OWNER’S MANUAL

bedienungsanleitung

manuel de l’utilisateur

manuale dell’utente

2012 CHEVROLET®CAMARO®ZL1™

SAFETY PRECAUTIONS AND GUIDELINES

»Always keep a safe distance in all directions around your

model to avoid collisions or injury. This model is controlled

by a radio signal subject to interference from many sources

outside your control. Interference can cause momentary

loss of control.

»Always operate your model in open spaces away

from full-size vehicles, trac and people.

»Always carefully follow the directions and warnings for this

and any optional support equipment (chargers, rechargeable

battery packs, etc.).

»Always keep all chemicals, small parts and anything electrical

out of the reach of children.

»Always avoid water exposure to all equipment not speciﬁcally

designed and protected for this purpose. Moisture causes

damage to electronics.

»Never place any portion of the model in your mouth as it

could cause serious injury or even death.

»Never operate your model with low transmitter batteries.

VATERRA PRODUCT ONLINE

the ﬁrst to ﬁnd out about the latest

option parts, product updates and

more. Click on the Support tab at

WWW.VATERRARC.COM and follow

the product registration link to

stay connected.

NOTICE

All instructions, warranties and other collateral documents are subject

to change at the sole discretion of Horizon Hobby, Inc. For up-to-date

product literature, visit www.horizonhobby.com and click on the

support tab for this product.

WARNING: Read the ENTIRE instruction manual to become familiar with the

features of the product before operating. Failure to operate the product correctly

can result in damage to the product, personal property and cause serious injury.

This is a sophisticated hobby product and NOT a toy. It must be operated with

caution and common sense and requires some basic mechanical ability. Failure

to operate this Product in a safe and responsible manner could result in injury or

damage to the product or other property. This product is not intended for use by

children without direct adult supervision. Do not attempt disassembly, use with

incompatible components or augment product in any way without the approval

of Horizon Hobby, Inc. This manual contains instructions for safety, operation and

maintenance. It is essential to read and follow all the instructions and warnings

in the manual, prior to assembly, setup or use, in order to operate correctly

and avoid damage or serious injury.

MEANING OF SPECIAL LANGUAGE

The following terms are used throughout the product literature to

indicate various levels of potential harm when operating this product:

NOTICE: Procedures, which if not properly followed, create a possibility

of physical property damage AND a little or no possibility of injury.

CAUTION: Procedures, which if not properly followed, create the

probability of physical property damage AND a possibility of serious injury.

WARNING: Procedures, which if not properly followed, create the probability

of property damage, collateral damage, and serious injury OR create a high

probability of superﬁcial injury.

AGE RECOMMENDATION: Not for children under 14 years. This is not a toy.

/ / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

GENERAL PRECAUTIONS

»Read through the wet conditions maintenance procedures

and make sure that you have all the tools you will need to

properly maintain your vehicle.

»Not all batteries can be used in wet conditions. Consult the

battery manufacturer before use. Do not use Li-Po batteries

in wet conditions.

»Most transmitters are not water-resistant. Consult your

transmitter’s manual or the manufacturer before operation.

»Never operate your transmitter or vehicle where lightning

may be present.

»Do not operate your vehicle where it could come in contact

with salt water (ocean water or water on salt-covered roads),

contaminated or polluted water. Salt water is very conductive

and highly corrosive, so use caution.

»Even minimal water contact can reduce the life of your motor

if it has not been certiﬁed as water-resistant or waterproof. If

the motor becomes excessively wet, apply very light throttle

until the water is mostly removed from the motor. Running a

wet motor at high speeds may rapidly damage the motor.

»Driving in wet conditions can reduce the life of the motor.

The additional resistance of operating in water causes

excess strain. Alter the gear ratio by using a smaller pinion

or larger spur gear. This will increase torque (and motor life)

when running in mud, deeper puddles, or any wet conditions

that will increase the load on the motor for an extended

period of time.

WET CONDITIONS MAINTENANCE

»Remove the battery pack(s) and dry the contacts. If you have

an air compressor or a can of compressed air, blow out any

water that may be inside the recessed connector housing.

»Remove the tires/wheels from the vehicle and gently rinse

the debris o with a garden hose. Avoid rinsing the bearings

and transmission.

NOTICE: Never use a pressure washer to clean

your vehicle.

»Use an air compressor or a can of compressed air to dry the

vehicle and help remove any water that may have gotten into

small crevices or corners.

»Spray the bearings, drive train, fasteners and other metal

parts with WD-40® solvent or any other water-displacing

light oil. Do not spray the motor.

»Let the vehicle air dry before you store it.

Water (and oil) may continue to drip for a few hours.

»Increase the frequency of disassembly,

inspection and lubrication of the following:

• Front and rear axle hub assembly bearings.

• All transmission cases, gears and dierentials.

• Motor—clean with an aerosol motor cleaner and

re-oil the bearings with lightweight motor oil.

WATER-RESISTANT VEHICLE WITH WATERPROOF ELECTRONICS / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

Your new Horizon Hobby vehicle

has been designed and built with

a combination of waterproof and

water-resistant components to

allow you to operate the product

in many “wet conditions”, including

puddles and even rain.

