homelabs HME030065N User manual
Beverage
Cooler
3.2 Cubic Feet
Thank you for purchasing our
appliance. Please be sure to
read the entirety of this user
manual carefully prior to using
this appliance. If you have any
questions regarding the use
of this product, please call
1-(800)-898-3002.
SKU: HME030065N
Important Safety Instructions...............................................
Before First Use.......................................................................
Parts Description.....................................................................
Operation..................................................................................
Maintenance.............................................................................
Specications...........................................................................
Troubleshooting.......................................................................
Warranty...................................................................................
Manufacturing Info..................................................................
Warning.....................................................................................
Contact Us................................................................................
6
7
7
8
9
9
10
10
11
11
11
Table of Contents
Before First Use
To prevent any internal damage, it is very important to
keep the units upright throughout its journey. Please leave it standing
upright and outside the box for 24 HOURS before plugging it in.
In the event this product malfunctions, or you believe it is
defective, please contact Customer Service at homelabs.com/help,
product (pending further instruction). A defective product should
be clearly marked or stored where it cannot be used by mistake.
Failure to keep the product in its original quality from the time of
receipt may impede hOmeLabs’s ability to correct any legitimate
problem and may limit the extent to which hOmeLabs
may provide recourse.
Before First Use
We recommend running the cleaning
program (See > Page 9) prior to
making ice for the rst time.
on bringing home your new appliance!
Congratulations
Don’t forget to register your product at homelabs.com/reg
for updates, coupons, and other relevant information.
Although greatly appreciated, product registration is not
required to activate any warranty.
6
• Read all instructions thoroughly before use.
• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
• Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not store explosive substances, such as aerosol cans with ammable propellant, in this appliance.
• Do not use extension cords or ungrounded (two-prong) adapters.
• This appliance is intended to be used in households and similar applications. Not intended for retail
or commercial use.
• Do not pull the power cord when pulling the power plug of the Beverage Cooler. Please rmly grasp the plug
and pull it out from the socket directly.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge unless they have been given supervision and instruction
concerning use of the appliance by a person responsible for their safety.
• Do not use the appliance for anything other than its intended use.
• Do not damage the power cord under any condition.
• Please use a dedicated three-hole power socket, which is 15 A or more and not shared with other
electrical appliances.
• Please ensure that the grounding electrode of the power socket is equipped with a reliable grounding line.
• The Beverage Cooler uses an AC power supply of 115 V / 60 Hz.
• In case of leaking gas, turn off the leaking valve and open your doors and windows. Do not unplug the Cooler
yourself, as it may cause a re. Contact Customer Support.
• For your safety, don’t place electric devices on top of the Cooler, like microwaves or electric kettles, and
don’t store your Beverage Cooler inside pantries.
• Always grasp the power plug to remove it from the wall outlet. Do not pull on the power cord itself.
• Power plug should be accessible.
• Make sure the Cooler is placed in a well-ventilated, indoor environment on at, sturdy ground (rotate left or
right to adjust the wheel to level if unstable).
• Be careful not to get ngers or dangling accessories caught in the Cooler Door.
• This Cooler and its packaging are not intended to be played with or used by children. If a child is using the
Cooler, it must be with adult supervision to avoid injury.
• Keep the Cooler out of moist, damp, or humid environments and situations, so as not to damage the
electrical insulation.
• Do not use a base, Cooler Door, etc. as pedal or support.
• Do not place heavy objects on top of the Cooler to prevent accidental damage or injury.
• Do not use this Cooler to store fresh foods, such as meats, vegetables, fruits, etc. This product can only be
used to chill beverages.
• Do not put ammable, explosive, volatile, or highly corrosive items in the Cooler to prevent damages to the
product or re accidents.
• Do not place ammable items near the Cooler to avoid a re hazard.
• This product is for household refrigeration appliances, mainly used for the storage of beverages. It’s not used
for other purposes, such as storage of blood, drugs, and biological products.
• Do not cover or close ventilation and exhaust holes.
For Household Use Only
WARNINGS RELATED TO PLACING ITEMS
WARNINGS RELATED TO USE
WARNINGS RELATED TO ELECTRICITY
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of
re, electric shock, and/or injury to persons.
7
1. Before using the Cooler, remove all packaging materials, including bottom cushions, foam pads, and tape inside
the Cooler. Tear off the protective lm on the Door and the Cooler Body.
2. Make sure the Cooler is placed in a well-ventilated, indoor environment on at, sturdy ground (rotate left
or right to adjust the wheel to level if unstable).
3. To ensure proper ventilation, allow for at least 11.8 in (30 cm) between the Cooler and any stove, furnace.
We also advise operate this Beverage Cooler in a room of 133 cubit feet (or larger) for safety concern.
4. Keep a circulation space of at least 1.5 in (4 cm) on both sides of the Cooler to preserve power.
5. Avoid putting the Cooler in direct sunlight or too close to a heat source. Keep a safe distance of at least
11.8 in (30 cm) between the Cooler and a stove or furnace if it can’t be avoided. We also advise applying an
insulation board in that case.
Parts Description
Temperature Control
Fan
Shelf
Shelf
Glass Door
Adjustable
Foot
PLACEMENT
INSTALLATION
• Keep in upright position for 24 hours before initial power up.
• While the Cooler is empty, set the “Temperature Control” to maximum and leave for 1 hour.
• When you start putting beverages inside the Cooler, maintain a 1.5 in (4 cm) gap between the interior wall
of the Cooler and the beverages to keep the proper airow.
• Follow steps below if you want to change the Door orientation from left-hinge to right-hinge:
1. Use a screwdriver to remove upper and lower left hinge (triangle with 3 screws).
2. Transfer the hinge to the right of the Cooler and attach to the right side of the Door.
Before First Use
8
Energy Conservation
• The Cooler should be placed in a room that is dry and ventilated. The Cooler cannot be placed under direct
sunlight or next to a heat source (such as a radiator, stove, etc.), and a suitable insulation board must be
applied if necessary.
• Try to shorten the opening time of the Cooler’s Door.
• Avoid putting warm beverages in the Cooler.
PROPER USE OF BEVERAGE COOLER
INTRODUCTION TO THE BEVERAGE COOLER’S FUNCTIONS
1. Display Controls
When turning on for the rst time, the display screen will be a full display for 3 seconds and the
startup tone will ring.
2. Standby Mode
To activate “Standby” mode, hold the “Standby” button for 3 seconds. You will hear a beep and the display
area will be cut off. To deactivate “Standby” mode, press the button again. You will hear a beep and the
standard display will show.
3. Lighting
Press the “Lighting” button to turn the light on or off.
4.
Press the “Increase Temperature” button to increase the temperature one degree at a time. Press the
“Decrease Temperature” button to decrease the temperature one degree at a time. To change display from
OF to OC, press and hold the “Increase” and “Decrease” button simultaneously for 5 seconds.
5. Memory Function
If turned off, this Cooler will remember any settings in place and will work according to those settings once
it’s turned on again.
6. Fault Indicators
If any of these indicators are displayed, it means the Cooler has the following issues:
Operation
FAULT CODE DESCRIPTION
E1 R room sensor failure
E4 R room defrost sensor failure
9
DISCONNECTING THE BEVERAGE COOLER
CLEANING YOUR BEVERAGE COOLER
FREQUENTLY ASKED QUESTIONS
I’m hearing some sounds, what’s up with that?
Buzzing or any gurgling sound is normal, as that can be a result of the unit working properly or refrigerating uid
owing through the pipeline.
Unplug the power plug from the socket to disconnect the Cooler.
Maintenance
Dusting behind the Cooler and on the ground will improve the cooling effect and save energy. The interior of the
Cooler should be cleaned to avoid any odor. Follow the cleaning procedure below:
1. Unplug the Cooler.
2. Wipe the door seal with warm water.
3. Use soap and warm water to clean the Cooler.
4. Reconnect the Cooler when the Cooler is clean and dry.
NOTE:
Do not use hard brushes, wire brushes, abrasives,
organic solvents, boiling water, acid, or alkaline items
as this may damage the cooler surface and interior.
