IMOUMLIVE GYQXJ User manual

We hope you love your pressure washer as much as we do
Questions or Concerns?
Contact IMOUMLIVE via [email protected]
Read all safety rules and instructions carefully before operating this tool.
Thank you for your purchase!
Cordless Pressure Washer
User Manual（Model:GYQXJ)

Catalog
Product Description
Installation Procedure and User Requirements
Instructions for faucet connectors
Cordless Pressure Washer use tips
Foam sprayer and nozzle usage instructions
Operation Precautions
Product component introduction
Battery charging information
Electrical Safety and Product Information
User Safety Warning!
Safety Precautions for Battery Packs
How to Clean Your Vehicle Quickly
Extend Your Warranty by 1 Year
Repair and Maintenance
Troubleshooting
EN.1
EN.1-3
EN.3-4
EN.5
EN.5-6
EN.6
EN.7
EN.7
EN.8
EN.9
EN.9-10
EN.10
EN.10
EN.11
EN.11

Product Description
Installation Procedure and User Requirements
Research and development, design, manufacture and product development of lithium
battery wireless handheld cleaning machine: Based on the principle of user experience
first and quality first, it is a custom-developed product for the majority of car enthusiasts
and home cleaning and cleaning, pursuing the advantages of convenience, speed,
portability and energy saving. Wireless products are not affected by the working radius
of the plug, and the battery is strong and stable , can be carried with you, suitable for
multi-scenario applications, saving power and saving you time and cleaning costs
anytime, anywhere. Its high efficiency will bring you DIY cleaning fun and quality experi-
ence.
Open the box and confirm that the machine and the corresponding model are in good
condition. Take out the accessories one by one and put them in the machine. Please
install and use according to the operating rules!
Warning: Please read the instructions carefully
before operating the pressure washer.
WARNING: DO NOT AIM THE SPRAY GUN AT HUMAN
BODY. OR SPRAY DIRECTLY ON LIVE EQUIPMENT.
Step 1:
As shown in the figure, insert the gun head correctly into the machine and rotate.
(Two-way force insert rotary tightening).
EN.1

Step 2:
As shown in the picture, first turn the lower knob in the indicated direction to loosen it,
then thread the hose through the lower knob and insert it into the upper interface,
finally tighten it in the indicated direction to complete the hose installation（The assem-
bly method for both ends of the hose interface is the same）.
Step 4:
Insert the water gun inlet into the hose interface as
shown in the picture, and you will hear a clicking
sound once the installation is completed.
Step 3:
1.Assemble the filter basket in the direction shown and insert it into the hose interface.
You will hear a clicking sound when the installation with the filter basket is completed.
2.To remove the filter basket, pull up the fixed part of the hose interface and pull down
the filter basket.
EN.2

Instructions for faucet connectors
Step 6:
As shown in the figure, insert the battery
pack into the machine correctly, and the
charging time is about 3 hours to be fully
charged, please do not overcharge).
Step 5:
To install the filter basket clip, insert the
squeezed hose into the clip (the clip can be fixed
to the wall of the water container to prevent the
filter basket from floating on the water surface).
Faucet Interface: In general, you will receive an assembled interface. If it is a dispersed
accessory, assemble it according to the instructions in the diagram.
(Note: Keep the two silicone circles in the interface properly to prevent water leakage
after connecting the water pipe!)
When the black and yellow interfaces are
combined, they can be used to connect a
faucet with a diameter of 3/4 inch
(19.05mm).
When the black and yellow interfaces are
separated, the yellow interface alone can
be used to connect a faucet with a
diameter of 1 inch (24.5mm).
EN.3

1.Taking this faucet as an example, some faucets require unscrewing their
own connectors before the conversion interface can be attached.
2.Choose the appropriate conversion interface based on the diameter of the
faucet, then screw it onto the faucet by rotating it in line with the threads.
(Note: When screwing, gently tighten it after aligning with the threads to avoid
overtightening and damaging the threads!)
3.Finally, insert the hose interface into the conversion interface until you hear
a clicking sound, indicating the installation is complete.
*Connect one end of the hose to
the faucet and the other end to
the inlet of the Cordless
Pressure Washer to complete
the installation.
After connecting to the faucet, you need to turn on the faucet switch to use it normally. When you turn on
the faucet switch, a small amount of water will come out of the pressure washer nozzle (this is normal!). It
means that the pressure washer hose and the machine are already filled with water, and you can proceed
with normal operation at this point.
*this is normal!
EN.4

