EXCURSION SXE 1002 EXELLENCE User manual

SXE DAILY EXELLENCE PERFORMANCE
...is all you need

CONGRATULATIONS !
Dealer's Name____________________________
Date of Purchase__________________________
Installaon Shop__________________________
Installaon Date __________________________
CAUTION !
1
EXCURSION
You now own an EXCURSION SXE EXELLENCE Subwoofer, the product of
an uncompromising design and german engineering philosophy. A product made
from Car Audio fanacs who truely believe in the relentless pursuit of perfecon.
A product made for the single goal to be the ulmate choice for SPL Compeon.
EXCURSION Subwoofers are the result of several decades of product improvements,
compeon, innovaon and highest quality parts and control standards in industry.
When properly installed these speakers will provide you with many years of
listening pleasere and are the perfect balance between high fidelity, extreme
performance and long-lasng reliabilty.
Should your SXE Subwoofer ever need a service, Please record your informaon
on the following lines to refer to in the event that you may need it later.
At EXCURSION Intl. we are confident you will have many years of outstanding
enjoyment from your high performance investment. For maximum performance
we recommend that you have your new EXCURSION SXE Subwoofer installed by
an exclusive Authorizied EXCURSION Dealer
To learn more about EXCURSION, please visit us on the World Wide Web at
hp://www.excursion.us
Connous exposure to sound pressure levels in excess of 100dB can cause permanent hearing loss. EXCURSION Speakers are capable
of producing sound pressure levels well over 170dB. Please observe all local sound ordinances while listening to your EXCURSION System.
EXCURSION Intl. acceptss no liability for hearing loss, bodily injury, or property damage due to the result of use or missuse of this product.

2
Kra Pulp Cone with Carbon Fibers in Matrix : The cone and its choice of
material effect almost everything in regard to the Performance Quality of
the sub. While the cone must remain exeponally stable under the stress of
high sound pressure levels a well balanced formula of maximum sffness at
minimum weight is the prior target to go ahead. We at EXCURSION have
set our focus at this keypoint of and for success, which is the single goal for
our EXELLENCE Bastards. We have designed a very light kra pulp sandwich
cone technology with carbon fibers enforcements. This pulped sandwich
structure keeps high parts of internal air chambers which decrease weight,
but increase thickness, sffness and effect in higher damping for lower FS.
The impressiv and stylish looking of ourFull size inversed EXCURSION Dustcap:
inversed dustcap is only the welcome side effect of a very carfully research of its
sound technolgy. We are confident that we are using the lightest dustcap at this
grade of sffness on the market which close an air chamber between dustcap
and cone. Its damping and its high grade Polyproylen surface effect into this
outstanding performance our SXE Bastards fill up your car with voluminous Sound.
The symmetrical 12 Spokes Cast Design 12 Spoke oversized Cast Basket:
made our basket to the most successful Subwoofer part in industry. It
effects into wasngs to design only to be different, if the only goal of SPL
performance is affordable to go with a proven Design. We set our focus on
those parts which are really in trouble at those awaited strokes for record
sound pressure levels and are going with our Rubatek Foam Surrounds and
progressiv spiders in various combinaons in order to controle the madness
The exclusive heart of our EXCURSION EXELLENCE Bastards3" Voice Coils:
are our outstanding 4 layered Aluminium 3" Voice Coil. An economy Formula
of max. lightless at max. load-bearing capacity on reliable aluminium formers
responsible for the Allround Performance these Bastards show up. We ensured with
extra vents in the upper aluminium former a fully air cooling circle flow between pole
piece of motor and perimeter venlaon of the cast basket. This progress at every
stroke they do and keep the coil fully air condioned for maximum performance.
The motor structure of a Subwoofer drives the 500 once Motor Structure:
cone. Just like an engine of a car our fully oversized tripple stacked monster
engines allow your SXE Bastard transfer incredible Speed, turns into outstanding
resoluon, result into the Exellence at all kind of applicaons there are.
If you need the Best for All than our SXE Bastards are your Edge of EXELLENCE.
EXCURSION SXE SUBWOOFER FEATURE

3
EXCURSION
It is recommend that you have your new EXCURSION SXE Sub professionally
installed by your authorizied EXCURSION dealer. This will ensure use of proper
installaon techniques & materials. If you choose to perform your own installaon,
the following instrucon will give you direcon making your purchase complete.
The factors for the port area are manifold and can not be reduced only to depend
on the cone area of the woofer that is used. But at least it is a good advice not to
go with less than 1/7 of the cone area for ported and 1/4 for bandpass enclosures.
While you are building up and tuning your sub system you should use a trial-port.
This should be longer than calculated or recommend. While tuning the system
you can find the best sounding length by shortening the port in aprox 2 cm steps.
The final tuning in the car does not only result out of what you do with the port.
Also the posion of the port in the enclosure and surrounding areas and posion
in the trunk have notable impact. The load-through of rear seats are also uncalcubale
as well size and construcon type of the car. This easy effect with different results.
Please do NOT use carpet or cloth within the port or inside the enclosure. It has
bad effects on the air flow. It is recommend to round up the ends of the port and
ensure a glossy surface where ever the air moves inside the enclosure or port.
The moving air mass will speed up and thank you by producing less side noises.
You can also prevent the port itself from resonang. The techniques are the same
as you know from building enclosures or damping doors. You can use energy
absorbing material or you can raise the sffness of the port by bracing.
To have your subwoofer system playing clear and acurate you must follow the
idea of an acouscal "dead" workplace, with just the moving cone. First of all,
the enclosure itself might be not rigid enough. In most cases you can raise the
sffness by implemenng braces, that connect in best way four walls. Or at least
sff up the baffle against back-wall. You can build enclosures with wallthickness
of many cenmetres, but bracing will have same effect with less weight! Now,
when your enclosure is sff and rigid to save you against bomb aacks, you can
put it in your trunk. Do not forget it is important to fix it in the trunk of your car.
For further direcon consult an authorizied EXCURSION installaon specialst
Pre-Installaon Instrucons:

4
If you are intending to use mulple subwoofers in your system, EXCURSION
recommends having seperate chambers for each subwoofer if the subwoofers
will be operated by different amplified signals. This prevent possible cancellaon.
The use of silicone rubber to seal in a speaker will void the Warranty!WARNING:
If sealing is needed to the speaker gasket, use caulking cord or vinyl weather strip.
IMPORTANT: Never cut any metal that is an integral part of an automobile`s
safety or structural support system.
NOTE: EXCURSION strongly recommends that you operate the complete audio
system at low volume before final installaon of your SXE Series Subwoofers.
This will allow a trial listening test to set maximum volume without distoron.
Make sure that all speaker wiring is fully protected from cung CAUTION:
or wear. Any short circuits developing as a result could severaley damage
the radio unit or amplifier. Make sure that all speaker wires easily reach the
speaker terminals without stress on the wire or connectors.
PREPARING FOR INSTALLATION
Note: The tools listed below may be required for proper installaon.
* An elecric drill with drill bits
* Phillips-head and standard screwdrivers
* Crimping tool and needle-nose pliers
* Silicon sealant or closed cell weather-stripping
* Metal file, Hole saw, Tin Snips, Wire strippers
INSTALLATION PRECAUTIONS
Note: Proceed only if you are a qualified installer otherwise let your dealer do it.
* Always wear protecve eyewear when using tools
* Turn OFF all stereo and other electrical devices before you begin
* Disconenect the (-) negave lead from your vehicle`s baery.
* Keep the speakers in the package unl final installaon.
* Locate fuel lines, brake lines, oil lines, electrical cables when planning installaon.
* Check to see clearance behind the mounng surface before installing speakers.
* When running speaker wires through sheet metal, be sure to use gromments
to properly insualte the wires from metal edges.

EXCURSION
5
SXE-10D2
VC: 2x 2Ohm
Test: 4,2Ohm
Fs: 35,184 Hz
Vas: 23,123 Liter
Qms: 5,248
Qes: 0,463
Qts: 0,426
Mms: 136,893g
BL™: 16,570
SD: 330,06 sqCM
Cms: 0,1495 mm/N
No: 0,21%
Splo: 85,2 dB
Xmax: 18 mm
SXE-10D4
VC: 2x 4Ohm
Test: 6,2Ohm
Fs: 33,377 Hz
Vas: 22,864 Liter
Qms: 4,970
Qes: 0,474
Qts: 0,433
Mms: 153,844 g
BL™: 20.540
SD: 330,06 sqCM
Cms: 0,1478 mm/N
No: 0,173%
Splo: 84,4 dB
Xmax: 18 mm
10" TSP DATAS & ENCLOSURE RECOMMENDATION
Optimum Ported
10" SPL Box :
Internal Volume: 42,8 Liter
VB nett Volume: 38,8 Liter
Port Diameter: 2x 75 mm
Port Length: each 240 mm
F3: 41,5 Hz
FB: 49,4 Hz
Enclosure Metrics
MDF: 19 mm
Wide: 540 mm
Height: 310 mm
Depth: 355 mm
Optimum Ported
10" SQPL Box :
Internal Volume: 40,0 Liter
VB nett Volume: 31,3 Liter
Port Height: 38 mm
Port Wide: 332 mm
Port Length: 390 mm
F3: 44,8 Hz - FB: 53,0 Hz
Enclosure Metrics
MDF: 19 mm
Wide: 370 mm
Height: 400 mm
Depth: 385 mm

