OWNER’S MANUAL
www.glaciericehouse.com

2
INTRODUCTION
Thank you for purchasing a Glacier Ice House. We hope you will get many years of productive
use from it. This frame is designed to be pulled by a proper size vehicle. All product users must read and
understand this manual prior to equipment operation. This manual is considered part of your fish house
frame and should remain with it at all times. Do not allow anyone to operate or maintain this fish house
frame that has not fully read and comprehended this manual. Failure to follow the recommended
procedures may result in personal injury or death or equipment damage.
Some photographs, diagrams or illustrations in this manual may show doors, guards and shields opened
or removed to aid in clarity and understanding of a particular procedure. All guards, shields and safety
devices must be in their proper position prior to operation.
WARRANTY
Glacier, warrants that its products and their components will be free from defects in material and
workmanship for a period of one (1) year from the date of original purchase when used as intended and
under normal service and conditions. This warranty does not cover or apply to any products or
component parts which have been tampered
with, modified or altered in any way or which have been subject to misuse, negligence, involved in an
accident, or damaged by an act of weather.
EXCLUSION OF WARRANTIES
GLACIER MAKES NO WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE
IN RESPECT TO ITS PRODUCTS OR COMPONENT PARTS. GLACIER SHALL NOT BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES FROM ANY BREACH OF WARRANTY, INCLUDING, BUT
NOT LIMITED TO, LOSS OF PROFITS, INCONVENIENCE, AND THE COST OF RENTAL OR REPLACEMENT
EQUIPMENT. NO AGENT, EMPLOYEE OR REPRESENTATIVE OF GLACIER HAS THE AUTHORITY TO BIND
IT TO ANY AFFIRMATION, STATEMENT OF WARRANTY CONCERNING ITS PRODUCTS AND THEIR
COMPONENT PARTS EXCEPT AS SPECIFICALLY SET FORTH HEREIN.
SAFETY
Read and understand this manual and all safety signs before operating and maintaining. Review the
safety instructions and precautions annually.
TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS USED TO CALL YOUR
ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL SAFETY AND THE SAFETY OF OTHERS.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY OR DEATH.
THIS SYMBOL MEANS - ATTENTION!
- BECOME ALERT!
- YOUR SAFETY IS INVOLVED!

3
SAFETY SIGNAL WORDS
Note the use of signal words WARNING: Indicates a potentially
DANGER, WARNING and hazardous situation that, if not
CAUTION with the safety messages. Avoided, could result in death or
The appropriate signal word for each serious injury, and includes hazards
has been selected using the that are exposed when guards are
following guidelines: removed. It may also be used to
alert against unsafe procedures.
DANGER: Indicates a CAUTION: Indicates a potentially hazardous
Imminently hazardous situation that, if not avoided, may result
that, if not avoided, will result in in minor or moderate injury. It may
death or serious injury. This signal also be used to alert against unsafe
word is to be limited to the most practices.
extreme situations typically for
machine components which, for
functional purposes cannot be guarded.
GENERAL SAFETY GUIDELINES
Safety of the operator is one of the main concerns in designing and developing a new piece of
equipment. Designers and manufacturers build in as many safety features as possible. However,
every year many accidents occur which could have been avoided by a few seconds of thought
and more careful approach to handling equipment. You, the operator, can avoid many accidents
by observing the following precautions in this section. To avoid personal injury, study the following
precautions and insist those working with you, or for you, follow them.
Replace any CAUTION, WARNING, DANGER or instruction safety decal that in not readable or is
missing. Location of such decals is indicated in this booklet.
For your safety, before operating the winches on your fish house frame, check all clamps to guarantee
they are tight. Failure to do so may result in bodily injury.
Do not attempt to operate this equipment under the influence of drugs or alcohol.
Review the safety instructions with all users annually.
This equipment is dangerous to children and persons unfamiliar with its operation. The operator
should be a responsible adult familiar and trained in this equipment’s operations. Do not allow persons
to operate or assemble this unit until they have read this manual and have developed a thorough
understanding of the safety precautions and of how it works.
Do not paint over, remove or deface any safety signs or warning decals on your fish house frame.
Observe all safety signs and practice the instructions on them. Never exceed the limits of a piece of
machinery. If its ability to do a job or, or to do so safely, is in question –DON’T TRY IT. 5

4
Safety signs
On our frames there are several areas which are pinch point hazards
meaning that there is a possibility of you pinching a body part so stay clear and be cautious of these
areas.
All grease zerks are pre-greased at the manufacture. It is the consumer’s responsibility
to maintain grease updates. Axels should be greased twice annually, once in the spring and once in the
fall.
ALIGNMENT:
It is each customers responsibility to have their Glacier aligned after purchase, regardless if the Glacier
is new or used. Alignments need to be done periodically throughout ownership. When one doesn’t
comply with these directions your Glacier may occur tire wear. Each customer will need to show a copy
of their receipt of alignment done to receive any warranty on tire or other related axle issues.
Proper maintenance and tips for sealing your roof. (Please
use attached diagram for instructions).
. Pressure wash the whole roof and remove any loose debris.
. Remove any loose or cracked caulking around the outer edge.
. Dry off all surface area.
. Apply new self-leveling caulking around the outer edge and let stand 12 hours before transporting
the unit.
.Apply new sealant at least once a year to the following
.Roof, Trim, Windows, Doors, All corners.
. Keep safety signs clean and legible at all times.
. Replace safety signs that are missing or have become illegible.
. Replaced parts that displayed a safety sign should also display the current sign.
. Safety signs are available from your distributor or dealer parts department or the
factory.

