HART HGCS02 20V User manual

HGCS02 20V
Chain Saw
Scie à chaîne
Motosierra
OPERATOR’S MANUAL
General Power Tool Safety Warnings 2-3
 ChainSawSafetyWarnings 4-8
Symbols 9-10
 GlossaryofTerms 11
Features 12
 Assembly 13
 Operation 13-22
Maintenance 23-29
 BarandChainCombinations 29
 Troubleshooting 29
 Parts/Service
 Backpage
MANUEL D’UTILISATION
 Avertissementsrèglesdesécurité
 relativesauxoutilsélectriques 2-4
 Avertissementsdesécurité
 relatifsauscieàchaîne 4-8
 Symboles 9-10
 Glossaire 11
 Caractéristiques 12
 Assemblage 13
 Utilisation 13-22
 Entretien 23-29
 Combinaisonsdeguideetchaîne 30
 Dépannage 30
 Commandedepièces/réparation
 Págearrière
MANUAL DEL OPERADOR
 Advertenciasdeseguridad
 paraherramientaseléctricas 2-4
 Advertenciasdeseguridad
 delamotosierra 4-8
 Símbolos 9-10
 Glosariodetérminos 11
 Características 12
 Armado 13
 Funcionamiento 13-22
 Mantenimiento 23-30
 Combinacionesdebarraycadena 30
 Correccióndeproblemas 30
 Pedidosdepiezasyservicio
  Pág.posterior
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
WARNING: To reduce the risk of
injury, the user must read and understand the
operator’s manual before using this product.
CE LIVRET D’INSTRUCTIONS CONTIENT DES
CONSIGNES DE SÉCURITÉ IMPORTANTES.
VEUILLEZ LE LIRE ET LE CONSERVER POUR
TOUTE RÉFÉRENCE FUTURE.
AVERTISSEMENT : Pour
réduire les risques de blessures, l’utilisateur
doit lire et veiller à bien comprendre le manuel
d’utilisation avant d’employer ce produit.
ESTE FOLLETO DE INSTRUCCIONES CONTIENE
INFORMACIÓN DE SEGURIDAD IMPORTANTE.
LÉALO Y CONSÉRVELO PARA REFERENCIA
FUTURA.
ADVERTENCIA: Para reducir
el riesgo de lesiones, el usuario debe leer y
comprender el manual del operador antes de
usar este producto.

2 – English
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Readallsafetywarningsandallinstructions.
Failure to follow the warnings and instruc-
tionsmayresultinelectricshock,fireand/or
serious injury.
Save all warnings and instructions for future
reference.Theterm“powertool”inthewarnings
referstoyourmains-operated(corded)powertool
orbattery-operated(cordless)powertool.
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered
ordarkareasinviteaccidents.
Do not operate power tools in explosive at-
mospheres, such as in the presence of flam-
mable liquids, gases or dust. Power tools cre-
atesparkswhichmayignitethedustorfumes.
Keep children and bystanders away while
operating a power tool. Distractionscancause
you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded)
power tools. Unmodifiedplugsandmatching
outletswillreduceriskofelectricshock.
Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. Thereisanincreasedriskofelec-
tricshockifyourbodyisearthedorgrounded.
Do not expose power tools to rain or wet
conditions. Waterenteringapowertoolwill
increasetheriskofelectricshock.
Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damagedorentangled
cordsincreasetheriskofelectricshock.
When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Useofacordsuitableforoutdoorusereduces
theriskofelectricshock.
If operating a power tool in a damp location
is unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply. Useofa
GFCIreducestheriskofelectricshock.
PERSONAL SAFETY
Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication.Amomentofinattentionwhile
operatingpowertoolsmayresult inserious
personalinjury.
Use personal protective equipment. Always
wear eye protection. Protective equipment
suchasdustmask,non-skidsafetyshoes,hard
hat,orhearingprotectionusedforappropriate
conditionswillreducepersonalinjuries.
Prevent unintentional starting. Ensure the
switch is in the off-position before connect-
ing to power source and/or battery pack,
picking up or carrying the tool. Carryingpower
toolswithyourfingerontheswitchorenergis-
ingpowertoolsthathavetheswitchoninvites
accidents.
Remove any adjusting key or wrench before
turning the power tool on. Awrenchorakey
leftattachedtoarotatingpartofthepowertool
mayresultinpersonalinjury.
Do not overreach. Keep proper footing and
balance at all times. Thisenablesbettercontrol
ofthepowertoolinunexpectedsituations.
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Looseclothes,jewel-
leryorlonghaircanbecaughtinmovingparts.
If devices are provided for the connection of
dust extraction and collection facilities, en-
sure these are connected and properly used.
Useofdustcollectioncanreducedust-related
hazards.
Do not let familiarity gained from frequent
use of tools allow you to become complacent
and ignore tool safety principles. Acareless
actioncancausesevereinjurywithinafraction
ofasecond.

