Hessaire MC37 User manual

Mobile Evaporative Cooler
Use & Care Guide
MC37 / MC61
INDEX
Safety Rules..............…1
Quick Start............….…2
Features........................3
Maintenance.........….....4
Cooler Parts........……...5
Warranty.............……...6
Trouble Shooting……....7

Safety
Key Operational Points
Your cooler must be positioned in front of an
open window ordoor if it isto operate effectively.
(see below picture)
1. Always ensure that there is another open
window or door through which the air can
exhaust from the room.
2. Ensure the rigid media is kept clean
throughout the use of your cooler.
3. At the end of each day run your cooler on
FAN ONLY for 30 minutes to dry out the
rigid media.
4. Prior to putting your cooler away for
winter, always:
a. Drain the tank and wipe clean.
b. Clean the rigid media.
c. Reassemble and run on FAN
ONLY for 30 minutes to dry out the rigid
media.
Indoor Use
Safety Rules
1. Read and follow all instructions, cautions,
and warnings. Failure to do so could result in
personal injury, death or property damage.
2. Unit must be in the OFF position and
UNPLUGGED from power receptacle before
performing any maintenance.
3. Make sure the electrical power source
conforms to the requirement of the evaporative
cooler(s) as well as local codes.
4. To reduce the risk of fire or electrical shock,
do not expose electrical connections to water.
5. Do not touch electrically live components.
6. Assure that all power cords do not meet any
sharp edges, hot surfaces or chemicals.
Immediately replace any damaged parts.
CAUTION: BEFORE CLEANING OR SERVICING DISCONNECT POWER SUPPLY

Quick Start
After unpacking your evaporative cooler, carefully inspect for any damage that may have occurred
during transit. Inspect for loose, missing or damaged parts.
Contents: Evaporative cooler (1), Hardware Bag (1), Casters (4)
Tools / Materials Needed: Drill with #2 Phillip’s bit or Phillip’s head screwdriver
A
B
C
D
Lay the cooler
down
Unscrew the two
screws, remove
the bottom panel
Taks out: Casters x4
Screws x16
Garden Hose adaptor x1
Install 4 Casters
1Install Casters and Front caster with lock
4 Fill cooler by
using bucket or hose
5 Turn the cooler
On and ENJOY
3 Connect to any
power supply
2 Install Garden
hose adapter

Features
MC37V / MC61V –Models Control Panel
Switch for Fan
Has 4 positions. (Clockwise from OFF)
OFF, LOW, MED, HI.
Switch for Pump - Controls the pump
Switch for Swing - Controls the fan oscillation
MC37M / MC61M –Models Control Panel
Rotary Switch for Fan
Has 4 positions. (Clockwise from OFF)
OFF, LOW, MED, HI.
Rocker Switch for Pump
Controls the pump
Rocker Switch for Swing
Controls the fan Oscillation
Rocker Switch for POWER
Main power control. When the power is turned
to the “OFF” position, the other controls will not
work.
Hose Adapter
Our convenient hose adapter allows you to have
continuous water fill on your cooler.
Air Intake
These coolers have 3 media panels instead of a
single panel found on most mobile coolers. 3
panels allow more air-intake area and reduce
pre-rotation of the air to the prop, which
translates into lower static pressure and more
efficient air delivery to the prop.

Cooler Maintenance
Cleaning Cooler and Rigid Media Pads
The removable panel and media pad can be
sprayed out on the ground to clean pad. Use
light pressure when spraying pads. You can use
a soft bristle brush to gently wipe away deposits.
NEVER spray pads with water while cooler is
operating, and fan is running. This can cause
damage to motor and will void the warranty.
Removal of the Back Panel (Disconnect power
supply before this procedure.)
Removal and Replacement of Cooling Media
1. If your cooler includes media pins,
remove by unscrewing/pulling out the
disc.
2. Remove media pad. Replace with new
pad.
3. Reinstall the back panel and you are
ready to use the cooler again.
Go to www.hessaire.com for replacement
videos and tips for eliminating any odor.
Draining the Cooler Tank
1. Pull or unscrew drain plug/cap from drain
assembly.
2. Tip unit to ensure all water exits the unit.
3. Replace drain plug.
Use all precautions and
disconnect from power source
before performing any
maintenance.

