IDEC DD3S Series User manual

Display Units
DD3S Series DD48 Series
DD96 Series

2
Series DD3S DD48 DD96
Shape
Unit Type Binary Decimal/Hexadecimal/Extra Decimal Character Display Binary Decimal Decimal
Display Part (mm)
+, –, 1
Red or green LED
7-segment
Red LED, Green LED
Red/green 2-color alternate LED
Notes:
The red and green colors of the
single color LEDs are different
from those of the 2-color
alternate display.
Red LED
– (minus)
Red or green LED
7-segment
Red or green LED 7-segment
Red LED
Display Character +, –, 1
decimal point
Decimal display unit: 0 to 9, decimal point
Hexadecimal display unit: 0 to F, decimal point
Extra decimal display unit: 0 to 9, –, –, –, =, =, decimal point
254 characters – (minus) 0 to 9
Decimal point
0 to 9
Decimal point
Function Standard Standard 2-color alternate Zero-suppress — — — —
Input
+, –, 1
Latch
BL
LT
DP
Binary
Latch
BL
LT
DP
Binary
Latch
R/G
BL
DP
Binary
Latch
BL
LT
RBI
DP
Data (8-bit) input
Latch
BL
–
Latch
BL
Binary
Latch
DP
RBI
Binary
Latch
DP
BI
Output — — — RBO — — RBO BO
Input Logic Positive or negative Positive or negative Negative
Data Input Level L: 0 to 2V
H: 9 to 30V
L: 0 to 2V
H: 12 to 30V
L: 0 to 2V
H: 12 to 30V
Power Voltage 12 to 24V DC ±10% 24V DC ±10% 24V DC ±10%
Current Draw
(Power Consumption)
(approx.)
Red: 35 mA max.
Green: 50 mA max.
Red: 40 mA max.
Green: 60 mA max. 60 mA max. Red: 40 mA max.
Green: 60 mA max. 65 mA max. 0.9W 2.0W 80 mA
No. of Digits 8 digits max. (1 digit/unit) 16 digits max. (1 digit/unit) 8 digits max. (1 digit/unit)
Panel Mounting Front mount, snap t Front mount, snap t Front mount: Snap t
Rear mounting: Screw mounting
Housing Color Black (End plate: black) Black or beige Black
Connector
•Solder terminal, PC board terminal, wire-wrap terminal (optional)
•Mother board: Dynamic (4- or 2-digit, optional)
Static (4-, 3-, or 2-digit, optional)
•Mother board: 4 digits (optional)
(For character display) •Solder terminal, PC board terminal (optional)
•Mother board: 4-digit (optional) for mounting binary and decimal units
•Solder terminal (supplied)
Dimensions 33H ×20W ×45.5D mm/unit 48H ×30W ×79D mm/unit Front mount: 96H ×72W ×42.5D mm/unit
Rear mount: 90H ×72W ×41D mm/unit
Weight (approx.) Display unit: 16.0g
End plates (pair): 4.5g
Display unit: 50g
End plates: 20g (pair)
Front mount: 130g
Rear mount: 100g
End plates: 26g (pair)
See Page 4 through 18 19 through 26 27 through 30
Front Mount
Rear Mount
6.2
6.2
33
13.2
20
33
20
8.8
14.2
33
20
17.8
12.7
48
30
2.5
11.1
25.4
14
48
30
57 96
33
72
Display Units (Selection Guide)

3
Series DD3S DD48 DD96
Shape
Unit Type Binary Decimal/Hexadecimal/Extra Decimal Character Display Binary Decimal Decimal
Display Part (mm)
+, –, 1
Red or green LED
7-segment
Red LED, Green LED
Red/green 2-color alternate LED
Notes:
The red and green colors of the
single color LEDs are different
from those of the 2-color
alternate display.
Red LED
– (minus)
Red or green LED
7-segment
Red or green LED 7-segment
Red LED
Display Character +, –, 1
decimal point
Decimal display unit: 0 to 9, decimal point
Hexadecimal display unit: 0 to F, decimal point
Extra decimal display unit: 0 to 9, –, –, –, =, =, decimal point
254 characters – (minus) 0 to 9
Decimal point
0 to 9
Decimal point
Function Standard Standard 2-color alternate Zero-suppress — — — —
Input
+, –, 1
Latch
BL
LT
DP
Binary
Latch
BL
LT
DP
Binary
Latch
R/G
BL
DP
Binary
Latch
BL
LT
RBI
DP
Data (8-bit) input
Latch
BL
–
Latch
BL
Binary
Latch
DP
RBI
Binary
Latch
DP
BI
Output — — — RBO — — RBO BO
Input Logic Positive or negative Positive or negative Negative
Data Input Level L: 0 to 2V
H: 9 to 30V
L: 0 to 2V
H: 12 to 30V
L: 0 to 2V
H: 12 to 30V
Power Voltage 12 to 24V DC ±10% 24V DC ±10% 24V DC ±10%
Current Draw
(Power Consumption)
(approx.)
Red: 35 mA max.
Green: 50 mA max.
Red: 40 mA max.
Green: 60 mA max. 60 mA max. Red: 40 mA max.
Green: 60 mA max. 65 mA max. 0.9W 2.0W 80 mA
No. of Digits 8 digits max. (1 digit/unit) 16 digits max. (1 digit/unit) 8 digits max. (1 digit/unit)
Panel Mounting Front mount, snap t Front mount, snap t Front mount: Snap t
Rear mounting: Screw mounting
Housing Color Black (End plate: black) Black or beige Black
Connector
•Solder terminal, PC board terminal, wire-wrap terminal (optional)
•Mother board: Dynamic (4- or 2-digit, optional)
Static (4-, 3-, or 2-digit, optional)
•Mother board: 4 digits (optional)
(For character display) •Solder terminal, PC board terminal (optional)
•Mother board: 4-digit (optional) for mounting binary and decimal units
•Solder terminal (supplied)
Dimensions 33H ×20W ×45.5D mm/unit 48H ×30W ×79D mm/unit Front mount: 96H ×72W ×42.5D mm/unit
Rear mount: 90H ×72W ×41D mm/unit
Weight (approx.) Display unit: 16.0g
End plates (pair): 4.5g
Display unit: 50g
End plates: 20g (pair)
Front mount: 130g
Rear mount: 100g
End plates: 26g (pair)
See Page 4 through 18 19 through 26 27 through 30
Front Mount
Rear Mount
6.2
6.2
33
13.2
20
33
20
883
14.2
33
20
17.8
12.7
48
30
2.5
11.1
25.4
14
48
30
57
96
33
72
Display Units (Selection Guide)