3 – English
GENERAL POWER TOOL SAFETY WARNINGS
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct
power tool for your application. Thecorrect
powertoolwilldothejobbetterandsaferatthe
rateforwhichitwasdesigned.
Do not use the power tool if the switch does
not turn it on and off.Anypowertoolthatcan-
notbecontrolledwiththeswitchisdangerous
andmustberepaired.
Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventivesafetymeasuresreducetheriskof
startingthepowertoolaccidentally.
Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Powertoolsaredan-
gerousinthehandsofuntrainedusers.
Maintain power tools. Check for misalign-
ment or binding of moving parts, breakage of
parts and any other condition that may affect
the power tool’s operation. If damaged, have
the power tool repaired before use. Many ac-
cidentsarecausedbypoorlymaintainedpower
tools.
Keep cutting tools sharp and clean. Prop-
erlymaintainedcuttingtoolswithsharpcutting
edgesarelesslikelytobindandareeasierto
control.
Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Useofthe
powertoolforoperationsdifferentfromthose
intendedcouldresultinahazardoussituation.
Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handlesandgraspingsurfacesdonotallowfor
safehandlingandcontrolofthetoolinunex-
pectedsituations.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by
the manufacturer. Achargerthatissuitablefor
onetypeofbatterypackmaycreateariskof
firewhenusedwithanotherbatterypack.
Use power tools only with specifically desig-
nated battery packs. Useofanyotherbattery
packsmaycreateariskofinjuryandfire.
When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small
metal objects, that can make a connection
from one terminal to another. Shortingthe
batteryterminalstogethermaycauseburnsor
a fire.
Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with wa-
ter. If liquid contacts eyes, additionally seek
medical help.Liquidejectedfromthebattery
may cause irritation or burns.
Do not use a battery pack or tool that is
damaged or modified. Damagedormodified
batteriesmayexhibitunpredictable behavior
resultinginfire,explosionorriskofinjury.
Do not expose a battery pack or tool to fire
or excessive temperature. Exposuretofireor
temperatureabove265°Fmaycauseexplosion.
Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instruc-
tions. Chargingimproperlyorattemperatures
outsidethespecifiedrange maydamagethe
batteryandincreasetheriskoffire.
SERVICE
Have your power tool serviced by a qualified
repair person using only identical replace-
ment parts. Thiswillensurethatthesafetyof
thepowertoolismaintained.
When servicing a power tool, use only iden-
tical replacement parts. Follow instructions
in the Maintenance section of this manual.
Useofunauthorizedpartsorfailuretofollow
Maintenanceinstructionsmaycreateariskof
shockorinjury.
Never service damaged battery packs. Ser-
viceofbatterypacksshouldonlybeperformed
bythemanufacturerorauthorizedservicepro-
viders.

4 – English
CHAIN SAW SAFETY WARNINGS
Keep all parts of the body away from the
saw chain when the chain saw is operating.
Before you start the chain saw, make sure
the saw chain is not contacting anything.A
moment of inattention while operating chain
sawsmaycauseentanglementofyourclothing
orbodywiththesawchain.
Always hold the chain saw with your right
hand on the rear handle and your left hand on
the front handle. Holdingthechainsawwitha
reversedhandconfigurationincreasestherisk
ofpersonalinjuryandshouldneverbedone.
Hold the power tool by insulated gripping
surfaces only, because the saw chain may
contact hidden wiring.Sawchainscontacting
a“live”wiremaymakeexposedmetalpartsof
thepowertool“live”andcouldgivetheoperator
anelectricshock.
Wear safety glasses and hearing protec-
tion. Further protective equipment for head,
hands, legs and feet is recommended.
Adequate protective clothing will reduce per-
sonalinjurybyflyingdebrisoraccidentalcontact
withthesawchain.
Do not operate a chain saw in a tree. Opera-
tionofachainsawwhileupinatreemayresult
inpersonalinjury.
Always keep proper footing and operate
the chain saw only when standing on fixed,
secure and level surface.Slipperyorunstable
surfacessuchasladdersmaycausealossof
balanceorcontrolofthechainsaw.
When cutting a limb that is under tension be
alert for spring back.Whenthetensioninthe
woodfibresisreleasedthespringloadedlimb
maystriketheoperatorand/orthrowthechain
saw out of control.
Use extreme caution when cutting brush and
saplings. Theslendermaterialmaycatchthe
sawchainandbewhippedtowardyouorpull
you off balance.
Carry the chain saw by the front handle with
the chain saw switched off and away from
your body. When transporting or storing the
chain saw always fit the guide bar cover.
Properhandlingofthechainsawwillreducethe
likelihoodofaccidentalcontactwiththemoving
sawchain.
Follow instructions for lubricating, chain ten-
sioning and changing accessories. Improperly
tensionedorlubricatedchainmayeitherbreak
orincreasethechanceforkickback.
Do not operate a chain saw, on a ladder, from
a rooftop, or any unstable support. Operation
of a chain saw in this manner could result in
serious personal injury.
Do not operate a chain saw in a tree unless
you have been specifically trained to do so.
Operation of a chain saw in a tree without
proper training could increase the risk of
serious personal injury.
Cut wood only. Do not use chain saw for
purposes not intended. For example: do not
use chain saw for cutting plastic, masonry
or non-wood building materials.Useofthe
chainsawforoperationsdifferentthanintended
couldresultinahazardoussituation.
Do not attempt to fell a tree until you have an
understanding of the risks and how to avoid
them. Seriousinjurycouldoccurtotheoperator
orbystanderswhilefellingatree.
Follow all instructions when clearing jammed
material, storing or servicing the chain saw.
Make sure the switch is off and the battery
pack is removed. Unexpectedactuationofthe
chain saw while clearing jammed material or
servicingmayresultinseriouspersonalinjury.
CAUSES AND OPERATOR PREVENTION OF
KICKBACK
Kickbackmayoccurwhenthenoseortipofthe
guidebartouchesanobject,orwhenthewood
closesinandpinchesthesawchaininthecut.
Tipcontactinsomecasesmaycauseasudden
reversereaction,kickingtheguidebarupandback
towardstheoperator.
Pinchingthesawchainalongthetopoftheguide
barmaypushtheguidebarrapidlybacktowards
theoperator.

