Fender Jimmie Vaughan Tex Mex Strat User manual

REF.# P/N
3 0083675000 Bone Nut
0019312000 Bushing
DESCRIPTION
1 0053008000 Neck, Jimmie Vaughan Staratocaster, M/N
2 0019309000 Tuning Key, (1) Set
0011357000 Mounting Screw
4 0010389000 String Retainer
0011357000 Mounting Screw
5 0038454000 Truss Rod Adjustment Nut
JIMMIE VAUGHAN STRATOCASTER 0139202
0050669503 2 Tone Sunburst
0050668505 Olympic White
Body Part Number
8 0021453000 Strap Buttom
6 0050668xxx Body, Solid Paint
0050669xxx Body, Sunburst
7 0018353000 Neck Mounting Plate
0015636000 Mounting Screw
0015610000 Mounting Screw
0019056000 Felt Washer, Black
9 0053009000 Pickguard, Jimmie Vaughan Strat
0015578000 Mounting Screw
11 0050658000 Pickup, Middle, Tex Mex
12 0053011000 Pickup, Bridge, Tex Mex
0048631000 Mounting Screw
0036481000 Tubing, Latex Cut
13 0013446000 Control, 250k, Taper, (3)
0016352000 Mounting Hex Nut
0022384000 Lock Washer, Intl
14 0056149000 Knob, Volume, Aged White
10 0050657000 Pickup, Neck, Tex Mex
0038467000 Truss Rod Adjusting Wrench
0050668509 Candy Apple Red
19 0010280090 Jack Ferrule
18 0047329000 Output Jack
16 0053291000 Switch, Lever 5-Position
0021417000 Mounting Screw
0019554000 Knob, Aged White
17 0024832000 Capacitor, .022uf
0016352000 Mounting Hex Nut
0016436000 Lock Washer, Intl
0015578000 Mounting Screw
0019473000 Bridge Block
0026103000 Arm, Tremolo
21 0019470000 Bridge Plate
0021421000 Mounting Screw
0019656000 Mounting Screw
0010272100 Claw, Tremolo
0015636000 Mounting Screw
0031643000 Spring, Claw
0019463000 Knob, Tremolo
20 0019642000 Bridge Assembly, Vintage Strat
06-13-2000
Pg. 3 of 4
23 0015693000 Intonation Screw, (6)
0019273000 Intonation Spring, 5&6
0019281000 Intonation Spring, 1-4
24 0032782000 Height Adjustment Screw, 1&6
0016071000 Height Adjustment Screw, 2-5
0018531000 Height Adjusting Wrench
25 0012180000 Spring, Tremolo
26 0050661002 Back Plate, Tremolo, White
0015578000 Mounting Screw
22 0019280000 Bridge Section, (6)
0050668506 Black
15 0056148000 Knob, Tone, Aged White, (2)