4
DD3S Series Display Units
7-segment digital display and 5 × 7 dot matrix character display units
Super bright LED display and short body for up to 8 digits
•Super bright LED for easy reading
•Units can be combined together and installed into a panel
cut-out.
•Binary, decimal, hexadecimal, extra decimal, and character
display units are available.
•The character display unit uses 5 × 7 dot matrix LEDs and
can display 254 characters, including katakana, symbols,
units, and simple kanji characters, as well as numbers and
alphabets.
•Positive or negative input logic
•Easy wiring and maintenance
•Power voltage 12 through 24V DC.
•Mother boards are available for dynamic and static display
modes; substantial saving of wiring.
DD3S
Display Units (Housing Color: Black)
Notation Function Input Logic LED Color Part No.
Binary Standard
Positive Red DD3S-F01P-R
Green DD3S-F01P-G
Negative Red DD3S-F01N-R
Green DD3S-F01N-G
Decimal
Standard
Positive Red DD3S-F31P-R
Green DD3S-F31P-G
Negative Red DD3S-F31N-R
Green DD3S-F31N-G
2-color Alternate Positive R/G DD3S-F31P-RG
Negative R/G DD3S-F31N-RG
Zero-suppress
Positive Red DD3S-F31P-R-S
Green DD3S-F31P-G-S
Negative Red DD3S-F31N-R-S
Green DD3S-F31N-G-S
Extra Decimal
Standard
Positive Red DD3S-F34P-R
Green DD3S-F34P-G
Negative Red DD3S-F34N-R
Green DD3S-F34N-G
2-color Alternate Positive R/G DD3S-F34P-RG
Negative R/G DD3S-F34N-RG
Zero-suppress
Positive Red DD3S-F34P-R-S
Green DD3S-F34P-G-S
Negative Red DD3S-F34N-R-S
Green DD3S-F34N-G-S
Hexadecimal
Standard
Positive Red DD3S-F36P-R
Green DD3S-F36P-G
Negative Red DD3S-F36N-R
Green DD3S-F36N-G
2-color Alternate Positive R/G DD3S-F36P-RG
Negative R/G DD3S-F36N-RG
Zero-suppress
Positive Red DD3S-F36P-R-S
Green DD3S-F36P-G-S
Negative Red DD3S-F36N-R-S
Green DD3S-F36N-G-S
Character Display Positive Red DD3S-F57P-R
Negative Red DD3S-F57N-R
Ordering Information
1. Specify the Part No. and quantity of the display units and accessories.
(Example)Display Unit DD3S-F31P-R 8 pcs
Accessories
  •SpacerUnit DD9Z-FY1-B 1pc
  •EndPlate DD9Z-W-B 1set
  •MotherBoard DD9Z-MB1-4 2pcs
2. Order spacer units, end plates, and mother boards separately.
See the next page.

5
DD3S Series Display Units
Accessories (Optional)
Name Part No.
Spacer Unit Black DD9Z-FY1-B
End Plate (pair) Black DD9Z-W-B
Connector Solder Terminal DMC-1
PC Board Terminal DMC-2
Retentive/One-way
Insertion Connector Solder Terminal DD9Z-CN1
Connector Stopper DD9Z-ST1
Mother Board
for binary/decimal/hex/
extra decimal display
unit
Dynamic 4-digit DD9Z-MB1-4
2-digit DD9Z-MB1-2
Static
4-digit DD9Z-MB2-4
3-digit DD9Z-MB2-3
2-digit DD9Z-MB2-2
Mother Board
for 5 × 7 dot matrix
character display unit
(with spacer)
4-digit DD9Z-MB3-4
Mother Board
Connector
Type A DD9Z-JE1A
Type B DD9Z-JE1B
Type C DD9Z-JE1C
Coupling Spacer
for IDEC DG Series
Digital Switches
Right Side Black DD9Z-FG1R-B
Left Side Black DD9Z-FG1L-B
Cable Length Code
Specify a cable length code in place of in the Part No. of mother
board cable types A, B, and C. These cables can be used for both
dynamic and static type mother boards.
Code 01 02 03 05 10
Cable Length (mm) 100 200 300 500 1000
Code 15 20 30 40 50
Cable Length (mm) 1500 2000 3000 4000 5000
Specifications
Power Voltage 12 to 24V DC ±10%
Current Draw
Binary 35 mA max. (red)
50 mA max. (green)
Decimal/
Hex/
Extra decimal
40 mA max. (red)
60 mA max. (green)
2-color: 60 mA max. (green)
Character
Display 65 mA max.
Data Input Level L: 0 to 2V
H: 9 to 30V
Display
Character
(see Function
Tables)
•Binary display unit
Red or green LED: +, –, 1, decimal point
•Decimal display unit
7-segment 1-color (red or green), 2-color
(red/green) LED: 0 to 9, decimal point
•Hexadecimal display unit
7-segment 1-color (red or green), 2-color
(red/green) LED: 0 to 9, A to F, decimal point
•Extra decimal display unit
7-segment 1-color (red or green), 2-color
(red/green) LED: 0 to 9, –, –, –, =, =, decimal
point
Character Height
•Binary display unit: 15 mm
•Decimal/Hex/Extra Decimal display units:
15.2 mm (2-color: 15 mm)
•Character display unit: 17.8H × 12.7W mm
Input
•Binary display unit
+, –, 1, Latch, BL, LT, DP
•Decimal/Hex/Extra Decimal display units:
<Standard>
Binary, Latch, BL, LT, DP
<Zero-suppress>
Binary, Latch, BL, LT, DP, RBI
<2-color>
Binary, Latch, BL, R/G, DP
•Character display unit: D0 to D7, Latch, BL
Output
•Decimal/Hex/Extra Decimal display units:
<Zero-suppress>
RBO output
Input Logic Positive or negative
No. of Digits 8 digits max.
Unit
Combination Snap t
Panel Mounting Snap t
Dielectric
Strength
•Binary/Decimal/Hex/Extra decimal display
units
Between live and dead parts :
1500V DC, 1 minute
•Character display unit
Between live and dead parts :
1000V AC, 1 minute
Insulation
Resistance
Between live and dead parts :
100 MΩ min. (500V DC megger)
Vibration
Resistance
(damage limits)
10 to 55 Hz, amplitude 0.25 mm
Shock
Resistance
(damage limits)
490 m/s²
Noise
Resistance
(operating
extremes)
•Binary/Decimal/Hex/Extra decimal display
unit
Power terminal (normal/common modes):
±1000V
Input terminal (normal/common modes):
±1000V
Output terminal (normal/common modes):
±500V
(Impulse condition: Pulse width 100 ns,
1 μs)
•Character display unit
Fast transient burst noise
Power supply: 2 kV, Signal: 1 kV
(IEC61000-4-4 capacitive clamp)
Operating
Temperature –10 to +55°C (no freezing)
Storage
Temperature –25 to +80°C (no freezing)
Operating
Humidity 35 to 85% RH (no condensation)
Power Inrush
Current
•Binary/Decimal/Hex/Extra decimal display
unit
Approx. 2.0A (Power voltage: 24V)
•Character display unit
Approx. 1.0A (Power voltage: 24V)
Degree of
Protection IP40 (IEC60529)
Weight (Approx.) •Display unit: 16g
•End plates: 4.5g (pair)

