Gama Garden GLM 40P Basic User manual

Instruction manual
GLM 40P Basic
GLM 46P Basic/Premium GLM 46P-1 Basic/Premium
GLM 46ES Premium
GLM 48P Basic/Premium GLM 48P-1 Basic/Premium
GLM 48ES Premium
GLM 51S Premium GLM 51ES Premium
Please read these instructions carefully and make sure you
understand them before using this machine.

Acquaer Kft. 2/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
CONTENTS
SAFETY RULES ..........................................................3-5
TECHNICAL DATA ......................................................6
OVERVIEW ..................................................................7
ASSEMBLY .................................................................8-9
START AND STOP ......................................................10
OPERATION.................................................................11
MAINTENANCE ..........................................................12-13
GENERAL INFORMATION ........................................14
TROUBLESHOOTING ................................................14-15

Acquaer Kft. 3/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
SAFETY RULES
IMPORTANT: This cutting machine is capable of amputating hands and feet and
throwing objects. Failure to observe the following safety instructions could
result in serious injury or death.
I. Training
• Read the instructions carefully. Be familiar
with the controls and the proper use of the
equipment.
• Never allow children or people unfamiliar
with the instructions to use the lawnmower.
Local regulations may restrict the age of the
operator.
• Never mow while people, especially
children, or pets are nearby.
• Keep in mind that the operator or user is
responsible for accidents or hazards occurring
to other people or their property.
II. Preparation
• While mowing, always wear substantial
footwear and long trousers. Do not operate
the equipment when barefoot or wearing
open sandals.
• Thoroughly inspect the area where the
equipment is to be used and remove all
objects which may be thrown by the machine.
•WARNING - Petrol is highly flammable.
- Store fuel in containers specifically designed
for this purpose.
- Refuel outdoors only and do not smoke
while refueling.
- Add fuel before starting the engine. Never
remove the cap of the fuel tank or add petrol
while the engine is running.
- Add fuel only when the engine is cold
- If petrol is spilled, do not attempt to start the
engine but move the machine away from the
area of spillage and avoid creating any source
of ignition until petrol vapors have dissipated.
- Replace all fuel tanks and container caps
securely.
• Replace faulty silencers.
• Before using, always visually inspect to see
that the blades, blade bolts and cutter
assembly are not worn or damaged. Replace
worn or damaged blades and bolts in sets to
preserve balance.
III. Operation
• Do not operate the engine in a confined
space where dangerous carbon monoxide
fumes can collect.
• Mow only in daylight or in good artificial
light.
• Avoid operating the equipment in wet grass,
where feasible.
• Always be sure of your footing on slopes.
• Walk, never run.
• For wheeled rotary machines, mow cross
the face of slopes, never up and down.
• Exercise extreme caution when changing
direction on slopes.
• Do not mow excessively steep slopes.
• Use extreme caution when reversing or
pulling the lawnmower towards you.
• Stop the blade if the lawnmower has to be

