Quick Setup
IMPORTANT: Before using the projector, make sure you read these instructions
and the safety instructions in the online User’s Guide.
Connect the projector
Computer
Choose from the following connections. See the sections below or the online
User’s Guide for details.
VGA cable
USB cable
HDMI cable
HDMI port
Connect one end of an HDMI cable to one of the projector’s HDMI ports and
the other end to an HDMI port on your computer.
Computer port
Connect one end of a VGA cable to the projector’s Computer1 port, and the
other end to your computer’s monitor port. If you are using a laptop,
switch it to external display (see “Troubleshooting”). You can also connect an
audio cable.
Note: To use the projector’s Computer2 port, you need to change the Monitor
Out Port setting in the Signal I/O menu. See the online User’s Guide for details.
USB port
Connect the square end of a USB cable to the projector’s USB-B (square) port.
Connect the flat end of the cable to any USB port on your computer.
Windows®7 or later: After turning on the projector, follow the on-screen
instructions to install the Epson®USB Display software (EMP_UDSE.EXE; only
on first connection). If the software screen does not display automatically, open
My Computer, Computer, or This PC, then double-click EPSON_PJ_UD.
OS X 10.8.x or higher: After turning on the projector, the setup folder for
USB Display appears in the Finder. Double-click USB Display Installer and
follow the on-screen instructions to install the Epson USB Display software
(only on first connection). If the software screen does not display automatically,
double-click EPSON_PJ_UD, then double-click USB Display Installer.
Screen mirroring
You can use Miracast®to send images to your projector from supported
smartphones, tablets, and laptops. See the online User’s Guide for details.
External monitor and speakers
You can connect an external monitor and external speakers to your projector to
enhance your presentations. See the online User’s Guide for details.
Wired network
Connect the projector to your network using an Ethernet cable. See “Wired
network configuration” for more information.
Ethernet cable
Microphone
Connect a dynamic microphone to the Mic port, using a 3.5 mm mini-jack cable.
3.5 mm mini-jack cable
Video device
Connect multiple video devices and use the Source Search button on the
projector or remote control to switch between them. For information on
playing sound through the projector, see the online User’s Guide.
RCA video cable
(composite video)
HDMI cable
Streaming device
Camera, USB device, or document camera
Connect a digital camera, USB flash drive, USB storage device, or Epson DC-07
document camera to the projector’s USB-A (flat) port.
USB cable
If you connect a digital camera, USB flash drive, or USB storage device, you can
use the projector’s PC Free feature. You can also connect other Epson document
cameras to the projector. See the online User’s Guide for details.
Using the remote control
Install the two AA batteries as shown.
Choose which source
to display
Turn projector on
and off
Access projector menus
Turn off projector
display and sound Access the Home
screen
Navigate projector
menus
Control projector
volume
For more information on using the remote control, see the online User’s Guide.
Turn on your equipment
1 Turn on your computer or video source.
2 Make sure the power cord is connected and plugged into an
electrical outlet.
3 Open the projector’s lens cover.
4 Press the power button on the projector or remote control. The
projector beeps, and the Status light flashes blue and then stays on.
Note: To shut down the projector, press the power button twice.
5 Follow the on-screen instructions to set up your projector. If you see a
screen displaying 123, press on the remote control to continue.
Note: To change these settings, see the online User’s Guide.
6 If you don’t see an image, do one of the following:
• Press the Source Search button on the remote control to select the
image source.
• Press the Home button on the remote control. Use the arrow buttons
to highlight any of the options on the Home screen, then press to
select it.
Note: If you still see a blank screen or have other display problems, see
“Troubleshooting”.
7 The default language of the menu system is English. To select another
language, press the Menu button on the remote control. Select
Management and press . Select Language and press . Select your
language and press . Press the Menu button to exit the menu system.
Adjust the image
1 To raise the image, press the foot release button and lift the front of the
projector. Release the button to lock the foot in position.
2 To reduce or enlarge the image, rotate the zoom ring on the projector.
3 To sharpen the image, turn the focus ring on the projector.
4 If your image looks like or , you may have placed the projector
off to one side of the screen at an angle. Place the projector directly in
front of the center of the screen, facing the screen squarely. If you can’t
move the projector, use the horizontal keystone slider on the projector to
correct the image shape.
5 Your projector automatically adjusts an image that looks like or ,
but if necessary you can press the or button on the projector to
correct it.
Wireless network
configuration
Follow these steps to set up the projector for a wireless network connection.
1 Press the Menu button on the remote control.
2 Select the Management menu and press .
3 Select On as the Wireless LAN Power setting.
4 Select the Network menu and press .
5 Select Network Settings and press .
6 Select Wireless LAN as the Priority Control Interface setting.
7 Select one of the following as the Simple AP setting:
• On for a direct connection to a computer, tablet, or smartphone.
• Off to connect your projector to a router or access point
Note: If you directly connect to the projector, you can only project locally
stored content.
8 Select any other wireless settings as necessary. See the online User’s Guide
for details.
9 When you are finished, return to the Network Settings menu and select
Set to apply your settings.
10 Press the Menu button to exit the menu system.
Wired network
configuration
Follow these steps to set up your projector for a wired network connection.
1
Press the Menu button on the remote control, select the Network menu,
then press .
2 Choose Network Settings and press .
3 Select Wired LAN as the Priority Control Interface setting.