6
DD3S Series Display Units
Terminal Connection
Connection Diagram Terminal Arrangement Internal Input Circuit
Binary Display Unit
Standard Standard
Decimal/Hexadecimal/Extra Decimal Display Units
Standard Standard
Positive Logic
2-color Alternate Display 2-color Alternate Display Negative Logic
Zero-suppress Zero-suppress
Character Display Unit
Positive Logic
Negative Logic
(Terminal No.)
Power
+
–
1
Vcc
GND
Latch
BL
LT
DP
4
12
8
10
9
5
7
6
2
Regulating Circuit
Input Circuit
Decoder
1. NC
12. GND
11. NC
10. +
+
9.
8. Latch
7. BL
6. LT
5. 1
4. Vcc
3. NC
2. DP
−
–
Power
12 to 24V DC
(Terminal No.)
Vcc
GND
Latch
A (2 )
B (2 )
C (2 )
D (2 )
BL
LT
DP
4
12
8
10
3
5
9
7
6
2
1
2
3
0
(Terminal No.)
Power
Regulating Circuit
Input Circuit
Decoder
1. NC
12. GND
11. NC
10. A (2 )
9. D (2 )
8. Latch
7. BL
6. LT
5. C (2 )
4. Vcc
3. B (2 )
2. DP
0
3
2
1
(Terminal No.)
+
−
Power
12 to 24V DC
200 kΩ
200 kΩ
12 kΩ
Data Input
GND
Vcc
GND
Latch
BL
R/G
DP
4
12
8
10
3
5
9
7
6
2
(Terminal No.)
Power
Regulating Circuit
Input Circuit
Decoder
A (2 )
B (2 )
C (2 )
D (2 )
1
2
3
0
1.
12.
11.
10.
9.
8.
7.
6. R/G
5.
4.
3.
2.
NC
GND
NC
A (2 )
D (2 )
Latch
BL
C (2 )
Vcc
B (2 )
DP
0
3
2
1
(Terminal No.)
+
−
Power
12 to 24V DC
200 kΩ
200 kΩ
12 kΩ
Data Inpu
t
GND
12 to 24V DC
Vcc
GND
Latch
BL
LT
RBI
RBO
DP
4
12
8
10
3
5
9
7
6
1
11
2
(Terminal No.)
Power
Regulating Circuit
Input Circuit
Decoder
A (2 )
B (2 )
C (2 )
D (2 )
1
2
3
0
1. RBI
12.
11. RBO
10.
9.
8.
7.
6.
5.
4.
3.
2.
GND
A (2 )
D (2 )
Latch
BL
LT
C (2 )
Vcc
B (2 )
DP
0
3
2
1
(Terminal No.)
+
−
Power
12 to 24V DC
Power
Control Input
Regulating Circuit
Input Circuit
Microprocessor
Data Input
Driver
5 x 7 dot matrix LED
(Terminal No.)
Latch
Power
Data Input
(Terminal No.)
Control Input Latch
470 kΩ
470 kΩ
12 kΩ
Data Inpu
t
GND
470 kΩ
470 kΩ
12 kΩ
Data Inpu
t
GND
12 to 24V DC

7
DD3S Series Display Units
External Wiring
Binary/Decimal/Hexadecimal/Extra Decimal Display Units
Positive Logic
[Contact Input (Digital Switch)] [Transistor Input]
A
Power
D
NC
NC
Latch
−
Vcc (+)
GND (–)
Data
Input
+
A
D
NC
NC
Latch Latch
Tr
Tr
R1
Tr
R2
Tr
R2
R1
A
D
NC
NC
+V+V
Power
−
Vcc (+)
GND (–)
Data
Input
Vcc (+)
GND (–)
Data
Input
+
Power
−
+
When Tr is on, output goes to H. When Tr is off, output goes to H.
Negative Logic
[Contact Input (Digital Switch)] [Transistor Input]
A
D
NC
NC
Latch
Power
−
Vcc (+)
GND (–)
Data
Input
+
A
D
NC
NC
Latch
Tr
Tr
R3
Tr
R1
Tr R1
R3
+V+V
A
D
NC
NC
Latch
Power
−
Vcc (+)
GND (–)
Data
Input
Vcc (+)
GND (–)
Data
Input
+
Power
−
+
When Tr is on, output goes to L. When Tr is off, output goes to L.
Note: When connecting pull-up or pull-down resistors to the external circuit, refer to the resistor
values shown below:
R1: 2.2 kΩ (1/2W) to 10 kΩ (1/4W)
R2: 1 kΩ (1W) to 2.2 kΩ (1/2W)
R3: 1 kΩ (1W)
Character Display Units
Positive Logic
[Contact Input (Digital Switch)] [Transistor Input]
Power
Power
Tr
Tr
R1
R1
+V +V
When Tr is on, output goes to H. When Tr is off, output goes to H.
Power
R2
R2
Tr
Tr
−
Vcc (+)
GND (–)
Vcc (+)
GND (–)
Vcc (+)
GND (–)
Data
Input
Data
Input
Data
Input
+
Latch
D0
D7
NC
NC
Latch Latch
D0
D7
NC
NC
D0
D7
NC
NC
Negative Logic
[Contact Input (Digital Switch)] [Transistor Input]
Power
Power Power
When Tr is on, output goes to L. When Tr is off, output goes to L.
Vcc (+)
GND (–)
Vcc (+)
GND (–)
Vcc (+)
GND (–)
Data
Input
Data
Input
Data
Input
Latch
Latch Latch
D0
D7
NC
NC
D0
Tr
R1
Tr R1
D7
NC
NC
D0
D7
+V+V
Tr
R3
Tr
NC
NC
Note: When connecting pull-up or pull-down resistors to the external circuit, refer to the resistor
values shown below:
R1: 2.2 kΩ (1/2W) to 10 kΩ (1/4W)
R2: 1 kΩ (1W) to 2.2 kΩ (1/2W)
R3: 1 kΩ (1W)
12
10
8
6
4
2
11
9
7
5
3
1
UP Making Side
Connector
Terminal No.
(DMC-1)
Connector Terminal No.

