Hiwin DMS Series User manual

Assembly instructions
Rotary tables DMS and DMN
TM-02-4-EN-2202-MA
www.hiwin.de

Assembly instructions Imprint
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 2of 32
Imprint
HIWIN GmbH
Brücklesbünd 1
D-77654 Offenburg, Germany
Phone [phone]
Fax [phone]
[email protected]
www.hiwin.de
All rights reserved.
Reprinting, even in part, is not permitted without our approval.
These assembly instructions are protected by copyright. Written permission is required from
HIWIN GmbH for any duplication, publication in whole or in part, alterations or abridgement.

Assembly instructions Contents
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 3of 32
Contents
1General information ............................................................. 5
1.1 About these assembly instructions................................................ 5
1.2 Presentation and layout conventions used in these assembly instructions ............ 5
1.3 Warranty and liability ............................................................ 6
1.4 Manufacturer information ........................................................ 7
1.5 Product monitoring .............................................................. 7
2Basic safety information......................................................... 8
2.1 Proper use...................................................................... 8
2.2 Reasonably foreseeable misuse .................................................. 8
2.3 Conversions or modifications..................................................... 8
2.4 Residual risks ................................................................... 8
2.5 Requirements for personnel ...................................................... 9
2.6 Safety equipment ............................................................... 9
2.7 Markings on the rotary tables..................................................... 9
3Description of rotary table ...................................................... 10
3.1 Application .................................................................... 10
3.2 Main components of the rotary table (example DMS3x) ............................ 10
3.3 Functional description .......................................................... 10
3.4 Versions....................................................................... 11
3.5 Protective plate (option) ........................................................ 11
3.6 Parking brake (option) .......................................................... 12
4Transport and setup ............................................................ 14
4.1 Delivery DMS, DMN ............................................................. 14
4.2 Transport to the installation location ............................................. 14
4.3 Installation location requirements................................................ 14
4.4 Storage ....................................................................... 14
4.5 Unpacking and setup ........................................................... 15
5Assembly and connection....................................................... 16
5.1 Assembly of rotary tables ....................................................... 16
5.2 Mounting the moving load....................................................... 16
5.3 Electrical connection ........................................................... 17
6Commissioning ................................................................ 24
6.1 Switching on rotary table........................................................ 24
6.2 Programming .................................................................. 24
7Maintenance and cleaning ...................................................... 25
7.1 Maintenance................................................................... 25
7.2 Cleaning....................................................................... 26
8Faults ......................................................................... 27
8.1 Motor faults ................................................................... 27
8.2 Operating faults with a servo drive ............................................... 27
9Disposal....................................................................... 28
10 Appendix 1: Order codes........................................................ 29
10.1 Order code DMS................................................................ 29
10.2 Order code DMN ............................................................... 29

Assembly instructions Contents
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 4of 32
11 Installation certificate .......................................................... 30

General information
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 5of 32
1General information
1.1 About these assembly instructions
1.1.1 Requirements
We assume that
The operating personnel have been instructed in the safe operation of the rotary tables and
have read and understood these assembly instructions in full
Maintenance personnel maintain and repair the rotary tables in such a way that they present
no danger to persons, the environment or property
1.1.2 Availability
Ensure that these assembly instructions are available at all times to persons working on or with
the rotary tables.
1.2 Presentation and layout conventions used in these assembly
instructions
1.2.1 Instructions for actions
Instructions for actions are provided in sequential order and identified with a triangle symbol.
The results of the actions are accompanied by a tick symbol.
Example:
Position the rotary table on the mounting holes.
Insert mounting bolts into mounting holes and tighten in spiral sequence with a torque of 10
Nm.
The rotary table is mounted.
1.2.2 Lists
Lists are identified through the use of bullet points.
Example:
Rotary tables must not be operated: Outdoors
In areas where there is a risk of explosion
…

