Philips VRA999PH User manual

Super VHS 6-Head Hi-Fi Stereo
S-VHS ET (Expansion Technology)
• Super 400 lines picture quality
• Pro-cision19 Micron head
• Plug & Play set-up
• Trilingual onscreen display
• Battery back-up
• Quick timer programming
• VCR Plus+ C3 cable box control
• Incredible picture chip — Best performance
& reliability
• Quick timer programming
Video Cassette Recorder
VRA999PH
Lighted jog/shuttle
multibrand TV
remote control
ENERGY STAR®IS A SYMBOL
FOR ENERGY EFFICIENCY

"Super VHS ET" Capable of recording over 400 lines of high resolu-
tion on conventional VHS Tapes. The brand-new technology "Super VHS
ET (Expansion Technology)" makes it possible to record Super VHS quality on
Standard VHS tapes. The new "Super VHS ET" feature on Super VHS decks
will allow users to record high-resolution Super VHS signals on the most
widely available VHS cassettes, thus delivering over 400 lines of resolution. In
turn, the new technology allows more users to easily enjoy higher-resolution
which previously had been available only to owners of Super VHS decks using
Super VHS cassette tapes. The technology will substantially expand the scope
of higher-quality home picture recording and the penetration of Super VHS.
Key benefit and communication for S-VHS ET :
• Perfect solution of high resolution picture (400 lines vs. 240 lines)
• Cheaper hardware cost than S-VHS in the past
• Enable to use standard tape for S-VHS recording
• Same running cost of recording on VHS
Features
S-VHS
More than 400 lines of horizontal resolution, (VHS 240 lines) and
separate luminance (Y) and chrominance (C) signal processing. This
provides Best picture quality.
S-VHS ET (S-VHS Expansion Technology)
400 lines picture quality can be recorded on standard tape. This allow
low running cost (same as normal recording on standard tape) for
perfect picture quality.
6 Head (4 Video & 2 Audio)
The DA 4 Head design ensures a perfect still, interference free slow motion
& frame-by-frame advance picture while another 2 heads are added to
provide high quality Stereo Hi-fi sound both in Playback & Recording. By
connecting the audio output to a Hi-fi Audio System, you will be able to enjoy
superb sound for the complete Home cinema experience.
Pro-cision 19µ Heads Child Lock
Trilingual On Screen Display Smart Picture Chip
VCR + C3 Cable Box Control Quick Timer Programming
Video Index Search System (VISS)
S-VHS + A/V Front In Socket
Lighted Jog/Shuttle Multibrand TV Remote Control
GENERAL
Power Supply : (+/- 10%) : 110 - 240V
Power Plug : UL/CSA Type
Front Panel Finishing : Black Metallic
Jog / Shuttle on set (J/S) : yes (J/S)
VIDEO
Video System - Rec : NTSC
Video System - Playback : NTSC
S-VHS : yes
S-VHS/ET : yes
No. of Heads : 4 video
: 2 audio
Head Cleaner : yes
Recording Speed : SP/SLP
Playback Speed : SP/LP/SLP
Still Picture (SP mode) : Perfect
Picture Control : Incredible Picture
AUDIO
Hi-fi Stereo : yes
TUNER
Tuning System : FST
No. of Channel Position : 181CH
Frequency Coverage : V / U / CATV
Stereo Decoder : MTS
Modulator : CH 3/4
DISPLAY/TIMER
Level Meter : yes
Dimmer : Auto
On Screen Display : Eng / Spa / Fre
Timer Program : 1 Year / 8 Events
Power Backup Time (6-month) : Lithium Batt. CR2025
Instant Recording (OTR) : yes
Quick Timer Programming : 10 Key (on remote)
TAPE ACCESS
Real Time Counter : yes
Repeat (50 Times) : yes
Index Search : yes
Skip Search : yes
CONNECTORS
Front AV Socket : yes (RCA + SVHS)
Rear S-VHS In : yes
Rear S-VHS Out : yes
REMOTE CONTROL
Jog and Shuttle on remote : yes
Illumination Function Key : yes
Multibrand TV Compatibility : yes
SUPER VHS ET
Video Signal Recording System
• Video input/output signal: NTSC-type color signal and separated Y/C
signals conforming to NTSC
• Luminance signal recording: Frequency modulated (FM) recording (con-
forming to Super VHS)
• FM frequency
White peak: 7.0 ± 0.1 MHz (conforming to Super VHS)
Sync tip: 5.4 ± 0.1 MHz (conforming to Super VHS)
Deviation: 1.6 MHz (conforming to Super VHS)
• Clip level
White clip: 190 ± 10% (210% for Super VHS)
Dark clip: -70 ± 10% (conforming to Super VHS)
• New signal emphasis
• Chrominance signal recording: Color-under phase-shift recording of
guadrature modulated chrominance signal (conforming to Super VHS)
Audio Signal Recording System
• Linear track recording: conforming to VHS audio recording method
• FM recording: conforming to VHS audio recording method
UPC: 037849881170
Product Dimensions: 17.1" W x 3.8" H x 12.9" D Product Weight: 10 lbs.
Carton Dimensions: 21" W x 7.5" H x 16.5" D Carton Weight: 14 lbs.
Master Pack: 1
Carton Contains: 6-Head , Hi-fi Stereo Video Cassette Recorder, Jog/Shuttle Remote
Control w/Batteries, Cable Box Mouse, Operating Instructions, Warranty Information
INTERNET ADDRESS: HTTP://www.philipsusa.com
Printed in U.S.A.
©1999 Philips Consumer Electronics Co.
A Division of Philips Electronics North America Corp.
KID Design GR99085, Philips Consumer Electronics Co.
Specifications subject to change without notice.
* VCR Plus+ C3 and PlusCode are registered trademark of Gemstar
Development Corporation. The VCR Plus+ system is manufactured
under license from Gemstar Development Corporation. As an Energy
Star®Partner, Philips has determined that this product meets the
Energy Star®guidelines for energy efficiency.
Video Cassette Recorder
VRA999PH
S-VHS
S-VHS ET
Standard
VHS
VHS Tape
• HG
• STD
S-VHS
Tape
S-VHS ETConcept
VHS
Recording
S-VHS
Recording
