EverFocus S200 User manual

S200
1080p Full HD MoniVue Camera
User’s Manual
Copyright © EverFocus Electronics Corp.
Release Date: January, 2017
All the images including product pictures or screen shots in this document are for example only.
The images may vary depending on the product and software version.
Information contained in this document is subject to change without notice.

i
Precautions
1. Do not install the camera near electric or magnetic fields. Install the camera away from TV/radio
transmitters, magnets, electric motors, transformers and audio speakers since the electromagnetic
fields generated from these devices may distort the video image or otherwise interfere with camera
operation.
2. Never disassemble the camera beyond the recommendations in this manual nor introduce materials
other than those recommended herein. Improper disassembly or introduction of corrosive materials
may result in equipment failure or other damage.
3. Try to avoid facing the camera toward the sun. In some circumstances, direct sunlight may cause
permanent damage to the sensor and/or internal circuits, as well as creating unbalanced illumination
beyond the capability of the camera to compensate.
4. Keep the power cable away from water and other liquids and never touch the power cord with wet
hands. Touching a wet power cord with your hands or touching the power cord with wet hands may
result in electric shock.
5. Never install the camera in areas exposed to oil, gas or solvents. Oil, gas or solvents may result in
equipment failure, electric shock or, in extreme cases, fire.
6. Cleaning. For cameras with interchangeable lenses, do not touch the surface of the sensor directly
with the hands. Use lens tissue or a cotton tipped applicator and ethanol to clean the sensor and the
camera lens. Use a damp soft cloth to remove any dirt from the camera body. Please do not use
complex solvents, corrosive or abrasive agents for cleaning of any part of the camera.
7. Do not operate the camera beyond the specified temperature, humidity or power source ratings.
This camera is suitable for indoor operation only. Use the camera at temperatures within -20°C ~ 50°C
/ -4°F ~ 122°F and humidity less than 90%; this device is not rated as submersible. The input power

ii
source is 12VDC. Be sure to connect the proper + / - polarity and voltage, as incorrect polarity or too
high a voltage will likely cause the camera to fail, and such damage is not covered by the warranty.
8. Mounting. Use care in selecting a solid mounting surface which will support the weight of the camera
plus any wind, snow, ice or other loading, and securely attach the camera to the mounting surface
using screws and anchors which will properly support the camera. If necessary (e.g. when mounting to
drop ceilings) use a safety wire to provide additional support for the camera.
Safety Notice
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.

iii
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

iv
Contents
1. Introduction .................................................................................1
1.1 Packing List .................................................................................2
1.2 Features......................................................................................3
2. Cable Description..........................................................................3
3. Installation ...................................................................................4
3.1 Installation and Adjustment .......................................................4
4. Configuration in the OSD Menu.....................................................9
5. Specifications ............................................................................. 13

S200
1
1. Introduction
The MoniVue System, bundled with one compact 4CH video recorder and four
1080p FHD cameras, is ideal for the surveillance environment where areas are
closely situated. With Its excellent compact size, the MoniVue System is
perfectly to be widely used no matter in the industrial, banking or various
markets such as ATM, luxury stores, industrial production lines or casino.
As MoniVue System is bundled with a video recorder and four-camera, we will
introduce the two products separately. The content below describes the
hardware and software of the 1080p FHD camera S200. For more details about
the video recorder, please refer to the User’s Manual of MoniVue Video
Recorder.
The S200 MoniVue Camera is equipped with a 1/2.9" SONY 2.24M pixels CMOS
sensor and providing high resolution of 1080p. Featured with the Digital Wide
Dynamic Range (D-WDR) function, the camera can provide clear images even
under back light circumstances where intensity of illumination can vary
excessively.
The S200 can work in both indoor and outdoor environments. The IP66-rating
housing makes it suitable for outdoor use. The camera supports both NTSC and
PAL scanning systems, which can be switched via OSD.

S200
2
1.1 Packing List
Camera Body x 1
User Manual x 1
Mounting Bracket x 1
Mounting Ring x 1
Mounting Screw x 2
Plastic Anchor x 2
Mac Address Sticker x 1

S200
3
1.2 Features
1080p Full HD with high flexibility and performance for astounding image
1/2.9" Sony 2.24MP CMOS sensor, delivering amazing high sensitivity
Special design, easy installation and operation
D-WDR to improve the visibility under high contrast scene
Weather resistance IP66-rated metal housing
eZ.Controller function: Control camera OSD settings from MoniVue Video
Recorder end
2. Cable Description
Name
Descriptions
Video Output
1080p output, using a 75 Ohm mini DIN cable.
Connect to a Camera IN cable of the MoniVue
Video Recorder.