While the entire vehicle is highly water-

resistant, it is not completely waterproof

and your vehicle should NOT be treated

like a submarine. The various electronic

components used in the vehicle, such

as the Electronic Speed Control (ESC),

servo(s) and receiver are waterproof,

however, most of the mechanical

components are water-resistant

and should not be submerged.

Metal parts, including the bearings,

hinge pins, screws and nuts, as well as

the contacts in the electrical cables, will

be susceptible to corrosion if additional

maintenance is not performed after

running in wet conditions. To maximize

the long-term performance of your

vehicle and to keep the warranty intact,

the procedures described in the “Wet

Conditions Maintenance” section to fol-

low must be performed regularly if you

choose to run in wet conditions. If you

are not willing to perform the additional

care and maintenance required, then

you should not operate the vehicle

in those conditions.

CAUTION: Failure to exercise caution while using this product and complying with the following precautions could

result in product malfunction and/or void the warranty.

INTRODUCTION

The DNA of the 2012 Camaro® ZL1™

is undeniable. Its muscular looks

bear a strong resemblance to that

of the original 1969 version. What

sets the modern ZL1 apart are the

smart new ways it applies the brute

force of its 580 horsepower V8. Mag-

netic Ride Control, high-G fuel pickups,

optional paddle shifters – it’s a whole

new breed of Camaro that’s as big a

threat on racing circuits like Nürbur-

gring as it is at the stop light.

This 1/10-scale recreation of the

2012 Camaro ZL1 is completely

assembled and ready-to-run. While

the battery is charging, you must take

a little time and read this manual.

In its pages you’ll ﬁnd helpful setup

and charging tips as well as a handy

troubleshooting guide. It’s all here to

make sure your experience at the

wheel is the best it can be.

TABLE OF CONTENTS / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / QUICK START / / / / / / / / / / / / / / / / / / / / /

Please read the entire manual to gain a full understanding

of the V100 sedan, ﬁne-tuning the setup, and performing

maintenance.

1Read the safety precautions found in this manual.

2Charge the battery. Refer to the included charging

warnings and instructions for battery charging

information.

3. Install the AA batteries in the transmitter.

Only use alkaline or rechargeable batteries.

4Install the fully charged battery in the vehicle.

5 Power ON the transmitter and then the vehicle. Always

power the transmitter ON before the vehicle and power

it OFF after the vehicle has been powered OFF.

6 Check the steering and throttle control directions.

Verify that the servos are moving in the correct

direction.

7Drive your vehicle.

8 Perform any necessary maintenance.

Introduction

Quick Start

Components

The Vehicle Battery

The Transmitter

Transmitter and Receiver Binding

Control Test

Run Time

Tuning, Adjusting & Maintaining Your Vehicle

Dynamite Li-Po Tazer 12T Waterproof Forward/Reverse ESC

Dynamite 15T Brushed Motor

Troubleshooting Guide

Limited Warranty

FCC Statement

Compliance Information for the European Union

Fasteners

Replacement Parts

Optional Parts

»1/10-scale V100 RTR Sedan

»Spektrum™ DX2E 2.4GHz DSM® Radio System

»Dynamite® Tazer™ Waterproof ESC

»Dynamite 540 Brushed Motor

»113WP Standard Waterproof Servo

»Dynamite Speedpack™ 7.2V 1800mAh Ni-MH Battery

»Dynamite 2A Ni-MH AC Charger

»4 AA Batteries (for transmitter)

COMPONENTS / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

REQUIRED TOOLS

»Hobby-grade knife

»Needle nose pliers

»Side cutting pliers

»Safety goggles

»Soldering iron

»Soft brush

* Use only Dynamite tools or other

high-quality tools. Use of inexpensive

tools can cause damage to the small

screws and parts used on this type

of model.

»3 “L” shaped hex wrenches

• 1.5mm, 2mm, 2.5mm

SUPPLIED TOOLS

»4-way wrench

• 7mm, 5.5mm, 5mm, 4.5mm

1Connect the AC power cord to

the power slot on the charger, then

connect the other end of the power

cord to an AC power source.

2The Power LED and Charging LED

will turn green when the charger is

connected to the AC power source.

3Connect the battery connector

to the charger connector.

4Press the Start/Stop button to

charge the battery. The Charging

LED turns red.

5When the battery is fully charged,

the Charging LED will turn green.

6Disconnect the battery pack

connector from the charger

connector.

7Disconnect the AC power cord

from the AC power source.

APower LED

BStart/Stop Button

CCharging LED

DAC Power Slot

ECharger to Battery Connector

The vehicle battery charger produces

2000 milliAmps. Divide the mAh capac-

ity on the label of a battery by 2000

to determine battery charge time. For

example, an 1800mAh battery requires

.9 hours, or 54 minutes, to charge.

Refer to the charging warnings. It is

recommended you charge the battery

while you inspect the vehicle. The

battery will be required to conﬁrm

proper operation in future steps.