5 – English
CHAIN SAW SAFETY WARNINGS
Eitherofthesereactionsmaycauseyoutolose
controlofthesawwhichcouldresultinserious
personalinjury.Donotrelyexclusivelyuponthe
safetydevicesbuiltintoyoursaw.Asachainsaw
user,youshouldtakeseveralstepstokeepyour
cuttingjobsfreefromaccidentorinjury.
Kickbackistheresultoftoolmisuseand/orincor-
rectoperatingproceduresorconditionsandcan
beavoidedbytakingproperprecautionsasgiven
below:
Maintain a firm grip, with thumbs and fingers
encircling the chain saw handles, with both
hands on the saw and position your body and
arm to allow you to resist kickback forces.
Kickbackforcescanbecontrolledbytheopera-
tor,ifproperprecautionsaretaken.Donotlet
goofthechainsaw.
Do not overreach and do not cut above chest
height. Thishelpspreventunintendedtipcon-
tactandenablesbettercontrolofthechainsaw
inunexpectedsituations.
Only use replacement bars and chains speci-
fied by the manufacturer.Incorrectreplace-
mentbarsandchainsmaycausechainbreak-
ageand/orkickback.
Follow the manufacturer’s sharpening and
maintenance instructions for the saw chain.
Decreasingthedepthgaugeheightcanleadto
increasedkickback.
Donotstartcuttinguntilyouhaveaclearwork
area,securefooting,andaplannedretreatpath
fromthefallingtree.Clutteredareasinviteac-
cidents.
KeepALLchildren, bystanders, visitors, and
animalsoutoftheworkareawhilestartingor
cuttingwiththechainsaw.Donotletvisitors
contactchainsaworextensioncord.
Donotoperatechainsawinexplosiveatmo-
spheres,suchasinthepresenceofflammable
liquids, gases, or dust. Chain saws create
sparkswhichmayignitethedustorfumes.
Dress Properly–Wear snugfittingclothing.
Alwayswearheavy,longpants,longsleeves,
overalls,jeansorchapsmadeofcutresistant
material or ones that contain cut resistant
inserts.Wear non-slip safety footwear.Wear
non-slipheavydutyglovestoimprove your
gripandtoprotect your hands.Donotwear
jewelry,shortpants,sandals,orgobarefoot.
Donotwearloosefittingclothing,whichcould
bedrawnintothemotororcatchthechainor
underbrush.Securehairsoitisaboveshoulder
level.Wearhearingandheadprotection.
Heavyprotectiveclothingmayincreaseoperator
fatigue,whichcouldleadtoheatstroke.Dur-
ingweatherthatishotandhumid,heavywork
shouldbescheduledforearlymorningorlate
afternoonhourswhentemperaturesarecooler.
Alwaysweareyeprotectionwithsideshields
markedtocomplywithANSIZ87.1aswellas
hearing and head protection when operating
thisequipment.
Alwaysbeawareofwhatyouaredoingwhen
usingthechainsaw.Usecommonsense.Do
notoperatethechainsawwhenyouaretired,ill,
upset,orundertheinfluenceofalcohol,drugs,
ormedication.
Donotexposethechainsawtorain.
Do not use the chain saw in damp or wet
locations.
Stayalertandpayattentiontowhatyouaredo-
ing.Usecommonsensewhenusingthisunit.
Keepallpartsofyourbodyawayfromthesaw
chainwhentheunitisrunning.
Neverletanyoneuseyourchainsawwhohas
notreceivedadequateinstructionsinitsproper
use.Thisappliestorentalsaswellasprivately
ownedsaws.
Beforeyoustarttheunit,makesurethe saw
chainisnotcontactinganyobject.
Stopthechainsawbeforesettingitdown.
Toavoidaccidentalstarting,nevercarrytheunit
withyourfingerontheswitchtrigger.
Maintain the unit with care. Keep the cutting
edgesharpandcleanforbestperformanceand
toreducetheriskofinjury.Followinstructions
forlubricatingandchangingaccessories.
Donotoperateachainsawwithonehand!Use
afirmgripwiththumbsandfingersencirclingthe

6 – English
CHAIN SAW SAFETY WARNINGS
chainsawhandles.Seriousinjurytotheopera-
tor,helpers,bystanders,oranycombinationof
thesepersonsmayresultfromone-handedop-
eration.Achainsawisintendedfortwo-handed
use.
Guardagainstelectricshock–Avoidbodycon-
tactwithgroundedsurfacessuchasmetalpipes
andwirefences.Thereisanincreasedriskof
electricshockifyourbodyisgrounded.
Donotoperateachainsawthatisdamaged,
improperly adjusted, ornot completely and
securelyassembled. Chain should slow to a
stopwhentheswitchtriggerisreleased.Ifthe
chaincontinuestoturnaftertheswitchtrigger
hasbeenreleased,havetheunitservicedbyan
authorizedservicecenter.
Checkfordamagedparts.Checkforalignment
ofmovingparts,bindingofmovingparts,break-
ageofparts,mounting,andanyothercondi-
tionsthatmayaffectitsoperation.Aguardor
otherpartthatisdamagedshouldbeproperly
repairedorreplacedbyanauthorizedservice
centerunlessotherwiseindicatedelsewherein
thismanual.
Allchainsawservice,otherthantheitemslisted
in the operation and maintenance sections,
shouldbeperformedbyanauthorizedservice
center.
Alwaysmaintainaproperstance.
Donotusechainsawifswitchdoesnotturniton
andoff.Haveswitchreplacedbyanauthorized
servicecenter.
Donotadaptyourpowerheadtoabowguide
oruseittopoweranyattachmentsordevices
notlistedforthesaw.
Disconnectchainsawfrompowersupplywhen
notinuse,beforeservicing,andwhenmaking
adjustmentsandchangingattachments,such
assawchainandguard.
Donotcutvinesand/orsmallunderbrush.
Donotoperateachainsawinatree,onaladder,
rooftop,scaffold,orotherunstablesupport;this
isextremelydangerous.
NOTE:Thesizeoftheworkareadependsonthe
jobbeingperformedaswellasthesizetreeor
workpieceinvolved.Forexample,fellingatree
requiresalargerworkareathanmakingbucking
cuts.
Donotforcethechainsaw.Thejobcanbeper-
formedbetterandsaferattherateforwhichit
wasintended.
Alwaysusetherightproductforyourapplica-
tion.Thechainsawshouldbeusedforcutting
woodonly.Neverusethechainsawtocutplas-
tic,masonryornon-woodbuildingmaterials.
Storechainsawwhennotchargingorwhennot
inuse.Chainsawshouldbestoredinadryand
highorlockedareaoutofthereachofchildren.
Whenstoringchainsawplacethescabbardon
thebarandchain.
Usethisproductonlywithbatteriesandchar-
gerslistedintool/appliance/batterypack/char-
gercorrelationsupplement995000885.
Battery operated units do not have to be
pluggedintoanelectricaloutlet;therefore,they
arealways in operating condition. Be aware
ofpossiblehazards even when unit is not
operating.
Removethebatterypackfromthechainsaw
whennotchargingandbeforecleaning,servic-
ing,storing,removing material fromtheunit,
changingaccessoriessuchasthebar and
chain,orwhennotinuse.
Neverusewateroranyliquidstocleanorrinse
offyourproductanddonotexposetheproduct
torainorwetconditions.Storeindoorsinadry
area. Corrosive liquids, water, and chemicals
canentertheproduct’selectroniccomponents
and/orbatterycompartmentanddamageelec-
tronic components and/or the battery pack,
whichcanresultinashortcircuit,increasedrisk
offire,andseriouspersonalinjury.Removeany
buildupofdirtanddebrisbywipingtheproduct
cleanwithadryclothoccasionally.

