products be installed
and servicedby
professionals who are
certified in theU.S.by
the National Fireplace
Institute
®
(NFI) as
NFIWood Burning
Specialists.
This replace is approved
for use as a wood burning
replace or for use with a
vented gas log approved
to ANSI Z21.60 or Z21.84
standards or for use with
a vent-free gas log heater
approved to ANSI Z21.11.2
standard.
WARNING
If the information in this manual is not
followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
— DO NOT store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
— DO NOT overre. Overring will void
your warranty.
— Comply with all minimum clearances to
combustibles as specied. Failure to
comply may cause house re.
WARNING
FIRE RISK! For use with solid wood fuel
only. Other fuels may overre and generate
poisonous gases (i.e. carbon monoxide).
DO NOTNEVERtouch glass until it is cooled. allow
children to touch glass. Keep children away.CAREFULLY
SUPERVISE children in same room as fireplace. Alert
children and adultstohazards of high temperatures.
High temperatures may igniteclothing or other
flammable materials.Keep clothing, furniture, draperies
and other flammable materials away.
DANGER
CAUSE BURNS.
AND COOL DOWN.
HOT GLASS WILL
HOT SURFACES! GLASS
AND OTHER SURFACES ARE
HOT DURING OPERATION
WOOD BURNING
FIREPLACE MODELS:
WB54FB0F
WARNING
DO NOT alter or modify the replace or
its components under any circumstances.
Any modication or alteration of the
replace system, including but not limited
to the replace, chimney components
and accessories, may void the warranty,
listings and approvals of this system and
could result in an unsafe and potentially
dangerous installation.

Page 2 44726-1-0623
TABLE OF CONTENTS
SECTION PAGE
Safety Denitions and Information .........................................................................................................................4
Certication and Important Safety Information
Fireplace Certication ...............................................................................................................................................5
Non-Combustible Materials ......................................................................................................................................5
Combustible Materials ..............................................................................................................................................5
Attention Installer
Fireplace Installation Checklist .................................................................................................................................6
Get Started
Typical Fireplace System ..........................................................................................................................................7
Installation Considerations .......................................................................................................................................8
a. Selecting Fireplace Locations ...........................................................................................................................8
b. Locating Fireplace and Chimney .......................................................................................................................9
Tools and Supplies Needed ....................................................................................................................................10
Inspect Fireplace and Components ........................................................................................................................10
Fireplace System Requirements ............................................................................................................................10
Dimensional Information / Framing and Clearances
Fireplace Dimensions .............................................................................................................................................11
Clearances .............................................................................................................................................................12
Minimum Clearances to Combustibles ...................................................................................................................12
Clearances to Combustible Materials .....................................................................................................................13
Chase Construction ................................................................................................................................................14
Frame the Fireplace ...............................................................................................................................................15
Secure and Level the Fireplace ..............................................................................................................................15
Protective Metal Hearth Strips ................................................................................................................................16
Outside Air Kit .........................................................................................................................................................17
Chimney and Termination Requirements
Chimney Requirements ..........................................................................................................................................18
O󰀨sets/Returns .......................................................................................................................................................19
Termination Requirements ......................................................................................................................................20
Chimney Components Installation
Typical Chimney System ........................................................................................................................................21
Assemble Chimney Sections ..................................................................................................................................22
Secure O󰀨set/Return ..............................................................................................................................................23
Install Ceiling Firestops ..........................................................................................................................................23
Install Attic Insulation Shield ...................................................................................................................................24
Double Check the Chimney Assembly ...................................................................................................................24
Roof Penetration ....................................................................................................................................................25
Install Flashing ........................................................................................................................................................25
Install Chase/Chase Top .........................................................................................................................................25
Termination Cap Requirements ..............................................................................................................................26
Install Termination Cap ...........................................................................................................................................26

44726-1-0623 Page 3
TABLE OF CONTENTS
Shrouds
Shroud Requirements .............................................................................................................................................27
Field Constructed Shrouds ....................................................................................................................................27
a. Mailbox Style Shroud ......................................................................................................................................28
b. House Style Shroud .......................................................................................................................................28
c. Pyramid Style Shroud .....................................................................................................................................29
Finishing
Finishing Materials ..................................................................................................................................................30
Hearth Extension, Construction ..............................................................................................................................30
a. Fireplace Installed Flush on the Floor, or Hearth Extension Raised to Bottom of Firebox Opening ...............31
b. Raised Hearth Extension and Raised Fireplace .............................................................................................32
c. Fireplace Opening and Hearth Extension Flush with the Floor ......................................................................32
Non-Combustible Sealant Material .........................................................................................................................33
Mantel and Wall Projections ...................................................................................................................................34
Sidewalls/Surrounds ...............................................................................................................................................35
Fireplace Setup
Install Refractory Brick Liners ........................................................................................................................... 36-37
Gas Log/Lighter Provision ......................................................................................................................................38
Unvented Gas Logs ................................................................................................................................................38
Wood Burning Inserts .............................................................................................................................................38
Troubleshooting ................................................................................................................................................ 40-41
WB54FB0F Wood Burning Fireplace
Exploded View ........................................................................................................................................................42
Parts List .................................................................................................................................................................43
Service Technician Notes ................................................................................................................................. 44-45
Master Parts Distributor List ..................................................................................................................................46
How To Order Repair Parts ....................................................................................................................................46
Warranty ...................................................................................................................................................................47
SECTION PAGE