Charge only batteries that are cool

to the touch and are not damaged.

Inspect the battery to make sure it

is not damaged, e.g., swollen, bent,

broken or punctured.

WARNING: Failure to exercise

caution while using this product and

comply with the following warnings

could result in product malfunction,

electrical issues, excessive heat,

FIRE, and ultimately injury and

property damage.

WARNING: Never leave charger

unattended, exceed maximum charge

rate, charge with non-approved

batteries or charge batteries in the

wrong mode. Failure to comply may

result in excessive heat, ﬁre and

serious injury.

CAUTION: If at any time

during the charging process the

battery becomes hot to the touch,

disconnect the battery immediately

and discontinue the charging process.

CAUTION: Always ensure the

battery you are charging meets the

speciﬁcations of this charger and that

the charger settings are correct. Not

doing so can result in excessive heat

and other related product malfunc-

tions, which can lead to user injury or

property damage. Please contact

Horizon Hobby or an authorized

retailer with compatibility questions.

THE VEHICLE BATTERY / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

B C

CHARGING WARNINGS

»Read all safety precautions and

literature prior to use of this product.

»Never leave the battery and charger

unattended during use.

»Never allow children under 14 years

of age to charge batteries.

»Never attempt to charge dead

or damaged batteries.

»Never charge a battery if the cable

has been pinched or shorted.

»Never allow the batteries or charger

to come into contact with moisture

at any time.

»Never charge batteries in extremely

hot or cold places (recommended

between 50–80°F (10–26°C)) or

place in direct sunlight.

»Always use only Ni-MH rechargeable

batteries. This charger cannot charge

batteries such as “heavy duty”, “alka-

line”, “mercury” or “lithium” batteries.

»Always connect to the charger

correctly.

»Always disconnect the battery and

charger after charging and let them

cool between charges.

»Always inspect the battery

before charging.

»Always terminate all processes and

contact Horizon Hobby if the product

malfunctions.

»Always make sure you know the speci-

ﬁcations of the battery to be charged

or discharged to ensure it meets the

requirements of this charger.

»Always constantly monitor the tem-

perature of the battery while charging.

»Always end the charging process if the

charger or battery becomes hot to the

touch or starts to change form during

the charge process.

INSTALLING THE VEHICLE BATTERY

1Ensure the ESC is powered OFF.

2Remove the body from the chassis.

3Remove the body clip from the battery

strap, then lift the back of the battery strap.

The battery strap will rotate toward the

front of the car.

4Install the fully charged battery in the

battery cavity.

5Connect the battery to the ESC.

6Lower the battery strap and secure

it using the body clip.

7Power ON the transmitter, then the vehicle.

8Replace the body on the chassis.

THE TRANSMITTER / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

INSTALLING THE TRANSMITTER BATTERIES

1Push in the battery cover a small amount

to release the retaining tab, then remove

the cover.

2Install 4 AA batteries, taking care to align

the battery polarity to the diagram in the

transmitter’s battery case.

3Carefully reinstall the battery cover

by aligning the tabs with the slots

on the transmitter.

CAUTION: NEVER remove the

transmitter batteries while the vehicle

is powered ON, as loss of control,

property damage or injury may result.

CAUTION: If using rechargeable

batteries, charge only rechargeable

batteries. Charging non-rechargeable

batteries may cause the batteries to

burst, resulting in injury to persons

and/or damage to property.

1Steering Wheel controls direction (left/right) of the model

2Throttle Trigger controls speed and direction

(forward/brake/reverse) of the model

3Antenna transmits the signal to the model

4ON/OFF Switch turns the power ON/OFF for the transmitter

5Indicator Lights

• Solid green light indicates adequate battery power

• Flashing green light indicates the battery

voltage is critically low. Replace batteries.

6ST. Trim adjusts the “hands o” direction of the model

7TH. Trim adjusts the motor speed to stop at neutral

8Steering Dual Rate adjusts the amount the front wheels

move when the steering wheel is turned left and right

9BIND Button puts the transmitter into Bind Mode

10 ST. REV reverses the function of the steering

when the wheel is turned left or right

11 TH. REV reverses the function of the speed

control when pulled back or pushed forward

For more information on the trans-

mitter, go to www.horizonhobby.com

and click on the support tab for the

Spektrum DX2E to downloadthe

instruction manual.

CHANGING THE RF MODE

The DX2E has a France RF Mode that

complies with French regulations. The

DX2E must be in France mode when

used outdoors in France. At all other

times, the transmitter should be in

Standard mode.

France mode ON

Turn the wheel full left, pull the trigger

full throttle and hold down the bind

button while turning on the transmitter.

The green LED will ﬂash twice.

France mode OFF (Standard Mode)

Turn the wheel full right, pull the trigger

full throttle and hold down the bind

button while turning on the transmitter.

The green LED will ﬂash once.

SPEKTRUM DX2E RADIO SYSTEM

910 11

563

Your Spektrum Transmitter comes

prebound to the vehicle.

