HKC 7" Capacitive Multi-Touch Tablet User manual

7” Capacitive
Multi-Touch Tablet
Instruction Manual

I
Instruction Manual
2
HKC brings you the latest in Android™ technology,
giving you the performance you want at an affordable
price. The crystal clear 7” capacitive touch screen is
great for watching movies, reading books, surfing the
web, video conferencing online and more. With
Google Play you can take advantage of more than
600,000 apps and games, as well as the world's largest
collection of eBooks, millions of songs, thousands of
movies, TV shows and magazines. Designed to
enhance your entertainment experience at home or
on the go and with up to 9 colors to choose from, you
can enjoy your technology in style! Welcome to
HKC…

I
Instruction Manual
3
Technical Specifications:
• Android 4.0 OS (Ice Cream Sandwich)
• 7” Capacitive multi-touch screen, 800 x 480
resolution, 16:9 aspect ratio
• 1GHZ processor with 1 GB system memory
• 8GB onboard storage memory, up to 32GB
additional memory via micro SD card slot
• Front facing webcam with microphone
• Built-in Wi-Fi
• Micro USB port
• Pre-loaded with Google™ applications including
Google Play™, Gmail™, Google Maps™, YouTube™
and more…
• Up to 5 hours of battery life
• Weights 0.5 lbs; 4.75" x 7.55" x 0.375" dimensions
What's in the Box:
• HKC tablet
• instruction manual
•in ear headphones
• AC charger
• micro USB cable

I
Instruction Manual
4
Switch on/Unlock:
Switch On and unlock: when the device is in the OFF mode, press
and hold “Power” key for 3 seconds to enter the Android startup
progress bar, it need about 100seconds enter to the system
desktop, the LCD is under locked mode, please press and pull the
icon to no glee point, then the LCD will unlock automatically.
Power Save Modes/Lock screen/Switch OFF:
Press the “POWER” key shortly after starting up, system will enter
to SLEEP power save and lock screen mode. Press the “POWER” key
or tap the touch screen. For example: playing music, movie, etc.
Switch OFF: when the device is in the OFF mode, press and hold the
“POWER” key for 3 seconds, the screen will display the power off
interface, choose the power off option to confirm, the system will
shut down automatically.

I
Instruction Manual
5
【Note】When the device has low battery, it will alarm
continuously and shut down automatically if the device is not being
charged and the device cannot start up. Please check if the battery
is low, and try it again after the battery is charged.
Battery Management and Charging:
Charge the battery for about 4-5 hours to make sure the battery is
fully charged before the first time of use.
Insert the micro port of the battery adapter into DC slot on the
device, and connect the other side with the power socket. Then the
Power indicating lamp of the device will be in a high-lighted blue
color, the desktop icon of the battery will keep rolling, which
shows it is charging, please wait until the battery is fully charged,
and do not disconnect the power while charging. Once the
battery is fully charged, the indicating lamp will change into a dark
blue color, the icon on the desktop will stop rolling. When the
battery is exhausted completely, please charge at least one minute
before starting up.
【Note】In order to keep the battery working in best condition,
please pay attention as follows:
• Please do not charge the battery in high temperatures.
• Do not wait for the batter to be fully depleted before charging
again. Keep the battery charged as needed.
• In order to keep the battery in the best condition make sure to
charge once per two weeks if you do not use the device for a long
time.

I
Instruction Manual
6
Operation of the Function Icons:
Function Icon Definitions:
Icon
Function
Instruction
Icon
Function
Instruction
Back to Home
menu
Note when the
system finds new
devices
Show current
power status
Menu for function
block
back
Wifi /Ethernet
Connection status
menu
Remain your last
task
Product Keys:

I
Instruction Manual
7
Symbol
Name
Description
1
Volume Key
Press Left to Vol -
2
Volume Key
Press Right to Vol+
3
POWER Key
Press the button shortly to enter
sleeping/wake up mode, press for a few
seconds to switch ON/OFF
4
Earphone Slot
Stereo earpiece Jack
5
USB Slot
MINI 5Pin USB Port, connect to a pc
6
TF card Slot
TF card slot (Micro SD Card Slot)
7
HOST Slot
HOST Slot to make USB Connection
8
DC Socket
Connect with 5V DC charger
Wireless and Networks:
WIFI
Turn on the Wi-Fi setting: tap the module icon to enter into
the function menu list; press “setting” and enter into the setting
interface; press “wireless and network” to setup, just select the
Wi-Fi option as per below:

I
Instruction Manual
8
Set the Wi-Fi and connect to a network: press the “Wi-Fi setting to
enter into the Wi-Fi options, the system will find the Wifi names
available automatically. Please refer to the picture below, WIF
networks available for use will be shown on the right:
You can see the network connection status when you press the
network name. There will be a Wi-Fi icon “”. Showing the
level of Signal
VPN Virtual Private Network:
You can create virtual private networks (VPN) and connect to your
private network securely through a public network, such as the
internet. You must set a lock screen PIN or password before you
can use credential storage.
Add VPN network and follow the instructions on the screen.

I
Instruction Manual
9
USB Function:
Read USB-disk:
Insert the USB-disk into the Mini USB port and press the “explorer”
option in the desktop, maybe you will need an additional adapter
cable to connect between the USB and the device, press “USB” and
enter into USB-disk. You may see the image below:

I
Instruction Manual
10
Camera Function:
You can use camera to take videos, pictures or for video
conferencing functionalities.
Select the Camera Icon to use the functionality:
Desktop System:
(Multimedia Music/ Video/ Pictures/Record /E-book）
In the main menu or desktop, click the icon to play audio.
When no music files are the audio play list, the system will
automatically load the music files from the card to the audio player
play list after turning on the audio player (the device supports the
following audio file format: MP3, WAV, MIDI & WMA).

I
Instruction Manual
11
If two or more songs are in the music play list area, slide up/down
on the touch screen to go page up/down.
Double-click favorites in the list to play music as shown in the
following picture:

I
Instruction Manual
12
In the music playing interface, tap the “ “ button and then enter
the audio playing list.
Drag the playback progress bar to adjust
audio playback progress.
Note: audio player can play WAV recorded files/
Photos:
In the main menu or desktop, tap the picture browsing icon:

I
Instruction Manual
13
Photo Browser Button Descriptions:
Add Pictures (This device supports BMP, JPG, JPEG, PNG & GIF
formats). Open the corresponding folder, find the image file and
add the picture you want. Tap the photo setting button, and the
photo can be set as your wallpaper:
Explorer
In the main menu or desktop, tap the explorer icon to enter the
Management Interface, tap 【TF Card】then【Internal Memory】
and【USB】to open. Their root directory folders to copy, paste, add,
delete, remove and rename operation options, then tap previous /
next folder or A menu to finish then copy, delete, paste, remove
and rename to the correct directory.
To store additional files, you must insert a memory card. Your
device accepts micro SD™ or micro SDHC™ memory cards with
maximum capacities of 32 GB (depending on memory card
manufacturer and type).

I
Instruction Manual
14
Desktop System (Network Applications)

I
Instruction Manual
15
IE Browser
When the WiFi connection is in normal (for details refer to the
Wi-Fi Settings section), tap the main menu or desktop’s IE browser
icon to enter to the IE interface, click the address bar and input the
website and click “Go” to enter a corresponding website.
Note: the IE explorer uses the popular third-party IE explorer
software, please follow the IE explorer’s standard operating mode
to operate.
Email
When Wi-Fi connection is in normal (for details refer to the Wi-Fi
Settings section), tap the mail icon in main menu or desktop to
enter Email.

I
Instruction Manual
16
Desktop System (Other Functions)
Calculator:
Click the icon on the desktop to open the calculator
Voice and Display Settings:
Tap【Sound】to enter the settings interface:

I
Instruction Manual
17
Media Volume Settings：
Select 【media volume】to enter the settings interface, then to set
up music and video volume…
Set operating sound (screen choosing) and SD card notifications as
optional, tap and click till the display is highlighted.
Display Settings：

I
Instruction Manual
18
【Orientation 】The display screen will change the direction
automatically when rotating.
【Brightness】Drag to adjust the brightness, the tap “Ok” or
“cancel” to save the changes.
【Screen Timeout】Select after how many seconds will you like for
the screen to go into power saving mode.

I
Instruction Manual
19
Location and Security Settings:
Tap “Location and Security” to enter the setting interface:
Apps
Tap “Apps” to enter apps setting interface:

I
Instruction Manual
20
Running:
Tap “Running” to see and control the running service:
Language & input
Tap “language & input” to enter the settings interface:
