Haier LET40T3 User manual

Please read this manual carefully before operating the unit, and keep it
for future reference.
DIGITAL LED LCD TELEVISION
INSTRUCTION MANUAL

Contents
EN-1 Digital LED LCD Television Instruction Manual
Content
Safety Warnings 2
WELCOME ............................................................. 2
IMPORTANT INFORMATION ................................ 2
About your LED LCD TV 5
INSTALLING THE STAND ...................................... 5
GET TO KNOW YOUR TV....................................... 6
Front control panel............................................................... 6
Rear TerminalsControl ...................................................... 6
GET TO KNOW YOUR REMOTE CONTROL ........... 7
CONNECTING YOUR TV........................................ 8
ANTENNA CONNECTION .................................................... 8
IMPROVE YOUR SIGNAL ...................................................... 8
CONNECT YOUR PC TO THE TV ......................................... 8
CONNECT A DVD PLAYER TO YOUR TV .......................... 8
CONNECT A DVD PLAYER OR VCR TO YOUR TV .......... 8
Connection Option 1 ........................................................... 8
Connection Option 2 ........................................................... 8
SCART INPUT........................................................................... 8
HDMI INPUT............................................................................. 9
MOUNT YOUR TV ONTO THE WALL................................. 9
PREPARATION OF YOUR REMOTE CONTROL...... 9
BATTERY INSTALLATION...................................................... 9
BATTERY CAUTION................................................................ 9
Getting Started 9
SETTING UP .......................................................... 9
LOCATION................................................................................. 9
CONNECTION.......................................................................... 9
SWITCHING YOUR TV ON ..................................................10
TUNING YOUR TV ............................................... 10
SWITCHING TO AN EXTERNAL SOURCE OTHER THAN
THE TV .....................................................................................10
AUTO SEARCH.......................................................................10
DIGITAL MANUAL SEARCH...............................................10
Analog Manual Search ......................................................11
Channel Edit..........................................................................11
RENAME..................................................................................12
MOVE .......................................................................................12
Setting favourite channel.................................................12
SKIP...........................................................................................12
GUIDE (Electronic Program Guide)...............................12
COMMON INTERFACE ........................................ 13
Software Update function ...............................................13
Operation...............................................................................14
USING YOUR TV.................................................. 14
How to select the TV program........................................14
HOW to adjust volume......................................................14
CH.LIST function ..................................................................15
ADJUSTING PICTURE SETTINGS ....................... 15
Changing the Picture Setting .........................................15
ADJUSTING SOUND SETTINGS ......................... 15
Changing the Sound Setting ..........................................15
FUNCTION SETTINGS......................................... 16
TIME SETTINGS .................................................. 17
LOCK MENU SETTING ........................................ 19
SHORTCUT MENU DISPLAY ............................... 20
Using the features 22
TELETEXT FUNCTIONS....................................... 22
Teletext....................................................................................22
USB MODE .......................................................... 23
TO USE THE USB DEVICE ...................................................23
When connecting/removing the USB device ...........23
Operating the USB device................................................24
Playing aPicture ..................................................................24
Playing Music........................................................................24
Playing aMovie....................................................................25
Text...........................................................................................25
USING EXTERNAL USB DISK FOR RECORDING. 25
TIME SHIFT .............................................................................26
RECORDING ...........................................................................26
Reference Sections 27
TROUBLESHOOTING.......................................... 27
SPECIFICATION................................................... 28

