Holatek A2 User manual

Smart Projector
HOLATEK-A2
User Manual

HOLATEK Home Theatre Instructions Content
Safety Instructions
Operation Instructions
About Lamp
Other Instructions
Summary
Packaging List
Control Positions and Functions
Top/Front/Left
Bottom
Back
Control Panel
Remote Control Functions
Projection Image
Installation
Adjusting Projection Size
Projection Instructions
Basic Operations
Starting and Stopping the Machine
Turning on the Power
Turning off the Power
Selecting Language
Selecting Input Source
Adjusting Image
Correcting Keystone
Auto Correcting Keystone
Manual Correcting Keystone
3D Function
Turning on 3D
2D TO 3D
Switching 3D Left/Right Eye
Turning off 3D
Settings
User Maintenance
About Lamp
Indicator
Troubleshooting
Specification
Warranty and Copyright Information
Warranty Certificate (attached)

Safety Instructions
Thank you for using HOLATEK Product. Read carefully the following Safety
Instructions before using this product. Keep the User Manual after reading for future
reference.
Safety Symbol
The User Manual use graphical symbols in order to avoid injury to persons
or property. The definitions of graphical symbols are as follows:
Danger
This symbol indicates information that, if ignored, could
possibly result in personal injury or even death due to
incorrect handling.
Warning
This symbol indicates information that, if ignored, could
possibly result in potential personal injury or even death
due to incorrect handling.
Caution
This symbol indicates information that, if ignored, could
possibly result in potential personal injury or even death
due to incorrect handling.
Operation Instructions
Warning!
●Smoke, Unusual Smells, Hot and Others
If smoke, unusual smells, or any other abnormal occurs, stop using the
machine immediately. Continuing to use may result in fire or electric shock.
Take the measures immediately as follows:
1. Unplug the power plug from the outlet.
2. Contact your dealer or HOLATEK service center.
●Malfunctions
Abnormal images display or other abnormal situations occur under
circumstances of correct operations, stop using the machine
immediately. Continuing to use may result in fire or electric shock. Take
the measures immediately as follows:
1. Turn off the power。

2. Unplug the power plug.
3. Contact your dealer or HOLATEK service center.
●Power Cord
Misusing the power cord may cause the fire and electric shock. Take the
following precautions:
1. Use AC voltage and make sure outplace voltage is corresponding to the rated
voltage of the machine.
2. Do not overload the electrical outlet by using too many devices on
it.
Damaged power cord may cause the fire and electric shock. Take the
following precautions:
1. Do not place heavy objects on the power cord or heat the power cord.
2. Do not stick the power cord between the wall and machine’s table
shelf.
3. Never try to modify the power cord, damage or bend it excessively .
4. Never twist or pull the power cord.
Never touch the power cord or plug with
wet hand, which may cause electronic
shock.
Use the attached power cord in the country that you buy the machine. When using the
machine in other countries, always use the power cord corresponding to the power
standard of that country. Meanwhile notice the safety standard of the country.
●Water and Foreign Object
Do not spill the water on the machine. Fire and electric shock may
result.
Do not place vase or any other container with water on the top of the
machine. Fire and electric shock may result.
Getting water or other liquid, or foreign objects (metal) into
the machine may cause the fire and electric shock. If foreign objects
(metal) are got into the machine, follow the directions
immediately:
1. Turn off the power.
2. Unplug the power plug.
3. Contact your dealer or HOLATEK service center.

●Disassembling and Modifying
Do not disassemble or modify the machine in any way. The high
voltage parts in the machine may cause electric shock and scalding.
Notice that the malfunctions that caused by dismantling or modifying
the machines by yourself are not in the scope of warranty,
HOLATEK do not provide free repair.
Make sure refer all the internal checking, debugging and repair works to your dealer
or HOLATEK service center.
●Falling and Shocking
Continuing to use the damaged machine caused by falling or other
reasons may result in fire and electric shock. Take the measures
immediately as follows:
1. Turn off the power.
2. Unplug the power plug.
3. Contact your dealer or HOLATEK service center.
●Burning
Do not discard the machine by burning. Explosion, fire and
personal injury may result.
●Looking into the Lens or Air Vents When the Lamp is Switched on
Do not look into the lens or air vents when the lamp is switched
on. The hard light from the light machine may damage eyes.
●Blocking the air vents
Do not block the air inlet or outlet. Otherwise the internal heat
accumulates, which may cause the fire and burn the machine. Make
sure to observe the following precautions:
1. Leave the space at least 30 cm between the machine and the wall.
2. Do not place the machine in stagnant air place.
3. Do not cover the machine with the blanket or other objects.
4. Place the machine on the stable and flat surface. Do not use the machine
on the carpet, blanket, towel, cushion and any other soft surface.
5. Do not erect the machine when the machine is in process.
●Lightning
If there is a thunderstorm, do not touch the power plug.