5
How to Install Safety Signs:
. Be sure that the installation area is clean and dry.
. Decide on the exact position before you remove the backing paper.
. Remove the smallest portion of the split backing paper.
. Align the decal over the specified area and carefully press the small portion with the
exposed sticky backing in place.
. Slowly peel back the remaining paper and carefully smooth the remaining portion of
the decal in place.
. Small air pockets can be pierced with a pin and smoothed out using the piece of decal
backing paper.
TIRE SAFETY
. Failure to follow proper procedures when mounting a tire on a wheel or rim can
produce and explosion which may result in serious injury or death.
. Do not attempt to mount a tire unless you have the proper equipment and experience
to do the job.
. Inflating or servicing tires can be dangerous. Whenever possible, trained personnel
should be called to service and/or mount tires.
. Always order and install tires and wheels with appropriate capacity to meet or exceed
the anticipated weight to be placed on the equipment.
DIRECTIONS FOR OPERATING YOUR DROP DOWN FRAME
When lowering your fish house frame, let the front hitch winch down first and then the side
winches.
When raising the fish house, raise both side winches first, then the front hitch winch.
AFTER RAISING THE WHOLE HOUSE AND INSERTING THE PINS, RELEASE ALL TENSION ON THE STRAPS
FOR TRANSPORT.
When lowering or raising your fish house frame, DO NOT lean over the leaf spring, stand behind
the winch.
FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE SERIOUS BODILY INJURY AND/OR
DAMAGE TO OUR FISH HOUSE FRAME.
Keep hands and feet clear of the frame when lowering the front and side winches of the fish
house frame.
LIGHTING AND MARKING
. It is the responsibility of the customer to know the lighting and marking requirements of
the local highway authorities and to install and maintain the equipment to provide
compliance with the regulations.

6
. Lighting Kits are available from your dealer or from the manufacturer.
BEFORE OPERATION
. For your safety, before operating the winches on your fish house frame,
check all clamps to guarantee they are tight. Failure to do this may result
in bodily injury.
. Carefully study and understand this manual.
. Keep wheel lug nuts or bolts tightened to specified torque.
. Assure that tires are inflated to proper air pressure.
. Give the unit a visual inspection for any loose bolts, worn parts or cracked welds, and
make necessary repairs. Follow the maintenance safety instructions in this manual.
. Do not use the unit until you are sure that the area is clear, especially children and
animals.
. Securely attach to towing unit. Use a high strength, proper-sized hitch ball with a
mechanical retainer and attach safety chain.
. Do not allow anyone to stand between the tongue or hitch and the towing vehicle when
backing up to the equipment.
DURING OPERATION
. Children should not be allowed on the product.
. Clear the area of small children and bystanders before moving the fish house frame.
. Make sure you are in compliance with all local and state regulations regarding
transporting equipment on public roads and highways. Lights must be clean and visible
by overtaking or oncoming traffic when fish house frame is transported.
. SAFETY CHAIN –If equipment is going to be transported on a public highway, a safety
chain should be obtained and installed. Always follow state and local regulations
regarding a safety chain and auxiliary lighting when towing your fish house frame on a
public highway. Be sure to check with local law enforcement agencies for your own
particular regulations. Only a safety chain (not an elastic or nylon/plastic tow strap)
should be used to retain the connection between the towing and towed machines in the
event of separation of the primary attaching system.
. Install the safety chain by crossing the chains under the tongue and secure to the draw
bar cage or hitch or bumper frame.
. Beware of bystanders, particularly children! Always look around to make sure that it is
safe to start the engine of the towing vehicle or move the unit. This particularly
important with higher noise levels and quiet cabs, as you may not hear people shouting.

7
. NO PASSENGERS ALLOWED –Do not carry passengers anywhere on, or in, the frame,
except as required for operation.
. Keep hands and clothing clear of moving parts.
. Do not clean, lubricate or adjust your equipment while it is moving.
. Be especially observant of the operating area and terrain –watch for holes, ice heaves,
rocks, or other hidden hazards. Always inspect the area prior to operation.
. DO NOT operate near the edge of drop-offs or banks.
. DO NOT operate on steep slopes as overturn may result.
. Operate up and down (not across) intermediate slopes. Avoid sudden
starts and stops.
HIGHWAY AND TRANSPORT OPERATIONS
DO NOT!! EXCEED 55 MILES PER HOUR
. Adopt safe driving practices:
. Always drive at a safe speed relative to local conditions and ensure that your speed is
low enough for an emergency stop to be safe and secure. Keep speed to a minimum.
. Reduce speed prior to turns to avoid the risk of overturning.
. Avoid sudden uphill turns on steep slopes.
. Do not drink and drive!
. Comply with state and local laws governing highway safety and movement of on public
roads.
. Local and state laws should be checked for all highway lighting and marking
requirements.
. Be a safe and courteous driver. Always yield to oncoming traffic in all situations,
including narrow bridges, intersections, etc.
. Be observant of bridge load ratings. Do not cross bridges rated lower than the gross
weight as which you are operating.
. Watch for obstructions overhead and to the side while transporting.
. Always operate equipment in a position to provide maximum visibility at all times. Make
allowances for increased length and weight of the equipment when making turns,
stopping the unit, etc.
. Be extra careful when working on inclines.
. Avoid loose fill, rocks and holes; they can be dangerous for equipment operation or
movement.
. Operate the towing vehicle from the operator’s seat only.
PLUMBING SYSTEMS ARE NOT TO BE USED WHEN TEMPS FALL BELOW
32 DEGREES. THIS WILL VOID ALL MANUFACTURE WARRANTIES.