If you encounter problems, obey

binding instructions and refer to the

transmitter troubleshooting guide for

other instructions. If needed, contact

the appropriate Horizon Product

Support oce.

BINDING PROCEDURE

1Make sure the transmitter and vehicle are both powered OFF.

2Install a bind plug in the receiver battery/bind port. You

do not need to remove any of the other plugs to re-bind.

3With the bind plug installed, power ON the vehicle.

The receiver LED will ﬂash green.

4Move the steering wheel and throttle trigger to the failsafe

positions and continue to hold those postions until the

binding process is complete.

5Press the bind button on the transmitter while powering on

the transmitter. The green LED on the transmitter will ﬂash

after 4 seconds when the transmitter is in bind mode.

6Release the bind button after the red LED on the

transmitter ﬂashes. Continue holding the failsafe positions

until the receiver LED is solid. The green LED on the receiver

will glow solid when the transmitter and receiver are bound.

7Disconnect the battery from the ESC. Remove the bind plug

from the receiver. The receiver will keep the binding to the

transmitter until another binding is done.

TRANSMITTER AND RECEIVER BINDING / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

CONTROL TEST / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

Perform a control test with the vehicle

wheels o the ground. If the wheels

rotate after the vehicle is powered

ON, adjust the “TH. Trim” knob until

they stop. To make the wheels move

forward, pull the trigger. To reverse

them, wait for the wheels to stop,

then push the trigger. When moving

forward, the wheels should maintain

a straight line without any steering

wheel input. If not, adjust the “ST.

Trim” knob so the wheels maintain

a straight line without having to

turn the steering wheel.

BRAKE/REVERSE

FORWARD

The largest factor in run time is the

capacity of the battery pack. A larger

mAh rating increases the amount

of run time experienced.

The condition of a battery pack is

also an important factor in both run time

and speed. The battery connectors may

become hot during driving. Batteries will

lose performance and capacity over time.

Driving the vehicle from a stop to

full speed repeatedly will damage the

batteries and electronics over time.

Sudden acceleration will also lead

to shorter run times.

TO IMPROVE RUN TIMES

»Clean and oil bearings often. If bearings

are dirty, they will increase friction and

cause reduced performance.

»Keep your vehicle clean and maintained.

»Allow more airﬂow to the ESC

and motor.

»Change the gearing to a lower ratio.

A lower ratio decreases the operating

temperature of the electronics. Use

a smaller pinion gear or larger spur

gear to lower the gear ratio.

»Use a battery pack with a higher

mAh rating.

DRIVING PRECAUTIONS

»Maintain sight of the vehicle at all times.

»Routinely inspect the vehicle for loose

wheel hardware.

»Routinely inspect the steering assem-

bly for any loose hardware. Driving the

vehicle o-road can cause fasteners

to loosen over time.

»Do not drive the vehicle in tall grass.

Doing so can damage the vehicle

or electronics.

»Stop driving the vehicle when you

notice a lack of power. Driving the

vehicle when the battery is overly

discharged can cause the receiver to

power o. If the receiver loses power,

you will lose control of the vehicle.

»Do not apply forward or reverse throttle

if the vehicle is stuck. Applying throttle

in this instance can damage

the motor or ESC.

»After driving the vehicle, allow the

electronics to cool before driving the

vehicle again. Remove the body of

the vehicle to reduce cooling time.

RUN TIME / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

»Examine your vehicle on a regular basis.

»Use a brush to remove dirt and dust.

»Look for damage to the suspension arms

and other molded parts.

»Re-glue the tires to the wheels, if necessary.

»Clean and oil all wheel bearings.

»Use suitable tools to tighten fasteners.

»Make sure the camber and steering linkages

are not bent. Replace any bent linkages.

»Adjust the Toe and Camber settings, if necessary.

»Remove the shocks and inspect them for

damage. Rebuild the shocks if oil is leaking.

»Inspect electronics and batteries for exposed wires.

Repair exposed wires with shrink-wrap, or replace the wire.

»Make sure the ESC and receiver are secure on

the chassis. Replace the double-sided tape,

if necessary.

»Power ON the transmitter. If the green LED is dim

or o, replace the AA batteries in your transmitter.

»Check the spur gear and pinion gear for wear.

TUNING, ADJUSTING & MAINTAINING YOUR VEHICLE / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

SERVICE/REPAIR

If any problems other than those

covered in this manual arise, please

call the appropriate electronics service

department. Refer to the Warranty and

Service Information section for the ap-

propriate department to contact.

CLEANING

Performance can be hindered if dirt

gets in any of the moving suspension

parts. Use compressed air, a soft paint-

brush, or a toothbrush to remove dust

or dirt. Avoid using solvents or chemi-

cals as they can actually wash dirt into

the bearings or moving parts, as well as

cause damage to the electronics.

BEFORE RUNNING YOUR VEHICLE

1Check for free suspension

movement. All suspension arms

and steering components should

move freely. Any binds will cause

the vehicle to handle poorly.

2Charge the battery.

3Check the calibration of the ESC.

If recalibration is required, follow

the setup instructions.

4Adjust the transmitter settings

to your desired conﬁguration.

DYNAMITE LI-PO TAZER 12T WATERPROOF FORWARD/REVERSE ESC / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

SPECIFICATIONS

Operation Forward/Reverse with

Smart Brake, Forward Only

with Brake, Crawler Mode

Input Voltage 4- to 7-cell

(4.8–8.4 volts) DC

Peak Current 380A

Continuous Current 38A

Full-On Resistance 0.0028 Ohms

Frequency 1 kHz

BEC output 5.6 V DC, 1 amp max.

Motor Limit 12T

Overload Protection Thermal, Stall,

Over-Voltage

Dimensions 1.57 in x 1.57 in x 1.06 in

(46mm x 37mm x 28mm)

Weight 2.70 oz (76 g)

CONNECTING THE BATTERY

The Tazer 12T comes pre-wired with

an EC3 connector and is compatible

with most battery packs. Only use 4-cell

(4.8 volt) to 7-cell (8.4 volt) sub-C size

battery packs.

1Ensure the on/o switch is in the

OFF position.

2Connect a fully charged battery

pack to the ESC battery connector

ADJUSTING THE TRANSMITTER

Refer to your transmitter’s instructions

for speciﬁc information on transmitter

setup.

1Set the Throttle Reversing switch

to the NORMAL position. (This may

need to be reversed on some

brands of radios).

WARNING: This product can

become extremely hot when in use,

which could lead to burns.

FEATURES

»Li-Po, Ni-MH/Ni-Cd compatible

»3 user selectable modes—

Forward/reverse, Forward-only

race, and Crawler

»High-power FET control with

proportional forward and reverse

»High frequency design delivers

smooth speed transition

»Thermal Overload Protection

prevents damage due to over-

current conditions

»Pre-wired with EC3™battery plug

and bullet-style motor connectors

»Designed to operate with stock

motors (12 turns or higher)

»Waterproof

2Set the Throttle Trim to the

CENTER position.

3Set the Throttle Exponential

to MINIMUM or ZERO.

4Set the ATV to 100%.

5If your transmitter has an adjustable

trigger (or stick) position, move it to

the 70/30 position.

FACTORY DEFAULT SETTINGS

Battery Chemistry Type - Ni-MH

ESC Running Mode - Forward/Reverse

with Smart Brake

TRANSMITTER CONTROLLED

PROGRAMMING

1Power on the transmitter and set the

transmitter’s throttle endpoint travel

to maximum and the throttle trim

to the center position.

2Hold the throttle trigger at the

maximum forward position,

then power on the ESC.

3Continue holding the throttle trigger

at the maximum forward position

until a beep sounds and both red and

green LEDs ﬂash, then release the

throttle to neutralposition.

4The ESC is now in programming

mode. The ESC will cycle through its

programmable features in this order:

a Green Change Battery Chemis-

LED only try Type: Ni-MH or Li-Po

b Red Transmitter/ESC

LED only Endpoint Calibration

c Red + Change ESC Running

Green Mode: Forward/Reverse

LED with Smart Brake or

Forward Only with Brake

or Crawler Mode

5Move the throttle trigger to maximum

forward position and back to neutral

position at A, B or C in order to execute

the setting task.

a Change Battery Chemistry Type:

Ni-MH or Li-Po

•The respective LED will indicate the

current battery type for 4 seconds:

-Solid Green LED Ni-MH

-Solid Red LED Li-Po

•Move the throttle trigger to full

throttle and return to neutral within

the 4 seconds. A beep will sound and

the respective LED will indicate the

updated battery type.

•To change back to the previous

battery type, repeat the step above

within 4 seconds of the beep.

•Both the red and green LEDs

will ﬂash 3 times with 3 beeps.

•Power OFF the ESC and then power ON

the ESC to return to normal operation.

b Transmitter/ESC Enpoint Calibration

•After executing the setting task, the

green LED will ﬂash as you release

the throttle trigger to neutral. Once

neutral is reached, a beep will sound

and the green LED will glow solid for

1 second. The red LED will begin

to ﬂash.

•Move the throttle trigger to full throttle

and hold it until a beep sounds and

the red LED glows solid for 1 second.

Release the throttle trigger to neutral

and the red LED will glow solid while

the green LED will begin to ﬂash.

•Move the throttle trigger to full brake

/reverse and hold until a beep sounds

and the green LED glows solid.

•Release the throttle trigger to neutral.

Both red and green LEDs will ﬂash 3

times with 3 beeps.

• Power OFF the ESC and then power ON the ESC to return to normal operation.

OPERATION LED STATUS

waiting for throttle position position set

Neutral Flashing Green Solid Green (1 second)

Forward Flashing Red Solid Red (1 second)

Full Brake/Reverse Solid Red /Flashing Green Solid Green (1 second) followed by Red and Green ﬂashing 3x

c Change ESC Running Mode: Forward/

Reverse with Smart Brake Forward

Only with Brake or Crawler Mode

•The green LED will indicate the

currently selected ESC running

mode for 4 seconds:

-Green Forward/Reverse

LED Solid with Smart Brake

-Green LED Forward Only

Flashing with Brake

-Red + Green

LED Solid Crawler Mode*

• Move the throttle trigger to full throttle

within the 4 seconds to select the next

ESC mode. A beep will sound and the

green LED will indicate the new ESC

running mode.