Page 4 44726-1-0623
CAUTION, WARNINGS AND DEFINITIONS
SAMPLE - CAUTION, WARNINGS AND DEFINITIONS:
CAUTION
FOR YOUR SAFETY:
• DO NOT store or use gasoline or any other ammable vapors
or liquids in the vicinity of this or any other appliance.
• Due to high temperatures, the appliance should be located
out of tra󰀩c and away from furniture and draperies.
• DO NOT place clothing or other ammable materials on
or near the appliance.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Refer
to this manual for correct installation and operational
procedures. For assistance or additional information
consult a qualied installer, service agency.
WARNING
Always leave glass doors fully opened or fully closed when
operating replace.
INSTALLATION INFORMATION
Before beginning the replace installation, read the instructions
completely.
• This replace and its components are safe when installed
according to this installation manual. Unless you use Empire
components, that are designed and tested for the replace
system, you may cause a re hazard.
• The warranty will be voided by Empire, and Empire disclaims
any re sponsibility for the following actions.
a. Modication of the replace, components, doors, air inlet
system and damper control.
b. Use of any component part not manufactured or approved
by Empire in combination with an Empire replace system.
Proper installation is crucial for safe and continuous replace
operation. Consult local building codes for the requirements of all
factory built replaces.
DISPOSAL OF ASHES
Place ashes in a metal container with a tight-tting lid. Place
the closed container of ashes on a noncombustible oor or on
the ground, away from all combustible materials, pending nal
disposal. If the ashes are buried in soil or otherwise locally
dispersed, they should be retained in the closed container until
all cinders have cooled.
When using the decorative appliance, the replace damper must
be set in the fully open position.
Do not use gasoline, gasoline-type lantern fuel, kerosene, charcoal
lighter uid, or similar liquids to freshen or start a re in the replace.
Keep these liquids away from the replace when it is in use.
WARNING
Use solid wood or processed solid fuel relogs only.
When processed wood fuel re logs are used, do not poke
or stir the logs while they are burning. Use only re logs
that have been evaluated for the application in replace
and refer to re log warnings and caution markings on
packaging prior to use.
WARNING
BURNING IMPROPER FUEL (I.E. CHARCOAL) CAN RESULT
IN CARBON MONOXIDE POISONING, WHICH MAY LEAD TO
DEATH!
Carbon Monoxide Poisoning – Early signs of carbon monoxide
poisoning resemble the u with headaches, dizziness, or
nausea. If you have these signs, get fresh air at once! Have
the appliance inspected by a qualied service technician.
Some people are more a󰀨ected by carbon monoxide than
others. These include pregnant women, people with heart or
lung disease or anemia, those under the inuence of alcohol,
and those at high altitudes.
VENTILATION REQUIREMENTS
Provide adequate air for combustion. The fresh air requirements
of this appliance must be met within the space where it will be
installed.
CREOSOTE – FORMATION
When wood is burned slowly, it produces tar and other organic
vapors that combine with expelled moisture to form creosote.
The creosote vapors condense in the cool chimney ue of a slow-
burning re. As a result, creosote residue accumulates on the ue
lining. When ignited this creosote makes an extremely hot re.
WARNING
Children and adults should be alerted to the hazards of
high surface temperatures and to stay away to avoid burns
or clothing ignition. Young children should be carefully
supervised when in the same room as replace.
When using SOLID WOOD only for fuel, use dry well seasoned
hardwood. Softwoods burn quickly. Do not use treated wood,
charcoal, coal, trash, driftwood or woods dipped in tar, pitch, pine
tar, or creosote. Wood products made with synthetic binders, such
as plywood, produce abnormally high temperatures and smoking
res. When burning articial logs follow the manufacturer's
instructions.

44726-1-0623 Page 5
CERTIFICATION AND IMPORTANT SAFETY INFORMATION
FIREPLACE CERTIFICATION
This replace system has been tested and listed in accordance with
UL 127 standards by Underwriters Laboratories Inc. for installation
and operation in the United States.
The decorative gas appliance shall be installed in accordance with
the National Fuel Code, ANSI Z223.1.
CAUTION
When using the decorative appliance, the replace damper
must be set in the fully open position.
This replace has been tested and listed for use with the optional
components specied in this manual. These optional components
may be purchased separately and installed at a later date. An outside
air kit, gas insert, gas log set or gas log-lighter should be installed
at the time of replace installation.
This replace may be installed in sleeping rooms. This replace is
not approved for manufactured housing. If installed with a gas log
set, provisions for the National Fuel Gas Code must be met.
WARNING
RISK OF FIRE! Empire Comfort Systems disclaims any
responsibility for, and the warranty and agency listing will
be voided by the following actions.
DO NOT:
• Install or operate
damaged replace
• Modify replace
• Install other than as
instructed by Empire
Comfort Systems
• Overre
• Operate the replace
without fully assembling
all components
• Install any component
not listed or approved
by Empire Comfort
Systems
I mproper installation, adjustment, alteration, service or maintenance
can cause injury or property damage. For more information, consult
a qualied installer, service agency or your dealer.
WARNING
This product and the fuels used to operate this product
(processed solid fuel relogs), and the products of combustion
of such fuels, can expose you to chemicals including carbon
black, which is known to the State of California to cause cancer
and carbon monoxide, which is known to the State of California
to cause birth defects or other reproductive harm. For more
information go to: www.P65Warnings.ca.gov.
WARNING
DO NOT install a replace insert in this box unless the
manufacturer's instructions with the insert specically
state this replace has been tested for use with this insert.
WARNING
When processed solid fuel relogs are used: Do not poke
or stir the logs while they are burning. Use only relogs
that have been evaluated for the application in replace
and refer to relog warnings and caution markings on
packaging prior to use.
ATTENTION
This installation manual will enable you to obtain a safe, e󰀩cient
and dependable installation of your replace system. Please
read and understand these instructions before beginning your
installation.
ATTENTION
This replace is not intended to be used as a substitute for a
furnace to heat an entire home. Use for supplemental heat only.
ATTENTION
The chimney shall be inspected at least twice a year during
the heating season to determine when a creosote buildup
has occurred.
NON-COMBUSTIBLE MATERIALS
• Materials which will not ignite and burn, composed of any
combination of the following:
– Steel – Concrete – Iron – Slate
– Brick – Glass – Tile – Plasters
• Materials reported as passing ASTM E 136, Standard Test
Method for Behavior