8
DD3S Series Display Units
Function Table
Binary Display Unit (Standard)
Data Input
LED
Display
Positive Logic Negative Logic
1 + – Latch LT BL DP 1 + – Latch LT BL DP
× × × × H × × × × × × L × × +1.
× × × × L H × × × × × H L × blank
× × × × L L H × × × × H H L *.
L L L L L L L H H H H H H H blank
L L H L L L L H H L H H H H
-
L H × L L L L H L × H H H H +
H L L L L L L L H H H H H H 1
H L H L L L L L H L H H H H
- 1
H H × L L L L L L × H H H H +1
× × × H L L L × × × L H H H maintain
Note 1: × indicates the display is not affected by voltage level of H or L.
Note 2: * A decimal point is displayed with any character.
Input Functions
1, +, and – Inputs
When the 1, +, or – input is set to level H for the positive
logic or level L for the negative logic, the 1, +, or – display
is turned on, respectively.
Latch Input
When the Latch input is set to level H for the positive logic
or level L for the negative logic, the 1, +, or – display at the
time is maintained. (DP input is independent.)
LT (Light Test) Input
When the LT input is set to level H for the positive logic or
level L for the negative logic, the entire display turns on.
BL (Blank) Input
When the BL input is set to level H for the positive logic
or level L for the negative logic, the entire display turns off
regardless of other inputs.
DP (Decimal Point) Input
When the DP input is set to level H for the positive logic or
level L for the negative logic, the decimal point turns on.
Decimal/Hexadecimal/Extra Decimal Display Units
(Standard, 2-color Alternate, and Zero-suppress)
Data Input LED Display
Positive Logic Negative Logic Dec. Hex. Extra
Dec.
D C B A Latch LT BL DP D C B A Latch LT BL DP
× × × × × H × × × × × × × L × × 8. 8. 8.
× × × × × L H × × × × × × H L × blank blank blank
× × × × × L L H × × × × × H H L *. *. *.
L L L L L L L L H H H H H H H H 0 0 0
L L L H L L L L H H H L H H H H 1 1 1
L L H L L L L L H H L H H H H H 2 2 2
L L H H L L L L H H L L H H H H 3 3 3
L H L L L L L L H L H H H H H H 4 4 4
L H L H L L L L H L H L H H H H 5 5 5
L H H L L L L L H L L H H H H H 6 6 6
L H H H L L L L H L L L H H H H 7 7 7
H L L L L L L L L H H H H H H H 8 8 8
H L L H L L L L L H H L H H H H 9 9 9
H L H L L L L L L H L H H H H H blank A –
H L H H L L L L L H L L H H H H blank b _
H H L L L L L L L L H H H H H H blank C
¯
H H L H L L L L L L H L H H H H blank d =
H H H L L L L L L L L H H H H H blank E =
H H H H L L L L L L L L H H H H blank F blank
× × × × H L L L × × × × L H H Hmaintain maintain maintain
Note 1: × indicates the display is not affected by voltage level of H or L.
Note 2: *A decimal point is displayed with any character.
Note 3: The 2-color alternate does not have the LT terminal.
(2-color Alternate Unit)
The display color is switched between red and green using the R/G (No. 6) terminal.
For other inputs, refer to the above table.
The 2-color alternate unit does not have an LT terminal.
Decimal/Hexadecimal/Extra Decimal
R/G Input Display Color
Positive Logic Negative Logic
L H Red
H L Green
Input Functions
A, B, C, and D (binary code) Inputs
These inputs are decimal or data
corresponding to 1, 2, 4, and 8,
respectively.
Latch Input
When the Latch input is set to level H
for the positive logic or level L for the
negative logic, the display at the time is
maintained. (DP input is independent.)
LT (Light Test) Input
When the LT input is set to level H for the
positive logic or level L for the negative
logic, the entire display turns on.
BL (Blank) Input
When the BL input is set to level H
for the positive logic or level L for the
negative logic, the entire display turns off
regardless of other inputs.
DP (Decimal Point) Input
When the DP input is set to level H for the
positive logic or level L for the negative
logic, the decimal point turns on.

9
DD3S Series Display Units
(Zero-suppress Unit)
Leading zeros are suppressed using the RBI (No. 1) and RBO (No. 11) terminals. For other
inputs, see the lower table on the preceding page.
Decimal/Hexadecimal/Extra Decimal
Data Input LED
Display
Positive Logic Negative Logic
X Latch LT BL DP RBI RBO YLatch LT BL DP RBI RBO
× × H × × × # × × L × × × & 8.
× × L H × × # × × H L × × & blank
H L L L L L L H H H H H L L blank
H L L L L H H H H H H H H H 0
H L L L H L H H H H H L L H 0.
L L L L L L H L H H H H L H *
X: X = A · B · C · D *: Any display
Y:Y=A·B·C·D #:# = DP · RBI · X
×: Either H or L &: & = DP · RBI·Y
Note: RBI and RBO operate in the negative logic mode on both positive and negative logic units.
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
RBI RBO
1st Digit2nd Digit3rd Digit4th Digit
[Ex. 1]
[
Ex. 2]
[
Ex. 3]
[
Ex. 4]
L or
H
L or
H
DP
DP
Application Examples of RBI and RBO
[Ex.1] Leading zeros are also displayed. RBI and RBO outputs are
disconnected.
[Ex.2] Leading zeros on the upper three digits are suppressed. When the data
on the 1st digit is zero, 0 is displayed.
[Ex.3] Zero on the 4th digit is suppressed. Zero and decimal point are
displayed on the 3rd digit.
[Ex.4] Trailing zeros on the 2nd and 1st digits are suppressed. When the data
on the 1st and 4th digits are zero, and the decimal point on the 4th digit
is on, 0.0 is displayed with zeros on the 2nd and 1st digits suppressed.
Note: Use the RBO output only for connection to the RBI input. Do not use the RBO for
other connections.
Input and Output Functions
RBI Input
When 0 is displayed and the decimal
point is turned off, the display is
blanked by setting the RBI input to
level L.
RBO Output
The RBO output remains in level L
during zero blanking. Leading zeros
can be suppressed by connecting the
RBO to the RBI on the lower digits.
The RBO output is an open collector output.
(Character Display Unit)
Data Input
LED
Display
Positive Logic Negative Logic
D0 to D7 Latch BL D0 to D7 Latch BL
∆ L L ∆ H H ∆ (Note1)
× × H × × L blank
× H × × L × maintain
(Note3)
Note 1: Refer to the character display patterns on the next page.
Note 2: Display is not affected whether × is level H or L.
Note 3: Data (D0 to D7) immediately before the Latch signal is input is maintained.
Input Functions
Latch Input
When the Latch Input is set to level H
for the positive logic or level L for the
negative logic, the display at the time
is maintained.
BL (Blank) Input
When the BL input is set to level H
for the positive logic or level L for the
negative logic, the entire display turns
off regardless of other inputs.

10
DD3S Series Display Units
Display Patterns of the Character Display Unit
D7, D6, D5, D4 (High-bit data)
Data Input
1: Level H
0: Level L
0123456789ABCD
EF
1111
0000
1110
0001
1101
0010
1100
0011
1011
0100
1010
0101
1001
0110
1000
0111
0111
1000
0110
1001
0101
1010
0100
1011
0011
1100
0010
1101
0001
1110
0000
1111
Positive
Logic
Negative
Logic
0
0000
1111
1
0001
1110
2
0010
1101
3
0011
1100
4
0100
1011
5
0101
1010
6
0110
1001
7
0111
1000
8
1000
0111
9
1001
0110
A
1010
0101
B
1011
0100
C
1100
0011
D
1101
0010
E
1110
0001
F
1111
0000
(Low-bit data)
D3, D2, D1,
D0
Note: 8-bit codes for Roman and katakana characters conforming to JIS X0201 (former C6220)

