HENX H40GC20 User manual

40-Volt Cordless Lawn Mower
H40GC20
OPERATOR’S MANUAL
WARNING: Read all safety rules and
instructions carefully before operating this tool.
Improper use can cause serious or fatal injury.

2
TABLE OF CONTENTS
Safety Symbols................................................................................................................................................................... 4
Safety Instructions........................................................................................................................................... 5-6
Safety Rules for Cordless Lawn Mower...................................................................................................................7-11
Specifications.....................................................................................................................................................13
Assembly............................................................................................................................................................................14
Description.................................................................................................................................................... 15-17
Operation......................................................................................................................................................................18-25
Maintenance.................................................................................................................................................26-32
Troubleshooting...........................................................................................................................................33-34
Warranty.............................................................................................................................................................................35
Parts List...................................................................................................................................................................... 36-37

3
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
WARNING: Some dust created by power cutting contains chemicals known to the state of California to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
Lead from lead-based paints
Crystalline silica from bricks and cement and other masonry products, and
Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these
chemicals: work in a well ventilated area, and work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.

4
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them
deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper accident prevention measures.
WARNING: Be sure to read and understand all safety instructions in this Operator’s Manual, including all safety alert symbols
such as “DANGER,” “WARNING,” and “CAUTION” before using this tool. Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, or CAUTION. May be used in conjunction with other symbols or
pictographs.
WARNING: The operation of any power tools can result in foreign objects being thrown into your eyes, which can result in
severe eye damage. Before beginning power tool operation, always wear safety goggles or safety glasses with side shields and a
full face shield when needed. We recommend a Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with
side shields. Always use eye protection which is marked to comply with ANSI Z87.1.

5
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the
machine before attempting to assemble and operate.
Safety Alert
Indicates a potential personal injury hazard.
Eye Protection
Always wear safety goggles or safety glasses with side shields and a
full face shield when operating this product.
Read Operator’s Manual
To reduce the risk of injury, user must read and understand operator’s
manual before using this product.
Maintain Safety Devices
Do not open or remove safety shields while the tool is running.
Look Behind While
Backing
Look down and behind first to avoid tripping when pulling back.
DANGER — Keep Hands
and Feet Away
To reduce the risk of injury, keep hands and feet away from rotating
parts. Do not operate unless discharge cover or grass bag is in its
proper place. If damaged, replace immediately.
DANGER — Steep Slope
Hazard
Use extra caution on slopes. Do not mow slopes greater than 15
degrees.
Remove disabling device before maintenance
Recycle Symbols
This product uses lithium-ion (Li-ion) batteries. Local, state, or federal
laws may prohibit disposal of batteries in ordinary trash. Consult your
local waste authority for information regarding available recycling and/or
disposal options.

6
Keep bystanders away
Never operate the machine while people, especially children, or pets
are nearby
Charging/Store the battery
pack
Charging and Store the battery pack only in dry rooms with an ambient
temperature of 50°F to 104°F (+10°C to +40°C).
IPX4
Ingress Protection Degree
Protection from splashing water
V
Volt
Voltage
A
Amperes
Current
Hz
Hertz
Frequency (cycles per second)
W
Watt
Power
min
Minutes
Time
Alternating Current
Type of current
Direct Current
Type or a characteristic of current
n
0
No Load Speed
Rotational speed, at no load
... /min
Per Minute
Revolutions per minute
WARNING: Toensure safety and reliability, all repairs should be performed by a qualified service technician.