• To select the next mode, repeat the

step above within 4 seconds of the

beep.

• Both red and green LEDs will ﬂash

3 times with 3 beeps.

• Power OFF the ESC and then power on

the ESC to return to normal operation

• At any time that the ESC is powered

and the transmitter is at neutral, the

green LED will indicate the current

running mode:

-Green Forward/Reverse

LED Solid with Smart Brake

-Green LED Forward Only

Flashing with Brake

-Red + Green

LED Solid Crawler Mode*

*NOTICE: Crawler mode is for use on

rocky surfaces only. Do not use this

mode with your vehicle on any other

surface, especially pavement. Doing

so may damage the vehicle.

SMART BRAKE

When the throttle is changed from

Forward to Reverse or Reverse to

Forward, the ESC will brake instead

of reversing the motor immediately.

The ESC will remain in brake mode

unless the throttle is returned to the

neutral/stop position for a short time.

DYNAMITE 15T BRUSHED MOTOR / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

PRECAUTIONS

»Never touch moving parts.

»Never disassemble while

the batteries are installed.

»Always let parts cool

before touching.

COMES WITH STD KIT

BRUSHED

MOTOR

RECOMMENDED

BRUSHLESS MOTOR

MOTOR MOUNT

PLATE POSITION

1st FINAL (2.66) TOTAL

GEAR RATIO MOTOR PLATE POSITIONPinion Spur Drive Ring

DYN1172

15 turn

motor

Brushless motor

10.5 turn or less

A22 77 12 32 9.33 STD 77T Spur Gear with

minimum Pinion Gear

B23 77 12 32 8.93

C24 77 12 32 8.56

D25 77 12 32 8.21

E26 77 12 32 7.90

F27 77 12 32 7.60

STD 77T Spur Gear with

max Pinion Gear

G28 77 12 32 7.33

H29 77 12 32 7.08

I30 77 12 32 6.84

A28 71 12 32 6.76 Optional 71T Spur Gear with

minimum Pinion Gear

B29 71 12 32 6.53

C30 71 12 32 6.31

Optional 71T Spur Gear

with max Pinion Gear

D31 71 12 32 6.11

E32 71 12 32 5.92

Brushless motor

13.5 turn

E38 65 12 32 4.56 Optional 65T Spur Gear

with minimum Pinion Gear

F39 65 12 32 4.44

G40 65 12 32 4.33

H41 65 12 32 4.23 Optional 65T Spur Gear

with max Pinion GearI42 65 12 32 4.13

VTR232044

VTR232050

TROUBLESHOOTING GUIDE / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

PROBLEM POSSIBLE CAUSE SOLUTION

Vehicle does

not operate

»Battery not charged or connected

»ESC switch not ON

»Transmitter not ON or low battery

»Charge battery/connect

»Turn ON ESC switch

»Turn ON/replace batteries

Motor runs but

rear wheels

don’t move

»Pinion not meshing with spur gear

»Pinion spinning on motor shaft

»Transmission gears stripped

»Drive pin broken

»Adjust pinion/spur mesh

»Replace pinion gear on motor

»Replace transmission gears

»Check and replace drive pin

Steering does

not work

»Servo plug not in receiver properly

»Servo gears or motor damaged

»Check if connected/all the way

»Replace or repair servo

Won’t turn in

one direction

»Servo gears damaged »Replace servo

Motor does

not run

»Motor plugs loose

»Motor wire broken

»ESC damaged

»Plug in completely

»Repair or replace as needed

»Contact Horizon Hobby Product Support

ESC gets hot »Motor over-geared

»Driveline bound up

»Use smaller pinion or larger spur gear on motor

»Check wheels, suspension and transmission for binding

Poor run time

and/or sluggish

acceleration

»Ni-MH pack not fully charged

»Charger not allowing full charge

»Motor worn out

»Driveline bound up

»Recharge battery

»Try another charger

»Replace motor

»Check wheels, transmission for binding

Poor range

and/or glitching

»Transmitter batteries low

»Vehicle battery low

»Loose plugs or wires

»Check and replace

»Recharge or replace

»Check all wire connections and plugs

WHAT THIS WARRANTY COVERS

Horizon Hobby, Inc. (“Horizon”) warrants to the original

purchaser that the product purchased (the “Product”)

will be free from defects in materials and workmanship

at the date of purchase.

WHAT IS NOT COVERED

This warranty is not transferable and does not cover (i)

cosmetic damage, (ii) damage due to acts of God, acci-

dent, misuse, abuse, negligence, commercial use, or due

to improper use, installation, operation or maintenance,

(iii) modiﬁcation of or to any part of the Product, (iv) at-

tempted service by anyone other than a Horizon Hobby

authorized service center, (v) Product not purchased

from an authorized Horizon dealer, or (vi) Product not

compliant with applicable technical regulations.

