IceQ IceQ48W User manual

Installation and Operating Instructions
MODEL:IceQ48W
A+ TABLE-TOP FRIDGE
This picture is for indicative purposes only. Actual models may display cosmetic
differences
Please read these instructions carefully before attempting to install or use this appliance.
It is advisable to keep these instructions in a safe place for future reference.
IceQ48S
IceQ48B
1
Introduction
Thank you for choosing this ICEQ appliance. It has been
designed to give years of trouble-free use provided it is installed
and maintained correctly.
Please read these instructions carefully before installing or using
your appliance. It is advisable to keep your purchase and installation
receipts with these instructions in a safe place for future reference.
Included is some important safety information in addition to
guidelines and recommendations that will enable you to take full
advantage of all the functions available.
This quality appliance has been tested and certified to meet all
applicable UK electrical and safety standards.
This appliance must be installed and connected in accordance
with current regulations by a qualified electrician.
After unpacking the appliance ensure that there is no visible
damage. If the appliance has been damaged during transit, do not
use it, contact your retailer immediately.
2
Description of the Appliance
1. Ice-Box
2. Thermostat Control Knob
3. Wire Shelf
4. Door Storage – Bottle Holder
5. Levelling Feet
1.
3.
2.
4.
5.
3
CONTENTS:
Section 1. Installation
Section 2. Safety Advice
Section 3. Operating the Appliance
Section 4. Maintenance
4
Section 1. Installation
IMPORTANT! This appliance must be left to stand in an upright position
for at least 4 hours before being switched on for the first time.
Remove all packaging and securing tape from the appliance.
Wash the interior of the appliance with luke warm water containing a
small amount of bicarbonate soda (5ml to 0.5 litres of water).
Position the appliance in a dry atmosphere and out of direct sunlight. Do
not sit it on top of another cooling appliance.
Do not position next to a cooker or other sources of heat, i.e. radiator.
If positioned next to another fridge or freezer, leave a minimum gap of
2cm between the appliances in order to avoid condensation.
A clearance of 50mm should be left above the appliance. If this cannot
be achieved you should ensure a clearance of 25mm is maintained on
each side of the appliance.
Fit the plastic wall spacers to the condenser on the rear of the appliance,
this will ensure an air gap between the appliance and the wall.
Do not place or store heavy items on the top of this appliance.
Ensure that the appliance is positioned on a firm flat floor.
This appliance must be level. Adjust the level by screwing the adjustable
feet up or down (use your fingers or a suitable spanner).
Ensure that the appliance is upright and both feet are in firm contact with
the floor so that the cabinet is stable.
Connect the plug to an adjacent 13amp socket outlet and ensure that the
appliance is not standing on the supply cable.
Section 2. Safety Advice
Please read this booklet thoroughly before installing and switching on the
appliance. The manufacturer accepts no responsibility for incorrect
installation and usage.
If this appliance is to replace an old refrigerator with a lock, as a safety
measure break or remove the lock and/or door before disposal.
Your old appliances contain insulation gases and refrigerant that must be
disposed of correctly. Please ensure that the refrigerant circuit is not
damaged before the appliance is taken away for correct disposal in line
with current legislation. If there is any doubt contact your Local Authority
for instructions.
This appliance may contain the refrigerant isobutene (R600a). This is a
natural gas with a high level of environmental compatibility; however,
caution is required as isobutene is a flammable gas. It is essential to ensure
5
that refrigerant tubes are not damaged during transportation and the
installation of the appliance. In the event that the refrigerant circuit is
damaged, avoid naked flames or sources of ignition and ventilate the room
in which the appliance is situated.
Do not damage the refrigerant circuit.
Do not allow children to play with the appliance. Children must never
play in or around the appliance.
If using an adaptor, this must be used in accordance with the
manufacturers instructions and ensure that the electrical circuit is not
overloaded as this could cause overheating.
Do not twist or bend the cables, and keep them away from hot surfaces.
Do not plug ın or unplug this appliance with wet hands.
Following installation make sure that the power cable is not trapped
underneath the appliance.
Section 3. Operating the Appliance
3.1. Switching on the Appliance
Allow the appliance to stand for a minimum of 4 hours after installation.
Plug in the appliance and switch on at the mains supply.
Set the thermostat control to the required setting as detailed in the
Temperature Control section (3.2.).
Leave the appliance for approximately 4 hours for the correct
temperature to be reached.
3.2. Temperature Control
The temperature control dial is located adjacent to the ice box and can be
adjusted by rotating the dial in a clockwise direction from ‘0’ to ‘6’.
Setting ‘Off’: Appliance switched off
Setting ‘1’: Warmest Temperature
Setting ‘3’ to ‘4’: Normal Operation (adequate for most situations)
Setting ‘6’: Coldest Temperature
Important!
During high ambient temperatures e.g. on hot summer days, it may be
necessary to set the thermostat to the coldest setting. This may cause the
compressor to run continuously in order to maintain a low temperature in the
cabinet.
3.3. Ice-Box
The ice-box can be used for the freezing and storage of small amounts of ice.
Please note: You cannot use this ice-box to store frozen food or freeze
any fresh food item.
6
3.4. Normal Operating Sounds
You may hear faint gurgling or bubbling sounds when the refrigerant is pumped
to the cooling system and through the coils or tubing at the rear of the
appliance. When the compressor is in operation you may hear a slight whirring
sound or pulsating noise. The thermostat controls the operation of the
compressor, and you may hear a slight click as it cycles in and out.
