Hi-Lux Phenom UHD 20-60X85 Operating and maintenance manual

Phenom UHD 20-60X85
Spotting Scope
INSTRUCTIONAL MANUAL

Hi-Lux Optics Phenom UHD Spotting Scope
t
1 2
The Phenom UHD is a versatile 85mm
spotting scope that is perfect for
glassing for hours on end without
eye fatigue. The large field of view
and zoom range ensure that you are
excellently prepared for any situation.
The Phenom UHD Spotting scope
incorporates porro prisms, fully
multicoated Ultra High Definition
lenses and Extra Low Dispersion
Elements. All components are made to
the tightest possible tolerances, which
results in unparalleled sharpness and
comfortable viewing.
By coupling our 50 years experience
in manufacturing optics with our
commitment to quality and customer
service, we trust that the Leatherwood
Hi-Lux Optics Phenom UHD Spotting
Scope rewards you with years of
dependable service and impressive
optical quality.

Hi-Lux Optics Phenom UHD Spotting Scope
t
3 4
TABLE OF CONTENTS
SECTION 1. SPECIFICATIONS AND BASIC DEFINITIONS Page 4
SECTION 2. BASIC OPERATIONS Page 6
SECTION 3. ADJUSTING MAGNIFICATION Page 8
SECTION 4. ADJUSTING FOCUS Page 9
SECTION 5. ADJUSTING THE EYE CUP Page 10
SECTION 6. ADJUSTING THE VIEWING ANGLE Page 11
SECTION 7. USING THE EXTENDABLE SUNSHADE Page 12
SECTION 8. MAINTAINING YOUR SCOPE Page 13
SECTION 9. DIAMONDTUFF LIFETIME GUARANTEE Page 14
SECTION 1 - SPECIFICATIONS
Model Power Objective
Lens Diameter Eye Relief Exit Pupil Diameter
Angular Field
Of View
Linear Field
Of View
Shortest
Focus
Distance
Twilight
Factor
Phenom
UHD 20-60X 85mm 20mm- 18mm 4mm - 1.4mm 2° - 1° 104’ - 53’ 29’ 41 - 71
All air-glass surfaces are fully multi-coated using our Proprietary DiamondTuff14
to reduce glare and maximize the light transmission. The Phenom UHD 20-80X85
uses porro prisms and is argon purged to prevent internal fogging. Special ED
glass elements are used to eliminate color fringing.

Hi-Lux Optics Phenom UHD Spotting Scope
t
5 6
BASIC DEFINITIONS: SECTION 2: BASIC OPERATIONS
Attaching the Eyepiece
Before attaching the eyepiece, remove the lens cover on the bottom of the eyepiece. We recommend
that you keep the exterior lens covers handy to prevent foreign material from entering the lens.
1) To attach the eyepiece, line up the indicator mark near the base of the eyepiece with the
orange dot on the spotting scope body. Insert the eyepiece into the body and rotate the eyepiece
clockwise ¼ turn until the eyepiece clicks into place and is lined up with the indicator line.
2) To remove the eyepiece, press and hold the eyepiece lock down and rotate the eyepiece
¼ turn counter clockwise.

Hi-Lux Optics Phenom UHD Spotting Scope
t
7 8
Mounting the Spotting Scope
There are many variables that come into play when looking down range. Some of these factors
include mirage, wind, humidity among others. For best results when spotting, we recommend using a
tripod for steady viewing. Secure the tripod mount foot on a quick release plate on the tripod head.
The tripod mount foot has 1/4-20 threads and is compatible with any 1/4-20 thread screw mounting
plate.
SECTION 3: ADJUSTING MAGNIFICATION
The Phenom UHD 20-60X85 spotting scope has a 20-60X magnification range. At lower magnification
settings, the wider field of view is suitable for target identification. Higher magnifications are ideal
when you need to zoom in on the target to see detail.
Increase the magnification by turning the adjustment ring in a clockwise direction.
Decrease the magnification by turning the adjustment ring in a counterclockwise direction.

Hi-Lux Optics Phenom UHD Spotting Scope
t
9 10
SECTION 4: ADJUSTING FOCUS
After setting the magnification, you will need to refocus the spotting scope. This is due to changing
the focal distance of the spotting scope.
To adjust the focus, slowly rotate the center focus ring until the image becomes sharply defined.
SECTION 5: ADJUSTING THE EYECUP
The adjustable eyecup on the Phenom UHD spotting scope twists up and down so that you can
see the full field of view regardless if you wear glasses or not.
Fully extend the eyecup for the best viewing without glasses. Adjust the eyecup position by twisting
on the eyecup.