11
DD3S Series Display Units
IGHT
6.5 2020 20 20 6.5
20N + 13
33 30
10
423.5
End Plate
Binary
Display Unit
Dec/Hex
Display Unit
Character Display Unit
Spacer Unit
DD9Z-FY1-8
Panel Thickness 0.8 to 4
Display units can be combined
for up to 8 digits.
6.5
0
+0.5
+0.5
0
20N + 10.5 3.5 min.
30.516 min.
(when mounting
more than 8 units)
(21 min.∗)
N = No. of digits (N ≤ 8)
∗
When using a static mother board
Panel Cut-out
For Connector Wiring
For Use of Dynamic Mother Board
Dimensions & Panel Cut-out All dimensions in mm.
2-
color Standard No.
F3** F01** F3**
GND
NC
A
D
LAT
BL
R/G
C
Vcc
B
DP
NC
GND
NC
+
-
LAT
BL
LT
1
Vcc
NC
DP
NC
GND
NC
A
D
LAT
BL
LT
C
Vcc
B
DP
NC
12
11
10
9
8
7
6
5
4
3
2
1
Terminal Arrangement
by Models
UP
DMC-2
11.3
(45.5)
1.6
1.5
4.5
13.5
(26.9)
Connector for Data Input
Screw
Spacer
Nut
DD3S
Housing
Connector
Spacer
DD3S Housing
PC Board
Nut
(M2.6)
Screw M2.6 × 18
1
2
3
4
5
6
7
8
9
10
11
12
(10 )(
10 )( 10 )( 10 )
0
321
13
20 20 20
10 6
14
39 45
12-ø3.2 (for mounting mother board)
3-ø2.8 (for securing DD3S)
78 (Note)
Note: 38 mm for 2-digit mother board DD9Z-MB1-2
Dynamic Mother Board (not applicable to zero-suppress)
4-digit: DD9Z-MB1-4
2-digit: DD9Z-MB1-2
Note: The DD3S housing can be secured to the mother board using screws.
Recommended tightening torque is 3.5 N·m at the maximum. When
no spacer is used, the tightening torque must not exceed 2 N·m.
Substrate: Glass epoxy, 1.6-mm
thick
Screws (M2.6 × 18), M2.6-3 nuts, and spacers are supplied with
the mother board.
(Top View)
11*
B
D <–>
Latch (101 )
Latch (103 )
7*(101 )
7*(103 )
DP (100 )
DP (102 )
Vcc
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
GND
<+> A
<1> C
Latch (100 )
Latch (102 )
7*(100 )
7*(102 )
6*
DP (101 )
DP (103 )
For 4-digit
Input Terminal Arrangement
(Top View)
11*
B
D <–>
Latch (101 )
NC
7*(101 )
NC
DP (100 )
NC
Vcc
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
GND
<+> A
<1> C
Latch (100 )
NC
7*(100 )
NC
6*
DP (101 )
NC
For 2-digit
Numbers marked with *are the DD3S terminal numbers.
IGHT
33 45
6
11.3
42
45.
55
Applicable Wire: ø0.8mm maximum
AWG #22 maximum
0.6
12-ø1 Holes
411.3
2
2.5 × 11
20
Applicable PC board thickness: 1.6
DD9Z-CN1
UP
2
1
4
35
6
7
8
9
10
11
12
35
1.55 1.7 6.813.1
33
6
5
13.5
1.6
13
27.8
(min25)
Accessories (Optional)
Connector
Solder Terminal Connector PC Board Terminal Connector Retentive/One-way Insertion Connector
(DMC-1) (DMC-2) (DD9Z-CN1) (Note)
Note: Use DD9Z-CN1 in combination with DD9Z-ST1 connector
stopper.

12
DD3S Series Display Units
(10 )(10 )(
10 )( 10 )
1
2
3
4
5
6
7
8
9
0
10
11
12
DP(10 )DP(10 )
321
1
3
DP(10 )
2
39
22.5
50
7
20 20 20
13
14
5.8
78
2.8
4-ø3.2 (for mounting mother board)
3-ø2.8 (for securing DD3S)
<+>
<1>
<
- >
<
- >< - >
<
- >
<+>A
B
C
D
A
B
C
D
A
B
C
D
A
B
C
D
GND
Vcc
GND
Vcc
(TOP VIEW)
(+)
(–)
GND Vcc Latch
1
2
3
4
5
6
7
8
9
10
11
12
NC
DP
B
Vcc
C
LT
BL
D
A
NC
GND
NC
DP
NC
Vcc
1
LT
BL
NC
GND
F3** F3**F01*
NC
DP
B
Vcc
C
R/G
BL
D
A
NC
GND
2-color Standard
LATLAT LAT
No.
<1>
(7) (6) (11)
<+>
<1>
<+>
<1>
10
10
1
2
3
4
56
7
8
9
10
11
12
1314
1516
1718
19
20
123456
0
1
10
10
2
3
+
−
Input Terminal Arrangement
Decimal Point Jumper
Negative
Logic Positive
Logic
(For all 4 digits)
Terminal Arrangement
by Models
4-digit
39
22.5
50
7
20
58
20 14
13 5.8
2.8
2-ø2.8 (for securing DD3S)
1
2
3
4
5
6
7
8
9
10
11
12
DP(10 )
1
DP(10 )
2
(10 )(10 )(
10 )0
21
<+>
<1>
<+>A
B
C
D
A
B
C
D
A
B
C
D
GND
Vcc
NC
Vcc
(TOP VIEW)
GND Vcc Latch
1
2
3
4
5
6
7
8
9
10
11
12
NC
DP
B
Vcc
C
LT
BL
D
A
NC
GND
NC
DP
NC
Vcc
1
LT
BL
NC
GND
NC
DP
B
Vcc
C
R/G
BL
D
A
NC
GND
LATLAT LAT
<1>
(7) (6) (11)
<+>
<1> 10
10
10
GND
NC
NC
NC
1
2
34
56
7
8
9
10
1112
13
14
15
16
17
18
19
20
123456
2
0
1
< - >
<
- >
<
- >
+
−
No.
(+)
(–)
Input Terminal Arrangement
Decimal Point Jumper
Negative
Logic Positive
Logic
(For all 3 digits)
F3** F3**F01*
2-color Standard
Terminal Arrangement
by Models
3-digit
(10 )(10 )
1
01
39
22.5
50
7
13
20 14
38
5.8
2.8
1
2
3
4
5
6
7
8
9
10
11
12
ø2.8 (for securing DD3S)
Jumper pin for (10¹)
decimal point
Jumper pin for selection
of terminal block 2
(6)
(7)
<+>
<
- >
<
- >
<
- >
<1>
<+>A
B
C
D
A
B
C
D
GND
Vcc
NC
Vcc
(TOP VIEW)
Latch (6) or (7) (11)
1
2
3
4
5
6
7
8
9
10
11
12
NC
DP
B
Vcc
C
LT
BL
D
A
NC
GND
NC
DP
NC
Vcc
1
LT
BL
NC
GND
NC
DP
B
Vcc
C
R/G
BL
D
A
NC
GND
LATLAT LAT
<1>
10
10
GND
NC
NC
NC
NC
NC
NC
NC
1
2
3
4
5
6
7
8
910
1112
13
14
1516
1718
1920
123
0
1
+
−
No.
(+)
(–)
Decimal Point
Jumper
Terminal 6 or 7 Selection
Jumper (Note 1)
DD3S
Terminal
No. 7
Negative
Logic Positive
Logic
(For all 2 digits)
DD3S
Terminal
No. 6
F3** F3**F01*
2-color Standard
Terminal Arrangement
by Models
Input Terminal Arrangement
2-digit
Note 1: For Terminal No. 2 on the mother board terminal block, select internal
connection to terminal No. 6 or 7 on the DD3S using a jumper.
•Numbers shown in ( ) for the input terminals represent the DD3S terminal numbers.
•A decimal point for the 2nd and the upper digits can be turned on using a jumper.
Note positive and negative logic when using a jumper.
•For terminal No. 2 on terminal block used for 2-digit, select internal connection to
terminal No. 6 or 7 on DD3S using a jumper.
UP
DMC-2
11.3
(45.5)
1.6 (26.9)
13.5
4.5
1.5
Terminal Block for Data Input
Screw
Connector for Data Input
Spacer
Decimal Point Jumper Pin
Nut
DD3S
Housing
Decimal Point Jumper Socket
Connector
Spacer
DD3S Housing
PC Board
Nut
(M2.6)
Screw M2.6 × 18
Static Mother Board (not applicable to zero-suppress)
4-digit: DD9Z-MB2-4
3-digit: DD9Z-MB2-3
2-digit: DD9Z-MB2-2 Note: The DD3S housing can be secured to the mother board
using screws. Recommended tightening torque is 0.35
N·m at the maximum. When no spacer is used, the
tightening torque must not exceed 0.2 N·m.
Screws (M2.6 × 18), M2.6 nuts, and spacers are supplied
with the mother board.