Safety Warnings
Digital LED LCD Television Instruction Manual EN-2
8"3/*/(
5PBWPJEFMFDUSJDIB[BSETJUJTTUSPOHMZTVHHFTUFEUIBUUIFCBDLDPWFSOPUCFPQFOFEBT
UIFSFBSFOPBDDFTTPSJFTJOTJEFUIFDBTJOH
*G OFDFTTBSZ QMFBTF DPOUBDU BVUIPSJ[FE BGUFSTBMFT TFSWJDFT
DPVMESFTVMUJOTFSJPVTJOKVSZCZIJHIWPMUBHF
"O FYDMBNBUJPO NBSL JO B USJBOHMF .BKPS QBSU PS BDDFTTPSZ PG XIJDI UFDIOJDBM
NVTU CF GPMMPXFE J U JT UP CF SFQMBDFE
8"3/*/(
3*4,0'&-&$53*$4)0$,
%0/0501&/
503&%6$&5)&3*4,0'&-&$53*$4)0$,%0/053&.07&$07&303#"$,/0
64&34&37*$&"#-&1"354*/4*%&3&'&35026"-*'*&%4&37*$&1&340//&-
FI
Safety Warnings
WELCOME
Thanks for buying this 40" 1080pDigital LED LCD TV.This guide will helpyou set up and begin using your TV.
First, check the contents of your box with the parts checklist below:
40" 1080pDigital LED LCD TVt
Remote controlt
AAA batteryt ×2
Instruction Manualt
Quick Start Guidet
Warrantyt
TV Standt
5XScrewsfor TV standt
Component adapter,Component audio adapter ,SCART adaptert
Cover bottomt
Now you can get started!t
IMPORTANT INFORMATION
READ ALL INSTRUCTIONS BEFORE USE AND KEEPFOR FUTURE REFERENCE.
WARNING: Toavoid fire or electric hazards, never place your television receiver in an area with heavy
moisture. Attention shouldbe paid to avoid accidental scratches or impacts onto the screen.
CAUTION: SPlease read this manual carefullybefore using your television and keep this manual in a
good place for future reference.
SToachievethe best performance of your television, read this User‘sManual carefullyand
properlystore it for future reference.
SInformation of screen displays and figures in the User’sManual may vary due to technical
innovations.
CAUTION: SUnauthorized disassemblyof this product is prohibited.
TruSurround XT,SRS and the symbol are trademarks of SRS Labs, Inc. TruSurround XT technology is
incorporated under license from SRS Labs, Inc.
TruSurround XT® creates atrulyimmersivesurround sound experience with rich bass and clear dialog from only
twospeakers.
WARNING Toprevent the spread of re,keep candles or other open ames away from this product at all
times.

Safety Warningss
EN-3 Digital LED LCD Television Instruction Manual
If fixing TV to the wall please make sure
unit is securely fixed. or close to any
heat sources.
al

Safety Warnings
Digital LED LCD Television Instruction Manual EN-4
Do not Do not
kept
Unplug the TV, if you are going to clean the
product, use soft fabric, never chemicals,
make sure that no water
drops are in the product.
Always make sure the TV is securely plugged
in, as a poor electrical connection may cause
a fire.

About your LED LCD TV
EN-5 Digital LED LCD Television Instruction Manual
1.Carefully place the TV screen face down on a table. We suggest that you place the
wrapping material fromthe TV package on thetable top to protect the screen from
damage.
2.Position the stand with the bottomof the TV as shown below.
4.Attach the screws from the bottom of the stand to the TV.
3.Push the stand onto the TVDŽ
.
About your LED LCD TV
INSTALLING THE STAND

About your LED LCD TV
Digital LED LCD Television Instruction Manual EN-6
GET TO KNOW YOUR TV
Front control panel




LOV
HC
UNEM
ECRUOS

1SOURCE Toggles between all the available input
sources
2MENU Press to see an on-screen menu of yourTV’s
features.
3VOL-/+ Press to increase or decrease the volume .
4CH-/+
Press to change channels.
5POWER Press to turn theTV on and o.
HDMI 1 IN
USB
DIGITAL AUDIO OUT (OPTICAL )
ANT IN






2 INIMDH
NITNENOPMOC
CP
Y P b
P r
L
OIDUA
R
NICP 3 INIMDHTRACS


    
PC/DVI AUDIO
1SCART input
2Component input
3Component Audio
input
4PC input
5PC/DVI AUDIO
input
6HDMI3 IN input
7HDMI2 IN
input
8Common Interface
9Earphone
0ANTENNA input
AOptical output
BUSB
CHDMI1 IN input
Rear Terminals Control

About your LED LCD TV
EN-7 Digital LED LCD Television Instruction Manual
GET TO KNOW YOUR REMOTE CONTROL
When using the remote control,aim it towards the remote sensor on the TV.
1POWER
2DVD Menu / REC
3
DVD open / close
4Picture Mode
5Sound Mode
6Call Screen Display
7Sleep button
8DTV Audio / NICAM / DVD Audio
9Aspect Ratio Control button
0Channel list button
ASubtitle button
BProgram Number Channel selection
C
Source Exchange
DQ.VIEW / Swap Channel
EV+/V-: Volume selection
FP+/P-: Channel selection
GMute
HMenu button
IGUIDE button (only for DTV)
JFavourite list button
KOK button
LCursor Mover button
MBack button (only for USB)
NExit Screen Display
OREPEAT (only for DVD & USB )/CANCEL button
PZoom (only for DVD & USB)/Teletext index (only for TV) / REC index
QPlay / Pause button (only for DVD & USB) /Timeshift
RStop (only for DVD, USB, REC & Timeshift)
S
Fast Reverse (only for DVD, USB, REC &Timeshift)
T
Fast Forward (only for DVD, USB, REC &Timeshift)
UPrevious (only for DVD, USB, REC &Timeshift)
VNext (only for DVD, USB, REC & Timeshift)
WDVD Set up / Text
XDVD Title / Teletext Mix
Y
DVD Search /Teletext Subcode
ZDVD 10+ /Teletext Hold
[DVD Program / Teletext Reveal
\DVD A-B Repeat /Teletext Size
]DVD Call /Teletext Mode
`DVD Angle/Teletext Time
Note
RED button, GREEN button,OBLUE
button and YELLOW button are fast
textbutton in analog signal.Function
button in DVBT (just reference the
OSD)

About your LED LCD TV
Digital LED LCD Television Instruction Manual EN-8
CONNECTING YOUR
TV
ANTENNA CONNECTION
Connect your aerial to the back of the TV into the
ANTENNA IN socket.
IMPROVE YOUR SIGNAL
Toimprovepicture quality in apoor signal area, use a
signal amplifier (not supplied).
CONNECT YOUR PC TO THE TV
You can use your TV as amonitor for your personal
computer by connecting it with aVGA cable(not
supplied).
Read your computer user guide and check it has a
A
VGA connector.
Turn the power o on your TV and PC.
B
Connect aD type 15-pin VGA interface cableto theC
VGA video interface connector on the PC.Connect
the other end of the cableto the PC interface
connector on the TV.Tighten the screwson the
VGA connectors and connect the audio cable(not
supplied) to the audio input socket on the back of
the TV.
Turn on the power of the TV firstlyand then the PC.
D
Press the button on the TV or TV remote control toE
set the video input mode to VGA.
Once the image shows, if there is noise present,
F
change the VGA mode to another resolution,
change the refresh rate to another rate or adjust
the brightness and contrast on the menu until the
picture is clear.
CONNECT A DVD PLAYER TO YOUR
TV
Connect the DVD video outputs (Y,Pb,Pr) to the
COMPONENT (Y,Pb,Pr) IN socket on your TV.
Turn on the DVD player and insert aDVD.A
Press the button to select .B
Refer to the DVD player user guide for operatingC
instructions.
DVD
CONNECT A DVD PLAYER OR VCR TO
YOUR TV
There are twoways in which you can connect aDVD
player or VCR to your TV.Make sure that both the TV and
DVD player or VCR are switched o before you connect
them.
Connection Option 1
Connect the audio and S-VIDEO cables from the VCRA
output jacks to the TV input jacks.
Insert avideo tape into the VCR and press
BPLAY on
the VCR.
Turn on the power of the TV first, then the VCR.
C
Press theDSOURCE button on the TV to set the video
input mode to S-VIDEO.
Connection Option 2
Connect the AV DVD/VCR outputs to the AV INA
socket on your TV.
Press the
BSOURCE button on the TV to set the video
input mode to AV.
SCART INPUT
Connect the scart lead from the external deviceA
(DVD player, Set-top box or games console) to the
TV scart socket.

