FDS FD932DVD-BLU-2 VER HDSDI User manual

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 1 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Installation and Operation Manual
FD932DVD-BLU-2
FD932DVD-BLU-2 VER HDSDI
Blu-ray/DVD/CD/MP3 Player

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 2 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Specifications
Disc Player
FD932DVD-BLU-2
FD932DVD-BLU-2 VER HDSDI
Technology
Blu-ray / DVD
Blu-ray / DVD
NTSC Supported Formats
(59.94/60 Hz)
1080P/1080i/720p/480p/480i
1080p/1080i/720p
PAL Supported Formats
(50 Hz)
1080p/1080i/720p/576p/576i
1080p/1080i/720p/576i
Audio Outputs
Analog and SPDIF Digital
2-Channel Stereo
Analog and SPDIF Digital
2-Channel Stereo
Playback Media
CD-ROM/DVD-ROM/DVD-R
DVD-RW/Audio/CD/CD-R/CD-
RW
CD-ROM/DVD-ROM/DVD-R
DVD-RW/Audio/CD/CD-R/CD-
RW
Playback Formats
VC-1/MPEG2/JPEG/MP3
VC-1/MPEG2/JPEG/MP3
Power
Power
28VDC 750mA
28VDC 750mA
Inrush Current
14.8 Amps peak
4.0Amps @50µS
0.8 Amp Steady State @100µS
14.8 Amps peak
4.0Amps @50µS
0.8 Amp Steady State @100µS
Environmental
Conditions
Operating Temperatures
0-50ºC (32-122ºF)
0-50ºC (32-122ºF)
Dimensions
External
6.98” (W) x 2.60” (H) x 8.57” (D)
6.98” (W) x 2.60” (H) x 8.57” (D)
External w/ Mounting
Brackets
8.25” (W) x 2.60” (H) x 8.57” (D)
8.25” (W) x 2.60” (H) x 8.57” (D)
Weight
3 lbs.
3.3 lbs.
Materials
Aluminum
Aluminum
Features
Menu Control
IR, included & 5’ IR Extension
Cable, RS485, CAN, Physical
Buttons
IR, included & 5’ IR Extension
Cable, RS485, CAN, Physical
Buttons
User Manual
Qualified
Testing
RTCA DO-160G
Section 21 Category B
Section 7 Category B
Section 21 Category B
Section 7 Category B

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 3 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Connectivity
PRODUCT
CERTIFICATIONS
INPUTS
OUTPUTS
COMMUNICATION
PMA
VGA
S-VIDEO
COMP
DISPLAY PORT
HDMI
DVI-D
HDSDI
VGA
S-VIDEO
COMPOSITE
HDMI
DVI-D
SD-SDI
HD-SDI
3G-SDI
RS232
RS485 CONTROL
CAN
IR REMOTE
FD932DVD-
BLU-2
✓
1*
1
1
1
1
FD932DVD-
BLU-2
VER HDSDI
✓
1*
1
1
1
1
1
* = NTSC or PAL (Depending on the Disc)
Blu-ray playback through HDMI requires a HDCP compatible monitor.

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 4 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Table of Contents
General Information ................................................................................................... 5
Features ...................................................................................................................... 5
Front View................................................................................................................... 5
Discs Supported......................................................................................................... 6
Installation Instructions............................................................................................. 7
Rear Panel Output...................................................................................................... 8
Assembly of Connector Spring Latch ...................................................................... 9
Video Wiring Suggestions....................................................................................... 10
Audio Wiring............................................................................................................. 11
Power and Ground Wiring ....................................................................................... 12
HDMI.......................................................................................................................... 13
Power/Video.............................................................................................................. 14
RS485 Controls......................................................................................................... 15
Remote Control ........................................................................................................ 16
RS485 Commands.................................................................................................... 17
Infrared Control ........................................................................................................ 18
Operating Instructions............................................................................................. 19
Operating with Remote............................................................................................ 20
Special Features....................................................................................................... 21
Region Codes ........................................................................................................... 22
Technical Drawing............................................................................................... 23-24
Technical Support/Airworthiness ........................................................................... 25
Warranty.................................................................................................................... 26
Log of Revisions ...................................................................................................... 27

