FALK Navigator 10 User manual

About Us
Falk Navigation GmbH
Marco-Polo-Str.1
73760 Ostfildern
Falk Navigation GmbH reserves the right to change the information and details given
in this manual without prior notice being given. No part of these documents may be
reproduced or transferred for any purpose whatsoever without the express written
permission of Falk Navigation GmbH, irrespective of by which manner or by which
means this takes place.
All of the trademarks and symbols mentioned in this manual are the sole property of their
respective owners and may therefore not be used for commercial or any other purposes.
As in spite of every effort being made it is never possible to completely prevent all errors and
mistakes, no liability is accepted for the content in this manual being correct. We are always
grateful to receive notification of any errors or mistakes.
© 2009 Falk Navigation GmbH, Ostfildern.
All rights reserved.
Revised September 2009 FMI_5106

Content
1INTRODUCTION........................................................................................................................................ 6
1.1 ABOUT THIS MANUAL ............................................................................................................................. 6
1.2 SAFETY NOTES &MAINTENANCE -CONFORMITY DECLARATION ............................................................ 7
1.3 SAFETY AND HELP FUNCTIONS ............................................................................................................. 10
1.3.1 Theft protection ............................................................................................................................... 10
1.3.2 Screen lock ...................................................................................................................................... 12
1.4 DEVICE SPECIFICATION ........................................................................................................................ 13
1.4.1 Memory card slot ............................................................................................................................ 14
1.4.2 Serial number.................................................................................................................................. 14
1.4.3 Technical data................................................................................................................................. 14
1.5 SERVICE &SUPPORT............................................................................................................................. 15
2NAVIGATION ........................................................................................................................................... 16
2.1 START ASSISTANT ................................................................................................................................17
2.2 NAVIGATION SCREEN ........................................................................................................................... 18
2.2.1 Overview ......................................................................................................................................... 18
2.2.2 Reality view (optional) .................................................................................................................... 24
2.2.3 Clickable POIs (optional) ............................................................................................................... 25
2.3 DESTINATION ENTRY ............................................................................................................................ 26
2.3.1 Destination entry by entering an address........................................................................................ 27
2.3.2 Destination entry by selecting the home address (Home) ............................................................... 32
2.3.3 Destination entry by selecting one of the recent destinations ......................................................... 32
2.3.4 Destination entry by selecting a favourite....................................................................................... 32
2.3.5 Destination entry by selecting a special destination (POI) ............................................................. 33
2.3.6 Destination entry by selecting a Travel Guide destination ............................................................. 35
2.3.7 Destination entry using tours .......................................................................................................... 35
2.3.8 Destination entry by clicking on the map - Location....................................................................... 35
2.3.9 Destination entry using geo-coordinates......................................................................................... 36
2.3.10 Entering a destination as a stopover destination........................................................................ 37
2.4 NAVIGATOR FUNCTIONS ....................................................................................................................... 38
2.4.1 NAVIGATION BY LOCAL PUBLIC TRANSPORT –PUBLIC TRANSPORT ...................................................... 38
2.4.2 Destination entry/simulation via the route planner......................................................................... 39
2.4.3 Route options................................................................................................................................... 40
2.4.4 Remember position.......................................................................................................................... 41
2.4.5 Travel Guide.................................................................................................................................... 41
2.4.6 Settings............................................................................................................................................ 42
2.4.7 Making telephone calls - Bluetooth® function (optional)............................................................... 42
2.4.8 Favourites ....................................................................................................................................... 42
2.4.9 Rerouting......................................................................................................................................... 43
2.4.10 Tours........................................................................................................................................... 45
2.4.11 Next destination .......................................................................................................................... 46
2.4.12 SOS (optional)/ “My location” function ..................................................................................... 47
2.4.13 Trip computer – Configure route information ............................................................................ 48
2.4.14 Profiles........................................................................................................................................ 49
2.4.15 Extras (optional) ......................................................................................................................... 49
2.4.16 Help ............................................................................................................................................ 49
2.4.17 Menu order ................................................................................................................................. 49
2.4.18 Delete route/manual mode.......................................................................................................... 50
2.4.19 Route list ..................................................................................................................................... 50
2.4.20 Public transport connection .............................................................................................................. 50

