Operator’s Manual
IMPORTANT: Read this manual carefully. It contains information about your
safety and the safety of others. Also become familiar with the controls and
their proper use before you operate the product.
FORM NO. 3322–131
ProLine
62” Mower
for Mid-Size Traction Unit
Model No. 30162 – 990001 & Up

Printed in USA
Introduction
We want you to be completely satisfied with your
new product, so feel free to contact your local
Authorized Service Dealer for help with service,
genuine replacement parts, or other information you
may require.
Whenever you contact your Authorized Service
Dealer or the factory, always know the model and
serial numbers of your product. These numbers will
help the Service Dealer or Service Representative
provide exact information about your specific
product. You will find the model and serial number
plate located in a unique place on the product as
shown below .
1
1074
1. Model and Serial Number Plate
For your convenience, write the product model and
serial numbers in the space below.
Model No:
Serial No.
The warning system in this manual identifies
potential hazards and has special safety messages that
help you and others avoid personal injury, even death.
DANGER, WARNING and CAUTION are signal
words used to identify the level of hazard. However,
regardless of the hazard, be extremely careful.
DANGER signals an extreme hazard that will cause
serious injury or death if the recommended
precautions are not followed.
WARNING signals a hazard that may cause serious
injury or death if the recommended precautions are
not followed.
CAUTION signals a hazard that may cause minor or
moderate injury if the recommended precautions are
not followed.
Two other words are also used to highlight
information. “Important” calls attention to special
mechanical information and “Note” emphasizes
general information worthy of special attention.
The left and right side of the machine is determined
in the normal operator’s position.

1
Contents
Page
Safety and Instruction Decals 2.
. . . . . . . . . . . . .
Assembly 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loose Parts 3 . . . . . . . . . . . . . . . . . . . . . . . . .
Installing the Castor Wheels 4 . . . . . . . . . . .
Installing the Carrier Frame to the Traction Unit
4
Installing the Cutting Deck 5 . . . . . . . . . . . .
Installing the Drive Belt 5 . . . . . . . . . . . . . . .
Installing the Flotation Springs 7 . . . . . . . . .
Operation 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Side Discharge 8 . . . . . . . . . . . . . . . . . . . . . .
Engaging the Mower Blades (PTO) 8 . . . . . .
Adjusting the Height-of-Cut 9 . . . . . . . . . . .
Adjusting Gage Wheels 9 . . . . . . . . . . . . . . .
Adjusting the Flotation Springs 10 . . . . . . . . .
Tips for Mowing Grass 11 . . . . . . . . . . . . . . .
Page
Maintenance 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Interval Chart 12 . . . . . . . . . . . . . . . .
Cutting Blades 12 . . . . . . . . . . . . . . . . . . . . . .
Correcting Cutting Unit Mismatch 15 . . . . . .
Setting the Front-to-Rear Pitch 15 . . . . . . . . .
Setting the Side-to-Side Leveling 16 . . . . . . .
Greasing the Bearings and Bushings 17 . . . . .
Adjust Idler Pulley 18 . . . . . . . . . . . . . . . . . . .
Replacing the Deck Belt 18 . . . . . . . . . . . . . .
Replacing the Drive Belt 19 . . . . . . . . . . . . . .
Replacing the Castor Wheel Fork Bushings 20
Servicing the Castor Wheels and Bearings 21
Replacing the Grass Deflector 22 . . . . . . . . . .
Storage 22 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 23 . . . . . . . . . . . . . . . . . . . . . . . . .

Safety
2
Safety and Instruction Decals
Safety decals and instructions are easily visible to the operator and are located near
any area of potential danger. Replace any decal that is damaged or lost.
See T raction Unit Operator ’s Manual for
Glossary of Safety Symbols
 " !!  #"" #"
&./ - 
 " !  #"" #"
&./ - 
#  "
&./ - 
 " "   " !!
  #  !!
&./ - 
 " ! 
#"" #"
&./ - 

 "  " "! #" #!!
 !!    % !# 
"  ! "  
 "  "
 "
&./ - 
 " % $" "
  "  "   
 !  #"" #"
&./ -  ()/ !,'(
 !  #"" #"
&./ -  ,*+/ !,'(
 !!  #"" #"
&./ - 0 ()/ !,'(

3
Assembly
Loose Parts
Note: Use the chart below to identify parts used for assembly.
DESCRIPTION QTY. USE
Castor Wheel Assembly
Thrust W asher
Spacer
Retaining Ring
2
8
2
2
Install castor wheels to carrier frame
Carrier Frame
Flange Screw 1/2–13 x 1” (25 mm)
Flange Nut 1/2–13
1
6
6
Install carrier frame to traction unit
Adjusting Shaft
Jam Nut 1/2–13
Spacer 1/2” (13 mm)
Spring
Bushing
2
4
2
2
2
Install adjusting shafts
Clevis Pin
Hairpin Cotter
4
4
Install cutting unit to carrier frame
Washer
Cotter Pin
2
2
Install flotation springs
Operator’ s Manual
Parts Catalog
1
1
Read before operating
Ordering parts

Assembly
4
Installing the Castor Wheels
1. Place the (2) thrust washers and spacer onto the
castor wheel fork (Fig. 1).
2. Insert the castor wheel fork into the carrier frame
mounting tube (Fig. 1).
3. Install (2) thrust washers and spacer onto the
castor wheel fork, then secure with a retaining
ring (Fig. 1).