Cordless Pressure Washer use tips
Foam sprayer and nozzle usage instructions
If you find that the water tap conversion adapter we provided does not match your
household water tap, you can use the method shown in the figure.
You can use a slightly larger bucket to collect the water from your garden faucet and
connect a cordless pressure washer with a filter basket to the bucket for water suction.
With both the faucet and the pressure washer working together, you can have a continu-
ous water supply! Your home faucet can be connected to the garden hose (length
depends on the length of your hose) to achieve long-distance cleaning operations!
Foam sprayer usage instructions: The foam sprayer is
mainly used to clean oil stains on cars. Before using the
sprayer, add one-third of the capacity of detergent to the
sprayer, and then insert it into the cleaning gun according
to the installation instructions (the foam volume of the
detergent can be adjusted by the knob above).
*The filter basket can draw water from any
outdoor water source and filter out impurities
on its own!
EN.5

Operation Precautions
1.The 1.0° nozzle is the strongest water pressure mode and is mainly used for cleaning
stubborn stains.
2. The 15° nozzle is the second strongest water pressure mode, with slightly less pres-
sure than 0° but a larger cleaning area, and can be used for cleaning walls or floors.
3. The 25° nozzle is the third strongest water pressure mode, with slightly less pressure
than 15° but a larger cleaning area, and can be used for washing cars.
4.The 40° nozzle is the fourth strongest water pressure mode, with slightly less pressure
than 25° but a larger cleaning area, and can be used for cleaning bicycles.
5.The Shower nozzle is a shower mode that can be used for watering plants and cleaning
windows.
6. Intermittent nozzles are used in intermittent mode to save water.
Instructions for use of the 6-in-1 nozzle:
1. After assembly, press and hold the trigger for 10 seconds to 15 seconds to empty
the air in the intake pipe (if there is still no water, check whether the intake port is
connected well or the intake pipe is full of water).
2. Do not use water guns on children and animals to avoid injury.
3. In winter, the water in the water pipe should be drained immediately to prevent
the water gun from freezing.
4. Due to excessive pressure, it is strictly forbidden for children to operate the car
wash water gun to avoid injury.
Note: 1. Nozzle needs to be inserted in the direction shown in the diagram, other-
wise it will affect the mode switching. 2. Make sure the nozzle is switched into
place during mode switching, otherwise water leakage may occur.
EN.6

Product component introduction
and battery charging information
Quick connector Nozzle with
detergent container
High/low
pressure button Trigger
Brushless Motor Water Intake Lithium battery
6-in-1 NOZZLE
Do not expose the battery to extreme conditions such as high temperature or shock.
Otherwise,it will cause personal injury due to the leakage of the electrolytic solution.
Before charging,check that the surface of the battery is clean and dry.
Before using for the first time,the battery needs to be fully charged.
After the battery is fully charged remove the charger plua from the outlet and remove
the battery from the charger.
Indicator Light
Red
Green Charging completed
Charging
Status
Charging the Battery with the Charger
Charging jack
EN.7

Electrical Safety
Product Information
Always check the voltage of the power supply corresponds to the voltage
on rating plate
Intended use
This equipment is suitable for gardening watering,shrub watering.Washing cars,Cleaning
boats,flushing stains,widely used in gardens,parks, farms,highways, pastures,
orchards,greenhouses.Anyother uses or modifications to the machine are deemed to be
improper usage and may result in serious physical injury.
The manufacturer accepts no responsibility for damages attributable to misuse.
Cordless Pressure Washer
Battery Pack
Model No
Power
Pumping capacity
Weight
GYQXJ
400W
6L/MIN
1.85KG
Technical Specifications
Battery Pack Type
Voltage
Capacity
Charging time
Working time
Li-Ion
21V
4.0AH 74Wh
3H
45MIN
EN.8