2.5 NAVIGATOR SETTINGS.......................................................................................................................... 51
2.5.1 Map display..................................................................................................................................... 51
2.5.2 Volume ............................................................................................................................................ 52
2.5.3 Speed camera detector .................................................................................................................... 52
2.5.4 Brightness........................................................................................................................................ 53
2.5.5 Speed warner................................................................................................................................... 54
2.5.6 Day/night mode ............................................................................................................................... 54
2.5.7 Setting/changing the home address (Home).................................................................................... 55
2.5.8 Define favourite lists ....................................................................................................................... 55
2.5.9 Speaker output - FM transmitter (optional) .................................................................................... 55
2.5.10 TMC station (optional) ............................................................................................................... 56
2.5.11 Battery......................................................................................................................................... 57
2.5.12 GPS Info...................................................................................................................................... 57
2.5.13 Screen lock.................................................................................................................................. 58
2.5.14 Theft protection........................................................................................................................... 58
2.5.15 Ask route options ........................................................................................................................ 58
2.5.16 Ask departure time ...................................................................................................................... 59
2.5.17 Street names – Text To Speech (optional)................................................................................... 59
2.5.18 Short menu on/off........................................................................................................................ 59
2.5.19 Start navigation automatically on/off ......................................................................................... 59
2.5.20 Voice control (optional).............................................................................................................. 60
2.5.21 Kilometres - Select unit of measurement..................................................................................... 60
2.5.22 Clear history ............................................................................................................................... 60
2.5.23 Default settings ........................................................................................................................... 60
2.5.24 Language .................................................................................................................................... 60
2.5.25 Time ............................................................................................................................................ 61
2.5.26 Screen ......................................................................................................................................... 61
2.5.27 Set rapid access menu................................................................................................................. 61
2.5.28 Info about - Display system information..................................................................................... 61
2.5.29 Copyright .................................................................................................................................... 62
2.5.30 Menu order ................................................................................................................................. 62
2.6 VOICE CONTROL (OPTIONAL)................................................................................................................ 63
2.6.1 Activating voice control .................................................................................................................. 63
2.6.2 Using voice control to enter a destination ...................................................................................... 64
2.6.3 Voice control from the navigation view........................................................................................... 66
2.6.4 Voice control - Short command....................................................................................................... 67
2.7 BLUETOOTH®FUNCTION (OPTIONAL).................................................................................................. 68
2.7.1 Connecting devices.......................................................................................................................... 68
2.7.2 Making telephone calls.................................................................................................................... 69
2.7.3 SMS (optional) ................................................................................................................................73
2.7.4 File manager ................................................................................................................................... 74
2.7.5 Hands-free....................................................................................................................................... 76
3TRAVEL GUIDE (OPTIONAL) .............................................................................................................. 77
3.1 ESTABLISHING A STARTING POINT ........................................................................................................ 77
3.2 TRAVEL GUIDE THEME CATEGORY ....................................................................................................... 78
3.2.1 Top Highlights................................................................................................................................. 78
3.2.2 Favourite lists.................................................................................................................................. 79
3.2.3 Favourites ....................................................................................................................................... 80
3.2.4 Attractions....................................................................................................................................... 81
3.2.5 Museums.......................................................................................................................................... 82
3.2.6 Eating & Drinking........................................................................................................................... 83
3.2.7 Shopping.......................................................................................................................................... 84
3.2.8 Overnight Accommodation.............................................................................................................. 85
3.2.9 In the Evening ................................................................................................................................. 86
3.2.10 Trade Fairs & Transport ............................................................................................................ 87
3.2.11 Art & Culture .............................................................................................................................. 88
3.2.12 All Categories ............................................................................................................................. 89
3.3 DETAILED VIEW OF A SPECIAL DESTINATION ........................................................................................ 91