7
Battery Tool Use And Care
Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a
risk of fire when used with another battery pack.
Use the lawn mowers only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and
fire.
When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small
metal objects that can make a connection from one terminal to another. shorting the battery terminals together may cause burns or
a fire.
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. if
liquid contact eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
Battery powered lawn mowers do not have to be plugged into an electrical outlet; therefore, they are always in operating condition.
Be aware of possible hazards when not using your battery powered lawn mowers or when changing accessories. Following this rule
will reduce the risk of electric shock, fire, or serious personal injury.
Do not charge the battery pack outdoors.
Use only the charger supplied by the manufacturer to recharge.
Do not leave lawn mowers unattended when the battery is inserted. Remove the battery when the lawn mower is not in use and
before servicing.
Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present.
Do not operate lawn mowers in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust.
SAFETY RULES FOR CORDLESS LAWN MOWER
For battery
1) Use only the following type and size battery
2) Do not dispose of the battery in a fire. The cell may explode. Check with local codes for possible special disposal instructions.
3) Do not open or mutilate the battery. Released electrolyte is corrosive and may cause damage to the eyes or skin. It may be
toxic if swallowed.
4) Exercise care in handling batteries in order not to short the battery with conducting materials such as rings, bracelets, and keys.
The battery or conductor may overheat and cause burns.
For Mower
1) Avoid Dangerous Environment – Don’t use lawn mowers in damp or wet locations.
2) Don’t Use In Rain.
3) Dress Properly – Do not wear loose clothing or jewelry. They can be caught in moving parts. Use of rubber gloves and footwear
is recommended when working outdoors.
4) Use Right Appliance – Do not use lawn mower for any job except that for which it is intended.
5) Don’t Force Lawn Mower – It will do the job better and safer at the rate for which it was designed.
6) Don’t Overreach – Keep proper footing and balance at all times.
7) Stay Alert – Watch what you are doing. Use common sense. Do not operate lawn mower when you are tired.
8) Store Idle Lawn Mower Indoors – When not in use, lawn mower should be stored in an indoor dry and locked-up place – out of
reach of children.
9) Maintain Lawn Mower With Care – Keep cutting edges sharp and clean for best and safest performance.
10) Keep guards in place and in working order.

8
11) Keep blades sharp.
12) Keep hands and feet away from cutting area.
13) Objects struck by the lawn mower blade can cause severe injuries to persons. The lawn should always be carefully examined
and cleared of all objects prior to each mowing.
14) If lawn mower strikes a foreign object, follow these steps:
a. Stop lawn mower. Release the switch.
b. Unplug power cord.
c. Inspect for damage.
15) Use identical replacement blades only.
DANGER: This machine was built to be operated according to the rules for safe operation included in this manual. As with
any type of power equipment, carelessness or error on the part of the operator can result in serious injury. This machine is capable
of amputating hands and feet and throwing objects. Failure to observe all safety instructions could result in serious injury or death.
WARNING: When using electric lawn mowers, basic safety precautions should always be followed to reduce the risk of fire,
electric shock, and personal injury. These basic precautions include the following:
CHILDREN
Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the mower and
mowing activity. They do not understand the dangers. Never assume that children will remain where you last saw them.
Keep children out of the mowing area and under the watchful care of a responsible adult other than the operator.
Be alert and turn the mower off if a child enters the area.
Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that may obscure your vision of a
child who may run into the mower.
Never allow children under 15 years old to operate a power mower. Children 15 years old and over should read and understand
the operation instructions and safety rules in this manual and should be trained and supervised by a parent. Only responsible
individuals who are familiar with these rules of safe operation should be allowed to use this machine.
OPERATION
General Operation:
Read this operator’s manual carefully in its entirety before attempting to assemble this machine. Read, understand, and follow
all instructions on the machine and in the manuals before operation. Be completely familiar with the controls and proper use of
this machine before operating it. Keep this manual in a safe place for future and regular reference and for ordering
replacement parts.
Use the right appliance – Do not use the lawn mower for any job except that for which it is intended. Your lawn mower has been
designed to perform only one job: to mow grass.
Don’t overreach – Keep proper footing and balance at all times.
Objects struck by the lawn mower blade can cause severe injuries to persons. The lawn should always be carefully examined
and cleared of all objects prior to each mowing.
Keep the area of operation clear of all persons, particularly small children, and pets.
Before and while moving backwards with the mower, look behind and down for small children and other people.
Keep clear of the discharge opening at all times.
This machine is a precise piece of power equipment, not a plaything. Therefore, exercise extreme caution at all times. Your unit
has been designed to perform one job: to mow grass. Do not use it for any other purpose.
Don’t force the lawn mower – it will do the job better and more safely at the rate for which it was designed.