Acquaer Kft. 4/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
tilted for transportation when crossing
surfaces other than grass, and when
transporting the lawnmower to and from the
area to be mowed.
• Never operate the lawnmower with
defective guards, or without safety devices,
for example deflectors and/or grass catchers,
in place.
• Do not change the engine governor settings
or overspeed the engine. Operating the
engine at excessive speed may increase the
hazard of personal injury.
• Disengage all blade and drive clutches
before starting the engine.
• Start the engine carefully according to
instructions and with feet well away from the
blade.
• Do not tilt the lawnmower when starting the
engine, except if the lawnmower has to be
tilted for starting. In this case, do not tilt more
than absolutely necessary and lift only the
part which is away from the operator.
• Do not start the engine when standing in
front of the discharge chute.
• Do not put hands or feet near or under
rotating parts.
•Keep clear of the discharge opening at all
times.
• Never pick up or carry lawnmower while the
engine is running.
• Stop the engine and disconnect the spark
plug wire:
- before cleaning blockages or un clogging
chute;
- before checking, cleaning or working on the
lawnmower;
- after striking a foreign object. Inspect the
lawnmower for damage and make repairs
before restarting and operating the
lawnmower;
- if the lawnmower starts to vibrate
abnormally (check immediately).
• Stop the engine:
- whenever you leave the lawnmower;
- before refueling.
• Reduce the throttle setting during engine
shut down and, if the engine is provided with
a shut-off valve, turn the fuel off at the
conclusion of mowing.
• Go slow when using a trailing seat.
IV. Maintenance and storage
• Keep all nuts, bolts and screws tight to be
sure the equipment is in safe working
condition.
• Never store the equipment with petrol in
the tank inside a building where fumes may
reach an open flame or spark.
• Allow the engine to cool before storing in
any enclosure.
• To reduce the fire hazard, keep the engine,
silencer, battery compartment and petrol
storage area free of grass, leaves, or excessive
grease.
• Check the grass catcher frequently for wear
or deterioration. • Replace worn
or damaged parts for safety.
• If the fuel tank has to be drained, this should
be done outdoors

Acquaer Kft. 5/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
These symbols may appear on your machine or in the literature supplied with the
product. Learn and understand their meaning.

Acquaer Kft. 6/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
TECHNICAL DATA
Type
GLM 40P Basic
GLM 46P / GLM
46P-1 Basic
GLM 46P / GLM
46P-1 Basic
(B&S450E)
GLM 46P / GLM
46P-1 Premium
GLM 46P / GLM
46P-1 Premium
(B&S500E)
A
146cm
159 cm
161 cm
B
99 cm
103 cm
103 cm
C
49.5 cm
54 cm
54 cm
Sound power level
96 d(B)A
96 d(B)A
96 d(B)A
Max. power
1.2kW/2900 rpm
1.9 kW/2900 rpm
1.65kw/2900rpm
1.9 kW/2900 rpm
1.95kw/2900rpm
Max. torque
4.0N.m/2500 rpm
6.0N.m/2800 rpm
6.3N.m/2600rpm
6.0N.m/2800 rpm
7.2N.m/2600rpm
Displacement
99 cc
139 cc
125cc
139 cc
140cc
Wheel drive
4.0 km/h
-/3.6 km/h
-/3.6 km/h
3.6 km/h
3.6 km/h
E-start
No
No
No
Spark plug
F7RTC (TORCH)
F7RTC (TORCH)
QC12YC
F7RTC (TORCH)
QC12YC
Fuel capacity
1.0L
1.3L
0.8L
1.3L
0.8L
Oil capacity
0.4 L
0.5L
0.47L
0.5L
0.47L
Oil type
10W-30
10W-30
10W-30
Grass catcher
45 L
70 L
70 L
Working width
400 mm
460 mm
460 mm
Cutting height
25-75mm
30-80mm
30-80 mm
Weight
21Kg/24Kg
32Kg / 34Kg
28Kg/30Kg
32Kg / 34Kg
30Kg/32Kg