4EXTRAS - MULTIMEDIA PACKAGE (OPTIONAL).......................................................................... 94
4.1 ADDRESS BOOK (OPTIONAL)................................................................................................................. 94
4.2 PICTURE VIEWER (OPTIONAL) .............................................................................................................. 96
4.3 CURRENCY CONVERTER/CALCULATOR (OPTIONAL).............................................................................. 97
4.4 TRANSLATOR (OPTIONAL) .................................................................................................................... 99
4.5 MP3 PLAYER (OPTIONAL) .................................................................................................................. 100
4.6 GAMES –BUBBLEBREAKER (OPTIONAL) ............................................................................................ 101
4.7 GAMES –GALAXY (OPTIONAL) .......................................................................................................... 101
4.8 GAMES –SUDOKU (OPTIONAL)........................................................................................................... 102
5FALK NAVI-MANAGER ....................................................................................................................... 103
5.1 INTRODUCTION TO THE FALK NAVI-MANAGER .................................................................................. 103
5.1.1 First start....................................................................................................................................... 104
5.2 TRANSFERRING CONTENT ................................................................................................................... 105
5.2.1 FALK NEWEST MAPS ........................................................................................................................... 106
5.3 COMPILING A TOUR OF YOUR OWN ON YOUR PC ................................................................................ 106
5.4 IMPORTING POIS................................................................................................................................107
5.5 FALK ONLINE COMMUNITY “PLACES.FALK.DE” ................................................................................. 109
5.5.1 Use “Favourite lists” from the Community .................................................................................. 110
5.5.2 Upload new “Favourites”............................................................................................................. 110
5.5.3 Upload new and amended ratings................................................................................................. 110
6APPENDIX ............................................................................................................................................... 111
6.1 GLOSSARY.......................................................................................................................................... 111
6.2 TROUBLESHOOTING............................................................................................................................ 114
6.3 LICENCE TERMS AND CONDITIONS FOR THE FALK NAVIGATOR AND NAVI-MANAGER ....................... 116

1 Introduction
Congratulations on your purchase of a mobile Falk navigation device with the new Falk
Navigator.
With the Falk Navigator, you have purchased a product that was developed and tested with
the utmost care. It meets the highest functionality and operating requirements.
Nevertheless, should you have any suggestions or comments that would allow us to make
our products even better, we would be glad to hear from you.
The Falk Navigator manual will teach you all about the extensive functions of your navigation
device. Furthermore, problems which are caused by possible operating errors can be
avoided by reading this manual.
We wish you lots of enjoyment, a good trip, and safe arrival with your mobile Falk navigation
device.
1.1 About this manual
The functions of your Falk Navigator navigation software are described in detail in the
following chapters of this manual. Some chapters are dedicated to functions or optional
accessories that only apply to specific products in the Falk family. Chapters that describe
optional functions or accessories are identified as “optional” in the manual.
The product description on the original packaging of your product will tell you whether you
can use these functions with your product. The packaging also indicates which accessories
are included in the scope of delivery of your product.
The following notation is used in this manual to improve legibility and comprehensibility:
Bold: Important text sections or terms that are used in the Navigator program interface in
the form of labels for the icons used.
Note: Notes are used repeatedly in order to identify important or essential information.
Tip: Tips are pointers designed to make the device easier to use or to solve problems.
In order to ensure you understand the description of the Falk Navigator properly and to avoid
misunderstandings, frequently used terms are explained in detail below.
Note: The screens used in this document show all of the options available in the Falk
Navigator. In the case of products which do not feature all of the functions, these functions
are not displayed on the navigation screen or in the blue bar at the top of the menu. For this
reason, the screens used in the document may differ from those in your navigation system.
In principle, the screens shown in this manual may differ from the screens on your navigation
systems.
User Manual Falk Navigator 10 - 6 -

1.2 Safety notes & maintenance - conformity declaration
Please read through this chapter carefully and follow all of the notes which are provided. This
will ensure reliable operation and a long service life for your device.
•Please establish the required settings and enter your desired destination before you set
off. Never operate your navigation device while driving, since this could distract you from
what is happening on the road and cause an accident.
•Road traffic regulations always take precedence over the instructions provided by the
Falk Navigator. Should this require you to leave the route suggested by your navigation
device, the Falk Navigator will recalculate the route and lead you to your destination
along an alternative route.
•Do not look at the display on your device for a lengthy period of time while driving.
•In order to ensure that the device does not pose a hazard to the vehicle or the occupants
of the vehicle, even in the event of a critical traffic situation such as an emergency stop,
always attach your mobile Falk navigation device in your vehicle using a mounting
bracket recommended by Falk. Ensure that the effectiveness of passive safety systems
in your vehicle such as airbags cannot be impaired by the installation of the bracket.
agnet
from Falk may contain a magnet.
ers (notebooks) or cards (EC cards, credit cards
g on the device and do not allow any objects to fall onto the device from
M
•PNDs
•Do not place near to magnetic data carri
etc.).
•They may be damaged or rendered unusable if they come into contact with the PND.
Operating environment
Outside influences:
Do not place anythin
above.
Do not drop your device and do not shake it either.
User Manual Falk Navigator 10 - 7 -

