P/N DESCRIPTION
REF.#
REF.# P/N
4 0021537000 String Retainer
3 0083675000 Bone Nut
DESCRIPTION
1 0028155000 Neck, American Standard Stratocaster, M/N
0028154000 Neck, American Standard Stratocaster, R/W
2 0021374000 Tuning Key, (1) Set
0021405000 Mounting Screw
5 0020810000 Truss Rod Adjustment Nut
0023811000 Truss Rod Adjusting Wrench
6 0026092xxx Body, Am. Std. Strat., Solid Paint
LONE STAR STRATOCASTER 0107900/7902
24 0026097000 Bridge Plate
25 0026099000 Bridge Section, (6)
26 0017031000 Intonation Screw, (6)
0019395000 Intonation Spring, 5&6
0019394000 Intonation Spring, 1-4
27 0026779000 Height Adjustment Screw, 1&6
0026780000 Height Adjustment Screw, 2-5
0018351000 Adjusting Wrench, Saddle Height
28 0012180000 Spring, Tremolo Arm
Body Part Number
0054015547 Sienna Sunburst
0026092505 Olympic White
0026092509 Candy Apple Red
0054014500 3 Color Sunburst
0026092544 Shoreline Gold Metallic
0026092545 Teal Green Metallic
8 0021453000 Strap Button
0054015xxx Body, Am. Std. Deluxe Strat., Ash
7 0054038000 Neck Mounting Plate
0021424000 Mounting Screw
0031571000 Tilt Adjustment Screw
0023811000 Tilt Adjusting Wrench
0021422000 Mounting Screw
0019056000 Felt Washer, Black
0020491000 Felt Washer, White
9 0050164000 Pickguard, Lone Star Strat., Shell
0021407000 Mounting Screw
10 0053101000 Pickup, Neck, Texas Special
0048631000 Mounting Screw
0036481000 Tubing, Latex Cut
11 0053102000 Pickup, Middle, Texas Special
0048631000 Mounting Screw
0036481000 Tubing, Latex Cut
12 0050165000 Pickup, Bridge, Seymour Duncan
0050166000 Mounting Screw
0050167000 Spring, Humbucker
0050163000 Pickguard, Lone Star Strat., Pearl
0049683000 Back Plate, Tremolo, Brown Shell
0021407000 Mounting Screw
0054014xxx Body, Am. Std. Strat., Sunburst 29 0038964000 Back Plate, Tremolo, Pearl
19 0012869000 Solder Lug
0016352000 Mounting Hex Nut
0022384000 Lock Washer, Intl
14 0056149000 Knob, Volume, White
15 0056148000 Knob, Tone, White, (2)
16 0050610000 Switch, Lever 5-Position
0021417000 Mounting Screw
0019554000 Knob, White
17 0015552000 Capacitor, .05uf
18 0024832000 Capacitor, .022uf
0015116000 Mounting Screw
21 0010280090 Ferrule, Jack
0026103000 Arm, Tremolo
0010272100 Claw, Tremolo
0016352000 Mounting Hex Nut
0016436000 Lock Washer, Intl
0021407000 Mounting Screw
22 0026095000 Bridge Assembly, '86 Am. Std. Strat
0019463000 Knob, Tremolo Arm, White
0015636000 Mounting Screw
0018671000 Spring, Tremolo
20 0021956000 Output Jack
4-18-2000
Pg. 3 of 4
23 0028957000 Pivot Screw
0019656000 Mounting Screw
0028958000 Insert, Pivot Screw
0026098000 Block, Bridge
13 0013446000 Control, 250K, (3) Taper