S200
4
3. Installation
3.1 Installation and Adjustment
Ceiling Mount / Wall Mount
1. Put the Mounting Bracket on the wall or ceiling to mark where to insert
the Mounting Screws. Drill two holes on the wall or ceiling according to
the marks and insert the supplied Plastic Anchors into the holes.
2. Screw the Mounting Bracket to the wall or ceiling with supplied
Mounting Screws. Slide the Mounting Bracket along the curved groove
to adjust its position.

S200
5
3. Inset the camera into the Mounting Bracket.
4. Use the Mounting Ring to fix the camera.
Mounting Ring

S200
6
5. Connect the camera to a Camera IN cable of the MoniVue Video
Recorder for viewing the video image while adjusting camera angles. To
configure camera settings, use the OSD Menu Joystick.
Video Output
Camera IN cable
6. Slide the adjusting screw or rotate the Mounting Bracket to adjust the
angle of the camera.
Adjusting
Screw

S200
7
Embedded Mount
1. Drill a Φ20.4 ~ 21.4mm / 0.80" ~ 0.84" hole on the wall or ceiling.
20.4 ~ 21.4mm / 0.80" ~ 0.84"
Wall or ceiling
2. Insert the camera into the hole.

S200
8
3. Use the Mounting Ring to fix the camera.
Mounting Ring Camera
7. Connect the camera to a Camera IN cable of the MoniVue Video
Recorder for viewing the video image. To configure camera settings, use
the OSD Menu Joystick.
Video Output
Camera IN cable

S200
9
4. Configuration in the OSD Menu
You can use the OSD Menu Joystick on the MoniVue Video Recorder to configure
camera settings in the OSD menu. Please see below details of the camera’s OSD
menu structure:
No.
Main Menu
Sub Menu
Sub Menu / Function
1
Exposure
Shutter
NTSC: Auto, 1/30, 1/60, FLK, 1/240, 1/480, 1/1000, 1/2000,
1/5000, 1/10000, 1/50000
PAL: Auto, 1/25, 1/50, FLK, 1/200, 1/400, 1/1000, 1/2000,
1/5000, 1/10000, 1/50000
AGC
0 –15
Brightness
1 –100 (40)
D-WDR
Off
On
Level
0 –15
Auto
2
Backlight
Off
BLC
Level
Middle, High, Low
Area
Position, Size,↑,↓,→,←
Default

S200
10
2
Backlight
HSBLC
Select
Area1, Area2, Area3, Area4
Display
Off
On
Position, Size,↑,↓,→,←
Black Mask
On, Off
Level
0 –100
Model
All Day
Night
AGC Level
0 –255
Default
3
White
Balance
ATW
AWC→SET
Indoor
Outdoor
Manual
Blue
0 –100
Red
0 –100
4
Day & Night
Ext
D→N (Delay)
0 –60
N→D (Delay)
0 –60
Auto
D→N (AGC)
2 –255
D→N (Delay)
0 –60
N→D (AGC)
1 –254
N→D (Delay)
0 –60
Color
B/W
IR Smart
Off
On
Level
0 –15
Area
Position,
Size,↑,↓,→,←
IR PWM
0(OFF) –100

S200
11
5
NR
2DNR
Middle, Low, Off, High
6
Special
Mirror
Off, Mirror, V-flip, Rotate
Defect
Live DPC
Off
On
AGC level
0 –255
Level
0 –100
White DPC
Off
On
Pos / Size
Position,
Size,↑,↓,→,←
Start
1. Close the Iris
2. Place a black
paper upright in
front of the lens
3. Press Enter
DPC View
Off, On
Level
0 –60
AGC
0 –14
Black DPC
Off
On
Pos / Siz
Position,
Size,↑,↓,→,←
Start
1. Place a white
paper upright in
front of the lens
2. Press Enter
DPC View
Off, On
Level
0 –60
Language
ENG / CHN1 / CHN2 / GER / FRA / ITA / SPA / POL / RUS /
POR / NED / TUR