Do not keep or carry any inflammable liquids, gases or explosives in the same
eption of GPS signals and cause unstable signal
operated and monitored under the sole responsibility of the government of the United
PS satellite signals do not go through solid materials (apart from glass). GPS positioning is
t least 4 GPS satellite signals are required to determine the current GPS position. Signal
ut of your vehicle, do not leave your device lying on the dashboard where it
be stored at temperatures of -20°C – +60°C and be operated at
xcessive moisture and extreme temperatures. The device
This might cause
Falk accessories. Other types of power adapter may cause
ower adapter in damp environments. Never touch the power adapter if your
ufficient ventilation around the power adapter if you are using it to
opriate power source. You will find the voltage
force a plug into a
compartment as your device, its parts or its accessories.
Wireless devices could interfere with the rec
reception.
GPS:
GPS is
States, which is also responsible for ensuring the availability and accuracy of this system.
FMI is therefore unable to accept responsibility for GPS availability and accuracy.
G
therefore not possible within a building.
A
reception may be impaired by bad weather or dense obstacles above the ground (e.g. trees
and tall buildings).
Temperature:
When you get o
might be exposed to sunlight. If the battery overheats, this may result in malfunctions and/or
dangerous situations.
The device may only
temperatures of -10°C – +45°C.
Keep your device away from e
should only be operated and stored in atmospheric humidity of 0% to 90%.
Do not expose your device to sudden extreme temperature fluctuations.
condensation to collect in the device, which might result in damage to the device. When
condensation forms, wait for the device to completely dry out.
Power adapter (optional)
Please only use original
malfunctions and/or serious damage and cancel FMI’s liability for the resulting
consequences.
Do not use the p
hands or feet are wet.
Ensure that there is s
operate the device or to charge the battery. Do not cover the power adapter. Do not use the
power adapter when it is in a carrier bag.
Connect the power adapter to an appr
requirements on the product casing.
Do not use the power adapter if its power cable is damaged. Never
socket.
User Manual Falk Navigator 10 - 8 -

Battery
Only use the original battery and the original car charger which is supplied with it. If you use
other parts, this may result in malfunctions and/or severe damage and cancel FMI’s liability
for the resulting consequences.
This product works with a lithium-ion battery. Do not use it in a damp, wet and/or corrosive
environment. You must not place your product in or next to heat sources, at places which are
subject to high temperatures or extreme sunlight, in a microwave oven or an excess pressure
container, store it or leave it there, and you must also not expose it to any temperatures
above 60°C (140°F). If you do not adhere to these guidelines, this may cause acid to escape
from the lithium-ion battery, cause it to become hot, explode or catch fire and may cause
injuries and/or damage. You must not pierce, open or dismantle the battery. If the battery
leaks and you come into contact with the liquids which have leaked, thoroughly rinse the
areas which have come into contact with water and consult a doctor immediately. For safety
reasons and in order to lengthen the lifetime of the battery, it will not charge at low
temperatures (below 0°C/32°F) or high temperatures (above 45°C/110°F).
Disposal
The symbol on the product or its packaging indicates that this product should not
be treated as normal domestic waste but must instead be deposited at a collection
point for recycling electrical and electronic devices. You can obtain further
information about recycling this product from your local authority, municipal
waste disposal companies or the shop where you bought the product.
WEEE Reg. No. DE 19715620
Aeroplanes and hospitals
The use of electronic devices is prohibited on most aeroplanes, in most hospitals and at lots
of other places. The device must not be used in such environments. Always switch your
device off wherever you are requested to do so.
CE certificates and RoHs
The device conforms to the Directives of R&TTE 1999/5/EC and Directive 2002/95/EC OF
THE EUROPEAN PARLIAMENT AND COUNCIL dated 27 January 2003 on the restriction of
the use of certain hazardous substances in electrical and electronic equipment (ROHS). You
will find detailed conformity declarations in the Service & Support section on our website
www.gofalk.com/nav.
Theft
Please never leave your navigation device unattended, openly on display in your car.
Updating maps and software
You can obtain information about updating software and maps from retailers or in the Falk
Online Shop at shop.gofalk.com/falk
Headphones connection/volume
Hearing experts issue warnings! If audio files etc. are played at a high volume for a lengthy
period of time, this can result in hearing damage.
In dangerous situations, headphones should be used with great caution or they should not be
used for a certain period of time. Never set the volume so high that you can no longer hear
what is going on around you.
User Manual Falk Navigator 10 - 9 -

