About This Document
This document describes how to install and operate the HTR1 mobile video recording
system. This guide is intended for installers, administrators, and operators.
The HTR1 mobile video recording system is referred to as the HTR1 throughout this guide.
Overview of Contents
This document contains the following chapters and appendixes:
•Chapter 1, System Overview, introduces the HTR1 and its components and describes
the system features.
•Chapter 2, Installation, describes how to install the HTR1 in a bus, including wiring
connections to all the peripherals.
•Chapter 3, System Setup, shows you how to configure the system after installation.
•Chapter 4, System Operation, describes how to perform routine operations.
•Appendix A, Solutions, provides answers for common technical issues.
•Appendix B, Specifications, lists specifications for the HTR1.
Important Safeguards and Warnings
Caution The installation of this equipment should be made only by qualified
technicians and should conform to all local codes.
WARNING! Connection of this device to any equipment other than that
recommended by Honeywell may result in a safety hazard,
defective operation, and/or equipment damage.

Rev B 12 Document 800-00759
11/07
Warranty and Service
Subject to the terms and conditions listed on the Product Warranty Card, during the
warranty period Honeywell will repair or replace, at its sole option, free of charge, any
defective products returned prepaid.
In the event you have a problem with any Honeywell product, please call Customer Service
for assistance or to request a Return Authorization (RA) number:
Call +1.800.796.CCTV
Be sure to have the model number, serial number, and the nature of the problem outlined
for the technical service representative.
Prior authorization must be obtained for all returns, exchanges, or credits. Items shipped to
Honeywell without a clearly identified Return Authorization (RA) number may be refused.

Rev B 13 Document 800-00759
11/07
1
System Overview
The HTR1 mobile video system records and displays audio and video signals, time and
date, vehicle speed, and the status of vehicle warning signals.
The HTR1 mobile video system consists of the following components:
• An industrial grade VHS VCR
• A sturdy, 18-gauge steel, tamper-resistant enclosure
• A Honeywell mobile camera
•Cables
Features
The HTR1 mobile video system gives you:
Recording
• Two camera inputs for optional Stop arm camera system (single channel recording)
• Two Hi-Fi audio channels for higher audio quality
• Up to nine hours of recording time (T180 tape)
• Continuous loop recording (on/off user programmable)
• Recording for up to 59 minutes after the vehicle ignition is switched off (user
programmable)
• Delay recording for up to 59 minutes after the vehicle ignition is switched on (user
programmable)
On-Screen Display
• Time and date stamps on recorded video signals with automatic Daylight Saving
Time adjustment
• On-screen alphanumeric recording of vehicle speed and up to five status signals
(typically, brake lights, turn indicators, and warning indicators)
• On-screen programmable title (up to 20 characters)

Rev B 14 Document 800-00759
11/07
System Overview
Ease of Operation
• Monitor video and audio output through front panel jacks for easy access
• User friendly programing using the supplied infrared remote control and on-screen
display
• The VCR settings are saved for ten years without powering the unit
• EP or SP recording speed (user programmable)
• Four daily timers for programming VCR operation
• Temporary power—using the POWER button—to remove tapes and program the
VCR while the vehicle ignition is off
• Automatically detects if the video signal from the camera is missing
GPS Module (Optional)
The HTRGPS module records vehicle speed without tapping into transmission speed
sensors. The HTRGPS module sends vehicle position, bearing, and speed data via serial
interface to the HTR1.
Compatibility
The HTR1 is fully upgradeable to an HTR4 digital mobile system.
The HTR1 is fully compatible with previous Silent Witness mobile video installations such
as the HTR62, SWS310, SWS210, and SWS210A mobile video systems. The HTR1 may be
installed in existing non-Honeywell systems with minimal adjustment.

Rev B 15 Document 800-00759
11/07
2
Installation
This chapter tells you how to install the HTR1 mobile video system in a bus.
Before You Begin
Unpack Everything
The HTR1 kit should include the following items in addition to this guide:
• One VCR enclosure (base, cover, and access panel with two keys)
• One 20 ft. (6.1 m) wiring harness
•OneVCRkit:
•OneVCR
• One remote control with batteries
• One hardware package:
• Four #10 x 3/4 in. Phillips sheet metal screws
• Two wire taps
• One inline fuse holder and 3A fuse
• One safety grommet for the enclosure cable outlet
• One Warranty card
Please read this guide carefully before you install
the HTR1 mobile video system.
Keep this guide for future reference.