8
PLUMBING SYSTEMS
The plumbing system in your trailer is typically categorized into three primary sub-systems: Fresh water,
Gray water, and Black water. Fresh or Potable water is stored in the fresh water tank or is directly
introduced into the plumbing system by way of the city water fill located on the exterior of the trailer.
Gray water system consists of the waste water from the sinks and tub/shower. Black water system
consists of the waste water from the toilet. Road vibrations, and shock as well as excessive water
pressure from city water sources are the main physical causes of water system damage. It is important
to frequently inspect all plumbing fittings and joints for water seepage. Many times a minor leak is easily
corrected merely by hand tightening the plastic fittings. Do not over tighten the fittings.
NOTICE
Water leakage from plumbing joints may result in considerable damage if left unchecked. It is the
owner’s responsibility to promptly take necessary action to lessen damage due to water leakage.
FRESH WATER AND WATER PUMP SYSTEM
The fresh water tank may be filled from the exterior water fill by inserting an open-end garden hose into
the city water fill then filling until the monitor panel indicates the tank is full. Only open the valve on
your garden hose faucet about 50% when filling the fresh water tank. Do not fill the fresh water tank at
full volume/pressure of your garden hose as full volume may not allow the tank to vent quickly enough –
thereby causing unnecessary strain on the tank.
1. Confirm water is present in the fresh water tank. You may visually check the tank or use the tank
monitor panel to confirm water level.
2. Open hot and cold kitchen, bath, and shower faucets.
3. Open the water heater bypass valve to allow water heater to fill.
4. Turn on the water pump.
5. Close each faucet after the water is flowing steadily.
6. The water pump will stop running when the water lines are fully pressurized.
7. The pump is a demand only pump which means that when the pump switch is in the “on” position the
pump will run when using water. Note: If the pump cycles on/off while not using water, you may require
minor adjustment of the water pump pressure switch or have a minor water leak in the plumbing
system. Seek service advice if the pump continues to cycle when not using water.
SANITIZING THE FRESH WATER SYSTEM
Keeping the fresh water system free of contaminates is critical in proper use of the fresh or potable
water system. To sanitize and reduce growth of algae and similar contaminants, you may sanitize the
fresh water system using the following procedure:
1. Drain the fresh water tank.
2. Prepare a chlorine solution of using one gallon of water and ¼ cup of liquid bleach for every 15 gallons
of tank capacity.
3. Close all drains and faucets.
4. Pour the solution into the fresh water tank by way of the exterior tank fill.
5. Turn on pump and open each faucet until the water flows freely and a distinct odor of bleach is
present. Close the faucets.
6. Allow the system to sit undisturbed for approximately 3 –4 hours.
7. Drain the system by opening all faucets and drains while running the water pump.

9
8. Continue filling the entire water system with clean water and run water through all facets until the
bleach odor is no longer present.
9. Fill the water system one more time followed by a final draining of the tanks.
10. Replace the water filter if so equipped.
11. The system is now ready for normal use. Connection to city water You may bypass the fresh water
tank and connect a garden hose directly to the exterior water fill which is threaded to accept a garden
hose. This method will bypass the fresh water tank and pump and will use the garden hose pressure to
supply water to faucets. Typically this is the preferred water use method when in an improved
campground.
Water heater
The water heater in your trailer is fueled by propane with a 12-volt electronic ignition switch. Your water
heater may also be equipped with a 120-volt electric heater element for use when connect to 120-volt
shore power. NOTICE The water heater must be completely filled with water prior to turning on the
propane or the electric heater element. Even momentary operation of the electric heater without
submersion in water will burn out the 120-volt heater element. Element failure is not covered under any
warranty terms. WATER HEATER PRESSURE RELIEF VALVE Your water heater is equipped with a pressure
relieve valve which is located behind the exterior access door. This valve will open when excess pressure
or temperature is reached. Due to the smaller size of the water heater tank, slight dripping of the
pressure valve is normal due to water expansion when heating the water. One can minimize the
dripping by creating or replenishing an air pocket at the top of the tank using the following the
procedure list below.
1. Turn off the water heater
2. Turn off the water supply (if connected to city water) otherwise, turn off the water pump.
3. Open the Pressure Relief Valve by lifting up on the lever at top of relief valve. Relief valve is to remain
open until water stops flowing. Caution: protect yourself from the hot water following from the valve as
scalds and burn could occur.
4. Allow the valve to snap closed and turn on water pump or water supply and allow the system to refill.
This procedure will allow formation of a small air pocket at the top of tank. This air pocket will assist in
absorbing the expansion of water during future uses of the water heater. The water heater must be
drained when placed in storage or when subjected to freezing conditions. A water heater failure due to
freezing is considered misuse or abuse and is not covered under any warranty. Please see the water
heater owner’s manual supplied with the RV for further operating, use, and care instruction. WATER
HEATER BYPASS VALVE Your trailer may be equipped with a water heater bypass valve system. This is a
system of three valves located at rear of water heater accessible from inside the trailer. There will be a
valve on the top (hot output) water line, a valve at the bottom (cold inlet) in addition to one valve
located between the hot and cold lines. The purpose of this bypass system is the allow winterization of
the water system without filling the entire water heater with antifreeze. Closed Open Open Closed Valve
position for normal use. Valve position for water heater bypass Normal valve position Center valve is
closed with top and bottom valve open 39 Winterization (bypass) position of the valves: Close top and
bottom valve and open center valve. This position connects the hot and cold lines together and bypasses
the water heater. Note: always check the positioning of the water heater bypass valves if at any time if
the water heater is running but no hot water is available. The problem may be easily solved with proper
placement of the valves.