1.3 Safety and help functions
1.3.1 Theft protection
You can protect your navigation device from being used by unauthorised people by setting
up theft protection with a personal PIN number.
Note: Theft protection can only be activated/changed using the Falk Navi-Manager PC
program (cf. Chapter 5). Your personal PIN number is stored on your PC and can be viewed
again at any time.
Requirements: PC with WinXP
P
TM, Windows VistaTM or Windows 7, active Microsoft®
ActiveSync® (alternatively Microsoft® Mobile Device Center®, component of Windows
VistaTM and Windows 7)
Note: Theft protection satisfies the highest security standards. Please note that, when theft
protection is activated and switched on, there is NO possibility of using your navigation
device without entering the correct PIN number.
Setting up theft protection via the Navi-Manager
Use a USB cable to connect your navigation device to your PC and establish an
ActiveSync® connection.
Choose Define partnership>No and then click on Next.
Start up the Falk Navi-Manager. On the menu of the Navi-Manager select Options>Theft
protection.
Enter a personal PIN with as many digits as you wish (but you may only use numbers) and
make sure you remember it. Confirm by tapping OK.
Disconnect your navigation device from your PC. Theft protection is now set up and
activated.
Changing PIN via Navi-Manager
Note: If a PIN has already been set up and this has been activated on the Settings menu,
you must first enter the PIN in order to be able to establish a connection to the Navi-
Manager.
Use a USB cable to connect your navigation device to your PC and establish an
ActiveSync® connection.
Choose Define partnership>No and then click on Next.
Start up the Falk Navi-Manager. On the menu of the Navi-Manager select Options>Theft
protection.
Change your personal PIN (but you may only use numbers) and make sure you remember it.
Confirm by tapping OK.
Disconnect your navigation device from your PC.
Removing theft protection via Navi-Manager
Note: If a PIN has already been set up and this has been activated on the Settings menu,
you must first enter the PIN in order to be able to establish a connection to the Navi-
Manager.
Use a USB cable to connect your navigation device to your PC and establish an
ActiveSync® connection.
User Manual Falk Navigator 10 - 10 -

Choose Define partnership>No and then click on Next.
Start up the Falk Navi-Manager. In the Navi-Manager select the Theft protection
tab.
Select Remove protection. Theft protection has been deactivated.
Using theft protection
To use theft protection, you must switch off the device completely after each trip by switching
the main power switch 5(cf. Chap. 1.4) on the back (M-Series) or bottom (F-Series) of the
device to OFF.
When you move the switch to ON again, you must enter your PIN to identify yourself.
Switching theft protection on and off
You can switch activated theft protection on and off at any time. Once you have switched it
off, you will not be asked for your PIN again.
To switch the theft protection on and off, go to the main menu and select the option
Settings>Theft protection. The button switches between switching on and off. Confirm your
entry by tapping OK.
Forgotten PIN?
You can view your PIN at any time via the Navi-Manager by connecting your navigation
device to your PC in the manner described above and calling up theft protection in the Navi-
Manager under Options>Theft protection.
Note: The PIN number is stored on your PC; if your PC has been completely formatted or no
longer works, it is not possible to restore your PIN number.
Falk does not accept any liability for expenditure incurred for any service that is required
because you have forgotten your personal PIN number.
User Manual Falk Navigator 10 - 11 -

1.3.2 Screen lock
The screen lock allows you to extend the battery running time of your navigation device. It
also prevents you from accidentally switching on the device or accidentally making entries on
the screen and thus ensures that you do not trigger any functions you do not want to.
Activating screen lock
You activate the screen lock via Settings>
Screen lock.
You have a choice between two basic settings:
Timer: Activates the screen lock according to
your personal presettings. You have a choice
between 1 minute, 3 minutes, 5 minutes and 10
minutes.
Manual: The screen lock is always activated when you manually activate the on/off switch on
the top of the device (6) (cf. Chap. 1.4). This means that audio will continue to be output, but
entries via the screen are no longer possible. For example, you can use your navigation
device with headphones (not included when the product is supplied) as an MP3 Player
(optional) and place the device in a case without accidental tapping on the screen resulting in
entries being made.
The screen is activated again if you touch the slide control on the display. Pressing the on/off
switch on the top of the device again will switch the device off and thus stop any audio
outputs.
Confirm your entry by tapping OK.
Screen lock active
The screen is activated after the device is switched on via the on/off button on the top of the
device or the battery switch on the bottom of the device. You will now see a virtual slide
control which you can use to switch on the device. To do this, place your finger on the touch
screen and move the slide control from top to bottom. The device is now switched on.
If the slide control is not operated within a certain period of time, your navigation device
automatically switches off again.
User Manual Falk Navigator 10 - 12 -

