Instruction Manual
Rechargeable Battery-Powered Lawn Mower
EVO1536Li
This manual contains important information regarding SAFETY, ASSEMBLY, OPERATION AND MAINTENANCE.
Please read and keep this book for future reference.

2
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
3
1
2
345
6
8 11 12 13 14 15
18
17
16
7
8
9
10
1 Safety button 11 Battery pack
2 Switch lever 12 Safety key
3 Handle Knob 13 Power lead for charger
4 Cable Clip 14 Charger
5 Battery cover 15 Mulching fitting
6 Height adjustment lever 16 Battery temperature indicator
7 Upper push bar 17 Battery power indicator
8 Grass collection indicator 18 Switch button for indicator
9 Grass collection bag
10 Quick fold lever
Intended Use
Safety Notes
• This lawn mower is designed for family use of grass and
lawn mowing, not for commercial use.
• Use this tool only for the purpose it is intended.
Explanation of symbols on the lawn mower
Warning! It is important that you read, fully understand
and observe the following safety precautions and
warnings. Careless or improper use of the machine
may cause serious or fatal injury. The user is responsible
for any accidents involving other people or other people‘s
property.
General hazard safety alert
Read instruction manual
Beware of thrown or flying objects

4
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
5
Keep bystanders at a safe distance away from the
machine
Sharp blade(s) - Beware of severing toe and fingers
Switch off and remove battery power plug from
battery power socket, before adjusting, cleaning,
performing any maintenance work and before leaving
the lawnmower unattended for any period
Wait until all machine components have completely
stopped before touching them. The blades continue
to rotate after the machine is switched off, a rotating
blade can cause injury
Do not mow in the rain or leave the lawn mower
outdoors whilst it is raining
Beware electric shock hazard
Keep power cord away from the blade
Only use the battery charger indoors
Only use the battery charger indoors
• Never allow children or people unfamiliar with these
instructions to use the lawnmower. Local regulations may
restrict the age of the operator.
• Never mow while people, especially children or pets, are
nearby.
• The operator or user is responsible for accidents or
hazards occurring to other people or their property.
• Do not operate the lawnmower when barefoot or wearing
open sandals, always wear substantial footwear and long
trousers.
• Thoroughly inspect the area where the lawn-mower is to be
used and remove all stones, sticks, wires, bones and other
foreign objects.
• Before using, always visually inspect to see that the
blades, blade bolts and cutter assembly are not worn or
damaged. Replace worn or damaged blades and bolts in
sets to preserve balance.
• Mow only in daylight or in good artificial light.
• Avoid operating the lawnmower in wet grass, where
feasible.
• Walk, never run.
• Never operate the appliance with defective guards or
shields, or without safety devices, for example deflectors
and/or grass catchers in place.
• Mowing on banks can be dangerous:
–Do not use the mower on a slope steeper than 15º
maximum.
–Always be sure of your footing on slopes or wet
grass.
–Mow across the face of slopes – never up and down.
–Exercise extreme caution when changing direction on
slopes.
• Use extreme caution when stepping back or pulling the
lawnmower towards you.
• Never mow by pulling the mower towards you.
• Stop the blades if the lawnmower has to be tilted for
transportation when crossing surfaces other than grass
and when transporting the lawnmower to and from the area
to be mowed.
• Do not tilt the machine when starting or switching on
the motor, except if the machine has to be tilted for