9
Thoroughly inspect the area where the equipment is to be used. Remove all stones, sticks, wire, toys and other foreign objects
that could be tripped over or picked up and thrown by the blade. Thrown objects can cause serious personal injury.
Plan your mowing pattern to avoid discharge of material toward roads, sidewalks, bystanders and the like. Also, avoid
discharging material against walls or obstructions, which may cause discharged material to ricochet back toward the operator.
To help avoid blade contact or an injury from thrown objects, stay in the operator zone behind the handles and
keep children, bystanders, helpers and pets at least 100 feet (30m) from the mower while it is in operation. Stop the machine if
anyone enters the area.
Always wear safety glasses or safety goggles during operation and while performing an adjustment or repair to protect your
eyes. Thrown objects that ricochet can cause serious injury to the eyes. Always use a face or dust mask if the operation is
dusty.
Dress properly – Do not wear loose clothing or jewelry. They can be caught in moving parts. Use of rubber gloves and footwear
is recommended when working outdoors. Wear sturdy, rough-soled work shoes and close-fitting slacks and shirts. Shirts and
pants that cover the arms and legs and steel-toed shoes are recommended. Never operate this machine in bare feet, sandals,
slippery or lightweight (e.g., canvas) shoes.
Do not put hands or feet near rotating parts or under the cutting deck. Contact with the blade can amputate hands and feet.
A missing or damaged discharge cover can cause blade contact or injuries from thrown objects.
Many injuries occur as a result of the mower being pulled over the foot during a fall caused by slipping or tripping. Do not hold
onto the mower if you are falling; immediately release the handle.
Never pull the mower back toward you while you are walking. If you must back the mower away from a wall or obstruction, first
look down and behind you to avoid tripping, and then follow these steps:
Step back from mower to fully extend your arms.
Be sure you are well balanced with sure footing.
Pull the mower back slowly, no more than half way toward you.
Repeat these steps as needed.
Do not operate the mower while under the influence of alcohol or drugs.
Stay alert – watch what you are doing. Use common sense. Do not operate the lawn mower when you are tired.
The motor/blade control handle is a safety device. Never attempt to bypass its operation. Doing so makes the safety device
inoperative and may result in personal injury through contact with the rotating blade. The motor/blade control handle must
operate easily in both directions and automatically return to the disengaged position when released.

10
Avoid dangerous environments – Don’t use lawn mowers in damp or wet locations so as to avoid slipping and falling during
operation.
Always be sure of your footing. A slip and fall can cause serious personal injury. If you feel you are losing your footing, release
the motor/blade control handle immediately and the blade will stop rotating within three seconds.
Mow only in daylight or good artificial light. Walk, never run while operating.
Stop the blade when crossing gravel drives, walks or roads.
If the equipment should start to vibrate abnormally, immediately stop the motor, remove the battery and check for the cause.
Vibration is generally a warning of trouble.
Before cleaning the machine, unclogging the chute or removing or replacing the grass bag, mulching insert, or side discharge
chute, turn the motor off and wait until the blade comes to a complete stop, then remove the battery pack. The cutting blade
continues to rotate for a few seconds after the motor is shut off. Never place any part of the body in the blade area until you
are sure the blade has stopped rotating.
Never operate the mower without the proper trailing shield, discharge cover, grass bag, mulching insert, side discharge chute,
motor/blade control handle or other safety protective devices in place and working. Never operate the mower with damaged
safety devices. Failure to do so can result in personal injury.
If situations occur that are not covered in this manual, use care and good judgment. Contact HENX Customer Service for
assistance.
Use only with the battery packs and chargers listed below:
BATTERY PACK
CHARGER
H40B25,H40B50,
H40B75,
H40MC100(XVE219/4200300)
H40KC400
OPERATION ON A SLOPE:
Slopes are a major factor related to slip-and-fall accidents, which can result in severe injury. Operation on slopes requires extra
caution. If you feel uneasy on a slope, do not mow it. For your safety, use the slope gauge on page 22 to measure slopes before
operating this unit on a sloped or hilly area. If the slope is greater than 15 degrees, do not mow it.
Do:
Mow across the face of slopes; never mow up and down. Exercise extreme caution when changing direction on slopes.
Watch for holes, ruts, rocks, hidden objects, or bumps which can cause you to slip or trip. Tall grass can hide obstacles.
Do not:
Do not mow near drop-offs, ditches or embankments; you could lose your footing or balance.
Do not mow slopes greater than 15 degrees, as shown on the slope gauge.
Do not mow on wet grass. Unstable footing could cause slipping.