S200
12
7
Adjust
Sharpness
Off
Auto
Level
0 –10
Start AGC
0 –255
End AGC
0 –255
Monitor
Gamma
User, 0.45, 0.50, 0.55, 0.60, 0.65, 0.70,
0.75, 0.80, 0.85, 0.90, 0.95, 1.00
Blue Gain
0 –100
Red Gain
0 –100
LSC
Off, On
Output
Mode
Format
AHD, THD(TVI)*
Frame Rate
25P(PAL), 30P(NTSC)
8
Exit
Save& END / Reset / Not Saved
*The MoniVue Video Recorder does not support TVI. Please do not switch the format to TVI
if you connect the camera to a MoniVue Video Recorder.

S200
13
5. Specifications
Pickup Device
1/2.9" Sony 2.24MP CMOS
Day/Night
Ext, Auto, Color, B/W
Video Format
NTSC / PAL (Can be
switched via OSD)
UTC Function
Supported
Lens Type
2.7mm, F2.2
OSD
Languages
13-Language
Effective
Pixels
1920 (H) x 1080 (V)
DNR
2DNR
Scanning
System
Progressive Scan
D-WDR
On / Off / Auto
Sensitivity
0.2Lux
Mirror
Off / Mirror / V-Flip / Rotate
S/N Ratio
> 45dB
Environment
IP66 Weather Resistant
Electronic
Shutter
Auto / Manual (1 ~
1/50,000) / FLK
Power Source
12VDC
Video Output
Mini DIN 1.0Vp-p 75Ω
Power
Consumption
12VDC, 0.1A max.
Gamma
Correction
0.45
Operating
Temperature
-20°C ~ 50°C / -4°F ~ 122°F
BLC
Yes
Humidity
Less than 90%
AGC
0 ~ 15 Levels
Dimensions
(L) x (Ф)
32.3 x 25mm / 1.27" x 0.99"
White
Balance
ATW / AWC-SET / Indoor /
Outdoor / Manual
Weight
96g / 0.22lb
Sync Mode
Internal
Certifications
CE, FCC, RoHS

EverFocus Electronics Corp.
EverFocus Taiwan:
12F-1, No.79, Sec. 1, Shin-Tai Wu Road,
Hsi-Chih, New Taipei City, Taiwan
TEL: [phone]
FAX: [phone]
www.everfocus.com.tw
[e-mail]
EverFocus Europe - Germany:
Albert-Einstein-Strasse 1, D-46446
Emmerich, Germany
TEL: [phone]
FAX: [phone]
www.everfocus.de
[e-mail]
EverFocus China - Beijing:
Room 609, Technology Trade Building,
Shangdi Information Industry Base,
Haidian District, Beijing 100085, China
TEL: [phone]~39
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus China - Shenzhen:
4F, No. 2, D4 Building, Wan Yelong
Industrial Park, Tangtou Road, Shiyan,
Baoan, Shenzhen, Guangdong 518101, China
TEL: [phone]
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus USA - California:
1801 Highland Avenue, Unit A, Duarte, CA
91010, USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[e-mail]
EverFocus Japan:
3F Kuramochi, Buildingll 2-2-3 Koto-Bashi,
Sumida-Ku Tokyo, 130-0022, Japan
TEL: [phone]
FAX: [phone]
www.everfocus.co.jp
[e-mail]
Your EverFocus product is designed and
manufactured with high quality materials
and components which can be recycled
and reused.
This symbol means that electrical and
electronic equipment, at their end-of-life,
should be disposed ofseparately from
your household waste.
Please, dispose of this equipment at your
local community waste
collection/recycling centre.
In the European Union there are
separate collection systems for used
electrical and electronic product.
Please, help us to conserve the
environment we live in!
Ihr EverFocus Produkt wurde
entwickelt und hergestellt mit
qualitativ hochwertigen Materialien
und Komponenten, die recycelt und
wieder verwendet werden können.
Dieses Symbol bedeutet, dass
elektrische und elektronische Geräte
am Ende ihrer Nutzungsdauer vom
Hausmüll getrennt entsorgt werden
sollen.
Bitte entsorgen Sie dieses Gerät bei
Ihrer örtlichen kommunalen
Sammelstelle oder im Recycling
Centre.
Helfen Sie uns bitte, die Umwelt zu
erhalten, in der wir leben!
PN: 4605S200002001A -Ver.O