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 5 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
General Information
The FD932DVD-BLU-2 (VER HDSDI) player is a combo Blu-ray/DVD player that allows
playback up to 1080P/60Hz. This is a slot load disc player which allows for mounting in
various angles within the aircraft.
Features
•Plays Blu-ray High-Definition discs (selectable output resolution: 1080p/60 Hz
signals available through HDMI and SDI output only)
•Selectable 720p/1080i/1080p video up conversion for DVD
•Outputs for the FD932DVD-BLU-2 include (1) Composite Video and (1) HDMI
•Outputs for the FD932DVD-BLU-2 VER HDSDI include (1) Composite Video
and (1) SDI
•Analog and digital audio outputs
•2-channel stereo audio outputs
•Blu-ray playback through HDMI requires a HDCP compatible monitor
Front View
Caution
This Digital Video Disc player employs a laser system.
Use of controls, adjustments or the performance of procedures other than those specified
may result in hazardous exposure to radiation. To prevent direct exposure to laser beam,
do not try to open the enclosure. DO NOT STARE INTO BEAM.

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 6 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Ventilation
Slots and openings in the player are provided for ventilation, to ensure correct operation of
the product. These openings protect the unit from overheating and must not be blocked or
covered. It is recommended that the player have a minimum 1-inch of ventilation around
the unit and not be installed in a location that does not have circulating air.
The following types of discs are supported
Notes:
•Writeable discs (DVD-RW, DVD-R) must be finalized, VR-mode only.
•Playback may not work for some types of discs, or when specific operations, such as angle change
and aspect ratio adjustment, are being performed. Information about the discs is written in detail on
the box. Please refer to this if necessary.
•Do not allow the disc to become dirty or scratched. Fingerprints, dirt, dust, scratches or deposits of
cigarette smoke on the recording surface will disrupt the proper operation and may prevent playback
of the disc.
•MP3 files must be written to the disc with an .mp3 file extension in order to be recognized and played
back properly.
•High bitrate or variable bitrate .mp3 and .wma files may not play back correctly.JPEG picture files
must be written to the disc with a .jpeg or .jpg file extension in order to be recognized and played back
properly.
Due to differing menu formats among Blu-ray and standard DVD-videos, the enter key may be
required to start some movies at the home screen, while the play key is required to start other
movies at the home screen. This can occur on both Blu-ray and standard DVD movies. If a movie
does not start when prompted, try using the enter button if play does not respond, or press the
play button if enter does not respond. Again, this is a function of individual Blu-ray and DVD
Discs, not the player.

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 7 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Installation Instructions
All cabin entertainment equipment, such as the FD932DVD-BLU-2 (VER HDSDI), should be
installed on a non-essential bus and have a dedicated circuit breaker. The units include two
angle mounting brackets which can be installed at the top or bottom on each side of the
player. The FD932DVD-BLU-2 player also includes a strain relief bracket which is used to
secure the HDMI cable in place with a 3/16” cable tie. NOTE: Care should be taken to
ensure the units are not installed in an area with poor ventilation, or in an area with
excessive heat.

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 8 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Rear Panel Output/Mechanicals
1. VIDEO OUTPUT
HDMI Video output to HD monitor with HDMI connector (FD932DVD-BLU-2)
SDI Video output to HD monitor or switch with BNC Connector (FD932DVD-BLU-2 VER
HDSDI)
2. POWER/GROUND INPUT & AUDIO OUT, IR Extension, CAN BUS, RS-485
3. Composite/NTSC/PAL Video Output for Interface to Non-HD Displays
FD932DVD-BLU-2
HDMI Output
Composite Power 28 VDC Power
Video Output LED
FD932DVD-BLU-2-HDSDI SDI
Composite Power 28 VDC Power
Video Output LED