DEFROST
1. Unplug the Beverage Cooler.
2. Remove beverages and cooler contents. Place them properly to prevent melting or spoiling, where necessary.
3. Allow the appliance to defrost naturally at room temperature.
4. If any lingering liquid remains after defrosting, wipe the Beverage Cooler interior with a clean, soft cloth.
5. Power on the appliance.
6. Allow it to run for 2–3 hours, then return any removed beverages to the Cooler.
NOTE:
Do not immerse the Beverage Cooler.
Specications
• Temperature Range: 34–50 °F
• Voltage/Current: 115 V~ / 1.1 A
• Net Weight: 68.3 lb
• Dimensions: W 18.9 × H 33.3 × D 17.30 in
10
hOmeLabs offers a limited two-year warranty (“warranty period”) on all of our products purchased new and
unused from hOmeLabs Technologies, LLC or an authorized reseller, with an original proof of purchase and where
a defect has arisen, wholly or substantially, as a result of faulty manufacture, parts or workmanship during the
warranty period. The warranty does not apply where damage is caused by other factors, including but without
limitation: (a) normal wear and tear; (b) abuse, mishandling, accident, or failure to follow operating instructions;
(c) exposure to liquid or inltration of foreign particles; (d) servicing or modications of the product other than
by hOmeLabs; (e) commercial or non-household use.
The hOmeLabs warranty covers all costs related to restoring the proven defective product through repair or
replacement of any defective part and necessary labor so that it conforms to its original specications.
A receipt indicating the purchase date is required for any claim, so please keep all receipts in a safe place. We
recommend that you register your product on our website, homelabs.com/reg. Although greatly appreciated,
the product registration is not required to activate any warranty and product registration does not eliminate the
need for the original proof of purchase.
The warranty becomes void if attempts at repair are made by non-authorized third parties and/or if spare parts,
other than those provided by hOmeLabs, are used.
You may also arrange for service after the warranty expires at an additional cost.
These are our general terms for warranty service, but we always urge our customers to reach out to us
with any issue, regardless of warranty terms. If you have an issue with a hOmeLabs product, please contact us
at 1-(800)-898-3002, and we will do our best to resolve it for you.
This warranty gives you specic legal rights, and you may have other legal rights which vary from state to state,
country to country or province to province. The customer may assert any such rights at their sole discretion.
Warranty
PROBLEM POSSIBLE CAUSES POSSIBLE CAUSES
Cooler isn't cool The Door is being opened too often.
The Cooler is too full of bottles or cans.
Reduce the frequency of opening the
door and give it 4–5 hours.
Cooler is not refrigerating The power is out or the Cooler isn’t
plugged in.
Check the power. Make sure that the
Cooler is plugged in.
LED light is off The LED light is broken. Contact Customer Support.
Condensation on the
Glass Door
The temperature is set too low or too high. Increase the temperature and use a
rag to wipe away any drops of water.
Troubleshooting
11
This manual is to be used with all items with the model number
SKU#: HME030065N
PART#: HME030065MNL
RATING: 115 V, 60 Hz, 75 W, AC ONLY
Manufacturing Info
Contact Us
CHAT WITH US CALL US EMAIL US
WARNING: Keep all plastic bags
away from children.
HME030065N
WARNING: This product could
contain one or more chemicals, which
are known to the Sate Of California
to cause cancer, birth defects,
or other reproductive harm.
Manufacturer, distributor, importer and seller are not liable
for ANY damage caused by improper use, storage, care or failure
to follow warnings associated with this product.
Distributed by hOmeLabs™, LLC
37 East 18 Street, 7th Floor
New York, USA 10003
1-(800)-898-3002
help@homelabs.com
homelabs.com/help
All rights reserved, hOmeLabs™
Made in China.
For Household Use Only
Table of contents