Acquaer Kft. 7/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
Type
GLM 48P / GLM
48P-1 Basic
GLM 48P / GLM
48P-1 Basic
(B&S500E)
GLM 48P / GLM
48P-1 Premium
GLM 48P / GLM
48P-1 Premium
B&S625E)
A
164 cm
164 cm
B
103cm
103cm
C
54 cm
54 cm
Sound power level
96 d(B)A
96 d(B)A
Max. power
1.9 kW/2900 rpm
1.95k/2900rpm
2.7kW/3050rpm
2.3kw/2900rpm
Max. torque
6.0N.m/2800 rpm
7.2N.m/2600rpm
9.7N.m/2800rpm
8.5N.m/2600rpm
Displacement
139 cc
140cc
173cc
150cc
Wheel drive
-/3.6 km/h
-/3.6 km/h
3.6 km/h
-/3.6 km/h
E-start
No
No
Spark plug
F7RTC (TORCH)
QC12YC
F7RTC (TORCH)
XC92YC
Fuel capacity
1.3L
0.8L
1.5L
0.8L
Oil capacity
0.5L
0.47L
0.6L
0.47L
Oil type
10W-30
10W-30
Grass catcher
70 L
70 L
Working width
480 mm
480 mm
Cutting height
30-80 mm
30-80 mm
Weight
34Kg / 36Kg
28Kg/30Kg
34Kg / 36Kg
31Kg/33Kg
Type
GLM 46 ES
Premium
GLM 48 ES
Premium
GLM 51 S Premium
GLM 51 S
Premium
(B&S625E)
GLM 51 ES
Premium
A
161 cm
164 cm
166cm
166cm
B
103 cm
103cm
103cm
103cm
C
54 cm
54 cm
56 cm
56 cm
Sound power level
96 d(B)A
96 d(B)A
98 d(B)A
98 d(B)A
Max. power
1.9 kW/2900 rpm
2.7kW/3050rpm
2.7kW/3050rpm
2.3kw/2900
2.7kW/3050rpm
Max. torque
6.0N.m/2800 rpm
9.7N.m/2800rpm
9.7N.m/2800rpm
8.5N.m/2600rpm
9.7N.m/2800rpm
Displacement
139 cc
173cc
173cc
150cc
173cc
Wheel drive
3.6 km/h
3.6 km/h
3.6 km/h
3.6 km/h
E-start
Yes
Yes
No
Yes
Spark plug
F7RTC (TORCH)
F7RTC (TORCH)
F7RTC (TORCH)
XC92YC
F7RTC (TORCH)
Fuel capacity
1.3L
1.5L
1.5L
0.8L
1.5L
Oil capacity
0.5L
0.6L
0.6L
0.47L
0.6L
Oil type
10W-30
10W-30
10W-30
10W-30
Grass catcher
70 L
70 L
70 L
70 L
Working width
460 mm
480 mm
510 mm
510 mm
Cutting height
30-80 mm
30-80 mm
30-80 mm
30-80 mm
Weight
32Kg / 34Kg
34Kg / 36Kg
38 Kg
33 Kg
40 Kg

Acquaer Kft. 8/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
OVERVIEW (Some type may different from drawing)
ASSEMBLING
1. Lower handle assembling
•Insert pin into the round hole of lower handle from both left and right side.
•Insert square neck bolt (M8X16) into the bracket and lower handle, then
tighten with knob nut.
NOTE: The handle level (high, medium or low) can be adjusted by setting of
square neck bolt in one of the three holes on the bracket.
Drive Control
Blade Control
Upper Handle
Square Neck Bolt
Bottom Hanle
Knobs
Spark plug
Grass Bag
Knobs
Height Adjusable
Handle
Oil fill
Recoil starter
Petrol intake
Air fiter
Side Discharg
Square Neck Bolt
Knobs
Pin
Bracket
Knobs

Acquaer Kft. 9/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
2. Upper handle assembling
•Insert bolt (M8X60) into left handle holder, lower handle and upper handle
assembly in turn, then tighten with knob nut.
•Insert bolt (M8X60) into right handle holder, lower handle, upper handle
assembly and start rope hook in turn, then tighten with knob nut.
•Fasten cables with the clips on the handle rod.
3. Grass catcher assembling
•Hold up the rear cover and fit the grass catcher.
4. Grass collection setting:
1) For rear bagging
• Grass catcher box installed.
2) For rear discharging
•stall grass catcher.
•close the rear cover.
3) For side discharging
• Rear cover closed.
• side discharge guard installed.
4) For mulching
• Lift the rear cover and hold up, insert mulching.
•Rear cover closed.