User Safety Warning!
Instructions
Safety Precautions for Battery Packs
Before using this product, please read the safety regulations and related safety warnings
carefully! The following signs and instructions can cause electric shock, fire or personal
injury! Be sure to keep the warning notes for unfamiliar operators! Hand-held lithium
battery cleaning machine use safety warning!
1. When using the machine, please ensure that it is the original machine and accessories
(charger and battery pack).
2. Avoid water flowing to people and live parts during use.
3. Make sure the battery pack is charged out of reach of children.
4. If the battery pack and charger are dropped, bumped or wet, please stop using them
immediately!
5. The battery pack must be charged under supervision.
6. The charger must be an original charger (other charging accessories or charging
methods are prohibited without authorization or as suggested by the original factory).
7. Do not charge in high temperature or unattended or within the reach of children.
8. Please check the charger, battery pack, and main unit of the Cordless Pressure Washer
regularly. If there is any abnormality, damage or failure, please do not modify or disas-
semble at will.
9. Batteries contain lithium. In order to protect the environment, used batteries should
be sorted and recycled, and should not be discarded at will!
10. Do not expose to water and fire (or near fire).
1. Do not disassemble, open or shred the battery pack.
2. Do not expose the battery pack to heat sources or high temperature sunlight.
3. Do not short-circuit the battery pack (connect the positive and negative poles), and do
not put the battery pack in the drawer of the box to avoid short-circuiting with other
batteries or other metal objects.
4. Do not remove the battery or battery pack from its original packaging before use.
5. Avoid dropping the battery pack or subjecting it to mechanical shock.
6. If the battery leaks, avoid direct contact with the leaked fluid on your eyes or skin. In
case of accidental contact, immediately rinse the contact area with water and seek
medical attention promptly.
7. Do not use non-original chargers and battery packs. (May cause machine failure or
unexpected personal injury)
8. Pay attention to the positive and negative symbols on the battery pack to ensure that
the connection is correct.
9. Keep the machine and battery pack away from children.
10. To purchase a matching battery pack or charger, you must purchase it according to
the manufacturer's instructions.
11. Ensure that the battery pack is clean and dry. (If there is dust or residual moisture,
please wipe it with a clean cloth or air dry immediately, do not use a hair dryer or heat
gun to dry it)
12.The battery pack must be charged before use, using the correct charger and referring
to the manufacturer's operating instructions or original equipment instructions.
13. Do not charge the battery pack for a long time when the machine is not in use. Note
that the green light is fully charged and the red light is charging.
14. The battery pack should undergo multiple charge/discharge cycles for optimum
performance when the machine is not in use for extended periods of time.
15. The battery pack has the best performance at room temperature (20℃+5℃).
16. This product is only suitable for cleaning home doors and windows, courtyards,
vehicles and gardens. Not intended for commercial or clocked mobile operation, must
not exceed battery life or high frequency forced use.
17. When the machine is not in use, remove the battery pack, disconnect it from the
main unit, and place it in a dry place out of the reach of children.
18. When the battery pack is damaged due to human error, collision, high temperature,
etc., it should be properly handled and restored. Do not discard it at will, so as not to
pollute the environment.
EN.9