Page 6 44726-1-0623
ATTENTION INSTALLER
Fireplace Installation Checklist
Use this checklist along with the instructions in this manual.
Customer: _____________________________________
Address:_______________________________________
_______________________________________________
Model: ________________________________________
Date Installed: __________________________________
Fireplace Location: ______________________________
Installer: _______________________________________
Dealer Phone #: _________________________________
Serial # ________________________________________
FIREPLACE INSTALLATION COMMENTS
Veried that the chase is insulated and/or sealed. (pgs. 14 and 25) ................................... o____________________
Protective hearth strips installed per manual........................................................................ o____________________
Fireplace is leveled and secured. (pg.15) ............................................................................ o____________________
Hearth extension installed per the manual ........................................................................... o____________________
Outside air kit installed ......................................................................................................... o____________________
CHIMNEY SECTION
Chimney and Firestops installed, locked and secured in place with proper clearances ...... o____________________
Chimney conguration complies with diagrams. (pgs. 18-19) .............................................. o____________________
Attic insulation shield installed. ............................................................................................ o____________________
Exterior roof ashing installed and sealed. .......................................................................... o____________________
Termination installed and sealed (pg. 21) ............................................................................. o____________________
SHROUDS (pgs. 27-29)
Shroud installed properly per instructions. ........................................................................... o____________________
FINISHING (pgs. 30-35)
Veried all clearances meet installation manual requirements. ............................................ o____________________
Combustible materials not installed in non-combustible areas............................................. o____________________
Mantels and wall projections comply with installation manual clearances. ......................... o____________________
FIREPLACE SETUP
Brick panels installed correctly. ............................................................................................ o____________________
Grate properly installed with grate retainer brackets. ........................................................... o____________________
Optional doors properly installed .......................................................................................... o____________________
Firescreen installed .............................................................................................................. o____________________
Manual bag and all of its contents are removed from the replace and given to
the Homeowner .................................................................................................................... o
____________________
Empire recommends the following:
• Keep this checklist visible on the replace until the installation is complete.
• Photograph the installation and copy this completed checklist for your le.

44726-1-0623 Page 7
OUTSIDE
COMBUSTION
AIR
COMBUSTIBLE
FRAMING/HEADER
ON TOP OF FRONT
STAND-OFF SUPPORTS
TERMINATION CAP
STORM COLLAR
CHIMNEY PENETRATES ROOF
PREFERABLY WITHOUT AFFECTING
ROOF RAFTERS
OFFSET & RETURN
(WITH HANGER STRAPS)
ATTIC INSULATION SHIELD REQUIRED
HERE TO KEEP INSULATION FROM
CHIMNEY IF ATTIC IS INSULATED
SUPPORT STRAPS FOR
RAFTER SUPPORT OF CHIMNEY
CEILING FIRE STOP
ON FLOOR OF ATTIC
CHIMNEY FRAMING HEADED OFF
IN CEILING JOISTS
ENCLOSED SPACE ABOVE AND
AROUND FIREPLACE
MANTEL AND
SURROUND
DECORATIVE FACING
AND TRIM
FACTORY-BUILT
FIREPLACE
HEARTH
EXTENSION
PROTECTIVE METAL
HEARTH STRIP(S)
GET STARTED
TYPICAL FIREPLACE SYSTEM
Figure 1
FLASHING OR
CHASE COVER
ADDITIONAL LATERAL
SUPPORT MAY BE NEEDED
FOR CHIMNEY ABOVE ROOF
(OR ENCLOSED IN CHASE)
NON-COMBUSTIBLE ROOF
FLASHING MUST MAINTAIN
MINIMUM CLEARANCES
AROUND CHIMNEY SYSTEM

Page 8 44726-1-0623
GET STARTED (CONT'D)
INSTALLATION CONSIDERATIONS
NOTICE: Check building codes prior to installation.
• Installation MUST comply with local, regional, state and national
codes and regulations.
• Consult insurance carrier, local building inspector, re o󰀩cials
or authorities having jurisdiction over restrictions, installation
inspection and permits.
Before Installing, Find The Following:
• Installation location.
• Vent system conguration.
• Gas supply piping.
• Electrical wiring.
• Framing and nishing details.
SELECTING FIREPLACE LOCATIONS
This replace can be used as a room divider or installed along a
wall, across a corner or in an exterior chase. See Figure 2.
Avoid locating this replace in a basement. Locating it near
frequently opened doors, central heat outlets or returns, or other
locations of air movement can a󰀨ect the performance.
NOTICE: In addition to these framing dimensions, also
reference the following section:
• Clearances. See page 12.
NOTICE: Illustrations and photos of typical installations are For
Design Purposes Only. Illustrations/diagrams are not drawn to
scale. Actual installation/appearance will vary with individual
design preferences.
NOTICE: Maintain a minimum 1-1/2 in. (38 mm) air clearance at
the back and a minimum 1-1/2 in. (38 mm) air clearance to the sides
of the replace assembly.
Chimney sections at any level require a 2 in. (51 mm) minimum
air space clearance between the framing and chimney
sections.
NOTE: 1-1/2 i n.
(38 mm) MIN.
DISTANCE
FROM SIDES
AND BACK OF
FIREPLACE TO
COMBUSTIBLE
MATERIALS. 1/2
in. (13 mm) MIN.
AT NAILING
FLANGES.
*8 in. (203 mm)
EXTRA SPACE
INCLUDED
(LEFT SIDE)
FOR OUTSIDE
AIR CONNECTION.
IF OUTSIDE
AIR DUCT HAS
NO BEND, THIS
DIMENSION MAY
BE REDUCED
AS LONG AS
MINIMUM
CLEARANCES
ARE MET.
Fireplace Locations
Figure 2
FLUSH WALL
INSTALLATION
CABINET
INSTALLATION
ROOM DIVIDER
INSTALLATION
ANGLED CORNER
INSTALLATION

44726-1-0623 Page 9
GET STARTED (CONT'D)
LOCATING FIREPLACE AND CHIMNEY
Location of the Fireplace and Chimney Will A󰀨ect Performance.
• Install in the warm airspace enclosed by the building envelope
to produce more draft, especially during lighting and die-down.
• Penetrate the highest part of the roof to minimize wind loading
e󰀨ects.
• Locate termination cap away from trees, adjacent structures,
uneven roof lines and other obstructions.
• Minimize the use of chimney o󰀨sets.
• Consider the replace location compared to oor, ceiling, and
attic joists.
• Consider the termination requirements. See page 20.
• Install the outside air kit with the intake facing prevailing winds
during the heating season.
• Ensure adequate outdoor air for all combustion appliances and
exhaust equipment.
• Ensure furnace and air conditioning return vents are not located
in the immediate vicinity of the replace.
• Avoid installing the replace near doors, walkways or small
isolated spaces.
• Recessed lighting should be a “sealed can” design.
• Attic hatches should be weather stripped or sealed.
• Ensure all attic-mounted duct work and air handler joints and
seams are taped or sealed.
MULTI-LEVEL ROOFS
WINDWARD
LOCATION NOT
RECOMMENDED:
•TO CLOSE TO THE TREE
•BELOW ADJACENT
STRUCTURE
LOWER ROOF LINE
•AVOID OUTSIDE WALL
MARGINAL LOCATION:
• WIND LOADING POSSIBLE
RECOMMENDED LOCATION:
• ABOVE PEAK
• INSIDE HEATED SPACE RECOMMENDED LOCATION:
• ABOVE PEAK
LOCATION NOT
RECOMMENDED:
• NOT THE HIGHEST
POINT OF
THE ROOFING
• WIND LOADING
POSSIBLE
RECOMMENDED:
• INSULATED EXTERIOR
CHASE IN COOLER CLIMATE
Recommended Chimney Locations
Figure 3