7 – English
CHAIN SAW SAFETY WARNINGS
KICKBACK
See Figures 1 - 3.
WARNING:
Kickbackmayoccurwhenthemovingchain
contactsanobjectattheupperportionofthe
tipoftheguidebarorwhenthewoodcloses
inandpinchesthesawchaininthecut.Con-
tactattheupperportionofthetipoftheguide
barcancausethechaintodigintotheobject
andstopthechainforaninstant.Theresultis
alightningfast,reversereactionwhichkicks
theguidebarupandbacktowardtheopera-
tor.Ifthesawchainispinchedalongthetop
oftheguidebar,theguidebarcanbedriven
rapidly back toward the operator. Either of
thesereactionscancauselossofsawcontrol
whichcanresultinseriousinjury.Donotrely
exclusivelyuponthesafetydevicesbuiltinto
thesaw.Asachainsawuser,youshouldtake
severalstepstokeepyourcuttingjobsfree
fromaccidentorinjury.
The following precautions should be followed
to minimize kickback:
 •Alwaysgripthesawfirmlywithbothhands.
Hold the saw firmly with both hands when
theunitisrunning.Placeyourrighthandon
the rear handle and yourleft hand on the
front handle with your thumbs andfingers
encirclingthechainsawhandles.Afirmgrip
togetherwithastiffleftarmwillhelpyoumain-
taincontrolofthesawifkickbackoccurs.
 •Makesurethattheareainwhichyouarecut-
tingisfreefromobstructions.Donotletthe
noseoftheguidebarcontactalog,branch,
fence,oranyotherobstructionthatcouldbe
hitwhileyouareoperatingthesaw.
 •Alwayscutwiththeunitrunningatfullspeed.
Fullysqueezethethrottletriggerandmaintain
asteadycuttingspeed.
 •Usereplacementpartssuchaslowkickback
chainandspecialguidebarsthatreducethe
risksassociatedwithrotationalkickback.Use
onlythereplacementguidebarsandlowkick-
backchainsspecifiedbythemanufacturerfor
thesaw.
With a basic understandingofkickback,you
canreduceoreliminatetheelementofsurprise.
Suddensurprisecontributestoaccidents.
Donotoverreach.Keepproperfootingandbal-
ance at all times.
Do not cut above chest height or overreach
whencutting.Donotletthenoseoftheguide
barcontactalog,branch,ground,oranyother
obstructionwhileyouareoperatingtheunit.
ROTATIONAL
KICKBACK
KICKBACK
DANGER ZONE
PUSH
PULL
FIG. 1
FIG. 2
FIG. 3

8 – English
CHAIN SAW SAFETY WARNINGS
Followthesharpeningandmaintenanceinstruc-
tionsforthesawchain.
PushandPull–Thisreactionforceisalways
oppositetothedirectionthechainismoving
wherewoodcontactismade.Thus,theoperator
mustbereadytocontrolthePULLwhencutting
onthebottomedgeofthebar,andPUSHwhen
cuttingalongthetopedge.See Figure 3.
UNDERSTANDING YOUR CHAIN SAW SAFETY
DEVICES
LOW KICKBACK SAW CHAIN
Therakers(depthgauges)aheadofeachcutter
canminimizetheforceofakickbackreactionby
preventingthecuttersfromdiggingintoodeeply
atthekickbackzone.Onlyusereplacementchain
thatisequivalenttooriginalchainorhasbeen
certifiedaslowkickbackchainperANSIB175.1.
Low kickback saw chain is chain that has met
thekickbackperformancerequirementsofANSI
B175.1(AmericanNationalStandard for Power
Tools–Gasoline-Powered Chain Saws-Safety
Requirements)whentestedontherepresentative
sampleofchainsawsbelow3.8c.i.d.specifiedin
ANSIB175.1.
Assawchainsaresharpenedduringtheiruseful
life,theylosesomeofthelowkickbackqualities
andextracautionshouldbeused.
GUIDE BARS
Generally,guidebarswithsmallradiustipshave
somewhatlowerkickbackpotentials.
Whenmakingareplacement, be suretoorder
oneofthebarslistedforthesawinthisoperator’s
manual.
Savetheseinstructions.Refertothemfrequent-
lyandusethemtoinstructotherswhomayuse
thisproduct.Ifyouloansomeonethisproduct,
loanthemtheseinstructionsalso.

9 – English
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn
their meaning. Proper interpretation of these symbols will allow you to operate the product
better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicatesapotentialpersonalinjuryhazard.
Read Operator’s Man-
ual
Toreduce the risk of injury, usermustread and
understandoperator’smanualbeforeusingthis
product.
Eye, Hearing, and Head
Protection
Alwaysweareyeprotectionwithsideshieldsmarked
tocomplywithANSIZ87.1,alongwithhearingand
headprotectionwhenoperatingthisequipment.
Wet Conditions Alert
Donotexposebattery,battery compartment, or
electroniccomponentstorain,water,orliquids.Do
notchargebatteryorexposeproducttorainordamp
locations.
Operate With Two
Hands Holdandoperatethesawproperlywithbothhands.
One Handed Donotoperatethesawusingonlyonehand.
The following signal words and meanings are intended to explain the levels of risk associated
with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicatesahazardoussituation,which,ifnotavoided,willresult
indeathorseriousinjury.
WARNING: Indicatesahazardoussituation,which,ifnotavoided,could
resultindeathorseriousinjury.
CAUTION: Indicatesahazardoussituation,that,ifnotavoided,mayresult
inminorormoderateinjury.
NOTICE: (WithoutSafetyAlertSymbol)Indicatesinformationconsidered
important,butnotrelatedtoapotentialinjury(e.g.messages
relatingtopropertydamage).

