MODEL SPECIFIC MANUAL 1. INTRODUCTION
REV September 22, 2022 11
1. INTRODUCTION
Congratulations! Thank you for selecting a Leisure
Travel Vans Motorhome.
Welcome to the exciting world of motorhome travel
and camping, with all the comforts of home with you,
while you travel and enjoy the outdoors.
Your motorhome has been designed and manufactured
to enhance your travel and camping experience and
to provide you with safe, ecient and trouble-free
operation.
Before your first drive, become familiar with the
operation of the vehicle chassis and all functions and
operations of the motorhome. Spend adequate time
with your dealer when you take delivery to learn all
you can about your new motorhome.
SUPPLEMENTAL MANUAL
This manual was prepared to aid the operator and
occupants in the operation and care of the motorhome
by giving specic information about your model. There
are many options to Leisure Travel Vans, so ensure
that you are familiar with your motorhome’s systems
and equipment. All operators and occupants of the
motorhome should read, understand and follow
the instructions in this manual, the vehicle chassis
manual &the information contained in the Motorhome
Information Kit provided with your new motorhome.
Your motorhome contains a number of systems,
components, equipment, and appliances manufactured
by vendors that supply components for Triple E RV.
These vendors are unrelated to Triple E RV.
Before operating the motorhome for the rst time –
even if an experienced motorhome operator – read
and become familiar with all of the relevant manuals
to your motorhome, components, equipment and
appliances provided in the Motorhome Information
Kit. Your familiarity with the detailed operation of
your motorhome will assist in your safe, ecient and
trouble-free motorhome operation.
KEEP the Motorhome Information Kit within your
motorhome for readily available reference.
PASS this manual, the Chassis Operation Manual and
the Motorhome Information Kit to any subsequent
operator or owner.
For clarication or further details on any ofthe enclosed
information, please contact:
Your Leisure Travel Vans Dealer orTriple E RV Customer
Service at:
Email: [e-mail]
Toll Free: 8779929906
Telephone: 2043254361
Fax: 2043255241

1. INTRODUCTION MODEL SPECIFIC MANUAL
12 REV September 22, 2022
MOTORHOME INFORMATION KIT
The Motorhome Information Kit includes but isn’t
limited to information on the components, equipment
and appliances listed below (based on options
selected).
•Refrigerator
•Stove top
•Furnace
•Electrical Panel
•Toilet
•Water Heater
•Water Pump
•Water Filtration
•Vent (roof)
•Fire Extinguisher
•Smoke Detector
•Thermostat
•CO Detector
•Propane Detector
•Gas Regulator
•TV Antenna
•TV/DVD
•Chassis
•Air Conditioner
•Generator
•Stabilizers/Leveling Jacks
•Rear View Monitor
•Inverter
•Entertainment System
•Safety
•Flooring and Countertops
•Electric Step
•Solar Panel
•Surge Protector
•Safe
•Awning
OPTIONS AND EQUIPMENT
Leisure Travel Vans are available in various sizes
and floor plan configurations and with differing
optional equipment. The equipment, accessories and
components described in this manual may not apply
in all respects to your motorhome. Read the material
and manuals provided in the Motorhome Information
Kit for detailed instructions regarding the equipment
specic to your motorhome.
SERVICE ASSISTANCE
Your dealer will assist you with any additional
information you need and will answer any questions
you have about the operation of your motorhome.
When it’s time to service the vehicle, remember
that your dealer knows your motorhome best and is
dedicated to your satisfaction. Your dealer will provide
quality maintenance and assistance during your period
ownership. Triple E RV strongly recommends that you
follow a regular maintenance schedule to keep your
motorhome functioning at its best.
Call the following numbers if you require warranty
assistance while traveling:
Triple E RV: 1-877-992-9906
Canada Sprinter Customer Service:
1-800-387-0100 www.thesprinter.ca
US Sprinter Customer Service:
1-877-762-8267 www.mbsprinterusa.com
Canada Ford Customer Service:
1-800-565-3673 www.ford.ca
US Ford Customer Service:
1-800-392-3673 www.ford.com
Emergency Roadside Service* Call:
1-877-219-3831
4287 Beltline Road, Box 198
Addison, Texas 75001
*This Emergency Roadside Service is available to
owner of the motorhome during the rst two years
after purchase.

