Faroudja Dvp4000 User manual

DVP4000

Digital Video Processor

Installation and

Operations Manual

NTSC/PAL Model

™

QUICK START

INSTRUCTIONS

The DVP4000 requires only a few adjustments to

be set for proper operation. However, since the

processor must be integrated with a display device,

and the settings on one will affect the other, careful

attention must be made to the settings on both

products.

CONNECTIONS

Read the complete Owner’s Manual for the DVP4000

before installation.

Also review the owner’s manual of the display. Most

display devices require specific settings to properly

integrate with an external processor.

Be sure to connect all sources to the proper inputs of

the DVP4000.

Note on DVDs: For proper aspect ratio and to insure

the highest quality image from the DVD player, be

sure to set the DVD screen shape to 16:9 in the DVD

player's Setup menu. See the DVD player's owner's

manual for details

Connect the proper cables from the output of the

DVP4000 to the display device and audio processor.

Be sure the cables are not crossed.

DVP4000 SETUP

•Plug the processor into the wall power.

The unit will go through initialization identifying

the output resolution.

•Turn the unit on and press the Setup button

on the front panel to enter the Setup menu.

Press Return again to return to the User Menu.

•Use the Function Up/Down buttons to select

different Functions, press the Left/ Right

buttons to change Values.

•Select Digital (DVI) or Analog (BNCs) output

•Select output type. When using the analog

output, RGBHV is recommended.

•Select the proper output scan rate.

•Composite Sync on H should be Off.

•Select the screen shape of your display.

DISPLAY POSITION AND

ALIGNMENT

The next step in the setup procedure is to align the

display device to the processor. Be sure to follow all

directions for setting up the display found in the

display’s manual. Using a test DVD with the Safe

Area test pattern, align the image size, position and

blanking first using the controls found in the display

device. Only use these controls in the DVP4000 if the

display device does not offer these controls or if there

is not enough range.

Note: Some displays do not respond to the H & V

position controls when using DVI.

SETTING DISPLAY PROFILES

The DVP4000 stores up to eight profiles for NTSC

and eight profiles for PAL. Each profile stored

contains all the settings for the unit at the time the

information was stored. This allows the installer to

store scan rates, screen shapes, etc. for multiple

displays that may be using in the theater. Store the

current settings by selecting the profile number (1-8)

in the OSD and then hit Store on the remote. Profiles

can also be stored in the Setup menu. See the

manual for more details.

IMAGE ALIGNMENT

The final step is optimizing the image. Use a test

pattern DVD to optimize the display and processor.

Set the brightness and contrast using the controls in

the display.

Adjust the gray scale of the display using the color

temperature controls in the display.

Reduce the detail or sharpness control in the display

to 0 or 1 (if available).

Using video material, adjust the Detail on the

DVP4000. Use of the Detail circuit is affected by the

quality of the material being viewed. High quality

sources need a lower Detail setting. DVDs or satellite

sources that are poor quality (compression artifacts)

can be cleaned up by reducing the detail level. Low

bandwidth sources such as VHS can be improved by

increasing the detail. Customized settings can be

stored as Profiles.

QUICK START OPERATION MENU

image could be burned in to the display device. Use

special care when projecting video games or

computer program images.

About the installation place

Do not install the processor in a place that cannot

support its weight securely, or that does not allow

for proper heat ventilation.

IMPORTANT SAFEGUARDS

IMPROPER USE OF THIS EQUIPMENT CAN

RESULT IN POTENTIAL ELECTRICAL SHOCK

OR FIRE HAZARD.

In order not to defeat the safeguards incorporated

into this product, observe the following basic rules for

its installation, use and service.

– All the safety and operating instructions should be

read before the product is operated.

– The safety and operating instructions should be

followed and retained for future reference.

– All warnings on the product and in the operating

instructions should be adhered to.

– Unplug this product from the wall outlet before

cleaning. Do not use liquid cleaners or aerosol

cleaners. Use a damp cloth for cleaning.

– Do not use attachments not recommended by the

product manufacturer as they may be hazardous.

– Do not use this product near water. Do not use

immediately after moving from a low temperature to

high temperature, as this causes condensation,

which may result in fire, electric shock, or other

hazards.

– Do not place this product on an unstable cart,

stand, or table. The product may fall, causing serious

injury to a child or adult, and serious damage to the

product. The product should be mounted according

to the manufacturer’s instructions, and should use a

mount recommended by the manufacturer.

– When the product is used on a cart, care should be

taken to avoid quick stops, excessive force, and

uneven surfaces which may cause the product and

cart to overturn, damaging equipment or causing

possible injury to the operator.

– Slots and openings in the cabinet are provided for

ventilation. These ensure reliable operation of the

product and protect it from overheating. These

openings must not be blocked or covered. (The

openings should never be blocked by placing the

product on bed, sofa, rug, or similar surface. It should

not be placed in a built-in installation such as a

bookcase or rack unless proper ventilation is

provided and the manufacturer’s instructions have

been adhered to.)

iii

SAFETY PRECAUTIONS

SAFETY

PRECAUTIONS

IMPORTANT INFORMATION

WARNING : TO PREVENT FIRE OR SHOCK

HAZARDS, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION :

To reduce the risk of electric shock, do not remove

cover. Refer servicing to qualified service personnel.

This product is equipped with a 3-blade grounding-

type plug to satisfy UL, CUL, TUV, FCC rules.

If you are unable to insert the plug into the outlet,

contact your electrician.

FCC INFORMATION (U.S.A. ONLY)

CAUTION :

Changes or modifications not approved by Faroudja

could void the user’s authority to operate the

equipment.

Note: This equipment has been tested and found to

comply with the limits for a Class B digital devices,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection

against harmful interference in a residential

installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may

cause harmful interference to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation. If this equipment

does cause harmful interference to radio or television

reception, which can be determined by turning the

equipment off and on, the user is encourage to try to

correct the interference by one or more of the

following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment.

– Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV

technician for help.

About burning-in of the display device

Do not allow the same still picture to be projected for

a long time or an abnormally bright video picture to

be projected. Do not project video images with high-

intensity or high contrast on a screen. The video