10 – English
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their
meaning.Properinterpretationofthesesymbolswillallowyoutooperatetheproductbetterandsafer.
SYMBOL NAME DESIGNATION/EXPLANATION
Kickback DANGER!BEWAREOFKICKBACK.
Bar Nose Contact
Avoidbarnosecontact.Tipcontactmaycausethe
guidebartomovesuddenlyupwardandbackward,
whichmaycauseseriousinjury.
Oil Can Addbaroiltoreservoir.
Wear Gloves Wear non-slip, heavy-duty protective gloves when
handlingthechainsaw.
Wear Safety Footwear Wear non-slip safety footwear when using this
equipment.
Keep Tool Away from
Electrical Lines/Keep
Bystanders Away
DANGER!Riskofelectrocution! Keep tool50feet
awayfromelectricallines.Keepallbystandersatleast
50ft.awayortwicetheheightofthelargesttreesin
thefellingareawhenfelling.
Recycle Symbol
Thisproductuseslithium-ion(Li-ion)batteries.Local,
stateorfederallawsmayprohibitdisposalofbatteries
inordinarytrash.Consultyourlocalwasteauthority
forinformationregardingavailablerecyclingand/or
disposaloptions.
VVolts Voltage
Direct Current Typeoracharacteristicofcurrent

11 – English
GLOSSARY OF TERMS
Bucking
Theprocessofcrosscuttingafelledtreeorlog
intolengths.
Chain Saw Power Head
Achainsawwithoutthesawchainandguidebar.
Drive Sprocket or Sprocket
Thetoothedpartthatdrivesthesawchain.
Felling
Theprocessofcuttingdownatree.
Felling Back Cut
Thefinalcutinatreefellingoperationmadeon
theoppositeside ofthetreefromthe notching
undercut.
Front Hand Guard
Astructuralbarrier betweenthefronthandleof
achainsawandtheguidebar,typicallylocated
closetothehandpositiononthefronthandle.
Front Handle
Thesupporthandlelocatedatortowardthefront
ofthechainsaw.Thishandleisforthelefthand.
Guide Bar
Asolidrailedstructurethatsupportsandguides
thesawchain.
Kickback
Thebackwardorupwardmotion,orboth,ofthe
guidebaroccurringwhenthesawchainnearthe
noseofthetopareaoftheguidebarcontactsany
objectsuchasalogorbranch,orwhenthewood
closesinandpinchesthesawchaininthecut.
Kickback (Pinch)
Therapidpushbackofthesawwhichcanoccur
whenthewoodclosesinandpinchesthemoving
sawchaininthecutalongthetopoftheguidebar.
Kickback (Rotational)
The rapid upwardand backward motion of the
sawwhichcanoccurwhenthemovingsawchain
neartheupperportionofthetipoftheguidebar
contactsanobject,suchasalogorbranch.
Lock-out Button
A movable stop that prevents the unintentional
operationoftheswitchuntilmanuallyactuated.
Low-Kickback Chain
Achainthatcomplieswiththekickbackperfor-
mancerequirementsofANSIB175.1whentested
onarepresentativesampleofchainsaws.
Normal Cutting Position
Thosepositionsassumedinperformingthebuck-
ingandfellingcuts.
Notching Undercut
Anotchcutinatreethatdirectsthetree’sfall.
Rear Handle
Thesupporthandlelocatedatortowardtherear
ofthesaw.Itnormallycontainsthethrottle.This
handleisfortherighthand.
Reduced Kickback Guide Bar
A guide bar which has been demonstrated to
reducekickbacksignificantly.
Replacement Saw Chain
Achainthatcomplieswiththekickbackperfor-
mancerequirementsofANSIB175.1whentested
withspecificchainsaws.ItmaynotmeettheANSI
performancerequirementswhenusedwithother
saws.
Saw Chain
Aloopofchainhavingcuttingteeththatcutthe
wood,andthatisdrivenbythemotorandissup-
portedbytheguidebar.
Springpole
Asmalltree(sapling)orlimbthatisbentortrapped
undertension.Itmay“springback”rapidlywhen
cut,causingadangeroussituation.
Switch Trigger
A device that when operated will complete or
interruptanelectricalpowercircuittothemotor
ofthechainsaw.

12 – English
FEATURES
PRODUCT SPECIFICATIONS
Motor.................................................. 20VoltDC
BarLength.................................................. 12 in.
NOTE: Thissawwasdesignedforoccasionallight
dutyuseandhassomelimitationsastowhatit
can cut.
KNOW YOUR CHAIN SAW
See Figure 4.
The safe use of this product requires an
understandingoftheinformationontheproduct
andinthisoperator’smanualaswellasa
knowledgeoftheproject you areattempting.
Beforeuseofthisproduct,familiarizeyourselfwith
alloperatingfeaturesandsafetyrules.
FRONT HANDLE
FRONT HAND
GUARD
SWITCH
TRIGGER
LOCK-OUT
SWITCH
CHAIN OIL
TANK CAP
REAR
HANDLE
GUIDE
BAR
CHAIN
SCABBARD
SCRENCH
FIG. 4

