Field Tuff ATV-2200HSH User manual

2200 LBS Utility Wagon
With High Speed Hub
OWNER’S MANUAL
WARNING:
Carefully read and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
03052020
Item# ATV-2200HSH

Page of 8
2
Thank you very much for choosing this product! For future reference, please complete the owner’s
record below:
Model: _______ATV-2200HSH______ Purchase Date: _______________
Save the receipt, the warranty, and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This product is designed for certain applications only. The manufacturer cannot be responsible for
issues arising from modification. We strongly recommend that this product not be modified and/or
used for any application other than that for which it was designed. If you have any questions relative
to a particular application, DO NOT use the product until you have first contacted us to determine if
it can, or should, be performed on the product.
For technical questions, please call 1-218-943-6290.
TECHNICAL SPECIFICATION
Item
Description
Capacity
2200 lbs.
Tires
4-PR, 16”, 35 psi MAX
Bearings
Tapered, 15 mph maximum
Construction
Steel
Dimensions
59” Long x 32.5” Wide x 30” High
GENERAL SAFETY RULES
WARNING: Read and understand all instructions. Failure to follow all instructions listed
below may result in serious injury.
CAUTION: Do not allow persons to operate or assemble this utility wagon until they
have read this manual and have developed a thorough understanding of how the utility
wagon works.
WARNING: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors that cannot be built into this
product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS

Page of 8
3
WORK AREA
•Keep work area clean, free of clutter, and well lit. Cluttered and dark work areas can cause
accidents.
•Keep children and bystanders away while operating a utility wagon. Distractions can cause
you to lose control, so visitors should remain at a safe distance from the work area.
•Be alert of your surroundings. Using a utility wagon in confined work areas may put you
dangerously close to sharp tools and rotating parts.
PERSONAL SAFETY
•Stay alert, watch what you are doing, and use common sense when using a utility wagon. Do
not use a utility wagon while you are tired or under the influence of drugs, alcohol, or medication.
A moment of inattention while operating a utility wagon may result in serious personal injury.
•Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair,
clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught
in moving parts.
•Use safety apparel and equipment. Use safety goggles or safety glasses with side shields that
comply with current national standards or, when needed, a face shield. Use a dust mask if
working in dusty work conditions. This applies to all persons in the work area.Also use non-skid,
safety shoes, hard hats, heavy-duty work gloves, dust collection systems, and hearing
protection when appropriate.
UTILITY WAGON USE AND CARE
•Do not modify the utility wagon in any way. Unauthorized modification may impair the
function and/or safety and could affect the life of the equipment. There are specific applications
for which the utility wagon was designed.
•Always check for damaged or worn-out parts before using the utility wagon. Broken parts
will affect the utility wagon operation. Replace or repair damaged or worn parts immediately.
•Do not exceed the utility wagon load capacity.
•Distribute the load evenly. Uneven loads may cause the utility wagon to tip, resulting in
personal injury to the operator or others.
•Use the utility wagon on flat and level surfaces capable of supporting the utility wagon and
its maximum load. Pulling or pushing a load on a slanted or uneven surface can result in loss of
control.
•Store idle utility wagon. When utility wagon is not in use, store it in a secure place out of the
reach of children. Inspect it for good working condition prior to storage and before re-use.
•Check connections to make sure all are tight and secure.Grease any fittings at joints and
wheels.

Page of 8
4
ASSEMBLY
Do not tighten bolts and nuts until assembly is complete.
Step 1: Remove Tongue Bolt (#12), Lock Nut (#4), Tongue Washers (#10), and Spacer (#11) from
the center of the Front Axle (#5). Align hole in center of the Front Axle (#5) with hole in center of the
Tongue (#2). Insert Spacer (#11) in between the Tongue Yoke and Axle Frame. Insert Tongue Bolt
(#12) with Washer (#10) through hole. Next, slide on Washer (#10) and Lock Nut (#14). Do not
tighten hardware until all assembly steps have been completed.
Note: Tongue Attachment is shipped secured to the tie rods and Front Axle (#5)
Step 2: Slide Wheel (#1) onto each side of the Front Axle (#5), followed by inserting the
bearing(#18), the Hub Washer (#19), the Hub Castle Nut (#20), then insert the Cotter Pin (#7) into
the hole of the axle, finish by adding Hub Cap (#21). Please be sure to push the cap all the way
down, a rubber hammer may be used to assist. Do not tighten hardware until all assembly steps
have been completed.
Step 3: Repeat the same step for the wheels on the Back Axle (#3). Do not tighten hardware until
all assembly steps have been completed.

Page of 8
5
Step 4: Position both Front Axle Assembly and Back Axle Assembly as shown below and insert
Frame Adapter (#4) into ends of both Axles. Slide in until you align holes of Frame Adapter (#4) with
the holes of the Axles. Secure in place using 12x70mm Bolt (#15), Washer (#10), and Lock Nut
(#14). Install Bolts from the bottom. Do not tighten hardware until all assembly steps have been
completed.
NOTE: There are 2 sets of holes on the Frame Adapter. Determine the desired length and adjust
using holes accordingly.
Step 5: Align holes on the Tongue (#2) with the holes on the Tongue Attachment. Secure in place
with a 12x80mm Bolt (#13), Washer (#10), and Lock Nut (#14). Do not tighten hardware until all
assembly steps have been completed.
Note: Hitch pin (#9) and R-Pin (#8) are provided for pulling.
Step 6: Tighten all hardware. Check wheels for proper inflation.
Slide Tongue (#2) into groove
and secure in place as shown
Tongue groove
Front Axle

Page of 8
6
OPERATION
WARNING: DO NOT load the wagon with more than 2200 lbs, with a balanced load.
DO NOT allow children to use the wagon. This wagon is NOT a toy. DO NOT over inflate
the tires. Maximum speed is 15 mph.
MAINTENANCE
•Maintain your utility wagon. It is recommended that the general condition of any utility wagon
be examined before it is used. Keep your utility wagon in good repair by adopting a program of
conscientious repair and maintenance. If any abnormal vibrations or noise occurs, have the
problem corrected before further use. Have necessary repairs made by qualified service
personnel.

Page of 8
7
DIAGRAM & PARTS LIST
\
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21

Page of 8
8
Part#
Description
Qty.
Part#
Description
Qty.
1
Wheel
4
12
Tongue Bolt M16xM12x125mm
1
2
Tongue
1
13
Bolt 12x80mm
1
3
Back Axle
1
14
Lock Nut M12x9mm
4
4
Frame Adaptor
1
15
Bolt 12x70mm
2
5
Front Axle
1
16
Left Axle Assembly
1
6
Large Washer M20mm
4
17
Right Axle Assembly
1
7
Cotter Pin M2.5x35mm
8
18
Hub Bearing (4 are
pre-assembled)
8
8
R-Pin M3mm
1
19
Hub Washer
4
9
Hitch Pin M11x60mm
1
20
Hub Castle Nut
4
10
Washer M12mm
4
21
Hub Cap
4
11
Spacer M28xM16x11mm
1
For replacement parts and technical questions, please call 1-218-943-6290.
WARRANTY
One-year limited parts warranty.
BAC
PO BOX 155
Miltona, MN 56354
Made in China