Page 10 44726-1-0623
GET STARTED (CONT'D)
TOOLS AND SUPPLIES NEEDED
Ensure the following tools and supplies are available:
• Gloves
• Safety glasses
• Reciprocating saw
• Pliers
• Hammer
• Phillips screwdriver
• Flat blade screwdriver
• Plumb line
• Level
• 5/16 in. (8 mm) nut driver
• Framing material
• Non-combustible sealant
• Framing square
• Electric drill and bits
• Tape measure
• 1/2-3/4 in. (13 mm-19 mm)
length, #6 or #8 self-drilling
screws, misc. screws and nails
INSPECT FIREPLACE AND COMPONENTS
Steps For Inspection:
WARNING
RISK OF FIRE AND/OR EXPLOSION! Damaged parts could
impair safe operation. DO NOT install damaged, incomplete
or substitute components. Keep replace dry.
• Unpack replace and components and inspect for damage.
• Inspect vent system components and doors shipped in separate
packages.
• Report any parts damaged in shipment to your dealer.
• Read all instructions before starting the installation. Follow
instructions during installation to ensure maximum safety and
performance.
HARDWARE PACK:
• SS self-drilling #10 x
1/2 in. screws (6)
• #10 x 1/2 in. sheet metal
screws (20)
• Framing brackets (4)
• Concrete liner brackets (3)
• Grate retainer brackets (2)
FIREPLACE SYSTEM REQUIREMENTS
Fireplace system requirements include:
• Fireplace
– Refractory brick liners
– Firescreen (included
with replace)
– Grate (included with
replace)
– Hearth extension
(required, and sold
separately)
• Outside Air System
– 4 in. (102 mm) Dia.
ex (optional, and
sold separately)
– WBOAK (optional, and
sold separately)
• Chimney System
– Attic insulation shield
(included with replace)
– Chimney termination
cap (required, and sold
separately)
– Chimney venting sections
and restops (sold
separately)
• Non-Combustible Finish
Material
– (Required, and sold
separately)

44726-1-0623 Page 11
FRAMING AND CLEARANCES
FIREPLACE DIMENSIONS
Figure 4
DIMENSION MEASUREMENTS
Index Description in. mm Index Description in. mm
A Face Height 4913 /
16 1265 JRear Wall To Center Of Vent 13 7
/
8352
B Face Width 667 /
81699 K Floor To Gas Line Opening 11 5
/
8295
C Fireplace Depth 31 787 L Face To Gas Line Opening 13 1 /
2343
D Firebox Opening Height 34 864 M Rear Wall To Gas Line Opening 171 /
2445
E Firebox Opening Width 54 1372 PFace To Center Of Vent 17 1 /
8435
FFirebox Depth 25 635 QFloor To Firebox Opening 93 /
16 233
H Height To Top Stand-Offs 801 /
42038 R Height To Adapter Collar 78 7
/
16 1992
I Face Side To Center Of Vent 337 /
16 849 S Height To Framing Header 741
/
81883

Page 12 44726-1-0623
FRAMING AND CLEARANCES (CONT'D)
CLEARANCES
WARNING
RISK OF FIRE!
Comply with all minimum air space clearances to combustibles
as specied in table on right and shown in Figures 5 and 6. DO
NOT pack required air spaces with insulation or other materials.
Framing or nishing material used on the front of, or in front of,
the replace closer than the minimums listed must be constructed
entirely of non-combustible materials (e.g., steel studs, concrete
board). Non-compliance can cause re.
MINIMUM CLEARANCES TO COMBUSTIBLES
Within Enclosure Area
Fireplace to back wall 1-1/2 in. (38 mm)
Fireplace to sidewall 1-1/2 in. (38 mm)
Header brackets to header 0 in. (0 mm)
Opening to sidewall 24 in. (610 mm)
Mantel
Mantel minimum height 18 in. (457 mm) above opening
Maximum mantel depth 10 in. (254 mm)
Clearances To Combustible Materials
Figure 5
ATTIC
INSULATION
SHIELD
CEILING
FIRESTOP
(CEILING)
0 in
FROM
FLOOR
(ATTIC)
STORM
COLLAR
ROOF
FLASHING
(CEILING)
OFFSET/RETURN
WITH HANGER STRAPS
CEILING
FIRESTOP
2 in. MIN.
(51 mm)
2 in. MIN.
(51 mm)
2 in. MIN.
(51 mm)
2 in. MIN.
(51 mm)
2 in. MIN.
(51 mm)
2 in. MIN.
(51 mm)
0” CLEARANCE TO
BACK AND SIDE
STANDOFFS
6 in.
(152 mm)
NON-COMBUSTIBLE ZONE
BELOW THIS LINE
ROOF
OPENING

44726-1-0623 Page 13
6 in.
6 in.
EXCEPT FOR FRAMING MEMBERS SHOWN,
NO COMBUSTIBLE MATERIALS BELOW THIS LINE INSIDE CHASE
EXCEPT FOR FRAMING
MEMBERS SHOWN,
NO COMBUSTIBLE
MATERIALS BELOW
THIS LINE INSIDE CHASE
Clearances To Combustible Materials
Figure 6
FRAMING AND CLEARANCES (CONT'D)