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 9 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Assembly of Connector Spring Latch
(WPI Interconnect Products P/N 17-529)

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 10 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Video Wiring Suggestions
Avoid routing video wiring parallel to:
•AC wiring
•Strobe wiring
•DC motor supply cables
•Inverter cabling
•Or any other potential noise source.
The recommended cable for both composite and SDI is PIC 75 Ohm Coax, P/N V75268.
This is a lightweight, flexible, and low signal loss cable which meets FAA flammability
requirements of FAR 23.1359(d), FAR 25.853(a) and FAR 25.869(a)(4).
Similar aviation coaxial cable can be used from other vendors, as well. Some aircraft are
prone to AC noise - we recommend adding to the composite source a 75Ohm video
isolation transformer such as Deerfield Laboratory, Inc. Part No. 162-1
(www.deerfieldlab.com, [phone]. In most cases this should be added to the video
output of the source.

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 11 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Audio Wiring
Audio Wiring for Use with Single Ended Audio Inputs. (i.e.: FDACS)
For best performance, use four individual wires or two twisted pairs in a shielded cable.
The four audio wires would be connected to Left +, Left -, Right +, Right -.
All four wires will run from the Blu-ray player to the destination.
Left + and Right + connect to the Left and Right signal inputs respectively.
Left –and Right –will join together at the destination and connect to the receiving
equipment’s audio return pin. The shield will be connected to the fuselage at one place
only.
Audio Wiring for Use with Balanced Audio Inputs
For best performance, use two twisted pairs in a shielded cable or two individual
shielded twisted pairs.
One pair is connected to Left + and Left -. The other pair connects to Right + and Right
- All four wires will run from the Blu-ray player to the destination.
Left + and Left –connect to the receiving equipment’s Left channel input.
Right + and Right –connect to the receiving equipment’s Right channel input.
The shield will be connected to the fuselage at one place only.
NOTE: The FD932DVD-BLU-2 (VER HDSDI) has high impedance balanced outputs instead
of the more popular low impedance inputs. This is usually not a problem. External audio level
pads may be installed at the installer’s discretion.

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 12 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Power and Ground Wiring
The rated current of the equipment and associated voltage drop should be taken into
consideration when selecting wire gauge. The following example is based on an install
with a 28VDC power system, 1.5-amp equipment load and a total of 50 feet of wire
between the circuit breaker, monitor and ground.
Example: 22awg wire has 16.2 Ohms per 1000 feet, this equates to .81 Ohms for 50 feet.
1.5 Amp of current on .81 Ohms will drop 1.22 Volts.
Resistance of Wire Type M22759/16-**
(** = Gauge)
Gauge (AWG)
OHMS/1000’
24
26.20
22
16.20
20
9.88
16
4.81
12
2.02
10
1.26
8
.701
Also, use short heavy gauge wire and a clean tight connection for ground.
It is the installer's responsibility to understand the product's requirements in order to
install the product in compliance with industry standards and safety.

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 13 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
HDMI HDMI (High-Definition Multimedia Interface) defines the protocol and electrical
specifications for the signalling, pin-out, electrical, and mechanical requirements of cable
and connectors used for transmitting High-Definition content. The Type A HDMI
connector (shown below) has 19 pins with bandwidth to support all SDTV, EDTV, and
HDTV modes. The plug's outside dimensions are 13.9 mm wide by 4.45 mm high. There
is no audio output available on the HDMI cable.
ECS manufactures an HDMI cable that is terminated at the factory. It is ordered as part
number 600-19786-XXX, where XXX is the length in inches for the desired cable.
NOTE: On the following Pinout page, Pin 14, 15, 16 are reserved for CAN BUS integration. The
FD932DVD-BLU-2 (VER HDSDI) is only intended to easily integrate with the FDS Avionics Select
CMS. If more information regarding the CAN BUS integration with this device is required, please
contact FDS Avionics Technical Support at 470-239-7421.