OTHER THAN THE EXPRESS WARRANTY ABOVE, HORI-

ZON MAKES NO OTHER WARRANTY OR REPRESENTA-

TION, AND HEREBY DISCLAIMS ANY AND ALL IMPLIED

WARRANTIES, INCLUDING, WITHOUT LIMITATION,

THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,

MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. THE PURCHASER ACKNOWLEDGES THAT

THEY ALONE HAVE DETERMINED THAT THE PRODUCT

WILL SUITABLY MEET THE REQUIREMENTS OF THE

PURCHASER’S INTENDED USE.

PURCHASER’S REMEDY

Horizon’s sole obligation and purchaser’s sole and

exclusive remedy shall be that Horizon will, at its option,

either (i) service, or (ii) replace, any Product determined

by Horizon to be defective. Horizon reserves the right

to inspect any and all Product(s) involved in a warranty

claim. Service or replacement decisions are at the sole

discretion of Horizon. Proof of purchase is required for

all warranty claims. SERVICE OR REPLACEMENT AS

PROVIDED UNDER THIS WARRANTY IS THE PURCHAS-

ER’S SOLE AND EXCLUSIVE REMEDY.

LIMITATION OF LIABILITY

HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDI-

RECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES,

LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL

LOSS IN ANY WAY, REGARDLESS OF WHETHER SUCH

CLAIM IS BASED IN CONTRACT, WARRANTY, TORT, NEG-

LIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF

LIABILITY, EVEN IF HORIZON HAS BEEN ADVISED OF

THE POSSIBILITY OF SUCH DAMAGES. Further, in no

event shall the liability of Horizon exceed the individual

price of the Product on which liability is asserted. As

Horizon has no control over use, setup, ﬁnal assembly,

modiﬁcation or misuse, no liability shall be assumed nor

accepted for any resulting damage or injury. By the act

of use, setup or assembly, the user accepts all resulting

liability. If you as the purchaser or user are not prepared

to accept the liability associated with the use of the

Product, purchaser is advised to return the Product

immediately in new and unused condition to the

place of purchase.

LAW

These terms are governed by Illinois law (without

regard to conﬂict of law principals). This warranty

gives you speciﬁc legal rights, and you may also have

other rights which vary from state to state. Horizon

reserves the right to change or modify this warranty

at any time without notice.

WARRANTY SERVICES

QUESTIONS, ASSISTANCE, AND REPAIRS

Your local hobby store and/or place of purchase cannot

provide warranty support or service. Once assembly,

setup or use of the Product has been started, you must

contact your local distributor or Horizon directly. This

will enable Horizon to better answer your questions

and service you in the event that you may need any

assistance. For questions or assistance, please visit

our website at www.horizonhobby.com, submit a

Product Support Inquiry, or call 877.504.0233 toll

free to speak to a Product Support representative.

INSPECTION OR SERVICES

If this Product needs to be inspected or serviced and

is compliant in the country you live and use the Product

in, please use the Horizon Online Service Request sub-

mission process found on our website or call Horizon to

obtain a Return Merchandise Authorization (RMA) num-

ber. Pack the Product securely using a shipping carton.

Please note that original boxes may be included, but are

not designed to withstand the rigors of shipping without

additional protection. Ship via a carrier that provides

tracking and insurance for lost or damaged parcels,

as Horizon is not responsible for merchandise until it

arrives and is accepted at our facility. An Online Service

Request is available at http://www.horizonhobby.com/

content/_service-center_render-service-center. If you

do not have internet access, please contact Horizon

Product Support to obtain a RMA number along with in-

structions for submitting your product for service. When

calling Horizon, you will be asked to provide your com-

plete name, street address, email address and phone

number where you can be reached during business

hours. When sending product into Horizon, please in-

clude your RMA number, a list of the included items, and

a brief summary of the problem. A copy of your original

sales receipt must be included for warranty consider-

ation. Be sure your name, address, and RMA number are

clearly written on the outside of the shipping carton.

NOTICE: Do not ship LiPo batteries to Horizon.

If you have any issue with a LiPo battery,

please contact the appropriate Horizon

Product Support oce.

WARRANTY REQUIREMENTS

For Warranty consideration, you must include

your original sales receipt verifying the proof-

of-purchase date. Provided warranty conditions

have been met, your Product will be serviced or

replaced free of charge. Service or replacement

decisions are at the sole discretion of Horizon.

LIMITED WARRANTY / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

NON-WARRANTY REPAIRS

Should your service not be covered by warranty,

service will be completed and payment will be

required without notiﬁcation or estimate of the ex-

pense unless the expense exceeds 50% of the retail

purchase cost. By submitting the item for service you

are agreeing to payment of the service without notiﬁca-

tion. Service estimates are available upon request. You

must include this request with your item submitted for

service. Non-warranty service estimates will be billed

a minimum of 1/2 hour of labor. In addition you will be

billed for return freight. Horizon accepts money orders

and cashier’s checks, as well as Visa, MasterCard,

American Express, and Discover cards. By submitting

any item to Horizon for service, you are agreeing to

Horizon’s Terms and Conditions found on our website

http://www.horizonhobby.com/content/_service-

center_render-service-center.