6
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
7
starting in long grass. In this case, do not tilt it more than
absolutely necessary and tilt only the part which is away
from the operator. Always ensure that both hands are in
the operating position before returning the machine to the
ground.
• Switch on the lawnmower according to instructions and
with feet well away from the blades.
• Do not put hands or feet near or under rotating parts. Keep
clear of discharge opening at all times.
• Never pick up or carry the lawnmower while the motor is
running.
• Under the following conditions, the unit must be switched
off, the safety key must be removed from its socket, and
the unit must be brought to a standstill:
–leaving the lawnmower
–unblocking a blade
–intending to check, clean or work on the lawnmower
–you have encountered a foreign object, in which case
you should check the lawnmower for damage and carry
out any necessary repairs.
–the lawnmower is vibrating heavily (switch off
immediately and ascertain the cause).
–you wish to change the settings or carry out cleaning
work.
–you wish to check whether the connection cables have
become tangled or damaged.
• Keep all nuts, bolts and screws tight to be sure that the
lawnmower is in safe working condition.
• Check the grass collection bag frequently for wear or
deterioration.
• Replace worn or damaged parts for safety.
• Ensure replacement cutting means of the right type
are used. Ensure replacement parts fitted are from
manufacturer.
• Protect the battery charger from rain and moisture. The
penetration of water in a battery charger increases the risk
of electric shock.
• Recharge only with the charger supplied by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
• Do not charge other batteries. The battery charger is
suitable only for charging the battery pack of this lawn
mower within the listed voltage range. Otherwise there is
danger, fire and explosion.
• Keep the battery charger clean. Contamination may cause
the danger of electric shock.
• Check the battery charger, cable and plug each time
before using. Do not use the battery charger when defects
are detected. Do not open the battery charger yourself and
have it repaired only by qualified personnel using original
spare parts. Damaged battery chargers, cables and plugs
increase the risk of electric shock.
• Do not operate the battery charger on easily inflammable
surfaces (e. g. paper, textiles, etc.) or in combustible
environments. There is danger of fire due to the heating of
the battery charger during charging.
• Use product only with specifically designated battery
packs. Use of any other battery packs may create a risk of
injury and fire.
• When battery pack is not in use, keep it away from other
metal objects like paper clips, coins, keys, nails, screws,
or other small metal objects that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
• Do not open the battery pack yourself. There is danger of a
short circuit.
• Do not short-circuit the battery.
• Touching electrically conductive parts of battery pack
might result in an electric shock, be sure to wear rubber

8
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
9
gloves before inspection or maintenance work.
• Protect the battery against moisture and water.
• Store the battery only within a temperature range between
-20°C and +40°C. As an example, do not leave the battery
in your car in the summer.
Product Specification
Assembly
Lawn mower
Model: EVO1536Li
Cutting width: 380mm (15”)
No load speed: 3000rpm
Cutting system: Rotating blade
Cutting height: 6 settings, 25-75mm
Fabric collection bag capacity: 40L
Battery Pack
Model: KXX-36V
Battery type: Li-ion Battery
Battery Voltage: 36V, 4Ah
Charging time: 3 - 5 hours
Do not insert the battery or the safety key before the
mower is completely assembled!
1. Fasten push bars
2. Securing cable by using cable clips
Figure 1 & 2
The push bar is already fully assembled, only need to be
unfolded to the desired position.
First unfold the quick fold lever (Pos. 12) and loosen the
handle knob (Pos. 3).
Expand the handle, make sure the upper handle and lower
handle match well.
Then screw them tight with the handle knob (Pos. 3) and
swing nuts. The swing nuts should be hand tightened only.
Never use a spanner or any other tool to tighten them.
Figure 1 Figure 2
Figure 3
Figure 3
Secure the cable from the motor to the switch assembly by
using four cable clips – two is fixed on upper push bar, the
others fixed on lower push bar. See Figure 3

10
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
11
4. Adjust cutting height
Stop, release the switch lever and wait until the
motor stops before adjusting height. The blades
continue to rotate after the machine was switched
off, a rotating blade can cause injury.
Caution , do not toughing rotating blades.
Under Normal conditions, the battery should run
for approximately 30 minutes per single charge,
this operation time and the area that can be mown
by this battery-powered mower is dependent on
various factors. These are:
Using the height of cut between 25mm to 35mm will
further shorten the battery duration.
Figure 5
For the first cutting of season, a high cutting adjustment
should be selected.
The mower can be set to 6 cutting heights, between 25mm
and 75mm. Press the height of cut lever inwards, then lift or
push down the mower until required height is selected.
The lawn mower maybe used to 25mm by moving the blank
plate.
Type of lawn
Battery-powered lawnmowers are suitable for lawns which
are mown frequently, for example, Battery-powered mowers
are not suitable for infrequently-mown meadows or similar.
To produce a well-maintained lawn, we recommend mowing
the lawn as often as you can, once a week if possible, so that
you are only cutting 1 to 2 inches (20mm to 50mm) of grass
each mowing session (see figure 6). Trying to cut more than
2 inches (50mm) will drastically reduce the charge life of the
battery and quality of the cut. After relatively long intervals
between mowing (holiday lawn), first of all cut in one direction
with the cutting height as high as possible, then cut in the
crosswise direction at the cutting height required.
Lawn structure
The area that can be mown decreases in proportion to the
density of the grass. The mowing capability is lowest on
extremely dense grass, e. g. golf greens, which is not suitable
for battery-powered lawn mowers to mow.
3. Mount the grass collection bag
Figure 4
Raise the safety flap as far as possible and place the
collection bag on two hooks of the under deck. Always fit
the grass collection bag on mower before connecting to the
mains.
Figure 4 Figure 5
Operation
1. TIPS for the use of this battery-powered mower
Figure 6

12
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
13
Lawn condition
The length of time that the mower’s battery can hold its
charge while mowing a lawn depends upon lawn conditions:
tall, thick, or damp grass make the Mower work harder,
causing the battery to discharge faster. Under normal mowing
conditions the run time is around 35 minutes. To mow longer,
consider purchasing a second battery and keeping it fully
charged. Before starting the mower, adjust the cutting height
so that you only cut 1 to 2 inches (20 mm to 50mm) of grass
at a time (see figure 6). Cut thicker grass at a higher cutting
height, or cut a narrower swath. Do not force the mower
forward in tall, thick or wet grass.
Charging Time
Important! The battery is supplied charged at the factory but
may lose charge during transportation, and when it has been
stored for some time. You MUST charge the battery for 3-5
hours before you use the mower for the first time.
Charging Procedure
The red light on the charger only indicates that the charger is
plugged in and the battery charging procedure starts, The light
on the charger will change color to green when the battery is
fully charged.
The battery for this mower can be charged in or outside
the mower. The performance of your mower is same,
regardless of which charging method you choose.
Use normal household voltage when charging your battery.
Plug the charger directly into the electric outlet. Ensure that
the charging plug is correctly seated, Do not abuse the cords,
Never carry the charger by the cord. Always pull the plug and
not the cord.
Mowing / walking speed
The walking speed influences the duration of mowing
and therefore the area that can be covered. We therefore
recommend mowing at a steady pace. To avoid damage
and extend battery life, always mow at a speed which allows
the motor to run smoothly. The mowing path should not be
covered twice if possible and the overlap of mowing tracks
should be kept as minimal as possible. Frequently switching
the mower on and off likewise decreases the battery‘s power.
Try to work continuously and smoothly when mowing.
Blade sharpness
Keep your mower blade sharp! A sharp mower blade cuts the
grass quickly and cleanly, using less of the mower’s power,
which conserves battery life. For best results, inspect the
blade often and have an extra sharp blade ready to install as a
replacement while the dull blade is being sharpened.
Important! Before charging the battery, read all instructions
and warning markings in this manual and on your mower, Do
not operate your mower until you have read and understand
all instructions and the battery has been fully charged.
Battery - This mower comes with a sealed Li-ion battery,
already assembled at the factory , the battery is rated for 36
volts and 4 amp hours.
The battery is completely maintenance-free. However, as
with all rechargeable batteries, they will eventually need
replacement.
2. Charging and care for the battery
Warning! Do not attempt to open or later the battery.
Attention! Only use the charger in dry rooms with the
supplied battery charger.
Note: During whole charging status, the LED light of
battery pack will not be on, The LED lights will be on
when you press the “on” button on the battery pack.

14
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
15
Figure 7 & 8
To take the battery out, open the transparent cover first, then
pull the battery pack out of mower.
Figure 9 & 10 - Charging the battery in/outside the mower
1. Plug charging plug into battery power socket.
2. Plug the charger into a wall outlet.
Storage Temperature Range
For superior battery performance, always store the battery
in temperatures between –4°F (–20°C) and +104°F (+40°C).
Make sure the storage temperatures will never be outside
these limits. The lower the storage temperature is within the
specified range, the better: The battery will discharge more
slowly at low temperatures.
Care for the battery
You can lengthen the life of your battery by following some
simple guidelines:
• Always charge the battery indoors in a garage or other
covered area where it will be dry and protected from the
weather.
• Only charge the battery when the temperature is at least
41°F (5°C) — above freezing — but not more than 95°F
(35°C).Charging in lower or higher temperatures can be
harmful to the battery.
• Always keep the battery away from water, heat sources
(stoves, radiators, open flames, etc.), and hazardous
chemicals.
• Only use the supplied battery charger to charge your
battery; never attempt to use any other charger .Use of a
different charger may cause a fire or explosion.
• Never use the charger with any other product. Never
operate the charger if it is damaged. If a cord or the
charger unit has been damaged, replace the charger.
• When storing the battery after removing it from the Mower,
follow the storage guidelines in “Maintaining and Storing
Your Mower.” on page 13-14.
• If the motor will not run after you have fully charged the
battery, consult the techniques in “Troubleshooting Tips.”
Figure 7 Figure 8
Important! Always connect the charger to the battery
first, and then plug it into the wall outlet. When
unplugging, reverse the process: unplug the charger
from the wall outlet first and then disconnect it from the
battery.
Figure 9 Figure 10
Note: During the charging process, the charger will be
warm to be touch. This is normal and does not indicate a
problem.

16
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
17
on page 15-16, If you still need help, contact with your
local service station for help.
3. Starting and Stopping
4. Mowing
Attention! Rotary cutter blade, The blade continues to
rotate for a few seconds after the machine is switched
off. Allow the motor/blade to stop rotating before
switching “on” again. Do not rapidly switch off and on.
Danger! Risk of injury! Do not put your hand in the
discharge opening
Danger! Foreign bodies thrown out of the mower
can cause injuries! Only lift safety flap with the motor
switched off and the cutting blade has come to a
standstill.
1. Lift safety flap and remove the grass collection bag
by the handle.
2. Empty the grass box and hang it on the back again
using the mounting hook on the under-deck.
We recommend always mowing the lawn with the grass
collection bag.
Figure 11 & 12
Before start make sure the battery pack was put into the
mower and put the safety key into it’s socket.
Switch on motor with mower placed on level and firm ground,
not in high grass - alternatively tilt slightly then follow the
below procedures:
1. Press and hold the safety botton
2. Squeeze the switch lever towards the handle
3. Release the safety botton and grip the switch lever firmly
Figure 12Figure 11
Stopping
Release switch lever
Mowing with the grass collection
The mulcher fitment must be removed before use the grass
collection bag.
Mowing with Mulching Fitment
Figure 13
The grass collection bag must be emptied as soon as grass is
left lying on the lawn.
1. Remove the grass collection bag and then insert the
Mulching Fitment.
2. The mulching fitment will click into place, seal off the grass
chute.
3. The grass will be rotated in the deck and be cut several
times till into tiny tips, then discharged onto the lawn.

18
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
19
Figure 14
Figure 13
Instructions for mowing without the grass collection bag
We recommend:
• The grass should not be too high nor too wet!
• Mow slow while mowing
• Do not cut grass more than 20mm (see Figure 14)
Mowing Tips
If grass residue is left in the discharge opening, pull mower
backwards about 1-2m so that the grass residue can drop out
downwards.
To produce a well-maintained lawn, we recommend mowing
the lawn as often as you can, once a week if possible, so that
you are only cutting 1 to 2 inches (20mm to 50mm) of grass
each mowing session (see figure 6). Trying to cut more than
2 inches (50mm) will drastically reduce the charge life of the
battery and quality of the cut.
Before starting the mower, adjust the cutting height so that
you only cut 1 to 2 inches (20 mm to 50mm) of grass at a time
(see figure 6). Cut thicker grass at a higher cutting height, or
cut a narrower swath. Do not force the mower forward in tall,
thick or wet grass.
Interruptions of work
Never leave the mower unattended at the working area. If you
interrupt your work, store the mower in a safe place, remove
the safety key from its socket!
If you stop work to move to another area of the garden, switch
off the mower and remove safety key form the socket!
• One green light goes on, low battery capacity
• Two green light goes on, mid battery capacity
• Three green light goes on, full battery capacity
• Red light which show the battery temperature lights on,
battery temperature was too high, please wait till the red
light off, then start charging process again.
Figure 15 & 16 - LED battery charge-control Indicator
The battery pack is equipped with a LED battery charge-
control Indicator, which indicates the battery capacity and it’s
temperature.
After relatively long intervals between mowing (holiday lawn),
first of all cut in one direction with the cutting height as high
as possible, then cut in the crosswise direction at the cutting
height required.
Figure 15 Figure 16

20
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
21
Maintaining and Storing
Warning! ALWAYS switch off the mower, remove
safety key from its socket, and remove battery before
performing any adjustments, maintenance, blade
change, or repairs to your mower.
1. Cleaning your mower
2. Removing and attaching the blade
Periodically clean your mower to ensure peak performance.
Supplies needed
• Clean cloth or sponge
• Mild soap or detergent (if needed)
• Soft nylon brush (if needed)
1. Remove the safety key from its socket, and remove
battery.
2. Only use a dry cloth or sponge for cleaning of battery pack.
3. Only use a dry cloth or sponge to clean the battery pack
seat.
4. Using a damp cloth or sponge with a mild soap or
detergent, clean the Mower. Never use water, gasoline,
solvents, or other petroleum-based or solvent-based
products when cleaning — remember, this is an electric
mower.
5. Use a soft nylon brush or non-metallic scrubbing pad
to remove any clippings that have accumulated on the
underside of the deck and in the rear discharge plate. Do
not use a wire brush; it will scratch and harm the surface of
your mower.
6. You may use water to clean the grass collection bag, but
not the mower itself. For proper grass collection, make
sure the grass collection bag is clean and the mesh holes
are not clogged. Allow the grass collection bag to dry
thoroughly before using it again.
Tools & supplies needed
• 14 mm socket wrench (supplied with Mower)
• Gloves or rag to protect your hands
Wear heavy gloves to protect your hands when holding,
removing and attaching blades.
1. Remove the safety key from its socket, and remove
battery. If you are charging the battery, first disconnect the
charger from the electrical (wall) outlet.
2. While holding the handle bars, turn the Mower over on its
right side to expose the blade.
3. Place the socket wrench over the blade nut.
4. While holding the blade in place, loosen the blade nut by
turning counterclockwise. Be careful; wear heavy gloves
Note: A wet grass collection bag will clog quickly and hamper
grass collection.
You must remove the blade to sharpen it, or to change
to a spare blade. Always check the blade for sharpness,
damage, and tightness before and after each use.
Replace the blade promptly if it has been bent or
damaged. Only use spare blade from manufacturer.
Figure 17 Figure 18

22
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
23
to hold the blade in place so the blade does not spin and
strike your hand (see Figure 17).
5. Remove the blade nut, plastic spacer and blade in that
order (see Figure 18).
6. To install a new or sharpened blade, reverse steps 1 to 5.
Be sure to replace all parts in order exactly as they were
removed. Make sure the blade is properly seated and
securely tightened.
7. Turn your mower upright.
Sharpening the blade
When the blade is dull, the cut ends of the grass will be
ragged and may turn brown soon after mowing. A dull blade
also causes the battery to discharge more quickly. When this
occurs, sharpen the blade.
Tools & supplies needed
• Fine-toothed file or sharpening stone
• Gloves.
• Safety glasses
Sharpening the Blade in a Vice
1. Remove safety key from its socket, and remove battery.
2. While holding the handlebars, turn the mower over on its
right side to expose the blade.
3. Remove the blade.
4. Secure the blade in a sturdy vise.
5. While wearing safety glasses, carefully file the cutting
edges of the blade using even strokes. Be sure to file both
sides of the blade equally.
6. Check the blade after sharpening to be sure it is still
balanced.
Whether you store the mower for a short or long period of
time, You can safely keep the battery in the mower or store
the battery outside the Mower, but always follow these
important guidelines:
• Remove safety key from its socket.
• Always store the mower in an environment where the
temperature is between –4°F (–20°C) and +104°F (+40°C).
Make sure the storage temperatures will never be outside
these limits. For long-term storage, store your battery in
an environment where the temperature is lower, since the
battery self-discharges slower at low temperatures.
• Store the Mower in a dry environment. Do not store it on a
floor that may be damp or subject to accidental flooding.
Water will damage the mower and battery.
• Do not store the mower near chemicals, such as fertilizers.
These products are often highly corrosive and may cause
permanent damage to your mower.
• Do not store the battery in proximity to organic or other
solvents.
Balancing the Blade
Important: You must remove the blade from the mower
to sharpen it.
Attention! When sharpening a used blade, be
especially careful to keep it balanced. If in doubt,
replace the blade with a new one.
• An out-of-balance blade causes your machine to vibrate
excessively. Excessive vibration may cause damage to the
Mower, especially to its motor.
• Because you are removing metal from the blade, make
sure to remove an equal amount from each side to keep
the blade balanced.
Of course, you can always have a mower service sharpen and
balance your blade.
3. Storing your mower

24
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
25
• Do not store the battery close to a source of heat, sparks
or open flames.
• Do not expose the battery to abnormal shaking or shocks.
• Store the battery away from children and animals.
• Do not press, bend, or use force on the terminals of battery
• Do not apply heat (such as a soldering iron) to the
terminals of battery
• Regularly observe the external appearance of the battery
and keep it clean and dry. Never use a battery that shows
cracks, changes shape, leaks, or otherwise is obviously
damaged.
Maintaining and Storing
Most difficulties are easy to fix. Consult the troubleshooting
table for common problems and their solutions. If you continue
to experience problems or need repairs beyond these minor
adjustments, contact your local licensed service center for
assistance.
WARNING! ALWAYS switch off the mower, remove
safety key from its socket, and remove battery before
performing any adjustments, maintenance, blade
change, or repairs to your mower.
Problem Possible Cause Corrective Action
Motor fails to
start
Safety key removed from
battery power socket
Put safety key into battery
power socket
safety key has been put into
the socket, but the connection
is not so tight and secure
Take out safety key and put
it into the socket again, to
ensure the tight and secure
plugging
Battery discharged Need to recharge the battery
before every use, only use a
fully charged battery.
Battery is defective Replace with a fully charged
battery
Starting procedure is not
correct
Make sure you follow the
correct starting procedure:
1.Press and hold the safety
button (1). 2.Squeeze the
switch lever(2) towards the
handle. 3.Release the safety
button (1) and hold switch
lever firmly
Mower stops
while mowing
The blade may be blocked. Remove safety key form the
socket, remove battery, turn
the mower over, and check the
blade.
(for reasons other
than releasing the
switch lever)
The battery has been
completely depleted.
Recharge the battery
immediately or replace it with a
fully charged battery.

26
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
27
Problem Possible Cause Corrective Action
Mower is hard to
push
The grass may be too high for
the cutting height.
Raise the cutting height or
narrow your cutting swath and
try again.
The blade, mower deck, or
rear discharge plate may be
clogged with debris.
Remove the safety key from
the socket,, and remove
battery, turn the mower over
on the left side, and check
below the deck. Clear the
debris if necessary.
The mower bogs down or
stalls in heavy grass
Raise the height of Mower. Cut
a narrower swath. Walk more
slowly.
The grass is wet Let the grass dry before
mowing
The battery capacity is not
enough
Charge the battery or replace
with a fully charged battery.
The wheels may not be
rotating freely.
Remove the safety key from
the socket,, and remove
battery, turn the mower over
on the left side, and check the
wheels for damage. Replace
with new wheels if necessary.
Problem Possible Cause Corrective Action
Excessive
vibration or noise
The blade may be loose Remove the safety key from
the socket,, and remove
battery, turn the mower
over on the right side, and
check that the blade is tightly
attached or not, if not, tighten
the blade.
The blade may be unbalanced,
bent, or damaged
Remove the safety key from
the socket, and remove
battery, turn the mower over
on the right side, remove the
blade, and check its condition.
Replace with a new blade if
necessary.
Mower runs,
but cutting
performance is
unsatisfactory, or
there is a loss of
power
The battery is not fully charged Charge the battery 5 hours to
get a full charge
The blade may be dull Remove safety key from the
socket, and remove battery,
turn the mower over on
the right side, and check
the condition of the blade.
Sharpen or replace the blade,
if necessary.
The blade may be bent, loose,
or damaged
Remove the safety key from
the socket, and remove
battery, turn the mower over
on the right side, and check
the condition of the blade.
Sharpen or replace the blade,
if necessary
The grass may be too high or
too thick for the cutting height
Raise the cutting height or
narrow your cutting swath and
try again.
The Mower is moving too fast Slow down a little bit

