DESCRIPTION
Mounting Screw
REF.#REF.# P/N
3 0083675000 Bone Nut
DESCRIPTION
1 0028154000 Neck, Am Std Strat, R/W
0028155000 Neck, Am Std Strat, M/N
2 0021374000 Tuning Key, (1) Set
4 0021537000 String Retainer
0021405000 Mounting Screw
5 0020810000 Truss Rod Adjustment Nut
AMERICAN STANDARD STRATOCASTER 0107400/7402
P/N
0028958000 Insert, Am. Std
24 0026105000 Back Plate, Tremolo, Black/White/Black
0021407000
25 0026097000 Bridge Plate, Am Std Strat
0026098000 Tremolo Block, '86 Strat
0019656000 Mounting Screw
26 0026099000 Bridge Section (6)
Body Part Number
0054015521 Natural
0054014500 3-Color Sunburst
0054015501 White Blond
8 0021453000 Strap Button
6 0026092xxx Body, Am Std Strat, Solid Color
0054014xxx Body, Am Std Strat, Sunburst
0054015xxx Body, Am Std Strat, Solid Ash
7 0054038000 Neck Mounting Plate
0021424000 Mounting Screw
0031571000 Tilt Adjustment Screw
0023811000 Tilt Adjusting Wrench
0021422000 Mounting Screw
0020491000 Felt Washer, White
0019056000 Felt Washer, Black
9 0026076000 Pickguard, Am Std, Black/White/Black
0021407000 Mounting Screw
10 0039826000 Pickup, Neck, Strat
0048631000 Mounting Screw
0036481000 Tubing, Latex Cut
11 0024288000 Pickup, Middle, Strat
0048631000 Mounting Screw
0019395000 Intonation Spring 5&6
0019394000 Intonation Spring 1-4
28 0026779000 Height Adjustment Screw 1&6
0026780000 Height Adjustment Screw 2-5
29 0012180000 Spring, Tremolo Arm
0023811000 Truss Rod Adjusting Wrench 27 0017031000 Intonation Screw (6)
0026092506 Black
0026092524 Inca Silver
0026092505 Olympic White
0026092574 Aqua Marine
0026092593 Purple Metallic
12 0050665000 Pickup, Hot Bridge, Strat
0048631000 Mounting Screw
0036481000 Tubing, Latex Cut
13 0013446000 Control, 250K, Volume/Tone (2)
0016352000 Mounting Hex Nut
0022384000 Lock Washer, Intl
14 0050666000 Control, 250K, No Load
0016352000 Mounting Hex Nut
0022384000 Lock Washer, Intl
19 0012869000 Solder Lug
20 0021956000 Output Jack
16 0056148000 Knob, Tone, White (2)
17 0053291000 Switch, Lever 5-Position
0019554000 Knob, White
0021417000 Mounting Screw
18 0024832000 Capacitor, .022uF
0015116000 Mounting Screw
0016352000 Mounting Hex Nut
15 0056149000 Knob, Volume, White
3-21-2000
Pg. 3 of 4
21 0010280090 Jack Ferrule
0010272100 Tremolo Claw
0026103000 Tremolo Arm
0021407000 Mounting Screw
22 0026095000 Bridge Assy, Am Std Strat
0015636000 Mounting Screw
0018671000 Tremolo Spring
0018531000 Adjusting Wrench, Saddle Height
0019463000 Knob, Tremolo Arm, White
23 0028957000 Pivot Screw, Am Std
0016436000 Lock Washer, Intl
0036481000 Tubing, Latex Cut