1
4
2
2
5
Figure 1
1. Retaining Ring
2. Thrust W asher (4)
3. Carrier Frame Mounting
Tube
4. Spacer
5. Castor Wheel Fork
Installing the Carrier Frame to
the T raction Unit
1. Align the carrier frame holes with the mounting
holes in the traction unit frame (Fig. 2).
2. Fasten each side of the carrier frame to the
traction unit with three (3) 1/2” x 1” (25 mm)
flange screws and locknuts. Torque the mounting
screws to 60–80 ft-lb (81–109 Nm) (Fig. 2).
2
1

Figure 2
1. Carrier Frame 2. T raction Unit Frame

Assembly
5
Installing the Cutting Deck
1. Position the cutting deck under the carrier frame.
2. Mount the cutting deck to the carrier frame with
four (4) clevis pins and hairpin cotters (Fig. 3).
Note: All four pins must be in the same hole
locations to prevent uneven cutting.
8
11
m-4256
9
10
1
3
5
7
2
4
6
Figure 3
1. 2” (51 mm) Cut Height
2. 2-1/2” (64 mm) Cut Height
3. 3” (76 mm) Cut Height
4. 3-1/2” (89 mm) Cut Height
5. 4” (102 mm) Cut Height
6. 4-1/2” (1 14 mm) Cut
Height
7.
5” (127 mm) Cut Height
8. Clevis Pin
9. Carrier Frame
10. Cutting Deck
11. Hairpin Cotter
Installing the Drive Belt
1. Remove the deck covers from the cutting unit.
2. Install the drive belt around the drive pulley on
the traction unit and the upper groove of the
center spindle pulley. The belt must be between
the belt guides (Fig. 4).
3. Reinstall the deck covers onto the cutting unit.
12
3
4
M-4257
Figure 4
1. Belt Guide (2)
2. T raction Unit Drive Pulley
3. Drive Belt
4. Center Spindle Pulley

Assembly
6
4. Thread two (2) 1/2” jam nuts approximately 9”
(22.8 cm) up on each adjusting shaft (Fig. 5).
5. Slide a 1/2” spacer, spring and bushing onto each
adjusting shaft. Make sure to install the bushing
with the flange end against the spring (Fig. 5).
m–2542
5
1
2
3
46
Figure 5
1. 1/2” Jam Nut (2)
2. 1/2” Spacer
3. Spring
4. Bushing
5.
Adjusting Shaft
6. Locknut (already installed
on Adjusting Shaft)
6. Insert the spring end of the adjusting shaft into
the hole in the deck mounting bracket. Note that
the small end of the bushing fits into the hole in
the deck bracket. Insert the locknut end of the
adjusting shaft into the carrier frame mounting
tab (Fig. 6).
7. To tension the belt, tighten the front jam nut on
each adjusting shaft until the springs are
compressed to 5” (12.7 cm). Measure the spring
compression between the spacer and the bushing
(Fig. 6).
8. Tighten the rear jam nuts (Fig. 6).
2
1
4
3
5
M-4303
Figure 6
1. 5” between the Spacer
and Bushing
2. Deck Mounting Bracket
3. Front Jam Nut
4. Rear Jam Nut
5. Carrier Frame Mounting
Tab
9. Check the position of the belt guides. The guides
should be positioned about 1/8” (3 mm) away
from the belt (Fig. 7). Adjust the belt guides as
necessary.
1
3
m-4257
Figure 7
1. Belt Guide (2) 2. Drive Belt
10. Check the front-to-rear blade pitch. Refer to
Setting the Front-to-Rear Pitch in the
Maintenance section.

Assembly
7
Installing the Flotation Springs
Note: The right side uses the single spring
flotation system (Fig. 9).
1. Move tension bracket rearward into farthest
notch (Fig. 8).
2. Secure cable end to pin on deck support bar with
washer and cotter pin (Fig. 8).
3. Repeat procedure for opposite side of deck
(Fig. 9).
1
2
4
3
M-4259
5
6
Figure 8
1. Tehsion Bracket
2. Cotter Pin
3. Washer
4.
Cable End
5. Deck Support Bar
6. Double Spring (Left Side)
1
2
4
3
5
M-4302
2
Figure
9
1. Tehsion Bracket
2. Cotter Pin
3. Washer
4.
Cable End
5. Deck Support Bar
6. Single Spring (Right Side)

8
Operation
Side Discharge
The mower has a hinged grass deflector that disperses
clippings to the side and down toward the turf.
POTENTIAL HAZARD
•Without the grass deflector or complete
grass catcher assembly mounted in place,
you and others are exposed to blade contact
and thrown debris.
WHAT CAN HAPPEN
•Contact with rotating mower blade(s) and
thrown debris will cause injury or death.
HOW TO AV
OID THE HAZARD
• NEVER r emove the grass deflector from
the mower because the grass deflector
routes material down toward the turf. If the
grass deflector is ever damaged, replace it
immediately.
•Never put your hands or feet under the
mower.
•Never try to clear discharge area or mower
blades unless you move the power take-off
(PTO) to “OFF” and rotate the ignition key
to “OFF.” Also remove the key and pull the
wire(s) off the spark plug(s).
Engaging the Mower Blades
(PTO)
The blade control switch (PTO) in conjunction with
the blade control bail engages and disengages power
to the electric clutch and mower blades.
1. Pull on the upper control bar to stop the machine
(Fig. 10).
2. To engage the blades, squeeze the blade control
bail against the upper control bar.
3. Press the blade control rocker switch forward to
“ON”. Hold the blade control bail against the
control bar while operating.
Note: Repeat the procedure to engage the
mower blades if the blade control bail
is released.
4. To disengage the blades, release the blade
control bail, or push the blade control switch to
the “OFF” position.
13
2

Figure 10
1. Upper Control Bar
2. Blade Control Bail
3. Blade Control Switch
(PTO)