●Remote Control
Never disassemble or modify the remote control in any way.
Otherwise cause electric shock, scalding and personal injury may result.
Make sure refer all the internal checking, debugging and repair works to
your dealer or HOLATEK service center.
Do not wet the remote control. Fire and electric shock may result.
●Wi-Fi Emitted from Radio Module
Never use the product in the airplane or medical facility, or any
other place that forbid the use of the device. Wi-Fi impacts the
electronic devices and medical devices, which may cause accident.
Do not use the product near high-precision electronic instruments or
electronic devices that used for dealing weak radio wave signal.
Wi-Fi impacts these devices, which may cause accident.
●If you are using cardiac pacemaker or any other electronic medical device,
consult the doctor or the product maker before using this product.
Caution!
●Power Cord
Misusing the power cord may cause the fire and electric shock. Always
follow the directions as follows:
1. Do not place the power cord close to the fire.
2. Hold the plug when disconnecting the power cord; do not pull the power
cord.
3. Plug into the bottom of the outlet.
4. Unplug the power cord from the outlet after using the machine.
5. Unplug the power cord from the outlet if the machine will not be used
for a long period.
6. Unplug the power cord from the outlet at least one time every year,
clean the dust of plug pins with dry cloths or vacuum cleaner.
7. Never use the detergent to clean the power cord, especially the plug pin and jack.
8. Before moving the machine, make sure to turn off the power and unplug the

power cord from the outlet.
●Important Data Backup
Backup all the data reserved in the machine memory. The data
reserved in the machine memory may be lost because of
malfunctions, repair and so on.
●Refraction Effects
No fish tank or any other object that has refracting effects in front of the lamp. Fire
may result.
●Lens
Do not touch the lens with hand.
Battery Instructions
Warning!
Misusing batteries may cause batteries fluid leakage and pollute the parts
around, which may cause an explosion, fire and personal injury. Make sure
to observe the following precautions:
zNever disassemble or short-circuit the batteries.
zNever place the batteries in high temperature or abundant in fire
zNever recharge the non-rechargeable batteries
Make sure the batteries are installed in the correct way
Caution!
Misusing batteries may cause batteries fluid leakage and pollute the parts
around, which may cause an explosion, fire and personal injury. Make sure
to observe the following precautions:
zOnly use the batteries specified with the remote control

●Exhausted Batteries
Take out the batteries as soon as they run out.
zTake out the batteries if the remote control will not be used for a long
period.
●Batteries Discarding
Discard the used batteries according to the local laws and rules.
Others
If the interior of the machine has not been cleaned for a long time, dust
may build up, which may cause fire and malfunctions. Contact the dealer
or HOLATEK service center one time every year for cleaning the interior of the
machine. Notice that this cleaning service is chargeable.
OperationInstructions
AboutLamp 
zThe lamp of this machine is LED.
zThe designed life of the lamp is about 20,000 hours. Practical life
differs from the using conditions, setups on the menu and lamps.
zWarranty duration of the lamp wrote in the warranty statement may
be 6,000 hours, take the first-reach duration as standard.
zLamp does not turn on or is obvious low brightness indicates the lamp
life ends. Contact your dealer or HOLATEK service center to change.
OtherInstructions
This machine consists of precision parts. Malfunctions and incorrect data
storing may result if not observing the following instructions.
●Do not use or store the machine in the following areas, otherwise may
cause the malfunctions and damages on the machine.
zStatic electricity areas
zExtremely high temperature areas