Page 14 44726-1-0623
FRAMING AND CLEARANCES (CONT'D)
CHASE CONSTRUCTION
A chase is a vertical boxlike structure built to enclose the replace
and/or its vent system. Vertical chimneys that run on the outside of
a building must be installed inside a chase.
In cold climates, Empire Comfort Systems recommends that the
chase is insulated using batt-type insulation between the joists.
Chase construction will vary by building type. These instructions
are not substitutes for local building codes.
Chases should be constructed similarly to outside walls of the home
to prevent air drafting issues. The chase should not break the outside
building envelope. All outer walls must be insulated.
Insulate walls, ceiling, base plate, and cantilever oor at the rst level
of the chase. See Figures 7 and 8. Install vapor and air inltration
barriers in the chase following regional codes for the rest of the home.
Empire Comfort Systems recommends that the inside surfaces are
drywalled and taped (or the equivalent method) for air tightness.
Caulk holes and other openings with high temperature caulk, or ll
with unfaced ber glass insulation.
WARNING
You must install false ceilings and ceiling restops at each oor
of the chase or every 10 ft. (3.05 m) to control spread of re.
WARNING
RISK OF FIRE! DO NOT seal area between re stop opening
and chimney pipe except where they enter the attic or leave
the warm air envelope of the home (use 600° F sealant).
• Construct the chase using framing materials like the walls in
the home, various siding materials can be used including brick,
stone, veneer, or standard siding materials.
• In chase construction, several factors must be considered:
– Maintain a 2 in. (51 mm) air space around the chimney.
– Construct the chase top of non-combustible material.
– In cold climates, install a restop spacer and attic
insulation shield in an insulated false ceiling at the 8 ft.
(2438 mm) level above the replace assembly, reducing
heat loss through the chase.
WARNING
RISK OF FIRE! You must maintain a minimum 2 in. (51
mm) air space clearance to insulation and other materials
surrounding the chimney system.
• Firmly secure insulation and other materials to prevent accidental
contact with chimney system.
• Properly block the chase to prevent blown insulation or other
combustibles from entering and making contact with replace
or chimney.
• Failure to prevent contact between insulation or other materials
and chimney system may cause overheating and re.
ROUND TERMINATION CAP
STORMCOLLAR
METAL CHASE TOP
CEILING
FIRESTOP
FALSE CEILING
ATTIC
INSULATION
SHIELD TAB
CEILING
FIRESTOP
CHIMNEY
CEILING
CEILING
INSULATION IN
THE OUTSIDE
WALLS OF THE
CHASE
Chase Assembly - Figure 7
WARNING
RISK OF FIRE! You must maintain a minimum 2 in. (51 mm) air
space clearance to insulation and other materials surrounding
the chimney system.
Figure 8 below shows three examples of chase construction
applications:
1. Fireplace and chimney enclosed in an exterior chase.
2. Chimney o󰀨set through exterior wall and enclosed in chase.
3. Chase constructed on roof.
INSULATE ALL OUTSIDE WALLS.
INSULATE ALLOUTSIDE WALLS
123 4
Chase Constructions - Figure 8

44726-1-0623 Page 15
FRAMING AND CLEARANCES (CONT'D)
NOTE: Before framing the chase, identify any obstacles in the way.
It may be necessary to make the chase larger for o󰀨sets. Refer to
o󰀨set chart on page 19.
CAUTION
Risk of Cuts/Abrasions. Wear protective gloves and safety
glasses during installation. Sheet metal edges are sharp.
SECURE AND LEVEL THE FIREPLACE
This replace can be placed on either a combustible or non-
combustible continuous at surface. Follow the instructions for
framing on pages 11-17. Slide the replace into position. Ensure
you provide the minimum 1-1/2 in. (38 mm) air clearance at the
sides and 1-1/2 in. (38 mm) at the back of the replace.
Position the replace so the face of the non-combustible material on
the replace will be ush with the face of the drywall on the walls.
Level the replace and shim as needed.
WARNING
RISK OF FIRE! Prevent contact with sagging, loose insulation.
• DO NOT install against vapor barriers or exposed insulation.
• Secure insulation and vapor barriers.
• Provide minimum air space clearances at the sides and
back of the replace assembly.
FRAME THE FIREPLACE
NOTE: Determine Hearth extension design before installation.
If the replace is placed on the oor the maximum height of a nished
raised hearth is 9-3/16 in. (233 mm). For a higher raised hearth the
replace must be placed on a platform.
WARNING
RISK OF FIRE! Comply with all minimum clearances specied.
• Maintain a minimum 1-1/2 in. (38 mm) air clearance at the back
and 1-1/2 in. (38 mm) to the sides of the replace assembly.
• Chimney sections at any level require a 2 in. (51 mm) minimum
air space clearance between the framing and chimney section.
WARNING
RISK OF FIRE! You must comply with all minimum air
space clearances to combustibles. DO NOT pack required
air spaces with insulation or other materials.
Figure 9 shows a typical framing (using 2 x 4 lumber), assuming
combustible materials are used. Adhere to all required clearances
to combustibles around the replace. See Figures 6 and 9.
The nished cavity depth must be no less than 31 in. (787 mm) from
the nished back wall to the front wall framing surface.
DO NOT install header until the replace is in position.
7+()5$0,1*0$7(5,$/
1/2 in.
(13 mm)
FIREPLACE MUST BE
SET OUT 1/2 in. (13 mm)
IN FRONT OF THE FACE
OF THE FRAMING MATERIAL.
8 in. (203 mm) EXTRA SPACE NEEDED
(LEFT SIDE) FOR OUTSIDE AIR
CONNECTION. IF OUTSIDE AIR DUCT
HAS NO BEND, THIS DIMENSION MAY
BE REDUCED AS LONG AS MINIMUM
CLEARANCES ARE MET.
8 in. 30-1/2 in.*
(775 mm)
67-5/8 in.
(1718 mm)
HEADER WILL
SIT ON TOPOF
FRONT STAND
-OFFS AFTER
FIREPLACE IS
INSTALLED.
USE ONLY
NON-COMBUSTIBLE
MATERIAL BELOW
THE TOPOF THE
FRONT STANDOFFS.
21 in. (533 mm)
FRAMING
* IF INTERIOR OF
CHASE WILL BE
DRYWALLED, ADD
THE THICKNESS
TO THIS
MEASUREMENT.
MIN. (1883 mm)
74-1/8 in.
* IF INTERIOR OF
CHASE WILL BE
DRYWALLED , ADD
THE THICKNESS
TO THIS
MEASUREMENT .
7+()5$0,1*0$7(5,$/
1/2 in.
(13 mm)
FIREPLACE MUST BE
SET OUT 1/2 in. (13 mm)
IN FRONT OF THE FACE
OF THE FRAMING MATERIAL.
8 in. (203 mm) EXTRA SPACE NEEDED
(LEFT SIDE) FOR OUTSIDE AIR
CONNECTION. IF OUTSIDE AIR DUCT
HAS NO BEND, THIS DIMENSION MAY
BE REDUCED AS LONG AS MINIMUM
CLEARANCES ARE MET.
8 in. 30-1/2 in.*
(775 mm)
67-5/8 in.
(1718 mm)
HEADER WILL
SIT ON TOPOF
FRONT STAND
-OFFS AFTER
FIREPLACE IS
INSTALLED.
USE ONLY
NON-COMBUSTIBLE
MATERIAL BELOW
THE TOPOF THE
FRONT STANDOFFS.
21 in. (533 mm)
FRAMING
* IF INTERIOR OF
CHASE WILL BE
DRYWALLED, ADD
THE THICKNESS
TO THIS
MEASUREMENT.
MIN. (1883 mm)
74-1/8 in.
8 in. (203 mm) EXTRA SPACE
NEEDED (LEFT SIDE) FOR OUTSIDE
AIR CONNECTION. IF OUTSIDE AIR
DUCT HAS NO BEND, THIS DIMENSION
MAY BE REDUCED AS LONG AS
MINIMUM CLEARANCES ARE MET.
Framing The Fireplace
Figure 9
30 -1/2 in.*
(775 mm)
1/2 in.
(13 mm)
FIREPLACE MUST BE
SET OUT 1/2 in. (13 mm)
IN FRONT OF THE FACE
OF THE FRAMING MATERIAL.
HEADER WILL
SIT ON TOP OF
FRONT STAND-OFFS
AFTER FIREPLACE
IS INSTALLED.
USE ONLY
NON-COMBUSTIBLE
MATERIAL BELOW
THE TOP OF THE
FRONT STANDOFFS.

Page 16 44726-1-0623
FRAMING AND CLEARANCES (CONT'D)
PROTECTIVE METAL HEARTH STRIPS
WARNING
RISK OF FIRE! Protective metal hearth strips MUST be
installed on combustible surfaces. DO NOT cover metal
strips with combustible materials.
WARNING
RISK OF FIRE! High temperatures, sparks, embers or other
burning material falling from the replace may ignite ooring
or concealed combustible surfaces.
Sparks or embers may ignite ooring.
• Protective metal hearth strips MUST be installed.
• Locate the two protective metal hearth strips measuring
approximately 38 in. x 4 in. (965 mm x 102 mm) included.
• Slide each metal strip 2 in. (51 mm) under front edge of replace.
• Overlap strips in the middle of replace opening by 1 in. (25
mm) minimum.
• Metal strips must extend beyond the front and sides of the
replace opening by at least 2 in. (51 mm). See Figure 10.
• Protect the front of a platform elevated above the hearth
extension with metal strips. See Figure 11. See pages 31
through 33 for hearth extension instructions.
• Install hearth extensions as specied.
1” (25mm)
OVERLAP
PROTECTIVE METAL STRIPS ARE PLACED 2” (51mm)
UNDER THE FRONT OF THE FIREPLACE AND MUST
EXTEND BEYOND THE FRONT AND SIDES OF
FIREPLACE OPENING BY 2” (51mm)
PROTECTIVE METAL STRIPS ARE PLACED 2 in. (51 mm)
UNDER THE FRONT OF THE FIREPLACE AND MUST EXTEND
BEYOND THE FRONT AND SIDES OF FIREPLACE OPENING
BY 2 in. (51 mm).
Position The Protective Metal Hearth Strips
Figure 10
TOP STRIP MUST OVERLAP
BOTTOM STRIP
1 in. (25mm)
MINIMUM
OVERLAP
FLOOR
RAISED HEARTH PLATFORM
2 in.
(51mm)
PROTECT THE FRONT OF A RAISED PLATFORM
2 in.
(51mm)
Protect The Front Of A Raised Platform
Figure 11
1 in. (25 mm)
OVERLAP

44726-1-0623 Page 17
FRAMING AND CLEARANCES (CONT'D)
OUTSIDE AIR KIT
Use one outside air kit (WBOAK, not supplied) for combustion.
Empire Comfort Systems recommends using the shortest duct runs
to optimize performance of the outside air kits and install a P-trap.
See Figure 14. Position the outside air inlet hoods so they will not
allow snow or leaves to block the inlets.
In some installations the air duct may need to run vertically. In
vertical installations, a 3 ft. (914 mm) height di󰀨erence must be
maintained from the top of the uppermost chimney section to the
outside air inlet hoods.
The 4 in. (102 mm) diameter outside air ex duct used must
meet the UL 181-UL Standard for Safety Factory-Made Air Ducts
and Air Connectors.
NOTE: The maximum length of a 4 in. (102 mm) diameter duct
is 20 ft. (6.1 m). The duct can be extended up to a maximum of
40 ft. (12.2 m) by using 6 in. (152 mm) duct. A 4 in. (102 mm) to
6 in. (152 mm) adapter will be needed. (not included).
Figures 12 and 13 show placing of the outside air inlet hoods.
The outside air duct is attached to the left side of the replace.
1. Cut 4-1/2 in. (114 mm) holes in outside wall to accommodate
the outside air ex vent.
2. Use 4 in. (102 mm) ex (not included) to directly connect
outside air to replace intake. Insulate the pipe to prevent
frost condensation.
3. Use the supplied outside air inlet hoods included with outside
air kit (WBOAK).
4. Seal between the wall and the pipe with (not included) silicone
to prevent moisture penetration and air leaks.
5. Seal between the outside air inlet hoods and the house with
silicone to prevent air inltration.
CAUTION
RISK OF FIRE OR ASPHYXIATION! DO NOT draw outside
combustion air from wall, oor or ceiling cavity, or enclosed
spaces such as an attic or garage.
6. DO NOT place outside air inlet hood close to exhaust vents or
chimneys. Fumes or odor can be drawn into the room through
the replace.
7. Locate outside air inlet hood to prevent blockage from leaves,
snow/ice, or other debris. Blockages can cause combustion air
starvation.
NO
YES
NO
NO
NO
CLEAR AREA
OUTSIDE
HOUSE OR IN
VENTILATED
CRAWL SPACE
OUTLET BLOCKED BY
SNOW, LEAVES, ETC
GARAGE OR
COMBUSTIBLE
LIQUID STORAGE
ATTIC SPACE
OUTLET PLACED
HIGHER THAN
3 FEET BELOW
THE TERMINATION
CAP
FACTORY-BUILT
FIREPLACE
● USE UL 1081 CLASS 1 OR CLASS 0 RIGID OR FLEXIBLE TUBING
● INSTALL WITH SHORT RUN AND ADD A P-TRAP WHICH WILL
HELP PREVENT FLOW OF COLD AIR
● SECURE FLEX DUCT WITH SCREWS OR BAND CLAMPS
•
USE UL 1061 CLASS 1 OR CLASS 0 RIGID OR FLEXIBLE TUBING
•
INSTALL WITH SHORT RUN AND ADD AP-TRAP WHICH WILL
HELP PREVENT FLOW OR COLD AIR
• SECURE FLEX DUCT WITH SCREWS OR BAND CLAMPS
Outside Air Installation - Figure 12
MAXIMUM
HEIGHT
8 FEET
FROM
FLOOR
OUTSIDE
COMBUSTION
AIR
Outside Air Hood Locations - Figure 13
CAUTION
Risk of Cuts/Abrasions. Wear protective gloves and safety
glasses during installation. Sheet metal edges are sharp.
TYPICAL
OUTSIDE
AIR
INST
ALLATION
RECOMMEND
24 in. FOR
A
MINIMUM BEND
RECOMMEND
24 in. FOR A
MINIMUM BEND
TYPICAL
OUTSIDE AIR
INSTALLATION
Outside Air Installation With P-Trap - Figure 14

Page 18 44726-1-0623
CHIMNEY AND TERMINATION REQUIREMENTS
CHIMNEY REQUIREMENTS
Vertical distances are measured from the base of the replace as
shown in Figure 15.
CHIMNEY MEASUREMENT REQUIREMENTS
Minimum overall straight height 20 ft. 6.1 m
Minimum height with
single o󰀨set/return 20 ft. 6.1 m
Double o󰀨set/return
minimum height 22 ft. 6.7 m
Maximum height 90 ft. 27.4 m
Maximum chimney length
between an o󰀨set and return 20 ft. 6.1 m
Maximum distance between
chimney stabilizers 35 ft. 10.7 m
Maximum unsupported chimney
length between the o󰀨set and return 6 ft. 1.8 m
Maximum unsupported chimney
height above the replace 30 ft. 9.1 m
Maximum unsupported
chimney above roof
6 ft. 1.8 m
NOTICE: A maximum of two pairs of o󰀨sets and returns may be used.
78-3/8 in. 20 ft (6.10 m) min. height/single offset-return
25 ft (7.32 m) min. height/double offset-return
60 ft (18.29 m) max. height
(199 cm)
Chimney Requirements - Figure 15
WARNING
RISK OF FIRE! You must maintain 2 in. (51 mm) air space
clearance to insulation and other combustible materials
around the chimney system. Failure to do so may cause
overheating and re.
NOTICE: Provide support for the pipe during construction and
check to ensure inadvertent loading has not dislodged the chimney
section from the replace or at any chimney joint.
CHIMNEY COMPONENT DIMENSIONS
HEIGHT OF CHIMNEY COMPONENTS
OFFSETS/RETURNS
Model Height Measurement
WB14V15E 14-1/2 in. 368 mm
WB14V30E 16 in. 404 mm
CHIMNEY SECTIONS*
Model Height Measurement
WB14V06 6 in. 152 mm
WB14V12 12 in. 305 mm
WB14V18 18 in. 457 mm
WB14V36 36 in. 914 mm
WB14V48 48 in. 1219 mm
* Dimensions reect e󰀨ective height.
78-7/16 in. (2 m)
EFFECTIVE HEIGHT
(BOTTOM OF
FIREPLACE TO
TOP OF STARTER
COLLAR)
20 ft. (6.1 m) MIN. HEIGHT/SINGLE
OFFSET-RETURN 22 ft. (6.7 m) MIN.
HEIGHT/DOUBLE OFFSET-RETURN
90 ft. (27.4 m) MAX. HEIGHT
6 ft. (1.8 m) MAX.
UNSUPPORTED RUN
20 ft. (6.1 m) MAX.
PIPE BETWEEN AN
OFFSET & RETURN
CEILING
FIRESTOP
GAS
KNOCKOUT
6 ft. (1.8 m) MAX.
UNSUPPORTED
CHIMNEY ABOVE
ROOF
30 ft. (9.1 m)
MAX. STRAIGHT
UNSUPPORTED
CHIMNEY HEIGHT