Acquaer Kft. 10/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
5. Working depth setting
Only when mower is stationary and rotating blade has come to complete
standstill.
Mow the lawn twice weekly during the most active periods of growth. Never cut
more than 1/3 of the length of the grass, especially during dry periods. Mow with a
high cutting height setting the first time. Examine the result and lower the mower to
the desired setting. Mow slowly or mow the grass twice if it is very long.
1=30mm 2=33mm 3=36mm 4=43mm 5=51mm 6=60mm
6. Assembling of battery case（if with）
1) Unlock the lock catch and open the battery case cover.
2）Insert the reeds on the power cables into the corresponding battery tabs by
colors.
3）For the first use of machine or after the long-time non-use of machine, unplug
the charging plug at the battery connecting cable and charge the battery by a
charger, till the battery is fully charged (it will take approximately 8~9h).
4）Take out the key from the parts bag and insert the key into the corresponding
hole in the battery case.
5）Cover the battery case cover and lock the lock catch.
Note: If a fuse is burnt, replace it timely.
Note: If the machine fails to start by motor, attempt to start the machine by using
the hand disc.
START AND STOP
1. Add fuel: See the Technical data table for the fuel characteristics. Add fuel only
when the engine is cold.

Acquaer Kft. 11/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
•Place the lawnmower level.
•Clean around the filler cap
•Remove the filler cap
•Using a clean funnel, fill tank to approximately 5 mm below the inner edge of the
filler neck, being careful not to spill fuel.
•Tighten the filler cap back and clean any spilled fuel.
NOTE: not on gravel or similar. Fill the tank with petrol, not oil-blended. Lead-free
petrol may be used.
Do not fill with petrol while the engine is running.
2. Add oil: See the Technical data table for the oil to be used.
•Place engine level.
•Clean around oil fill.
•Remove the filler cap, clean the tip of the dipstick, insert and tighten down.
•Remove dipstick again and check the oil level that must be between the “MIN”
and “MAX”marks.
•If oil is required, add oil of the same kind up to the “MAX”mark, being careful not
to spill any outside the oil fill.
•Close the filler cap and wipe off any spilled oil.
3. Spark plug cap
Connect the cap of cable to the spark plug, making sure that there is no grass or dirt
either inside the cap or on the spark plug terminal.
4. Starting engine:
Always start the engine with the lawnmower traction device (if equipped)
disengaged.
a) Push down the button three times.
b) Close blade control handle
c) Then pull cord rapidly (If your lawn mower is equipped with starter push
“start” botton)
d) When engine starts, release the recoil starter.

Acquaer Kft. 12/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
NOTE: If the engine does not start, repeat whole starting procedure.
NOTE: If the engine starts but does not keep running, repeat the whole starting
Starting the engine (hot starting)
Follow the whole cold-starting procedure.
WARNING! Keep your hands away from the silencer and surrounding
areas that can become extremely hot. While the engine running, do not
get loose-fitting clothing (ties, scarves, etc.) or hair closer to the top part
of the engine.
IMPORTANT: inclines can prevent malfunctioning of engine. Do not operate your
lawn mower over 13°inclination angle.
5. Drive
• Forward drive is engaged and disengaged with the drive control at the top of the
handle.
6. Stopping during operation
Release the blade control handle to stop the engine.
7. Stopping at the end of operation
a) Release the blade control handle to stop the engine.
b) Once the engine has cooled, disconnect the spark plug cap.
c) Remove any grass build-up from the engine, in particular from the silencer, to
reduce fire hazard.

Acquaer Kft. 13/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
OPERATION
1. The mower should not be used on ground that slopes more than 13°. This could
cause engine lubrication problems.
2. To empty grass catcher: when the indictor cap is closed, the grass catcher is full.
Please empty it.
3. To remove grass box:
• Release engine brake control to stop engine
• Lift up rear cover and remove the grass catcher by handle.
•Empty the grass catcher.
• Do not drag the bag when emptying, it will cause unnecessary wear.
4. Clean up the grass inside chassis with water when the mower is used:
(if your lawn mower is equipped with hose plug）
• Open hose cover
• Insert the hose into quick connector through hose cover.
• Tighten hose cover.
•Connect the quick coupling with the outlet connector on the chassis by rotating the
fastening clip as indicated.
• Open faucet and clean the mower 30 - 60 seconds
• Shut down the mower.
• Wipe up the mower with dry cloth.