10
WATER LINE DRAINS
The freshwater system is typically equipped with at least one water drain which extend downward
below the chassis frame. Removal of the threaded drain cap will allow water to drain out of the fresh
water system. It will still be necessary to add RV antifreeze in order to fully winterize the water system.
WINTERIZATION OF PLUMBING SYSTEM
It will be necessary to winterize the water system of your RV when storing or using the trailer in
subfreezing weather. Failure to properly drain and winterize the water system will result in freeze
damage this is not covered under any warranty.
1. Park the recreational vehicle on a level surface.
2. Completely drain the black and grey waste water tanks.
3. Turn the water pump off, and then open all faucets, low-point drains, water heater exterior drain
plug, and fresh water tank drain.
4. When completely drained, close the faucets, and drains.
5. Remove water filter (if so equipped)
6. Position the water heater bypass valves to closed top and bottom with the center valve open. Note, if
properly drained of water, it is not necessary to fill the water heater with RV antifreeze. Antifreeze (and
water) is prevented from entering the water heater when valves are in the winterization mode.
7. Remove the inlet line to the water pump and connect a temporary hose from the inlet side of pump
to a container of RV antifreeze.
8. Run the water pump until the RV antifreeze flows freely and is visible on both the cold and hot
portions of each faucet.
9. Flush the toilet multiple times until the antifreeze is visible.
10. Add several cups of RV antifreeze to the kitchen sink drains, the bath sink drain and the tub/shower
drain.
11. Reinstall the drain plug on exterior of water heater.
12. Remove the temporary hose at water pump and reconnect original water line.
13. Only use non-toxic RV anti-freeze.
DO NOT use automotive antifreeze to winterize your RV as serious injury or death may occur from
ingestion of toxic antifreeze. Be sure to discuss winterization techniques and needs with your dealer
who is familiar with your local climate. 40 De - Winterization of the freshwater system, the following
procedures are recommended when removing the RV anti-freeze from the water system in preparation
of vehicle use.
1. Fill water tank with fresh water.
2. Turn on water pump.
3. Run the hot and cold side of each faucet until the water is no longer tinted by the RV antifreeze.
4. Flush toilet until water is clear.
5. Drain the fresh water tank.
6. Perform the water system sanitization as prescribed in this manual.
7. Install a new water filter (if so equipped).
8. Upon completion of the sanitization process, change the water heater bypass valves to the normal
position (top and bottom valves open and center closed). Reminder: do not turn on the water heater
until the water heater is completely filled with water.

11
WASTE WATER TANKS
The shower and sink water is discharged into a holding tank which is commonly referred to as a “Gray”
water tank. This tank connects to an exterior valve with a connection for sewer hose. The toilet waste
and water is discharged into a separate holding tank which is also referred to as a “Black” tank. This tank
also connects to an exterior valve adjacent to the “grey” valve.
EMPTYING THE WASTE WATER TANKS
1. Remove the exterior sewer valve outlet cover by turning it counterclockwise
2. Attach sewer hose to the valve outlet by placing the hose over the valve and turning it clockwise to
latch.
3. Place the other end into an approved dump station inlet making certain the hose is secured so as to
prevent movement when empting the tank.
4. Arrange the hose to slope downward from the trailer to the drain.
5. Open the Black drain valve (the larger valve) by pulling the valve handle away from the trailer.
6. Open the Gray drain valve (the smaller valve) by pulling the valve handle away from the trailer.
7. Allow both tanks to drain completely.
8. Run fresh water through both tanks to rinse the tanks.
9. Close both drain valves.
10. Remove the sewer hose and rinse hose with fresh water.
11. Secure sewer outlet cover.
12. Secure sewer hose.
13. Add odor control chemicals and two or three gallon of water to the Black water tank prior to your
next usage as this will assist in preventing build-up of solids. Waste tank tips • Only empty tanksinto an
approved dumping facility. It is unlawful to empty these tanks into sewer drains or other such
unapproved locations. • Solid waste build-up inside the black water tank is possible. It is recommend
you use adequate amounts of water when flushing the toilet as this will aid in rinsing out the tank when
emptying the tank. Should you have a problem with solids build- up in the black tank, close the valve, fill
the tank about ½ -3/4 full then drive around to agitate and loosen the solids. • Do not dump black tanks
until ¾ full. This practice assists in making certain that enough water is in the tank to flush out the tank
waste. If necessary, fill the tank with fresh water to the ¾ level prior to empting the tank. • Do not
introduce items such as paper, gum wrappers, sanitary products, cigarettes, facial tissues, paper towels,
and food scraps to the holding tanks. Note some of these items may state they are flushable; however
they are only flushable in home sewer systems. Addition of these items to the tank will likely cause
significant obstructions which will not be easily removed. Note: removal of foreign objects from holding
tanks is not covered under any warranty.
• State and local regulations may prohibit highway travel unless the holding tank outlet is securely
capped.
• Keep two garden hoses. One to fill the fresh water tank and one to rinse the sewer hose. Cross
contamination between the hoses may occur causing significant health risks.
• Use only biodegradable toilet tissues formulated for RV sewer systems
• Do not place any item into the tank that can puncture, damage or scratch the tanks.
• Use a deodorizing agent designed for RV use, in your black water tank
Follow the maintenance safety procedures.

