Sound Control Technologies RC8-CQC User guide

Module Dimensions
RC8-CE™: 1.625”H x 7.5”W x 4.375”D
RC8-HE™: 1.375”H x 9.25”W x 5.375”D
RC8-HE™
RC8-CE™
Cisco Codec Plus, Codec Pro & SX80
Cisco Quadcam
W PS-48 48VDC
100-240V~47-63Hz
Power Supply
Cisco Touch10
Ethernet/POE
*Cisco Provided*
RCC-H001 [2]
3’ HDMI Cables
RCC-H016
3’ UTP Cable
Pin 1
RJ45 Pinout
o O g B b G br BR
1 2 3 4 5 6 7 8
T-568B
g G o B b O br BR
1 2 3 4 5 6 7 8
T-568A
LINK Cable Specs
Integrator-Supplied CAT6 STP Cable
EIA568A or EIA568B (Min. 30’ to 300’ Max)
LINK Cable
Power, Control, Audio & Video
PPC-018
1’ Power Cable
RCC-C015
1’ Flat CAT6
RCC-C014 [2]
1’ Angled
HDMI Cables
Important: Due to the power
demands of Cisco’s QuadCam, it
is best practice to utilize SCT’s
provided RC-RKL™ rack shelf to
facilitate ventilation.
RC8-CQC™ Application Guide

RC8-CQC Installation Instructions
Supporting the Cisco Quad Camera and
Cisco SX80, Plus & Pro Codecs
TEST YOUR LINK CABLE
We highly recommend using an Ethernet Network Tester/Analyzer alongside our provided PowerSniffer to confirm your LINK
cable’s wiring. Our PowerSniffer only tests conductor continuity and will not identify data integrity or capacity issues.
1. Test and verify your CAT6 STP or FUTP LINK cable for UTP 568A/568B. Link cable must be between 30ft - 300ft.
The LINK cable between the RC8-CE module (transmitter) & RC8-HE module (receiver)
must always be a single, point-to-point CAT cable with no couplers or interconnections.
2. Connect the provided PowerSniffer to the Quad Camera end of your CAT6 STP or FUTP LINK cable.
3. Connect the other end of the LINK cable to the blue “SCTLink™” connection on the Head End module.
4. Connect the WPS-48 power supply to the Head End module.
5. Connect the WPS-48 power supply to AC mains.
6. If the “SCTLink™” cable is properly terminated, it will display eight GREEN LEDs.
If you get any other result, stop and re-terminate cable .
7. Once your cable has been tested, please disconnect the WPS-48 power supply from the RC8-HE module,
and the PowerSniffer from the LINK cable, before proceeding to install.
INSTALL THE EXTENSION KIT
Connect the camera-end cables:
1. Connect the RCC-C014 HDMI cables between the Quad
Camera’s HDMI 1 & 2 connectors RC8-CE’s “HDMI 1” and
“HDMI 2” ports.
2. Connect the RCC-C015 UTP cable between the Quad
Camera’s RJ45 Ethernet port and the RC8-CE’s Ethernet
port.
3. Connect the PPC-018 power cable between the Quad
Camera’s power connector and the RC8-CE’s “12VDC
Output” port.
Connect the codec-end cables:
4. Connect two 3 ft RCC-H001 HDMI cables between
the codec’s HDMI camera inputs and the RC8-HE’s
corresponding “HDMI Out 1 A” and “HDMI Out 2 A” port.
5. Connect the 3ft RCC-H016 UTP control cable between
the codec’s RJ45 camera Ethernet port and the RC8-
HE’s “Ethernet 1”.
Connect and Initiate the Extended System:
6. Connect one end of your CAT6 STP or FUTP LINK cable
to the RC8-HE module’s blue “SCTLink™” port.
7. Connect the other end of the CAT6 STP or FUTP LINK
cable to the RC8-CE module’s blue “SCTLink™” port.
8. Connect the WPS-48 power supply to the RC8-HE.
TECH SUPPORT: 203-854-5701 • WWW.SOUNDCONTROL.NET • © SOUND CONTROL TECHNOLOGIES, INC
•ALLOW UP TO TWO MINUTES FOR THE QUAD CAMERA SYSTEM TO INITIALIZE •
Power Supply Specications (AC-Mains Side): Input Voltage: 100VAC to 240VAC 47Hz to 63Hz. Efficiency: 85% minimum.
Turn-on Surge: Less than 60 amperes for a duration less than 1mS. Power Factor: 0.9 minimum (where applicable). 48VDC
power supply uses 2.80 amperes AC maximum. All specifications subject to change without notice.
Installation Status - Refer to our modules’ LEDs for installation status.
For assistance troubleshooting INACTIVE LED statuses, please contact Tech Support at 203-854-5701.
MODULE LED LABEL ACTIVE STATUS INACTIVE STATUS
RC8-CE OK LED 1 & 2 Blinking Green (~1 second interval) Blinking or Solid Red
RC8-HE OK LED 1 & 2 Blinking Green (~1 second interval) Blinking or Solid Red
RC8-HE LINK LED Solid Green Solid Red or Dormant
RC8-HE HDCP 1 & 2 Blinking Green N/A
Cable Table - Part numbers, descriptions and functions of all SCT cables provided for the RC8-CQC™.
This kit is also inclusive of [1] RC-RKL Rack Shelf.
CABLE DESCRIPTION FUNCTION
[2] RCC-C014 1’ HDMI Cables Video connection between Quad Camera and RC8-CE module.
RCC-C015 1’ UTP Cable Control connection (Ethernet) between Quad Camera and RC8-CE module.
PPC-018 1’ Power Cable Power connection between Quad Camera and RC8-CE module.
[2] RCC-H001 3’ HDMI Cables Video connection between the codec and RC8-HE module.
RCC-H016 3’ UTP Cable Control connection (Ethernet) between the codec and RC8-HE module.