1. Do not disassemble, open or shred the battery pack.
2. Do not expose the battery pack to heat sources or high temperature sunlight.
3. Do not short-circuit the battery pack (connect the positive and negative poles), and do
not put the battery pack in the drawer of the box to avoid short-circuiting with other
batteries or other metal objects.
4. Do not remove the battery or battery pack from its original packaging before use.
5. Avoid dropping the battery pack or subjecting it to mechanical shock.
6. If the battery leaks, avoid direct contact with the leaked fluid on your eyes or skin. In
case of accidental contact, immediately rinse the contact area with water and seek
medical attention promptly.
7. Do not use non-original chargers and battery packs. (May cause machine failure or
unexpected personal injury)
8. Pay attention to the positive and negative symbols on the battery pack to ensure that
the connection is correct.
9. Keep the machine and battery pack away from children.
10. To purchase a matching battery pack or charger, you must purchase it according to
the manufacturer's instructions.
11. Ensure that the battery pack is clean and dry. (If there is dust or residual moisture,
please wipe it with a clean cloth or air dry immediately, do not use a hair dryer or heat
gun to dry it)
12.The battery pack must be charged before use, using the correct charger and referring
to the manufacturer's operating instructions or original equipment instructions.
13. Do not charge the battery pack for a long time when the machine is not in use. Note
that the green light is fully charged and the red light is charging.
14. The battery pack should undergo multiple charge/discharge cycles for optimum
performance when the machine is not in use for extended periods of time.
15. The battery pack has the best performance at room temperature (20℃+5℃).
16. This product is only suitable for cleaning home doors and windows, courtyards,
vehicles and gardens. Not intended for commercial or clocked mobile operation, must
not exceed battery life or high frequency forced use.
17. When the machine is not in use, remove the battery pack, disconnect it from the
main unit, and place it in a dry place out of the reach of children.
18. When the battery pack is damaged due to human error, collision, high temperature,
etc., it should be properly handled and restored. Do not discard it at will, so as not to
pollute the environment.
Extend Your Warranty by 1 Year
Register your product within 14 days of purchase at www.imoum.com to extend your 1-year
warranty by an additional year.
How to Clean Your Vehicle Quickly
Wet the vehicle with a fan nozzle (spray from top to bottom), wash off the dust on the surface,
then use a high-pressure straight pipe to wash off the dirty parts such as thick soil, and use a
foaming pot to spray foam the entire body. Then use a car wash sponge to scrub
thevehicle .Finally, wash the vehicle with a car washer.
Car washing machine, the standard car washing time is 10-20 minutes, and the water is 25-40
liters (2-3 buckets of water).
EN.10

EN.11
Repair and Maintenance
1. Before each use, check the machine and parts for damage. If damaged, stop using the machine
immediately.
2. The intake pipe and filter must be cleaned after each use, and the bag must be stored to avoid
oxidation for future use.
3. After use, run the machine empty for a few seconds to drain the residual moisture inside the
machine, avoid oxidative dirt and weather freezing, and store it in a dry and cool place.
4. Waste disposal: Damaged accessories and packaging materials must be sorted, recycled and
marked.
5. In hot weather, do not store in the trunk of the car to avoid fire caused by high temperature.
Warning: Do not use chemical acids and muddy water, always use clean, impurity-free
water.
Troubleshooting
3. The connection between the inlet pipe
and the machine is faulty, or the intake
pipe is broken
1. The machine is too high from the water
surface
2. The filter is blocked by foreign matter
4. bending water inlet pipe
5. The pump was frozen due to the cold
weather
Check and replace air pipes
As low as 1.5 meters below the ground
Remove filter and clean
Straighten the intake pipe and reconnect
Reboot after defrosting
FAQ Cause Analysis Solutions
The machine does not
absorb water
Sudden increase of water
pressure or abnormal shape
of water
The battery pack does not
charge
A foreign object blocks the head of the
water gun
A mismatched or damaged charger
Prick the nozzle with a needle or
replace it with a new head
The machine won't start
1. No battery pack installed
1. There is air in the pump
2. The machine is in low voltage mode
1. The battery pack is out of battery
2. The gun head is blocked. Current
protection
Chemical acid source or assembly
reason
2. The battery pack is out of battery
3. Damaged battery pack
Reinstall
Charge or replace the battery pack with
a new one
Check that fittings and pipes are in
good condition
Normal at low pressure, no need to do
anything
Charge or replace the battery pack
Clean or replace the head
Avoid chemical liquids
Replace the supporting charger
Replace the battery pack
The pressure of the
machine is not continuous
Machine stops automati-
cally
Internal leakage

EU Responsible Person：C&E Connection E-Commerce (DE) GmbH
Address：Zum Linnegraben 20, 65933, Frankfurt am Main,Germany
E-mail：[email protected]
Brand: IMOUMLIVE
Product name: Cordless Pressure Washer
Model number: GYQXJ
WEEE-Reg.-Nr. DE 45049658
Manufacture: Chongqing Mouma Keji You Xian GongSi
Address: 4-1, 131Ha0, Tian Chi Da Dao, Ba Nan Qu, 401320,Chongqing, China
Contact Us:[email protected]