12
FOLLOWING OPERATION
. Store the unit in an area away from human activity.
. Do not permit children to play on or around the stored unit.
. Make sure all parked machines are on a hard, level surface and engage all safety
devices.
. Wheel chocks may be needed to prevent unit from rolling.
FISH HOUSE WEIGHTS/ CAPACITIES:
MODEL DESCRIPTION GVWR UNIT WEIGHT CARRYING CAPACITY
A612 6.5 X 12 FT SGL CRANK 2990# 2680# 310#
A612SP 6.5 X 12 Ft SGL CRANK SPEAR 2990# 2720# 200#
A614RC 6.5 X 14 FT SGL CRANK 2990# 2840# 150#
A614RD 6.5 X 14 FT SGL CRANK 2990# 2815# 175#
A614FD 6.5 X 14 FT SGL CRANK 2990# 2810# 180#
A164FBH 8 X 16 FT SGL CRANK 5500# 4280# 1220#
A164RD 8 X 16 FT SGL CRANK 5500# 4260# 1240#
A164HYD 8 X 16 FT SGL HYD 7000# 4350# 2650#
817RD 8 X 17 FT SGL CRANK 5500# 4760# 740#
817RDHYD 8 X 17 FT SGL HYD 7000# 4860# 2140#
818RD 8 X 18 FT TANDEM HYD 7000# 5740# 1260#
8 X 21 FT TANDEM HYD 7000# 6460# 540#
RV EXPLORER WEIGHTS/ CAPACITIES
MODEL DESCRIPTION GVWR WEIGHT CAPACITY
17’RVEXPL 8 X 17 FT SGL CRANK 5500# 5140# 360#
17’RVEXPL 8 X 17 FT SGL HYD 7000# 5240# 1760#
20’RVEXPL 8 X 20 FT TANDEM HYD 7000# 6080# 920#
22’RVEXPL 8 X 22 FT TANDEM HYD 10,000# 6600# 3400#
24’RVEXPL 8 X 24 FT TANDEM HYD 10,000# 6800# 3200#
TOY HAULER MODELS
A164TH 8 X 16 FT SGL CRANK 5500# 4640# 860#
17’RVEXPLTH 8 X 17 FT SGL CRANK 5500# 5240# 260#
18’RVEXPLTH 8 X 18 FT TANDEM HYD 7000# 6060# 920#
24’RVEXPLTH 8 X 24 FT TANDEM HYD 10,000# 6820# 3180#

13
CARRYING CAPACITY EQUALS THE TOTAL OF WHAT IS BUILT ON
TO THE
FRAME PLUS ANYTHING THAT IS CARRIED IN THE UNIT WHEN
COMPLETE!
PERFORMING MAINTENANCE
. Good maintenance is your responsibility. Poor maintenance is an invitation to trouble.
. Be certain all moving parts on frame have come to a complete stop before attempting
To perform maintenance.
. Always use a safety support and block the wheels. Never us a jack to support the
frame.
. Always use the proper tools or equipment for the job at hand.
. Use extreme caution when making adjustments.
. Never replace hex bolts with less than grade five bolts unless otherwise specified.
. After servicing, be sure all tools, parts and service equipment are removed.
. Where replacement parts are necessary for periodic maintenance and servicing,
genuine factory replacement pats must be used to restore your equipment to original
specifications. The manufacturer will not claim responsibility for use of unapproved
parts and/or accessories and other damages as a result of their use.
. If equipment has been altered in any way from original design, the manufacturer does
not accept any liability for injury or warranty.
Most trailer axle bearings are unlike those in your motor vehicle in that
they require yearly maintenance to ensure reliable, safe operation of
your trailer.
Greasing Bearings
1. Remove dust cap to expose the axle nut.
2. Straighten cotter pin in order to remove pin from nut and axle.
3. Hub should now slide off of axle shaft.
Packing Bearings
Prior to repacking bearings, all grease must be removed from the hub/drum and
bearings. Bearings should be packed by machine or by hand methods to ensure that
grease is forced into the cavities between the rollers, cone and cage of the bearings.

14
Use a high temperature, automotive type wheel bearing grease to repack your
bearings. Once bearings are greased properly you are now ready to reassemble the
hub to the axle.
MAINTENANCE CHART
ITEM INTERVAL
Check tire pressure. Before transporting.
Check lug nuts for tightness. Before transporting.
Grease wheel bearings. Yearly.
Grease wheel assemblies & hinge points. Yearly.
Review safety instructions. Annually.
Clean & paint. As needed.
Sealing Roof Yearly.
Glacier desires that you have full enjoyment of
your new Glacier Ice House recreational vehicle.
If for any reason your vehicle is out of service
and cannot be used because of a manufacturing
or chassis defect for a cumulative total of seven
(7) days during the warranty period you are to

15
immediately contact Glacier LLC by certified
mail, return receipt requested, setting forth the
service problems and asking for immediate
assistance, RV Warrior is willing and able to
make every effort for a quick response.
WARRANTY SERVICE
1. GLACIER CARRIES A LIMITED ONE YEAR
WARRANTY FROM THE DATE OF
PURCHASE BY THE CUSTOMER
2. Warranty service under your Limited
Warranty is to be performed by your
authorized Glacier Ice House service
center. For those appliances and
equipment not maintained by Glacier
Ice House your dealer has a vested
interest in your satisfaction.
3. If you are traveling and an issue occurs,
service can be done by an authorized
dealer (with Glacier approval). Keep
your warranty registration form with
the vehicle at all times since it must be
presented for warranty service. This
form is your proof of purchase and
provides the date of retail sale, both of
which are necessary to determine
warranty eligibility.
4. If you cannot locate an authorized
Glacier Ice House Service Center
contact:
Glacier LLC
11287 ASH AVE
BRAINERD, MN 56401
218-454-1078 ph.
218-454-1079 fax
5. Other warranties –the retail customer
is responsible for completing and
forwarding warranty forms for all items
not covered by either the chassis
manufacturer’s or warranty.
Occasionally, a warranty or service matter may
not be handled to your satisfaction. In this
case, we recommend that you discuss the
problem with service center management. If
you are unable to find satisfaction at the dealer
level, please contact the Glacier Ice House
Service Department, where we will make our
best effort to reach an agreeable solution.
LP GAS HEATING AND LP GAS
APPLIANCE SAFETY REGULATIONS
The United States Government requires that
the manufacturer of this recreational vehicle
provide the following safety information by the
National Fire Prevention Association (NFPA) and
the American National Standards Institute
(ANSI).
WARNING: LP GAS CONTAINERS SHALL NOT BE
PLACED OR STORED INSIDE THE VEHICLE. LP
GAS CONTAINERS ARE EQUIPPED WITH SAFETY
DEVICES THAT RELIEVE EXCESSIVE PRESSURE BY
DISCHARGING GAS TO THE ATMOSPHERE.
WARNING: IT IS EXTREMELY DANGEROUS TO
USE COOKING APPLIANCES FOR COMFORT
HEATING. COOKING APPLIANCES NEED FRESH
AIR FOR SAFE OPERATION. BEFORE OPERATION
(1) OPEN THE OVERHEAD VENT OR TURN ON
AN EXHAUST FAN AND (2) OPEN A NEARBY
WINDOW. A WARNING LABLE HAS BEEN
PLACED IN THE COOKING AREA OF THE VEHICLE
TO REMIND YOU THAT YOU MUST PROVIDE AN
ADEQUATE SUPPLY OF FRESH AIR FOR
CUMBUSTION. UNLIKE HOMES, THE AMOUNT
OF AIR IN AN RV IS LESS DUE TO ITS LIMITED
SIZE (VOLUME). PROPER VENTILATION WHEN
USING COOKING APPLIANCES WILL AVOID THE
DANGERS OF ASPHYXIATION.
THE THREAT OF AXPHYXIATION INCREASES
WHEN A COOKING APPLIANCE IS USED FOR
LONG PERIODS OF TIME, THUS, THEY SHOULD
NEVER BE USED FOR INTERIOR HEATING
PURPOSES.
WARNING: PORTABLE FUEL-BURNING
EQUIPMENT, INCLUDING CHARCOAL GRILLS
AND STOVES, SHALL NOT BE USED INSIDE THE
RV. THE USE OF JTHIS CATEGORY OF