1.4 Device specification
F-Series
M-Series
1. Battery charge indicator: During the charging process the charge indicator glows red. It
glows white or blue (M-Series) when the battery has been fully charged.
2. Touch screen: Displays the Falk Navigator software. Use your fingers to tap on the
screen in order to select menu commands or enter data.
Attention: Do not touch the display with sharp-edged or pointed objects in order to avoid any
damage.
3. Magnet: Magnet for fixing the device in the holding shell.
4. Loudspeaker: Emits spoken instructions and warnings.
5. Main power switch: Controls the main power supply. Slide the switch to “ON” to switch
on the power supply. By sliding the switch to “OFF” you also perform a hard reset on your
device. Switch your device off to activate the theft protection.
6. On/off switch: Switches the device on or off when you press it.
7. Mini-USB cable: Socket for the USB cable for connection to a PC or for connecting the
car charger cable.
8. SD/MMC slot: Slot for receiving an SD (Secure Digital) or MMC (MultiMediaCard) card or
a Micro-SD card with a max. memory capacity of up to 2 GB.
9. Headphones socket/TMC antenna input: Socket for headphones, socket for an external
TMC antenna.
10. Mounting bracket: Mounting bracket for lanyards and hand straps.
User Manual Falk Navigator 10 - 13 -

1.4.1 Memory card slot
You can use a memory card to store map data or audio files (optional). These files can be
recognised and used by the navigation device. For this to happen, you must insert an SD
card which has country maps or audio files (optional) stored on it into the memory card slot
on your device.
Map data:
In order for map data to be recognised, a soft reset must be carried out after inserting the SD
card into the device. Removing the SD card during navigation or even when the device is
turned off causes the software to crash. A soft reset is therefore required every time the SD
card is removed.
1.4.2 Serial number
For some services or offers in the Falk Online Shop, you need
to specify the serial number of your navigation device.
You will find the serial number of your navigation device on the
product sticker on the back of the device beneath the barcode.
It comes after S/N, e.g. S/N: MCA20G0803812
Please enter only the serial number without S/N, so in our
example: MCA20G0803812
1.4.3 Technical data
F-Series
Screen Display 4.3“, colour, LED Backlight
Resolution
Brightness
480 × 272, WQVGA resolution
400cd/m2
Memory 1GB, 2 GB or 4GBInternal memory
RAM 64 MB or 128 MB
Memory card slot SD/MMC card slot up to 2 GB or
Micro-SD card slot up to 4 GB
GPS Chip
Antenna
ST-NXP GNS7560
Built-in 12 x 12 ceramic patch antenna
Input / output
Input
Loud speaker
Headphones/TMC
USB
Screen interface, keypad
Built in, 1W or 1.5 W
3.5 mm jack socket for headphones
combined with external TMC antenna socket
USB 2.0 (Mini USB)
TMC Integrated TMC module (external TMC dipole
antenna)
Additional internal TMC module
Battery
Lithium-ion battery, 1300 mAh
Lifespan 3.0 ~ 3.5 hours
Environmental conditions
Operating temperature
Storage
Atmospheric humidity
0~+50 °C
-20~+60 °C min. / max. storage temperature
0~90% atmospheric humidity
User Manual Falk Navigator 10 - 14 -