Hi-Lux Optics Phenom UHD Spotting Scope
t
11 12
SECTION 6: ADJUSTING THE VIEWING ANGLE
The Phenom UHD Tripod Mount Collar allows you to rotate the spotting scope body for greater
viewing flexibility. To rotate the body, first loosen the thumbscrew on the mounting collar. There
are detents located every 45 degrees.
Lock the scope body in your preferred viewing position by rotating the mounting collar
thumbscrew clockwise.
SECTION 7: USING THE EXTENDABLE SUNSHADE
Extendable Sunshade
Extend this fitted hood to effectively block out disturbing stray light. The sunshade also shields
the objective lens from mechanical damage and guards against soiling by fingerprints and
precipitation.

Hi-Lux Optics Phenom UHD Spotting Scope
t
13 14
SECTION 8: MAINTAINING YOUR SCOPE
This sight, though amazingly tough, is a precision instrument that deserves reasonable and cautious
care. For normal maintenance:
A. Do not attempt to disassemble or clean the sight internally.
B. The external optical lenses should occasionally be wiped with the microfiber lens cloth
provided or optical quality lens paper.
C. Remove any external dirt or sand with a soft brush so as to avoid scratching the finish.
D. Wipe the sight with a damp cloth, followed by a dry cloth.
E. Then go over the metal portions of the sight with a silicon treated cloth in order to protect
the sight against corrosion.
F. Store the sight in a moisture-free environment.
G. Avoid storing the sight in a hot place, such as the passenger compartments of a vehicle
on hot days. The high temperatures could adversely affect the lubricants and sealants.
H. Never leave the sight where direct sunlight can enter either the objective or the eyepiece
lens. Damage may result from the concentration of the sun’s rays (burning glass effect).
WARNING: UNNECESSARY RUBBING OR USE OF A COARSE CLOTH MAY CAUSE PERMANENT
DAMAGE TO LENS COATINGS.
SECTION 9: DIAMONDTUFF GUARANTEE
Hi-Lux, Inc. warranties its products against defects arising from faulty workmanship, or materials,
for the lifetime of the product. Normal wear and tear is not covered under this warranty policy.
Any attempt to alter, dismantle or change the standard specifications of the products, will make
this warranty null and void.
This warranty is made to the original purchaser of the goods including all international sales,
and applies only to the products purchased through our authorized distributors or dealers. The
international warranty is subject to approval from our authorized distributor or us directly. The
warranty is transferable.
Warranty obligation is limited to the repair or replacement of any product returned to Hi-Lux,

Hi-Lux Optics Phenom UHD Spotting Scope
t
15 16
Inc. that is determined by the manufacturer to have defects arising from faulty workmanship or
materials that adversely affect the satisfactory operation of the product. It should be noted that on
items containing an etched glass reticle, that the occasional appearance of some small particles is
common and not a warrantable repair. Hi-Lux, Inc. offers a two-year warranty for the electronic
components that are contained on the products.
Hi-Lux, Inc. reserves the right to request proof of purchase and purchase date. To guarantee warranty
service, the enclosed warranty form must be completed and returned within ninety (90) days of
purchase to establish all warranty rights between you, the original purchaser, and Hi-Lux, Inc.
We assume no liability for any incidental or consequential damages, or incidental expenses. Some
states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusion may not apply to you.
No warranties are made, or are authorized to be made, other than those expressly contained herein.
To file a claim under this warranty, please contact the Customer Service Department of Hi-Lux, Inc.
at [phone] to obtain a Return Authorization number (RA number). After receiving your RA
number, please mark the number on the outside of the package; enclose the defective item with a
brief explanation of the problem. Please be sure to include your name, address and phone number.
Failure to obtain a RA number may result in either refusal upon delivery, or lengthy delays for
warranty repairs and service required for the item returned to us.
All scopes are to be shipped prepaid direct to Hi-Lux, Inc. and must include a check or money
order in the amount of $21 to cover return postage and handling, regardless of purchase date.
Attention: Warranty & Service Department
Hi-Lux, Inc.
3135 Kashiwa Street
Torrance, CA 90505
Tel: [phone]
Fax: [phone]
E-Mail: [email protected]
www.hi-luxoptics.com
In the event of a non-warranty repair, you will receive an estimate prior to any work being done. This
warranty gives you specific legal rights and you may have other rights, which vary from state to state.

For the Latest Hi-Lux Videos and Tutorials
www.hi-luxoptics.com