General information
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 6of 32
1.2.3 Presentation of safety information
Safety information is always indicated by a signal word and sometimes with a hazard-specific
symbol (see section 1.2.4 Symbols used).
The following signal words/hazard levels are used:
Danger! Immediate danger!
Failure to follow this safety instruction will result in severe or fatal injury!
Warning! Potentially dangerous situation!
Failure to follow this safety instruction could result in severe or fatal injury!
Attention! Potentially dangerous situation!
Failure to follow this safety instruction could result in moderately severe or minor injury!
Caution! Potentially dangerous situation!
Failure to follow this safety instruction could result in damage to property or the environment!
1.2.4 Symbols used
The following symbols are used in these assembly instructions and on the rotary tables:
Warning symbols
Warning of electric
shocks!
Warning of hot surfaces!
Environmentally
hazardous substance!
Instruction symbols
Wear safety gloves!
Disconnect before
maintenance or repair
work.
1.2.5 Information
Note:
Provides general information and recommendations.
1.3 Warranty and liability
The manufacturer's "General Terms and Conditions of Sale and Delivery" apply.

General information
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 7of 32
1.4 Manufacturer information
Address HIWIN GmbH
Brücklesbünd 1
77654 Offenburg, Germany
Telephone +49 (0) 781 / 9 32 78 - 0
Technical customer service team +49 (0) 781 / 9 32 78 - 77
Fax +49 (0) 781 / 9 32 78 - 90
Technical customer service team fax +49 (0) 781 / 9 32 78 - 97
E-mail [e-mail]
Internet www.hiwin.de
1.5 Product monitoring
Please inform HIWIN, as the manufacturer of the rotary tables, about:
Accidents
Possible sources of danger at the rotary tables
Any unclear information in these assembly instructions

Basic safety information
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 8of 32
2Basic safety information
Note:
There are no magnetic fields in the vicinity of complete rotary tables.
Note:
With IP65 version according to DIN 40050/IEC 529/VDE 0470/EN 60529:
Ensure that the materials used are chemically resistant to the ambient atmosphere/liquid:
Housing:
Anodised aluminium; with DMS3 and DMS7 partly carbon
Plug material:
Brass, nickel
-plated
Screws:
Stainless steel
Seals:
NBR (sealing lip)
Protective plate:
Stainless steel
2.1 Proper use
The rotary table is a rotating drive and guide system for the exact, time-controlled positioning of
permanently mounted loads, such as system components, in an automated system.
Rotary tables are designed for installation and operation in any position, but do not have a
parking brake. The loads to be moved must be fixed into position on the rotor.
The rotary tables must not be used outdoors or in hazardous areas where there is a risk of
explosions. Rotary tables may only be used as described for the intended purpose.
Rotary tables may only be operated within their specified performance limits (see “Rotary
tables” catalogue).
The assembly instructions and the maintenance and servicing instructions must be
complied to ensure the intended use of the rotary tables.
Any other use of the rotary tables is considered improper use.
Only original spare parts from HIWIN GmbH may be used.
2.2 Reasonably foreseeable misuse
Rotary tables must not be operated:
Outdoors
In areas where there is a risk of explosion
2.3 Conversions or modifications
Conversions or modifications to the rotary tables are not permitted!
2.4 Residual risks
No residual risks emanate from the rotary tables during normal operation. Dangers that may
arise during maintenance and servicing are specified in the respective chapters.

Basic safety information
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 9of 32
2.5 Requirements for personnel
Only authorised and competent persons may carry out work on the rotary tables! They must be
familiar with the safety equipment and regulations before they start work (see following table).
Activity Qualifications
Normal operation Instructed personnel
Cleaning Instructed personnel
Maintenance Qualified personnel of the operator or manufacturer
Servicing Qualified personnel of the operator or manufacturer
2.6 Safety equipment
2.6.1 Personal protective equipment
Table 2.1: Personal protective equipment
Operating phase Personal protective equipment
Normal operation The following personal protective equipment is required when standing or
working near the rotary tables:

Safety shoes
Cleaning The following personal protective equipment is necessary when cleaning the
rotary table:

Safety shoes
Servicing and
maintenance
The following personal protective equipment is necessary during maintenance
and servicing:

Safety shoes
2.7 Markings on the rotary tables
2.7.1 Type plate
Fig. 2.1: Type plate (example)