13 – English
ASSEMBLY
UNPACKING
Thisproducthas been shipped completely
assembled.
Carefullyremovetheproductandanyacces-
soriesfromthebox.Makesurethatallitems
listedinthepackinglistareincluded.
WARNING:
Donotusethisproductifitisnotcompletely
assembledorifanypartsappeartobemissing
ordamaged.Useofaproductthatisnotprop-
erlyandcompletelyassembledcouldresultin
seriouspersonalinjury.
Inspecttheproductcarefullytomakesureno
breakageordamageoccurredduringshipping.
Donotdiscardthepackingmaterialuntilyou
havecarefullyinspectedandsatisfactorilyoper-
atedtheproduct.
Ifanypartsaredamagedormissing,pleasecall
1-800-776-5191forassistance.
PACKING LIST
ChainSawwithScabbard
Scrench
Operator’sManual
WARNING:
Ifanypartsaredamagedormissingdonotop-
eratethisproductuntilthepartsarereplaced.
Useofthisproductwithdamagedormissing
partscouldresultinseriouspersonalinjury.
WARNING:
Donotattempttomodifythisproductorcreate
accessoriesnotrecommendedforusewiththis
product.Anysuchalterationormodificationis
misuseandcouldresultinahazardouscondi-
tionleadingtopossibleseriouspersonalinjury.
WARNING:
Topreventaccidentalstartingthatcouldcause
seriouspersonalinjury,alwaysremovethebat-
terypackfromtheproductwhenassembling
parts.
OPERATION
DANGER:
Nevercutnearpowerlines,electriccords,orotherelectricsources.Ifbarandchainjamsonany
electricalcordorline,DONOTTOUCHTHEBARORCHAIN!THEYCANBECOMEELECTRICALLY
LIVEANDVERYDANGEROUS.Continuetoholdthechainsawbytheinsulatedrearhandleorlayit
downandawayfromyouinasafemanner.Disconnecttheelectricalservicetothedamagedlineor
cordbeforeattemptingtofreethebarandchainfromthelineorcord.Contactwiththebar,chain,
otherconductivepartsofthechainsaw,orliveelectriccordsorlineswillresultindeathbyelectro-
cution,electricshock,orseriouspersonalinjury.

14 – English
WARNING:
Do not allow familiarity with this product to
makeyoucareless.Rememberthatacareless
fractionofasecondissufficienttoinflictseri-
ous injury.
WARNING:
Alwaysweareyeprotectionwithsideshields
markedtocomplywithANSIZ87.1,alongwith
hearingandheadprotection.Failuretodoso
couldresultinobjectsbeingthrownintoyour
eyesresultinginpossibleseriousinjury.
WARNING:
Do not use any attachments or accessories
notrecommendedbythemanufacturerofthis
product. The use of attachments or acces-
soriesnotrecommendedcanresultinserious
personalinjury.
WARNING:
Neverfellatreeorcutalogorlimbthathasa
diametergreaterthanthelengthoftheguide
bar.Onlyproperlytrainedprofessionalsshould
performthesecuts.Performingthesetypesof
cutscancauseanaccidentandresultindeath
orseriouspersonalinjury.
NOTICE:
Before each use, inspect the entire product
fordamaged,missing,orloosepartssuchas
screws,nuts,bolts,caps,etc.Tightensecurely
allfastenersandcapsanddonotoperatethis
productuntilallmissingordamagedpartsare
replaced.Pleasecontactcustomerserviceor
anauthorizedservicecenterforassistance.
APPLICATIONS
Youmayusethisproductforthefollowingpur-
poses:
Basiclimbing,felling,andwoodcutting
OPERATION
TO INSTALL/REMOVE BATTERY PACK
See Figure 5.
WARNING:
Always remove battery pack from your tool
whenyouareassemblingparts,makingadjust-
ments,cleaning,carrying,transportingorwhen
notinuse.Removingbatterypackwillprevent
accidental starting that could cause serious
personalinjury.
NOTE: To avoid serious personal injury, always
removethebatterypackandkeephandsclearof
thelook-outbuttonwhencarryingortransporting
thetool.
To install:
Placethebatterypackinyourchainsaw.Align
raisedribonbatterypackwithgrooveinchain
saw’sbatteryport.
WARNING:
Makesurethelatchonthebatterypacksnaps
in place and the battery pack is fully seated
andsecureinthebatteryportbeforebeginning
operation.Failuretosecurelyseatthebattery
packcouldcausethebatterypacktofallout,
resultinginseriouspersonalinjury.
BATTERY
PACK
BATTERY
PORT
FIG. 5
LATCH

15 – English
OPERATION
To remove:
Locatelatchonbackofbatterypackanddepress
toreleasethebatterypackfromthechainsaw.
Forcompletecharginginstructions,seetheopera-
tor’smanualsforyourbatterypackandcharger.
NOTICE:
Whenplacingbatterypackinyourchainsaw,
besureraisedribonbatterypackalignswith
groove in chain saw’s battery port and latch
snaps in place properly. Improper assembly
ofbatterypackcancausedamagetointernal
components
CHAIN LUBRICATION SYSTEM
See Figure 6.
NOTICE:
Removebatterypackfromunit.Filloiltankwith
HARTBarandChainLubricantbeforestarting
thechainsaw.Failuretolubricatethechainwill
causedamagetothebarandchain.
UseHARTBarandChainLubricant. Itisformu-
latedtoperformoverawidetemperaturerange
withnodilutionrequired.
NOTE: Donotusedirty,usedorotherwisecon-
taminatedlubricants.Damagemayoccurtothe
barorchain.
Carefullypourthebarandchainlubricantinto
thetank.
Checkandfilltheoiltankwhenbatteryisre-
charged,orasneeded.
Depresstheoiltankcaponcetopumpthelu-
bricanttothechainbeforestartingthesaw.
Tokeepthechainlubricatedwhilecutting,de-
presstheoiltankcaponceeveryfewminutes.
NOTE:Itisnormalforlubricanttoseepfromthe
sawwhennotinuse.Topreventseepage,empty
theoiltankaftereachuse.Whenstoringtheunit
foralongperiodoftime(threemonthsorlonger)be
surethechainislightlylubricated;thiswillprevent
rustonthechainandbarsprocket.
NOTICE:
Beforeeachuse,checktomakesurethatthe
chainisproperlytensioned.Acoldchainiscor-
rectlytensionedwhenthereisnoslackonthe
undersideoftheguidebar,thechainissnug,
anditcanbeturnedbyhandwithoutbinding.
Duringnormalsawoperation,thetemperature
ofthechainincreases.Thedrivelinksofacor-
rectlytensionedwarmchainwillhangapproxi-
mately.050in.outofthebargroove.
FIG. 6