MODEL SPECIFIC MANUAL 1. INTRODUCTION
REV September 22, 2022 13
REPORTING SAFETY DEFECTS
If you suspect your motorhome has a safety defect
that could cause injury or death, immediately contact
Triple E RV. Also, contact the National Highway Trac
Safety Administration (NHTSA) in the US orTransport
Canada to report your concern.
NHTSA will investigate the concern if there are a
number of similar complaints. NHTSA has the authority
to order a recall and repair campaign depending on
the nature and severity of the problem.
You can reach the NHTSA by calling the Auto Safety
Hot-line at 18004249393 (2023660123 in the
Washington, DC, area) or by writing to NHTSA, US
Department ofTransportation, Washington, DC 20590.
The hot-line also will provide you with additional
information on motor vehicle safety.
In Canada, call 18003330510 or write to Transport
Canada and Road Safety, 2780 Sheeld Road, Ottawa,
Ontario K1B 3V9.

MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION
REV September 22, 2022 21
2. GENERAL INFORMATION
FLOOR PLAN
LEISURE LOUNGE
4
5
6
7
8
9
10
11
12
13
14
16
17
19
20
21
22
23
24
25
26
27
28
29
30
37
38
39
41
42
43
44
45
46
47
35
32 31
36
40
48
18
1 2
3
34
49 50
51
15
33
18
52
1Macerator Option Under Floor
2Utility Center Under Floor
3Water Tank/Drain Under Floor
4Water Heater Under Galley
5
Surge Protector on Wardrobe Floor
6Shore Power Plug
7
GeneratorTransfer Switch Behind
Wardrobe Drawers
8Propane Tank Under Floor
9Sewer Hose Under Slide Out
10 DC/DC Charger under Seat
11
Step Switch, battery heat, G12
RTC shared 5A fuse under TV
12
Chassis Batteries Under Captain
Seat
13 12 Volt Plug and USB Plug
14 Swivel Seats
15
Battery Power and Ignition Fuses
under Driver Seat
16
Awning Switch on Passenger
Seat Pedestal
17
Battery Disconnect Switch on
Cabinet Wall
18 Wardrobe
19 Fire Extinguisher
20
Solar Controller, Inverter Remote,
and Water Heater Dial above
Entrance Door
21 MultiPlex Display
22 Smoke Alarm on Ceiling
23 Propane/CMD Alarm
24 USB Plug
25 TV
26
Coach Batteries In Compartment
Under Floor (Solar panel 30A fuse
behind batteries)
27 Inverter In Compartment Under
Floor
28
MultiPlex G12 Panel Board
behind cover
29 BluRay Player
30 USB Plug
31 Generator Option Under Floor
32
Exterior BBQ Connection Under
Floor
33 Furnace Under Wardrobe
34 Exterior Storage
35 Toilet
36 Shower
37 Fridge (2A fuse behind Exterior
vent) Microwave Above
38 Pull Out Pantry
39
Thermostat Sensor on Fridge Wall
40 Water Pump Under Vanity
41 Galley
42 Breaker Panel
43
Satellite Option Prewire and
Component Connection Plate Under
cabinet
44 Dinette
45 Murphy Bed
46 Slide Module
47
TV Antenna Booster/WIFI Switch
in Overhead cabinet
48 Water Filter under vanity
49
Tank Flush Non Return Valve
Behind Faucet Access
50 Subwoofer
51
Chassis Battery Under Cab Floor
/100Amp Fuse Under Seat
52 Interior/Exterior Storage