13
DD3S Series Display Units
6.5
33
20N
20
20N + 8M + 20
88M
8
5.5
End plate
DGNW
DD9Z-FG1R-B
Coupling Spacer for right side
20
5.5
33
8
8M
20N + 8M + 20
8 20N 6.5
DD9Z-FG1L-B
Coupling Spacer for left side
30.5 +0.5
0
(DGNW-1)
20N + 8M + 15.5
+0.5
20N + 8M + 17.5 (DGNW-2)
+0.5
0
0
Coupling Spacer
For using DD3S series Display Units and the IDEC DGAN/DGBN
series Digital Switches in combination, coupling spacers (two
types: for right side and left side) are available.
Coupling Spacer for Right Side (DD9Z-FG1R-B)
DD3S series Display Units
DG series
Digital Switches
Note: The above photo shows the spacer for right side.
Coupling Spacer
Coupling Spacer for Left Side (DD9Z-FG1L-B)
Panel Cutout
N: Number of display units
mounted
M: Number of digital switches
mounted (N + M ≤ 8)
Screw
Connector for Data Input
Spacer
1.
5
4.5
13.5
1.6
11.3
UP
DMC-2
(26.9)
Power Supply
Terminal
Hexagonal Nut
3-ø2.8 (for securing DD3S)
Spacer
DD3S
Housing
12-ø3.2 (for mounting Mother Board)
Vcc
GND
Vcc
Vcc
GND
GND
12
12
34
56
78
910
11 12
13 14
15 16
17 18
19
20
(TOP VIEW)
8.013.53.0
7.0
D7
D6
D5
D4
D3
D2
D1
D0
BL (100)
BL (101)
BL (102)
BL (103)
Latch (100)
Latch (101)
Latch (102)
Latch (103)
20 142020
78
6
50 45 39
13
12
11
10
9
8
7
6
5
4
3
2
1
(103)(102)(101)(100)
5 × 7 Dot Matrix Mother Board (with spacer)
(DD9Z-MB3-4) Substrate: Glass epoxy, 1.6-mm thick
Note: Recommended tightening torque: 0.35 N.m maximum
When the spacer is not used, tightening torque must not
exceed 0.2 N.m.
*Screws (M2.6 ×5), M2.6 nuts, and spacers are supplied with the mother
board.
Spacer DimensionsInput Terminal Arrangement

14
DD3S Series Display Units
Connectors for Mother Board
Three types of connectors (with cable) are available for both dynamic and static mother boards. The connector on the mother board has a
strain relief to protect the insulation displacement connection from external force.
For Connection to Connector Header
±0.2
±0.2
29.97
14 0.38
7
5.6
15.9
3.6
3.81 1.27
2.54
22.86
6
2.54
Marking
20 19
18 17
16 15
14 13
12 11
10 9
8 7
6 5
4 3
2 1
20 19
18 17
16 15
14 13
12 11
10 9
8 7
6 5
4 3
2 1
[Input Side Connector]
MIL at cable connector (with strain relief)
IDEC’s JE1S-201 (with strain relief)
Dimensions Applicable Connector Header
IDEC’s JE1H-201 (Right Angle)
IDEC’s JE1H-202 (Straight)
DD9Z-JE1B
Gray Cable Input Side
Connector
Data Input
Connector
Cable
Marking Marking
L
Mother Board
Mother Board
For Soldering Connection to PC Board, or Others
Note: Specify a cable length code in place of in the Part No.
(01: 100 mm, 02: 200 mm, 03: 300 mm, 05: 500 mm, 10: 1000 mm, 15: 1500 mm, 20: 2000 mm, 30: 3000 mm, 40: 4000 mm, 50: 5000 mm)
1.27
24.13
25.40
0.89
20 19
18 17
Black
White
Gray
Purple
Blue
Green
Yellow
Orange
Red
Brown
Black
White
Gray
Purple
Blue
Green
Yellow
Orange
Red
Brown
16 15
14 13
12 11
10 9
8 7
6 5
4 3
2 1
[Input Side Connector]
Not provided.
Flat Cable
Material
Conductor AWG28 (7 cores/0.127 mm)
Tinned annealed copper wire
Insulator Heat-resisting vinyl
DD9Z-JE1C
Data Input
Connector
Cable
Marking
Color-coded
Cable
L
Mother Board
Mother Board
For Direct Connection to PC Board
31.86
119
7
0.53.5
0.5 0.3
2.54
2.54
22.86
31.86
Marking
4 kink pins
each on
both sides
Marking
ø0.8 min.
-
0.08
- 0.08
2.54
22.86
2.54
20 19
18 17
16 15
14 13
12 11
10 9
8 7
6 5
4 3
2 1
20 19
18 17
16 15
14 13
12 11
10 9
8 7
6 5
4 3
2 1
[Input Side Connector]
Flat cable connector for direct connection to PC board
Dimensions PC Board Drilling Layout
Gray Cable
Input Side
Connector
Data Input
Connector
Cable
Marking
Marking
L
Mother Board
Mother Board
DD9Z-JE1A