44726-1-0623 Page 19
OFFSETS/RETURNS
• Use an o󰀨set/return to bypass overhead obstructions.
• An o󰀨set and return can be used as a single entity or separated
by chimney section(s).
WARNING
RISK OF FIRE! DO NOT use o󰀨set/returns greater than 30°.
Chimney draft will be restricted and could cause overheating
and re. Secure o󰀨sets with screws (not to exceed 1/2" /
13 mm in length) Secure returns with strapping. Straight
chimney sections may be secured with screws. Keep chimney
sections from separating or twisting.
• Measure the shift needed to avoid the overhead obstruction.
Refer to Dimension C in Figure 16.
• Find the appropriate Dimension C listed in below O󰀨set
Dimensions table. The Dimension B coinciding with the
Dimension A measurement in below O󰀨set Dimensions
table represents the required vertical clearance needed to
complete the o󰀨set/return.
• Read across the chart to nd the number of chimney sections/
model numbers needed between the o󰀨set and return.
EXAMPLE:
Using the 30 degree o󰀨set chart, Dimension C from Figure 16 is 25
in. (635 mm). Using below O󰀨set Dimensions table the dimension
closest to, but not less than 25 in. (635 mm) is 28-5/8 in. (727 mm)
using a 30° o󰀨set/return.
CHIMNEY AND TERMINATION REQUIREMENTS (CONT'D)
You determined from the table that you would need 62-1/8 in. (1578
mm) Dimension B between the o󰀨set and return. The chimney
component that best ts your application is one WB14V48.
1-1/4 in. (32 mm)
OVERLAP
C
A
B
Chimney O󰀨set/Return - Figure 16
Proper assembly of air cooled chimney parts results in an overlap of chimney joints of 1-1/4 in. (32 mm). E󰀨ective length is built into this table.
A
B
C1-1
/ 4 in. (32 mm)
OVERLAP
ELBOW OFFSET CHART
15° OFFSETS 30° OFFSETS
Elbow
Angle
Quantity
And
Length A
O󰀨set
Vertical B
O󰀨set
Horizontal C Elbow
Angle
Quantity
And
Length A
O󰀨set
Vertical B
O󰀨set
Horizontal C
in. mm in. mm in. mm in. mm
15° 0,0 231 /
8587 27
/
873 30° 0,0 22 559 51
/
2140
15° 1-6" 271 /
4692 4 102 30° 1-6" 253
/
4654 75
/
8194
15° 1-12" 33 838 51 /
2140 30° 1-12" 307
/
8784 105
/
8270
15° 1-18" 387 /
8987 7178 30° 1-18" 361
/
8918 135
/
8346
15° 1-18", 1-6" 43 1092 81 /
8206 30° 1-18", 1-6" 393
/
41010 153
/
4400
15° 1-18", 1-12" 483 /
41238 93
/
4248 30° 1-18", 1-12" 45 1143 183
/
4476
15° 1-36" 561 /
41429 113
/
4298 30° 1-36" 513
/
41314 225
/
8575
15° 1-36", 1-6" 603 /
81534 127
/
8327 30° 1-36", 1-6" 553
/
81407 243
/
4629
15° 1-48" 67 3 /
41721 147
/
8378 30° 1-48" 621
/
81578 285
/
8727
15° 1-48", 1-6" 717 /
81826 157
/
8403 30° 1-48", 1-6" 653
/
41670 303
/
4781
15° 1-48", 1-12" 773 /
41975 171
/
2445 30° 1-48", 1-12" 71 1803 333
/
4857
15° 1-48", 1-18" 831 /
22121 19 483 30° 1-48", 1-18" 761
/
81934 363
/
4933
15° 2-36" 891 /
42267 205
/
8524 30° 2-36" 813
/
82067 393
/
41010
15° 1-48", 1-18", 1-12" 933 /
82372 215
/
8549 30°
1-48", 1-18", 1-12" 85 2159 417 /
81064
15° 1-48", 1-36" 100
7
/
82562 233
/
4603 30° 1-48", 1-36" 913
/
42330 453
/
41162
15° 1-48", 1-36", 1-6" 105 2667 243 /
4629 30° 1-48", 1-36", 1-6" 953
/
82423 477
/
81216
15° 2-48" 112
1
/
22858 263
/
4679 30° 2-48"
102
1
/
82594 513
/
41314

Page 20 44726-1-0623
CHIMNEY AND TERMINATION REQUIREMENTS (CONT'D)
• The bottom of the termination cap must be at least 3 ft. (.91 m)
above the roof AND at least 2 ft. (.61 m) above any portion of
roof within 10 ft. (3.05 m).
• The distance required between caps is shown below.
TERMINATION REQUIREMENTS
• Install a cap approved and listed for this replace system.
• Locate cap where it will not become plugged by snow or other
materials.
• Locate cap away from trees or other structures.
Figure 17
MULTIPLE CHIMNEY LOCATIONS
CHIMNEY DISTANCES
A B
6 in.
(minimum)
up to 20 in.
(152 mm) /
(508 mm)
18 in.
minimum
(457 mm)
20 in.
and over
508 mm
0 in.
minimum
Figure 18
*IN A STAGGERED INSTALLATION WITH BOTH GAS AND WOOD
TERMINATIONS, THE WOOD TERMINATION CAP FLUE OUTLET MUST
BE HIGHER THAN THE GAS TERMINATION CAP FLUE OUTLET.
SLANTED ROOFS
FLAT ROOFS
CHIMNEY FLUE OUTLET
MUST EXTEND 3 ft. (.91 m)
ABOVE THE ROOF
CHIMNEY FLUE OUTLET MUST
EXTEND 2 ft. (.61 m) ABOVE ANY
PORTION OF THE ROOF OR
ADJACENT STRUCTURES WITHIN
10 ft. (3.05 m) OF THE CHIMNEY
SLANTED ROOFS
FLAT ROOFS
CHIMNEY MUST EXTEND 2 ft. (.61 m)
ABOVE ANY PORTION OF THE ROOF
OR ADJACENT STRUCTURES WITHIN
10 ft. (3.05 m) OF THE CHIMNEY
CHIMNEY MUST
EXTEND 3 ft. (.91 m)
ABOVE THE ROOF
CHIMNEY FLUE
OUTLET MUST
EXTEND 3 ft.
(.91 m) ABOVE
THE ROOF
CHIMNEY DISTANCES
6 in.
(minimum)
up to 20 in.
152 mm /
508 mm
20 in.
and over
508 mm
18 in.
minimum
457mm
0 in.
minimum
AB
GAS, WOOD
OR FUEL OIL
TERMINATION CAP
GAS
TERMINATION
CAP*
B
A
GAS, WOOD
OR FUEL OIL
TERMINATION CAP
GAS
TERMINATION
CAP*
A
B
CHIMNEY FLUE OUTLET
MUST EXTEND 3 ft. (.91 m)
ABOVE THE ROOF
CHIMNEY FLUE OUTLET MUST
EXTEND 2 ft. (.61 m) ABOVE ANY
PORTION OF THE ROOF OR
ADJACENT STRUCTURES WITHIN
10 ft. (3.05 m) OF THE CHIMNEY
SLANTED ROOFS
FLAT ROOFS
CHIMNEY MUST EXTEND 2 ft. (.61 m)
ABOVE ANY PORTION OF THE ROOF
OR ADJACENT STRUCTURES WITHIN
10 ft. (3.05 m) OF THE CHIMNEY
CHIMNEY MUST
EXTEND 3 ft. (.91 m)
ABOVE THE ROOF
CHIMNEY MUST
EXTEND 3 ft.
(.91 m) ABOVE
THE ROOF
