Essilor DS550 User manual

CAMERA DIGITAL DS550
Installation manual
www.essilor-instruments.com

INSTALLATION MANUAL > CONTENTS
CONTENTS
I. PRESENTATION 4
II. INSTALLATION 6
a. Activation software 11
b. Perform a new examination 12
1. Equipment installation
2. Software installation
7
11
1. Accessories provided 5

I. PRESENTATION

Camera digital DS550 > v1.0 -03.16
5
This guide describes the steps of physical installation as well as the software installation of camera DS550.
Prerequisite: installation and set up of the slit lamp has already been performed.
1. Accessories provided
The following accessories are delivered with the system:
A USB key
A DS550 power supply cable
A DS550/PC connector cable

II. INSTALLATION

Camera digital DS550 > v1.0 -03.16
7
1.Equipment installation
This section describes the system equipment installation stages.
Install the digital camera
1Remove the ocular block by unscrewing the screw from the upper part of the slit lamp.
2Using the screw located above microscope of the slit lamp, press then screw on the DS550 digital camera.
3In the same way, reposition the ocular block.

Camera digital DS550 > v1.0 -03.16
8
> The system is assembled.
Plug in the digital camera
1Plug the elbow end of the power supply cable for the DS550 camera on the port of the slit lamp designed
for this purpose.

Camera digital DS550 > v1.0 -03.16
9
2Then, plug the other end ofthe power supply cable into the supply port on the DS550 located under
the
product.
> The system is plugged in.

10
Camera digital DS550 > v1.0 -03.16
Connect the digital camera to the PC
1Plug the elbow end of the DS550camera connector cable into the camera port designed for this purpose.
2Then, plug the other end of the connector cable into the 3.0 USB port for the PC.
> The system is connected.

Camera digital DS550 > v1.0 -03.16
11
2.Software installation
This section describes the steps for system software installation.
a. Activation software
The 3.2 Version of AnaEyes allows for the recognition and automatic activation of the software.
DS550 digital camera, installed with AnaEyes in version 3.2, functions now like a data-processing key.
The P-code, the serial number of the product and other information are contained inside the memory of
the camera. It is no longer necessary to put in this information to activate the software.
To activate the software, make sure that:
the software is installed beforehand in version 3.2,
DS550 camera is turned on.
Then, start the AnaEyes application.
> An automatic search of the connected instruments is launched.
> The software detects the camera automatically and extracts the necessary information.
> As soon as the instrument is detected, installation of the associated drivers is launched.
> The device is automatically recognized and detected by the AnaEyes software:
> At the end ofthe operation, the detected instruments as well as the associated functions are listed.
2Confirm by clicking on the Configure button.
1

12
Camera digital DS550 > v1.0 -03.16
2
1
2
1
> The following window is displayed:
3Click OK.
> The device is ready to perform an examination.
b. Perform a new examination
Click on the icon to access a new examination window.
> The following screen is displayed:
Click on the icon which corresponds to the slit lamp.
1
2

13
Camera digital DS550 > v1.0 -03.16
> The following screen is displayed:
> To take a measurement, you only need to press on the button on top of the grip handle.