11
SERVICE
WARNING: Grass bag components, the discharge cover, side discharge chute, mulching insert and trailing shield are subject
to wear and damage, which could expose moving parts or allow objects to be thrown and could increase the risk of injury. For
safety protection, frequently check all components and replace damaged components immediately with identical replacement parts,
listed in this manual.
If the mower’s built-in overload protection switch frequently trips, contact HENX Customer Service or your Closest service
center.
Do not wash the mower with a hose; avoid getting water in the motor and electrical connections.
Remove the battery and store the idle lawn mower in a covered area when not in use. Allow the motor to cool before storing it
in any enclosure. The lawn mower should be stored in a dry, high, or locked-up enclosure, out of reach of children.
When servicing, use only identical replacement parts listed in this manual. Use of parts that do not meet the original equipment
specifications may lead to improper performance and compromised safety.
Remove or disconnect the battery pack before servicing, cleaning, or removing material from the lawn mower.
Follow instructions for lubricating and changing accessories.
Keep handles dry, clean and free from oil and grease.
To reduce a fire hazard, keep the motor cover free of grass, leaves and debris build-up.
Check the blade and motor mounting bolts at frequent intervals for proper tightness. Also, visually inspect the blade for damage
(e.g., bending, cracking and wear.). Replace the blade only with the identical replacement blade, as listed in this manual.
Maintain your mower with care – keep the mower blade sharp and clean for the best and safest performance. Mower blades
are sharp and can cut. Wrap the blade or wear gloves and use extra caution when servicing it.
Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.
Never remove or tamper with safety devices. Regularly check their proper operation. Never do anything to interfere with the
intended function of a safety device or to reduce the protection provided by a safety device.
Always stop the motor before making adjustments to a wheel or a cutting-height adjustment.
After striking a foreign object, stop the motor, remove the battery pack, allow the blade to stop rotating, and thoroughly inspect
the mower for any damage. Repair the damage before operating the mower.
Maintain or replace safety and instruction labels, as necessary.
SAVE THESE INSTRUCTIONS. Refer to them frequently and use them to instruct others who may use this tool. If you lend
this tool to someone else, also lend these instructions to them to prevent misuse of the product and possibly injury.

12
INTRODUCTION
Congratulations on your selection of a new generation of 40V Lithium-ion powered lawn mower. It has been designed,
engineered and manufactured to give you the best possible dependability and performance.
Should you experience any problem you cannot easily remedy, please contact HENX customer service
center 86-574-62037812.
This manual contains important information on the safe assembly, operation and maintenance of your mower.
Read it carefully before using the mower.Keep this manual handy so you can refer to it at any time.
SERIAL
NUMBER
DATE OF
PURCHASE
THE MODEL AND SERIAL NUMBERS WILL BE FOUND
ON A LABEL ATTACHED ON THE REAR DISCHARGE
DOOR.
YOU SHOULD RECORD BOTH SERIAL NUMBER AND
DATE OF PURCHASE AND KEEP IN A SAFE PLACE FOR
FUTURE REFERENCE

13
SPECIFICATIONS
Model Number
H40GC20
Voltage
40V DC
No-Load Speed
0-2600rpm / 0-3300rpm
Approximate Cutting Height Setting
5
5 different cutting heights from 1-
1/5”(30mm) to 3”(75mm) are
available.
Deck Cutting Size
20” (510mm)
Grass Bag Volume
60L
Mower Weight (Without battery pack;
with mulching insert)
52 lb. (23Kg)
APPROXIMATE RUNNING TIME
Battery pack type
Lithium-ion
H40B25
30 min.
H40B50
45 min.
H40B75
60 min.
NOTICE: The actual running time will vary with grass condition: species, density, moisture, etc.