3.5. Energy Saving Advice
Do not install the appliance close to sources of heat, such as a cooker,
dishwasher or radiator.
Locate the appliance in a cool well-ventilated room and make sure that
the air vents are clear.
Try to avoid keeping the door open for a long time, warm air will enter the
cabinet and may cause a build up of ice as well as affecting the energy
consumption. Ensure there are no obstructions preventing the door from
closing properly.
Ensure that the door seal is clean and there are no tears or splits.
Do not put hot food into the freezer – let it cool down first.
3.6. In the Event of a Power Failure
If there is a power failure, keep the door closed. When the power has been
restored the appliance will start to operate but it may take some time to achieve
the pre-set operating temperature. Check the condition of your stored food
items and liquids.
Section 4. Maintenance
Before any maintenance or cleaning work is carried out, DISCONNECT the
appliance from the ELECTRICITY supply.
4.1. Internal Cleaning
Clean the interior and accessories with warm water and bicarbonate of soda
(5ml to 0.5 litre of water). Rinse and dry thoroughly. Do not use detergents,
abrasive powders, highly perfumed cleaning products, wax polishes or cleaning
products containing bleach or alcohol.
4.2. External Cleaning
Wash the outer cabinet with warm soapy water. Do NOT use abrasive
products. There may be sharp edges on the underside of the product, so care
should be taken when cleaning. Once or twice a year dust the rear of the
appliance and the compressor at the back of the appliance, with a brush or
vacuum cleaner, as an accumulation of dust will affect the performance of the
appliance and cause increased energy consumption.
7
4.3. Defrosting
If ice build up in the ice-box exceeds 3-5mm, empty the contents and switch off
the appliance, leave the door open and allow the ice to melt. Do not use sharp
objects to scrape the ice away. Clean and dry the interior, close the door and
turn on the power to the appliance. When the power has been restored the
appliance will start to operate but it may take some time to achieve the pre-set
operating temperature.
4.4. When the appliance is not in use
When the appliance is not in use for long periods, remove the contents,
disconnect from the electricity supply and clean the appliance, leaving the door
ajar until you wish to use the appliance again.
4.5. Reversing the door
To reverse the door opening from right hand hinged to left hand hinged, please
proceed as follows:
Remove the upper hinge cover, screws and hinge assembly
Lift the door off the lower hinge and set aside
Remove the screws and lower hinge assembly
Remove the adjustable foot from the lower left hand side
Remove the hinge and the adjustable foot assembly
from the lower hinge
8
Now fit the lower hinge assembly using the pre-drilled holes on the lower
left hand side of the cabinet and fit the foot to the r-hand side
Remove the plastic caps from the top left hand side and refit them into
the holes on the top right hand side
Remove the plastic cap from the top left hand side of the door and refit
into the hole on the top right hand side
Position the door onto the lower hinge assembly and refit the upper hinge
assembly .
Ensure that the door is correctly aligned and sealed, then tighten all the
screws and refit the upper hinge cover
4.6. What to do if something goes wrong
There is no power to the appliance:
Check there is not a power cut
Check there is power to the electric socket/appliance
Check the fuse in the plug (Must be 13 amp)
Check that the Temperature Control is set to “1” or above
The compressor runs continuously:
Is the door closed correctly?
Have large quantities of food recently been added to the appliance? – if
yes, allow the interior temperature to recover
Has the appliance door been opened frequently? – if yes, allow the
interior temperature to recover
Check that the Temperature Control has not been set to maximum (“6”)
There is excessive frost/ice build up:
Ensure that the door has been closed correctly
Ensure that the door seal is clean and sealing correctly
Check that the Temperature Control has not been set to maximum (“6”)
The appliance is making a noise:
Refer to Normal Operating Sounds, section 3.4.
Ensure that the appliance has been installed correctly (see section 1).
If after the above checks there is still a fault please contact your retailer.
9
Insurance
!
Any warranty provided with this product does
not
cover
loss
of
!
fridge/
freezer content
.
Any claim for loss, damage, costs or expenses of an indirect or consequential
nature including any economic loss or damage to foodstuffs or any other goods
is excluded. We recommend that you inspect your fridge/freezer regularly to
check that it is working correctly, losses can result from deterioration following
breakdown or accidental failure of the appliance, fuses, plugs or public
electricity supply, these can be covered by your standard home insurance or
might require extra cover. Check with your insurance provider.
Important Note:
This
appliance is
marked
according
to
the
European
directive
2002/96/EC
on
Waste
Electrical and
Electronic
Equipment
(WEEE).
By
ensuring
this
product
is
disposed
of
correctly,
you
will
help prevent
potential
negative
consequences
for
the
environment
and
human
health,
which
could
otherwise
be
caused
by
inappropriate
waste
handling
of
this
product.
The
symbol
on
the
product,
or
on
the
documents
accompanying
the
product,
the
Crossed
Out Wheelie
Bin,
indicates
that
this
appliance may
not
be
treated
as
household
waste. Instead
it
shall
be
handed
over
to
the
applicable
collection
point
for
the
recycling
of
electrical
and electronic
equipment.
Disposal
must
be
carried
out
in
accordance
with
local
environmental
regulations
for
waste
disposal.
For
more
detailed
information
about
treatment,
recovery
and
recycling
of
this product,
please
contact
your
local
authority,
your
household
waste
disposal
service
or
the
retailer
where
you purchased
the
product.
We
continuously
try
to
improve
our
products
for
the
benefit
of
our
customers.
For
this
reason
we
reserve
the
right
to
make
changes
to
any
product
at
any
time,
without
notice
Issue: 01/27-02-2012