16 – English
SeetheAdjusting the Chain Tension instruc-
tionsintheMaintenancesectionofthismanual
toproperlyadjustthechaintension.
STARTING/STOPPING THE CHAIN SAW
See Figure 7.
WARNING:
Keepbodytotheleftofthechainline.Never
straddlethesaworchain,orleanoverpastthe
chainline.Improperoperationofthechainsaw
couldresultinseriouspersonalinjury.
Starting the chain saw:
Placethechainsawonaflatbaresurfaceand
makesurenoobjectsorobstructionsareinim-
mediatevicinitywhichcouldcomeincontact
withthebarandchain.
Pressandholdthelock-outbutton.Thismakes
theswitchtriggeroperational.
Pressandholdtheswitchtrigger,releasethe
lock-outbuttonandcontinuetosqueezethe
switchtriggerforcontinuedoperation.
Stopping the chain saw:
Releasetheswitchtriggertostopthechainsaw.
Uponreleaseoftheswitchtrigger,thelock-out
button will be automatically reset to thelock
position.
Thiscordlesschainsawisnotdesignedforcutting
treeslargerthan7in.indiameter.
Thiscordlesschainsawisdesignedforlimbing
andpruningtypecutting,aswellascuttingtrees
upto7in.indiameteronly.
PREPARATION FOR CUTTING
PROPER GRIP ON HANDLES
See Figures 8 - 10.
Refer to Important Safety Instructions earlierinthis
manualforappropriatesafetyequipment.
Wear non-slip gloves for maximum grip and
protection.
Holdthesawfirmly withbothhands.Always
keepyourlefthandonthefronthandleandyour
righthandontherearhandlesothatyourbody
istotheleftofthechainline.
LOCK-OUT
BUTTON
SWITCH
TRIGGER
LOCK-OUT
BUTTON
SWITCH
TRIGGER
OPERATION
WARNING:
Neverusealeft-handed(cross-handed)grip,or
anystancewhichwouldplaceyourbodyorarm
acrossthechainline.Improperoperationofthe
chainsawcouldresultinseriouspersonalinjury.
FIG. 7
FIG. 8

17 – English
OPERATION
CHAIN LINE
Maintain a propergriponthesawwhenever
theunitisrunning.Thefingersshouldencircle
thehandleandthethumbiswrappedunderthe
handlebar.Thisgripisleastlikelytobebroken
(byakickbackorothersuddenreactionofthe
saw).Anygripinwhichthethumbandfingers
areonthesamesideofthehandle,isdanger-
ousbecauseaslightkickofthesawcancause
loss of control.
WARNING:
Donotoperatetheswitchtriggerwithyourleft
handandholdthefronthandlewithyourright
hand.Neverallowanypartofyourbodytobe
inthechainlinewhileoperatingasaw.Improper
operationofthechainsawcouldresultinseri-
ouspersonalinjury.
PROPER CUTTING STANCE
See Figure 11.
WARNING:
Alwayusethepropercuttingstancedescribed
in this section. Never kneel when using the
chainsawexceptwhenfellingatreeasshown
infigure15.Kneelingcouldresultinlossofsta-
bilityandcontrolofthesawresultinginserious
personalinjury.
Weightshouldbebalancedwithbothfeeton
solidground.
Keepleftarmwithelbowlockedina“straight
arm”positiontowithstandanykickbackforce.
Yourbodyshouldalwaysbetotheleftofthe
chainline.
Thumbshouldbeonundersideofhandlebar.
BASIC CUTTING PROCEDURE
Practicecuttingafewsmalllogsusingthefollow-
ingtechniquetogetthe“feel”ofusingthesaw
beforeyoubeginamajorsawingoperation.
Supportlogonasawhorseorcradle.
Taketheproperstanceinfrontofthewoodwith
thesawoff.
Squeeze the switch trigger and let the chain
acceleratetofullspeedbeforeenteringthecut.
STRAIGHT ARM
POSITION
CHAIN LINE
Begincuttingwiththesawagainstthelog.
Keeptheunitrunningtheentiretimeyouare
cutting,maintainasteadyspeed.
Allowthechaintocutforyou;exertonlylight
downwardpressure.Ifyouforcethecut,dam-
agetothebar,chain,orunitcanresult.
Releasetheswitchtriggerassoonasthecut
iscompleted,allowingthechaintostop.Ifyou
runthesawwithoutacuttingload,unnecessary
wearcanoccurtothechain,bar,andunit.
Donotputpressureonthesawattheendofcut.
FIG. 9
FIG. 10
FIG. 11

18 – English
WORK AREA PRECAUTIONS
Cutonlywoodormaterialsmadefromwood,
nosheetmetal,noplastics,nomasonry, no
non-woodbuildingmaterials.
Neverallowchildrentooperatethesaw.Allow
nopersontousethischainsawwhohasnot
read this Operator’s Manual or received ad-
equateinstructionsforthesafeandproperuse
ofthischainsaw.
Keepeveryone-helpers,bystanders,children,
andanimals-asafedistancefromthecutting
area.During felling operations, thesafedis-
tanceshouldbealeasttwicetheheightofthe
largesttreesinthefellingarea.Duringbucking
operations,keepaminimumdistanceof15feet
betweenworkers.
Alwayscutwith bothfeetonsolidgroundto
preventbeingpulledoffbalance.
Donotcutabovechestheight,asasawheldhigh-
erisdifficulttocontrolagainstkickbackforces.
Donotfelltreesnearelectricalwiresorbuild-
ings.Leavethisoperationforprofessionals.
Cutonlywhenvisibilityandlightareadequate
for you to see clearly.
FELLING TREES
See Figures 12 - 15.
HAZARDOUS CONDITIONS
WARNING:
Donotfelltreesduringperiodsofhighwindor
heavy precipitation. Wait until the hazardous
weatherhasended.
OPERATION
45°
45°
PLANNED LINE
OF FALL
RETREAT PATH
RETREAT PATH
WARNING:
Closely check for broken or dead branches,
whichcouldfallwhilecuttinganddonotcut
nearbuildingsorelectricalwiresifyoudonot
knowthedirection of treefall. Do not cutat
nightorduringbadweatherconditions,suchas
rain,snow,orstrongwinds,whichcanreduce
visibilityandcontrolofthechainsaw.Ifthetree
youarefellingmakescontactwithanyutility
line,youshoulddiscontinueuseofthechain
sawandimmediatelynotifytheutilitycompany.
Failuretofollowtheseinstructionscouldresult
indeathorseriouspersonalinjury.
Whenfellingatree,itisveryimportantthatyou
closelyfollowthesewarningsandinstructionsto
preventpossibledeathorseriouspersonalinjury.
Donotcutdowntreeshavinganextremeleanor
largetreeswithrottenlimbs,loosebark,orhol-
lowtrunks.Havethesetreespushedordragged
downwithheavyequipment,thencutthemup.
Donotcuttreesnearelectricalwiresorbuildings.
Checkthetreefordamagedordeadbranches
thatcouldfallandhityouduringfelling.
FIG. 12