M-Series
Screen Display 3.5“, colour, LED Backlight
Resolution
Brightness
320 x 240, QVGA resolution
320cd/m2
Internal memory Flash memory 1GB, 2 GB or 4GB
RAM 64 MB
Memory card slot Mini-SD card slot up to 2 GB or
Micro-SD card slot up to 4 GB
GPS Chip
Antenna
ST-NXP GNS7560
Built-in 12 x 12 ceramic patch antenna
Input / output
Input
Loud speaker
Headphones/TMC
USB
Screen interface, keypad
Built in 1W
3.5 mm jack socket for headphones
combined with external TMC antenna socket
USB 2.0 (Mini USB)
TMC
Integrated TMC module (external TMC dipole
antenna)
Battery
Lifespan
Lithium-ion battery , 750 mAh
2.0 ~ 2.5 hours
Environmental conditions
Operating temperature
Storage
0~+50 °C
-20~+60 °C min. / max. storage temperature
Atmospheric humidity 0~90% atmospheric humidity
1.5 Service & support
If you experience any problems with the Falk Navigator, you can contact our telephone
support service.
Hotline:
Germany: 01805 32 55 46 (0.14 EUR/min. from a German landline, mobile prices may vary)
Switzerland: 0848 20 12 12 (cost of call 0.11 SFR/min.)
Austria: 0820 20 12 12 (cost of call 0.15 EUR/min.)
Internet: www.falk.de/navigation
Note on service: Please ensure before sending in your navigation device that theft
protection has been deactivated as otherwise it is not possible to search for errors or make
repairs.
The PIN number is stored on your PC; if your PC has been completely formatted or no longer
works, it is not possible to restore your PIN number.
Falk does not accept any liability for expenditure incurred for any service that is required
because you have forgotten your personal PIN number.
If the PIN number is activated when you send your device in to Falk Service (plus Service
fee), you will be charged the costs of sending it back.
Please also note the instructions given in our Service & Support section on the Internet at
www.falk.de/navigation.
User Manual Falk Navigator 10 - 15 -

2 Navigation
The Falk Navigator provides you with extensive
functions which you can operate with ease from
the main menu.
The first page of the menu provides an easy
introduction to the most important navigation
functions.
Select Destination entry to navigate to a
destination directly.
Define a Home address in order to be guided
home quickly and without any fuss from any
location you find yourself at. Once you have
defined a Home address, the view switches to
“Home“.
From the start menu you can access the
Navigation view by tapping on Map.
The Settings button takes you to the Settings
menu where you can configure your navigation
device to your own particular needs. On the Main menu you can access other convenient
functions of the Falk Navigator.
The following chapter describes the navigation functions in detail.
User Manual Falk Navigator 10 - 16 -

2.1 Start Assistant
The first time you turn on your navigation device or after you reset it to the factory default
settings (cf. Chap. 2.5.23), the Start Assistant guides you through the essential Basic
settings (cf. Chapter 2.5).
In the first part you define the Language which is to be used, the Speaker (optional), the
Country map and the Time zone. This request cannot be skipped.
You can then make further optional settings which will each be explained to you in brief.
Optional settings:
•Profiles
•Route option
•Options for the map display
•Navigation settings
•Volume
•Brightness
•Day and night mode
•Top speed warner
•Theft protection
•Define Home
Tap on Next to make further settings. Tap on Information to read the explanations again.
Tap on Ok to save your entries.
You can tap on Cancel to exit the Start Assistant. Your entries will not be saved.
Note: The Start Assistant can be called up again. To do this, select Settings>Start
Assistant.
You can use the Settings menu to adjust your settings at any time.
If necessary, you can restore the device to its default settings. To do this, select Settings >
Default settings.
User Manual Falk Navigator 10 - 17 -

2.2 Navigation screen
In addition to your current position on the map view, the navigation screen also provides you
with lots of extra information.
Safety note: The menus on the navigation screen which contain additional information
should not be operated while you are driving as this may divert your attention from the road.
Your current position is marked on the map view by a red arrow.
The route which has been calculated by the Falk Navigator and on which you are travelling
has a blue background on the map view. This allows you to see ahead to where the route is
taking you.
You can get to the main menu of the application at any time by tapping on the main
menu button.
2.2.1 Overview
A Information bar
The information bar shows the next street name and, if applicable, the associated road
number. When you are on a main road or motorway, additional direction indicators and exit
numbers are displayed before a turnoff. This means that you are informed about the main
road or motorway number or exit you will take next. This number is displayed in conjunction
with a corresponding symbol.
Note: If your next manoeuvre is more than 5 km away, the information bar is hidden. If you
are in Position Tracking mode, the information bar is automatically hidden.
User Manual Falk Navigator 10 - 18 -