Acquaer Kft. 14/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
MAINTENANCE AND STORGE
Always remove the spark plug lead before repair, cleaning or
maintenance work. After 5 hours running time, tighten screws and
nuts. Check the oil. The spark plug must be at the highest point on
the mower when it is tilted up.
Clean mower thoroughly after each mowing with cloth or
brush.
Do not spray with water. Keep mower in a dry room.
·Annually (After end of season)
Grinding and balancing the cutter blade. Remove the sparkplug
lead. Fitting and removing the blade require the use of protective
gloves. Unscrew the cutter blade and deliver it to a service
workshop for grinding and balancing. Tighten the screw properly
when reassembling.
Drain fuel from tank to prevent build-ups inside the tank.
Change oil after each season or after 25 hours running time. Run
the engine warm, remove the spark plug lead. Remove the drain
plug from bottom of engine and drain oil. Fill with new oil.
·Cleaning the air filter.
Keep the filter clean and oil saturated. Replace it if broken, cut or with
damaged parts.
IMPORTANT: Never use compressed air to clean the filtering
element.
• Clean around the filter cover
•Release the clip; remove the cover and the foam element.
•Wash the foam element in liquid detergent and water. Squeeze dry
in a clean cloth.
•Saturate the foam element with 2 table-spoons of clean engine oil and squeeze it a
few times to distribute the oil evenly.
•Remove excess oil with a clean cloth.
•Clean the interior of the air cleaner housing from any dust and grass, making sure
that they do not enter the intake manifold.
•Install the foam element in its housing and close the cover.
If the foam element has been replaced, proceed to oil the new filter as described
above in sections.

Acquaer Kft. 15/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
GENERAL INFORMATION
1.Installing and removing a battery
• Switch off the engine and all power consumers
• This battery may only be used on the place provided by the manufacturer.
• Avoid short circuits by tools.
• Remove the foreign body from the surface of the battery and firmly clamp the
battery after inserting it.
• Before installation: Clean the poles and terminals and grease them.
• When installing: clamp the positive pole and ensure that the pole terminals are
firmly seated.
2.Storage and transport
In unfilled condition, the batteries should be stored cool and dry. Batteries are to be
subjected to a full charge (see Charge the battery) before storage (for example
during the winter break). New battery has about 80% charge capacity.
3.Maintenance
Sealed batteries require no maintenance in the form of water refill, so do not open
the batteries again. Keep the terminal poles and the battery surface clean (damp
cloth, antistatic). Tighten the clamps and grease them lightly. Check the charge level
of the battery by voltage control and recharge if necessary (see 4.Charge the
battery).
4. Charge the battery
Important! For sealed batteries such as yours, the charge is carried out using the
supplied battery charger as shown in Following pictures. Table 1 in the case of a non-
original charger requires monitoring of the charging voltage as well as a manual
override. Observe the instructions of the charger manufacturer!
IMPORTANT:
• If the characteristic of a charger manufacturer is not known, check voltage
monitoring with one voltmeter and perform manual switch-off at 14.4V.
• The rated current of the charger should be 1/10 of the nominal capacity in
amperes.
• When charging, first connect the battery to the charger, then switch on the
charger.

