HIK VISION DS-2CD802P (N)-IR5 User manual

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
1
DS-2CD802P (N)-IR5 Analog Camera
Technical Manual

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2010 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
[e-mail]
Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
3
Contents
1. Key Features
2. Specifications
3. Dimension

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
4
1.Key Features
High Performance Sony CCD
Linux OS Embedded
TI DaVinci Hardware Compression
H.264 or MPEG-4 Video Compression
1 Channel Audio Compression
Support 4CIF / DCIF / 2CIF / CIF / QCIF Real Time Compression
Support Dual Stream Compression
Support Motion Detection, and Notification on PC Client
Support both Variable Bit Rate and Variable Frame Rate
Support TCP / IP, HTTP, DHCP, DNS, RTP / RTCP, PPPoE, etc.
Support IE for Network Preview
Support Sensor Alarm Input and Relay Output
Support Network Intercom Function
Compatible with Current HIKVISION DVR / DVS SDK and Client Software
Min. Illumination: 0.1Lux @ F1.2 (0 Lux with IR)

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
5
2.Specifications
Model
Parameter DS-2CD802P (N)- IR5
Camera
Image Sensor 1/3 inch SONY Super HAD CCD
Effective Pixels PAL:500(H) × 582 (V)
NTSC:510 (H) × 492 (V)
Lens Mount M12×0.5
Signal System PAL / NTSC
Electronic Shutter 1/50 (1/60)S ~ 1/50~1/100,000S
Min. Illumination 0.1Lux @ F1.2 (0 Lux With IR)
Lens 16mm (3.6mm, 6mm, 8mm,12mm optional)
S/N Ratio More than 48dB
Video Output 420 TVL,1Vpp Composite Output (75Ω/BNC)
Compression Standard
Video Compression H.264 or MPEG-4
Video Output 32 K ~ 2M, adjustable (8Mbps maximum)
Audio Compression OggVorbis
Image Resolution PAL: 704 × 576, 528 × 384, 704 × 288, 352 × 288, 176 × 144
NTSC: 704 × 480, 528 × 320, 704 × 240, 352 × 240, 176 × 120
Frame Rate 25 fps (704 × 576), 30fps (704 × 480)
Function
Motion Detect Support
Dual Stream Support
Heartbeat Support
Password Protect Support
Protocols TCP / IP,HTTP,DHCP,DNS,RTP / RTCP, PPPoE (FTP,SMTP,NTP,SNMP addible)
Infrared Distance series: approx 50 to 60 meters
Interface
Audio Input 1 channel (2.0 ~ 2.4Vp-p, 1kΩ)
Audio Output 1 channel (Line level, 600Ω)
Communication 1 RJ45 10M / 100M self-adapted Ethernet port and one RS-485 interface
Alarm Input 1 channel signal input
Alarm Output 1 channel relay output
Others
Working -10℃~ 60℃

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
6
Temperature
Weather Proof IP66
Power Supply 12VDC, ±10%
Power Consumption 9W MAX
Dimensions(mm) 86.5 × 83 × 228 (3.43” × 3.29” × 9.04”)
Weight 1400g (3.04lbs)

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
7
3.Dimension