Rev B 16 Document 800-00759
11/07
Installation
Check that the items received match those listed on the order form and packing slip. If any
parts are missing or damaged, please contact the dealer you purchased the HTR1 system
from, or call Honeywell Customer Service (see Warranty and Service, page 12).
Equipment Required
The following tools may help you to complete the installation:
•Drill
• Phillips screwdriver
• Wire cutters
New Installation
This section shows you how to install an HTR1 in a school bus that does not have an
existing mobile video system. To upgrade an existing mobile video system (for example, a
Silent Witness SWS310 or SWS210), see Upgrade Installation, page 21.
Choosing the Location
Choose a location for installation that:
• Provides convenient access for installing or removing the VCR or tapes
• Has a rigid surface, such as the dashboard, headliner, or under a seat
• Conforms to local regulatory guidelines
Avoid any location for installation:
• That is subject to high vibration
• That is subject to high sunlight levels
• Where passengers can interfere with it
• Next to a heater duct
• On the floor if the bus is washed out with a hose

HTR1 Installation and Operating Guide
Rev B 17 Document 800-00759
11/07
Table 2-1 lists recommended location options.
Caution Honeywell recommends that you do not install the HTR1 on the
transmission access hatch. This location has the highest level of
vibration (and may be subject to water damage).
Mounting Options
The VCR enclosure can be mounted:
• Horizontally, either upright or inverted, as shown in Figure 2-1.
Figure 2-1 Mounting Options
Table 2-1 Installation Locations
Location Convenient
operation
Easy to
install
Low
vibration
Good air
flow
Bottom of glove box -
horizontal mount
Inside glove box - horizontal
mount
Bottom of passenger seat
behind bus driver - horizontal
mount
Underneath bulkhead -
horizontal mount
Console - horizontal mount
Beside driver seat - horizontal
mount
Horizontal options
Inverted Installation Upright Installation

Rev B 18 Document 800-00759
11/07
Installation
Mounting the VCR Enclosure Base
To mount the VCR enclosure base:
1. Unlock the access panel in the front of the VCR enclosure cover, using one of the
keys included with the enclosure.
2. Slide the cover forward and lift it off the enclosure base.
3. Use the VCR enclosure base as a template to mark and drill pilot holes for the four
#10 x 3/4 in. sheet metal mounting screws (included with the hardware package).
Note If desired, you can drill alternate mounting holes in the VCR enclosure base.
Locate the mounting holes as close as possible to the outside edges of the
enclosure base. Ensure that the mounting fasteners do not touch the VCR
when it is installed.
4. Attach the VCR enclosure base to the mounting surface, using the four #10 x 3/4 in.
sheet metal mounting screws.
Wiring
Figure 2-2 shows the wiring harness and camera harness that connects into the back panel
of the VCR.
Note Start cabling at the VCR to ensure that the DB25 connector has sufficient
length to reach the VCR.
To connect the wiring harness:
1. Plug the DB25 connector on the HTR1 wiring harness into the back of the VCR (see
Figure 2-2) and tighten the retaining screws.
2. Remove the 3A fuse from the fuse holder.
3. Connect the fuse holder and power harness to the vehicle main battery power and
ground points. If a master power switch (kill switch) is used in the vehicle, attach the
power harness after the switch.
4. Connect the signal harness to the ignition switch and input signals at the fuse box or
under the dash.
The connection to the ignition switch starts and stops the VCR; it does not power the
VCR. If possible, connect this wire to the radio accessory fuse to avoid electrical
interference from fans or blowers.
5. Connect the Video and Audio connectors from Camera 1 into Cam 1 Video and Main
Audio respectively.
6. If a second camera (for example, Stop Arm) is used, connect it to Cam 2 Power and
Cam 2 Video.

HTR1 Installation and Operating Guide
Rev B 19 Document 800-00759
11/07
7. An optional external microphone can also be connected to the Aux In Audio. To order,
contact your Honeywell representative. See the back cover of this guide for contact
information.
8. Insert the 3A fuse into the fuse holder connected to the positive battery terminal of the
vehicle.
Figure 2-2 shows the wiring on the wiring harness that connects to the electrical system.
Figure 2-2 Wiring Connections
Power harness
Signals harness
20 ft. (6.1 m) cables
DB25 connector
Red wire Battery (POS - 3A fuse)
Blue wire Input signal 5 ARM
Black wire Battery (NEG)
White wire Ignition
Brown wire Input signal 1 BRK
Black wire Input signal 2 STP
Green wire Input signal 3 TRN
Red wire Input signal 5 FSH
N/A Cam 2
Cam 1 Cam 1
Pow e r
Cam 2
Power
Interface
Main AudioAux Audio
VCR rear panel
Camera 1
Audio in
Video in
Power
Camera 2 (Stop Arm)
Video in
Power
Optional external
microphone (call
to order)

Rev B 20 Document 800-00759
11/07
Installation
Installing the VCR
Note If you are replacing an HTR62 unit with this HTR1 unit, you need to replace
the foam pads, locations indicated in Figure 2-3. Please contact your
Honeywell representative for replacement pads.
To install the VCR:
1. Slide the VCR into the foam padded holder in the VCR enclosure base and secure it in
place with the velcro retaining strap. Do not press on the center of the VCR.
2. For inverted mount installations, see Figure 2-3.
Figure 2-3 Enclosure Inverted Mount Installation
Installing the Enclosure Cover
To install the enclosure cover:
1. Unlock the access panel in the front of the enclosure cover, using one of the keys
supplied with the VCR enclosure.
2. Place the enclosure cover inside the side rails of the enclosure base.
3. Slide the cover toward the rear of the base (see Figure 2-4).
4. Replace the access panel and lock it to secure the cover to the base.
Inverted VCR enclosure base
VCR
Foam pads
Foam pads