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 14 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Power/Video
P1 (DB-25 Connector –Supplied with Contacts & Hood)
Connector P/N: DB-F25H/or Equivalent
Crimp Contacts P/N: M39029/63-368 or Equivalent
Pin
Number
Description
NOTES:
As with all IFE Equipment,
the Blu-ray requires a separate bus
Blu-ray Wiring Options:
Option 1
Standard Power applied on PIN 1 only,
DO NOT CONNECT POWER @ PIN 3,
Result: When aircraft is powered ON,
Blu-ray must be physically powered
on using the front control panel on
the unit itself or through RS-485 or
CAN. Remote control does not power
the Blu-ray on or off.
Option 2 (Force On)
Standard Power applied on PIN 1,
Results: Aircraft is powered on,
Blue-ray powers on when user applies
28V power to PIN 3. Remote control
does not power the Blu-ray on or off.
1
28 VDC Power Input
2
28 VDC Ground Input
3
Force On
4
Audio L+
5
Audio L-
6
Audio R+
7
Audio R-
8
N/C
9
IR Data
10
IR Ground
11
IR 5V
12
Digital Audio Shield
13
Digital Audio
14
Reserved CAN BUS LO
15
Reserved CAN BUS HI
16
Ground
17
N/C
18
RS485A
19
RS485B
20
RS485 Shield
21
N/C
22
Ground Out
23
Address Ground Pin 1
24
Address Ground Pin 2
25
Address Ground Pin 3

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 15 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
RS485 Controls
Full control of the FD932DVD-BLU-(VER HDSDI) can be achieved through a standard RS485
port on the rear panel. All controls available on the front panel and all controls on the Blu-ray
remote control are supported. Please refer to the DB25 connector diagram in the
FD932DVD-BLU-2 VER HDSDI manual for connection information.
RS485 Port Configuration: The RS-485 port is standard 9600 bauds, no parity, 8 data bits,
1 stop bit, and no flow control. It is standard two wires half duplex.
Command Format: <Prefix><Device ID><Address><Command><Termination>
Prefix: One Character. All RS-485 remote commands must start with the “!” character.
Device ID: Two Characters. “BR” identifies all commands directed to the Blu-ray player.
Address: One character in the range of 0 - 7. See Address section below.
Termination: One Character; ASCII CR. Each command must end with Carriage
Return<CR>.
PA Command: PA on will enable PA interrupt.
Command Notes: Each command number corresponds to a remote-control pushbutton as
shown in the figure shown below. An optional ASCII Line Feed Char permitted after the
Carriage Return character.
Example:
!BR135<CR> will send a command to Blu-ray player number 1 to play.
!BR139<CR> will send a command to Blu-ray player number 1 to stop playback.
!BR039<CR> will send a command to all Blu-ray players to stop playback.
!BR0PAOFF<CR> will disable PA interrupt.

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 16 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
RS485 Commands Cont’d
PA Commands:
“PA ON” will enable PA interrupt.
“PA OFF” will disable PA interrupt.
NOTE: “PA ON” command must be received every 9 seconds or interrupt will time out.
Addresses:
Up to 7 Blu-ray players can easily exist on the same CAN bus. Each unit must have a unique
address assigned to it in the range 1 through 7 to permit the commands issued from the
remote controllers to be received by the correct units. Use the chart below for information on
setting the address of each Blu-ray player. If there is a dot in the pin column of the chart, then
connect that pin to Pin 22. Up to three address pins may be connected to Pin 22 at the same
time.
Examples:
If there is a single Blu-ray player in a system, then it should be set to address 1. The player
will be referenced in all Flight Display Configuration Documents as Blu-ray Player #1 or “The
Blu-ray Player.”
If there are two Blu-ray players in a system, then one should be set to address 1 and the
other should be set to address 2. The player that is set to address 1 will be referenced in all
Flight Display Configuration Documents as Blu-ray Player #1. The other Blu-ray Player will be
referenced as Blu-ray Player #2.
If there are three Blu-ray Players, then the Blu-ray player referenced as Blu-ray #1 in the
Flight Display Configuration Documents should be set to address 1, the Blu-ray player
referenced as Blu-ray #2 should be set to address 2, and the Blu-ray player referenced as
Blu-ray #3 should be set to address 3.
This addressing system is used for all installations containing from one to seven players.
= connect to ground (Pin 22)
Address
Pin 23
Pin 24
Pin 25
F1