Acquaer Kft. 16/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
Table 1
Unregulated chargers with manual monitoring (acceptable).
Curve
Applications
Soltage limitation
(manual monitoring)
W
Wa*
Single charge
Single charge
14,4 Volt max.
14,4 Volt max.
*Charger with automatic switch-off by time switch or temperature monitoring.
Table 2
Regulated chargers without additional monitoring (recommended).
Curve
Applications
Voltage limitation
IU
Wu
Wae
Single charge/Collective
charge
Single charge
Single charge
14,4 Volt max.
14,4 Volt max.
14,4 Volt max.
Charge the charger here
Open battery housing here
E-Start
Insert the ignition key here

Acquaer Kft. 17/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
Table 3
Guideline values for the charging time depending on the battery status and charging
unit size.
Open circuit
voltage*
(Volt)
Charge status (%)
Charging time at charging device rated
current
0.1×battery rated capacity (amp)
>12,7
approx. 12,5
approx. 12,2
approx. 12,0
approx. 11,8
100
75
50
25
0
-
4h
7h
11h
14h
*The open circuit voltage adjusts to a constant value after a few hours; it should
therefore not be measured immediately after a charge or discharge. In this case, a
waiting period of approx. 2 hours is required.
TROUBLESHOOTING
PROBLEM
LIKELY CAUSE
SOLUTION
Hard starting
No fuel
Check and top up
Stale fuel or build-ups in
tank
Empty fuel tank and refill with fresh
fuel
Spark plug disconnected
Check that the spark plug cap fits well
over the plug terminals
Dirty electrodes or
incorrect gap
Check
Air filter clogged
Check and clean the air cleaner
Incorrect oil for the season
Replace with proper oil
Fuel evaporation in the
carburetor (vapor lock) due
to high temperatures
Wait for a few minutes then start again
Fault in carburation
Contact a Licensed Service Centre
Inconsistent
working
Stale fuel or build-ups in
tank
Empty fuel tank and refill with fresh
fuel
Dirty electrodes or
incorrect gap
Check
Air filter clogged
Check and clean the air cleaner
Fault in carburation
Contact a Licensed Service Centre
Loss of power
Air filter clogged
Check and clean the air cleaner

Acquaer Kft. 18/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
while mowing
Fault in carburation
Contact a Licensed Service Centre
Governor out of phase
with respect to the
accelerator
Adjust the cable
Guarantee terms
Please carefully retain the guarantee card completed by the seller, or the proof of
purchase.
Pre-conditions for the 24-month guarantee entitlement:
- Deployment of the device solely for private use.
The guarantee is reduced to 12 months in the commercial sector or leasing
business.
- Proper handling and observance of all information given in the operating manual,
which forms part of our guarantee terms.
- Observance of the prescribed maintenance intervals
- No unauthorized alteration of the design.
- Presentation of the completed guarantee card and/or proof of purchase.
This guarantee does not extend to normal wear-and-tear on blades, blade
mounting components or friction disks, running wheels/tyres air filters spark plugs
and spark plug connectors. Any guarantee claim shall be immediately void in the
event of unauthorized repairs. Faults and defects, which can be traced to material
or manufacturing faults will be rectified exclusively by our contracted workshops
(the seller has the right to remedy a defect) in your vicinity or by the manufacturer
if the latter is closer. Any claims going beyond the provision of a guarantee are
ruled out. Any transport damage should be reported not to us but to the shipper in
question since, otherwise, any compensation claims the shipper would be voided.
This symbol on the device or the packaging indicates that the product shall
not be managed as household waste. Please dispose of it at the collecting
place assigned for the collection of electrical and electronic devices. By
proper management of superseded products you can help prevent the
environment and human health from damage which would occur if you do
not follow the proper way of waste disposal. The recycling of the materials helps in
the preservation of the natural resources. For further information on the recycling of
the product, please turn to the competent authorities, the local waste collecting
service provider or the shop where this product was bought.

Acquaer Kft. 19/19 www.gamagarden.eu
H-4900, Fehérgyarmat, Szatmári utca 11.
Information concerning the packaging materials
The used packaging materials must be thrown into the relevant waste collector.
In case of the need of any parts, questions or service instructions please contact:
[email protected]
[phone]
Acquaer Ltd., 4900 Fehérgyarmat, Szatmári u. 11 certifies CE conformity of the above-
mentioned product and that it complies with the technical data specified in the data
plate and the “Operating instructions”.
You can get detailed information about the CE declarations at: www.gamagarden.eu