zHigh humidity areas
zAreas where temperature may change suddenly
zAreas where is a lot of dust
zShaky, slant or unstable areas
zAreas where may be got wet
●Do not use the machine in the following areas, otherwise may cause
the malfunctions and damages on the machine.
zExtreme temperature areas (The working temperature
is 5℃to 35℃)
zDo not place heavy objects on the machine
zDo not insert or fall the foreign objects into the machine
zDo not place vase or any other containers with water
on the top of the machine.
●Do not leave the exhausted batteries in the remote control for a long
time.
Exhausted batteries has fluid leakage ,which may cause the remote control
trouble or even damage.
●Use soft clean cloth for cleaning
If the machine is dirty, clean it with the soft cloth soaked in the water
or neutral detergent diluted solution. Wring the excess water before
cleaning. Never use thinner, benzene or any other volatile agents to clean
the machine. The printed word may be erased and may stain the machine.
●Screen Dot do not Light on
The machine use the most advantaged digital technology，however, some
dots on the screen may not light up. This is a normal phenomenon, not the
malfunctions.
●Do not shock on the machine when it is in process
If machine suffer fierce shock, the projected images may disappear for
a while. The images will appear soon, but could have abnormal color or
error messages.
If the machine image color is abnormal, reselect the source. If the color
is still abnormal, turn off the machine according to the steps in chapter
“Turn on and off the machine” on page 17, and then restart the machine.

●Cautions After Using
The outlet and its around is very hot when the machine is in process, and
is still very hot when the machine is just turned off, so hold the two
flanks to move the machine.
●Take the Machine into the Carrying Bag
Make sure the machine is not hot before taking it into the carrying bag.
OpenPackage
Unpack the package box, and check below items is complete.
HOLATEK Home Theater Remote control AC power cord
AV-IN cord mini VGA cord User Manual

Software Installation
Computer software driver can be downloaded on the HOLATEK website.
Download link:
http://www.holatek.cn/supports.html
ControlPositionsandFunctions
[Top/Front/Left]
[Bottom]
Inlet
Adjustable pin
Control
Inlet
Power On/Off
Infrared remote
Outlet
LED Lens
USB2.0

[Back]
[Control Panel]
Support
S
p
eaker
HDMI
VGA Input
AV-IN
Infrared
r
emote sensor
VGA
S
p
eake
r
USB
Speaker Input

RemoteControlFunctions
①Power On/Off PC and Projector
②Source
Menu
Source
Enter Disk
Wi-Fi signal
Enter
Menu setup
Right
ESC

FAdj

③Left
④Mute
⑤Down
⑥Volume
⑦3D module menu
⑧3DLeft/RightEyeSwitching
⑨Up
⑩Power On/Off Machine
Remote Control Range
Both in the front and back of the machine have infrared remote (IR) sensors. Hold the
remote control; take the angel with IR sensor less than 30 angle to make it effective.
The distance between the remote control and IR sensor cannot be longer than 8 m
(about 26 inch)
Do not place any barrier that blocks the IR between the IR sensors on the remote
control and that on the machine.
Caution！
zAvoid excessive heat and humid.
zDo not place the remote control where the buttons may be pressed
accidently to avoid using out the batteries
zDo not throw the batteries into the fire, which may cause an explosion.
zTake out the batteries to prevent damages from fluid leakage if the
batteries are used out or the remote control will not be used for a
long time

ProjectionImage
Installation
Adjusting Projection Size
Longer the distance between the home theater projector and the wall, bigger
the machine image size.
Refer to the table below to obtain the best size image
屏幕 screen
投影屏尺寸 projection screen size
镜头中心 lens center
投影距离 distance
＊The height from the lens center to the bottom of the projection image (A: when
move the lens at its top height)
单位 units
Distance
Units：
m
Screen Size 40 80 100 150 200 250 300
Min
Distance
1.2 2.3 2.9 4.4 5.9 7.3 8.8
Max
Distance
1.4 2.8 3.6 5.4 7.2 9.0 10.7

There may be a slight different between the designed value and practical
value in the table.
NOTE!
zThe lens of the machine is adjustable, the max tilt is up 40 angle
（+40°）,and max tilt down 40 angle（—40°)
zAuto correcting keystone range record is 0±40 angle. If the image tilts
downward, use the manual correcting keystone to adjust the image.
ProjectionInstructions
Warning!
zIf installing the machine on the ceiling, this machine should be
installed by refer qualified technicians using only approved
equipment. If installation work is not carried out correctly, the
machine could fall down. This may cause personal injury or accident.
Contact you dealer to install the machine correctly.
zIf using adhesives on the ceiling mount to prevent the screws from
loosening, or if using things such as lubricant, oils on the machine,
the machine case may crack causing it fall from the ceiling mount.
This could cause injury to anyone under the ceiling mount and could
damage the machine.
When installing or adjusting the ceiling mount, do not use adhesives
to prevent the screws from loosening and do not use lubricant, oils
and so on.
Caution!
Working conditions has great effect on the machine efficiency. Use the
machine in the conditions as follows:
zUse the close and easy-using outlet in order to unplug the power cord
at any time when it is necessary
Do not place any object inside the dotted line as the figure below.
Leave the distance no less than 30 cm between any object and the inlet
or outlet.

