Introduction
Thank you for buying the guitar kit. All the wood, hardware, and electrical components of the guitar are
containedinthispackage.Pleasereadthefollowinginstructionsforassemblyandnishing.
BDA_EK318_Self_build_guitar_kit_T-style_en_print.indd 3 18.07.2011 09:49:20

www.thomann.de
Harley Benton E-Guitar Kit T-Style
4
Body finish
Therstconsiderationtobemadebeforeassemblingistochoosethepreferrednishoftheguitarbody.
The basswood body of the guitar is sealed and prepared for various types of lacquer coating. A wide variety of
nishescanbeprocuredfromDIY,timberandautomotiveoutletsinaerosolcansmakingnishingstraightfor-
ward without requiring specialist skills. The use of a dust mask is essential when spraying.
Therststepistocheckthetofthebodytotheneckjoint.Theguitarismachinedfromhigh-gradetone-
woods to ensure optimum alignment. But all woods have a natural propensity to change the shape very slightly
overtime.Ifthetistootight,agentleadjustmentusingasharpchiselorsandpapermayberequired.Please
rememberthatthecoatingoflacquerwillmakethenecktalittlemoretightlyintothecutout.
Before coating the body, ensure that all surfaces are clean and free of dirt and dust. Conduct all coating proc-
esses in a well-aired, dust-free environment. Slow and patient progress is the key to a good quality of the body
nishanditisrecommendedtotestthecolourandtechniqueonasparepieceofwoodrst.
A hole is drilled in the neck cutout so that it can be suspended by a hook for spraying and drying or alterna-
tively, a spare length of wood can be screwed in place of the neck in the cutout as a handle.
Sprayontheedgesofthebodyrstandallowthecoattobecometouchdry.Oncetheedgesaredry,continue
ontherearandthenonthefrontofthebody.Gradualandsmoothpasseswillensureanevencoat.Ifthereare
anyimperfections,allowfortobecomefullydryandthensandoutwithnegrade(e.g.800+grit)beforere-
spraying. Apply three or more coats for full coverage.
Neck finish
Theneckoftheguitarissuppliedsealedwithalightcoatofmattelacquerandisreadytouse.Ifpreferred,the
neckcanbenishedwithacolourorglosslacquer.Ifso,dothefollowing.
Therosewoodngerboarddoesnotneedcoatingwithlacquer,soitisimportanttomaskofftheexposedrose-
wood and frets prior to spraying. Ensure all parts to be sprayed are free from dirt and dust and that the envi-
ronment is dust-free and well-aired. The use of a dust mask is essential when spraying.
Choose a good quality, clear or lightly tinted wood lacquer aerosol for the neck and begin at the front and sides
oftheheadstock.Startwithagradual,evenpasstoapplyathincoat,allowdrying(tobetouchable)andrepeat
thistwoorthreetimes.Takecarenottoapplytoomuch,whichmaycauseruns.Ifthishappens,sanddown
the area and re-apply evenly.
Aftertheheadstockhasbecomedry,turntheneckoverandlayitdownonitsngerboard.Repeattheabove
processfortherestoftheexposedmaple.
Allow two to three days for the lacquer to fully harden and then, if desired, polish the lacquered surfaces to get
a suitable shine.
BDA_EK318_Self_build_guitar_kit_T-style_en_print.indd 4 18.07.2011 09:49:20

www.thomann.de
Harley Benton E-Guitar Kit T-Style
5
Assembling of tuners
Beforeattachingthenecktothebody,tthetuningmachine-headstotheheadstockbyinsertingthethread
through the pre-drilled holes and setting a washer and bush over it. Screw down the bush onto the thread until
ittstightlytothetouchandthenadjusttherearofthemachine-headsothatthetuningbuttonsitsvertically
above the top edge of the headstock.
Fixtheretainingscrewthroughtheloopontherearofthegearhousingintothepilotholetoholdthetunerin
position.Thentightenthenutonthefrontfaceofthetuneruntilitisrmbyusingaspannerofthecorrectsize.
Repeatthisfortheremainingvetunersandthentthestringtree.
BDA_EK318_Self_build_guitar_kit_T-style_en_print.indd 5 18.07.2011 09:49:22

www.thomann.de
Harley Benton E-Guitar Kit T-Style
6
Neck
With the body placed face up on a protective surface, position the neck into the neck cutout until it is fully
inserted.
Turntheassemblyoverandpositiontheneckplate(withitsblackprotectiveseal)overthefourboltholesat
the rear of the body and drive in the four long screws through the neck plate, body and pilot holes in the neck
untilalltstightly.
Wiring
The pickups and controls are pre-assembled on the pickguard and simply need to be connected to the output
jacksocketandearth.Wiringisimplementedasplug-inmodules,solderingisnotrequired.
The neck pickup is pre-assembled on the pickguard, however, the bridge pickup is pre-assembled on the
bridge.Eachpickuphasoneloosecable.Insertthecablewithconnectorintothesmallholeineachpickup
cavity until it runs through and reaches the cavity of the control panel.
BDA_EK318_Self_build_guitar_kit_T-style_en_print.indd 6 18.07.2011 09:49:23