16
EQUIPMENT INSIDE AN ENCLOSED SPACE MAY
CAUSE ASPHYXIATION AND CREATES A FIRE
HAZARD.
WARNING: DO NOT BRING OR STORE LP GAS
CONTAINERS, GASOLINE OR OTHER
FLAMMABLE LIQUIDS, INSIDE THE VIHICLE DUE
TO THE POSSIBILITY OF EXPLOSION AND FIRE.
A warning label has been attached near the LP
gas container. The label reads: DO NOT FILL
CONTAINER(S) TO MORE THAN 80 PERCENT OF
CAPACITY.
Uncontrolled gas flow can result from overfilling
LP gas containers, resulting in a fire or
explosion. A properly filled container will
contain approximately 80 percent of its volume
as liquid.
The following label has been placed in the
cooking area of the vehicle:
IF YOU SMELL GAS:
1. Extinguish any open flame, pilot light
and smoking material.
2. Do not touch any electrical switch.
3. Shut off the LP gas supply at the tank
valve(s) or gas supply connection.
4. Open doors and other ventilation
openings.
5. Leave the area until the odor clears.
6. Have the gas system checked and
leakage source corrected before using
again.
LP gas regulators must always be installed with
the diaphragm vent facing down. Regulators
that are not in compartments have been
equipped with a protective cover. Make sure
the regulators vent faces down and the cover is
kept in place to minimize vent blockage;
blockage could result in excessive gas pressure
and, therefore, possibly cause a fire or
explosion.
Notice: All LP gas regulators are factory tested
for proper pressure output. Pressure output
should be checked periodically by a qualified LP
dealer. Only qualified persons should install,
adjust or service LP gas regulators. If service is
needed contact a qualified LP dealer.
GENERAL SAFETY
FIRE SAFETY
Prevention is the best form of fire safety.
Carefully follow the instructions for the care
and operation of the various appliances in your
vehicle (see appropriate sections).
Follow the same basic rules of fire prevention
that you use at home. DO NOT SMOKE IN BED.
DO NOT OVERLOAD THE ELECTRICAL SYSTEM.
DO NOT PERMIT CHILDREN NEAR THE LP GAS
CONTROLS OR CONTAINER. DO NOT STARE
FLAMMABLE LIQUIDS INSIDE THE UNIT.
Carry-over your preparedness from your home
to your Glacier Ice House by having a pre-
planned escape route. BE SURE EVERYONE
KNOWS WHERE THE EMERGENCY EXIT IS
LOCATED AND HOW IT OPERATES.
Your Glacier Ice House is equipped with a fire
extinguisher. MAKE SURE EVERYONE KNOWS
WHERE IT IS LOCATED, HOW TO OPERATE IT
AND WHAT TYPES OF FIRES IT IS DESIGNED TO
HANDLE.
Check the fire extinguisher on a regular basis to
make sure it is charged.
SMOKE DETECTOR
All units are equipped with a smoke detector.
Check its operations on a regular basis. If it
does not check properly, get it serviced or
replaced prior to using the vehicle again.
NOTE: IF A FIRE DOES START WITHING THE
UNIT, GET ALL OCCUPANTS OUT IMMEDIATELY.
IF IT IS A SMALL FIRE, USE THE FIRE
EXTINGUISHER. IF THE FIRE IS NOT QUICKLY
PUT OUT, GET OUT OF THE VEHICLE. CONTACT