15
DD3S Series Display Units
OUT B0
OUT B1
OUT B2
OUT B3
OUT B4
OUT B5
OUT B6
OUT B7
COM (0V)
+V
B (10 )
C (10 )
D (10 )
(+)
(+)
(
- )
( - )
(+)
(
- )
A (10 )
PLC
Transistor Output
10 101010
+V
OUT A0
OUT A1
OUT A2
OUT A3
OUT A4
OUT A5
OUT A6
OUT A7
COM (0V)
C (10 )
D (10 )
B (10 )
A (10 )
D (10 )
C (10 )
B (10 )
A (10 )
A (10 )
B (10 )
C (10 )
D (10 )
0
3
3
12 to 24V DC
Power Supply
0
30
1
2
0
0
2
2
2
2
3
3
1
1
1
1
D C B A D C B A D C B A D C B A
Latch Latch Latch Latch
++++ ----
Static Type Mother Board
OUT C0
OUT C1
OUT C2
OUT C3
OUT C4
OUT C5
OUT C6
OUT C7
COM (0V)
+V
B (10 )
A (10 )
10
+V
OUT A0
OUT A1
OUT A2
OUT A3
OUT A4
OUT A5
OUT A6
OUT A7
COM (0V)
C (10 )
D (10 )
A (10 )
B (10 )
C (10 )
D (10 )
OUT B0
OUT B1
OUT B2
OUT B3
OUT B4
OUT B5
OUT B6
OUT B7
COM (0V)
+V
C (10 )
D (10 )
B (10 )
A (10 )
D (10 )
C (10 )
B (10 )
A (10 )
10 101010 10 10
0
0
0
0
0
1
1
1
1
3
3
3
2
2
2
2
3
3 124
5
6
D C B A D C B A D C B A D C B A D C B A D C B A D C B A
Latch Latch Latch Latch Latch Latch Latch
+
+++
−−−−−−−
+++
PLC
Transistor Output
(+)
(+)
(
- )
(
- )
(+)
(
- )
(+)
(
- )
12 to 24V DC
Power Supply
Static Type Mother Board Static Type Mother Board
Common to set 1
Common to set 2
Latch
Latch
Wiring Diagrams
Static Mother Board Connection (2 to 4 digits)
16-point Bus Connection (5 to 8 digits, multiple latch sets)

16
DD3S Series Display Units
OUT 0
OUT 1
OUT 2
OUT 3
OUT 4
OUT 5
OUT 6
OUT 7
COM (0V)
+V
10
Latch (10 )
Latch (10 )
Latch (10 )
A
B
C
D
Latch (10 )
101010
3
1
2
3
0
0
12
D C B A D C B A D C B A D C B A
Latch Latch Latch Latch
+
−−−−
+++
(+)
(
- )
(+)
(
- )
PLC
Transistor Output
12 to 24V DC
Dynamic Type Mother Board
Power Supply
OUT B0
OUT B1
OUT B2
OUT B3
OUT B4
OUT B5
OUT B6
OUT B7
COM (0V)
+V
10
Latch (10 )
Latch (10 )
Latch (10 )
A
B
C
D
Latch (10 )
1010
+V
OUT A0
OUT A1
OUT A2
OUT A3
OUT A4
OUT A5
OUT A6
OUT A7
COM (0V)
10 10 10
Latch (10 )
Latch (10 )
5
4
1
0
5
34210
3
2
D C B A D C B A D C B A D C B A D C B A D C B A
Latch Latch Latch Latch Latch Latch
+
−− −−−−
+++++
(+)
(+)
(
- )
(
- )
(+)
( - )
PLC
Transistor Output
12 to 24V DC
Dynamic Type Mother Board
Power Supply
Dynamic Connection (2 to 4 digits)
Dynamic Connection (5 to 8 digits)

17
DD3S Series Display Units
Data
Input
D0 (H)
(L)
(H)
(L)
(H)
(L)
(H)
(L)
(H)
(L)
(H)
(L)
(H)
(L)
(H)
(L)
(H)
(L)
D1
D2
D3
D4
D5
D6
D7
Latch Input
Display Character
Maintains display
Maintains display
“1” “2” “3” “4” “5” “6” “7” “8” “9”
“1” “2” “5” “6” “8”
“9”
Data Input
(D0 to D7)
Latch Input
(Positive Logic)
Latch Input
(Negative Logic)
Maintain
T1 T2 T3
Maintain
Maintain
Maintain
T1 ≥ 0 ms
T2 ≥ 1 ms
T3 ≥ 1 ms
[Character Display Unit]
Latch Operation (Positive Logic)
Latch Input Timing Chart
Note 1: The above chart represents positive logic units. Negative logic units
have characteristics with (H) and (L) reserved.
Note 2: The rise and fall times of input pulses should be made as short as
possible. (0.1 ms maximum)
Note 3: If the data input is changed in the period of T2, the display will
change.
(H)
(L)
(H)
(L)
(H)
(L)
(H)
(L)
(H)
(L)
A
B
C
D
Binary-
Coded
Input
Latch Input
Maintains display
Display Character
“1” “2” “3” “4” “5” “6” “7” “8” “9”
“1” “2” “5” “6” “8” “9”
Maintains
display
Data Input
Latch Input T1 ≥ 0 ms
T2 ≥ 1 ms
T3 ≥ 1 ms
(H)
(L)
Maintain Data is
read. Maintain
T1 T2 T3
Binary-Coded
Input
(Data Input)
4th
Digit
(H)
(L)
(H)
(L)
(H)
(L)
(H)
(L)
3rd
Digit
2nd
Digit
1st
Digit
“4”
4th Digit
Data
“7”
3rd Digit
Data
“5”
2nd Digit
Data
“2”
1st Digit
Data
Latch
Input
Maintain Maintain
Maintain Maintain
Maintain Maintain
Maintain Maintain
ABCD ABCD ABCD ABCD
ABC D
Display
(Example)
Display Unit
4th Digit 3rd Digit 2nd Digit 1st Digit
4th Digit 3rd Digit 2nd Digit 1st Digit
(Block Diagram)
Latch Latch Latch Latch
Binary-Coded Input
(Data Input)
(Latch Input)
1st
4th
3rd 2nd
Latch Input
[Binary/Decimal/Hex/Extra Decimal Display Units]
Latch Operation (Positive Logic)
Latch Input Timing Chart
Note 1: The above chart represents positive logic units. Negative logic units
have characteristics with (H) and (L) reserved.
Note 2: The rise and fall times of input pulses should be made as short as
possible. (0.1 ms maximum)
Note 3: If the data input is changed in the period of T2, the display will
change.
Application of Latch Function