F2


F3

F4


F5

F6

F7

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 17 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Remote Control
Actual Remote for button reference
Image for RS485 Control Reference with
command number layover for available
commands. Buttons without numerical
overlays in the above image do not have
available RS485 Commands.
Available Commands

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 18 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Infrared Control
The FD932DVD-BLU-2 (VER HDSDI) has the ability to use an infrared external eye, which is
supplied by FDS Avionics Corp. The following guidelines should be met when using the
external IR eye to insure correct and optimal operation.
•IR Data, IR Ground, and IR 5V pins on DB25 connector listed above are intended
for use by supplied 5’ IR remote receiver only.
•IR Data line can be used on open-collector style IR receivers. The line needs to be
in a Tri-state condition while not in use.
•Contact FDS Avionics before installing different IR control schemes

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 19 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Operating Instructions Using Front panel and Remote Control
In addition to the basic operating controls using the front panel listed above, the remote
control can be used for added functionality. See additional functionality listed on the next
page.
Basic Playback
1. Press the PWR button on the front panel to turn
on your player.
2. Turn on the monitor, then select the input setting
on the monitor that matches the connection
method used to connect your player.
3. Press EJECT to open the disc tray.
4. Place a disc on the disc tray with the label facing
up, then press EJECT to close the disc tray. It
may take a few seconds for the disc to load.
5. If the disc does not start playing automatically,
press PLAY.
6. If a Blu-ray Disc or DVD menu opens, press
PLAY >or ENTER to begin playback.
7. To eject the disc, press EJECT .
NOTES:
The device will enter screen saver status (Black
screen) automatically after five minutes of the
following conditions:
1. Eject or No Disc;
2. “Pause” or “Stop” during MP3/CD/WMA/DVD/
JPEG/BD playback; Pressing any key on remote
control or face panel will deactivate the black
screen saver immediately.
Stop Playback
1. Press the STOP button to go to stop mode,
the monitor screen will show the start logo.
Some discs can recall to the location where it
was stopped, such as a Blu-ray disc.
2. Press PLAY >to resume playback from the
location where playback has been stopped or
from the beginning of the disc.
3. Press STOP twice to stop completely.
Note: Not all Blu-ray Discs support the resume
feature. The resume information is saved even when
the power is turned off.
Playback
1. Press PLAY >to resume normal playback.
Previous and Next
Pressing the PREV will take you back to the
previous chapter unless it is pressed within the
first five seconds of the current chapter. In that
case, it will start at the beginning of the current
chapter. Each press of NEXT key during
playback will skip the current chapter and play
the next one.
Notes:
1. may appear on the monitor during
operation. A means that the operation is not
permitted by the unit or the disc.

Document Number:
MAN –FD932DVD-BLU-2 (VER X)
Rev:
D
Revision Date:
07/11/2017
Page 20 of 27
©2017 FDS Avionics Corp.
All Rights Reserved.
TECHNICAL SUPPORT
470-239-7421 or FDSAvionics.com
Operating with the Remote
Distance: Approximately 7m (23 feet) from 30º 30º
The front of the remote sensor.
Angle: Approximately 30° in each direction of
the remote sensor.
Do not expose the remote sensor
of the unit to a strong light source
such as direct sunlight or other
illumination. If you do so, you may
not be able to operate the unit via
the remote control.
Notes on the remote control
•Point the remote control at the remote sensor of the unit.
•Do not drop or give the remote control an electrical shock.
•Do not leave the remote control near an extremely hot or humid place.
•Do not spill water or put anything wet on the remote control.
•Do not open the remote control.
.
60º