17
THE FIRE DEPARTMENT. IF POSSIBLE, CLOSE
THE LP GAS SERVICE VALVE. MOVE A SAFE
DISTANCE FROM THE VEHICLE.
CARBON MONOXIDE SAFETY
Carbon Monoxide is a colorless, odorless,
tasteless gas, which can be fatal if a high
concentration builds up in a sealed area over a
period of time. Carbon monoxide is a by-
product of burning fuel, and is found in high
concentrations in exhaust from gas burning
engines. A water heater or furnace operating
improperly can also produce Carbon Monoxide.
Under normal conditions your Glacier Ice House
should be free from Carbon Monoxide at any
given time. Due to the safety hazards of Carbon
Monoxide (CO), each Glacier Ice House is
equipped with a CO Detector.
Carefully read the instructions included with
your CO detector to ensure proper use and
maintenance. Most CO detectors require only
occasional dusting and weekly testing. DO NOT
use any type of cleaner when dusting your CO
detector. Doing so may render the unit useless
without warning.
Carbon Monoxide is often confused with illness
such as “flu like symptoms” (Headaches,
nausea, dizziness). Such symptoms should be
discussed with all vehicle occupants. RV
certified CO detectors will sound an alarm if 100
PPM (parts per million) if CO is present within
90 minutes. 50 PPM is allowed in a work place
for up to 8 hours. Cigarette smoke contains
about 5 PPM Carbon Monoxide.
If your CO alarm sounds, exit the vehicle
immediately. After exiting the vehicle take a
head count and make sure everyone is
accounted for. Air out the vehicle and check
again to ensure that the alarm came from the
CO detector, as your vehicle is also equipped
with a smoke detector. Following instructions
included with your CO detector is
recommended.
LP GAS SAFETY
LP appliances should never be operated while
the vehicle is in motion.
If the pungent odor of LP gas is detected,
immediately shut off the LP gas valve and check
the LP gas label for further instructions.
Check other sections of this manual for more
information on the LP gas system.
VEHICLE LOADING
CARRYING CAPACITY
During the design and development of our
Glacier units the number and size of storage
compartments and the liquid tank capacities are
maximized for value and convenience. If the
operator fills all liquid tanks to capacity, fills all
storage compartments and cupboards to
maximum volume the vehicle will probably be
overloaded. According to National Highway
Traffic Safety Administration figures, an average
occupant weighs 150 pounds and each gallon of
water weighs over eight (8) pounds. The
operator is responsible for analyzing the
conditions in which the RV will be utilized for
each trip and ensuring the RV is not overloaded.
The placement of cargo will affect the amount
of water and cargo that you can carry. It may
be necessary to reduce the amount of water
carried and unload some cargo items normally
carried in order to provide for larger carrying
capacity.
WARNING: DO NOT EXCEED THE RATED LOAD
OF THE RV OR THE RATED LOAD OF ANY AXLE.
NOTE: THE CARRYING CAPACITY OF YOUR RV
CAN BE DETERMINED BY WEIGHING. THE
SHIPPING WEIGHT DOES NOT NORMALLY
INCLUDE OPTIONS SUCH AS AWNINGS, ROOF
PODS, EXTRA CABINETS, ETC. THE WEIGHT OF

18
THESE ITEMS MUST BE SUBTRACTED FROM THE
TOTAL OF THE CARGO CARRYING CAPACITY.
Notice: If your RV is equipped with holding
tanks, empty the holding tanks before filling
fresh water tank otherwise you will limit cargo
capacity.
LOADING TIPS
After you have determined how much weight
you can safely carry and selected those items to
make up that weight, make a list and keep it for
future reference. Load the RV and distribute
the load so that you get proper weight on the
axle(s). Do not load upper cabinets with heavy
items. Secure and brace items so they won’t
move during travel, thereby shifting the load in
the RV. Do not load heavy items near either
end of the RV. Adjust cargo storage to keep the
side to side wheel loads as equal as possible. If
your RV has holding tanks, carry only as much
water as needed for travel use or to balance the
load. Always empty your waste water and
sewage holding tanks before traveling.
WARNING: DO NOT INSTALL ANY TYPE OF
WEIGHT CARRYING RACK OR FRAME TO THE RV.
DAMAGE TO THE RV AND UNSTABLE HANDLING
CHARACTERISTICS MAY RESULT.
WARNING: EXCEEDING THE GAWR, GVWR OR
GCWR OF YOUR RV CAN CAUSE UNDESIREABLE
HANDLING CHARACTERISTICS AND MAHY
CREATE A SAFETY HAZARD. MODIFICATION OF
YOUR VEHICLE BY ADDITION OF RACKS NOT
SPECIFIED BY THE MANUFACTURER TO CARRY
ADDITIONAL EQUIPMENT OR VEHICLE IS NOT
RECOMMENDED, MAY CREATE A SAFETY
HAZARD AND MAY VOID YOUR WARRANTY.
Make a loading diagram of your properly loaded
RV. It will help you locate where specific items
are stored, and will help speed the loading
process. Store emergency items in a readily
accessible location. Include tools, first-aid kit,
rain gear, flashlight, highway warning devices
and an electric cord or light.
The difference between the empty weight and
the weight of the RV in traveling configuration is
your usable load. If the loaded weight of your
RV exceeds the GVWR or the weight on any axle
exceeds that axle's GAWR, the RV is overloaded
and you’ll have to remove items to bring the
weight down to or below the GVWR and GAWR.
All items must be considered for their weight
and stored according to how heavy they are.
Heavy items should be placed close to the floor
and in the center of the vehicle. Luggage and
similar cargo carried inside the RV must be
secure to prevent possible damage in the case
of a sudden stop or an accident.
MANUFACTURER’S LABELS
Your vehicle is equipped with several federally
required labels pertaining to the vehicle’s
weight, load capacity and operating limitations.
On the outside of the vehicle on the driver’s
side is the sticker that lists the manufacturer’s
serial number, the axle(s) GROSS AXLE WEIGHT
RATING (GAWR), the vehicle’s GROSS VEHICLE
WEIGHT RATING (GVWR), tire and wheel rim
sizes, tire operating pressure, and the VEHICLE
IDENTIFICATION NUMBER (VIN). (FIG 1)
FIG 1
FEDERAL WEIGHT DEFINITIONS
GAWR: The allowable weight, INCLUDING
CARGO AND PASSENGERS, which can be SAFELY
supported by a specified axle.