About your LED LCD TV
EN-9 Digital LED LCD Television Instruction Manual
Press theBSOURCE button to select SCART mode.
Press the
CPLAY button on the external device.
HDMI INPUT
Connect the cablefrom the HDMI device to the TVA
HDMI socket.
Press the
BSOURCE button to select HDMI mode.
Refer to the HDMI device user guide for how to
C
operate.
MOUNT YOUR TV ONTO THE WALL
You can mount your TV onto the wall by using awall
bracket (not supplied).Use M4/M6 machine screws(4
pcs) to screw the TV onto the bracket (not supplied).
PREPARATION OF
YOUR REMOTE
CONTROL
BATTERY INSTALLATION
Place the remote control face down, then open theA
cover of the battery compartment.
Install twoAAA batteries. (The + and - symbol of theB
battery must match with the marks on the remote).
Close the cover of the battery compartment.C
BATTERY CAUTION
Confirm there is no object between the remote control
and the remote sensor of the TV set.
Sunshine or other strong light will interfere with the
signal sent by the remote control.Inthis situation turn
the TV set to avoid the direct light source.
Donot put the remote control in direct heat or in a
damp place as you may damage the remote.
Please use twoAAA 1.5V batteries. Donot mix battery
types. Install the batteries at the correct polarities. Do
not use rechargeablebatteries. Ifyour TV is to be stored
for aperiod of time, removethe batteries from the
remote control.
Getting Started
SETTING UP
LOCATION
You will need to place your TV near your plug socket
(so the power cablecan comfortablyreach) and within
reach of your aerial socket or extension lead.
CONNECTION
Insert your TV aerial lead into the Antenna input atA
the side of the TV.
Insert the batteries into the remote control.Make
B
sure they are inserted the right way around,
About your LED LCD TV / Getting Started

Getting Started
Digital LED LCD Television Instruction Manual EN-10
matching the polarity as indicated inside the battery
compartment.
SWITCHING YOUR TV ON
Press theAPOWER button on the right side of the TV
once. A red ashing light will appear in the corner of
the screen.
Press
BPOWER on the remote control.The TV will turn
on and the red light will turn blue. This may take a
few moments.
Select your chosen language when prompted from
C
the list that will appear on screen. Use the button
to scroll to the language you want and press to
confirm.
TUNING YOUR TV
SWITCHING TO AN EXTERNAL
SOURCE OTHER THAN THE TV
Ifyou haveattached aDVD player or similar external
device to the TV,you will need to tell the TV to display
the content from it. Simplypress SOURCE which will
bring up the source menu in the left corner of the screen,
use the and button to highlight the required
source and press OK select.
For detailsof how to plug in other equipment see GET
TO KNOW YOUR TV on page 6.
AUTO SEARCH
PressAMENU button.
PressB button to select Tuning menu, press 
button to enter.
Press
C button to select Country item.
Press  button to select you needed.
Press
D button to select Auto Search item, press
OK button to enter.
Press  button to select the OK option, and press
OK button to start searching.
Press the MENU button, you can choose to skip the
TV /DTV Search or not.
PressEEXIT button to stop auto search during
searching.
Note
Itmay take afew moments to complete the AutoO
Search.
DIGITAL MANUAL SEARCH
PressAMENU button.
DTV

Getting Started
EN-11 Digital LED LCD Television Instruction Manual
PressB button to select Tuning menu, press 
button to enter.
Press
C button to select Digital Manual Search
item, press button to enter.
PressD button to select the Channel.
Press OK button to start searching.
Once achannel is located, you can press
EOK button
to saveit.
Press EXIT button to exit.
Analog Manual Search
Follow the below steps when you need to haveamanual
search.
Press
AMENU button.
PressB button to select Tuning menu, press
button to enter.
Press
Cbutton to select Analog Manual Search
item, press button to enter.
PressD button to select Search item, press
button is used to select the higher frequency
channel.
Press button is used to select the lower frequency
channel.
And then select Storage To, press
E button to
select the position number you want the channel
on. Once achannel is located, you can press red
button to saveit. Press EXIT button to exit.
Sound SystemV
Press button to select “Sound System”, then
press  button to select the correct sound system.
Current CHV
Press  button to select the channel number to
edit.
Storage ToV
Press  button to select the program number you
want to storage to.
Fine tuneV
Ifthe picture and/or sound are poor, try using the
FINE TUNE feature. Donot use this feature unless
reception is poor.
Repeat abovesteps
AA-C,then press button to
select the Fine Tune item.
Press
B button repeatedlyto carry out fine
tune, till the best picture and sound are obtained,
then loosen the button.
Channel Edit
Using this function, you can rename, move, set favorite
channel and skip the channel in the analogue mode.
Press
AMENU button.

Getting Started
Digital LED LCD Television Instruction Manual EN-12
PressB button to select TUNING menu, press 
button to enter.
Press
C button to select CHANNEL EDIT item.
Press button to enter the sub-menu. You can
press red, green, yellow or blue button to enter the
menu you need.
RENAME
PressA button to select the channel,and press
green button to rename.
Press
B button to select the number position of
channel name. Press  button to select number.
You can press the
CEXIT button to cancel the changes
at anytime.
Note
The RENAME function is onlyavailablein ATVO
program.
MOVE
PressA button to select the channel and press
yellow button to select the position.
PressB button to select the number position you
want to removeto, press yellow button to confirm.
You can press the
CEXIT button to cancel the changes
at anytime.
Setting favourite channel
PressA button to select the channel,press red
button to set your favourite channel.
You can press the red button to cancel the changes
B
at anytime.
Press
CFAV button on the remote control and
Favourite List will be displayed.
Press
D button to select the channel,and press
OK button to enter.
SKIP
PressA button to select the channel and press
blue button to skip the current channel.
You can press the
Bblue button to cancel the changes
at anytime.
GUIDE (Electronic Program Guide)
Using this function, you can access the DTV program
information.
Press
AMENU button.
PressB button to select TUNING menu.
Press button to enter.

Getting Started
EN-13 Digital LED LCD Television Instruction Manual
Press
C button to select the guide item.
Press OK button to enter the submenu, the
electronic program guide is displayed.
You can quicklycall up Guide menu by GUIDE
button on the remote control.
Note
OnlyDTV mode.O
COMMON INTERFACE
The common interface (CI) slot is designed to accept the
Conditional Access (CA) Moduleand Smart card in order
to view the pay TV programmes and additional services.
Contact your Common Interface service provider to get
more information about the modules and subscription.
Please note that CA modules and smart cards are neither
supplied nor optional accessories from us.
Warning
Switch o your TV before any moduleis inserted int
the Common Interface slot.
Insert the CAM correctly, then Smart Card to the CIA
slot that is located at the side of the TV.
CI Slot
CAM
Smart Card
Turn on the TV and it will display the below messageB
if the CA moduleis detected. Wait for few moments
until the card is activated.
Press the
CMENU button to display the Main Menu
and use the and button to highlight the
“Common Interface” line and press the “OK” button.
Detailed information on the CI card in use is
D
displayed.
Press
EOK button to access the card menu. Refer to
the moduleinstruction manual for setting details.
When moduleis removed, the following message
F
will appear on the screen.
Software Update function
When you get the updating newsfrom the TV shop’st
web, you can update the operating software using
the Download menu. The data for various units are
transferred consecutivelyon aspecial receiving
channel.
You need to search the channel with updating codet
stream.

Getting Started
Digital LED LCD Television Instruction Manual EN-14
Note
You can get information from the TV shop orO
internet.
Operation
PressAMENU button.
PressB button to select TUNING menu, press 
button to enter.
Press
C button to select Software Upgrade item.
Press
D button to set it as On. (The defaultis O)
The Start Upgrade item can be selected.(The default
E
is grey and cannot be selected).
13%
Press EXIT to cancel download
PressF button to select the Start Upgrade option
and use OK button to enter. Then the TV will restart
and search the upgrade information.
Note
Ifthe upgrade information is received, the TV willO
begin to upgrade. Orelse, the TV will go back to
the DTV source.
Load the receiver identification. This process may
G
also take several minutes. You can press EXIT button
to cancel the download and your TV set will go back
to the DTV source.
100%
15%
Press EXIT to cancel download
Updating in progress - Do not turn off the TV
After the download has finished, your TV set willH
enter conguration state and the indicator light is
shining. The menu 4 of right appears.
The set will be back the DTV source when the update is
completed.
USING YOUR TV
How to select the TV program
Using Program number button Enter the channelA
number with the number keypad on the remote
control.
Using
BP+/P- button.
Press the P+/P- button to select achannel number.
HOW to adjust volume
Press V+/V- button on the remote control or the side of
the TV to adjust the volume level.

