Hisense LCT43D6ASE User manual

Owner’ s manual
Compact Double Door Refrigerator
Model:LCT43D6ASE
LCT43D6AVE

© 2015 Hisense Company Ltd. All Rights Reserved.
All material in this Owner's Manual is the property of Hisense
Company Ltd. and its subsidiaries, and is protected under US and
in any manner, electronic, print, or otherwise, without the prior
or distributed, in whole or in part, in any manner, electronic or
Requests for permission to store, reproduce, transmit or distribute
materials may be made to the following address:
PO Box 3289
Suwanee, GA 30024
Hisense, and any and all other Hisense product names, logos, slogans
or marks are registered trademarks of Hisense Company Ltd. and its
holders.
COPYRIGHT STATEMENT

appliance, unless they are of the type recommended by the manufacturer.
21. WARNING: Do not use electrical appliances inside the food storage compartments of the
20. WARNING: Do not damage the refrigerant circuit.
clear of obstruction.
19. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure,
1
This appliance is not intended for use by persons (including children) with
reduced physical,sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure their do not play with the appliance
pertaining to the installation, handing, servicing
For compression-type appliances which use flammable refrigerants, instructions
shall include information
4
6
22

2
22. WARNING: Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
Appliances which use flammable insulation blowing gases instructions shall include
information regarding disposal of the appliance
Instructions shall contain the substance of the following;
Do not use extension cords or ungrounded (two prong) adapters
This product should not be disposed with other household wastes.
To prevent possible harm to the environment or human health from uncontrolled waste
disposal recycles it responsibly to promote the sustainable reuse of material resources.
To return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling
WARNING! Refrigerators contain refrigerant and gases in the insulation.
Refrigerant and gases must be disposed of professionally as they may cause eye
injuries or ignition Ensure that tubing of the refrigerant circuit is not
damage prior to proper disposal.

Do not use extension cords or ungrounded(two
prong) adapters.
3

4

5
1.Freezer Compartment
2.Freezer Shelf
3.Light Bulb(Behind Thermostat)
4.Thermostat Control Knob
5.Refrigerator Shelf
6.Refrigerator Compartment
1.Freezer Compartment
2.Freezer Shelf
3.Light Bulb(Behind Thermostat)
4.Thermostat
5.Refrigerator Control Knob
6.Refrigerator Compartment
7.Crisper Drawer
8.Freezer Door Gasket
9.Refrigerator Door Gasket
10.Upper Shelf
11.Middle Shelf
12.Down Shelf
8.Freezer Door Gasket
7.Crisper Drawer
12.Down Shelf
11.Middle Shelf
10.Upper Shelf
9.Refrigerator Door Gasket

6
0
0

7
Warning: The LED light must not be replaced by the user!
If the LED light is damaged, contact the customer helpline
for assistance. To replace the LED light, the below steps
can be followed:
1 .Unplug your appliance.
2. Remove light cover by pushing and prying.
3. Remove screw cover and unscrew the controller box.
4. Replace LED light and snap it correctly in place.

The side at which the door opens can be
changed from the right side (as supplied) to
the left side, if the installation site requires.
Tools you will need:
. 8mm socket driver
.
Note: Before this step, you should lay the refrigerator
on it’s back in order to gain access to the base, you
should rest it on soft foam packaging or similar
material to avoid damaging the cooling pipes at the
rear of the refrigerator.
.
2. open the screw hole cove and the upper
hinge cover which is at the top right corner of
the refrigerator. upper hinge
cover (right)
1. Stand the refrigerator, open the upper
door and remove the things in the door and
close it.
3.Unscrew the special flange self-tapping
screws which are used for fixing the right
upper hinge part by a 8mm socket driver
or a spanner(please support the upper
door with your hand when doing it ).
right upper hinge part
special flange
selftapping screws
5.Remove upper door and place it on
smooth surface with panel upwards.
6. Loose screws used to fix middle hinge
and remove middle hinge. Then turn middle
hinge by 180. Take washer on axis and put
it on another end. Place it well for use.
7. Remove lower door and place panel
upwards on smooth surface.
8. Change screw hole covers on middle
cover plate from left to right (as shown in
figure below).
Front foot fixed board
Self tapping screws
Adjustable bottom feet part
Lower hinge paΰrt rightα
4.Remove the right upper hinge part and
, the screw hole cover place them on
smooth surface.
screw hole cover
. 7mm wrench and 6mm wrench
Caution:
To avoid to injury yourself and/or property,
we recommend someone assist you during
the door reversal process.
.Ensure the Appliance is unplugged and
empty.
.Following steps are generally
recommended
Changing the door from the right side to the left.
8
phillips screwdrivers
Putty Knife or slotted srewdrivers
Parts you will need ,parts are from the package of manual
door stopper door stop

10. Change lower hinge part to left and front
foot fixed board to right and fix them with
screws. Then install adjustable bottom feet
parts.
Lower hinge part (left)
ower
door and adjust its position to align lower
hole(left) site and lower hinge axis. Then
adjust middle hinge and align the middle
hinge axis to the higher (left) hole site. Then
install the middle hinge.
Stand the refrigerator then
Note: washer may
stick to lower door. Washer
13. Replace and the right upper hinge Install
cover on the left corner, Replace the screw
hole cover on the right corner.
14.Stand and level the appliance.
NOTE:
Before the appliance is powered, We
recommend that you should wait for about
.
2 hours
9
11.Remove the door stop (right) and
door stopper (right) with
,Install the door stopper(left) and
door stop (left) which are from the package
of user's manual
move l
Phillips screwdrivers
