Essentials For Living AZURE CARRERA MEDIA SIDEBOARD User manual

19511 Pauling, Foothill Ranch, CA 92610 USA | www.EssentialsForLiving.com
ASSEMBLY INSTRUCTIONS | AZURE CARRERA MEDIA SIDEBOARD
Please do not begin assembly or discard any packaging until you have
checked that all the parts and hardware are present. Follow instructions
closely as deviation from them may void your warranty and present a
possible safety risk. It is recommended that assembly is done on a
soft surface to avoid any damage. Periodically check and re-tighten
any fasteners. Wipe down all surfaces weekly with a clean cloth. Do not
clean any surfaces with harsh abrasives or chemicals.
PARTS
ABody (1pc)
BWine Rack (2pcs)
CLeft Shelf (1pc)
DRight Shelf (1pc)
Step 1 Step 2
HARDWARE CHECKLIST
01 Shelf Pin (8pcs)
01
01
Step 3 Step 4
A
A
D
B
B
B
C
C

19511 Pauling, Foothill Ranch, CA 92610 USA | www.EssentialsForLiving.com
ASSEMBLY INSTRUCTIONS | AZURE CARRERA MEDIA SIDEBOARD
Step 5 Step 6
Step 7
Adjust
Feet Levelers
D
B

19511 Pauling, Foothill Ranch, CA 92610 USA | www.EssentialsForLiving.com
ASSEMBLY INSTRUCTIONS | AZURE CARRERA MEDIA SIDEBOARD
LATERAL MOVEMENT
VERTICAL MOVEMENT
HORIZONTAL MOVEMENT
BODY
BODY
BODY
SCREW A
SCREW C
SCREW C
SCREW B
DOOR
DOOR
DOOR
Issue:
Right and left sides of the
door are not sitting flush with
the side panel
Issue:
The top and bottom of the
door are not sitting flush with
the vertical panel
Issue:
The door will appear too far/
close from the front edge of
the side panel leaving a gap
behind the door
Solution:
To move the door towards or
away from the center of the
unit, loosen screw A. Adjust
the door and then tighten the
screw.
Solution:
To move the door towards
or away from the center of
the horizontal panels, loosen
screws C. Adjust the door and
tighten the screws.
Solution:
To move the door towards
or away from the unit, adjust
screw Band move the door
forwards/backwards until
there is an even gap between
the door and front edge of the
side panel.