14
ASSEMBLY
WARNING: To prevent accidental starting that could cause serious personal injury, always remove the battery
pack from the tool when assembling parts.
WARNING: Do not attempt to modify this tool or create accessories not recommended for use with this mower. Any
such alteration or modification is misuse and could result in a hazardous condition leading to serious injury.
UNPACKING
◾
First remove all the accessories from the carton, then grasp the front handle and rear handle at the same time to
carefully lift the mower up and out of the carton. Make sure that all items listed in the parts list are included.
◾
Inspect the product carefully to make sure that no breakage or damage occurred during shipping.
◾
Do not discard the packing material until you have carefully inspected and satisfactorily operated the mower.
◾
If any parts are damaged or missing, please return the mower to the place of purchase.
LIST OF CONTENTS
PART NAME
QUANTITY
Lawn mower
1
Grass bag
1
Grass bag frame
1
Side Discharge Chute
1
Mulching insert (pre-installed in mower)
1
Operator’s manual
1

15
DESCRIPTION
1a
Handle-LockingClamp
Rear-Discharge Door
Rear Handle
Battery-Pack Cove
LED Headlights
Front Handle
Safety Button
Handle
Bail switch (Switch Lever)
Side Rail
Handle-Locking
Clamp
Quick-Adjust Lever
Grass Bag
Cutting-Height Adjustment Lever
Rear Wheel
Front Wheel
1b
Trailing Shield
Rear Discharge Door
Support for
Upright Storage
1c
Connection socket
for backpack battery
Power Indicator
Control Panel
LED headlight
Start Button
Low speed
mode

16
WARNING: The safe use of this product requires an understanding of the information on the tool
and in this operator’s manual, as well as knowledge of the project you are attempting. Before use
of this product, familiarize yourself with all operating features and safety rules.
SAFETY BUTTON
The safety button must be pressed down before the motor can be started.
WARNING: The bail switch and the safety button are safety devices. Never attempt to bypass their operations.
ELECTRIC BRAKE
Quickly stops blade rotation when the bail switch is released.
HANDLE-LOCKING CLAMP
Locks/unlocks the side rails in the extended or the recessed position.
SIDE RAILS
Can be extended and locked for operation or recessed for storage.
battery-release
button
Dual battery port
Side Discharge Chute
(available separately)
Mulching Insert
1d
1e

17
QUICK-ADJUST LEVER
Locks/unlocks the handle position when adjusting the angle of the mower handle, there will be 3 positions
available:
1. Locked Storage Position
2. Grass Bag Attachment/Removal Position
3. Operating Position
TRAILING SHIELD & REAR DISCHARGE DOOR
The trailing shield is designed to minimize stones or other objects
being thrown backward by the mower blade. The shield and the rear
door minimize the possibility of accidental foot contact with the blade.
DO NOT operate the mower without the trailing shield and rear door in
place.
LED HEADLIGHTS
The LED headlights are located in the front of the mower. This feature
provides extra light for increased visibility.
SPRING-LOADED CUTTING-HEIGHT ADJUSTMENT LEVER
One-handed cutting-height adjustment

18
4
OPERATION
ADJUSTING THE FOLDABLE HANDLE
WARNING: Do not attempt to start the mower until the handle has
been locked at Operating Position.
1. LOCKED STORAGE POSITION: Your mower is shipped with the
handle in the compact, locked position (Fig. 2).
2. GRASS BAG ATTACHMENT/REMOVAL POSITION: Press and hold the quick-
adjust lever with your right hand to release the handle from the locked
storage position. Begin to lift the handle from its folded position with
y our left hand, and then release the lever (Fig. 2). Gently pivot the
handle upward until you hear and feel the lock pin engage in the
first position (Fig. 6.) This position allows easy access to install and
remove the grass bag.
3. OPERATING POSITION: press and hold the quick-adjustment lever
with your left hand to release the handle from Grass Bag
Attachment/Removal Position(Fig.3).Begin to lower the handle with
your right hand, and then release the lever. Gently pivot the handle
downward until you hear and feel the lock pin engage in the
Operating Position(Fig.3). Fully extend the side rails and securely
close the two handle-locking clamps(Fig. 4 & 5).
NOTE: The motor cannot be started unless:
a) The side rails are fully extended
b) Both green handle-locking clamps are securely closed
c) The handle is locked into Operating Position.
2
Press the Quick-
Adjust Lever
Locked Storage Position
Grass Bag
Attachment/R
emoval
Position
3
Operating
Position
4
5
A
B
C