Getting Started
EN-15 Digital LED LCD Television Instruction Manual
CH.LIST function
Press CH.LIST button on the remote control will display
Channel List menu, and then press button to enter.
Press button to select the channel,and then press
OK button to enter.
ADJUSTING PICTURE
SETTINGS
Changing the Picture Setting
PressAMENU button.
PressB button to select Picture menu, press 
button to enter.
Press
C button to select the item requires
adjusting.
Press
D button to adjust the selection item.
When you are satisfied with your choice, press the
E
EXIT button to return to normal viewing or press
MENU button to return to the previous menu.
ContrastV
This will adjust the intensity of bright parts in the
picture but keep the dark parts unchanged.
BrightnessV
This will adjust the light output of the complete
picture, which will mainlyaect the darker areas of
the picture.
ColourV
This will adjust the saturation level of the colours to
suit your personal preference.
SharpnessV
This will adjust the sharpness of fine detailsin the
picture.
TintV
Allowsyou to select the colour mix (Tint) of the
picture.
Note
The Tint function is onlyavailablein NTSC mode.O
ModeV
This will select the picture mode. Select Standard/
Mild/User/Vivid according to the program. You can
quicklyselect the desired mode by P.MODE button on
the remote control.
Colour temperatureV
This will increase or decrease Warm (red) and Cool
(blue) colours to suit personal preferences.
Select Cool to givethe white colour ablue tint,
Normal to givethe white colour aneutral tint, Warm
to givethe white colour ared tint.
Noise ReductionV
Automaticallyfilters out and reduces the image noise
and improves picture quality when receiving weak
video signals.
Select O/Low/Standard/High according to the
image noise.
ResetV
Torecover to the defaultvalue.
ADJUSTING SOUND
SETTINGS
Changing the Sound Setting
PressAMENU button.
Press
B button to select Sound menu, press 
button to enter.

Getting Started
Digital LED LCD Television Instruction Manual EN-16
PressC button to select the item requires
adjusting.
Press
D button to adjust the selection item.
When you are satisfied with your choice, press the
E
EXIT button to return to normal viewing or press
MENU button to return to the previous menu.
BalanceV
This will adjust the output of the right and left
speakers to obtain the best stereo reproduction for
your listening position.
ModeV
This will select the sound mode.
Press  button to select Standard/Music/
Theater/User according to the program. You can
quicklyselect the desired mode by S.MODE button
on the remote control.
AVLV(Automatic volume control)
This will reduces the dierences in volume level
among broadcasters.
SRS TS XTV
This will control the Woofer output.
Press  button to select SRS TS XT.
Press  button to set SRS TS XT as OFF, ON.
Digital Audio OutputV
This will control the Digital Audio Output.
Press button to select Digital Audio Output.,
Press button to set Digital Audio Output. as OFF,
PCM,RAW.
EqualizerV
This sound setting can be adjusted to suit your
personal preference.
Audio LanguagesV
Press  button to select Primary/Secondary item,
and then press  button to select the languages
you needed.
Press button to select Close item, press OK button
to close it.
Note
The Audio Language function is onlyavailableinO
DTV mode.
ResetV
Torecover to the defaultmenu setting.
FUNCTION SETTINGS
PressAMENU button.
PressB button to select Sound menu, press 
button to enter.

Getting Started
EN-17 Digital LED LCD Television Instruction Manual
PressC button to select the item requires adjusting.
PressD button to adjust the selection item.
When you are satisfied with your choice, press the
E
EXIT button to return to normal viewing or press
MENU button to return to the previous menu.
LanguageV
Toselect the menu language.
Subtitle LanguageV
Toselect the Subtitlelanguage.
Display ModeV
Toset the picture proportion, press button to
select 4:3/Zoom1/Zoom2/Wide/16:9/Auto. You can
quicklyselect the desired mode by SCREEN button
on the remote control.
4:3 modet
Choose 4:3 when you want to view apicture
with an original 4:3 aspect ratio, with gray bars
appearing at both the left and right sides.
16:9 modet
Choose 16:9 when you want to adjust the picture
horizontally, in alinear proportion to fill the entire
screen.
Zoom1t
Choose Zoom1 when you want to view the picture
without any alteration. However, the top and
bottom portions of the picture will be cropped.
Zoom2t
Choose Zoom2 when you want the picture to be
altered, both verticallyextended and cropped.
The picture taking ahalfway trade o between
alteration and screen coverage.
Widet
Choose Wide when you want to adjust the picture
in anon-linear proportion, that is, more enlarged
at top sides and no alteration, at bottom side.
Blue ScreenV
This will select the character background colour.
Note
The Blue Screen function is onlyavailableforO
ATV mode.
RecorderV
Torecord the DTV program. Detailsof Recording are
described on the page of 25-27.
SCART InputV
The item does not work.
OSD Time OutV
Toset how long you want the menus to appear
on-screen. Each press of  button repeatedlyto
select the number of preset minutes, the Time will be
set in sequence: o,10sec, 15sec, 30sec, 45sec, 60sec.
OSD TransparencyV
Toset the transparency background of OSD,the
transparency will be set in sequence: O,25%,50%,
75%,100%.
ResetV
Torecover to the defaultvalue.