zThe outlet is extreme hot when the machine is in process. Do not touch it with
hand. It is also extreme hot near the outlet. Never place the plastic or any other
object that are sensitive to heat near or below the machine. The heat may cause
deformation and color change.
zDo not place the machine on the unstable or shaky surface. Never place
the machine on the carpet, blanket, towel or any other soft object.
zDo not place the machine where is exposed to direct sunlight.
zDo not place the machine where there is a lot of humidity or dust.
zKeep the machine far away from speakers, televisions, radio and other
magnetic devices, and heater.
zDust and dirty may build up in the inlet and around after the machine
is used for a long period of time, which may cause malfunctions. Check
if dust built up at the inlet every time before using the machine.
Wipe the dust with cloths if there is dust and dirty in the inlet.
zDo not block the inlet. Block the inlet may reduce the light source
life.
Outlet
Inlet
Inlet
Reserve enough space; do not
block the inlet and outlet.

zAirflow from the air conditioner will blow the heat exhausted by the
lens, which cause heat wave in the image. Adjust the air conditioner
or move the machine if this situation turns up.
zDo not place it on one of its side to use the machine, malfunctions
may result.
Projecting in the front
Projecting from the ceiling
BasicOperations
StartingandStoppingtheMachine
AC power Instructions
zUse the AC power cord attached with the machine
zUse AC power of which outplace voltage corresponds to rated voltage
of the machine

zDo not share the outlet with other devices. Make sure the rated current
corresponds to power consumption of this machine if using extension
cord.
zDo not use the bundled power cord
zDo not place objects on the power cord or step on it.
zDo not pull the power cord. Hold the plug when disconnecting it from
the outlet.
zUse the close and easy-using outlet in order to unplug the power cord
at any time when it is necessary
Connect the power inlet with attached AC power cord.
The power on/off indicator on the top of the machine turns to orange when
the power cord is connected to the outlet, which means the machine is
normal and standby.
TurningontheMachine
Press (power) on the top of the machine or (power)（red）on the remote
control to turn on and off the complaceer power， (power)（blue）on the
remote control only turn on and off the project function. When on
the top of the machine lights as white, it indicates that PC disk has started,
when the white indicator flashes continuously, it indicates that PC is
reading the disc, when the white indicator turns dark ,it indicates that
the disc has stopped operation.
TurningofftheMachine
1. Press (power) on the top of the machine to turn off the power.
2. Press (power)（red）on the remote control and confirm the message“Power
off ?Press the power again” displayed at the right down corner of the
screen.
zIf you do not turn off the power, the message disappears after 5
seconds. Press [ESC] also can remove the message.
3. Check and make sure that (power) on the top of the machine turns to
orange, lens blue light circle goes out and unplug the power cord from the outlet.
4. Make sure that the machine, connected external computer or vedio
device are truned off, unplug the power cord from the connected
devices.

SelectingLanguage
Chinese is the default language when the first time to turn on the machine,
follow the steps if you need to change into other languages.
Use the control panel or remote control, press [MENU], and press[∨] or [∧]
to select [Machine setup1], then press [ENTER] to select the language, and then press
[MENU] to confirm the selection.
SelectingInputSource
When turning on the machine, the input source selected at last time will
be the first choice. To select other input sources, follow the steps.
1. Press [SOURCE]
2. Use [▲] and [▼] on the remote control to select the input source name,
then press [ENTER].
AdjustingImage
How to Adjust the Focus
[FOCUS▲] and[FOCUS▼]on the remote control to adjust the focus,
release the button when adjustment is done.
Use the control pane, press [MENU] and press[∨] or [∧] to select [Machine
setup2], then press [Focus], and [＜] or [＞] to adjust , and then press [MENU] to
logoff the operation.
CorrectingKeystone 
When there is a certain angle between the machine and the projection
screen or the wall, the upper and lower sides length of projection image
may be different, this is called “keystone”. This machine has the
function of auto and manual correcting keystone to adjust the projection
image.
Auto Correcting Keystone