www.thomann.de
Harley Benton E-Guitar Kit T-Style
7
Wiring
There are four loose cables in the wiring assembly. Three of them have connectors and the other one has no
connector.Insertthecablewithoutconnectorintotheholeleadtothebridgepickupcavityandpressitunder
thebridge.Thegroundwireisnished.
Connect the cables of the pickups to the cables which are on the switch.
Gently thread the cable on the potentiometers lead through the hole behind the tone control cavity to the sepa-
rateroutingforthejacksocket.Connecttheconnectorwiretotheconnectoronthejacksocket(theyonlyt
onewayround),thentthejacksocketplateandsecureitwithdome-headscrews.
BDA_EK318_Self_build_guitar_kit_T-style_en_print.indd 7 18.07.2011 09:49:25

www.thomann.de
Harley Benton E-Guitar Kit T-Style
8
Wiring
Now position the pickguard, bridge, and control panel on the front of the body in a way that the pickups and all
the wiring sit neatly in the routed cavities. Ensure that the edge of the pickguard sits snugly at the end of the
neck and straight to the bridge assembly. Secure the pickguard with the small dome-head screws provided into
the pre-drilled pilot holes.
Strap buttons
Screw the strap buttons into the pre-drilled holes at the bottom edge of the body and at the tip of the upper
horn of the body.
BDA_EK318_Self_build_guitar_kit_T-style_en_print.indd 8 18.07.2011 09:49:26

www.thomann.de
Harley Benton E-Guitar Kit T-Style
9
Setting up
Fitting strings to the guitar is achieved by threading from the bridge, emerging through the relevant saddle on
the bridge. Start with the thickest string bottom E in the uppermost position on the bridge.
Ensure that the string sits smoothly on its saddle and keep taut whilst winding a couple of turns on the relevant
tuner. Thread through the string post and bend the string back on itself to anchor it in place. Apply a little ten-
sionfromthetunerandmoveontothenextstring.Repeattheaboveprocessforallsixstrings.
Bringing all the strings up to pitch gradually is better achieved with a digital guitar tuner or pitch pipes as a ref-
erence. Please be aware that the tension in the strings may take some time to settle and re-tuning a few times
might be necessary. Stretching each string gently after reaching the pitch will help to take up slack.
BDA_EK318_Self_build_guitar_kit_T-style_en_print.indd 9 18.07.2011 09:49:27

www.thomann.de
Harley Benton E-Guitar Kit T-Style
10
Setting up
Theneckisttedwithatrussrodwhichmayneedadjusting.Whenthestringsaretunedup,theywilltrytopull
awayfromtheneck,whichmaymeanthattheactionbecomestoohigh.Ifthishappens,usethelargerofthe
twohexkeysprovidedtograduallytightenthetrussrod–ahalfturnisusuallyenoughandmaynottakeef-
fectimmediately–allowtheadjustmentstosettleeachtime–donotbetemptedtoover-tightenthetrussrod.
Sighting along the neck should show a very slight concave tendency which is called “relief” and too straight a
neckmayleadto“fretbuzzing”.Somestringsmayneedtoberaisedorloweredindividuallytogivethecor-
rectactionandthiscanbeadjustedusingthesmallerofthetwohexkeysprovided.Forthelaststepscrewthe
truss-rod cover.
Oncethedesiredactionisachieved,allthatremainsistosettheintonation.Aftertuningupallthestrings,you
justhavetogentlytouchastring,rightabovethetwelfthfretandthenpickthestring.Theresultingchime-like
soundisaharmonic(12thfretharmonic).Thisharmonicshouldhavethesamepitchaswhenthestringis
pressedatthetwelfthfret.Ifthepitchofthetwonotesdiffers,adjustthesaddleforthisstringbackorforthon
thebridge.Listencarefullyandadjustgentlyuntilthetwonotesmatch,toachievecorrectintonation.Repeat
this procedure on all strings until the harmonics and the fretted notes sound the same.
Pleasealsorememberthatovertime,slightadjustmentsmayneedtobemadeanddifferentgaugesofstrings
will need compensating for in the setup.
Thepickupheightcannowbeadjustedforbestperformanceandcanbebalancedbyadjustingthescrewsat
thetopandbottomofeachpickup.Asageneralrule,holddownthestringsatthe22ndfretandadjustsothat
thestringsareatleast2mmclearofthepickup.Anypickupsthatarenoticeablylouderthanotherscanbe
madequieterbyadjustingthemfurtherawayfromthestrings.
Forfutureadjustments,keeptheseinstructionsasareferenceandenjoyyourcustommadeguitar.