2. GENERAL INFORMATION MODEL SPECIFIC MANUAL
22 REV September 22, 2022
LEISURE LOUNGE PLUS
4
5
6
7
8
9
10
11
12
13
14
16
17
19
20
21
22
23
24
25
26
27
28
29
30
37
38
39
41
42
43
44
45
46
47
35
32 31
36
40
48
18
1 2
3
34
49 50
51
15
33
18
52
1Macerator Option Under Floor
2Utility Center Under Floor
3Water Tank/Drain Under Floor
4Water Heater Under Galley
5
Surge Protector on Wardrobe
Floor
6Shore Power Plug
7
GeneratorTransfer Switch Behind
Wardrobe Drawers
8Propane Tank Under Floor
9Sewer Hose Under Slide Out
10 DC/DC Charger under Seat
11
Step Switch, battery heat, G12
RTC shared 5A fuse under TV
12
Chassis Batteries Under Captain
Seat
13 12 Volt Plug and USB Plug
14 Swivel Seats
15
Battery Power and Ignition Fuses
under Driver Seat
16
Awning Switch on Passenger
Seat Pedestal
17
Battery Disconnect Switch on
Cabinet Wall
18 Wardrobe
19 Fire Extinguisher
20
Solar Controller, Inverter Remote,
and Water Heater Dial above
Entrance Door
21 MultiPlex Display
22 Smoke Alarm on Ceiling
23 Propane/CMD Alarm
24 USB Plug
25 TV
26
Coach Batteries In Compartment
Under Floor (Solar panel 30A fuse
behind batteries)
27 Inverter In Compartment Under
Floor
28
MultiPlex G12 Panel Board
behind cover
29 BluRay Player
30 USB Plug
31 Generator Option Under Floor
32
Exterior BBQ Connection Under
Floor
33 Furnace Under Wardrobe
34 Exterior Storage
35 Toilet
36 Shower
37 Fridge (2A fuse behind Exterior
vent) Microwave Above
38 Pull Out Pantry
39
Thermostat Sensor on Fridge
Wall
40 Water Pump Under Vanity
41 Galley
42 Breaker Panel
43
Satellite Option Prewire and
Component Connection Plate Under
cabinet
44 Dinette
45 Murphy Bed
46 Slide Module
47
TV Antenna Booster/WIFI Switch
in Overhead cabinet
48 Water Filter under vanity
49
Tank Flush Non Return Valve
Behind Faucet Access
50 Subwoofer
51
Chassis Battery Under Cab Floor
/100Amp Fuse Under Seat
52 Interior/Exterior Storage

MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION
REV September 22, 2022 23
EXTERIOR EQUIPMENT LOCATION
PASSENGER SIDE VIEW
1Light
2Refrigerator Vents
3External Receptacle
4Awning
5Entrance Step
6BBQ Hook-Up
7Storage Compartment
8
Inverter and Storage
Compartment
9Furnace Exhaust
10 Generator Compartment
11 Ladder
1
22
3
4
5
6
77
8
9
10
11
DRIVER SIDE VIEW
1Awning
2Slide Out Room
3Water Heater
4Diesel Fill
5Storage Compartment
6
Sewer Hose Hatch (Behind
Doors)
7Shore Power Connection
8Utility Center
9Sewer Termination
1 2
34 55 6 7 8 9

2. GENERAL INFORMATION MODEL SPECIFIC MANUAL
24 REV September 22, 2022
TOP VIEW
1Solar Panel (Optional)
2Roof Vent
3Sky Light
4Air Conditioner
5WiFi/TV Antenna
6Satellite (Optional)
7Stack Vent
111
12
23
3
4
56
7

MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION
REV September 22, 2022 25
BEDS AND SEATING
LEISURE LOUNGE PLUS SYSTEM
(OPTIONAL)
LOWERING THE MURPHY BED
1. Refer to the “Slide Out Room” section in the
“Motorhome Operation” section for details.
2. Raise the table
1
, secure in upright position with
latch 3and fold support/small table 2.
1
2
3
3. Ensure lounge chairs are in the fully upright
position using recliner buttons 4on the side of
the chair.
4 5
4. Rotate the lounge chairs so they are facing away
from bed by lifting and holding the lock button
5
while you swivel the seat. Release the lock button
when the chair is slightly rotated to ensure the seat
locks into the next position.
5. Remove the lounge chair seat back cushions and
headrests and fold the seat backs forward until
they lay at 6.
66
6. Release the locks on both sides of the Murphybed
(rotate to unlock).
7. Slowly and carefully lower the Murphy bed. Ensure
the Murphy bed locks into place once fully lowered
by lifting slightly on the side of the bed. If bed is
not locked, sit on corner of bed to apply additional
downward pressure.
8. Lower step cover
7
. Refer to the “Step Cover”
section in the “Motorhome Operation” section
for details.
7
ᘐCAUTION
Lower the step cover when lounge chairs
are in recliner mode
7
to prevent tripping
accidents. Refer to the “Step Cover” section
in the “Motorhome Operation” section of this
manual for detailed instructions.

2. GENERAL INFORMATION MODEL SPECIFIC MANUAL
26 REV September 22, 2022
RAISING THE MURPHY BED
1. Pull the adjustable headboard/backrest
1
toward
you for desired comfort. To collapse headboard/
backrest, pull it out all the way and it will release.
Push it back toward the wall.
1
2. Ensure both Murphy bed reading lights
2
are
switched o by pressing the lens on/o button
3
2
3
3. Pull the release strap
4
and slowly raise the
Murphybed.
4
ᘐCAUTION
Failure to pull the release strap will cause damage
to the Murphy Bed
4. Rotate the locks 5on both sides of the Murphy
bed to secure the bed in place.
5

MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION
REV September 22, 2022 27
LEISURE LOUNGE PLUS SEATING
Leisure lounge recliners can be congured as follows:
• Coee Table
6
: Use the small ip-up coee table/
support for a dinette table or to support large table.
Stow the table
7
in the wall of the bed
8
when
not in use. Use the chairs
9
on each side of the
tables as required.
6
7
99
8
99
•Armchair Seating 10 : You can rotate the chairs by
lifting and holding the lock button 11 on the side
of the chair and releasing the lock when the chair
is at the desired angle.
10
13 11
•Recliner Seating 12 : Push the recliner buttons 13
on the side of the chair to recline the seats.
12
NOTE: The dinette table must be stowed when using
the lounge chairs in armchair or recliner mode. Refer
to the “Lowering the Murphy Bed” instructions in this
section for details.

2. GENERAL INFORMATION MODEL SPECIFIC MANUAL
28 REV September 22, 2022
LEISURE LOUNGE SEATING
1. Bench conguration 1.
1
2. Seats with table conguration 2.
2
3. Seats pulled out (Pull out seats before lowering
Murphy bed) 3.
3
4. Bed down with the headboard tilted out as
backrest 4.
4

MODEL SPECIFIC MANUAL 2. GENERAL INFORMATION
REV September 22, 2022 29
TV LOCATION
The TV is stowed in the coach passenger side
countertop 5and is accessed by pulling the release
lever 6located at the coach entrance.
6
5
NOTE: The TV will rise from the cabinet under spring
tension. Ensure the top of the TV cabinet is clear
before opening.
To store, push down on the center of the cover panel
10
to lower the TV into the cabinet until the TV assembly
latches.
NOTE: Push down only in the center of the cover panel
to prevent damaging the panel.
NOTE: When traveling, ensure the TV is latched in the
stored position.

MODEL SPECIFIC MANUAL 3. SCHEMATICS
REV September 22, 2022 31
3. SCHEMATICS
ELECTRICAL
12 VOLT ELECTRICAL REFERENCE
U24MB 12V ELECTRICAL WIRING SCHEMATIC
PLEASE REFER TO FUSE PANEL LABELS FOR EXACT LAYOUT
1
2
3
4
27
7
8
9
10
11
12
13
14
16
17
18
19
20
21
22
23
24
4
26
15
6
5
25
1Macerator Pump (Optional)
2Water Pump
3Water Heater
4
Power Roof Vent (Washroom/Galley)
5Multiplex System
6Winegard Connect 2.0
7Satellite Dish (Optional)
8Furnace
9Fridge
10 DC Fuse Panel
11 Air Conditioner
12 USB Chargers
13 Light Circuits
14 Inverter
15 120V AC Power Input
16 AGM Low Voltage Disconnect
17 RV Batteries
18 Solar Charge Controller
19 DC/DC Charger
20 Chassis Battery
21 Awning
22 Battery Disconnect
23
Lithium Battery Heat Enable Switch
(Optional)
24
Solar Panels (200W or 400W
Optional)
25 Generator (Optional)
26 Leveling Jacks (Optional)
27 Slide Module

3. SCHEMATICS MODEL SPECIFIC MANUAL
32 REV September 22, 2022
120 VOLT ELECTRICAL REFERENCE
U24MB 30 AMP 120V ELECTRICAL WIRING SCHEMATIC
PLEASE REFER TO BREAKER PANEL LABELS FOR EXACT LAYOUT
30 AMP
POWER
CORD
10 11 12
15
14
17
9
13
2
6
7
8
5
41
3
16
1AC Distribution Panel
2Air Conditioner
3Inverter/Charger
4Fridge
5Microwave
6Surge Protector
7Transfer Switch
8Generator
9
Generator Current Switch (Diesel
Option)
10 Lower Galley Receptacle
11
Subwoofer/Power Chairs
Receptacle
12 Bed Receptacle
13 Washroom Receptacle
14 Lower Entertainment Receptacle
15 Sound Bar Receptacle
16 Entertainment
17 Exterior Receptacle