6
Optimum Ported
12" SPL Box :
Internal Volume: 56,2 Liter
VB nett Volume: 49,2 Liter
Port Diameter: 2x 100 mm
Port Length: each 250 mm
F3: 46,2 Hz
FB: 55,0 Hz
Enclosure Metrics
MDF: 19 mm
Wide: 540 mm
Height: 360 mm
Depth: 360 mm
Optimum Ported
12" SQPL Box :
Internal Volume: 51,0 Liter
VB nett Volume: 39,0 Liter
Port Wide: 382 mm
Port Height: 42 mm
Port Length: 390 mm
F3: 46,6 Hz - FB: 53,0 Hz
Enclosure Metrics
MDF: 19 mm
Wide: 420 mm
Height: 450 mm
Depth: 380 mm
12" TSP DATAS & ENCLOSURE RECOMMENDATION
SXE-12D2
VC: 2x 2Ohm
Test: 4,2Ohm
Fs: 30,065 Hz
Vas: 52,155 Liter
Qms: 3,743
Qes: 0,643
Qts: 0,549
Mms: 199,007 g
BL™: 15.786
SD: 525 sqCM
Cms: 0,1408 mm/N
No: 0,213%
Splo: 86,3 dB
Xmax: 18 mm
SXE-12D4
VC: 2x 4Ohm
Test: 6,2Ohm
Fs: 31,003 Hz
Vas: 49,111 Liter
Qms: 5,940
Qes: 0,616
Qts: 0,558
Mms: 198,745 g
BL™: 19,747
SD: 525 sqCM
Cms: 0,1326 mm/N
No: 0,23%
Splo: 85,6 dB
Xmax: 18 mm

7
EXCURSION
Optimum Ported
15" SPL Box :
Internal Volume: 70,5 Liter
VB nett Volume: 60,0 Liter
Port Diameter: 2x 100 mm
Port Length: each 250 mm
F3: 41,0 Hz
FB: 50,0 Hz
Enclosure Metrics
MDF: 19 mm
Wide: 630 mm
Height: 420 mm
Depth: 352 mm
Optimum Ported
15" SQPL Box :
Internal Volume: 90,5 Liter
VB nett Volume: 68,4 Liter
Port Wide: 462 mm
Port Height: 52 mm
Port Length: 530 mm
F3: 37,2 Hz - FB: 43,4 Hz
Enclosure Metrics
MDF: 19 mm
Wide: 500 mm
Height: 550 mm
Depth: 425 mmm
15" TSP DATAS & ENCLOSURE RECOMMENDATION
SXE-15D2
VC: 2x 2Ohm
Test: 4,2Ohm
Fs: 24,655
Vas: 172,01 Liter
Qms: 6,427
Qes: 0,658
Qts: 0,597
Mms: 251,65 g
BL™: 15.772
SD: 855 sqCM
Cms: 0,1656 mm/N
No: 0,379%
Splo: 87,8 dB
Xmax: 18 mm
SXE-15D4
VC: 2x 4Ohm
Test: 6,2Ohm
Fs: 24,666 Hz
Vas: 141,453 Liter
Qms: 6,816
Qes: 0,739
Qts: 0,667
Mms: 275,744 g
BL™: 19.948
SD: 855 sqCM
Cms: 0,1362 mm/N
No: 0.278%
Splo: 86,9 dB
Xmax: 18 mm

9
EXCURSION

1410
EXCURSION LIMITED WARRANTY POLICY
EXCURSION Intl. offers limited warranty on EXCURSION products under normal use on the following terms:
.EXCURSION Speakers are to be free of defects in material and workmanship for a period of one year
This warranty applies only to EXCURSION products sold to consumers by Authorizied EXCURSION Dealers
in Germany. Products purchased by consumers from an EXCURSION dealer in another country are covered
only by that country´s Distributor and not by EXCURSION Intl.
This warranty covers only the original purchaser of EXCURSION product. In order to receive service, the
purchaser must provide EXCURSION with the receipt stang the consumer name, dealer, product and date
of purchase.
Products found to be defecve during the warranty period will be repaired or replaced (with a product
deemed to be equivalent) at Excursion`s discreon and will not be liable for incidental or consequenal
damages. EXCURSION will not warranty this product under the following situaons:
* Speakers received with bent frames or water damages
* Abuse such as holes in the cone, surround or ripped spider
* Voice coil damage due to amplifier clipping or distoron
* Product that has not been installed according to this owner manual
Any implied warranes including warranes of fitness for use and merchantability are limited in duraon
to the period of the express warranty set forth above. No person is authorizied to assume for EXCURSION
any other liability in connecon with the sale of this product.
Please call prior your authorizied EXCURSION dealer the product got purchased. In case they
are not accessible call 0961-416-0420 for EXCURSION Customer Service. You must obtain an RA#
(Return Authorizaon Number) to return any product to EXCURSION Intl. The RA number must
be prominently marked on the outside of the shipping carton or the delivery will be refused.
Please pack your return carefully! We are not responsibile for items damaged in shipping.
Return the defecve product along with a copy of the original dated retail sales receipt, plus 10,- EUR
for handling and diagnosc evaluaon to:
EXCURSION Intl. - A Division of CHPW
An: Returns (RA# ........................ )
Neustaedter Str. 20
D-92685 Floss / Germany

EASCA
E
UROPEAN
A S
UTO OUND
A
SSOCIATION
...is all you need
EXCURSION - A Division of CHPW
All Rights reserved - Intl. Trademark No: 010 640 597
Friedrich-Ebert-Str. 42 - D-92637 Weiden / Germany
Tel: [phone] - Fax: [phone]
www.facebook.com/Excursion.us