ATTENTION: Horizon service is limited to

Product compliant in the country of use and

ownership. If received, a non-compliant Product

will not be serviced. Further, the sender will be

responsible for arranging return shipment of the

un-serviced Product, through a carrier of the

sender’s choice and at the sender’s expense.

Horizon will hold non-compliant Product for

a period of 60 days from notiﬁcation, afer

which it will be discarded.

CONTACT INFORMATION

COUNTRY OF

PURCHASE

HORIZON HOBBY ADDRESS PHONE NUMBER / EMAIL ADDRESS

United States

of America

Horizon Service Center

(Electronics and engines)

4105 Fieldstone Rd

Champaign, Illinois

61822 USA

877-504-0233

productsupport@horizonhobby.com

Horizon Product Support

United

Kingdom

Horizon Hobby Limited Units 1-4 Ployters Rd

Staple Tye

Harlow, Essex

CM18 7NS

United Kingdom

+44 (0) 1279 641 097

sales@horizonhobby.co.uk

Germany Horizon Technischer

Service

Christian-Junge-Straße 1

25337 Elmshorn

+49 (0) 4121 2655 100

service@horizonhobby.de

France Horizon Hobby SAS 11 Rue Georges Charpak

77127 Lieusaint, France

+33 (0) 1 60 18 34 90

China Horizon Hobby - China Room 506

No. 97 Changshou Rd.

Shanghai, China 200060

+86 (021) 5180 9868

info@horizonhobby.com.cn

FCC STATEMENT / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

ANTENNA SEPARATION DISTANCE

When operating your Spektrum

transmitter, please be sure to maintain

a separation distance of at least 5 cm

between your body (excluding ﬁngers,

hands, wrists, ankles and feet) and the

antenna to meet RF exposure safety

requirements as determined by

FCC regulations.

The following illustrations show the

approximate 5 cm RF exposure area

and typical hand placement when

operating your Spektrum transmitter.

This device complies with part 15 of the

FCC rules. Operation is subject to the

following two conditions: (1) This device

may not cause harmful interference,

and (2) this device must accept any

interference received, including

interference that may cause

undesired operation.

CAUTION: Changes or

modiﬁcations not expressly

approved by the party responsible

for compliance could void the user’s

authority to operate the equipment.

DECLARATION OF CONFORMITY

(in accordance with ISO/IEC 17050-1)

No. HH2012120901

Product(s): VTR 2012 Chevrolet Camaro ZL-1 V100-S 1/10th RTR

Item Number(s): VTR03007

Equipment class: 2

The object of declaration described above is in conformity with the requirements

of the speciﬁcations listed below, following the provisions of the European R&TTE

directive 1999/5/EC, EMC Directive 2004/108/EC and LVD Directive 2006/95/EC:

EN 300-328 V1.7.1: 2006

EN 301 489-1 V1.7.1: 2006

EN 301 489-17 V1.3.2: 2008

EN 60950-1:2006+A11:2009+A1:2010+A12: 2011

EN 55022:2010 + AC:2011

EN 55024:2010

EN 61000-3-2:2006+A1:2009+A2:2009

EN 61000-3-3:2008

Signed for and on behalf of:

Horizon Hobby, Inc.

Champaign, IL USA

Decmeber 9, 2012

COMPLIANCE INFORMATION FOR THE EUROPEAN UNION / / / / / / /

Steven A. Hall

Executive Vice President and Chief Operating Ocer

International Operations and Risk Management

Horizon Hobby, Inc.

INSTRUCTIONS FOR DISPOSAL OF

WEEE BY USERS IN THE EUROPEAN UNION

This product must not be disposed of with other waste. Instead, it is the user’s

responsibility to dispose of their waste equipment by handing it over to a designated

collection point for the recycling of waste electrical and electronic equipment. The

separate collection and recycling of your waste equipment at the time of disposal

will help to conserve natural resources and ensure that it is recycled in a manner that

protects human health and the environment. For more information about where you

can drop o your waste equipment for recycling, please contact your local city oce,

your household waste disposal service or where you purchased the product.

This product contains a radio

transmitter with wireless technology

which has been tested and found to

be compliant with the applicable

regulations governing a radio

transmitter in the 2.400GHz to

2.4835GHz frequency range.

IC INFORMATION / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / / /

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not

cause interference, and (2) this device must accept any interference,

including interference that may cause undesired operation of the device.

Table of contents

Other Horizon Hobby Model Vehicle manuals

Horizon Hobby

Horizon Hobby Vaterra 1969 Chevrolet Camaro RS User manual

Horizon Hobby

Horizon Hobby Vaterra 1969 Chevrolet Corvette User manual

Popular Model Vehicle manuals by other brands

BSD-Racing

BSD-Racing BS801T instruction manual

Horizon Hobby Vaterra Chevrolet Camaro ZL1 2012 User manual

Popular Model Vehicle manuals by other brands