Cooler Parts
Please visit www.hessaireparts.com to shop for cooler parts.
#
Parts
MC37
MC61
1
Pump
6036050
6060050
2
Motor
6037051
6061051
3
Rigid Media Set
6036053
6060053
4
Control for V model
6038069
6038069
Control for M model
6037069
6037069
5
Casters
6036061
6060061
6
Casters w/lock
6036062
6060062
7
Fan Blade
6037052
6061052
8
Float Valve
6018058
6018058
9
Hose Adapter
6018088
6018088
10
Water Level Float
6037059
6037059
11
Oscillator Motor
6037057
6037057
12
Water Fill Door
6037076
6037076
13
Drain Plug
6017081
6017081

Warranty Policy
Hessaire Products Inc. Manufacturing
Warranty
EVAPORATIVE COOLER
Each new cooler is warrantied to be free from
defects in material or workmanship for one full
year from the date of original purchase. If a
component is found to be defective in this one-
year period, it will be repaired or replaced with a
new or refurbished product at the option of the
factory.
What is not covered by the warranty
1. Malfunctions resulting from misuse,
negligence, alteration or lack of necessary
maintenance.
2. Loss of time, inconvenience, use of product
or other consequential damages due to defects.
3. Return transportation costs. All return
transportation costs are the responsibility of the
purchaser.
4. We do not provide maintenance personnel.
Damaged Shipments
Hessaire is not responsible for damaged
shipments or shortages resulting from carrier
mishandling. Notify your carrier’s office
immediately to file a claim. Keep damaged
goods and containers for inspection until
advised by the carrier as to disposal.
Returns
All items must be returned with all original parts
and packaging. Additional charges may apply
for any missing or damaged parts.
The customer must re-package and ship their
item(s) back to the manufacturer at their own
expense.
No freight cost/shipping cost will be re-funded to
the customer.
The customer needs to provide us with the
tracking number of the shipment.
Upon receipt of the product, including original
parts and packaging, we may issue a full refund
for the product or may repair or replace the item
with a new or refurbished product.
If our returns department finds that the item is
not defective, you may be responsible for
additional shipping costs as well as a 10-30%
re-stocking fee.

Trouble Shooting
*** - See instructional videos for repairs and replacements at www.hessaire.com under the Media tab
Problem
Cause/Remedy
1. Cooler fails to work at all
1.1 Check that the unit is plugged properly.
1.2 Check the POWER switch, push it to "ON".
1.3 The TIMER switch is "OFF", turn it to "ON".
1.4 Make sure cooler is not plugged into a tripped GFIC outlet. If so,
reset GFCI or move to non GFCI outlet.
2. Cooler does not pump
2.1 Pump is not activated. Push the PUMP switch to "ON".
2.2 Water level is low. Fill with water and make sure pump is
activated.
2.3 Be sure the pump and pump hose are clear of debris.
2.4 Pump may be defective. Replace pump. ***
3a. Fan does not operate
3.1 Check that unit is plugged properly.
3.2 Check the POWER switch, push it to "ON".
3.3 If connected to a GFCI outlet, check if it is tripped.
3.4 Troubleshoot rotary switch.***
3b. Fan runs slowat start up
3b.1 Replace motor capacitor. ***
4. Louver does not operate
4.1 Louver does not move. Put swing switch position to "ON".
4.2 Check Oscillator motor for proper placement and operation.
5. Water leakage
5.1 Check the cap of the drain assembly, make sure it tightened.
5.2 Inspect tank for cracks or breakage.
5.3 Make sure cooler is level.
5.4 Check media pads for buildup allowing water out on outside of
pad frame -- change media if needed.
5.5 If water is coming out fan, check for leaks in water distribution
hoses and/or leaks at hose connections to spreaders,
5.6 Be sure there is at least 4 inches of space for rear panel free
from wall or other obstruction. This could make the side panels
release water to airstream due to increased air velocity through the
sides.
5.7 Spreaders may have scale buildup allowing water to pool and
spill over into airstream---Clean spreaders.
6. Float Valve
6.1 If water levels are too high/low, adjust the wing nut on the valve.
6.2 If there is a leak, check for cracks. Purchase new valve at
www.hessaireparts.com