28
evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower Instruction Manual
Safe. Clean. Green.
29
Problem Possible Cause Corrective Action
Battery loses its
power quickly
The battery is not fully charged Charge the battery 5 hours to
get a full charge ,You will need
to charge the battery at least
five times to achieve maximum
cutting time
The grass may be too high or
too thick
Raise the cutting height or
narrow your cutting swath
The battery may be getting old The battery will need to be
replaced.
Collection bag is
collecting grass
poorly
The collection bag is full Empty the collection bag, and
clean it if necessary.
The grass is too long, or the
Mower is cutting too low
Raise the cutting height
The Mower is moving too fast Slow down
The rear discharge may be
clogged
Remove the safety key from
the socket, and remove
battery, turn the mower over
on the left side, and clean
away any debris from the rear
discharge plate and below the
deck
The mesh holes on the
collection bag are clogged
Clean the collection bag
The collection bag is wet. Allow the collection bag to
dry thoroughly before using it
again.
Limited One-Year Warranty
Thank you for purchasing this product, which has
been made to demanding high quality standards and is
guaranteed for domestic use against manufacturing faults
for a period of 12 months from the date of purchase.
This guarantee does not affect your statutory rights. If your
product fails during this period due to a defect in material or
workmanship when put to personal residential household use,
please return it to the place of purchase. Normal wear and
tear is not covered under the guarantee. For the purposes of
WARNING! Do not attempt to dispose of your battery in
a fire. The cell may explode.
The battery contains Li-ion cells. After their lifetime
has expired, they must not be disposed of as normal
household rubbish, but must be disposed of properly.
Please dispose of the flat battery via you local municipal
disposal point. It is essential to return the battery or to
dispose of it via your local municipal disposal point.
Only hand over the battery in a discharged condition.
the warranty, “personal residential household use” refers to
non-commercial residential use and further excludes misuse,
accidents, or damage due to inadequate maintenance.
This guarantee is invalid if the product has been misused,
subject to neglect, or has been attempted to be repaired by
anyone other than by a licensed service center.
The owner is responsible for replacement of normally wearing
parts including blades and batteries.
Accessories to the machine are not covered by this warranty.
We will not be liable under any circumstances for any
incidental or consequential damages or expenses of any kind,
including, but not limited to, cost of equipment rentals, or cost
of hiring services to perform tasks normally performed by this
battery mower.
Due to continuous product improvement, we reserve the right
to change the product specification without prior notice.
Dispose of used batteries in an evironmentally-friendly
manner

EC DECLARATION OF CONFORMITY
The undersigned, as authorised by: Genpower Ltd
Declares that the following equipment manufactured by Evopower conforms to the Directive: -
2000/14/EC (as amended)
of the European Parliament and of the council on the approximation of the laws of the Member
States relating to the noise emission in the environment by equipment for use outdoors.
Equipment Category: Lawnmower
Product Name/Model: EVO1536Li
Type/Serial No: Pedestrian lawnmower
Cutting Width: 370mm
Net installed power: 36v, 4.0ah
The technical documentation is kept by:
Roland Llewellin, Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW.
The conformity assessment procedure followed was in according with annex VI of the Directive.
Notified Body: The Notified Body of TÜV SÜD Industrie Service GmbH No. 0036
Measured Sound Power Level: 90.6dB(A)
Guaranteed Sound Power Level: 91dB(A)
A copy of this certificate has been submitted to the European Commission and to EU Member
State United Kingdom.
Place of Declaration: Milford Haven
Date: 04/02/2014
Signed by: Roland Llewellin
Position in Company: Director
Name and address of manufacturer or Authorised representative: Genpower Ltd, Isaac Way,
Pembroke Dock, Pembrokeshire, SA72 4RW.
UK After-sales Tel. [phone]
Warranty Registration Form
Thank you for purchasing your Evopower Power Product.
IMPORTANT
Register your product within 7 days of purchase to obtain warranty cover.
Failure to do so may result in loss of warranty cover.
Please keep original purchase invoice, as a copy of this will be required if a warranty
claim is made.
How to register:
Call 01646 663848
Email the details below to: [email protected]
Scan this form and send to the above email address
Fax this form to 01646 663856
Post this form to: Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW
Name:
Address:
Post code:
Telephone No:
Email:
Purchase date:
Purchased from:
Purchase invoice no:
Model No:
Serial No:
Engine No:
30 evopower.co.uk
Evopower EVO1536Li Battery-Powered Lawn Mower

www.evopower.co.uk
GENPOWER LTD
Isaac Way, Pembroke Dock, Pembrokeshire
UNITED KINGDOM, SA72 4RW
T: [phone] F: [phone]
E: [email protected]