Description of rotary table
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 10 of 32
3Description of rotary table
3.1 Application
The rotary table is a rotating drive and guide system for the exact, time-controlled positioning of
permanently mounted loads, such as system components, in an automated system.
Rotary tables are designed for installation and operation in any position, but do not have a
parking brake. The loads to be moved must be fixed into position on the rotor.
3.2 Main components of the rotary table (example DMS3x)
Fig. 3.1: Main components of a rotary table
Table 3.1: Main parts of a rotary table
1 Hollow shaft 6 Encoder 11 Carrier for encoder
2 Upper housing cover (rotor) 7 Stator 12 Raster disc
3 Upper housing ring (stator) 8 Receptacle 13 Support for raster disc
4 Crossed roller bearings 9 Seal 14 Motor housing
5 Rotor 10 Lower housing cover 15 Seal
3.3 Functional description
The rotary table is driven by a 3-phase, permanently excited torque motor. The integrated
bearing absorbs loads and torques and transfers them to the machine bed. The integrated
distance measuring system provides a standardised sin/cos-1 VSS output signal. The rotary
table is operated with a suitable servo drive.

Description of rotary table
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 11 of 32
3.4 Versions
3.4.1 DMS
Key features:

Backlash-free and extremely dynamic

Brushless and high torque

Integrated optical encoder
Typical applications:

Automation technology

Pick and Place
3.4.2 DMN
Key features:

Backlash-free and extremely dynamic

Brushless and high torque

Integrated optical encoder
Typical applications:

Automation technology

Pick and Place
For information on the torque motors suitable for the HIWIN rotary tables, please refer to the
“Torque motors DMR, TMRW” assembly instructions. These are available for download at
www.hiwin.de.
3.5 Protective plate (option)
The sealing of the torque rotary tables consists of a labyrinth and sealing lips inserted into it,
so-called V-seals. If the rotary table is exposed to abrasive liquids, such as in grinding
machines, then this liquid comes into contact with the sealing lips and can damage the sealing
lip and its drainage surface.
In order to achieve a sufficient service life of the sealing even when abrasive liquids are used, a
stainless steel protective plate is placed on the gap of the labyrinth. This protective plate
provides reliable protection against the ingress of liquids when the rotary table is mounted
horizontally.
Only in the case of overhead and wall mounting should the protective plate not be used, as it
would collect additional liquid and dirt particles in this position.
Note:
The outer diameter of the rotary table increases by 5 mm due to the protective plate.
Fig. 3.2: DMSX – version with optional protective plate

Description of rotary table
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 12 of 32
For overhead mounting and for wall mounting combined with abrasive liquids, HIWIN rotary
tables are supplied with a sealing air preparation.
For the additional sealing air, 5 of the radial M4 threads (see Fig. 3.3) are sealed with the
enclosed grub screws and the sealing air is connected through the 6th threaded hole. The
matching push-in fitting is enclosed.
Hose diameter: 4 mm
Air pressure: 0.2 to 0.5 bar
Fig. 3.3: DMS3X – M4 threaded holes
1 M4 threaded holes
3.6 Parking brake (option)
Note:
The parking brake (clamping element) is only used to clamp the stationary shaft in continuous
operation.
Note:
The parking brakes are mounted under the housing cover as standard. This changes the
dimensions of the rotary table.
Depending on the type, the rotary tables are equipped with a pneumatic parking brake. The
brakes used are emergency-activated, i.e. they are activated without pressure. Parking brakes
are currently available for the DMS3 series and DMS7 series.
Fig. 3.4: DMS3, view from below on the clamping – view from the front (left) and from the back
(right)
1 Parking brake
2 Rear pneumatic connection
3 Front pneumatic connection