19
GVWR: The maximum permissible weight of
your vehicle, INCLUDING CARGO, ALL OPTIONS,
PASSENGERS, GASOLINE AND WATER.
USEFUL WEIGHTS:
Water –8.328 pounds per gallon
Gasoline –6.0 pounds per gallon
TIRES
The tires installed on your RV have been
preselected as the proper size and weight for
the type of RV built. The tag located on the
outside of the RV will show the proper tire size
for your RV. When replacing tires, make sure
these guidelines are followed:
TIRE MARKINGS
Sample tire size: LT225/75R 16 E
•LT reflects the “Light Truck” usage.
Light truck tires are used on anything
from compact pickups to class A motor
homes.
•225 indicates the “contact patch”
width. The contact patch is the amount
of tire surface that actually comes into
contact with the pavement. In this case
the width is 225 millimeters wide.
•75 indicates the height to width ratio of
the tires.
•R identifies the construction type of the
tire. R-Radial, B-Bias belted, D-Diagonal
Bias. Some tires may have a speed
designation label in front of the
construction type. Example –MR tires
are rated for use up to 81 mph. SR tires
up to 112 mph. ZR tires carry the
highest speed rating, and are safe for
speed over 150 mph. However, ZR tires
should never be installed on any motor
home or travel trailer. If no speed
rating is listed on the sidewall, the
maximum speed for light truck tires is
87 mph, and for passenger cars 105
mph.
•16” is the rim size. This is the only
measurement made in inches.
•E is the load range.
TIRE LOAD RATINGS
Load ratings for tires go up as the
corresponding letter changes. For example,
load range “E” tires have a heavier rating than
load range “D” tires. Load capabilities of tires
can change as the psi (air pressure) is lowered.
As much as 220 lbs. of load carry capacity is lost
per tire for each 5 psi below the recommended
inflation. This decreased load amount varies
from one tire manufacturer to the next;
therefore it is recommended that you contract
your tire manufacturer for further information
in this regard.
TIRE AIR PRESSURE
When checking air pressures, if the tire has
been driven more than 6 miles, you can add 4-6
psi to the rated maximum “cold” inflation
recommendations. For example, if the tire has
a maximum rating of 90 psi cold, you can inflate
the tire to 96 psi after being driven on. Under
inflation generates excessive heat (a tire’s worst
enemy!), increases tread wear in the shoulder
area, and reduces your vehicle’s fuel economy.
Never mix radial, bias belter or bias type tires.
Never mix brand names. This can adversely
affect vehicle handling and stability. Use only
the tire size that is listed on the Safety
Compliance Certification Label.
TIRE MAINTENANCE
When cleaning tires, try to use a tire-cleaning
agent. Never use any cleaner that contains
solvents. Solvents will draw oil from tires and
cause them to prematurely crack. Inspect your
tires prior to each trip, looking for bulges or
cracks in sidewalls.
When storing your RV for long periods you
should completely unload the vehicle so that a
minimum weight will be placed on the tires.
Make sure the tires are inflated to the

20
recommended operation inflation pressure.
Move the vehicle at least every three months to
prevent ozone cracking in the tire bulge area as
well as “flat spotting” from prolonged strain of
sidewall and tread deflection. Make sure you
check the inflation and adjust to the
recommended operating pressure before
putting the vehicle back into service.
ELECTRICAL SYSTEM
Your Glacier RV is equipped with two (2)
separate electrical systems that provide your
vehicle with power.
12-VOLT DC/110-VOLT AC
Like all vehicles, it has a 12-volt system that is
used for running the vehicle’s equipment
designed for 12-volt operation as well as other
accessories. This is a direct current (DC) system
(12V).
Like your home, the vehicle has a 110-volt
alternation current (AC) system that requires an
external source of 110-volt electricity. A
shoreline connection (extension cord) or a
power generator or an inverter can provide this
power. In order to use your 12-volt electrical
system, your shoreline (power cord) should be
plugged into either a properly rated external
power source or the generator should be
running, or in some cases the inverter should be
turned on. TO CONSERVE BATTERY POWER,
USE OF THE SHORELINE IS RECOMMENDED
WHENEVER POSSIBLE.
Consult your generator’s manufacturer’s
owner’s manual for further details on its use
and maintenance.
DO NOT USE A CHEATER PLUG TO HOOK UP
YOUR MOTOR HOME TO A 110-VOLT CIRCUIT.
DO NOT USE AN EXTENSION CORD WITH A
CURRENT RATING LESS THAN THE AMPERAGE
YOUR RV REQUIRES. EXTRA EXTENSION CORDS
REDUCE THE AMPERAGE AND VOLTAGE BEING
SUPPLIED TO THE RV AND MAY CAUSE DAMAGE
TO ELECTRICAL COMPONENTS.
30-AMP 110-VOLT SERVICE
Your Glacier RV comes with a 30-amp service.
30-amp service is 110-volt service limited to a
total of 30 amps of draw. A three pronged
power supply cord much like your clothes dryer
would have in your house identifies this type of
power supply. Each appliance in your vehicle is
capable of working by itself with this type of
service. However, you may not be able to
operate all your appliances at the same time
without causing a circuit breaker to blow.
A typical component in your vehicle such as a
TV or VCR will draw only about 1 amp. Other
items such as coffee makers and microwaves
will draw 10-15 amps when used. Roof air
conditioners usually draw the most, pulling up
to 15 amps when the compressor is running.
Using other items in your coach such as
converters, refrigerators, water heaters, etc.
may put your draw over the 30-amp mark
causing a circuit break.
30-amp service is the most common electrical
service in the RV industry and can be found at
most, if not all, RV campgrounds. This makes
30-amp service the most user friendly as far as
availability.
Listed are components that might be used in
Glacier vehicles and the maximum amperage
draw each one has:
•Roof A/C unit –15 amps
•Electrical water heater –12 amps
•Microwave –15 amps
•TV –1 amp
•Refrigerator –3.5 amps
POWER CONVERTER