Zoom – Map extract: You can use the +/- buttons to enlarge or reduce the size of
the map extract (zoom in and out). If you activate one of the buttons, a slide
control also appears which you can use to infinitely adjust the map size you desire. To do
this, tap on the relevant point on the guide line.
B Display area (status symbol)
The display area shows you what is currently going on by way of the status symbols.
Depending on the status, the symbols may only be displayed temporarily. The following
status symbols can be displayed.
Profile: The symbols Car , Motorbike Bicycle and Pedestrian tell you which
profile you have currently set.
Compass: The compass symbol is used to display the direction in which you are
travelling.
GPS quality: The satellite symbol shows the GPS quality currently available.
Red: Insufficient GPS signal to determine your position. Signals are being received from
fewer than 3 satellites.
Yellow: The GPS signal is sufficient to determine your position, but not sufficient to
determine elevation. Signals are being received from 3 satellites.
Green: You are receiving a high-quality GPS signal that allows your elevation to be
determined. Signals are being received from at least 4 satellites.
Battery: The battery indicator shows the remaining battery capacity for the device. It is
first shown on the navigation screen when the remaining capacity falls to less than 30%.
Once the remaining capacity falls below 15%, the battery indicator is shown in red. When the
battery capacity drops below 10%, a prompt is displayed on the screen asking you to
connect your device to a power supply. Once the device has been connected to a power
source, the symbol indicates that the navigation device is currently charging.
Mute: If you mute the system volume controls, this is indicated on the navigation screen
by a loudspeaker symbol with a line through it.
Note: You can adjust the system volume settings via the rapid access menu or the settings
menu. To do this, tap the loudspeaker symbol on the navigation screen.
Mobile phone (optional): This symbol is shown if there is an active phone connection as
part of the Bluetooth® function which has been activated. If the mobile phone symbol is
displayed, the mute symbol is switched off. Please consult Chapter 2.7 for more detailed
information on how to make phone calls using Bluetooth®.
Speed camera detector (optional): The warning triangle tells you if you have activated
the speed camera detector or not. If you encounter a fixed speed camera on your journey,
you will see a corresponding alert icon along the route on the navigation screen. Please
consult the Navigator settings chapter 2.5 for details on how to activate the speed camera
detector.
Note: If you have downloaded speed camera detector data from the Internet onto your
navigation device using the PC program Falk Navi-Manager (cf. Chap. 5) and activated this
data via the Settings menu, you will, on the basis of what speed is permitted, receive a visual
and audible warning for the first time at least 50 m before a fixed speed camera and for the
second time at least 15 m before a fixed speed camera.
User Manual Falk Navigator 10 - 19 -

Note: For terms and conditions on the use of the speed camera detector, please
consult Chapter 2.5.3.
C Map
The scale of the map display is dependent on the speed you are travelling at. The more
slowly you drive, the more detailed a map will be displayed.
Note: The autozoom functions can be deactivated via the Settings menu (cf. Map display
2.5.1).
Moving the map: The section of the map which is displayed can be moved. To do this, tap
the map and, at the same time, drag it in the direction you want to see. This allows you to
follow the path of the calculated route.
If you want to realign the vehicle position in the map in the direction of travel, tap on the
Centre button which is displayed on the navigation screen when moving the map.
Map scale: The display shows you which scale is currently being
used. When you press the zoom button, the map scale is shown to you on the info bar on the
2D view. The scale of the map display will change dynamically depending on the speed of
your vehicle and the zoom level which is set.
D Rapid access menu – Functions
The rapid access menu features a large number of functions and
settings which you can activate or change during navigation
without having to stop navigating.
Rapid access menu
Via the Functions rapid access menu, you can call up information, make settings or
activate functions.
You can adapt the functions which are available on the rapid access menu to reflect your
own personal needs in the settings menu under Settings>Rapid access menu (see Chap.
2.5.27 Set rapid access menu ).
All functions and settings are described in the following chapters.
E Rapid access menu- TMC traffic messages (optional)
Depending on the TMC settings you made in the TMC settings menu, your Falk
Navigator receives TMC and/or TMCpro (optional) traffic messages during your trip and
processes this information during route calculation. A coloured bar continuously indicates the
TMC status on the navigation screen.
Grey: No reception of TMC or TMCpro traffic messages.
Possible causes may be:
•TMC/TMCpro (optional) are deactivated on the Settings menu
•The TMC antenna is positioned incorrectly
•An unknown TMC encryption format is being received
•No TMC station is available in the region
•Your product is not TMC/TMCpro-compatible (not supplied with all products)
Green: A TMC transmitter is being received. However, there are no current TMC messages
regarding traffic problems.
User Manual Falk Navigator 10 - 20 -