Description of rotary table
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 13 of 32
3.6.1 Holding torques
If no supplementary air is connected, the rear valve (“Close”) must remain open.
The holding torques are given in Table 3.2. Without application of air, the parking brakes are
closed. The holding torque can be increased by adding air to the rear valve ("Close"), see Fig.
3.5.
Table 3.2: Holding torques of the pneumatic parking brake
Rotary table DMS3x DMS7x
Opened at nominal pressure 6 bar 4 bar 6 bar 4 bar
Holding torque without additional air 114 Nm 114 Nm 336 Nm 336 Nm
Holding torque with additional air 210 Nm 140 Nm 600 Nm 400 Nm
3.6.2 Connection
Note:
To minimise reaction time, the valves should be placed as close as possible to the parking
brake. In addition, quick exhaust valves can shorten the reaction time.
The parking brake must be controlled with a 3/2 or 5/2-way valve, as shown in Fig. 3.5. The
valves must have a minimum nominal size of G 1/8. The hose connection must not fall below a
minimum diameter of 6 mm.
Fig. 3.5: Pneumatic connection of the parking brake
3.6.3 Commissioning
The function of the parking brake is checked by HIWIN before delivery. Before commissioning
the rotary table, it must nevertheless be checked to ensure that
The parking brake is open (check by turning the shaft manually)
There is no dirt (oil or grease, small solids) between the clamping surfaces

Transport and setup
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 14 of 32
4Transport and setup
4.1 Delivery DMS, DMN
4.1.1 Delivery condition
The rotary table is delivered fully assembled, functionally tested and ready for connection.
4.1.2 Scope of delivery
For scope of delivery, see contract documentation.
4.2 Transport to the installation location
Caution! Damage to the rotary table!
The rotary table can be damaged by mechanical stress.
Do not transport any additional loads on the rotary table during transport!
Secure the rotary table against tipping!
Transport the rotary table to the installation site using suitable lifting gear (for weights, see
the "Rotary tables" catalogue).
Ensure even load distribution when lifting.
4.3 Installation location requirements
4.3.1 Environmental conditions
Ambient tempera
ture
+ 5 °C to + 40 °C
Installation site
Level, dry, vibration
-free
Atmosphere
Non
-corrosive, non-explosive
4.3.2 Safety equipment to be provided by the operator
Possible safety equipment/measures:
Personal protective equipment according to UVV
Electrosensitive protective equipment
Mechanical safety equipment
4.4 Storage
Store the rotary table in the transport packaging.
Do not store the rotary table in an explosive atmosphere or in an environment contaminated
with chemicals.
Store rotary tables only in dry, frost-free rooms with a non-corrosive atmosphere.
Make sure that the rotary tables are not exposed to vibrations or impacts during storage.
Clean and protect used rotary tables before storage.
The ambient temperature when storing the motors is between +5 and +70 °C.

Transport and setup
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 15 of 32
4.5 Unpacking and setup
Caution! Damage to the rotary tables!
Rotary tables can be damaged by mechanical stress.
Do not transport any additional loads on the rotary tables during transport!
Secure rotary tables against tipping!
Note:
The rotary tables must be set up and operated indoors only.
Remove protective film.
Carefully transport rotary table to the intended installation site.
Ensure that the maintenance points are freely accessible.
Dispose of packaging in an environmentally-safe manner.

Assembly and connection
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 16 of 32
5Assembly and connection
Danger! Danger due to electrical voltage!
Dangerous currents may flow before and during assembly, disassembly and repair work.
Work may only be carried out by qualified electricians when the device is de-energised!
Before working, disconnect the linear motor system from the power supply and secure
them against being switched on again!
Danger! Danger due to electrical voltage!
Electrical superstructures are not safely earthed via the rotary table.
Secure electrical superstructures via separate earthing!
Warning! Danger from heavy loads!
Lifting heavy loads can cause damage to health.
Use appropriately dimensioned lifting equipment for positioning heavy loads!
Comply with the applicable industrial safety regulations for handling suspended loads.
Caution! Damage to the rotary tables!
Rotary tables with protection class IP40 can be damaged by liquids.
Clean rotary tables only with a damp cloth!
Note:
Assembly of the rotary tables only by qualified personnel.
5.1 Assembly of rotary tables
Note:
The rotary table is attached from below as standard.
Drill the mounting holes on the mounting surface according to the dimensional drawing (see
"Rotary tables" catalogue).
Clean the mounting surface.
Position the rotary table on the mounting holes.
Insert the mounting bolts into the mounting holes and tighten them crosswise while
observing the permissible torque.
The rotary table is mounted.
5.2 Mounting the moving load
Clean the mounting surface for the load on the rotary table.
Clean the mounting surface on the load.
Position the load on the rotary table.
Insert the mounting bolts and tighten them crosswise while observing the permissible
torque.
Manually check the freedom of movement of the load over the entire travel angle.
Moving load is mounted.

Assembly and connection
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 17 of 32
5.3 Electrical connection
Danger! Danger due to electrical voltage!
If the rotary table motor is not properly earthed, there is a risk of electric shock.
Make sure that the electrical power supply of the rotary table is properly earthed before
connecting it!
Danger! Danger due to electrical voltage!
Electrical currents can also flow when the motor is not moving.
Make sure that the rotary table is disconnected from the power supply before
disconnecting the electrical connections of the motors!
After disconnecting the servo drive from the power supply, wait at least 5 minutes before
touching live parts or loosening connections!
To be on the safe side, measure the voltage in the intermediate circuit of the servo drive
until it has fallen below 40 V.
Note:
Observe the separate assembly instructions for the servo drive!
5.3.1 Direction of rotation
If the motor cable is connected according to Table 5.1, the direction of rotation of the rotor is
clockwise (view to the output shaft)
Fig. 5.1: Illustration of the direction of rotation of the rotary table
L1 = U, L2 = V, L3 = W
1 Motor connector
2 Encoder plug

Assembly and connection
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 18 of 32
5.3.2 Motor connection
Note:
Maximum length of the supply cable 10 m.
Suitable filters against voltage peaks must be used for longer cables.
Fig. 5.2: Motor connection DMS, DMN
1 Motor connector
2 Encoder plug
Brushless 3-phase synchronous motors
Connection via motor plug (round plug M17, 7-pin)
Motor plug up to max. 630 VAC
Motors are designed for intermediate circuit voltage up to 600 VDC
Suitable for servo drives up to 3 × 400 VAC
Fig. 5.3: PIN assignment of rotary table round plug
Table 5.1: Pin assignment of rotary table
PIN no. Signal Function Colour of motor
extension cable
1 U Motor phase Black-1
4 V Motor phase Black-2
3 W Motor phase Black-3
5 T+ Thermal protection
contact
Red
6 T– Thermal protection
contact
Yellow
2 Not assigned
Protective earth/ground GND Green/yellow

Assembly and connection
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 19 of 32
5.3.3 Distance measurement
All rotary tables have a position encoder with output signal sin/cos 1 VSS with an index as
standard. The position of the index is marked on the housing (see Fig. 5.4).
Fig. 5.4: Index marker for position encoder
H1 = marking of the 0° position ± 15°
5.3.4 Incremental encoder connection
Fig. 5.5: Encoder connection DMS, DMN
1 Motor connector
2 Encoder plug
Ready-to-operate encoder installed
Connection via round plug M17, 17-pin
Encoder is an optical incremental measuring system with sin/cos-1 VSS output signal

Assembly and connection
Rotary tables DMS and DMN TM-02-4-EN-2202-MA Page 20 of 32
Fig. 5.6: PIN assignment of distance measuring system round plug
Table 5.2: PIN assignment of distance measuring system
Round plug connector PIN no. Output signals of the distance
measuring system
Colour of encoder line
1 V 1- Green
9 V 1+ Yellow
4 Power supply 5 VDC Red (0.5 mm2)
2 V 2- Black
12 GND Black (0.5 mm2)
11 V 0-/Ref- Red
3 V 0+/Ref+ Orange
10 V 2+ Brown
15 Inner shielding Inner shielding
Plug connector housing Outer shielding Outer shielding
Note:
With motor connection according to Table 5.1 and encoder connection according to Table 5.2,
the rotary tables of the DMS series have a positive counting direction with positive direction of
rotation, the rotary tables of the DMN series have a negative counting direction.
5.3.5 Absolute encoder connection
Ready-to-operate encoder installed
Connection via round plug M17, 17-pin
Encoder is an optical absolute measuring system with sin/cos-1 VSS output signal and
EnDat 2.1 interface
With rotary tables DMS3x-Axxx and DMS7x-Axxx, the encoder has 2048 lines and 13 bit data
width (= 8192 increments, corresponding to 156 arcsec resolution).
Fig. 5.7: PIN assignment of distance measuring system round plug