Getting Started
Digital LED LCD Television Instruction Manual EN-18
TIME SETTINGS
ClockV
PressAMENU button.
Press
B button to select Time menu, press 
button to enter.
Press
C button to select Clock item, press 
button to enter setting.
Press  button to select hour or minute, press
 button to adjust the value.
DateV
PressAMENU button.
Press
B button to select Time menu, press 
button to enter.
Press
C button to select Date item, press 
button to enter setting.
Press button to select the option, and then
press  button to adjust value.
Note
InDTV mode, because the time information isO
from the signal,the Clock and Date are not able
to be changed.
Ifyou want to change the time, turn o the TV in
ATV mode, then turn on the TV.
O TimeV
PressAMENU button.
Press
B button to select Time menu, press 
button to enter.
Press
C button to select O Time item, press 
button to enter setting.
Press  button to select Repeat option, and
then pressbutton to set it on.
Press button to select hour or minute, press
 button to adjust the value.
When the o time has arrived, the TV set will
enter into standby mode.
SleepV
The sleep timer automaticallyshuts o the TV after a
preset time (from 5 to 240 minutes).
Press the
AMENU button and then use  button
to select the Time menu.
Press the
Bbutton and then use  button to
select the Sleep.
Press the
C button and then use  button
to select the number of minutes. Select O, 5Min,
10Min, 15Min, 30Min, 45Min, 60Min, 90Min,
120Min, 180Min, 240Min.
When you are satisfied with your choice, press
D
MENU button to return to the previous menu or

Getting Started
EN-19 Digital LED LCD Television Instruction Manual
press the EXIT button to return to TV viewing.
And the time begins to count downfrom the
number of minutes selected.
Time ZoneV
PressAMENU button.
Press
Bbutton to select Time menu, press 
button to enter.
Press
Cbutton to select Time Zone item.
Press
D button to select the correct time zone.
Press
EMENU button to saveand exit.
LOCK MENU SETTING
Using this function can control the tuner, program,
source volume and so on. Pressing MENU on the remote
control,press  button to select Lock menu, press 
button to enter the sub-menu, and you will be required
to enter the password. The initial password of the
television is 0000.Ifyou forget your password, you can
always input 9443 to regain control.
CHANGE PASSWORDV
PressA button to select Change Password
item. Press button to enter the submenu.
When you haveinputted the four digits you willB
be prompted to enter it again.
Your new password will then be automatically
saved.
CHILD LOCKV
Press button to select ChildLock.
Press  button to set On or O mode. Iflock on
mode is set, ChildLock is in activated automatically.
Insuch case, if Child Lock button (button on the
television) is pressed, the screen will display Child
Lock, which can be erased by press of MENU button.
5 seconds later after the latest press, the screen
display will disappear automatically. The ChildLock
mode can be resumed by entering Lock Set menu, set
ChildLock On or O.
Tuning LockV
Press  to select Tuner Lock and  to set On/O.
(Toset On, some operation such as search will be not
available. When enter the Tuning menu, Tuner Lock
will be on the screen. Ifyou want to operate Tuning
menu, you need to enter the Lock menu to set Tuner
Lock O or operate unlock.)
Channel NO.V
Channel NO.is opted for setting up preset channel.
Press  button to select preset Channel.Press 
button to select channel number.
Source setV
Channel set is opted for setting up start source.
Press  button to select O,DTV,TV,SCART,
S-Video, Component ,PC,HDMI1,HDMI2,HDMI3,USB
in turn.
Source LockV
Source Lock will control the Onor O of hinder
external input modes.
Press  button to set as on or o.
When the source lock is set as on, TV source will
display, at this time, when press SOURCE button,
the TV can switch to corresponding source and will