19 – English
OPERATION
Periodicallyglanceatthetopofthetreeduring
thebackcuttoassurethetreeisgoingtofallin
thedesireddirection.
Ifthetreestartstofallinthewrongdirection,
orifthesawgetscaughtorhungupduringthe
fall,leavethesawandsaveyourself!
 Felling a tree - When bucking and felling op-
erations are being performed by two or more
persons,atthesametime,thefellingoperation
shouldbeseparatedfromthebuckingoperation
byadistanceofatleasttwicetheheightofthe
treebeingfelled.Treesshouldnotbefelledina
mannerthatwouldendangeranyperson,strike
anyutilitylineorcauseanypropertydamage.If
thetreedoesmakecontactwithanyutilityline,the
utilitycompanyshouldbenotifiedimmediately.
Beforeanycutsarestarted,pickyourescape
route(orroutesincasetheintendedrouteis
blocked);cleartheimmediateareaaroundthe
treeandmakesuretherearenoobstructionsin
yourplannedpathofretreat.Clearpathsofsafe
retreatshouldextendbackanddiagonally(45°)
totherearoftheplannedlineoffall.Whenthe
treebeginstofall,youshouldretreatawayfrom
thedirectionoffallalongaretreatpathandat
least20feetawayfromthetrunkincaseitkicks
backoverthestump.See Figure 12.
Beforefellingisstarted,considertheforceand
directionofthewind,theleanandbalanceof
thetree,andthelocationoflargelimbs.These
thingsinfluencethedirectioninwhichthetree
willfall.Donottrytofellatreealongalinedif-
ferent from its natural line of fall.
The chainsawoperatorshouldkeeponthe
uphillsideoftheterrainasthetreeislikelyto
rollorslidedownhillafteritisfelled.
Removedirt,stones,loosebark,nails,staples,
andwirefromthetreewherefellingcutsareto
bemade.
Notched Undercut.Cutanotchabout1/3the
diameterofthetree,perpendiculartothedirec-
tionoffall.Makethecutsofthenotchsothey
intersectatarightangletothelineoffall.This
notchshouldbecleanedouttoleaveastraight
line.Tokeeptheweightofthewoodoffthesaw,
HINGE
2 in. OR 1/10 DIA
NOTCH -
APPROX. 1/3
DIAMETER OF
TRUNK
BACK CUT
2 in.
NOTCH
BACK CUT
HINGE
WEDGE
alwaysmakethelowercutofthenotchbefore
theuppercut.See Figure 13.
Felling Backcut.Thebackcutisalwaysmade
levelandhorizontal,andataminimumof2in.
abovethehorizontalcutofthenotch.See Fig-
ures 13 - 14.
Nevercutthroughtothenotch.Alwaysleavea
bandofwoodbetweenthenotchandbackcut
(approximately2in.or1/10thediameterofthe
tree).Thisiscalled“hinge”or“hingewood.”It
controlsthefallofthetreeandpreventsslip-
FIG. 13
FIG. 14
FIG. 15

20 – English
OPERATION
pingortwistingorshoot-backofthetreeoffthe
stump.See Figures 13 - 14.
On large diameter trees, stop the back cut
beforeitisdeepenoughforthetreetoeither
fallorsettlebackonthestump.Theninsert
softwoodenorplasticwedgesintothecutso
theydonottouchthechain.Thewedgescan
bedrivenin,littlebylittle,tohelpjackthetree
over.See Figure 15.
 Astreestartstofall,stopthechainsawandput
itdownimmediately.Retreatalongthecleared
path,butwatchtheactionincasesomething
fallsyourway.Bealert for overhead limbs or
branchesthatmayfallandwatchyourfooting.
WARNING:
Nevercutthroughtothenotchwhenmakinga
backcut.Thehingecontrolsthefallofthetree,
thisisthesectionofwoodbetweenthenotch
andbackcut.
BUCKING
See Figures 16 - 19.
Buckingisthetermusedforcuttingafallentree
tothedesiredloglength.
Alwaysmakesureyourfootingissecureand
yourweightisdistributedevenlyonbothfeet.
Cutonlyonelogatatime.
Supportsmalllogsonasawhorseoranother
logwhilebucking.
Keepaclearcuttingarea.Makesurethatno
objects can contact the guide bar nose and
chainduringcutting,thiscancausekickback.
Refer to Kickbackearlierinthismanual.
Whenbuckingonaslope,alwaysstandonthe
uphillsideofthelog.Tomaintaincompletecon-
trolofthechainsawwhencuttingthroughthe
log,releasethecuttingpressureneartheendof
thecutwithoutrelaxingyourgriponthechain
sawhandles.Donotletthechaincontactthe
ground.Aftercompletingthecut,waitforthe
sawchaintostopbeforeyoumovethechain
saw.Alwaysstopthemotorbeforemovingfrom
tree to tree.
KICKBACK
LOAD
FINISHING CUT
1ST CUT
1/3 DIA
LOG SUPPORTED AT ONE END:
LOG SUPPORTED AT BOTH ENDS:
FINISHING CUT
1ST CUT 1/3 DIA
LOAD
FIG. 16
FIG. 17
FIG. 18