This manual suits for next models

2

Other IceQ Refrigerator manuals

IceQ IceQ48S User manual

IceQ

IceQ IceQ48S User manual

IceQ ICEQ4SB User manual

IceQ

IceQ ICEQ4SB User manual

IceQ IceQ43B User manual

IceQ

IceQ IceQ43B User manual

IceQ IceQ70W User manual

IceQ

IceQ IceQ70W User manual

Popular Refrigerator manuals by other brands

Hanseatic HEKS12254E user manual

Hanseatic

Hanseatic HEKS12254E user manual

Haier HRF-183 Manual de servico

Haier

Haier HRF-183 Manual de servico

Progress PK1201 user manual

Progress

Progress PK1201 user manual

NEFF KI1412FE0G INFORMATION FOR USE

NEFF

NEFF KI1412FE0G INFORMATION FOR USE

Hisense LCT43D6ASE owner's manual

Hisense

Hisense LCT43D6ASE owner's manual

Frigidaire PLHT189SS Factory parts catalog

Frigidaire

Frigidaire PLHT189SS Factory parts catalog

AMERICANA 16 Owner's manual and installation instructions

AMERICANA

AMERICANA 16 Owner's manual and installation instructions

Whirlpool W10175487A User instructions

Whirlpool

Whirlpool W10175487A User instructions

LG GSJV71MCTE owner's manual

LG

LG GSJV71MCTE owner's manual

KLUGE KC2294J user manual

KLUGE

KLUGE KC2294J user manual

Quest Engineering Atlantic E0014 Troubleshooting and warranty

Quest Engineering

Quest Engineering Atlantic E0014 Troubleshooting and warranty

Whirlpool WRF736SDAB Energy guide

Whirlpool

Whirlpool WRF736SDAB Energy guide

Sub-Zero 200 Series installation guide

Sub-Zero

Sub-Zero 200 Series installation guide

Kenmore Kenmore Side by Side Refrigerator Use & care guide

Kenmore

Kenmore Kenmore Side by Side Refrigerator Use & care guide

Amica GS15470W instruction manual

Amica

Amica GS15470W instruction manual

KitchenAid KTRC22ELBL01 parts manual

KitchenAid

KitchenAid KTRC22ELBL01 parts manual

Jenn-Air W10297654A installation guide

Jenn-Air

Jenn-Air W10297654A installation guide

Delfield 4427N-9M Specifications

Delfield

Delfield 4427N-9M Specifications

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