18
DD3S Series Display Units
Mother
Board
PC Board Connector
Up
Down
Unit Combination
Display units and end plates can be combined together by snap
t. Connection bolts and nuts are not required.
End Plate
Connector (optional)
DMC-1
DMC-2
DD9Z-CN1
End Plate
DD9Z-W-
(pair)
Panel Mounting
Display units can be installed into a panel cut-out by snap t.
Assemble display units and end plates together in advance. Hold
the assembly at the end plates and push it into a panel cut-out.
Mother Board (for 4-digit display)
The mother board is intended for 4-digit display and must be
connected to four display units at once. Therefore, mount or
dismount the mother board properly according to the procedure
below.
[Installation]
Put the substrates of four display
units into the connectors on the
mother board. Insert the substrates
into the connectors, pushing the
display units on upper and lower
sides alternately.
Note: Be sure to insert four display
units at once.
[Removal]
Remove the display units, pulling the
upper and lower sides alternately. Be
sure to remove all the four units at the
same time.
CAUTION:
Never insert or remove the display
units one by one as shown. The
substrate may be damaged.
Note: For installation of the mother
board for 2-digit and 3-digit
display, perform the same
procedure.
Instructions
1. When cleaning the surface of the lter and housing, use a soft
cloth. Do not use thinner or acid to clean the surface.
2. When the display unit is mounted in a panel cut-out, do not
place a metal object or power line within 40 mm from the end
of the connector terminals (or PC board terminals) at the rear
of the display unit.
3. If the display units are subjected to voltage surges, install a
surge suppressor in the power line.
4. Use shielded cable or metal conduit for the input line. Run the
input wiring as far away as possible from high-voltage and
motor lines. Make the input line as short as possible.
5. When using display units in environments where a large
amount of electrostatic noise is generated, such as where
molding materials, powders, or uids are transferred through
pipe lines, keep the display units as far away as possible from
electrostatic sources.
6. Avoid using the display unit in a place where excessive and
frequent vibration or impact may occur.
7. Avoid using the display unit in a place where it is exposed to
corrosive gas, water or oil splashes, dust or direct sunlight, or
in a place where organic solvents are used.
8. The lter is made of polycarbonate. Make sure that machine oil
does not touch the lter.
9. If the Latch input is on when the DD3S is powered up, the
data input cannot be read correctly or wrong data may be
maintained. Do not turn on the Latch input for 0.5 sec after the
DD3S is powered up.
10. When connecting a pull-up or pull-down resistor to the input
terminals, ensure compatibility with the input resistor of the
DD3S internal circuit.
11. When the DD3S is powered up, an inrush current of 2A (10
ms maximum) ows through the internal power supply circuit.
Select an external power supply of sufcient capacity, taking
this inrush current into consideration.
12. Solder the terminal at 350°C within 3 seconds using a 60W
soldering iron. Sn-Ag-Cu is recommended when using lead-
free solder. When soldering, do not touch the control unit with
the soldering iron. Also ensure that no tensile force is applied
to the terminal. Do not bend the terminal or apply excessive
force to the terminal. Use a non-corrosive rosin ux.

19
DD48 Series Display Units
Modular units can be combined for up to 16 digits.
•Super bright LED
•Units can be combined together and installed into a panel
cut-out by snap t.
•Binary and decimal display units are available.
•Easy wiring and maintenance
•LED display color: red or green
•Decimal display units are available with zero suppression
function.
•Available in positive and negative input logic types.
DD48
Unit Input
Logic
Housing
Color Part No.
Binary
Display
Positive Black DD48-F01PB *DC24
Beige DD48-F01PZ *DC24
Negative Black DD48-F01NB *DC24
Beige DD48-F01NZ *DC24
Decimal
Display
Positive Black DD48-F31PB *DC24
Beige DD48-F31PZ *DC24
Negative Black DD48-F31NB *DC24
Beige DD48-F31NZ *DC24
Note: Specify the LED color code in place of * in the Part No.
MR: red, R: red (super bright), G: green
Accessories (Optional)
Name Part No.
Spacer Unit Black DD48-FY1-B
End Plate (Pair) Black DD48-W-B
Beige DD48-W-Z
Mounting Clip
(Note 1) Black DD48-KT1
Long Filter For red LED DD48-P16R
For green LED DD48-P16G
Connector Solder Terminal DMC-4
PC Board Terminal DMC-5
Mother Board
for 4 digits (with
connectors)
Binary/Decimal/
Character Display DD48-MB1-4
Connector for
Mother Board
Type A DD48-JE1A (Note 2)
Type B DD48-JE1B (Note 2)
Type C DD48-JE1C (Note 2)
Note 1: Used for mounting four units or more.
Note 2: Specify a cable length code in place of in the Part No.,
referring to the table below.
Cable Length Code for Mother Board
Code 0.5 1 2 3 4 5
Cable Length (mm) 500 1000 2000 3000 4000 5000
Note: Input connector types
DD48-JE1A: Flat cable connector for direct mounting on
PC boards
DD48-JE1B: Flat cable connector conforming to MIL
Standard
DD48-JE1C: None (soldering, etc)
Specications
Power Voltage 24V DC ±10%
Power Consumption
(Approx.)
Binary: 0.9W
Decimal: 2.0W
Operating Temperature –10 to +55°C (no freezing)
Storage Temperature –25 to +80°C (no freezing)
Operating Humidity 35 to 85% RH (no condensation)
Data Input L: 0 to 2V
H: 12 to 30V
Display Character
•Binary display unit
red or green LED display: –
•Decimal display unit
7-segment red or green LED:
0 to 9, decimal point
Character Height
(Approx.)
•Binary display unit: 2.5 mm
•Decimal display unit: 25.4 mm
Input
•Binary display unit:
–, Latch, and Blank inputs
•Decimal display unit:
Binary-coded, Latch, DP, and RBI
inputs
Output •Decimal display unit: RBO output
Input Logic Positive or negative
No. of Digits 16 digits max.
Unit Combination Snap t
Panel Mounting Snap t
Degree of Protection IP40 (IEC 60529)
Weight (Approx.) Display unit: 50g
End plates: 20g (pair)
Note: It is recommended to use a long lter when combining 9 to
16 digits.

20
DD48 Series Display Units
Terminal Connection
Connection Diagram Terminal Arrangement Internal Input Circuit
Binary Display Unit
Positive Logic
200 kΩ
200 kΩ
12 kΩ
Data Input
GND
Negative Logic
200 kΩ
200 kΩ
12 kΩ
Data Input
GND
24V DC
Decimal Display Unit
(Name) (Terminal No.)
Power
Vcc
GND
BL
(–)
Latch
19
1
7
9
11
Regulating Circuit
Decoder
Input Circuit
Vcc
NC
NC
NC
(−)
Latch
BL
NC
NC
GND
24V DC
19
17
15
13
11
9
7
5
3
1
-
(Name)(Terminal No.)
+
Vcc
GND
19
1
9
17
15
13
11
7
5
3
Latch
A(2 )
B(2 )
C(2 )
D(2 )
DP
RBI
RBO
0
1
2
3
(Name) (Terminal No.)
Power
Data
Input
Regulating
Circuit
Decoder
Input Circuit
Vcc
A (2 )
Latch
DP
RBI
RBO
GND
24V DC
19
17
15
13
11
9
7
5
3
1
0
B (2 )
1
C (2 )
2
D (2 )
3
-
(Name)(Terminal No.)
+
Connector Terminal No.
(Binary/Decimal Display Unit Compatible)
Connector Terminal No.
UP marking side
Power
24V DC Power
24V DC 24V DC
Tr
R1
Tr
R1
+24V
Tr
R1
Tr
R1
+24V
Power
Decimal
Vcc(+)
A
D
NC
NC
LATCH
GND(—)
Vcc(+)
A
D
NC
NC
LATCH
GND(—)
Vcc(+)
A
D
NC
NC
LATCH
GND(—)
Decimal Decimal
Data
Input Data
Input
Data
Input
When Tr is on,
output goes to H.
When Tr is off,
output goes to H.
External Wiring
Positive Logic
[Contact Input (Digital Switch)] [Transistor Input]
Power Power
Power
Decimal Decimal Decimal
Data
Input
Data
Input
Data
Input
When Tr is on,
output goes to L.
When Tr is off,
output goes to L.
Negative Logic
[Contact Input (Digital Switch)] [Transistor Input]
Note: When connecting pull-up or pull-down resistors to
the external circuit, refer to the following table.
External
Power Supply
Type R1 R2
24V DC Binary/
Decimal
2.2 kΩ to 8.2 kΩ
(1/2W) (1/4W) 1 kΩ (1W)