19
ATTACHING/REMOVING THE GRASS BAG
WARNING: Do not at any time make any adjustment to the
lawn mower without first stopping the motor,removing the
battery pack and waiting for the blade to stop rotating.
NOTICE: Remove the mulching insert or side discharge chute
before attaching the grass bag on the mower;
1. Remove the battery.
2. Adjust the handle to the Grass Bag Attachment/Removal
Position (please see ADJUSTING THE FOLDABLE HANDLE).
3. Lift the rear-discharge door.
4. Hook the grass bag assembly on the pivot rod (Fig. 6).
Release thedischarge door so that itrests on the grass
bag.
5. To remove the grass bag, lift the rear-discharge door on
the mower. Lift the grass bag up, off of the pivot rod.
d) Release the discharge door.
WARNING: When using the grass bag, never operate the mower unless the hooks on the grass bag are firmly seated
on the pivot rod and the rear-discharge door rests firmly against the top of the grass bag.
WARNING: Under normal usage, bag material is subject to wear. To reduce the risk of injury, frequently inspect the
bag assembly and replace if there are any signs of wear or deterioration. Use only grass bags manufactured
for this mower.
ATTACHING/REMOVING THE MULCHING INSERT
WARNING: Do not at any time make any adjustment to the
lawn mower without first stopping the motor,removing the battery
pack and waiting for the blade to stop rotating.
1. Remove the battery.
2. Lift the rear-discharge door.
3. Grasp the handle of the mulching insert and fully insert it
into the mower,so that it is securely seated (Fig. 7).
4. To remove the mulching insert, lift the rear-discharge door,
grasp the handle of the mulching insert,and pull it out.
5. Release the discharge door and make sure it rests firmly
against the mulching insert.
NOTICE: The mulching insert must be removed in order to install and use the grass bag and must be re-
installed when the grass bag is removed.
6
7
Rear Discharge Door
Hook

20
ATTACHING/REMOVING THE SIDE DISCHARGE CHUTE
(available separately) (Fig. 8a & b)
WARNING: Do not at any time make any adjustment to
the lawn mower without first stopping the motor,removing the
battery pack and waiting for the blade to stop rotating.
1. Remove the battery.
2. Lift the rear-discharge door.
3. Align the lower edge of the discharge with the groove of the
door sill and insert it into the slot.
4. Push the top of the discharge and insert it into the mower.
Check to see that it is securely seated in the deck.
5. To remove the side discharge chute, lift the rear-discharge
door,grasp the side discharge chute and pull it out.
6. Release the discharge door and make sure that it rests firmly
against the discharge chute.
SPRING-LOADED CUTTING-HEIGHT ADJUSTMENT (Fig. 9)
WARNING: Do not at any time make any adjustment to the
lawn mower without first stopping the motor,removing the battery
pack and waiting for the blade to stop rotating.
WARNING: Keep your feet away from the deck when adjusting
its height.
The mower can be set to 5 cutting heights between1-1/5” (30mm)
and 3” (75mm).Choose the proper cutting height according to the
type and condition of the grass.
To raise the blade height
1. Grasp the height-adjustment lever, and move it outwards.
2. Move the lever toward the back of the mower and engage
the lever in the desired cutting-height position on the
mower deck.
To lower the blade height
1. Grasp the height adjustment lever, and move it outwards.
2. Move the lever toward the front of the mower and engage
the lever in the desired cutting-height position on the
mower deck.
8a
Groove
8b
Step1
9
Step2
Height-Adjustment Lever
2
1
